Ranger
™
TDR
VDV501-090
ENGLISH
Español pág. 15
Français page
29
•
MEASURES
CABLE LENGTH
•
CABLE FAULT
FINDER
•
TONE GENERATOR
•
CABLE MANAGER

2
ENGLISH
FEATURES
The Klein Tools Ranger™ TDR is a portable time domain reflectometer
(TDR) and voice-data-video cable tester. It measures cable length,
calibrates Nominal Velocity of Propagation (NVP) values, finds faults in
cables, and provides built-in tone generation for cable tracing.
•
±1% and ±3 ft (1 m) length accuracy.
•
Stores up to two NVP values.
•
Displays length reading in feet or meters.
•
Extra large seven-segment, back-lit LCD screen.
•
Tests most types of copper cable including data, voice, video, lamp
wire, siamese, and NM cables.
•
Discovers NVP values for cables with known length.
•
Automatic pre-test voltage checks.
•
Identifies cable faults.
•
Tone generator with selectable tone cadence to easily trace cables
with an analog tone probe (not included).
•
Conserves power and supports long battery life with auto power off.
GENERAL SPECIFICATIONS
•
Dimensions:
6.8" x 3.15" x 1.3" (17.3 x 8.0 x 3.3 cm)
•
Weight:
12.0 oz. (340 grams) with batteries
•
Operating Temperature:
0°C /32°F to 50°C /122°F
•
Storage Temperature:
-20°C /-4°F to 60°C /140°F
•
Humidity:
10% to 90%, non-condensing
•
Altitude:
10,000 ft (3,050 m) maximum
•
Input Protection:
400V peak 50/60Hz AC or DC
•
Voltage Warning
: At maximum of Safety Extra Low Voltage
limits (60V peak AC or DC). Measurement continues while
warning is displayed.
•
Battery Low Level
: Approximately 4V
•
Battery Life
: 4 AA alkaline batteries
•
Standby:
4 years
•
Active:
15 hours (average)
•
Measurement Method:
Spread Spectrum Time Domain Reflectometry
•
NVP (VOP) Range
:
20.0 to 99.9%
•
NVP Accuracy Range:
±
1% and ±3 ft (1 m) with known NVP and
consistent cable parameters
•
Common Cable Length Ranges:
•
Coaxial:
0 to 2,000 ft
•
Data:
0 to 1,500 ft
•
Electrical:
0 to 1,000 ft
•
Tone Generation
: Constant output amplitude of 3Vpp, 4 cadences
centered around 1 kHz

3
WARNINGS
WARNINGS
To ensure safe operation and service of the tester, follow these instructions.
Failure to observe these warnings can result in severe injury or death.
•
The Ranger™ TDR should NOT be used on energized cabling
systems.
•
Connecting the instrument to voltages above the Safety Extra Low
Voltage range of less than 60V peak AC or DC may pose a safety
hazard to the user.
•
Internal components of the Ranger™ TDR are protected up to 400V
peak AC or DC. Connecting the instrument to voltages above this
range may pose a safety hazard to the user and the instrument.
SYMBOLS:
Warning: Potential for personal injury.
Caution: Potential for damage or destruction to equipment.
Always wear approved eye protection.
Do NOT use on energized circuits.
Conformité Européenne. Conforms with European
Economic Area directives.
Do not place equipment and its accessories in the trash.
Items must be properly disposed of in accordance with
local regulations.
DEFINITIONS:
Nominal Velocity
of Propogation
(NVP)
Also known as the Velocity of Propagation
(VOP), Velocity Factor (VF) and Wave
Propagation Speed, NVP is the speed of an
electrical signal traveling through a cable,
measured as a percentage of the speed of light.
Safety Extra Low
Voltage (SELV)
SELV is a rating determined by the International
Electrotechnical Commission that defines
safe voltage standards when using electronic
devices. SELV is 60V for DC systems and 42.5V
RMS for AC Systems.
F-Connector
An F-Connector is a common connector for a
coax cable, often associated with televisions.
Spread
Spectrum
Time Domain
Reflectometry
(TDR-SS)
Spread spectrum is the technological foundation
of cell phone communications and is used to
transmit small signals in high noise environments.
By combining spread spectrum with TDR
technology, TDR-SS allows for a length test on
cables without interference from voltage.

4
ENGLISH
OVERVIEW
RangerTM TDR
F-Connector (Male)
LCD Screen
Keypad

5
ACCESSORIES
The VDV501-815 kit includes several accessories to facilitate testing on
almost all popular cable types. See
Preparing to Test Cables
section to
learn how to connect the accessories for specific applications.
F-Connector Barrel Connector Coupler
(Female to Female)
F-Connector to BNC Connector Coupler
(Female to Female)
F-Connector to RJ45 Jack Adapter
(Male to Male)
F-Connector to Alligator Clips Adapter
(Male to Male)
BNC Connector to Alligator Clips Adapter
(Male to Male)

6
ENGLISH
LCD SCREEN ICONS
A. Length Adjustment Indicator:
Indicates the cable length can be
adjusted during Calibration Mode. Indicates tone style can be
changed in Tone Mode.
B. Cable Status:
Open or Short is displayed if the cable has a fault.
C. Memory Storage Locations:
Indicates the currently selected NVP
memory location.
D. Calibration Mode:
Indicates that Calibration Mode is active.
E. NVP Adjustment Indicator:
Indicates that the currently selected NVP
memory location has been edited.
F. Primary Display:
Shows numerical cable length. Shows tone
cadence in Tone Mode.
G. Unit of Measurement:
Indicates the unit of measurement (feet or
meters) currently being used to display the measurement.
H. Voltage Warning:
Indicates voltage above the SELV rating of 60V
peak AC or DC has been detected on the cable.
NOTE: The absence
of the "Voltage!" symbol DOES NOT necessarily mean that there are 0
volts on the line.
I. Tone Mode:
Indicates the unit is in Tone Mode.
J. Battery Life Indicator:
Indicates the estimated battery life of the unit.
Flashes when batteries require replacement.
K. Error Message:
Indicates an error in a test or calibration. In Test
Mode, the cable is terminated or there is excessive signal loss. In
Calibration Mode, the NVP value calculated is outside the required
range (20.0 to 99.9%).
L. NVP Value:
Shows the current NVP value used to make length
calculations.
A
B
C
D
E
F
G
H
I
J
K
L

7
KEYPAD
N
O
P
Q
R
S
M
M
Up/Down
•
In Calibration Mode: the buttons are used to adjust the
measured cable length to match the known cable length
within the range of 25ft to 1000ft (10m to 300m).
•
In Tone Mode: the buttons select a cadence (HI, LO, HL1,
HL2).
N
Memory
The Memory button is used to store up to two NVP values
for testing purposes.
•
Short presses of the Memory button toggles between the
two memory storage locations: M1 and M2.
•
A long press (two seconds) of the button stores an NVP
value in the selected storage location.
O
+
A long press (two seconds) of the Memory and Calibration
buttons simultaneously toggles between units of
measurement (feet and meters).
P
Calibration
The Calibration button allows you to discover the NVP
value based on an inputted cable length.
•
Short presses of the Calibration button adjust cable
length in increments of 50ft or 20m within the range of
50ft to 1,000ft or 20m to 300m.
•
A long press (two seconds) of the Calibration button
aborts Calibration mode and enters Test Mode.
Q
Test
The Test button initiates length testing on the connected cable.
•
A short press runs a single test on demand.
•
A long press (two seconds) of the button starts loop
testing. Pressing any button (except Power) stops loop
testing (or the unit turns off after 3 minutes).
R
Tone
The Tone button allows you to trace cables by sound.
•
A short press of the button transmits an audio tone from
the unit through the connected cable.
•
Subsequent presses of the Tone button toggle between
Test and Tone modes.
•
An analog tone probe (not included) must be used in
order to hear the tone.
S
Power
•
A long press (two seconds) of the Power button powers
on the
Ranger™ TDR.
•
Subsequent presses of the button toggle the backlight on and off.
•
A long press (two seconds) of the button powers off the
Ranger™ TDR.

8
ENGLISH
STARTUP AND SHUTDOWN
TURNING THE UNIT ON AND OFF
•
Press and hold the power button for two seconds to turn the unit on.
•
The unit will immediately run a length test at startup.
•
Press and hold the power button for two seconds to turn the unit off.
AUTO POWER OFF
The Ranger™ TDR will automatically turn off after a period of inactivity in
order to conserve battery power. The time until auto power off depends on
which mode the unit is in.
•
Test Mode: 1 minute
•
Loop Test Mode: 3 minutes
•
Tone Mode: 15 minutes
•
Calibration Mode: 1 minute
GENERAL TESTING PROCEDURES
PREPARING TO TEST CABLES
It is important that the included accessories be used correctly in order to
ensure quick and accurate testing.
IMPORTANT SAFETY INFORMATION
•
The cable to be tested should be evaluated for the presence
of voltage with a voltage measurement device by a qualified
professional before beginning work with the Ranger™ TDR. The
cable should be disconnected from any voltage source before
beginning work.
•
The "Voltage!" icon appears on the LCD when the voltage on
the cable surpasses the SELV rating of 60V peak AC or DC. The
Ranger™ TDR should be disconnected from the cable immediately
if the "Voltage!" icon appears. The Ranger™ TDR should NOT be
used on energized cabling systems.
•
Testing Coax Cable:
1.
Connect the F-connector coupler (barrel connector) to the input
port of the Ranger™ TDR by carefully screwing it in.
2.
The cable to be tested should be terminated with an F-connector
on the end that will be attached to the Ranger™ TDR.
3.
The opposite end of the cable to be tested should be left unterminated
OR terminated with an F-connector but left unconnected.
4.
Attach the cable to be tested to the Ranger™ TDR by carefully
screwing or pushing the terminated end onto the F-connector
coupler, depending on what type of F-connector was used to
terminate the cable.
•
Testing Twisted Pair (8P8C) Cable:
1.
Connect the F-connector coupler (barrel connector) to the input
port of the Ranger™ TDR by carefully screwing it in.
2.
The cable to be tested should be terminated with a female RJ45
jack on the end that will be attached to the Ranger™ TDR.
3.
The opposite end of the cable to be tested should be left unterminated
OR terminated with an RJ45 plug or jack but left unconnected.
4.
Attach the included F-connector-to-male-RJ45 plug adapter to the
Ranger™ TDR.
5.
Attach the RJ45 plug adapter end to the female RJ45 jack of the
cable being tested.

9
•
Testing Two-Conductor Cable:
1.
Connect the F-connector coupler (barrel connector) by carefully
screwing it into the input port of the Ranger™ TDR.
2.
The cable to be tested should have a pair of exposed
conductors that run side-by-side. This includes inner pairs on
twisted pair cable.
3.
The opposite end of the cable to be tested should be left open
(unconnected).
4.
Attach the included F-connector to alligator clips adapter to the
Ranger™ TDR.
5.
Securely attach the alligator clips to the exposed conductors of
the cable to be tested.
•
Testing BNC Cable:
1.
Connect the BNC coupler (barrel connector) by carefully screwing
it into the input port of the Ranger™ TDR.
2.
The cable should be terminated with a BNC connector.
3.
The opposite end of the cable to be tested should be left
unterminated OR terminated with a BNC connector but left
unconnected.
4.
Attach the BNC connector of the cable to be tested to the female
BNC connector on the Ranger™ TDR.
OBTAINING NVP VALUES
There are three ways to obtain NVP values for a cable.
1.
The NVP can usually be obtained by checking the cable specifications
or contacting the manufacturer.
2.
The NVP can be estimated based on the type of cable (RG6, Cat5e,
etc.) using the chart on page 13.
3.
The NVP can be calculated using a known length of the cable that
will be used during testing.
•
Calculating an NVP:
1.
Prepare a length of the same type of cable for which you need to
determine the NVP.
2.
The Ranger™ TDR can calculate an NVP from a test cable length
of 25~1000ft (10~300m). Longer test lengths will give more
accurate results. It is recommended to use at least 50ft (20m).
50ft (20m) is the default setting in Calibration Mode.
3.
Determine the physical length of the test cable length. Use the
markings on the cable, a tape measure, laser distance meter, etc.
4.
Connect the test cable length to the Ranger™ TDR as described in
"Preparing to Test Cables" section.
5.
Press the Power button on the Ranger™ TDR.
6.
Press the Calibration button.
7.
Select the unit of measurement (feet or meters) by pressing and
holding the Memory and Calibration buttons at the same time.
8.
Enter the known cable length using the Calibration button and Up
and Down buttons. The Calibration button adds 50ft (20m) with
each press. The Up and Down buttons increase or decrease the
distance by 1ft or 1m per press.
9.
Press the Test button. After a few seconds, the calculated NVP
will appear in the bottom left corner of the LCD.
10.
Press and hold the Memory button to save the new NVP in the
current storage location (M1 or M2).
11.
If the calculated NVP is outside of the range 20.0 to 99.9, the LCD
will display "Error".

10
ENGLISH
Step 6
Step 9
Step 11
SETTING NVP VALUES
The NVP value must be set correctly in order to obtain an accurate length
measurement from the device.
•
Manually Setting NVP:
1.
Press the Power button. The unit will start up in Test Mode.
2.
Use the Up and Down buttons to set the NVP value shown in the
lower left hand corner of the LCD screen.
3.
Pressing and holding a button will change the value more quickly.
•
Saving NVP:
1.
The Ranger™ TDR has two storage locations for NVP values.
2.
Press the Memory button repeatedly to toggle between memory
locations.
3.
Set the memory location using the procedure noted above.
4.
Press and hold the Memory button. The up and down arrows
shown on the LCD screen will disappear when the new value has
been stored.
5.
Recall a stored value by pressing the Memory button until the
desired memory location is shown.
TESTING CABLE & DETERMINING LENGTH
Once a cable's NVP value has been set, the cable length can be determined
using Test Mode. As stated in
Preparing to Test Cables,
the cable to be
tested should be left open on the opposite end from the tester.
A cable
terminated with an impedance closely matching the characteristic
impedance of the cable can produce inaccurate test results.
•
Testing Cable:
1.
Attach the cable to be tested as instructed in
Preparing to Test
Cables
section.
Cables section.Cables

11
2.
Note that the connection to the cable to be tested should be as
short as possible to ensure the Ranger™ TDR does not see the
impedance continuity at the attachment point as a fault.
3.
Determine the correct NVP value for the cable to be tested as
instructed in
Obtaining NVP Values
section.
Obtaining NVP Values section.Obtaining NVP Values
4.
Set the NVP value as instructed in
Setting NVP Values
section.
Setting NVP Values section.Setting NVP Values
5.
Turn the unit on by pressing the Power button.
6.
Change the unit of measurement if necessary by pressing and
holding the Memory and Calibration buttons at the same time.
7.
Press the Test button once. After a moment, the calculated length of
the cable will appear in the upper right hand corner of the screen.
8.
The screen will display "Short" if the two conductors are directly
connected or have a low resistance connection between them.
The length will be shown up to the shorted point.
9.
The screen will display "Open" if the two conductors are not
directly connected or have a high resistance connection between
them. This is the normal condition for performing length testing.
If there is an unexpected open condition along the length of the
cable, only the length up to that point will be displayed.
10.
The screen will display "Error" and show dashes instead of the
length if an error condition has occurred. This could be because
the cable is improperly terminated or there has been excessive
signal loss.
Step 7
Step 10
•
Using Loop Testing Mode:
The Ranger™ TDR can run continuous tests when set to Loop Mode.
Loop Mode can help when testing long cable runs susceptible to
signal loss, and enabling you to test multiple cables without having to
press the Test button each time.
1.
While in Test Mode, press and hold the Test button.
2.
The screen will momentarily flash "LOOP", then run a test every
two seconds and display the results.
3.
Pressing any other button except the Power button exits
Loop Mode.

12
ENGLISH
Step 1
TONING CABLE
Tone Mode can be used to trace cables by sound. A cadence is emitted
from the unit through a connected cable. The cadence can only be
detected and amplified with an analog tone probe, such as the Klein Tools
PROBEplus tone tracing probe (VDV500-060) not included, and is not
audible to the human ear without the probe.
•
Enabling Tone Mode:
1.
Attach the cable to be toned as instructed in
Preparing to Test
Cables
section.
Cables section.Cables
2.
Press the Power button.
3.
Press the Tone button (two music notes).
4.
Press the Up button or Down button to switch cadences (HI, LO,
HL1, HL2).
5.
Use a tone probe to trace the cable being toned.
6.
See the tone probe's instruction manual for more information on
how to tone cables.
Step 3

13
COMMON NVP VALUES
Below is a list of NVP values for common types.
Cable Type
NVP
Range
Coaxial Cable
RG58
65.4
64.5 - 66.4
RG59
83.9
83.0 - 85.0
RG6U
84.6
83.5 - 85.5
RG6 Quad Shield
84.9
84.0 - 86.0
Phone Cable
CAT3 4-Pair
67.3
65.5 - 68.0
CAT3 3 Pair CMX
67.5
66.5 - 68.1
24/25 Pair CAT3
64.0
63.0 - 65.0
Data Cable
CAT5e (Orange/Orange White)
65.9
65.0 - 67.0
CAT5e STP
65.2
64.2 - 66.2
CAT5e FTP
73.1
72.1 - 74.1
24/25 Pair CAT5e
71.0
70.0 - 72.0
CAT6
68.8
67.5 - 69.5
Electrical Cable
10/2 NM Coiled
68.8
68.0 - 70.0
10/2 NM Uncoiled
71.2
70.2 - 72.2
12/2 NM Coiled
67.1
66.0 - 68.0
12/2 NM Uncoiled
73.2
72.0 - 74.0
12/3 NM Coiled
63.7
63.0 - 64.5
12/3 NM Uncoiled
70.6
69.5 - 71.5
12/3 NM Twisted Coiled
68.4
67.8 - 69.4
12/3 NM Twisted Uncoiled
68.4
67.8 - 69.0
14/2 NM Coiled
66.4
65.0 - 68.6
14/2 NM Uncoiled
71.9
71.0 - 73.0
14/3 NM Coiled
64.8
64.0 - 65.5
14/3 NM Uncoiled
68.6
67.5 - 69.5
Security Cable
12/2 Fire PLN
59.9
59.0 - 60.9
16/2 Fire PVC
65.9
65.0 - 67.0
18/4 Fire PLN
60.4
59.5 - 61.5
18/6 Fire PLN
61.6
60.5 - 62.5
14/2 Audio Cable
71.0
70.0 - 72.0

14
ENGLISH
BATTERY REPLACEMENT
1. Remove
single screw in the middle of the back of the Ranger™ TDR
with a #1 Phillips head screwdriver. Remove battery door.
2. Remove
and recycle exhausted batteries.
3. Acquire
4 AA 1.5V alkaline batteries (IEC LR6, ANSI/NEDA 15A).
4. Insert
batteries into the battery compartment observing the polarity
marked inside the case.
5. Replace
battery door and screw, taking care not to over-tighten it.
WARRANTY
This product is warranted to be free from defects in materials and work-
manship for a period of two years from the date of purchase. During this
warranty period, Klein Tools has the option to repair or replace or refund
the purchase price of any unit which fails to conform to this warranty
under normal use and service. This warranty does not cover dam-
age which occurs in shipment or failure which results from alteration,
tampering, accident, misuse, abuse, neglect, or improper maintenance.
Batteries and damage resulting from failed batteries are not covered by
warranty. A purchase receipt or other proof of original purchase date will
be required before warranty repairs will be rendered.
Any implied warranties, including but not limited to implied warranties
of merchantability and fitness for a particular purpose, are limited to the
express warranty. Klein Tools shall not be liable for loss of use of the
instrument or other incidental or consequential damages, expenses, or
economic loss, or for any claim or claims for such damage, expenses or
economic loss.
Some states or countries laws vary, so the above limitations or exclu-
sions may not apply to you. This warranty gives you specific legal rights,
and you may also have other rights which vary from state to state. If
your Klein product requires repair or for information on how to exercise
your rights under the terms of this warranty, please contact Klein Tools
at 1-800-553-4676.
CLEANING
Turn instrument off and disconnect any cables. Clean the instrument by
using a damp cloth. Do not use abrasive cleaners or solvents.
STORAGE
Remove the batteries when instrument is not in use for a prolonged
period of time. Do not expose to high temperatures or humidity. After a
period of storage in extreme conditions exceeding the limits mentioned
in the
Specifications
section, allow the instrument to return to normal
Specifications section, allow the instrument to return to normalSpecifications
operating conditions before using it.
DISPOSAL /RECYCLE
This symbol indicates that equipment and its accessories
shall be subject to a separate collection and correct disposal.
CUSTOMER SERVICE
KLEIN TOOLS, INC.
•
450 Bond Street
•
Lincolnshire, IL 60069
1-800-553-4676 •
www.kleintools.com


www.kleintools.com
Manual de
instrucciones
For Professionals...Since 1857
®
TDR Ranger
™
VDV501-090
ESPAÑOL
•
MEDIDOR DE
LONGITUD
DE CABLE
•
LOCALIZADOR
DE FALLAS
EN CABLE
•
GENERADOR
DE TONOS
•
ADMINISTRADOR
DE CABLE

16
ESPAÑOL
CARACTERÍSTICAS
El TDR Ranger™ de Klein Tools es un reflectómetro en el dominio de
tiempo (TDR) portátil y comprobador de cable de voz-datos-video. Mide
longitud de cable, calibra valores de velocidad de propagación nominal
(VPN), localiza fallas en cables y brinda generación de tonos incorporada
para rastrear cables.
•
Precisión de longitud de
±
1% y
±3 pies (1 m)
.
•
Almacena hasta dos valores de VPN.
•
Muestra la lectura de longitud en pies o metros.
•
Pantalla de LCD extragrande de siete segmentos con iluminación de fondo.
•
Comprueba la mayoría de tipos de cable de cobre, incluyendo cables
de datos, voz, video, alambre de lámpara, siameses, y NM.
•
Descubre valores de VPN para cables con longitud conocida.
•
Revis
iones automáticas de tensión antes de realizar comprobaciones.
•
Identifica fallas en cables.
•
Generador de tonos con cadencia de tonos seleccionable para
rastrear fácilmente los cables con un probador de tonos analógico
(no incluido).
•
Conserva energía y respalda una vida útil larga de las pilas con el
apagado automático.
ESPECIFICACIONES GENERALES
•
Dimensiones:
6,8 x 3,15 x 1,3 pulgadas (17,3 x 8,0 x 3,3 cm)
•
Peso:
12,0 onzas (340 g) con pilas
•
Temperatura de funcionamiento:
0 °C /32 °F a 50 °C / 122 °F
•
Temperatura de almacenamiento:
-20 °C/ -4 °F a 60 °C / 140 °F
•
Humedad:
10% a 90%, incondensable
•
Altitud:
10.000 pies (3.050 m) como máximo
•
Protección de entrada:
400 V pico 50/60 Hz CA o CC
•
Advertencia de tensión:
En el máximo de los límites de tensión
extrabaja de seguridad (60 V pico de CA o CC). La medición continúa
mientras se muestra la advertencia.
•
Nivel bajo de las pilas:
Aproximadamente 4 V
•
Vida útil de las pilas:
4 pilas alcalinas AA
•
En espera:
4 años
•
En activo:
15 horas (promedio)
•
Método de medición:
Reflectometría en dominio de tiempo de
espectro ensanchado
•
Intervalo de VPN (VDP):
20,0 a 99,9%
•
Intervalo de precisión de la VPN:
±1% and ±3 pies (1 m) con una
VPN conocida y parámetros de cable uniformes
•
Intervalos de longitud de cables comunes:
•
Coaxial:
0 a 2,000 pies
•
De datos:
0 a 1,500 pies
•
Eléctrico:
0 a 1,000 pies
•
Generación de tonos:
Amplitud de salida constante de 3 V de pico
a pico, 4 cadencias centradas alrededor de 1 kHz

17
ADVERTENCIAS
Para asegurar un funcionamiento y un servicio seguros del comprobador,
siga estas instrucciones. Si no se hace caso de estas advertencias, el
resultado puede ser lesiones graves o muerte.
•
El TDR Ranger™ NO se debe utilizar en sistemas de cableado que
tengan corriente eléctrica.
•
Si se conecta el instrumento a tensiones por encima del intervalo de
tensión extrabaja de seguridad de menos de 60 V pico de CA o CC, se
puede crear un peligro para la seguridad del usuario.
•
Los componentes internos del TDR Ranger™ están protegidos hasta
400 V pico de CA o CC. Si se conecta el instrumento a tensiones por
encima de este límite, se puede crear un peligro para la seguridad del
usuario y del instrumento.
SÍMBOLOS:
Advertencia: Potencial de lesiones corporales.
Precaución: Potencial de daños al equipo o destrucción
del mismo.
Use siempre protección visual aprobada.
NO utilice la unidad en circuitos que tengan corriente
eléctrica.
Conformité Européenne. Cumple con las directrices del
Área Económica Europea.
Conformité Européenne. Cumple con las directrices del
Área Económica Europea.
Conformité Européenne. Cumple con las directrices del
No ponga el equipo ni sus accesorios en la basura. Los
artículos se deben desechar apropiadamente de acuerdo
con los reglamentos locales.
DEFINICIONES:
Velocidad de
propagación
nominal (VPN)
Conocida también como velocidad de
propagación (VDP), factor de velocidad (FV) y
velocidad de propagación de las ondas, la VPN
es la velocidad de una señal eléctrica que viaja
por un cable, medida como porcentaje de la
velocidad de la luz.
Tensión extrabaja
de seguridad
(TEBS)
La TEBS es una calificación determinada por
la Comisión Electrotécnica Internacional, que
define los estándares de tensión segura cuando
se utilizan dispositivos electrónicos. La TEBS
es 60 V para sistemas de CC y 42,5 V de valor
eficaz (RMS) para sistemas de CA.
Conector F
Un conector F es un conector común para
un cable coaxial, asociado a menudo con
televisores.
Reflectometría
en dominio
de tiempo
de espectro
ensanchado
(TDR-SS)
El espectro ensanchado es la base tecnológica
de las comunicaciones de los teléfonos celulares
y se utiliza para transmitir señales pequeñas en
entornos con niveles elevados de ruido. Al
combinar el espectro ensanchado con la
tecnología TDR, la TDR-SS permite realizar una
prueba de longitud en cables sin interferencia de
la tensión.

18
ESPAÑOL
GENERALIDADES
RangerTM TDR
Conector F (macho)
Pantalla
de LCD
Teclado

19
ACCESORIOS
El kit VDV501-815 incluye varios accesorios para facilitar la comprobación
en casi todos los tipos populares de cable. Consulte la sección
Preparación
para comprobar cables
con el fin de saber cómo conectar los accesorios
para comprobar cables con el fin de saber cómo conectar los accesoriospara comprobar cables
para aplicaciones específicas.
Acoplador de conector cilíndrico para
conector F
(hembra a hembra)
Acoplador de conector F a conector BNC
(hembra a hembra)
Adaptador de conector F
a conector hembra RJ45
(macho a macho)
Adaptador de conector F a pinzas de cocodrilo
(macho a macho)
Adaptador de conector BNC a pinzas de cocodrilo
(macho a macho)

20
ESPAÑOL
ICONOS DE LA PANTALLA DE LCD
A. Indicador de ajuste de longitud:
Indica la longitud de cable que se
puede ajustar durante el modo de calibración. Indica que el estilo de
tono se puede cambiar en el modo de tono.
B. Estado del cable:
Se muestra Open (Abierto) o Short
(Cortocircuitado) si el cable tiene una falla.
C. Ubicaciones de almacenamiento en memoria:
Indica la ubicación
de memoria de VPN seleccionada actualmente.
D. Modo de calibración:
Indica que el modo de calibración está activo.
E. Indicador de ajuste de VPN:
Indica que la ubicación de memoria de
VPN seleccionada actualmente ha sido editada.
F. Visualización primaria:
Muestra la longitud numérica del cable.
Muestra la cadencia de tono en el modo de tono.
G. Unidad de medida:
Indica la unidad de medida (pies o metros) que
se está utilizando actualmente para mostrar la medición.
H. Advertencia de tensión:
Indica que se ha detectado tensión en el
cable por encima de la capacidad nominal de TEBS de 60 V pico
de CA o CC.
NOTA: La ausencia del icono de tensión “Voltage!” NO
significa necesariamente que haya 0 V en la línea.
I. Modo de tono:
Indica que la unidad está en el modo de tono.
J. Indicador de vida útil de las pilas:
Indica la vida útil estimada de las
pilas de la unidad. Parpadea cuando las pilas requieren reemplazo.
K. Mensaje de error:
Indica un error en una prueba o una calibración.
En el modo de prueba, el cable está terminado o hay una pérdida
excesiva de señal. En el modo de calibración, el valor de VPN
calculado está fuera del intervalo requerido (20,0 a 99,9%).
L. Valor de VPN:
Muestra el valor actual de VPN utilizado para hacer
los cálculos de longitud.
A
B
C
D
E
F
G
H
I
J
K
L
