KMC Controls REE-2002 User manual

REE-2002 1 Installation Guide
Installation Guide
Mounting 1
Connections and Wiring 1
Specifications 2
Troubleshooting 2
Maintenance 2
More Information 2
Important Notices 2
Mounting
The module may be mounted directly to a control
box surface or in a 2 x 4" electrical handy box. Add a
blank cover to conceal the module if desired.
Connections and Wiring
1. Connect a controller input to one of the three
THE-1102/REE-2002 (0–5 VDC, 0–10 VDC, 4–20
mA) outputs as shown in the sample illustration
below.
2. Connect the B, F, C, and D terminals to the
corresponding terminals on the THE-1102.
3. Supply the REE-2002 with 24 VAC (+20%/–15%)
from a Class 2 transformer (only).
Power Supply and E-E/I Converter Module
REE-2002
REE-2002
24 VAC
GND
24 VAC
0-5 VDC
0-10
VDC
4-20
mA
F
C D
B
THE-1102
Humidity Output
(0-5 VDC)
(Without the REE-2002, only the THE-1102’s 0-5 VDC humidity
output and thermistor signal are available to a controller)
Temp. Output
(10K Thermistor)
Signal Ground
– Power Ground
+ 10-15 VDC Power
F
C
D
B
AController
Temp. Input
Signal Ground
Humidity Input*
+
Phase Neutral
*Load between Humidity Input and Signal Ground
is 250 ohms min. to 650 ohms max. for 4-20 mA
or 1000 ohms min. for VDC
NOTE: Use wire size 14 to 22 AWG, stranded.
NOTE: See also the THE-1102 Installation Guide
for additional information about this
application. (The THE-1101 has been
discontinued.)

REE-2002 2 Installation Guide
© 2013 KMC Controls, Inc. 884-019-02F
KMC Controls, Inc.
19476 Industrial Drive
New Paris, IN 46553
574.831.5250
www.kmccontrols.com
[email protected]
Important Notices
The material in this document is for information
purposes only. The contents and the product it
describes are subject to change without notice.
KMC Controls, Inc. makes no representations or
warranties with respect to this document. In no event
shall KMC Controls, Inc. be liable for any damages,
direct or incidental, arising out of or related to the
use of this document.
Maintenance
No routine maintenance is required, however protec-
tion from extremes of humidity and dirt is recom-
mended. Careful installation will also ensure long
term reliability and performance.
Troubleshooting
• Check the wiring.
• Check the voltages.
More Information
NOTE: The REE-2002 may also be used to convert
0–5 VDC signals from building automation
systems to 0–10 VDC or 4–20 mA signals.
See the graph for output options over a 0–5
VDC input range.
For more information about
using the THE-1102 with the
REE-2002, see the THE-1102
Installation Guide.
Specifications
Supply Voltage 24 VAC (+20%/–15%), Class 2
only
Input Power 0.75 VA at 24 VAC
Output Capacity
0–10 VDC output into 1000
ohms or greater
 4–20 mA output into 250 ohms
min. and 650 ohmsmax.
Connections Plated screw terminals
Wire Size 14–22 AWG, stranded
Material Flame-retardant plastic
Weight 2 oz. (57 grams)
Temperature Limits
Operating 40 to 120° F (4 to 49° C)
Shipping –40 to 140° F (–40 to 60° C)
