KleenRite 36408C Product manual

MNL36408
C
Rev. 00 (07-02)
36408C
Carpet And Upholstery Cleaner
Model No.:
36408C–13gal Extractor
KLEENRITE
1122 MAPLE STREET
MADERA CA 93637 U.S.A.
FAX: [phone]
CUSTOMER SERVICE: 1-800-241-4865
Operator and Parts Manual
®

36406C(07-02)
2
Please fill out at
time of installation for future reference.
Model No.-_______________________________________
Install. Date-______________________________________
Serial No.-________________________________________
OPERATION
This manual is furnished with each new model. It
provides necessary operation and maintenance
instructions and an illustrated parts list.
Read this manual completely and understand the
machine before operating or servicing it.
Use the illustrated Parts Lists to order parts. Before
ordering parts or supplies, be sure to have your
machine model number and serial number handy.
Parts and supplies may be ordered by phone or mail
from any authorized parts and service center,
distributor or directly from Kleenrite.
This machine will provide excellent service. However,
the best results will be obtained at minimum costs if:
•The machine is operated with reasonable care.
•The machine is maintained regularly –per the
maintenance instructions provided.
•The machine is maintained with manufacturer
supplied or equivalent parts.
MACHINE DATA
©Kleenrite Printed in U.S.A.
Kleenrite is a registered United States trademark
TABLE OF CONTENTS
SAFETY PRECAUTIONS.............................. 3
MACHINE COMPONENTS............................ 4
MACHINE SETUP......................................... 4
MACHINE OPERATION ................................ 5
DRAINING TANKS........................................ 6
FREEZE PROTECTION ................................ 6
MACHINE MAINTENANCE ........................... 7
STORING MACHINE..................................... 7
RECOMMENDED STOCK ITEMS.................. 7
TROUBLE SHOOTING.................................. 8
SPECIFICATIONS ........................................ 9
ELECTRICAL DIAGRAM .............................. 10
PARTS LIST................................................. 11
OPTIONS ..................................................... 16
WARRANTY POLICY.................................... 19

36408C(07-02)3
OPERATION
SAFETY PRECAUTIONS
This machine is intended for commercial use. It is
designed to wet clean carpet and upholstery in a
indoor environment and is not constructed for any
other use. Use only recommended cleaning solutions
and accessory tools.
All operators must read, understand and practice the
following safety precautions.
The following safety-alert symbols are used throughout
this manual as indicated in their description:
WARNING: To warn of hazards or unsafe
practices which could result in severe personal
injury or death.
FOR SAFETY: To identify actions which must be
followed for safe operation of equipment.
The following information signals potentially dangerous
conditions to the operator or equipment.
FOR SAFETY:
1. Do not operate machine:
–Unless trained and authorized.
–Unless operator manual is read and
understood.
–In flammable or explosive areas.
–With damaged cord or plug.
–If not in proper operating condition.
–Unless cord is properly grounded.
–In outdoor areas.
–In standing water.
–With the use of an extension cord.
2. Before operating machine:
–Make sure all safety devices are in place
and operate properly.
3. When using machine:
–Do not run machine over cord.
–Do not pull machine by plug or cord.
–Do not pull cord around sharp edges or
corners.
–Do not unplug by pulling on cord.
–Do not stretch cord.
–Do not handle plugs with wet hands.
–Keep cord away from heated surfaces.
–Report machine damage or faulty operation
immediately.
–Follow mixing and handling instructions on
chemical containers.
–Connect hoses before turning on pump.
–Be sure chemicals are safe and non-toxic.
4. Before leaving or servicing machine:
–Turn off machine.
–Unplug cord from wall outlet.
5. When servicing machine:
–Unplug cord from wall outlet.
–Avoid moving parts. Do not wear loose
jackets, shirts, or sleeves.
–Use manufacturer supplied or approved
replacement parts.
WARNING: Hazardous Voltage. Shock or
electrocution can result. Always unplug machine
before servicing.
WARNING: Flammable materials can cause
an explosion or fire. Do not use flammable
materials in tank(s).
WARNING: Flammable materials or reactive
metals can cause an explosion or fire. Do not pick
up.
WARNING: Hot solutions up to 88°C (190°F).
Do not touch with any part of the body. Use
thermometer to gauge temperature.
WARNING: Contents of solution hoses may
be under pressure even after pump is off.
GROUNDING INSTRUCTIONS
Machine must be grounded. If it should
malfunction or breakdown, grounding provides a
path of least resistance for electrical current to
reduce the risk of electrical shock. This machine is
equipped with a cord having an equipment-
grounding connector and grounding plug. The
plug must be plugged into an appropriate outlet
that is properly installed in accordance with all
local codes and ordinances. Do not remove
ground pin; if missing, replace plug before use.
International models will have different cord ends.
GROUNDED OUTLET
(3 HOLE)
GROUNDING
PIN

36406C(07-02)
4
OPERATION
MACHINE COMPONENTS
1. Recovery Tank
2. Solution Tank (under lid)
3. Recovery Tank Lid
4. Solution Tank Lid
5. Vacuum Switch
6. Pump Switch
7. Heater “ON” Light
8. Preheat / Clean Switch
9. Power Cord Connector
10. Empty-Out Nozzle
11. Vacuum Hose Connector
12. Latches
13. Recovery Tank Drain
14. Solution Hose Connector
MACHINE SETUP
1. Carefully check carton for signs of damage.
Report damages at once to carrier. The machine
is shipped fully assembled and is ready for use.
2. Connect hoses and tool to be used (Figure1).
3. Using a clean bucket or hose, fill solution tank
with 49liters (13gallons) of hot water, 60°C
(140°F) maximum (Figure 2).
WARNING: Flammable materials can cause an
explosion or fire. Do not use flammable materials
in tank(s).
4. Add a recommended cleaning chemical.
FOR SAFETY: When using machine, follow
mixing and handling instructions on chemical
containers.
Fig. 1
Fig. 2
4
3
6
9
8
2
10
13
1
5
7
12
11
14

36408C(07-02)5
Fig. 7
OPERATION
ATTENTION: If using powdered cleaning
chemicals, mix prior to adding.
NOTE: If desired, water alone achieves excellent
cleaning results.
5. Plug machine’s power cord into grounded wall
outlet (Figure 3).
FOR SAFETY: Do not operate machine unless
cord is properly grounded.
FOR SAFETY: Do not operate machine with the
use of an extension cord.
6. Secure recovery and solution lidsin place. It is
important to secure both lids whenever vacuum is
turned on.
MACHINE OPERATION
FOR SAFETY: Do not operate machine unless
operator manual is read and understood.
PRE-OPERATION AND HEATING
1. Vacuum carpet and remove other debris with
standard vacuum.
2. Inspect power cord for damage.
3. Turn on preheater (Figure 4). Red light indicates
heater on. Once heat exchanger reaches 71° C
(160° F°), the pump will momentarily come on and
circulate the heated water into the solution tank.
CLEANING CARPETS
1. Place preheater switch in “Clean” position. Turn
on vacuum and pump switches (Figure 5).
2. Take carpet cleaning wand in hand and squeeze
valve trigger while moving the tool in short
forward and backward strokes. (Figure 6).
WHILE OPERATING
1. Overlap each path by 50 mm (2 in).
Warning: Flammable materials or reactive
metals can cause an explosion or fire. Do not
pick up.
2. Periodically check for excessive foam buildup in
recovery tank. Use a recommended foam control
solution to prevent vacuum motor damage.
ATTENTION: Excessive foam buildup will not
activate the float shut-off screen.
3. To clean heavily soiled areas, repeat cleaning
path from a different direction.
4. Empty recovery tank every time water is added to
solution tank.
CLEANING WITH ACCESSORY TOOLS
1. Connect accessory tool hoses to the couplers at
the end of the hoses already attached to the
machine. (Figure 7).
GROUNDED OUTLET
(3 hole)
GROUNDING
PIN
Fig. 3
Fig. 4
Fig. 6
Fig. 5

36406C(07-02)
6
OPERATION
2. Operate accessory tool as normal (Figure 8).
NOTE: Before cleaning upholstery, always check
cleaning instructions sewn in furniture by
manufacturer.
3. After cleaning, relieve water pressure from tool
before disconnecting hose. Squeeze trigger for
five seconds after turning switches off.
DRAINING TANKS
DRAINING RECOVERY TANK
1. Turn machine off.
2. Insert supplied 45°elbow in drain valve. Place a
bucket below it and slowly pull up on the handle
(Figure 9).
3. Rinse tank with clean water at the end of the day.
DRAINING SOLUTION TANK
1. Remove empty-out nozzle from its storage
bracket (Figure 10) and attach to end of solution
hose.
2. Place empty-out nozzle over a bucket and turn on
pump until all the solution has been pumped from
solution tank.
3. Replace empty-out nozzle to its storage location.
FREEZE PROTECTION
1. After draining solution tank as described in steps
one and two in the previous section (DRAINING
SOLUTION TANK), place empty-out nozzle in
end of vacuum hose and seal with hand
(Figure 11).
2. Turn on vacuum and pump for 15 seconds. This
will fill the pump and hoses with air and prevent
freezing.
3. Replace empty-out nozzle to its storage place.
Fig. 8
Fig. 9
Fig. 11
Fig. 10
Fig. 8

36408C(07-02)7
OPERATION
MACHINE MAINTENANCE
To keep machine in good working condition, simply
follow machine’s daily, weekly and monthly
maintenance procedures.
FOR SAFETY: When servicing machine, unplug
cord from wall outlet.
DAILY MAINTENANCE
(Every 4 Hours of Operation)
1. Empty and rinse out recovery tank thoroughly.
2. Remove float shut-off screen from recovery tank
and clean (Figure 12.)
3. When solution tank is empty, remove and clean
solution filter screen located in the bottom of the
solution tank.
4. Wipe off power cord and check for damage,
replace if necessary. Coil cord neatly after use.
5. Clean machine with an all purpose cleaner and
damp cloth.
WEEKLY MAINTENANCE
(Every 20 Hours of Operation)
1. Inspect vacuum hoses for holes and loose cuffs.
2. Inspect spray pattern for plugging. If plugged,
remove spray tips and soak them in acetic acid
solution for up to six hours. Do not use pointed
objects to unplug tips, damage will occur.
FOR SAFETY: When using machine, follow mixing
and handling instructions on chemical containers.
3. Inspect cord and cord grip for damage. Replace
immediately if damaged.
4. Lubricate metal shaft on recovery tank drain with
water resistant oil.
5. Lubricate female hose couplers with lightweight
oil.
MONTHLY MAINTENANCE
(Every 80 Hours of Operation)
1. Lubricate wheels with water resistant oil.
2. Inspect machine for water leaks and loose
hardware.
QUARTERLY MAINTENANCE
(Every250 hours of Operation)
Check vacuum motor for carbon brush wear. Replace
motor if worn to a length of 10mm (0.38”) or less.
STORING MACHINE
1. Before storing machine, be certain to drain and
rinse tanks of all water.
2. Store machine in a dry area in the upright position.
3. Open recovery tank lid to promote air circulation.
ATTENTION: Do not expose to rain. Store
indoors.
ATTENTION: If storing machine in freezing
temperatures, be sure that machine and solution
system are completely drained and dry.
RECOMMENDED STOCK ITEMS
Refer to Parts List section for recommended stock
items. Stock items are clearly identified with a bullet
preceding the parts description. See example below:
PART# DESCRIPTION QTY.
J-30. LID,DOME 1
•J-38GRANITE
TOP,SOLTANKROTOGRANITE 1
J-39.5GRANITE HANDLE,WASTETANK ROTOGRANI 1
J-39GRANITE WASTETANK,ROTOGRANITE 1
FIG. 12

36406C(07-02)
8
OPERATION
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
Faulty switches or wiring. Contact Service Center.
Faulty power cord. Contact Service Center.
Machine does not operate.
Building circuit breaker tripped. Reset Breaker.
Heater does not heat. Faulty switch or wiring. Contact service center.
Faulty switch or wiring. Contact Service Center.
Faulty solution pump motor. Contact Service Center.
Faulty pump head. Contact Service Center.
Trigger on wand not pulled. Pull Solution Trigger.
Solution pump does not operate.
Quick couplers not fully engaged. Connect quick couplers.
Loose or broken wiring. Contact Service Center.
Faulty vacuum switch. Contact Service Center.
Defective vacuum motor. Contact Service Center.
Vacuum motor does not
operate.
Worn carbon brushes. Contact Service Center.
Recovery tank drain valve open. Close valve.
Vacuum or solution lids loose. Tighten both lids.
Defective lid gasket(s).Replace gasket(s).
Clogged float shut-off screen. Remove recovery tank lid and clean
screen.
Loose vacuum hose connections. Secure cuffs to hose.
Poor solution pick-up.
Defective vacuum hose. Replace hose.
Plugged spray tips. Clean or replace tips.
Improper spray tip size or spray angle. Replace with proper tips.
Worn spray tips. Replace spray tips.
Solution tank low or empty. Refill solution tank.
Uneven or no spray.
Faulty solution pump. Contact Service Center.

36408C(07-02)9
OPERATION
SPECIFICATIONS
MACHINE DIMENSIONS
Model 36408C
LENGTH 711 mm (28 in)
WIDTH 450 mm (17.7 in)
HEIGHT 902 mm (35.5 in)
WEIGHT 47.6Kg (105lbs)
SOLUTION TANK CAPACITY 49.2 L (13 gal)
RECOVERY TANK CAPACITY 56.7L (15 gal)
SOLUTION PUMP 120 V, 6.8 bar (100 psi), 1.0A
VACUUM MOTOR –3 STAGE 120 V, 12.1A, 1452 W
INLINE HEATER 120V, 14.5A, 1750W
SEALED WATER LIFT 3454 mm (136 in)
TOTAL POWER CONSUMPTION HEATER:120v,14.5A, 1750 W;CLEAN: 13.1A 1572w
POWER CORD 7.6m (25 ft) 3/12
DECIBEL RATING 3 METERS (10 FT) FROM
MACHINE ON CARPET <75db(A)
902 mm
(35.5 in)
450 mm
(17.7 in)
711 mm
(28 in)

36406C(07-02)
10
ELECTRICAL DIAGRAM 36408C
120 V WIRING DIAGRAM

36408C(07-02)11
PARTS LIST 36408C
TANK GROUP

36406C(07-02)
12
PARTS LIST 36408C
TANK GROUP
PART # DESCRIPTION QTY.
B-17.2 8-32 X 1/2 PHXSS 12
B-18 NUT 8-32 HEX SS 8
B-21 10-32 X 5/16 PHXSS 6
B-22 10-32 X 7/16 PHXSS 1
B-23.7 10-32 X 5/8 PHXSS 1
B-24 10-32 X 3/4 PHXSS 12
B-26.7 10-32 X 1 1/2 PHXZINC 2
B-28.01 NUT 10-32 HEX ZINC 2
B-28.02 NUT, 10-32 SS NYLOCK 12
B-33 1/4-20 X 1 HEX HD CP 3
B-38.5 WASHER, 1/4 FLAT CP 3
B-40.91 3/8-16 X 1 1/2 HEX ZINC 2
B-40.95 3/8-16 X 3 1/2 HEX ZINC 1
B-40.96 3/8-16 X 4 HEX ZINC 1
B-41.5 WASHER, 3/8 FLAT ZINC 3
B-42.7 WASHER, 3/4 FLAT BLKHD CP 1
B-49 NUT,BULKHEAD 3/4-16 X.225 2
C-01.25 BUSHING,HOLDER EMPTY-OUT 1
C-03.02 CLAMP, HOSE 1/4" #4 1
C-03.2 CLAMP, HOSE 2" #24 1
C-03.3 CLAMP, HOSE 2 1/4 #32 2
•C-05.05 FILTER, 1/4NPT 50MESH 1
•C-07.2 GASKET, DOME LID 2
C-11.9 LATCH, SOFT DRAW BLACK 2
C-13.5 PLUG, HOLE NYLON .562 2
C-26 FLOAT,VAC SHUT OFF ROTO 1
C-56 O-RING, 1.75 X .187 1
D-01.91A BULKHEAD,1/4FPTX1/4FPTX2.25LNGX2"DI 1
D-01.92A NUT,BLKHD 3/4-16 X.843X 2.0"DIA 1
D-07.005 COUP 1/8 NPT -4 SAE 1
D-07.02 COUP 1/4 NPT X -6 SAE 1
D-41 NIPPLE, 1/4 NPT CLOSE BR 1
E-14.65 CUFF, 1 1/2 SLIP 1 1/2 HOSE 2
G-03.19 O-RING,VITON 2-020 BLKHD 1
PART # DESCRIPTION QTY.
•J-30 LID, DOME EDGE 2
J-31 RING, BLADDER EDGE 2
J-43BLK NECK,VAC FLTR EDGE ROTO 1
K-09.1 CORD,25' 12/3SJT UG 1
K-13.3 LIGHT, RED ROUND 1
K-16.96 BUSHING,RELIEF 1/2 NPT 1
K-16.97 NUT,NYLON BUSHING REL.1/2 1
•K-21W SWITCH, SPST WATER RESIS 2
•K-21.7W SWITCH, DPDT WATER RESIS 1
K-28.05 TIE, WIRE NYLON #10 SCREW 1
M-06.6 GUARD, SPLASH INTAKE EDGE 1
M-0791.03 BRACKET,SF-09 HOLDER EDGE 1
M-0791.05 BRACKET,DUMP VAL MNT EDGE 1
M-0792.1 PLATE,HANDLE SW COVR EDGE 1
N-30 LABEL, EDGE 2
N-30.100 PNL,EDGE PVH 1
N-30.6 LABEL,"IMPRTNT LIDS EDGE" 1
SC-35.5 HOSE BARB, ABS 1 1/2 CUT 1
SD-48.25/4.470 TEE COMP,3/8X3/8X1/8 W1/4"x4.47TUB 1
SE-10.05/31 HOSE, VAC 1.5" FLEX 31" 1
SE-10.6/15 HOSE,VAC 1 1/2X15' W/1.5 CUFFS 1
SE-10.6/15A HOSE,VAC 1 1/2X15' 1
SE-12/2.25 HOSE,2" VINYL X 2.25" 1
SF-09 NOZZEL, EMPTY OUT MALE 1
•SG-16 VALVE,DUMP 1.5 W/PVC EXT 1
SJ-32 FLANGE, ASM-DOME LID GLUE 2
SJ-41GRY.1 TANK,EDGE DRILL 3/4 BULKH 1
SJ-42GRY.2 HANDLE, EDGE 3SW & HEATER LIGHT 1
SJ-44BLK.1 INTAKE,AIR SINGLE VAC EDG 1
SJ-47BLK.75 BLADDER,EDGE 3/4" BOT HOL 1
SK-09.8 CORD,PIG TAIL EDGE COMP. 1
SK-12.73HARNESS HTR,HARNESS ASM SOL VALVE 1
SK-86.1/HNDL HRNS,HNDL ED PVH HTR LT SOL VALVE 1
•RECOMMENDED STOCK ITEMS

36408C(07-02)13
PARTS LIST 36408C
BASE GROUP

36406C(07-02)
14
PARTS LIST 36408C
BASE GROUP
PART # DESCRIPTION QTY.
B-09.1 6-32 X 3/8 PHXSS 2
B-10 6-32 X 1/2 PHXSS 5
B-11.2 6-32 X 3/4 FHXSS 100 DEG 1
B-14 NUT 6-32 HEX SS 9
B-16.2 8-32 X 3/8 PHXSS 4
B-17.6 8-32 X 3/4PHX ZINC 4
B-18.02 NUT 8-32 NYLOK, ZINC 4
B-21 10-32 X 5/16 PHXSS 5
B-22 10-32 X 7/16 PHXSS 2
B-23.17 10 X 1/2 SELF TAP HEX 1
B-23.7 10-32 X 5/8 PHXSS 4
B-28.01 NUT 10-32 HEX ZINC 4
B-28.03 NUT, 10-32 NYLOK ZINK 4
B-32 1/4-20 X 3/4 HEX HD CP 8
B-33.4 1/4-20 X 3 3/4 HEX CP 3
B-36.01 NUT 1/4-20 NYLOK ZINK 11
B-38.5 WASHER, 1/4 FLAT CP 6
B-42 WASHER 9/16 x 1 1/4 FLAT 6
C-02.3 CASTER 3 1/2" 2
C-03.3 CLAMP, HOSE 2 1/4 #32 1
C-04.1 COTTER, HAIRPIN 7/16-9/16 2
•C-06 GASKET, BLOWER/ARLON 1/4" 1
C-07.3 GASKET,VAC SEAL EDGE BASE 1
C-23.8 WHEEL 10" -1/2"BORE 2
C-59 PUSHNUT FASTNER, 1/2 CAP 2
C-95 VELCRO, ONE WRAP STRAP 1/2" X 12" 1
D-17 90 ST ELBOW 1/4" NPT 3
D-20.015 ELBOW 90 1/4NPT X -6 SAE 1
D-20.03 ELBOW 90 3/8NPT X -6 SAE 1
D-41 NIPPLE, 1/4 NPT CLOSE BR 1
D-43 NIPPLE, 1/4 HEX BRASS 1
D-48.1 TEE,1/4 NPT BRASS 1
E-14 CUFF, 1 1/2SLIP X 1 1/4HOSE 1
•F-09 Q/C 1/4" PLUG BR SHUT OFF 1
PART # DESCRIPTION QTY.
•F-11 Q/C 1/4" SOC BR SHUT OFF 2
•G-40 VALVE, SOLENOID 120V 1
K-17.4 CLAMP,NYLON CABLE 1/4" 2
K-17.5 CLAMPS, NYLON CABLE 3/8 2
K-23.21 THERMOSTAT, 160 SPST 1
K-25.82 THERMOSTAT, 190 SPST 1
K-25.83 THERMOSTAT, 230 SPST 1
K-28.1 TIE WRAP,8" LONG NATURAL 2
M-0790.5 AXIL, ROD 1/2 EDGE ECONO 1
M-0791 AXIL, ROD 1/2 EDGE 1
M-0791.3 PIVOT, TUBE EDGE 3.400" 2
M-0792.03 PLATE,VAC MNT 1 VAC -NO QUIET 1
M-0792.3 PLATE,HTR MNT EDGE 1
M-0792.45 PLATE,ASM HTR COVER EDGE 3 THERMO 1
M-31.175 STAND-OFF 5.7 EDGE 3.190 3
M-72 SPACER, QUICK CONNECT 1
M-93 WASHER, .219 X .625 18GA 4
SE-02/15 HOSE, 1/8"X1/4NPTX1/4NPT 1
SE-02/15E HOSE,1/8 SOL 15' EDGE 1
SE-06.7/19 HOSE,1/4SOL 1/4MPTX3/8FMLSVL 19" 1
SE-06.7/23 HOSE 1/4"SOL 23" -4SAESVL X 1/4MPT 1
SE-06.7/30A HOSE,3/8NPT X -6SAEFMLSVL 30"LONG 1
SE-06.9/20 HOSE, -6SAE X 1/4NPT 20 1
SE-12.5/10 HOSE,2" FLEX EXHAUST 10" 1
SJ-02.3 EXCHG, CASTING COMP EDGE 1
SJ-40BLK103200210 BASE,BLK DRLD 1 VAC NO QT 1
SJ-45BLKCOV COVER,HTR EDGE 1
SK-12.73 HTR,CRT 1750 120V COM W/HAR SOL VLV 1
SK-85.1/BASE HRNS,BASE ED PVH HTR LGHT SOL VALVE 1
•SL-006.5 BLOWER,3STG 120 5.7W/PLUG 1
•SL-22.5 PUMP,SH FL 100SI 115V W PLUG 1
SM-0277.13 EXCHG,HT EDG 110V 1750 4/SOL VALVE 1
SR-08/2 INSULATION, BLOWER 2" 1
SR-08/6 INSULATION,HTR EDGE 1
•RECOMMENDED STOCK ITEMS

36408C(07-02)15
PARTS LIST
PUMP 100 PSI BREAKDOWN
PART # DESCRIPTION QTY.
SL-22.5 •PUMP SH FL 100 PSI 100V 1
L-22.6 PUMP HEAD 100 PSI COMP ASM 1
L-22.66 •SWITCH ASM, 100 PSI SH FL 1
L-22.65 •CHECK VALVE ASM, 100 PSI SH FL 1
L-24.12 HEAD, PUMP DIAPHRAGM 1
L-22.8 •VALVE ASM, BYPASS SH FL 1
L-22.9 DIAPHRAGM, SOLID DRIVE ASM 1
SL-22.4 MOTOR,100 PSI 120V SH FL PLG 1
•RECOMMENDED STOCK ITEMS
SL
-
22.5
L-22.6 L-22.9
SL-22.4

36406C(07-02)
16
OPTIONS 20258 ECONO
FLOOR TOOL
PART # DESCRIPTION QTY.
B-24.1 10-32 X 3/4 PHXZINC 1
B-26.57 10-32 X 13/8 PHX ZINC 1
B-28.03 NUT, 10-32 NYLOK ZINK 2
B-40.15 5/16-18 X 3/4 HEX CP 2
B-40.33 NUT 5/16-18 NYLOCK, ZINC 2
C-07.9 GRIP, FLRTOOL 1 1/2 X 6 1
D-15.2 45 ST ELBOW 1/4 NPT 1
D-41 NIPPLE, 1/4 NPT CLOSE BR 1
PART # DESCRIPTION QTY.
•F-09 Q/C 1/4" PLUG BR SHUT OFF 1
G-23 VALVE, KNGSTN STD S BND 1
•H-37 JET, 11006 E VEE BRASS 1
M-16.5 HOE HANDLE,ECONO FLRTL 1
M-16.5A "U"CLAMP,SUPP HOE HNDL EC 1
M-19.5 WAND,FLOORTOOL COMP. ECONO 1
SC-82 TRIGGER,COMP KNGSTN VALVE 1
SE-06.7/47 HOSE,1/4 SOL 47"FLRTL ECO 1
•
RECOMMENDED STOCK ITEMS

36408C(07-02)17
OPTIONS LP/20208; HP/20216
FLOOR TOOL
PART # DESCRIPTION QTY.
B-24.1 10-32 X 3/4 PHXZINC 1
B-26.57 10-32 X 1 3/8 PHX ZINC 1
B-28.03 NUT, 10-32 NYLOK ZINK 2
B-40.15 5/16-18 X 3/4 HEX CP 2
B-40.33 NUT 5/16-18 NYLOCK, ZINC 2
C-07.9 GRIP, FLRTOOL 1 1/2 X 6 1
D-15.2 45 ST ELBOW 1/4 NPT 1
D-41 NIPPLE, 1/4 NPT CLOSE BR 1
•F-09 Q/C 1/4" PLUG BR SHUT OFF 1
G-23 VALVE,KNGSTN STD "S" BEND 1
PART # DESCRIPTION QTY.
G-23.5 VALVE,KNSTN HP "S" BEND 1
H-02.5 BODY, TEE JET 1/4 BRASS 2
H-03 CAP NUT, TEE JET BRASS 2
•H-18.5 JET,11003 TEE BRASS 2
•H-18.7 JET,110015 E TEE BRASS 2
M-16.5 HOE HANDLE,ECONO FLRTL 1
M-16.5A "U"CLAMP,SUPP HOE HNDL EC 1
M-20 WAND,"S"BND FLTL COM W/HD 1
SC-82 TRIGGER,COMP KNGSTN VALVE 1
SE-06.7/39.2 HOSE,1/4"SOL BLU X39.25DB 1
•
RECOMMENDED STOCK ITEMS

36406C(07-02)
18
OPTIONS 20078A
HAND TOOL
PART# Description QTY.
B-05.5 4-40X7/8PHXZINC 1
B-07.5 NUT,4-40HEXZINCNYLOK 1
B-11.5 6-32X1PHXZINC 2
B-14.6 NUT,6-32HEXZINCNYLOK 2
B-16.2 8-32X3/8PHXSS 1
B-18.01 NUT8-32NYLOK,SS 1
C-05.07 FILTER,4"DETAILTOOL50MESH 1
C-08.5 GROMMET,CLEARDETAILTOOL 1
D-02 BUSHING1/4X1/8NPTBR 1
E-13.5 CUFF,EXTRNHOSE11/2SLPX11/4HOSE 1
E-14 CUFF,11/2SLIPX11/4HOSE 1
F-09 Q/C1/4"PLUGBRSHUTOFF 1
G-04.5 GUIDE,VALVESTEMHEXBRASS 1
G-05.5 STEM,VALVESS4"DETAILTOOL 1
G-08.5 SPRING,VALVE4"UPHTOOL 1
PART# Description QTY.
GR-2-006N70 O-RING,2-006BUNA70DR 2
GR-2-011N70 O-RING,2-011BUNA70DR 1
GR-2-013N70 O-RING,2-013BUNA70DR 1
H-03.5 CAPNUT,TEEJETPOLYPRO 1
H-18.8 JET,110015STDFLATSPRYTIPPLSTIC 1
J-62 VALVE,4"DETAILTOOLASMOLDED 1
J-63 TRIGGER,4"DETAILTOOL 1
J-64 ELBOW,4"DETAILTOOL 1
M10.5A COUPLER,1.5"VACHOSEALUM 1
SE-02/16.5A HOSE,1/8BLK16.5"ASMW/EXTRNCUFF 1
SE-10/12 HOSE,VAC11/4GREY/BLACK12"LONG 1
SG-04.5 STEMASM4"TOOLBUNAW/BRASSCAP 1
SJ-60 HANDLEASM,4"DETAILTOOL 1
SJ-62 VALVE,NYLONCOMPLETESTD4"DETAIL 1

36408C(07-02)19
EDGE WARRANTY POLICY
LABOR & PARTS POLICY
For the first 12 months from the date of original purchase, upon Kleenrite’s determination, product manufacturing
defects will be repaired or replaced at no charge for labor and/or parts provided that the machine or part(s) is
delivered or shipped freight prepaid to Kleenrite or its designated repair center and provided that a Return
Authorization is obtained from Kleenrite prior to machine or part(s) being shipped. (See “How to Obtain a Return
Authorization”.)
Kleenrite is not responsible to pay for parts supplied by or labor performed by any of its distributors or any general
service companies.
PARTS ONLY –STANDARD REPLACEMENT POLICY
For the first 12 months from the date of original purchase, in the event that a part believed to be under warranty fails,
simply call Kleenrite to obtain a Return Authorization, ship the part freight prepaid to Kleenrite and, Kleenrite will
either repair or replace the part at no charge if it is determined that failure was a manufacturing defect. Kleenrite will
then ship the repaired or replaced part back to you freight collect. Our service department can usually talk a person
through any part replacement procedure in a matter of minutes. There is no charge for this nationwide toll-free
service.
PARTS ONLY –EMERGENCY REPLACEMENT POLICY
For the first 12 months from the date of original purchase, in the event that a part believed by the registered owner to
be under warranty fails and an immediate replacement part is requested before Kleenrite can inspect the part that is
suspected to be faulty or have a chance to repair it, Kleenrite will ship the requested part on a COD basis (part plus
freight) or if credit has been established prior to the request the part will be shipped on an Open Account basis (part
plus freight). A Return Authorization must be requested at the time of order so that the suspected defective part can
be returned freight prepaid to Kleenrite for warranty consideration. If after receiving the part, Kleenrite determines
that the part has a manufacturing defect and can be repaired, the part will be repaired to normal working condition
and returned (freight collect) to the original registered owner as a spare part and no refund will be made. Should
Kleenrite determine that the part is covered by warranty and cannot be repaired, Kleenrite will credit an open
account customer the same amount as was charged when the replacement part was sent less freight and will refund
a COD customer the same way. However, should Kleenrite determine that the part received was not a
manufacturing defect, you will be informed of such and credit will not be given nor will the damaged part be returned
unless requested specifically to the registered owner.
HOW TO OBTAIN A RETURN AUTHORIZATION
Prior to shipping any part, assembly or machine to Kleenrite a Return Authorization Number must be requested from
Kleenrite and displayed prominently on the outside of all packages containing parts or machines for warranty
consideration to be processed and in effect. A Return Authorization can be obtained by calling Kleenrite Service
Department at 1-800-241-4865 or 1-559-673-5700. The machine and/or part serial number must be communicated
to Kleenrite Customer Service to receive a Return Authorization Number. Any machine, part or assembly must be
returned with its original serial number as affixed by Kleenrite for warranty consideration to be in effect. All returns
will be sent to Kleenrite at 1122 Maple Street, Madera Ca. 93637. Fax communications can be sent to
1-559-673-5725 and emails sent to kleenritemfg.com.

36406C(07-02)
20
WARRANTY
Kleenrite Equipment, Inc. warrants the Edge Cleaning Machine against defects in material and workmanship
under normal use and service. Kleenrite, hereby, extends a limited three-year warranty on the polyethylene
machine housing of the Edge against cracking or leaking and a one-year warranty on the rest of the machine
against manufacturing defect or workmanship subject to the terms and conditions that follow.
TERMSANDCONDITIONS
The warranty obligation extends only to the repair or replacement of parts, assemblies or machine housing found
upon examination by Kleenrite to be defective in manufacturing or workmanship, and Kleenrite reserves the right
to make that determination. Any adjustment or replacement of defective parts made under this warranty does not
void the warranty; neither does it extend the original warranty beyond its term.
Repair or replacements of any machine component(s) with any part(s) other than genuine Kleenrite parts will
immediately void this and all warranties.
Filters, brass fittings, seals, o-rings and quick disconnects are considered expendable in normal use and are not
covered by this warranty.
Dry cleaning solvents cannot be used in the Edge.
This warranty shall not cover any Edge machine housing, part or assembly if there is evidence of misuse,
alteration, owner neglect, lack of proper maintenance, improper chemical use, improper voltage, abuse, accident,
freezing, flood, fire, etc. and any and all circumstances beyond Kleenrite’s control.
In no event shall Kleenrite be liable for loss of use, incidental or consequential damages or any damages to
persons or property.
1122 MAPLE STREET, MADERA CA 93637 USA
Phone [phone]; Fax [phone]; Email kleenritemfg.com
PLEASE RETURN REGISTRATION WITHIN 10 DAYS OF RECEIVING YOUR EDGE CLEANING MACHINE.
SPECIALS: Check our web site at: kleenritemfg.com for parts and equipment price specials.
KEEP THIS COPY FOR YOUR RECORDS
Date Received
Registered Owner(s)
Address
Phone Number
Fax Number
Email Address
Machine Serial Number
Purchased From (Distributor)
WARRANTY
REGISTRATION
