Klever Kleena K-Bot SX1 User manual

Robotic Pool Cleaner K-Bot SX1
User Instructions.......................... p. 1
EN
8151665
SATURN SERIES

1
Robotic Pool Cleaner K-Bot Saturn Series SX1 | |User Instructions
Robotic Pool Cleaner
K-Bot Saturn Series SX1
User Instructions
EN
Contents
1. INTRODUCTION ...................................................................... 2
2. SPECIFICATIONS ..................................................................... 2
3. WARNINGS AND CAUTIONS .................................................. 2
3.1 Warnings ............................................................................ 2
3.2 Cautions............................................................................. 2
4. POOL CLEANER PARTS ........................................................... 3
5. USING THE POOL CLEANER ................................................... 4
5.1 Setup ................................................................................. 4
5.2 Putting the Pool Cleaner into the pool ............................. 5
5.3 Removing the Pool Cleaner from the pool ........................ 5
6. CLEANING THE FILTER BASKET.............................................. 7
6.1 Cleaning after use ............................................................. 7
6.2 Periodic cleaning ............................................................... 8
7. CLEANING THE NET CANISTER ............................................. 9
8. CLEANING THE IMPELLER ...................................................... 10
9. OFF-SEASON STORAGE ......................................................... 11
10. TROUBLESHOOTING .............................................................. 11

2
Robotic Pool Cleaner K-Bot Saturn Series SX1 |Instructions User
Robotic Pool Cleaner K-Bot Saturn Series SX1
User Instructions
1. INTRODUCTION
Thank you for purchasing your new K-Bot Pool Cleaner.
We are sure that your Robotic Pool Cleaner will provide you with reliable, convenient and cost-
effective pool cleaning, that includes filtration in all pool conditions with active brushing to
enhance pool hygiene.
Robotic Pool Cleaners deliver advanced cleaning technology, long-lasting performance and
easy maintenance. You and your family will be free to enjoy your swim with full confidence that
your pool is completely clean.
2. SPECIFICATIONS
Motor protection: IP 68
Minimum depth: 0.80m/2.6ft
Maximum depth: 5m/16.4ft
3. WARNINGS AND CAUTIONS
3.1 Warnings
•Use the originally supplied power supply only
•Ensure the electrical outlet is protected by a ground fault interrupter (GFI) or an
earth leakage interrupter (ELI)
•Keep the power supply out of standing water
•Position the power supply at least 3m/10ft away from the edge of the pool
•Do not enter the pool while the Pool Cleaner is working
•Unplug the power supply before servicing
3.2 Cautions
Use the Pool Cleaner in the following water conditions only:
Chlorine Maximum 4 ppm
pH 7.0-7.8
Temperature 6-34°C/ 43-93°F
NaCl Maximum 5000 ppm
CAUTION
Digital Power supply
Input: 100-130 AC Volts / 200-230 AC Volts
50-60 Hertz
Output: <30 VDC
IP 54

3
Robotic Pool Cleaner K-Bot Saturn Series SX1 | |User Instructions
4. POOL CLEANER PARTS
Robotic Pool Cleaner Model K-Bot Saturn Series SX1
Power supply unit
Filtration - options
Net Canister
included with SX1
SX1 Optional upgrade SX1 Optional upgrade
Ultra-Fine Filter Basket Filter Basket Net Panels

4
Robotic Pool Cleaner K-Bot Saturn Series SX1 |Instructions User
5. USING THE POOL CLEANER
5.1 Setup
Before using the Pool Cleaner for the first time, perform the following steps:
Position the power supply so
that it is approximately in the middle
of the long side of the pool at
a distance of 3m/10ft.
Unwind the cable and stretch it out completely so that
it has no kinks.
Attach the floating cable to the power
supply by inserting it with the notch on the
connector (1), lined up with the groove in
the socket on the power supply, and turning
clockwise (2).
Plug in the power supply and leave it in the
OFF position.
5.1.1
5.1.4
5.1.2
5.1.3
1
2
3m/10ft

5
Robotic Pool Cleaner K-Bot Saturn Series SX1 | |User Instructions
5.2 Putting the Pool Cleaner into the pool
5.3 Removing the Pool Cleaner from the pool
CAUTION
Turn OFF and unplug the power supply.
Put the Pool Cleaner into the pool.
Release the Pool Cleaner and let it sink to the floor
of the pool.
Make sure that the floating cable is free of any
obstructions.
5.2.1
Turn the power supply ON.
The Pool Cleaner will now operate until it has
reached the end of the cleaning cycle.
5.2.2
5.3.1
ON

6
Robotic Pool Cleaner K-Bot Saturn Series SX1 |Instructions User
CAUTION
DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE.
Using the floating cable, bring the Pool Cleaner to the pool’s edge.
Using the handle, remove the Pool Cleaner from the pool.
Place the Pool Cleaner on the edge of the
pool and let the water drain out.
5.3.3
5.3.2

7
Robotic Pool Cleaner K-Bot Saturn Series SX1 | |User Instructions
6. CLEANING THE FILTER BASKET (SX1 optional upgrade)
CAUTION
Make sure the power supply is switched off and unplugged.
It is highly recommended to clean the filter basket after each cleaning cycle.
Note: Do not let the filter basket dry out before cleaning.
Open the filter cover. Upon opening the filter cover,
the handle will lift independently.
6.1.1 6.1.2
Lift up the basket. Open the latch
to release the bottom
lid in order to remove
the debris.
6.1.3 6.1.4 Clean the filter basket with a hose. 6.1.5
1
2
6.1 Cleaning after use - removing and cleaning the filter basket

8
Robotic Pool Cleaner K-Bot Saturn Series SX1 |Instructions User
Dismantle the 2 ultra-fine filter panels of the basket, according to the following steps:
Insert the clean filter basket and
close the filter cover.
6.2.4
6.2 Periodic cleaning – recommended at least once a month
Clean the filter panels with a hose.
Assemble the filter panels .
Dismantle the 2 panels using your thumbs.
6.2.2 6.2.3
6.2.1

9
Robotic Pool Cleaner K-Bot Saturn Series SX1 | |User Instructions
7. CLEANING THE NET CANISTER (Included with SX1)
CAUTION
Make sure the power supply is switched off and unplugged.
It is highly recommended to clean the net canister after each cleaning cycle.
Note: Do not let the net canister dry out before cleaning.
7.1 Cleaning after use - removing and cleaning the net canister
Open the filter cover. Lift up the net canister.
7.1.1 7.1.2
Clean the net canister with a hose.
7.1.3

10
Robotic Pool Cleaner K-Bot Saturn Series SX1 |Instructions User
CAUTION
Make sure the power supply is switched off and unplugged.
8.1 Clean the debris trapped in the impeller opening, according to the
following steps:
8. CLEANING THE IMPELLER
If you notice debris trapped in the impeller:
Pull the impeller cover backwards to release it.
Clean the debris trapped around the impeller.
Assemble the impeller cover.
8.1.3
If the debris is not reachable follow the next
steps.
8.1.1 Using a short
screwdriver open the
2 screws.
8.1.2

11
Robotic Pool Cleaner K-Bot Saturn Series SX1 | |User Instructions
If the Pool Cleaner will not be in use for an extended period of time, perform the following storage steps:
If the suggested solutions do not solve the problem, please contact your dealer or Service Center.
•Make sure that no water is left in the Pool Cleaner
•Thoroughly clean the filter basket and panels/canister and insert in place
•Roll up the cable so that it has no kinks
•Store the Pool Cleaner in a protected area out of direct sun/ rain/frost, at a temperature of between
5°-45°C/41°-113°F
9. OFF-SEASON STORAGE
10. TROUBLESHOOTING
Symptom Possible reason Corrective action
The power-supply
or its switch led
are not working.
•No voltage in the power socket in the wall.
•The power supply is not switched ON.
•The power cable is not well connected
into the power supply inlet.
•Check that there is voltage in the power socket in the wall.
•Check that the power supply is plugged in and turned ON.
•Check that the power cable is securely connected all the way
into the power supply.
•Turn the power supply off. Wait 30 seconds then turn it back on.
The Pool Cleaner
does not move. •The floating cable is not well connected into the power supply outlet.
•An obstacle blocks the impeller,
tracks or wheels.
•Check that the floating cable is securely connected all the way
into the power supply.
•Unplug the power supply. Open the impeller cover
and check that nothing is trapped in the impeller.
Verify that nothing blocks the tracks or wheels.
The Pool Cleaner
is moving in
circles.
•Clogged filter basket/canister.
•Debris stuck in the impeller-house or
impeller-cover.
•Power supply incorrectly positioned.
•Algae or pool water is out of Spec.
•Clean the filter basket/canister.
•Remove debris stuck in the impeller-house or impeller-cover
(according to the drawings).
•Place power supply in a position so that the Pool Cleaner
can freely reach all the pool area.
•Correct pool and water conditions.
The Pool Cleaner
does not turn
or moves in one
direction only.
•Debris stuck in the impeller-house
or impeller-cover. •Remove debris stuck in the impeller-house or impeller-cover
(according to the drawings).
The Pool Cleaner
moves but does
not clean the
pool.
•Clogged filter basket/canister.
•Debris stuck in the impeller-house or
impeller-cover.
•Clean the filter basket/canister.
•Remove debris stuck in the impeller-house or impeller-cover
(according to the drawings).
The Pool Cleaner
cleans only part
of the pool.
•Power supply incorrectly positioned.
•Not enough floating is released for the
correct operation of the Pool Cleaner.
•Place the power supply in a position so that the Pool Cleaner
can freely reach all the pool area.
•Check that there is enough slack in the floating cable
for the Pool Cleaner to reach all of the pool.
•Clean the filter basket/canister.
The floating cable
has kinks. •Clogged filter basket/canister.
•Debris stuck in the impeller-house or
impeller-cover.
•Clean the filter basket/canister.
•Remove debris stuck in the impeller-house or impeller-cover
(according to the drawings).
•To remove the kinks, stretch the floating cable out completely
and let it sit for at least a day in the sun.
The Pool Cleaner
doesn’t climb
the walls.
•Clogged filter basket/canister.
•Algae on walls.
•Unsuitable pH level.
•Debris stuck in the impeller-house or
impeller-cover.
•Clean the filter basket/canister.
•Check the level of the chemicals of the water. Improper levels
may allow the growth of algae making the walls slippery.
If so, adjust the levels and scrub the walls.
•Remove debris stuck in the impeller-house or impeller-cover
(according to the drawings).
