KleenRite 36465D3-1 Product manual

MNL36465D3-1
Rev. 00 (08-06)
36465D3-1
Carpet And Upholstery Cleaner
Model No.:
36465D3-1 – 11 gal Extractor
KLEENRITE
1122 MAPLE STREET
MADERA CA 93637 U.S.A.
FAX: [phone]
CUSTOMER SERVICE: 1-800-241-4865
Operator and Parts Manual
®

36465D3-1 (08-06)
2
Please fill out at time of installation for future reference.
Model No.- _____________________________________
Install. Date-____________________________________
Serial No.- _____________________________________
OPERATION
This manual is furnished with each new model. It
provides necessary operation and maintenance
instructions and an illustrated parts list.
Read this manual completely and understand the
machine before operating or servicing it.
Use the illustrated Parts Lists to order parts. Before
ordering parts or supplies, be sure to have your
machine model number and serial number handy.
Parts and supplies may be ordered by phone or mail
from any authorized parts and service center,
distributor or directly from Kleenrite.
This machine will provide excellent service. However,
the best results will be obtained at minimum costs if:
•The machine is operated with reasonable care.
•The machine is maintained regularly – per the
maintenance instructions provided.
•The machine is maintained with manufacturer
supplied or equivalent parts.
MACHINE DATA
© Kleenrite Printed in U.S.A.
Kleenrite Equipment is a registered United States trademark
TABLE OF CONTENTS
SAFETY PRECAUTIONS ................................. 3
MACHINE COMPONENTS............................... 4
MACHINE SETUP............................................. 4
MACHINE OPERATION ................................... 5
DRAINING TANKS............................................ 6
FREEZE PROTECTION.................................... 6
MACHINE MAINTENANCE .............................. 7
STORING MACHINE......................................... 7
RECOMMENDED STOCK ITEMS.................... 7
TROUBLE SHOOTING..................................... 8
SPECIFICATIONS............................................. 9
ELECTRICAL DIAGRAM.................................. 10
PARTS LIST...................................................... 11
OPTIONS........................................................... 16
WARRANTY POLICY ....................................... 18

36465D3-1 (08—06) 3
OPERATION
SAFETY PRECAUTIONS
This machine is intended for commercial use. It is
designed to wet clean carpet and upholstery in a
indoor environment and is not constructed for any
other use. Use only recommended cleaning solutions
and accessory tools.
All operators must read, understand and practice the
following safety precautions.
The following safety alert symbols are used throughout
this manual as indicated in their description:
WARNING: To warn of hazards or unsafe
practices which could result in severe personal
injury or death.
FOR SAFETY: To identify actions which must be
followed for safe operation of equipment.
The following information signals potentially dangerous
conditions to the operator or equipment.
FOR SAFETY:
1. Do not operate machine:
– Unless trained and authorized.
– Unless operator manual is read and
understood.
– In flammable or explosive areas.
– With damaged cord or plug.
–If not in proper operating condition.
–Unless cord is properly grounded.
– In outdoor areas.
– In standing water.
– With the use of an extension cord.
2. Before operating machine:
– Make sure all safety devices are in place
and operate properly.
3. When using machine:
– Do not run machine over cord.
– Do not pull machine by plug or cord.
– Do not pull cord around sharp edges or
corners.
– Do not unplug by pulling on cord.
– Do not stretch cord.
– Do not handle plugs with wet hands.
– Keep cord away from heated surfaces.
–Report machine damage or faulty operation
immediately.
–Follow mixing and handling instructions on
chemical containers.
–Connect hoses before turning on pump.
–Be sure chemicals are safe and non-toxic.
4. Before leaving or servicing machine:
–Turn off machine.
–Unplug cord from wall outlet.
5. When servicing machine:
–Unplug cord from wall outlet.
–Avoid moving parts. Do not wear loose
jackets, shirts, or sleeves.
–Use manufacturer supplied or approved
replacement parts.
WARNING: Hazardous Voltage. Shock or
electrocution can result. Always unplug machine
before servicing.
WARNING: Flammable materials can cause
an explosion or fire. Do not use flammable
materials in tank(s).
WARNING: Flammable materials or reactive
metals can cause an explosion or fire. Do not pick
up.
WARNING: Hot solutions up to 88° C (190°F).
Do not touch with any part of the body. Use
thermometer to gauge temperature.
WARNING: Contents of solution hoses may
be under pressure even after pump is off.
GROUNDING INSTRUCTIONS
Machine must be grounded. If it should
malfunction or breakdown, grounding provides a
path of least resistance for electrical current to
reduce the risk of electrical shock. This machine is
equipped with a cord having an equipment-
grounding connector and grounding plug. The
plug must be plugged into an appropriate outlet
that is properly installed in accordance with all
local codes and ordinances. Do not remove
ground pin; if missing, replace plug before use.
International models will have different cord ends.
GROUNDED OUTLET
(
3 HOLE
)
GROUNDING
PIN

36465D3-1 (08-06)
4
OPERATION
MACHINE COMPONENTS
1. Recovery Tank
2. Solution Tank
3. Recovery Tank Lid
4. Solution Tank Lid
5. Vacuum Switches
6. Pump Switch
7. Heater Switch
8. Heater On Indicator Light
9. Power Cord Connectors
10. Empty-Out Nozzle
11. Vacuum Hose Connector
12. Latches
13. Recovery Tank Drain
14. Separate Circuit Indicator Light
15. Solution Hose Connector
MACHINE SETUP
1. Carefully check carton for signs of damage.
Report damages at once to carrier. The machine
is shipped fully assembled and is ready for use.
2. Connect hoses and tool to be used (Figure1).
3. Using a clean bucket or hose, fill solution tank
with 41 liters (11 gallons) of hot water, 60° C
(140° F) maximum (Figure 2).
WARNING: Flammable materials can cause an
explosion or fire. Do not use flammable materials
in tank(s).
4. Add a recommended cleaning chemical.
FOR SAFETY: When using machine, follow
mixing and handling instructions on chemical
containers.
Fig. 1
Fi
g
. 2
4 3 14 6
9
8
2
10
13
1
57
12
11
15

36465D3-1 (08—06) 5
OPERATION
ATTENTION: If using powdered cleaning
chemicals, mix prior to adding.
NOTE: If desired, water alone achieves excellent
cleaning results.
Plug machine’s power cord into grounded wall outlet
on separate circuits (Figure 3). Green circuit
indicator light on switch panel illuminated
confirms connection to separate circuit.
FOR SAFETY: Do not operate machine unless
cord is properly grounded.
FOR SAFETY: Do not operate machine with the
use of an extension cord.
Secure recovery lid in place.
MACHINE OPERATION
FOR SAFETY: Do not operate machine unless
operator manual is read and understood.
PRE-OPERATION AND HEATING
1. Vacuum carpet and remove other debris with
standard vacuum.
2. Inspect power cord (s) for damage.
3. Turn on heater for 5 minutes to warm up heat
exchanger. (Figure 4).
CLEANING CARPETS
1. Turn on vacuum and pump switches (Figure 5).
2. Take carpet cleaning wand in hand and squeeze
valve trigger while moving the tool in short
forward and backward strokes. (Figure 6).
WHILE OPERATING
1. Overlap each path by 50 mm (2 in).
Warning: Flammable materials or reactive
metals can cause an explosion or fire. Do not
pick up.
2. Periodically check for excessive foam buildup in
recovery tank. Use a recommended foam control
solution to prevent vacuum motor damage.
ATTENTION: Excessive foam buildup will not
activate the float shut-off screen.
3. To clean heavily soiled areas, repeat cleaning
path from a different direction.
4. Empty recovery tank every time water is added to
solution tank.
CLEANING WITH ACCESSORY TOOLS
1. Connect accessory tool hoses to the couplers at
the end of the hoses already attached to the
machine. (Figure 7).
GROUNDED OUTLET
(3 hole)
GROUNDING
PIN
Fi
g
. 3
Fig. 4
Fig. 6
Fig. 5

36465D3-1 (08-06)
6
OPERATION
1. Operate accessory tool as normal (Figure 8).
NOTE: Before cleaning upholstery, always check
cleaning instructions sewn in furniture by
manufacturer.
2. After cleaning, relieve water pressure from tool
before disconnecting hose. Squeeze trigger for
five seconds after turning switches off.
DRAINING TANKS
DRAINING RECOVERY TANK
1. Turn machine off.
2. Insert a 45° elbow (optional) in drain valve. Place
a bucket below it and slowly pull up on the handle
(Figure 9).
3. Rinse tank with clean water at the end of the day.
DRAINING SOLUTION TANK
1. Remove empty-out nozzle from its storage
bracket (Figure 10) and attach to end of solution
hose.
2. Place empty-out nozzle over a bucket and turn on
pump until all the solution has been pumped from
solution tank.
3. Replace empty-out nozzle to its storage location.
FREEZE PROTECTION
1. After draining solution tank as described in steps
one and two in the previous section (DRAINING
SOLUTION TANK), place empty-out nozzle in
end of vacuum hose and seal with hand
(Figure 11).
2. Turn on vacuum and pump for 15 seconds. This
will fill the pump and hoses with air and prevent
freezing.
3. Replace empty-out nozzle to its storage place.
Fig. 9
Fig. 11
Fig. 10
Fig. 8

36465D3-1 (08—06) 7
OPERATION
MACHINE MAINTENANCE
To keep machine in good working condition, simply
follow machine’s daily, weekly and monthly
maintenance procedures.
FOR SAFETY: When servicing machine, unplug
cord from wall outlet.
DAILY MAINTENANCE
(Every 4 Hours of Operation)
1. Empty and rinse out recovery tank thoroughly.
2. Remove float shut-off screen from recovery tank
and clean (Figure 12.)
3. When solution tank is empty, remove and clean
solution filter screen located in the bottom of the
solution tank.
4. Wipe off power cord and check for damage,
replace if necessary. Coil cord neatly after use.
5. Clean machine with an all purpose cleaner and
damp cloth.
WEEKLY MAINTENANCE
(Every 20 Hours of Operation)
1. Inspect vacuum hoses for holes and loose cuffs.
2. Inspect spray pattern for plugging. If plugged,
remove spray tips and soak them in acetic acid
solution for up to six hours. Do not use pointed
objects to unplug tips, damage will occur.
FOR SAFETY: When using machine, follow mixing
and handling instructions on chemical containers.
3. Inspect cord and cord grip for damage. Replace
immediately if damaged.
4. Lubricate metal shaft on recovery tank drain with
water resistant oil.
5. Lubricate female hose couplers with lightweight
oil.
MONTHLY MAINTENANCE
(Every 80 Hours of Operation)
1. Lubricate wheels with water resistant oil.
2. Inspect machine for water leaks and loose
hardware.
QUARTERLY MAINTENANCE
(Every 250 hours of Operation)
Check vacuum motor for carbon brush wear. Replace
motor if worn to a length of 10mm (0.38”) or less.
STORING MACHINE
1. Before storing machine, be certain to drain and
rinse tanks of all water.
2. Store machine in a dry area in the upright position.
3. Open recovery tank lid to promote air circulation.
ATTENTION: Do not expose to rain. Store
indoors.
ATTENTION: If storing machine in freezing
temperatures, be sure that machine and solution
system are completely drained and dry.
RECOMMENDED STOCK ITEMS
Refer to Parts List section for recommended stock
items. Stock items are clearly identified with a bullet
preceding the parts description. See example below:
PART # DESCRIPTION QTY.
J-30. LID, DOME EDGE 1
•
J-
38GRANITE TOP,SOL TANK ROTO GRANITE 1
J-
39.5GRANITE
HANDLE,WASTE TANK SPHERE ROTO GRANI 1
J-39GRANITE WASTE TANK,SPHERE ROTO GRANITE 1
FIG. 12

36465D3-1 (08-06)
8
OPERATION
TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
Machine does not operate. Faulty switches or wiring. Contact Service Center.
Faulty power cord. Contact Service Center.
Building circuit breaker tripped. Reset Breaker.
Heater does not heat. Faulty switch or wiring. Contact service center.
Solution pump does not operate. Faulty switch or wiring. Contact Service Center.
Faulty solution pump motor. Contact Service Center.
Faulty pump head. Contact Service Center.
Trigger on wand not pulled. Pull Solution Trigger.
Quick couplers not fully engaged. Connect quick couplers.
Vacuum motor does not
operate. Loose or broken wiring. Contact Service Center.
Faulty vacuum switch. Contact Service Center.
Defective vacuum motor. Contact Service Center.
Worn carbon brushes. Contact Service Center.
Poor solution pick-up. Recovery tank drain valve open. Close valve.
Defective recovery tank lid gasket. Replace gasket.
Clogged float shut-off screen. Remove recovery tank lid and clean
screen.
Loose vacuum hose connections. Secure cuffs to hose.
Defective vacuum hose. Replace hose.
Uneven or no spray. Plugged spray tips. Clean or replace tips.
Improper spray tip size or spray angle. Replace with proper tips.
Worn spray tips. Replace spray tips.
Solution tank low or empty. Refill solution tank.
Faulty solution pump. Contact Service Center.

36465D3-1 (08—06) 9
OPERATION
SPECIFICATIONS
MACHINE DIMENSIONS
Model 36465D3-1
LENGTH 711 mm (28 in)
WIDTH 450 mm (17.7 in)
HEIGHT 1016 mm (40 in)
WEIGHT 58 Kg (128lbs)
SOLUTION TANK CAPACITY 41 L (11 gal)
RECOVERY TANK CAPACITY 38L (10 gal)
SOLUTION PUMP 120 V, 34.5 bar (500psi), 3.5 A
VACUUM MOTORS – 2 STAGE 2 @ 120 V, 9.0 A, 1080 W
HEATER 120 V, 14.6 A, 1750 W
SEALED WATER LIFT 3429 mm (135 in)
TOTAL POWER CONSUMPTION CIR 1–120V, 21A, 2520W; CIR 2– 120V, 14.6A,1750W
POWER CORDS 2 @ 7.6m (25 ft) 3/12
DECIBEL RATING 3 METERS (10 FT) FROM
MACHINE ON CARPET <68 db(A)
711 mm
(28 in)
1016 mm
(40 in)
450 mm
(17.7 in)
902 mm
(35.5 in)

36465D3-1 (08-06)
10
ELECTRICAL DIAGRAM 36465D3-1
120 V WIRING DIAGRAM

36465D3-1 (08—06) 11
PARTS LIST 36465D3-1
TANK GROUP

36465D3-1 (08-06)
12
PARTS LIST 36465D3-1
TANK GROUP
Part # Description Qty.
B-09.1 6-32 X 3/8 PHXSS 2
B-14.5 NUT 6-32 HEX SS NYLOK 2
B-17.2 8-32 X 1/2 PHXSS 4
B-21 10-32 X 5/16 PHXSS 6
B-22 10-32 X 7/16 PHXSS 1
B-23.7 10-32 X 5/8 PHXSS 1
B-26.7 10-32 X 1 1/2 PHXZINC 2
B-28.01 NUT 10-32 HEX ZINC 2
B-29 WASHER #10 LOCK 1
B-33.05 1/4-20 X 1 HEX HD SS 2
B-36.02 NUT 1/4-20 NYLOK SS 2
B-38.6 WASHER, 1/4 FLAT SS 4
B-40.91 3/8-16 X 1 1/2 HEX ZINC 2
B-40.95 3/8-16 X 3 1/2 HEX ZINC 1
B-40.96 3/8-16 X 4 HEX ZINC 1
B-41.5 WASHER, 3/8 FLAT ZINC 3
B-42.7 WASHER, 3/4 FLAT BLKHD CP 1
B-49 NUT,BULKHEAD 3/4-16 X.225 2
C-01.25 BUSHING,HOLDER EMPTY-OUT 1
C-03.02 CLAMP, HOSE 1/4" #4 2
C-03.13 CLAMP, HOSE 1 3/4 #20 2
C-03.2 CLAMP, HOSE 2" #24 1
C-03.3 CLAMP, HOSE 2 1/4 #32 2
•C-05.06 FILTER, 3/8NPT 50 MESH 1
•C-07.6 GASKET,LID FLD WATER RMVL&EDGE 1
C-11.9 LATCH, SOFT DRAW BLACK 2
C-13.5 PLUG, HOLE NYLON .562 3
•C-26 FLOAT,VAC SHUT OFF ROTO 1
C-35.5 HOSE BARB,1 1/2XMPT W/FLA 1
C-57 FLAT WASHER 1.75 ID X 2.75 1
D-01.935 BULKHEAD,3/4-16x3/8 MPT 2.10"LNG 1
D-01.94 BULKHEAD,ADAPT3/8NPTX1/2N 1
F-02 Q/C 1/8" PLUG SS 1
F-03 Q/C 1/8 SOC BR ST TH 1
Part # Description Qty.
F-13.5 QC 3/8" PLUG BR ST TH 1
F-14 QC 3/8 SOC BR ST TH 1
G-03.19 O-RING,VITON 2-020 BLKHD 1
J-48GRANITE LID, SOLUTION EDGE 2/3 GREY GRANIT 1
J-49GRYGRNT LID,MEGA/E3 ROTO GREY GRANITE 1
J-57.5 SPACER,ROTO 3"OD X 2.4"ID 1
K-09.1 CORD,25' 12/3SJT UG 2
K-13.2 LIGHT, GREEN ROUND 1
K-13.3 LIGHT, RED ROUND 1
K-16.96 BUSHING,RELIEF 1/2 NPT 2
K-16.97 NUT,NYLON BUSHING REL.1/2 2
•K-21W SWITCH, SPST WATER RESIS 4
K-28.05 TIE, WIRE NYLON #10 SCREW 1
M-06.7 GUARD,SPLASH EDGE 3 LID 1
M-0791.03 BRACKET,SF-09 HOLDER EDGE 1
M-0791.05 BRACKET,DUMP VAL MNT EDGE 1
M-0792.1 PLATE,HANDLE SW COVR EDGE 1
M-18.2 HINDGE, SOLUTION LID EDGE 2 8.125" 1
N-30.107 PNL,SW EDGE P PVV 1
N-33.5 DECAL, ATEX RAM FORCE 2
SC-05.025E3 ELBOW,PVC LID ASSM EDGE 3 1
SC-35.5 HOSE BARB, ABS 1 1/2 CUT 1
SD-48.25/3.57 TEE COMP,3/8X3/8X1/8 W/1/4"X3.57TUB 1
SE-10.05/31 HOSE, VAC 1.5" FLEX 31" 1
SE-12/2.25 HOSE,2" VINYL X 2.25" 1
SF-09 NOZZEL, EMPTY OUT MALE 1
•SG-16 VALVE,DUMP 1.5 W/PVC EXT 1
SJ-41SOLCUP/GRYGT-01 SOL TANK,E2/3 CUP BOT GRYGRNT DRI 1
SJ-41VACE3/GRYGNT-01 VAC TANK,E3 GREY GRANITE DRILLED 1
SJ-42GRYGRNT.35 HANDLE, EDGE 4 SW & 2LT 1
SJ-43.75 COMP,VAC FLTR NECK ASSM EDGE 3 1
SJ-49.5GRYGRNT LID COMPLETE EDGE 3-GREY GRANITE 1
SK-09.8 CORD,PIG TAIL EDGE COMP. 2
SK-85K/HNDL HARNESS,HNDL EDGE C2LH CI C1PFVV 1
•RECOMMENDED STOCK ITEMS

36465D3-1 (08—06) 13
PARTS LIST 36465D3-1
BASE GROUP

36465D3-1 (08-06)
14
PARTS LIST 36465D3-1
BASE GROUP
Part # Description Qty.
B-09.1 6-32 X 3/8 PHXSS 4
B-10 6-32 X 1/2 PHXSS 8
B-14 NUT 6-32 HEX SS 8
B-16.2 8-32 X 3/8 PHXSS 4
B-17.6 8-32 X 3/4PHX ZINC 4
B-18.02 NUT 8-32 NYLOK, ZINC 4
B-21 10-32 X 5/16 PHXSS 7
B-22 10-32 X 7/16 PHXSS 3
B-23 10-32 X 1/2 PHXSS 1
B-23.17 10 X 1/2 SELF TAP HEX 1
B-23.7 10-32 X 5/8 PHXSS 1
B-26.7 10-32 X 1 1/2 PHXZINC 2
B-28.01 NUT 10-32 HEX ZINC 7
B-29.1 WASHER,#10 SS 6
B-31.5 1/4-20 X 1/2 HEX CP 4
B-32 1/4-20 X 3/4 HEX HD CP 12
B-33.4 1/4-20 X 3 3/4 HEX CP 6
B-36.01 NUT 1/4-20 NYLOK ZINK 14
B-38.5 WASHER, 1/4 FLAT CP 20
B-42 WASHER 9/16 x 1 1/4 FLAT 6
B-45 NUT, 9/16-18 JAM NUT 1
C-02.3 CASTER 3 1/2" 2
C-03.3 CLAMP, HOSE 2 1/4 #32 4
C-04.1 COTTER, HAIRPIN 7/16-9/16 2
•C-06 GASKET, BLOWER/ARLON 1/4" 2
C-07.3 GASKET,VAC SEAL EDGE BASE 1
C-23.8 WHEEL 10" - 1/2"BORE 2
C-30.2 GAUGE, PRESSURE 0-600 PSI 1
C-51 MUFFLER, FOAM EDGE 1
C-59 PUSHNUT FASTNER, 1/2 CAP 2
C-95 VELCRO, ONE WRAP STRAP 1/2" X 1
D-04 BUSHING 3/8 X 1/4 NPT BR. 2
D-15.2 45 ST ELBOW 1/4 NPT 3
D-17 90 ST ELBOW 1/4" NPT 4
D-18 90 ELBOW 1/4MPT x 1/4 MPT 1
D-20.015 ELBOW 90 1/4NPT X -6 SAE 1
D-43 NIPPLE, 1/4 HEX BRASS 1
D-44.03 NIPPLE, 1/4 X 2.5 BRASS 1
D-45.5 PLUG, 3/8" MPT BRASS 2
D-48.1 TEE,1/4 NPT BRASS 1
D-48.2 TEE,3/8 NPT BRASS 1
E-04.6 HOSE,1/4" PULSE W/SWVL 2
Part # Description Qty.
F-09 Q/C 1/4" PLUG BR SHUT OFF 1
G-37 VALVE,VAC SHUT OFF DUAL 1
J-45.6BLK PMP MNT,DRLD 2 VAC FAN SILNCE B 1
K-17.4 CLAMP,NYLON CABLE 1/4" 2
K-17.5 CLAMPS, NYLON CABLE 3/8 2
K-25.82 THERMOSTAT, 190 SPST 1
K-25.83 THERMOSTAT, 230 SPST 1
M-0563.85 BRACKET, MTR STARTER CAP 500PSI 1
M-0790.5 AXIL, ROD 1/2 EDGE ECONO 1
M-0791 AXIL, ROD 1/2 EDGE 1
M-0791.01 BRACKET,PRES RELFVAL EDGE 1
M-0791.01A BRACKET,PRES RELFVAL 300PSI ED 1
M-0791.3 PIVOT, TUBE EDGE 3.400" 2
M-0792.01 PLATE,VAC MNT 2 VAC PARALL - QUI 1
M-0792.3 PLATE,HTR MNT EDGE 1
M-0792.4 PLATE,ASM HTR COVER EDGE 4 THE 1
M-0792.51 PLATE,FLAPPER VALVE-EDGE 1
M-0792.6 PLATE, MUFFLER/PMP MOUNT COVE 1
M-0792.7 BRACKET, MANIFOLD DIV 1
M-31.17 STAND-OFF 5.7 EDGE 2.260” 6
M-72 SPACER, QUICK CONNECT 1
SE-06.7/24 HOSE,1/4 BLU 1/4NPTX1/8NP 1
SE-06.9/23 HOSE, -6SAE X 1/4NPT 21 1
SE-09.1/14A HOSE,1/2GPH 14" 3/8NPTX3/8NPT 1
SE-09.1/25 HOSE,1/2"GPH 25" 3/8NPTX3/8NPT 1
SE-09.1/8A HOSE,1/2GPH 8" 3/8NPTX3/8NPT 1
SE-12.5/5 HOSE,2" FLEX EXH 5" 1
SE-12.5/6 HOSE, 2" FLEX EXH 6" 1
SG-37 VALVE,DUAL FLPR MODI EDGE 1
SG-46.9 VALVE,PRESS RELF 500PSI MACH 1
SJ-02.3 EXCHG, CASTING COMP EDGE 1
SJ-40BLK101206210 BASE,BLK DRLD E2/3,PAR,QT,300PSI 1
SJ-45BLKCOV COVER,HTR EDGE 1
SJ-46BLK MANIFOLD,ASM VAC EDGE 1
SK-12.7 HTR,CRT 1750 120V COM EDG 1
SK-85K/BASE HARNESS,BASE EDGE C2H CI C1PFV 1
•SL-004.5 BLOWER,2STG 120 5.7W/PLUG 2
•SL-28.500 PUMP, 500PSI CMP 110V 1
SM-0277.1 EXCHG,HT EDGE 110V 1750 1
SR-08/6 INSULATION,HTR EDGE 1
•RECOMMENDED STOCK ITEMS

36465D3-1 (08—06) 15
OPTIONS 20258J
FLOOR TOOL
PART # DESCRIPTION QTY.
B-24.1 10-32 X 3/4 PHXZINC 1
B-26.57 10-32 X 1 3/8 PHX ZINC 1
B-28.03 NUT, 10-32 NYLOK ZINK 2
B-40.15 5/16-18 X 3/4 HEX CP 2
B-40.33 NUT 5/16-18 NYLOCK, ZINC 2
C-07.9 GRIP, FLRTOOL 1 1/2 X 6 1
D-15.2 45 ST ELBOW 1/4 NPT 1
•D-30.4 FILTER & CHECK, 100 MESH 1
D-41 NIPPLE, 1/4 NPT CLOSE BR 1
PART # DESCRIPTION QTY.
•F-09 Q/C 1/4" PLUG BR SHUT OFF 1
G-23 VALVE, KNGSTN STD S BND 1
H-03 CAP NUT, TEE JET BRASS 1
•H-18.2 JET, 11002 BRASS 1
M-16.5 HOE HANDLE,ECONO FLRTL 1
M-16.5A "U"CLAMP,SUPP HOE HNDL EC 1
M-19.5J WAND,FLOORTOOL COMP. ZOAH 1
SC-82 TRIGGER,COMP KNGSTN VALVE 1
SE-06.7/47 HOSE,1/4 SOL 47"FLRTL ECO 1
•RECOMMENDED STOCK ITEMS

36465D3-1 (08-06)
16
EDGE WARRANTY POLICY
LABOR & PARTS POLICY
For the first 12 months from the date of original purchase, upon Kleenrite’s determination, product manufacturing
defects will be repaired or replaced at no charge for labor and/or parts provided that the machine or part(s) is
delivered or shipped freight prepaid to Kleenrite or its designated repair center and provided that a Return
Authorization is obtained from Kleenrite prior to machine or part(s) being shipped. (See “How to Obtain a Return
Authorization”.)
Kleenrite is not responsible to pay for parts supplied by or labor performed by any of its distributors or any general
service companies.
PARTS ONLY – STANDARD REPLACEMENT POLICY
For the first 12 months from the date of original purchase, in the event that a part believed to be under warranty fails,
simply call Kleenrite to obtain a Return Authorization, ship the part freight prepaid to Kleenrite and, Kleenrite will
either repair or replace the part at no charge if it is determined that failure was a manufacturing defect. Kleenrite will
then ship the repaired or replaced part back to you freight collect. Our service department can usually talk a person
through any part replacement procedure in a matter of minutes. There is no charge for this nationwide toll-free
service.
PARTS ONLY – EMERGENCY REPLACEMENT POLICY
For the first 12 months from the date of original purchase, in the event that a part believed by the registered owner to
be under warranty fails and an immediate replacement part is requested before Kleenrite can inspect the part that is
suspected to be faulty or have a chance to repair it, Kleenrite will ship the requested part on a COD basis (part plus
freight) or if credit has been established prior to the request the part will be shipped on an Open Account basis (part
plus freight). A Return Authorization must be requested at the time of order so that the suspected defective part can
be returned freight prepaid to Kleenrite for warranty consideration. If after receiving the part, Kleenrite determines
that the part has a manufacturing defect and can be repaired, the part will be repaired to normal working condition
and returned (freight collect) to the original registered owner as a spare part and no refund will be made. Should
Kleenrite determine that the part is covered by warranty and cannot be repaired, Kleenrite will credit an open
account customer the same amount as was charged when the replacement part was sent less freight and will refund
a COD customer the same way. However, should Kleenrite determine that the part received was not a
manufacturing defect, you will be informed of such and credit will not be given nor will the damaged part be returned
unless requested specifically to the registered owner.
HOW TO OBTAIN A RETURN AUTHORIZATION
Prior to shipping any part, assembly or machine to Kleenrite a Return Authorization Number must be requested from
Kleenrite and displayed prominently on the outside of all packages containing parts or machines for warranty
consideration to be processed and in effect. A Return Authorization can be obtained by calling Kleenrite Service
Department at 1-800-241-4865 or 1-559-673-5700. The machine and/or part serial number must be communicated
to Kleenrite Customer Service to receive a Return Authorization Number. Any machine, part or assembly must be
returned with its original serial number as affixed by Kleenrite for warranty consideration to be in effect. All returns
will be sent to Kleenrite at 1122 Maple Street, Madera Ca. 93637. Fax communications can be sent to
1-559-673-5725 and emails sent to kleenritemfg.com.

36465D3-1 (08—06) 17
WARRANTY
Kleenrite Equipment, Inc. warrants the Edge Cleaning Machine against defects in material and workmanship
under normal use and service. Kleenrite, hereby, extends a limited three-year warranty on the polyethylene
machine housing of the Edge against cracking or leaking and a one-year warranty on the rest of the machine
against manufacturing defect or workmanship subject to the terms and conditions that follow.
TERMSANDCONDITIONS
The warranty obligation extends only to the repair or replacement of parts, assemblies or machine housing found
upon examination by Kleenrite to be defective in manufacturing or workmanship, and Kleenrite reserves the right
to make that determination. Any adjustment or replacement of defective parts made under this warranty does not
void the warranty; neither does it extend the original warranty beyond its term.
Repair or replacements of any machine component(s) with any part(s) other than genuine Kleenrite parts will
immediately void this and all warranties.
Filters, brass fittings, seals, o-rings and quick disconnects are considered expendable in normal use and are not
covered by this warranty.
Dry cleaning solvents cannot be used in the Edge.
This warranty shall not cover any Edge machine housing, part or assembly if there is evidence of misuse,
alteration, owner neglect, lack of proper maintenance, improper chemical use, improper voltage, abuse, accident,
freezing, flood, fire, etc. and any and all circumstances beyond Kleenrite’s control.
In no event shall Kleenrite be liable for loss of use, incidental or consequential damages or any damages to
persons or property.
1122 MAPLE STREET, MADERA CA 93637 USA
Phone [phone]; Fax [phone]; Email kleenritemfg.com
PLEASE RETURN REGISTRATION WITHIN 10 DAYS OF RECEIVING YOUR EDGE CLEANING MACHINE.
SPECIALS: Check our web site at: kleenritemfg.com for parts and equipment price specials.
KEEP THIS COPY FOR YOUR RECORDS
Date Received
Registered Owner(s)
Address
Phone Number
Fax Number
Email Address
Machine Serial Number
Purchased From (Distributor)
WARRANTY
REGISTRATION

36465D3-1 (08-06)
18
WARRANTY
Kleenrite Equipment, Inc. warrants the Edge Cleaning Machine against defects in material and workmanship
under normal use and service. Kleenrite, hereby, extends a limited three-year warranty on the polyethylene
machine housing of the Edge against cracking or leaking and a one-year warranty on the rest of the machine
against manufacturing defect or workmanship subject to the terms and conditions that follow.
TERMSANDCONDITIONS
The warranty obligation extends only to the repair or replacement of parts, assemblies or machine housing found
upon examination by Kleenrite to be defective in manufacturing or workmanship, and Kleenrite reserves the right
to make that determination. Any adjustment or replacement of defective parts made under this warranty does not
void the warranty; neither does it extend the original warranty beyond its term.
Repair or replacements of any machine component(s) with any part(s) other than genuine Kleenrite parts will
immediately void this and all warranties.
Filters, brass fittings, seals, o-rings and quick disconnects are considered expendable in normal use and are not
covered by this warranty.
Dry cleaning solvents cannot be used in the Edge.
This warranty shall not cover any Edge machine housing, part or assembly if there is evidence of misuse,
alteration, owner neglect, lack of proper maintenance, improper chemical use, improper voltage, abuse, accident,
freezing, flood, fire, etc. and any and all circumstances beyond Kleenrite’s control.
In no event shall Kleenrite be liable for loss of use, incidental or consequential damages or any damages to
persons or property.
1122 MAPLE STREET, MADERA CA 93637 USA
Phone [phone]; Fax [phone]; Email kleenritemfg.com
PLEASE RETURN REGISTRATION WITHIN 10 DAYS OF RECEIVING YOUR EDGE CLEANING MACHINE.
SPECIALS: Check our web site at: kleenritemfg.com for parts and equipment price specials.
PLEASE RETURN THIS ENTIRE SHEET
Date Received
Registered Owner(s)
Address
Phone Number
Fax Number
Email Address
Machine Serial Number
Purchased From (Distributor)
WARRANTY
REGISTRATION
