R-5800-W
Creating a new benchmark in architectural
audio excellence, the installer-friendly
Klipsch R-5800-W in-wall loudspeaker
delivers a level of realism and subtlety that
surpasses and even intimidates competing
designs.
By featuring an 8-inch Cerametallic™
woofer cone, 1-inch titanium tweeter mated
to a pivoting Tractrix® Horn, as well as
treble and bass contour switches, there’s no
denying this speaker’s natural precision,
clarity and efficiency.
Available in a white finish, the R-5800-W can
be paired with one of Klipsch’s new
installation kits (sold separately). Each of
these revolutionary kit designs allow for
increased mounting flexibility and
incorporate a mud ring, wire tie and
universal metal mesh wing for multi-position
placement and a color-coded bracket for
easy speaker size identification.
8" Two-Way In-Wall Loudspeaker
SPECIFICATIONS
FREQUENCY RESPONSE 40Hz-20kHz ± 3dB
SENSITIVITY 94dB @ 1 watt/1 meter
NOMINAL IMPEDANCE 8 ohms
CROSSOVER FREQUENCY 2600Hz
POWER HANDLING 50 watts (200 watts peak)
ENCLOSURE MATERIAL/TYPE ABS/ Infinite baffle, front flush with wall
DRIVE COMPONENTS Two-way system using one 1" (2.54cm)
titanium dome compression tweeter with a 6"
(15.24cm) square 90° x 60° pivoting
Tractrix®Horn and one 8" (20.32cm)
aluminum cone woofer
WIRE GAUGE ACCOMMODATED 12
WEIGHT 7.9 lbs. (3.6kg)
HEIGHT 16.1" (40.89cm)
WIDTH 10.6" (26.92cm)
MOUNTING DEPTH 3.75" (9.5cm)
CUTOUT DIMENSIONS 14.75" (37.47cm) x 9.25" (23.50cm)
FINISH White
INSTALLATION KIT IK-800-W (sold separately)
■Very high sensitivity and power handling
■Pivoting Tractrix Horn compression driver tweeter for clear sound in
any location
■Treble and midbass attenuation switches and IR receiver knock out
■Single piece grille frame and rustproof aluminum grille
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2004
