KleenRite SPP-32327A Product manual

®
SPP-32327A
Carpet And Upholstery Cleaner
Operator and Parts Manual
Model No.:
32327A – 4 gal Extractor
KLEENRITE
1122 MAPLE STREET
MADERA CA 93637 U.S.A.
FAX: [phone] MNL32327A
Rev. 00 (04-05)
CUSTOMER SERVICE: 1-800-241-4865

OPERATION
This manual is furnished with each new model. It
provides necessary operation and maintenance
instructions and an illustrated parts list.
Please fill out at time of installation for future reference.
Model No.- _____________________________________
Install. Date- ____________________________________
Serial No.- _____________________________________
Read this manual completely and understand the
machine before operating or servicing it.
Use the illustrated Parts Lists to order parts. Before
ordering parts or supplies, be sure to have your
machine model number and serial number handy.
Parts and supplies may be ordered by phone or mail
from any authorized parts and service center,
distributor or directly from Kleenrite.
This machine will provide excellent service. However,
the best results will be obtained at minimum costs if:
•The machine is operated with reasonable care.
•The machine is maintained regularly – per the
maintenance instructions provided.
•The machine is maintained with manufacturer
supplied or equivalent parts.
MACHINE DATA
© Kleenrite Printed in U.S.A.
Kleenrite Equipment is a registered United States trademark
TABLE OF CONTENTS
SAFETY PRECAUTIONS ................................. 3
SAFETY LABELS ............................................. 4
MACHINE COMPONENTS ............................... 5
MACHINE SETUP ............................................. 5
MACHINE OPERATION ................................... 6
DRAINING TANKS............................................ 7
FREEZE PROTECTION.................................... 7
MACHINE MAINTENANCE .............................. 8
STORING MACHINE......................................... 8
RECOMMENDED STOCK ITEMS .................... 8
TROUBLE SHOOTING ..................................... 9
SPECIFICATIONS............................................. 10
ELECTRICAL DIAGRAM.................................. 11
PARTS LIST...................................................... 12
OPTIONS........................................................... 15
WARRANTY POLICY ....................................... 18
SPP-32327A (04-05)
2

OPERATION
SAFETY PRECAUTIONS
This machine is intended for commercial use. It is
designed to wet clean carpet and upholstery in a
indoor environment and is not constructed for any
other use. Use only recommended cleaning solutions
and accessory tools.
All operators must read, understand and practice the
following safety precautions.
The following safety alert symbols are used throughout
this manual as indicated in their description:
WARNING: To warn of hazards or unsafe
practices which could result in severe personal
injury or death.
FOR SAFETY: To identify actions which must be
followed for safe operation of equipment.
The following information signals potentially dangerous
conditions to the operator or equipment.
FOR SAFETY:
1. Do not operate machine:
– Unless trained and authorized.
– Unless operator manual is read and
understood.
– In flammable or explosive areas.
– With damaged cord or plug.
–If not in proper operating condition.
–Unless cord is properly grounded.
– In outdoor areas.
– In standing water.
– With the use of an extension cord.
2. Before operating machine:
– Make sure all safety devices are in place
and operate properly.
3. When using machine:
– Do not run machine over cord.
– Do not pull machine by plug or cord.
– Do not pull cord around sharp edges or
corners.
– Do not unplug by pulling on cord.
– Do not stretch cord.
– Do not handle plugs with wet hands.
– Keep cord away from heated surfaces.
–Report machine damage or faulty operation
immediately.
–Follow mixing and handling instructions on
chemical containers.
4. Before leaving or servicing machine:
–Turn off machine.
–Unplug cord from wall outlet.
5. When servicing machine:
–Unplug cord from wall outlet.
–Avoid moving parts. Do not wear loose
jackets, shirts, or sleeves.
–Use manufacturer supplied or approved
replacement parts.
WARNING: Hazardous Voltage. Shock or
electrocution can result. Always unplug machine
before servicing.
WARNING: Flammable materials can cause
an explosion or fire. Do not use flammable
materials in tank(s).
WARNING: Flammable materials or reactive
metals can cause an explosion or fire. Do not pick
up.
WARNING: Do not leave machine (especially
heater) on while unattended or overnight.
GROUNDING INSTRUCTIONS
Machine must be grounded. If it should
malfunction or breakdown, grounding provides a
path of least resistance for electrical current to
reduce the risk of electrical shock. This machine is
equipped with a cord having an equipment-
grounding connector and grounding plug. The
plug must be plugged into an appropriate outlet
that is properly installed in accordance with all
local codes and ordinances. Do not remove
ground pin; if missing, replace plug before use.
GROUNDED OUTLET
(
3 HOLE
)
GROUNDING
PIN
SPP-32327A (04-05) 3

OPERATION
SAFETY LABELS
The safety labels appear on the switch panel of the machine. Replace switch label if any become damaged or
illegible.
FOR SAFETY LABEL-
Located on switch panel.
FOR SAFETY:
Read manual
before operating
machine.
SPP-32327A (04-05)
4
FLAMMABLE MATERIALS -
Located on switch panel.
WARNING: Flammable materials
can cause explosion or fire. Do
not use flammable materials in
tank(s). Flammable materials or
reactive metals can cause
explosion or fire. Do not pick up.
HAZARDOUS VOLTAGE
LABEL- Located on switch
panel.
WARNING: Hazardous Voltage.
Shock or electrocution can
result. Always unplug machine
before servicing.

OPERATION
MACHINE COMPONENTS
1. Recovery Tank
2. Solution Tank
3. Recovery Tank Lid
4. Solution Tank Lid
5. Vacuum Switch
6. Pump Switch
7. Heater Switch
8. Power Cord Connect
9. Vacuum Hose Connector
10. Latches
11. Recovery Tank Handle
12. Solution Hose Connector
13. 76 mm (3”) Wheels, non-marking
14. Heater “ON” Indicator Light
MACHINE SETUP
1. Carefully check carton for signs of damage.
Report damages at once to carrier. The machine
is shipped fully assembled and is ready for use.
2. Connect hoses and tool to be used (Figure 1).
3. Using a clean bucket or hose, fill solution tank
with 15 liters (4 gallons) of hot water, 60° C
(140° F) maximum (Figure 2).
WARNING: Flammable materials can cause an
explosion or fire. Do not use flammable materials
in tank(s).
4. Add a recommended cleaning chemical.
FOR SAFETY: When using machine, follow
mixing and handling instructions on chemical
containers.
Fig. 1
Fig. 2
2
43 11
1
9
10
5
6
8
7
13
1214
SPP-32327A (04-05) 5

OPERATION
ATTENTION: If using powdered cleaning
chemicals, mix prior to adding.
NOTE: If desired, water alone achieves excellent
cleaning results.
5. Plug machine’s power cords into grounded wall
outlets that are on separate circuits (Figure 3).
6
FOR SAFETY: Do not operate machine unless
cord is properly grounded.
FOR SAFETY: Do not operate machine with the
use of an extension cord.
6. Secure recovery tank lid in place.
MACHINE OPERATION
FOR SAFETY: Do not operate machine unless
operator manual is read and understood.
PRE-OPERATION AND HEATING
1. Vacuum carpet and remove other debris with
standard vacuum.
2. Prime pump by connecting empty-out nozzle to
the end of hose (Figure 12), hold nozzle over
solution tank, and turn pump on until fully primed.
3. Turn on heater (Figure 4) for approximately four
minutes to allow it to preheat the internal heat
exchanger. Red light will go out when heater has
reached maximum temperature.
CLEANING CARPETS
1. Activate vacuum and pump switches (Figure 5).
2. Take carpet cleaning wand in hand and squeeze
valve trigger while moving the tool in short
forward and backward strokes over the carpet
(Figure 6).
GROUNDED OUTLET
(3 hole)
GROUNDING
PIN
Fig. 3
Fig. 6
WHILE OPERATING
1. Overlap each path by 50 mm (2 in).
Warning: Flammable materials or reactive
metals can cause an explosion or fire. Do not
pick up.
2. Periodically check for excessive foam buildup in
recovery tank. Use a recommended foam control
solution to prevent vacuum motor damage.
ATTENTION: Excessive foam buildup will not
activate the float shut-off screen.
3. To clean heavily soiled areas, repeat cleaning
path from a different direction.
4. Empty recovery tank every time water is added to
solution tank.
CLEANING WITH ACCESSORY TOOLS
1. Connect accessory tool hoses to the couplers at
the end of the hoses already attached to the
machine (Figure 7).
Fig. 4 Fig. 7 Fig. 5
SPP-32327A (04-05)

OPERATION
2. Operate accessory tool as normal (Figure 8).
NOTE: Before cleaning upholstery, always check
cleaning instructions sewn in furniture by
manufacturer.
3. After cleaning, relieve water pressure from tool
before disconnecting hose. Squeeze trigger for
five seconds after turning switches off.
DRAINING TANKS
DRAINING RECOVERY TANK
1. Turn machine off.
2. Disconnect vacuum hose from tank. Release
both latches and lift tank away from machine
(Figure 9).
3. Empty tank by pouring waste out vacuum inlet
(Figure 10).
4. Rinse tank with clean water at the end of the day.
DRAINING SOLUTION TANK
1. Turn on vacuum and remove water from solution
tank (Figure 11).
Fig. 8
Fig. 11
FREEZE PROTECTION
1. After draining solution tank as described in step
one in the previous section (DRAINING
SOLUTION TANK), place empty-out nozzle in
vacuum inlet on vacuum tank and seal with hand
(Figure 12).
Fig. 12
2. Turn on vacuum and pump for 15 seconds. This
will fill the pump and hoses with air and prevent
freezing.
Fig. 9 Fig. 10
SPP-32327A (04-05) 7

OPERATION
MACHINE MAINTENANCE
To keep machine in good working condition, simply
follow machine’s daily, weekly and monthly
maintenance procedures.
FOR SAFETY: When servicing machine, unplug
cord from wall outlet.
DAILY MAINTENANCE
(Every 4 Hours of Operation)
1. Empty and rinse out recovery tank thoroughly.
2. Remove float shut-off screen from recovery tank
and clean (Figure 13).
3. When solution tank is empty, remove and clean
solution filter screen located in the bottom of the
solution tank.
4. Wipe off power cord and check for damage,
replace if necessary. Coil cord neatly after use.
5. Clean machine with an all purpose cleaner and
damp cloth.
WEEKLY MAINTENANCE
(Every 20 Hours of Operation)
1. Inspect vacuum hoses for holes and loose cuffs.
2. Inspect spray pattern for plugging. If plugged,
remove spray tips and soak them in acetic acid
solution for up to six hours. Do not use pointed
objects to unplug tips, damage will occur.
FOR SAFETY: When using machine, follow mixing
and handling instructions on chemical containers.
3. Inspect cord and cord grip for damage. Replace
immediately if damaged.
4. Lubricate female hose couplers with lightweight
oil.
MONTHLY MAINTENANCE
(Every 80 Hours of Operation)
1. Lubricate wheels with water resistant oil.
2. Inspect machine for water leaks and loose
hardware.
QUARTERLY MAINTENANCE
(Every 250 hours of Operation)
Check vacuum motor for carbon brush wear. Replace
motor if worn to a length of 10mm (0.38”) or less.
STORING MACHINE
1. Before storing machine, be certain to drain and
rinse tanks of all water.
2. Store machine in a dry area in the upright position.
3. Unscrew recovery tank lid to promote air
circulation.
ATTENTION: Do not expose to rain. Store
indoors.
ATTENTION: If storing machine in freezing
temperatures, be sure that machine and solution
system are completely drained and dry.
FIG. 13
RECOMMENDED STOCK ITEMS
Refer to Parts List section for recommended stock
items. Stock items are clearly identified with a bullet
preceding the parts description. See example below:
PART # DESCRIPTION QTY.
•J-30 LID, DOME EDGE 1
J-38GRANITE TOP,SOL TANK ROTO GRANITE 1
J-
39.5GRANITE HANDLE,WASTE TANK SPHERE ROTO GRANI 1
J-39GRANITE WASTE TANK,SPHERE ROTO GRANITE 1
SPP-32327A (04-05)
8

OPERATION
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
Faulty switches or wiring. Contact Service Center.
Faulty power cord. Contact Service Center.
Machine does not operate.
Building circuit breaker tripped. Reset Breaker.
Heater does not heat. Faulty switch or wiring. Contact service center.
Faulty switch or wiring. Contact Service Center.
Faulty solution pump motor. Contact Service Center.
Faulty pump head. Contact Service Center.
Trigger on wand not pulled. Pull Solution Trigger.
Solution pump does not operate.
Quick couplers not fully engaged. Connect quick couplers.
Loose or broken wiring. Contact Service Center.
Faulty vacuum switch. Contact Service Center.
Defective vacuum motor. Contact Service Center.
Vacuum motor does not
operate.
Worn carbon brushes. Contact Service Center.
Recovery tank drain valve open. Close valve.
Defective recovery tank lid gasket. Replace gasket.
Clogged float shut-off screen. Remove recovery tank lid and clean
screen.
Loose vacuum hose connections. Secure cuffs to hose.
Poor solution pick-up.
Defective vacuum hose. Replace hose.
Plugged spray tips. Clean or replace tips.
Improper spray tip size or spray angle. Replace with proper tips.
Worn spray tips. Replace spray tips.
Solution tank low or empty. Refill solution tank.
Uneven or no spray.
Faulty solution pump. Contact Service Center.
SPP-32327A (04-05) 9

OPERATION
SPECIFICATIONS
Model SPP-32327A
LENGTH 660 mm (26 in)
WIDTH 341 mm (13.43 in)
HEIGHT 698 mm (27.5 in)
WEIGHT 25.4 Kg (56 lbs)
SOLUTION TANK CAPACITY 16 L (4.2 gal)
RECOVERY TANK CAPACITY 14.2 L (3.75 gal)
SOLUTION PUMP 120 V, 4.13 bar (60psi), .8A
VACUUM MOTOR – 3 STG 120 V, 10.6A, 1272 W
HEATER 120 V, 8.1A, 1000 W
SEALED WATER LIFT 3454 mm (136 in)
TOTAL POWER CONSUMPTION 120V, 18.8 A, 2256 W
POWER CORD 6m (20 ft) 14/3
DECIBEL RATING 3 METERS (10 FT) FROM
MACHINE ON CARPET
<77 db(A)
MACHINE DIMENSIONS
698 mm
(27.5 in) 635 mm
(25 in)
660 mm
(26 in)
341 mm
(13.43 in)
SPP-32327A (04-05)
10

ELECTRICAL DIAGRAM
120 V WIRING DIAGRAM
SPP-32327A (04-05) 11

PARTS LIST 32327A
SPP-32327A (04-05)
12

PARTS LIST 32327A
PART # DESCRIPTION QTY.
B-09.1 6-32 X 3/8 PHXSS 4
B-11.2 6-32 X 3/4 FHXSS 100 DEG 3
B-14 NUT 6-32 HEX SS 3
B-17.2 8-32 X 1/2 PHXSS 4
B-17.6 8-32 X 3/4PHX ZINC 4
B-21.5 10-32 X 3/8 FHXSS 100 DEG 5
B-23.7 10-32 X 5/8 PHXSS 6
B-28.02 NUT, 10-32 SS NYLOCK 6
B-28.03 NUT, 10-32 NYLOK ZINK 10
B-32 1/4-20 X 3/4 HEX HD CP 18
B-33.5 1/4-20 X 4 1/2 HEX CP 3
B-35 1/4-20 X 6" HEXCP 2
B-36 NUT 1/4-20 HEX CP 2
B-36.01 NUT 1/4-20 NYLOK ZINK 19
B-38.5 WASHER, 1/4 FLAT CP 27
B-48 NUT, 1/4" BULK HD 3/4-16 2
C-02.1 CASTER 3" 4
C-03.02 CLAMP, HOSE 1/4" #4 1
C-03.3 CLAMP, HOSE 2 1/4 #32 1
C-03.9 CLAMP, HOSE 4 1/2" 2
•C-05.05 FILTER, 1/4NPT 50MESH 1
C-06 GASKET, BLOWER/ARLON 1/4" 1
C-06.3 GASKET, BLOWER SPHERE 1
C-07.2 GASKET, DOME LID 1
C-11.9 LATCH, SOFT DRAW BLACK 2
C-13.5 PLUG, HOLE NYLON .562 1
C-13.9 PLUG, HOLE NYLON 1"OD 2
C-26 FLOAT,VAC SHUT OFF ROTO 1
C-35.5 HOSE BARB,1 1/2XMPT W/FLA 1
C-58 RETAINER,1/4"ID EXTRNL SELF LOCKING 2
D-01.8OR BULK HEAD, 1/4" BRASS W/O-RING 1
D-07.01 COUP 1/4 NPT X -4 SAE 1
D-17 90 ST ELBOW 1/4" NPT 1
D-20.015 ELBOW 90 1/4NPT X -6 SAE 1
D-20.03 ELBOW 90 3/8NPT X -6 SAE 2
D-41 NIPPLE, 1/4 NPT CLOSE BR 2
D-48.1 TEE,1/4 NPT BRASS 1
D-48.5 TEE,STREET 1/4 NPT BRASS 1
D-93.4 VALVE,PRESSURE REL 1/4 SS 1
E-14 CUFF, 1 1/2SLIP X 1 1/4HOSE 2
F-09 Q/C 1/4" PLUG BR SHUT OFF 1
F-11 Q/C 1/4" SOC BR SHUT OFF 2
G-03.19 O-RING,VITON 2-020 BLKHD 1
J-30 LID, DOME EDGE 1
PART # DESCRIPTION QTY.
J-38.5GRANITE SOLUTION TANK,SPHERE ROTO GRY GRN 1
J-39.5GRANITE HANDLE,WASTE TANK SPHERE ROTO GR 1
J-48GRANITE LID, SOLUTION EDGE 2/3 GREY GRANITE 1
K-09.45 CORD 20' 14/3 SJT EXT CORD W/LOCK 1
K-16.96 BUSHING,RELIEF 1/2 NPT 1
K-16.97 NUT,NYLON BUSHING REL.1/2 1
K-17.3 CLAMP,NYLON CABLE 3/16" 3
•K-21W SWITCH, SPST WATER RESIS 3
•K-25.82 THERMOSTAT, 190 SPST 1
•K-25.83 THERMOSTAT, 230 SPST 1
M-0237 COVER, HEATER EXCH SPHERE 1
M-06.6 GUARD, SPLASH INTAKE EDGE 1
M-0792.2 PLATE,SHFL PMP&INLINE HTR MNT SPHR 1
M-0792.4B2 PLATE,HTR COVER DISC EDGE 2 THRMST 1
M-18.2 HINDGE, SOLUTION LID EDGE 2 8.125" 1
M-31.175 STAND-OFF 5.7 EDGE 3.190 3
M-72 SPACER, QUICK CONNECT 1
M-93 WASHER, .219 X .625 18GA 4
N-30.600 PANEL,SPHERE PVH 1
SC-16.69 SCREEN,BLOWER GUARD 1
SE-02.6/8.5 HOSE,1/8TYGON 1/8MPTXBLUNT CUT 8.5" 1
SE-02/15 HOSE, 1/8"X1/4NPTX1/4NPT 1
SE-02/15E HOSE,1/8 SOL 15' EDGE 1
SE-06.7/10.5 HOSE,1/4SOL -1/4NPTX-6SAEFMLSVL10.5 1
SE-06.7/14.5 HOSE,1/4SOL -1/4NPTX-6SAEFMLSVL14.5 1
SE-06.7/7.5 HOSE,1/4SOL -4SAEFMSVLX1/4FPTSVL7.5 1
SE-06.7/9.5 HOSE,1/4NPTX-6SAEFMLSVL 9.5"LONG 1
SE-10.001 HOSE,VAC 1 1/4X15 W/CUFF 1
SE-10/15 HOSE, VAC 1 1/4 GRAY 15 1
SE-12.5/8 HOSE, 2" FLEX EXH 8" 1
SJ-02.4 EXCHG,CASTING COMP SPHERE 1
SJ-32 FLANGE, ASM-DOME LID GLUE 1
SJ-36BLK.01 BASE, DRILLED 1 VAC ROTO SPHERE BLK 1
SJ-37GRT.024 CASE,GRY SPH LOGO,SHFL,INLN HTR,3ST 1
SJ-39GRANITE ASSM,WASTE TANK COMPLETE GRANITE 1
SJ-43.25 VAC FILTER ASSM COMPLETE W/NECK SP 1
SK-09.82/MAIN MAIN,CORD PIGTAIL 14/3 SPHERE TERM 1
SK-12.35 HTR, CRT 1000W 110V COM EDGE 1
SK-149.5 HARNESS, SPHERE C1PVH 1
SK-50.14/3.5 WIRE,BLACK 14GA W/.25FASTONS 3/5" 1
•SL-006.5 BLOWER,3STG 120 5.7W/PLUG 1
•SL-24 PUMP,DIAPH 60PSI 120V W/WIR&SWITCH 1
SM-0277.44 EXCH, HT COMP SPHERE 120V 1000W 1
SR-08/6 INSULATION,HTR EDGE 1
•RECOMMENDED STOCK ITEMS
SPP-32327A (04-05) 13

PARTS LIST
PUMP 60 PSI BREAKDOWN
1 8
2 7
6
5
4
3
REF# PART # DESCRIPTION QTY.
1 610550 •PUMP SH FL 100 PSI 120V PLG 1
2 610767 PUMP HEAD 100 PSI COMP ASM 1
3 610768 •SWITCH ASM, 100 PSI SH FL 1
4 610769 •CHECK VALVE ASM, 100 PSI SH FL 1
5 610770 HEAD, PUMP DIAPHRAGM 1
6 610771 •VALVE ASM, BYPASS SH FL 1
7 610772 DIAPHRAGM, SOLID DRIVE ASM 1
8 610773 MOTOR, 100 PSI 120V SH FL PLG 1
•RECOMMENDED STOCK ITEMS
SPP-32327A (04-05)
14

OPTIONS LP/20208; HP/20216
FLOOR TOOL
PART # DESCRIPTION QTY.
B-24.1 10-32 X 3/4 PHXZINC 1
B-26.57 10-32 X 1 3/8 PHX ZINC 1
B-28.03 NUT, 10-32 NYLOK ZINK 2
B-40.15 5/16-18 X 3/4 HEX CP 2
B-40.33 NUT 5/16-18 NYLOCK, ZINC 2
C-07.9 GRIP, FLRTOOL 1 1/2 X 6 1
D-15.2 45 ST ELBOW 1/4 NPT 1
D-41 NIPPLE, 1/4 NPT CLOSE BR 1
•F-09 Q/C 1/4" PLUG BR SHUT OFF 1
G-23 VALVE,KNGSTN STD "S" BEND 1
PART # DESCRIPTION QTY.
G-23.5 VALVE,KNSTN HP "S" BEND 1
H-02.5 BODY, TEE JET 1/4 BRASS 2
H-03 CAP NUT, TEE JET BRASS 2
•H-18.5 JET,11003 TEE BRASS 2
•H-18.7 JET,110015 E TEE BRASS 2
M-16.5 HOE HANDLE,ECONO FLRTL 1
M-16.5A "U"CLAMP,SUPP HOE HNDL EC 1
M-20 WAND,"S"BND FLTL COM W/HD 1
SC-82 TRIGGER,COMP KNGSTN VALVE 1
SE-06.7/39.2 HOSE,1/4"SOL BLU X39.25DB 1
•RECOMMENDED STOCK ITEMS
SPP-32327A (04-05) 15

OPTIONS 20258J
FLOOR TOOL
PART # DESCRIPTION QTY.
B-24.1 10-32 X 3/4 PHXZINC 1
B-26.57 10-32 X 1 3/8 PHX ZINC 1
B-28.03 NUT, 10-32 NYLOK ZINK 2
B-40.15 5/16-18 X 3/4 HEX CP 2
B-40.33 NUT 5/16-18 NYLOCK, ZINC 2
C-07.9 GRIP, FLRTOOL 1 1/2 X 6 1
D-15.2 45 ST ELBOW 1/4 NPT 1
•D-30.4 FILTER & CHECK, 100 MESH 1
D-41 NIPPLE, 1/4 NPT CLOSE BR 1
PART # DESCRIPTION QTY.
•F-09 Q/C 1/4" PLUG BR SHUT OFF 1
G-23 VALVE, KNGSTN STD S BND 1
H-03 CAP NUT, TEE JET BRASS 1
•H-18.2 JET, 11002 BRASS 1
M-16.5 HOE HANDLE,ECONO FLRTL 1
M-16.5A "U"CLAMP,SUPP HOE HNDL EC 1
M-19.5J WAND,FLOORTOOL COMP. ZOAH 1
SC-82 TRIGGER,COMP KNGSTN VALVE 1
SE-06.7/47 HOSE,1/4 SOL 47"FLRTL ECO 1
•RECOMMENDED STOCK ITEMS
SPP-32327A (04-05)
16

OPTIONS 20078A
HAND TOOL
PART # Description QTY.
B-05.5 4-40 X 7/8 PHXZINC 1
B-07.5 NUT, 4-40 HEX ZINC NYLOK 1
B-11.5 6-32 X 1 PHXZINC 2
B-14.6 NUT, 6-32 HEX ZINC NYLOK 2
B-16.2 8-32 X 3/8 PHXSS 1
B-18.01 NUT 8-32 NYLOK, SS 1
C-05.07 FILTER, 4" DETAIL TOOL 50 MESH 1
C-08.5 GROMMET, CLEAR DETAIL TOOL 1
D-02 BUSHING 1/4 X 1/8 NPT BR 1
E-13.5 CUFF,EXTRN HOSE 1 1/2SLPX1 1/4HOSE 1
E-14 CUFF, 1 1/2SLIP X 1 1/4HOSE 1
F-09 Q/C 1/4" PLUG BR SHUT OFF 1
G-04.5 GUIDE, VALVE STEM HEX BRASS 1
G-05.5 STEM, VALVE SS 4" DETAIL TOOL 1
G-08.5 SPRING, VALVE 4" UPH TOOL 1
PART # Description QTY.
GR-2-006N70 O-RING,2-006 BUNA 70DR 2
GR-2-011N70 O-RING,2-011 BUNA 70DR 1
GR-2-013N70 O-RING,2-013 BUNA 70DR 1
H-03.5 CAP NUT,TEE JET POLYPRO 1
H-18.8 JET, 110015 STD FLAT SPRYTIP PLSTIC 1
J-62 VALVE, 4" DETAIL TOOL AS MOLDED 1
J-63 TRIGGER, 4" DETAIL TOOL 1
J-64 ELBOW, 4" DETAIL TOOL 1
M10.5A COUPLER, 1.5" VAC HOSE ALUM 1
SE-02/16.5A HOSE, 1/8 BLK 16.5" ASM W/EXTRN CUFF 1
SE-10/12 HOSE, VAC 1 1/4 GREY/BLACK 12" LONG 1
SG-04.5 STEM ASM 4"TOOL BUNA W/BRASS CAP 1
SJ-60 HANDLE ASM, 4" DETAIL TOOL 1
SJ-62 VALVE,NYLON COMPLETE STD 4"DETAIL 1
SPP-32327A (04-05) 17

SPHERE WARRANTY POLICY
LABOR & PARTS POLICY
For the first 12 months from the date of original purchase, upon Kleenrite’s determination, product manufacturing
defects will be repaired or replaced at no charge for labor and/or parts provided that the machine or part(s) is
delivered or shipped freight prepaid to Kleenrite or its designated repair center and provided that a Return
Authorization is obtained from Kleenrite prior to machine or part(s) being shipped. (See “How to Obtain a Return
Authorization”.)
Kleenrite is not responsible to pay for parts supplied by or labor performed by any of its distributors or any general
service companies.
PARTS ONLY – STANDARD REPLACEMENT POLICY
For the first 12 months from the date of original purchase, in the event that a part believed to be under warranty fails,
simply call Kleenrite to obtain a Return Authorization, ship the part freight prepaid to Kleenrite and, Kleenrite will
either repair or replace the part at no charge if it is determined that failure was a manufacturing defect. Kleenrite will
then ship the repaired or replaced part back to you freight collect. Our service department can usually talk a person
through any part replacement procedure in a matter of minutes. There is no charge for this nationwide toll-free
service.
PARTS ONLY – EMERGENCY REPLACEMENT POLICY
For the first 12 months from the date of original purchase, in the event that a part believed by the registered owner to
be under warranty fails and an immediate replacement part is requested before Kleenrite can inspect the part that is
suspected to be faulty or have a chance to repair it, Kleenrite will ship the requested part on a COD basis (part plus
freight) or if credit has been established prior to the request the part will be shipped on an Open Account basis (part
plus freight). A Return Authorization must be requested at the time of order so that the suspected defective part can
be returned freight prepaid to Kleenrite for warranty consideration. If after receiving the part, Kleenrite determines
that the part has a manufacturing defect and can be repaired, the part will be repaired to normal working condition
and returned (freight collect) to the original registered owner as a spare part and no refund will be made. Should
Kleenrite determine that the part is covered by warranty and cannot be repaired, Kleenrite will credit an open
account customer the same amount as was charged when the replacement part was sent less freight and will refund
a COD customer the same way. However, should Kleenrite determine that the part received was not a
manufacturing defect, you will be informed of such and credit will not be given nor will the damaged part be returned
unless requested specifically to the registered owner.
HOW TO OBTAIN A RETURN AUTHORIZATION
Prior to shipping any part, assembly or machine to Kleenrite a Return Authorization Number must be requested from
Kleenrite and displayed prominently on the outside of all packages containing parts or machines for warranty
consideration to be processed and in effect. A Return Authorization can be obtained by calling Kleenrite Service
Department at 1-800-241-4865 or 1-559-673-5700. The machine and/or part serial number must be communicated
to Kleenrite Customer Service to receive a Return Authorization Number. Any machine, part or assembly must be
returned with its original serial number as affixed by Kleenrite for warranty consideration to be in effect. All returns
will be sent to Kleenrite at 1122 Maple Street, Madera Ca. 93637. Fax communications can be sent to
1-559-673-5725 and emails sent to kleenritemfg.com.
SPP-32327A (04-05)
18

WARRANTY
Kleenrite Equipment, Inc. warrants the Sphere Cleaning Machine against defects in material and workmanship
under normal use and service. Kleenrite, hereby, extends a limited three-year warranty on the polyethylene
machine housing of the Sphere against cracking or leaking and a one-year warranty on the rest of the machine
against manufacturing defect or workmanship subject to the terms and conditions that follow.
TERMS AND CONDITIONS
The warranty obligation extends only to the repair or replacement of parts, assemblies or machine housing found
upon examination by Kleenrite to be defective in manufacturing or workmanship, and Kleenrite reserves the right
to make that determination. Any adjustment or replacement of defective parts made under this warranty does not
void the warranty; neither does it extend the original warranty beyond its term.
Repair or replacements of any machine component(s) with any part(s) other than genuine Kleenrite parts will
immediately void this and all warranties.
Filters, brass fittings, seals, o-rings and quick disconnects are considered expendable in normal use and are not
covered by this warranty.
Dry cleaning solvents cannot be used in the Sphere.
This warranty shall not cover any Sphere machine housing, part or assembly if there is evidence of misuse,
alteration, owner neglect, lack of proper maintenance, improper chemical use, improper voltage, abuse, accident,
freezing, flood, fire, etc. and any and all circumstances beyond Kleenrite’s control.
In no event shall Kleenrite be liable for loss of use, incidental or consequential damages or any damages to
persons or property.
1122 MAPLE STREET, MADERA CA 93637 USA
Phone [phone]; Fax [phone]; Email kleenritemfg.com
PLEASE RETURN REGISTRATION WITHIN 10 DAYS OF RECEIVING YOUR SPHERE CLEANING MACHINE.
SPECIALS: Check our web site at: kleenritemfg.com for parts and equipment price specials.
KEEP THIS COPY FOR YOUR RECORDS
Date Received
Registered Owner(s)
Address
Phone Number
Fax Number
Email Address
Machine Serial Number
Purchased From (Distributor)
WARRANTY
REGISTRATION
SPP-32327A (04-05) 19

WARRANTY
Kleenrite Equipment, Inc. warrants the Sphere Cleaning Machine against defects in material and workmanship
under normal use and service. Kleenrite, hereby, extends a limited three-year warranty on the polyethylene
machine housing of the Sphere against cracking or leaking and a one-year warranty on the rest of the machine
against manufacturing defect or workmanship subject to the terms and conditions that follow.
TERMS AND CONDITIONS
The warranty obligation extends only to the repair or replacement of parts, assemblies or machine housing found
upon examination by Kleenrite to be defective in manufacturing or workmanship, and Kleenrite reserves the right
to make that determination. Any adjustment or replacement of defective parts made under this warranty does not
void the warranty; neither does it extend the original warranty beyond its term.
Repair or replacements of any machine component(s) with any part(s) other than genuine Kleenrite parts will
immediately void this and all warranties.
Filters, brass fittings, seals, o-rings and quick disconnects are considered expendable in normal use and are not
covered by this warranty.
Dry cleaning solvents cannot be used in the Sphere.
This warranty shall not cover any Sphere machine housing, part or assembly if there is evidence of misuse,
alteration, owner neglect, lack of proper maintenance, improper chemical use, improper voltage, abuse, accident,
freezing, flood, fire, etc. and any and all circumstances beyond Kleenrite’s control.
In no event shall Kleenrite be liable for loss of use, incidental or consequential damages or any damages to
persons or property.
1122 MAPLE STREET, MADERA CA 93637 USA
Phone [phone]; Fax [phone]; Email kleenritemfg.com
PLEASE RETURN REGISTRATION WITHIN 10 DAYS OF RECEIVING YOUR SPHERE CLEANING MACHINE.
SPECIALS: Check our web site at: kleenritemfg.com for parts and equipment price specials.
PLEASE RETURN THIS ENTIRE SHEET
Date Received
Registered Owner(s)
Address
Phone Number
Fax Number
Email Address
Machine Serial Number
Purchased From (Distributor)
WARRANTY
REGISTRATION
SPP-32327A (04-05)
20
