Klimawent KILLVIR-48 User manual

Orginal instruction E25.01.2021
EN
USER MANUAL 800Z01
Ozone generator KILLVIR-48
KLIMAWENT S.A. Poland
194 Chwaszczyńska street, 81-571 Gdynia
phone: [phone]
fax: [phone]
e-mail: [e-mail]
www.klimawent.com.pl
800Z01 KILLVIR-48
EN E2021-01-25

Klimawent – the warranty of highest quality at attractive price
2 of 12 Ozone generator KILLVIR-48 25.01.2021
TAB LE OF CO NTEN TS
INTRODUCTION ....................................................................................................................................... 3
APPLICATION ........................................................................................................................................... 3
MANUFACTURER'S DISCLAIMER ......................................................................................................... 3
TECHNICAL DATA.................................................................................................................................... 4
STRUCTURE AND FUNCTION................................................................................................................ 4
INSTALLATION AND COMMISSIONING ............................................................................................... 4
OPERATION .............................................................................................................................................. 5
TROUBLESHOOTING GUIDE ................................................................................................................. 7
MAINTENANCE AND RECYCLING INSTRUCTIONS ........................................................................... 7
OHS MANUAL ........................................................................................................................................... 7
STORAGE .................................................................................................................................................. 8
TERMS OF WARRANTY .......................................................................................................................... 8
RESIDUAL RISK INFORMATION ............................................................................................................ 8
EXAMPLE OF EC DECLARATION OF CONFORMITY ....................................................................... 10
WIRING DIAGRAMS ............................................................................................................................... 11

Klimawent – the warranty of highest quality at attractive price
25.01.2021 Ozone generator KILLVIR-48 3 of 12
INTRODUCTION
This user manual is intended for the users of the KILLVIR-48 device. Its purpose is to provide the users with
instructions on the use, assembly, commissioning, and operation of the device.
NOTICE
Carefully read this manual before installing the device at the workplace and using it.
Due to the continuous improvement of its products, the manufacturer reserves the right to introduce
construction changes to increase the utility values and safety of use.
The design of the KILLVIR-48 device takes into account the current state of knowledge and technology level
and is following normative principles and regulations, and above all with the principles of safety and health
protection set out in the following legal acts and also meets the requirements of the following harmonised
standards:
 Directive 2006/42/EC (MD)
 Directive 2014/35/EU (LVD)
 Directive 2014/30/EU (EMC)
 PN-EN ISO-12100:2012
 PN-EN 60204-1:2018-12
 PN-EN 60034-1:2011
 PN-EN 60529:2003/A2:2014-07
 PN-EN ISO-13857:2020-03
 PN-EN IEC 61000-6-1:2019-03
 PN-EN ISO 14123-1:2016-03
 PN-EN 1005-2+A1:2010
 PN-EN 842+A1:2010
APPLICATION
The KILLVIR-48 ozone generator is designed for ozonation and deodorization of closed rooms with a volume
of up to 450 m3.
NOTICE
The KILLVIR-48 ozone generator can be used to inactivate virus particles in the air while maintaining
the appropriate proportions of the exposure time of the atmosphere inside the room to ozone and
the size of the room.
Table 1 Approximate ozonation times
The size of the room Ozonation time
150 m2 (volume ~450m3) 90 min
75 m2 (volume ~225m3) 45 min
MANUFACTURER'S DISCLAIMER
 The manufacturer is not liable for damages resulting from the incorrect connection of the power supply
and improper use of the device.
 It is unacceptable to install any additional elements not included in the device or equipment on the device.
 Unauthorized alterations and modifications to the device are not allowed.
 The device should be operated and repaired by an authorized and trained person.
 Protect all machine components against mechanical damage.
 The manufacturer is not responsible for bodily injury resulting from incorrect use.
 Protect people, animals and plants from the harmful effects of ozone.
 Protect ozone-sensitive materials.
 Protect the device from falling as it may permanently damage the generator.

Klimawent – the warranty of highest quality at attractive price
4 of 12 Ozone generator KILLVIR-48 25.01.2021
! DANGER
The KILLVIR-48 ozone generator should be used in compliance with the safety
and hygiene regulations! Ozone [O3], which is the result of the device's
operation and at the same time an agent with strong biocidal, antiseptic, and
oxidizing properties, is used in disinfection and at the same time is harmful to
human health, also in the form of ozonation treatment residues.
TECHNICAL DATA
Ozone generator KILLVIR-48 produces 15 g/h volatile ozone.
Table 2 Technical data of ozone generator KILLVIR-48
Type Part no.
Maximum
volume flow of
ozonu (O3) [g/h]
Fan
maximum
volume
flow [m3/h]
Motor
power
[W]
Supply
voltage
[V, Hz]
Sound
pressure
level
[dB(A)]
Mass
[kg]
Ingress
protection
KILLVIR-48
8
00
Z
01
48
2×350 250 230V, 50Hz 60 8 IP20
Device dimensions (L×W×H):
600 × 390 × 250 mm
NOTICE
The life of the ozone generator installed in the device – 6000 working hours.
STRUCTURE AND FUNCTION
Principle of operation and function
The principle of operation of the KILLVIR-48 device is based on the production of ozone in a volatile state as
a result of the phenomenon of partial discharges on the surfaces of ionizing plates. A fan located on one of the
walls forces air through the inside of the device and blows the ozone generated outside into the room.
Structure
The KILLVIR-48 ozone generator has the following components:
 Perforated metal housing with handle.
 2 axial fans forcing the airflow inside the generator.
 2 ozone production units with a summary capacity of 48 g/h of volatile ozone.
 Control panel.
INSTALLATION AND COMMISSIONING
Installation
The KILLVIR-48 ozone generator can only be operated in a closed room, protected against the effects of
precipitation, moisture and dust.
Before using the KILLVIR-48 device, check that the device is complete, undamaged, has no dents, has an
undamaged connection socket, power cord and a legible nameplate, etc.
NOTICE
The KILLVIR-48 ozone generator is delivered fully assembled and ready to use.
Connecting the power supply
The KILLVIR-48 device has an IEC 10A, 250VAC socket and a 3 m power cord with a grounded plug.

Klimawent – the warranty of highest quality at attractive price
25.01.2021 Ozone generator KILLVIR-48 5 of 12
! WARNING
The device must be connected to a 230 V, 50 Hz earthed socket.
OPERATION
The operation of the KILLVIR-48 ozone generator consists in turning the device on and off and controlling the
working time – see Picture 1 Control panel.
The control panel includes a socket for connecting the power cord with grounding, an illuminated O / I switch,
a display with operating time control buttons and a warning lamp "DISINFECTION – DO NOT ENTER". Before
starting, check that the power cord is not damaged.
Picture 1 Control panel
Procedure
Installation
A. Place the device as high as possible and in the centre of the room.
B. Before starting, check that the power cord is not damaged.
NOTICE
Ozone is a gas heavier than air and it falls.
Turning on the device
A. Plug the power cord into the power socket of the device.
! WARNING
The device must be connected to a 230 V, 50 Hz earthed socket.
B. Turn the "POWER SWITCH" switch to position I. The switch will be illuminated red.
C. Set the ozonation time using the + and – buttons according to the room volume - see - Table 1
Approximate ozonation times.
D. Press the START button to start ozonation. The "DISINFECTION – DO NOT ENTER" warning light will
illuminate. The dot in the lower right corner will flash on the display.
E. Leave the room – see Note 1 Warning regarding ozonation.

Klimawent – the warranty of highest quality at attractive price
6 of 12 Ozone generator KILLVIR-48 25.01.2021
F. Secure the entrance to the room and mark with an information sign with the appropriate content, e.g.
DO NOT ENTER! OZONATION or NO ENTRY! DISINFECTION WITH OZONE.
! WARNING
DO NOT go into the room when the light is on warning "DISINFECTION – DO NOT ENTER"
without adequate protection!
Operation
A. The device will automatically finish ozonation after the set time has elapsed, and the fan will continue
to work for another 30 minutes, mixing the air in the room.
! CAUTION
The fan of the device continues to work 30 minutes after the end of ozonation, which is
signalled by the warning light "DISINFECTION - DO NOT ENTER".
When the time reaches 0 value, the device stops working, and the time on the display will
return to the previously set time.
B. After the warning light goes out, you can enter the room and take the device away, observing the safety
rules described below in the warning (Note 1 Warning regarding ozonation) and point 10 - OHS
INSTRUCTIONS.
Turning off the device
A. Turn the “POWER SWITCH” switch to the position O. The switch turns off. The device will stop
working.
B. Disconnect the power cord from the power socket.
C. Ventilate the room for at least 15 minutes.
! CAUTION
If no one is left in the room after ozonation, you can leave it unventilated and let the ozone
decompose itself. Then the room will be ready for use after at least 1 hour.

Klimawent – the warranty of highest quality at attractive price
25.01.2021 Ozone generator KILLVIR-48 7 of 12
TROUBLESHOOTING GUIDE
Table 3 Typical disturbances and remedies
Disturbances Possible causes Remedies
The device does not turn on Incorrectly connected or damaged
power cord
Check and correctly insert the
cable into the device and power
socket
The device turns on,
but the fan is not running Blocked or broken fan Contact the manufacturer
KLIMAWENT S.A.
The device turns on but
produces no ozone
Blocked or damaged fan or ozone
generator
Contact the manufacturer
KLIMAWENT S.A.
MAINTENANCE AND RECYCLING INSTRUCTIONS
Maintenance
The design of the device enables continuous operation provided it is properly used and does not require
maintenance from the user. All repairs and maintenance are performed by the manufacturer or his representative.
Recycling and cassation
! CAUTION
When the product is transferred for cassation, the provisions on the erasing of machines
withdrawn from use and/or recycling of waste should be applied. No part of the
construction of the device belongs to the hazardous waste group.
OHS MANUAL
! CAUTION
The device, according to the definition, is a machine and meets the safety requirements
of Directive 2006/42/EC and does not require additional safeguards for safe use, but
requires careful use and compliance with the operating procedure - see 7 – OPERATION
and 13 – RESIDUAL RISK INFORMATION!
Use personal protective equipment and protective clothing while operating the working
device! The KILLVIR-48 ozone generator should be used in compliance with the safety
and hygiene regulations! Ozone is an agent with strong biocidal, antiseptic and oxidizing
properties and, at the same time, is harmful to human health, also in the form of ozone
treatment residues.
Start-up and operation of the device may only take place after reading these
instructions. The device is not dangerous if it is handled according to this manual!
The device has a plug socket with a grounding pin and a cable with a grounding plug.
The device must only be connected to a 230V, 50Hz earthed socket!
Ozone must not be used in the environment of flammable gases or explosives, because
Ozone is a highly oxidizing compound!

Klimawent – the warranty of highest quality at attractive price
8 of 12 Ozone generator KILLVIR-48 25.01.2021
Note 1 Warning regarding ozonation
! WARNING
A. People and animals must not be in the ozonated room, plants should also be removed
from it.
B. Ozone room should be properly sealed so that ozone does not leak outside to adjacent
rooms or the environment.
C. If the room is ventilated, turn off its ventilation.
D. People should not stay in rooms adjacent to ozone plants, into which some ozone could
penetrate. It is necessary to exclude the possibility of exposure to increased
concentrations of ozone by outsiders.
E. All ozone sensitive materials should be removed from the room.
F. Do not use ozone in the environment of flammable gases or explosives!
G. It is forbidden to smoke, work with open fire, work with tools that generate a flame or
sparks, work with oils and greases, or leave objects contaminated with oil or grease in
an ozonated room!
H. After the ozonation treatment is completed, the room should be aired for at least 15
minutes; it is best not to enter it earlier than 1 hour after the end of ozonation.
STORAGE
The device should be stored according to the following rules:
A. The device should be stored in a transport packaging that protects against external factors.
B. The storage place should be dry and dust-free and at a temperature between -10ºC and + 40ºC.
TERMS OF WARRANTY
The warranty period is specified in the device Warranty Card. The warranty does not cover:
 mechanical and electrical damages of the device caused by the user,
 damage resulting from improper use or failure to comply with the operating instructions,
 damage resulting from improper transport, storage, or improper maintenance.
! CAUTION
Non-compliance with point 3 “MANUFACTURER'S DISCLAIMER” of this manual,
especially the unauthorized modification of the device or its improper use will void the
warranty!
RESIDUAL RISK INFORMATION
! CAUTION
Ozone treatment of rooms must always be performed by qualified personnel secured with
appropriate personal protective equipment.
Types of risk and security measure
Ozone [O3]
During operation of the KILLVIR-48 generator, 48 g of volatile ozone are produced each hour. Ozone is harmful
to human health during the operation of the device, as well as in the form of ozone treatment residues.

Klimawent – the warranty of highest quality at attractive price
25.01.2021 Ozone generator KILLVIR-48 9 of 12
! WARNING
Do not enter and do not allow bystanders to come into contact with the atmosphere of the
ozonated room!
Immediately after ozonation, ventilate the room for at least 15 minutes until the concentration of ozone in the
room is reduced to a safe level, i.e. 0.1 ppm ozone. The characteristic odour after ozonation may persist for another
48 hours.
! WARNING
Use personal protective equipment and protective clothing while operating the working device!

Klimawent – the warranty of highest quality at attractive price
10 of 12 Ozone generator KILLVIR-48 25.01.2021
EXAMPLE OF EC DECLARATION OF CONFORMITY
EC DECLARATION OF CONFORMITY
NO. _______________
Manufacturer (eventually also the authorized representative/importer)
name: KLIMAWENT S.A.
address: POLAND, 81-571 GDYNIA, 194 Chwaszczyńska street
A person, authorized for issuing the technical documentation:
name and address: Teodor Świrbutowicz, KLIMAWENT S.A.
hereby declares that the product:
Ozone generator
type / model: KILLVIR-48
Serial number: ___________________ Year of production: ___________________
Meets the requirements of the subsequent European Directives
:
Directive 2006/42/EC (MD), Directive 2014/35/EU (LVD), Directive 2014/30/EU (EMC)
Meets the requirements of the following harmonised standards
:
PN-EN ISO-12100:2012, PN-EN 60204-1:2018-12, PN-EN 60034-1:2011,
PN-EN 60529:2003/A2:2014-07, PN-EN ISO-13857:2020-03, PN-EN IEC 61000-6-1:2019-03,
PN-EN ISO 14123-1:2016-03, PN-EN 1005-2+A1:2010, PN-EN 842+A1:2010
place, date
signature of the
authorized person
name, surname, a
function of the signatory

Klimawent – the warranty of highest quality at attractive price
25.01.2021 Ozone generator KILLVIR-48 11 of 12
WIRING DIAGRAMS
Diagram 1 Electrical connections

Klimawent – the warranty of highest quality at attractive price
12 of 12 Ozone generator KILLVIR-48 25.01.2021
KLIMAWENT S.A. Poland
194 Chwaszczyńska street, 81-571 Gdynia
phone.: [phone]
fax: [phone]
e-mail: [e-mail]
800Z01 KILLVIR-48
PL E2021-01-25
