KNEGT 304G2 User manual

OPERATION MANUAL
K NEGT 304 G 2
WWW . K NEGT - INTERNATIONAL.COM.

304G2 TRACTOR
OPERATION MANUAL
Please Read and Save This Manual
KNEGT QUALITY TRACTORS EUROPE
2018.09

304G2 SERIES TRACTOR OPERATION MANUAL
FOREWORD
These series model 304G2 of KNEGT Brand is a series newly
developed product of KNEGT BV. It is powered with the
three-cylinder diesel engines that have the features of ample
output, less vibration and low noise as well.
Model 304G2 tractors are of dual-function type for using in
both paddy and dry fields. The designers have cogitated on
some components, which can be selected for assembling in order
to meet users’ various needs.
In order to fit in with the international market, some
components for perfecting the tractor have been designed and
developed, such as the hydraulic power steering, two-speed PTO
and so on. All of these have improved the performance of the
tractor greatly.
These tractors have the advantages of economic fuel
consumption, easy operation, harmonious appearance, compact
construction and easy maintenance. This tractor series is only used
for conventional agriculture and domestic purposes and similar
operations, with the suitable agricultural machinery, for other
operating contrary to the intended use of the tractor, such as shall
not be used for front-end loader and forestry application and
spraying.This tractor can only be operated by the personnel who is
familiar with tractor’s characteristics and have the knowledge of
relevant safe manipulation, the same for maintenance and repair.
This tractor can not be operated by children and agedness and other
personnel who is not to conformity with the provisions.
1

304G2 SERIES TRACTOR OPERATION MANUAL
Read the Operation Manual carefully before starting, using,
maintaining, refueling or making other service interventions on
the tractor. Comply strictly with the safety regulation and follow
the suggested precautions in order to safeguard yourselves. If
you are unsure about anything, ask your East Wind dealer or
employer. Do not guess, others and you could be killed or
seriously injured.
Many warming sign alerts such as ‘ ’on the tractor and
operation manual. This warning sign alerts you about important
messages involving your safety. Read these safety rules
attentively and strictly follow suggested precautions to avoid
any potential danger and ensure your health and personal
safety.
In order to meet users’ needs continuously, this tractor is subject
to improvement without notice. It may happen to the fact that there
are some differences between the manual/illustrated parts catalogue
and the structure of the real tractors. So the dealers or users are
requested to provide PIN number and manufacturing date of the
tractor while placing order for spare parts.
Thank you for purchasing the Knegt Brand Tractor and
cordially welcome your advice, suggestions and comments on
our product so that we can make improvements timely in future.
Knegt BV
September 2018
2

304G2 SERIES TRACTOR OPERATION MANUAL
3
CONTENT
FOREWORD .....................................................................................1
CONTENT .........................................................................................3
Chapter 1 Safety Precautions............................................................5
1.1 Safety Instructions .................................................................................5
1.2 Safety symbols.....................................................................................12
1.3 Measures for emergency ......................................................................16
Chapter 2 Technical Specifications.................................................17
2.1 Tractor characteristic............................................................................17
2.2 Identifying your machine.....................................................................17
2.3 Technical specification of the tractor ...................................................19
Chapter 3 Running-in of the tractor..............................................26
3.1 Preparation before Running-in of the tractor.......................................26
3.2 Running-in the engine without load.....................................................26
3.3 Running in of hydraulic hitch system ..................................................27
3.4 Running-in of hydraulic steering system .............................................27
3.5 Running in of PTO...............................................................................27
3.6 Running in of the Tractor.....................................................................28
3.7 Maintenance after running-in...............................................................29
Chapter 4 Operating tractor...........................................................30
4.1 Instrument and Controls.......................................................................30
4.2 Driving the Tractor...............................................................................36
4.3 Using the Tractor implents...................................................................47
4.4 The use of electrical systems ...............................................................54
Chapter 5 Maintenance...................................................................58
5.1 Oil and lubricants.................................................................................58
5.2 Periodic Service ...................................................................................59
5.3 Transporting the Machine ....................................................................61
5.4 Storage .................................................................................................63
Chapter 6 Adjustment of the tractor..............................................65
6.1 Adjustment of the engine .....................................................................65
6.2 Adjustment of the clutch ......................................................................65

304G2 SERIES TRACTOR OPERATION MANUAL
4
6.3Adjustment of the Brake....................................................................67
6.4Adjustment of the Rear Axles ...........................................................67
6.5Adjustment of the Front Axle (4WD)................................................69
6.6 Adjustment of the toe-in.......................................................................73
6.7 Adjustment of the wheel track .............................................................73
Chapter 7 Troubleshooting..............................................................74
7.1 Clutch...................................................................................................74
7.2 Gearbox................................................................................................75
7.3 Rear axle ..............................................................................................75
7.4 Braking system.....................................................................................76
7.5 Front driven axle (4WD)......................................................................76
7.6 Walking system ....................................................................................77
7.7 Hydraulic steering system....................................................................77
7.8 PTO ......................................................................................................78
7.9 Hydraulic Hitch System.......................................................................79
7.10 Electrical system ................................................................................80
Chapter 8 Appendix.........................................................................82
Appendix 1 Standards and Regulations .....................................................82
Appendix 2 Tightening Torque Table of Main Bolts and Nuts..................83
Appendix 3 Scheme of the electric system................................................84
Appendix 4 List of damageable parts ........................................................85
Appendix 5 List of Attached Tools ............................................................85
Appendix 6 Mechanical couplings.............................................................86
Appendix 7 E-MARK certificate ...............................................................92
Appendix 8 Optional Accessories..............................................................98
Appendix 9 Application Packing List........................................................98

304G2 SERIES TRACTOR OPERATION MANUAL
5
Chapter1SafetyPrecautions
1.1 Safety Instructions
1.1.1Safetyfirst
The respect of the rules for tractor use, maintenance and repair given in this manual is
an essential element for the correct use of the tractors as envisioned by the
manufacturer.
Carefully read all safety messages in this manual and on your
machine safety signs.Replace missing or damaged safety signs.Be
sure new equipment components and repair parts include the
current safety signs.Replacement safety signs are available
from your Knegt dealer.
Learn how to operate the machine and how to use controls properly.Do not let anyone
operate without instruction.
Keep your machine in proper working condition.Unauthorized modifications to the
machine may impair the function and safety and affect service life of machine.
Lightning and high voltage cable can kill you. Do not use the machine if there is
lightning in your area or under high voltage cable.
Handle fuel carefully, it is highly flammable.Do not refuel the machine while
smoking or when near open flame or sparks.
Always stop the engine before refueling machine.Fill fuel tank outdoors.
Prevent fires by keeping machine clean of accumulated trash, grease, debris.Always
clean up spilled fuel.
Please remember that you will undertake the personal responsibility for any
associated consequences with the improper use of these tractors. All the time you are
working with or on the machine, take care and stay alert. Always be careful. Always be
alert for hazards.
It is extremely dangerous to operate machinery when under the influence of alcohol
or drugs. Do not drink excessively or take drugs before or while operating the machine
or attachments. Be aware of medicines which can cause drowsiness.

304G2 SERIES TRACTOR OPERATION MANUAL
6
Do not attempt to operate the machine if you are feeling unwell. By doing so you
could be a danger to yourself and those you work with.
You can reduce the risk of damage to the machine or your body by following the
instructions in this manual.
If you do not understand any parts of this manual and need assistant, contact your
Knegt dealer.
This machine is manufactured in compliance with legislative and other requirements.
It should not be altered in any way which could affect or invalidate any of these
requirements. For advice consult your Knegt Distributor.
Use only the Knegt approved attachments that are specified for your
machine. Operating with nonspecified attachments can overload the
machine, causing possible damage and machine instability which could result in
injury to yourself or others. The use of non-approved attachments could invalidate
your warranty.
1.1.2Startthetractor
1. Keep all guards and shields in the right place.
2. Make sure that everyone be away from the
machine, attached implements, and work area
before starting engine or operation.
3. Start engine only from seat with shuttle control in
Neutrual.
4. Front drvie lever should be netural and PTO
switch must be disengaged before starting the
engine.
5. Make sure all implements are fully lowered
down to the ground before starting the engine.
6. Don’t start engine by shorting across starter
terminals. Otherwise it may cause injury or even
death to you.
1.1.3Operatingthetractorsafely
1. Select the track width setting best suited for work, always keeping tractor stability

304G2 SERIES TRACTOR OPERATION MANUAL
7
in mind.
2. Engage clutch gradually. Abrupt engagements,
particularly if pulling out of a low area, a ditch or
muddy grounds, or driving over a steep gradient,
may cause dangerous tractor pitching. Immediately
disengage the clutch if the front wheels tend to
come off the ground.
3. When coasting downhill, keep the transmission
gear engaged. Never disengage the clutch and
never drive your tractor in neutral.
4. When tractor is in motion, the operator should be
correctly seated in the driver’s seat.
5. Do not get on or off a moving tractor.
6. Keep all children and nonessential personnel off
tractors and all equipment.
7. Always press the brake pedal gently.
8. Reduce speed when turning, applying individual
brakes, or operating around hazard on rough
ground or steep slopes.
9. Always operate the tractor at a safe speed for the
type of ground being worked. When operating on
rough ground, use proper caution to assure tractor
stability.
10. When working on sloping grounds (i.e. hillsides)
drive at moderate speed, particularly when
steering.
11. Always try to go straight up or straight down a
slope, never at an angle.
12. Proceed with extreme caution when driving with
wheels close to the edge of a ditch or bank.
13. Never ride on a tractor unless seated on a

304G2 SERIES TRACTOR OPERATION MANUAL
8
Knegt approved seat with seat belt.
14. When driving on public roads, be sure to respect traffic rules and regulations.
15. Do not rest your feet on the brake and the clutch pedals.
16. When driving on roads latch the brake pedals together by using the latch plate,
braking with the pedals unlatched may cause side skidding of the tractor. Try to
avoid overworking the brakes.
1.1.4Towi nglo a ds 
1. To assure tractor stability while working, correctly adjust the towing attachments
(depending on the towed trailer or drawn implement).
2. Be careful when towing and stopping heavy loads.Stopping distance increase with
speed and weight of towed loads, and on slopes.Towed loads with or without
brakes that are too heavy for the tractors or are towed too fast can cause loss of
control.
3. For your personal safety, trailers should not be
towed unless equipped with an independent braking
system.
4. Always use drawbar and towing equipment to pull
heavy loads. Never hook or connect towed
equipment to the 3-point hitch lower links or to the
top link because pitching danger exists.
5. When towing never attempt to make a turn with a locked differential, because you
may not be able to steer the tractor.
1.1.5UsingAgriculturalImplementsand
Machines
1. Do not connect implements or machinery
requiring a higher power rating than your tractor
class.
2. Do not negotiate sharp turns with the PTO under heavy load; this will avoid
damaging the universal joints of the PTO (power take-off) propeller shaft.
3. When connecting the implement to the tractor never stand between the two, while

304G2 SERIES TRACTOR OPERATION MANUAL
9
the tractor is being backed up.
4. Never activate the power take-off (PTO) when it is connected to a moving
implement, without previously making sure that no one is within operating range of
this implement.
5. You can be injured if you use faulty lifting equipment. Make sure that lifting
equipment is in good condition. Make sure that lifting tackle complies with all local
regulations and is suitable for the job. Make sure that lifting equipment is strong
enough for the job. Raised equipment can fall and injure you. Do not walk or work
under raised equipment unless safely supported.
6. No standing on the 3-point hitch or the shield. It
may cause accident.
1.1.6Parkingandle avi ng thetractor
1. Before dismounting, disengage PTO, move
transmission control lever to neutral, stop engine,
lower implements or attachments to ground and
securely engage the park brake. In addition, if
the tractor is left unattended, remove key.
2. When parking look for level grounds if any, shift
into gear and lock the park brake. On sloping
grounds in addition to locking the park brake,
shift into first forward gear if uphill or into first
reverse gear if downhill. For greater safety also use the specific stopping wedge
(available on request); be sure to do so if parking your tractor with a trailer.
1.1.7TractorMaintenance
1. Allow engine to cool off sufficiently before
removing the radiator cap. With the engine
shut-off, slowly turn the cap and release pressure
before removing it completely.
2. Disconnect the storage battery ground cable before
starting to work on any of the electrical system’s

304G2 SERIES TRACTOR OPERATION MANUAL
10
parts or components.
3. Before disconnecting any hydraulic line or hose, make sure the system is
pressure-free.
4. Hydraulic oil escaping under pressure can cause serious personal injury. When
searching for or detecting oil leaks, make sure to use adequate safety protection
such as shields, goggles and gloves.
5. Prior to inspection, cleaning, adjustment or maintenance of the tractor or any
mounted or connected implement, always make sure that engine is shut off. Also
make sure the transmission is in neutral, the brakes
are locked, the power take-off (PTO) is disengaged
and all other moving parts are stationary.
6. Do not fill fuel tank completely when expecting to
work in full sunlight because the fuel might expand
and escape. In such case, promptly wipe off
any fuel that has escaped.
7. Tractor fuel may be dangerous. Never refuel
while engine is running, is still hot, or you are
near an open flame or when someone is
smoking.
8. Do not service the tractor while it is in motion or while the engine is running．When
servicing front-wheel-drive-equipped tractor with rear wheels supported off ground
and rotating wheels by engine power，always
support front wheels in a similar
manner．Engaging front-wheel drive will pull rear
wheels off support if front wheels are not
raised．Tighten wheel hardware to correct torque
as specified in Wheels ，Tires and Tread
section．Torque at intervals shown in Break-In
Period and Lubrication and Maintenance sections，to ensure that wheel hardware
does not loosen．Reinstall protective covers removed during service．
9. Do not work on tires unless suitable tools are available and you have the training

304G2 SERIES TRACTOR OPERATION MANUAL
11
and experience for tire repair. Any incorrect tire installation may seriously threaten
your personal safety. If any doubt exists, have work done by qualified persons.
Explosive separation of a tire and rim parts can
cause serious injury or death.
Always maintain the correct tire pressure．Do not
inflate the tires above the recommended pressure.
Never weld or heat a wheel and tire assembly.
The heat can cause an increase in air pressure
resulting in a tire explosion.
Welding can structurally weaken or deform the
wheel.
When inflating tires, use a clip—on chuck and extension hose long enough to allow
you to stand to one side and NOT in front of or over the tire assembly. Use a safety
cage if available.
Check wheels for low pressure, cuts，bubbles, damaged rims or missing lug bolts
and nuts.
10. Improperly disposing of waste can threaten the
environment and ecology. Potentially harmful
waste used with equipment include such items as
oil, fuel, coolant, brake fluid, filters, and
batteries.
Use leak proof containers when draining fluids.
Do not use food or beverage containers that may
mislead someone into drinking from them.
Do not pour waste onto the ground，down a drain，or into any water source.
Air conditioning refrigerants escaping into the air can damage the Earth's
atmosphere. Government regulations may require a certified air conditioning
service center to recover and recycle used air conditioning refrigerants.
Inquire on the proper way to recycle or dispose of waste from your local
environmental or recycling center,or from your East Wind dealer.

304G2 SERIES TRACTOR OPERATION MANUAL
12
1.2 Safety symbols
No. Safety symbol Meaning Position
1
Keep away from rotating
components when the mechine
is working.
On the right side
of the radiator
2
Don’t touch the hot surface
until it’s cool enough,
otherwise you may be
damaged.
On the right side
of the radiator,
near the
muffler
3
Keep away from radiator.
There may be hot fluids or
steam
Above the
radiator
4 If you want to operate Please
Read the operators handbook。
On the PTO
shield
5
Don’t jump out of the tractor
when it turns over, it may
cause worse result.
Keep the ROPS in the fully
extended and locked position.
On the left side
of SafetyFrame
6 Please fasten your seat belt. Above the Panel

304G2 SERIES TRACTOR OPERATION MANUAL
13
7
Don’t add fuel, do
maintenance and so on when
the tractor is running.
On the right
windshield
8
Power take-off actuator and/or
rotational-speed selector
position：disengaged
Beside the PTO
operating
lever,on the
fender
9
Power take-off actuator and/or
rotational-speed selector
position：540rpm
10
Power take-off actuator and/or
rotational-speed selector
position：1000rpm
11
Only ride on the operator’s
seat. Or it may cause serious
accident.
on the right
fender
12 Lifting mechanism control:
raised position. on the fenders
13 Lifting mechanism control:
lowered position. on the fenders
14
Be clear of the mechine when
it’s lifting implements or
heavies. It may cause
accidents.
On outside
surface of the
squab panel
15
Parking brake control,
Stopping and parking the
machine.
Beside the
Handle brake
control lever,on
the squab panel

304G2 SERIES TRACTOR OPERATION MANUAL
14
16
No standing on the 3-point
hitch or the shield. It may
cause accident.
On the outside
surface of the
squab panel
17
When you see this symbols,
you should read Operators
handbook.
On the Panel
18 Checking and adjusting the
fluid level.
Near the oil
filler
19 Do not use the differential lock
at high speed or on the road.
Beside the
differential
pedal,on the
outside surface
of the squab
panel
20 DFilling the tank. On fuel tank
cap
21 Do not trample. Above the
battery
22
Disconnect the battery before
working on the
machine.
Above the
battery
23 Freeing a Mired Machine.
On the right
outside surface
of SafetyFrame

304G2 SERIES TRACTOR OPERATION MANUAL
15
24 Define of Remote hydraulic
valve.
Above the Rear
beam
25 Define of Remote hydraulic
control valve.
Above the Rear
board
26 Open the engine hood. On the engine
hood.
27 Mandatory sign of front drive. On the Seat
plate.
28 Mandatory sign of support
point.
On the frame,or
rear axle
housing,or axle
shaft housing.
29 Mandatory sign of lifting
point.
On the
assistant
weight
support,or axle
shaft housing
30 Mandatory sign of engine oil. On the engine.
31 Oil filler. On the left side
of SafetyFrame.
If you need symbols ,please give number to your East Wind dealer or employer.

304G2 SERIES TRACTOR OPERATION MANUAL
16
1.3 Measures for emergency
1. When lost of steering control, slow down the tractor, engage the emergency brake,
and then shut down the engine.
2. If the engine shut down when going up the slope, step down the brake pedals
immediately, and engage the park brake to avoid slipping down along the slope.
Ignite the engine after that, and shift to a proper gear, then go up the slope with
smooth.
3. If the brake system fails, control the steering wheel, slow down the tractor or shift
to lower gear, and running the tractor in neutral, then shut down the engine in safe
place.
4. In following situations, the tractor can not be started up:
A. When the brake system fails.
B. When the steering system can not be managed easily or the steering system is
broken.
C. After reinstall the tractor by oneself, and there exist safety problems.
D. When you are unsure that you can control it.
E. When you are unsure that you and those around you will be safe.

304G2 SERIES TRACTOR OPERATION MANUAL
17
Chapter2TechnicalSpecifications
2.1 Tractor characteristic
DF304G2 series tractor operator see table.
Table 2-1 Technical Specification
Tractor
Model
Type
Engine
Type of
hydraulic lift
system
Control of
clutch and
brake
ROPS
Rated Power
(Kw)
Rated
Speed
(rmp)
DF304G2 4WD 22.1 2400 independent Hang ROPS
2.2 Identifying your machine
2.2.1MachineIdentificationPlate
Your machine has an
identification plate mounted
on the front right hand side of
the machine. Information
contained on this plate
includes Category and speed
index, VIN, Technically
permissible laden masses,
Technically permissible
towable masses, Manufacturer
and Address.
The machine VIN and engine
serial numbers can help
identify exactly the type of equipment you have.

304G2 SERIES TRACTOR OPERATION MANUAL
18
2.2.2ComponentIdentificationPlates
Engine Identification Plate Location
The engine identification plate is
attached to the left hand side of
the engine block. The information
contained on this plate includes the
engine model and serial number.
ROPS Certification Plate
Your machine is built to the ROPS
standard and has an identification
identification label is shown below.
Label fitted to the ROPS or cab.
Tractor Drawbar Or Clevis type Certification Plate
The Tractor drawbar or Clevis type on
your machine is built to a standard and has
an identification label fitted to the top of
the trailer hitch. A typical identification
label is shown below.
