Zetor UTILIX HT Series User manual

OPERATOR´S MANUAL
UTILIX HT
2/2019
45
Tractor is Zetor. Since 1946.
55

ZETOR
This Operator’s Manual for the Zetor tractors, which we are presenting to you will help you to
become familiar with the operation and maintenance of your new tractor.
Although many of you have rich experience with the operation of other tractors, please, read the
information contained in this Operator’s Manual very carefully.
In the Manual you will find a lot of new information and get a perfect overview of how to use the
tractor with maximum efficiency during various kinds of work.
If you observe the rules of tractor operation and maintenance and driving safety, your new tractor will
become your reliable and long-term friend.
The manufacturer of the tractor wishes you thousands of hours of satisfactory work.
ZETOR
Brno
The technical specifications and information about the design, equipment, material and appearance are valid at the time
of print. The manufacturer reserves the right to implement changes.
The instructions for use are a part of the machine.
1

2

Tractor identification........................................................................................................................................9
Warranty of the product.................................................................................................................................9
Parts ..............................................................................................................................................................9
About this manual ..........................................................................................................................................11
Introduction & Description ............................................................................................................................13
Tractor an introduction.................................................................................................................................13
Description...................................................................................................................................................14
ROPS (Roll over protection structures) .......................................................................................................15
Roll over protective structures (ROPS).......................................................................................................15
Danger.........................................................................................................................................................15
Use of the tractor with the ROPS lowered can cause fatal injuries.............................................................15
Damage of the ROPS..................................................................................................................................15
How to adjust the Seat ................................................................................................................................16
For sliding seat ............................................................................................................................................16
Seat suspension adjustment knob ..............................................................................................................17
Cushion strength adjustment.......................................................................................................................17
Safety instructions, Do's & Don'ts................................................................................................................19
Introduction to safety information ................................................................................................................19
Signal words................................................................................................................................................19
Introduction to safety instructions Introduction to safety instructions..........................................................19
Protection children.......................................................................................................................................19
Use of rops and seat belt ............................................................................................................................20
Precaution to avoid tipping..........................................................................................................................20
Safe parking of the tractor...........................................................................................................................20
Keep riders off tractor..................................................................................................................................20
Handle fuel safely-avoid fires ......................................................................................................................21
Stay clear of rotating shafts.........................................................................................................................21
Always use safety lights and devices..........................................................................................................21
Practice safe maintenance..........................................................................................................................22
Avoid high-pressure fluids...........................................................................................................................22
Prevent battery explosions..........................................................................................................................22
Prevent acid burns.......................................................................................................................................23
Service tractor safely...................................................................................................................................23
Work in ventilated area................................................................................................................................24
Tractor runaway...........................................................................................................................................24
Safety starter switch....................................................................................................................................24
Emergency exits..........................................................................................................................................24
Safety precautions when using the loader ..................................................................................................25
Towing safely...............................................................................................................................................27
Falling object protective structure (FOPS) ..................................................................................................27
Operator protective structure (OPS)............................................................................................................27
Use of hazardous substances.....................................................................................................................28
Safety tips during maintenance...................................................................................................................30
Mounting and demounting implements .......................................................................................................31
The following precautions are suggested to help prevent accidents ..........................................................32
Do's-for better performance.........................................................................................................................35
Don'ts - for safe operation ..........................................................................................................................36
Safety signs.....................................................................................................................................................37
General safety information ..........................................................................................................................37
Decals on the dash cover............................................................................................................................37
Decals on the chassis..................................................................................................................................38
Decals on the cabin.....................................................................................................................................39
Universal symbols..........................................................................................................................................41
Controls, Instruments & Operations.............................................................................................................43
Description of tractor controls......................................................................................................................43
Battery disconnector....................................................................................................................................43
Instrument and switches..............................................................................................................................44
Main switch (key switch)..............................................................................................................................45
Headlights, turn signal lights, beacon and horn switch...............................................................................45
Tachometer..................................................................................................................................................46
Hour meter...................................................................................................................................................46
Fuel gauge and water temperature gauge .................................................................................................46
Hazard warning signal switch......................................................................................................................46
CONTENTS
3

Warning lights .............................................................................................................................................47
Independent PTO........................................................................................................................................48
PTO shaft revolutions 540 and 1000 rpm shifting lever..............................................................................50
Connecting and disconnecting implement...................................................................................................51
Cruise control button ...................................................................................................................................52
Cruise speed control switch.........................................................................................................................52
Load sensing button....................................................................................................................................52
Mode (sensitivity) switch..............................................................................................................................53
Tractor controls............................................................................................................................................54
Hand throttle (Throttle lever)........................................................................................................................55
Speed and direction control pedals.............................................................................................................55
Foot brakes..................................................................................................................................................56
Parking brake lever......................................................................................................................................57
To avoid personal unjury:............................................................................................................................57
Air brakes of trailers and semi-trailers.........................................................................................................57
Air pressure indication.................................................................................................................................57
The button for temporary deactivation of brakes of the trailer or semi-trailer .............................................58
One-hose and two-hose brakes ..................................................................................................................59
One-hose brakes.........................................................................................................................................59
Two-hose brakes.........................................................................................................................................59
Sub gear lever (Linear shift lever)...............................................................................................................60
Diff-lock pedal..............................................................................................................................................60
Front axle drive lever...................................................................................................................................61
Driver's seat.................................................................................................................................................61
Tilt lever.......................................................................................................................................................62
Operating the hydraulics..............................................................................................................................63
Position control............................................................................................................................................63
Lowering speed control knob for the 3 point hitch.......................................................................................64
Outer hydraulic circuit..................................................................................................................................64
Outer hydraulic circuit controls....................................................................................................................65
Remote hydraulic control valve coupler connecting and disconnecting......................................................65
Connection...................................................................................................................................................65
Disconnection..............................................................................................................................................65
Joystick lever...............................................................................................................................................66
Safety implement for joystick lever..............................................................................................................66
Rear three-point hitch..................................................................................................................................67
Adjustment of the top link............................................................................................................................68
Adjustment of the lift link on the lower link ..................................................................................................69
Mounting implement....................................................................................................................................69
*Front three-point hitch................................................................................................................................70
Controlling front three-point hitch ................................................................................................................70
Hydraulic lock of the front three-point hitch.................................................................................................71
Working and transport position of the front three-point hitch ......................................................................72
Driving with agricultural machines attached to the front three-point hitch...................................................72
Towing equipment.......................................................................................................................................72
Maximum permissible load of the hitch.......................................................................................................72
Lower hitch ..................................................................................................................................................73
Connection and disconnection of implements.............................................................................................73
Multistage adjustable suspension ...............................................................................................................73
Disassembly of the rear PTO cover ............................................................................................................73
Lower hitch disassembly .............................................................................................................................74
Height adjustment and disassembly of the multi-level hitch attachment tail piece .....................................74
Starting the engine ......................................................................................................................................75
Stopping the engine.....................................................................................................................................75
Warming up .................................................................................................................................................75
Warming up in cold weather........................................................................................................................75
Running-in Period........................................................................................................................................75
Sharp change of direction in the field..........................................................................................................76
Normal service braking and parking............................................................................................................76
Driving downhill ...........................................................................................................................................77
Operation of the diff lock..............................................................................................................................77
Check during driving....................................................................................................................................78
Oil pressure light..........................................................................................................................................78
CONTENTS
4

Battery charging ..........................................................................................................................................78
Fuel gauge...................................................................................................................................................78
Engine cooling water...................................................................................................................................79
Trailer socket (seven terminal electrical socket type) .................................................................................79
Treads..........................................................................................................................................................80
Changing the front wheel tread ...................................................................................................................81
Changing the rear wheel tread....................................................................................................................81
Front drive axle fenders...............................................................................................................................81
Setting wheel stops with front drive axle .....................................................................................................82
Front loader mounting points.......................................................................................................................83
Main technical parameters ............................................................................................................................85
Check and service.......................................................................................................................................85
Service inspections......................................................................................................................................85
Pre-start checks...........................................................................................................................................85
Engine coolant.............................................................................................................................................85
Engine oil.....................................................................................................................................................86
Transmission oil...........................................................................................................................................87
Fuel..............................................................................................................................................................87
Tyre pressure ..............................................................................................................................................88
Tire size and inflation pressure....................................................................................................................88
Tire inflation.................................................................................................................................................88
Steering .......................................................................................................................................................89
Brake ...........................................................................................................................................................89
Electrical installation....................................................................................................................................89
Installation of the front loader......................................................................................................................89
Maintenance and adjustment schedule.......................................................................................................90
Periodical check and service table..............................................................................................................90
Diagram of filling points and lubrication points............................................................................................93
Fuels, coolants and lubricants used - amounts...........................................................................................94
Recommended SAE viscosity grades for engine oil ...................................................................................94
ZETOR service fillings.................................................................................................................................94
Motor oils.....................................................................................................................................................94
Oil in the gearbox and final drivehousing....................................................................................................94
Oil for the front driving axle..........................................................................................................................94
Other recommended service fillings tested on Zetor tractors......................................................................94
Oil to gear systems of tractors.....................................................................................................................94
Fuel..............................................................................................................................................................94
Procedure to open the front hood
................................................................................................................95
Front bonnet opening ..................................................................................................................................95
Opening the side cover................................................................................................................................95
Fuel system .................................................................................................................................................96
Bleeding the fuel system .............................................................................................................................96
Changing oil in tractor..................................................................................................................................97
Changing engine oil.....................................................................................................................................97
Draining oil from engine...............................................................................................................................98
Engine oil filter.............................................................................................................................................98
Pouring oil to engine....................................................................................................................................98
Changing the transmission oil .....................................................................................................................99
Changing front axle oil...............................................................................................................................100
Cleaning and replacing filters....................................................................................................................101
Engine oil filter...........................................................................................................................................101
Fuel filter....................................................................................................................................................102
Hydraulic oil filter.......................................................................................................................................102
Changing coolant.......................................................................................................................................103
Anti freeze..................................................................................................................................................103
Cleaning the radiator.................................................................................................................................104
Greasing the tractor...................................................................................................................................105
Setting the play of controls........................................................................................................................106
Adjusting the brake....................................................................................................................................106
Adjusting method.......................................................................................................................................106
Adjusting the throttle lever.........................................................................................................................106
Adjusting toe-in..........................................................................................................................................106
Checking the battery..................................................................................................................................107
CONTENTS
5

Battery maintenance..................................................................................................................................107
Battery charging ........................................................................................................................................108
Battery disconnect.....................................................................................................................................108
Battery disconnector..................................................................................................................................108
Fan belt adjustment...................................................................................................................................109
Alternator inspect.......................................................................................................................................109
Alternator and fan belts inspect/adjust/replace .........................................................................................109
Air conditioner compressor belt adjustment..............................................................................................110
Air filter maintenance.................................................................................................................................110
Checking hoses and lines..........................................................................................................................111
Checking the wiring harness and fuses.....................................................................................................111
Replacing fuses.........................................................................................................................................112
Main fuses .................................................................................................................................................112
Storage......................................................................................................................................................113
For daily or short term storage ..................................................................................................................113
Long-term storage.....................................................................................................................................113
Re-use after long term storage..................................................................................................................113
Fuel saving tips..........................................................................................................................................113
Air cleaning system ...................................................................................................................................113
Engine........................................................................................................................................................114
Fuel system ...............................................................................................................................................114
Oil system..................................................................................................................................................114
Cooling system..........................................................................................................................................114
How to use of jacks ...................................................................................................................................115
Cabin..............................................................................................................................................................117
Instruments and related parts....................................................................................................................117
Doors.........................................................................................................................................................118
Rear window..............................................................................................................................................118
Side window ..............................................................................................................................................118
Work lights (front and rear)........................................................................................................................118
Rearview mirrors .......................................................................................................................................119
Cab ceiling.................................................................................................................................................119
How to controls cabin................................................................................................................................120
Interior devices..........................................................................................................................................120
Ventilation..................................................................................................................................................120
Re-circulation inlets fully closed ................................................................................................................120
Control panel on right cab pillar.................................................................................................................121
Windscreen washer tank...........................................................................................................................121
Interior lamp...............................................................................................................................................122
Blower control switch.................................................................................................................................122
Temperature control..................................................................................................................................122
Air conditioner switch.................................................................................................................................122
Circulation diffuser.....................................................................................................................................123
Heating system..........................................................................................................................................123
Heating system configuration....................................................................................................................123
Compressor belt adjustment......................................................................................................................124
Air conditioning system..............................................................................................................................124
Roof hatch (if equipped)............................................................................................................................124
Cab air intake filter.....................................................................................................................................125
Radio, CD player (if equipped)..................................................................................................................125
Ash tray......................................................................................................................................................126
Cigarette lighter.........................................................................................................................................126
Main technical parameters ..........................................................................................................................129
Maximum permissible weight of the unit (tractor with trailer or semi-trailer).............................................131
Maximum permissible tractor axle load.....................................................................................................131
Permitted maximum weight of set 'tractor + mounted machine' (kg) ........................................................131
Manoeuvrability condition..........................................................................................................................131
Permissible wheel combination for tractors and load capacity of tires......................................................131
Traveling speed.........................................................................................................................................132
Noise levels ...............................................................................................................................................133
Vibration referred to the operator position.................................................................................................134
Fault tracing ..................................................................................................................................................135
Engine troubleshooting..............................................................................................................................135
CONTENTS
6

Brake and hydraulic system troubleshooting.............................................................................................137
Steering wheel and electric instruments troubleshooting..........................................................................138
Towing the tractor ........................................................................................................................................139
Wiring Diagram.............................................................................................................................................141
UTILIX HT 45 / UTILIX HT 55 Electric system diagram (1).......................................................................141
UTILIX HT 45 / UTILIX HT 55 Electric system diagram (2).......................................................................142
UTILIX HT 45 / UTILIX HT 55 Cabin wiring diagram (1)...........................................................................143
UTILIX HT 45 / UTILIX HT 55 Cabin wiring diagram (2)...........................................................................144
UTILIX HT 45 / UTILIX HT 55 Cabin wiring diagram (3)...........................................................................145
Power train ....................................................................................................................................................147
Index...............................................................................................................................................................149
CONTENTS
7


8

The engine number is stamped on the left hand side of the engine block.
The chassis number is shown on the left hand side of the tractor as shown in the drawing.
Warranty of the product
The manufacturer warrants this product and full details of the warranty are provided on a separate warranty
schedule.
Parts
To obtain spare parts please contact your nearest dealer and give him the details listed below.
Tractor model
Tractor serial number
Tractor engine number
Part number and description
Quantity required
1- Stamped position of the Engine type or Number
2- Stamped position of the chassis number
U18N001
TRACTOR IDENTIFICATION
9


NOTES
10

This manual has been prepared to assist you in following / adopting the correct procedure for running-in
operation and maintenance of your new ZETOR Tractor.
Your tractor has been designed and built to provide maximum performance, low fuel consumption and ease
of use. To maintain the condition and ensure trouble-free performance, it is important that maintenance is
performed at the recommended intervals as described in this manual.
Read this Manual carefully and keep it in a convenient place for future reference.
If at any time you require advice concerning your Tractor, do not hesitate to contact your Authorized ZETOR
dealer / Distributor. He has trained personnel, genuine parts and necessary equipments to undertake all your
service requirements.
All data given in this book is subject to production variations. Dimensions & weight are approximate only and
the illustrations do not necessarily show Tractors in standard condition.
For exact information about any particular Tractor, please consult your ZETOR dealer / Distributor.
ABOUT THIS MANUAL
11


NOTES
12

Tractor an introductio
n
The word 'tractor' is derived from 'traction', which means towing.
A tractor is necessary for drawing or towing equipment, implements or carts that are suitably connected to
the tractor body.
The tractor can also be used as a driving machine, thanks to the Power Take-off or PTO shaft.
This manual provides instructions for the operation, maintenance and storage of all Zetor tractor models.
This material has been elaborated in detail to help you better understand maintenance and efficient
operation.
If you need information not provided in this manual or the services of a trained mechanic, please contact
Zetor Dealer/distributor at your location. Dealers and distributors are kept informed about the latest methods
of servicing tractors.
They are supplied with original spare parts and are fully supported by the manufacturer.
Through this manual
The use of the terms LEFT, RIGHT, FRONT and REAR must be understood, to avoid any confusion when
following the introductions. The LEFT and RIGHT means left and right sides of the Tractor when facing
forward in the driver's seat, Reference to the FRONT indicates the radiator end of the Tractor, while the
REAR, indicates the drawbar end (Fig. U18N002).
When spare parts are required, always specify the Tractor and engine serial number when ordering these
parts. (See Fig. U18N001).This will facilitate faster delivery and help ensure that the correct parts for your
particular Tractor is received. The tractor serial number is punched on a plate attached to the left hand side
of the engine body (See Fig. U18N001), For easy reference, we suggest you to write the number in the
s
p
ace
p
rovided in the owner's
p
ersonal data
.
1- Right turn (Clockwise)
2- Right
3- Front
4- Left
5- Rear
6- Left turn (Counterclockwise)
U18N002
INTRODUCTION & DESCRIPTION
13

Descriptio
n
General construction
The transmission case, clutch, clutch housing, engine and front axle support are bolted together to form
a rigid unit.
Front Axle and wheels
The 4WD front axle is a center-pivot, reverse Eliot type. The front wheel drive mechanism is incorporated as
a part of the axle.
The front wheel drive power is taken off the rear transmission and transmitted to the differential in the front
axle where the power is divided into right and left and to the respective final cases.
In the final cases, the transmitted revolution is reduced by the level gears to drive the front wheel. The 4WD
mechanism with level gears provides wider steering and greater durability.
Engine
The tractors are fitted with fuel efficient engine with 4 cylinders manufactured by Perkins.
Hydrostatic transmission
The tractor is equipped with a three-speed hydrostatic transmission with power steering, individual speed
ranges are shifted using the selector lever. The tractor is equipped with two pedals, for speed and for
forward / reverse travel. The tractor with an independent PTO is equipped with an electro-hydraulic clutch.
Brakes
Tractors are equipped with independent disc brakes. The handbrake lever is adapted for parking.
Rear axle and wheels
This is mounted on ball bearings and is enclosed in removable housing which are bolted to the transmission
case. The rim & Disc fitted with rear tires are bolted to the outer flange of rear axle.
Hydraulic system & Linkages
ZETOR Tractors are fitted with Live independent, very touch of hydraulic System.
Three point Linkages can be used for Category 1 type of implements.
Steering
It consists of hydrostatic power steering system, which has a hydraulic cylinder and tandem type hydraulic
pump.
Electrical system
A 12 Volt lead acid propylene battery is used to activate the engine through the starter motor and the
electrical system comprising horn, head lamp. Side indicator lamps, plough lamp, brake light, gauge lamp,
hazard lamp. Generator or alternator, fuse box also from part of the electrical system.
Warning: When operating the tractor at High speed, Do not attempt to make sharp turns by
using the brakes. This may result in overturning of the Tractor causing serious injury or DEATH.
INTRODUCTION & DESCRIPTION
14

Roll over protective structures (ROPS)
ZETOR Tractors are equipped with a frame for the protection of operators.
In the case of cab tractors the frame is incorporated in the cab structure.
The objective of the frame or cab structure is to protect the operator in the event of a roll over and they are
designed to support the entire weight of the tractor in that event.
Each ZETOR ROPS frame or cab structure is designed and has been tested to meet industry and or
Government standards.
Included in these tests were all mounting bases and bolts or other fasteners.
DANGER
For ROPS frames to be effective and protect the operator, the seat belt provided must be worn in
order to keep operators within the ROPS protected area in the event of a roll over. Failure to use the
seat belt can still cause serious injury or death.
On some models the ROPS frame has a fold down feature, which can be used to enter low buildings etc.
Take care when lowering the upper section of the ROPS frame and take extreme care while driving the
tractor with the ROPS frame lowered.
Do not wear the seat belt with the ROPS lowered and please remember that the fold down facility is for
special circumstances only and must not be lowered for general use.
Use of the tractor with the ROPS lowered can cause fatal injuries
As the ROPS frame or cab together with the seat belt was designed to meet certain standards, they must be
maintained in good order and condition. To achieve this objective, both the structure and the seat belt should
be inspected on a regular basis (every time the tractor is serviced).
In the event that the seat belt is damaged or frayed, it should be replaced and in the event that the ROPS
frame or any part of the mounting structure is damaged or cracked, the faulty component must be replaced
with a new unit. Such a unit must meet all of the test criteria of the original unit. Fitment of an inferior item or
items affects the certification of the entire ROPS structure and the effectiveness of the structure in the event
of an accident. Drilling or welding of the ROPS structure is forbidden.
Damage of the ROPS
Cabin type
Warning: Do not weld, drill or straighten the ROPS.
Warning: Never attach chains, ropes to the ROPS for pulling purposes; this will cause the
Tractor to tip backwards. Always pull from the Tractor drawbar. Be careful when driving through
door opening or under low overhead objects. Make sure there is sufficient overhead clearance for the
ROPS fatal injuries.
Warning: If the ROPS is removed or replaced, make certain that the proper hardware is used to
replace the ROPS and the recommended torque values are applied to the attaching bolts.
Warning: Always wear your seat belt if the tractor is equipped with ROPS.
If the tractor has rolled over or the ROPS has damaged
(such as striking an overhead object during transport), it
must be replaced to provide the original protection. After
an accident, check for damages to the 1.ROPS.2.Seat
3.seat belt & seat mountings. Before you operate
a Tractor, replace all damaged parts.
U18N003
ROPS (ROLL OVER PROTECTION STRUCTURES)
15

How to adjust the Seat
NOTE: Do not use solvents to clean the seat. Use warm water with a little detergent added.
Before operating a Tractor it is important to adjust the seat to the most comfortable position & check whether
it is properly locked in its position. Figure 1 identifies the seat fitted to your Tractor.
For sliding seat
Caution: Do not put a hand between the seat and the slides when adjusting the seat position.
You can get injured unexpectedly.
1- Seat Bel
t
2- Forward / Backward adjustment lever
3 - Knob for weight adjustment
U18N005
To select seat position, move adjusting lever and slide
seat closer to or away from dash panel and controls.
3
ROPS (ROLL OVER PROTECTION STRUCTURES)
16

Seat suspension adjustment knob
To adjust the seat correctly, turn Weight adjustment knob clockwise or counterclockwise, while seated in the
driving position.
Caution: Do not put a hand between the seat and the slides when adjusting the seat position.
You can get injured unexpectedly.
Danger: Check whether the seat properly locked in its position before driving the tractor.
Danger: Always use the seat belt when the ROPS is installed. Do not use the seat belt if
a foldable ROPS is down or there is no ROPS. Check the seat belt regularly and replace if frayed or
damaged.
Danger: Check whether the seat properly locked in its position before driving the tractor.
Danger: Always use the seat belt when the ROPS is installed. Do not use the seat belt if
a foldable ROPS is down or there is no ROPS. Check the seat belt regularly and replace if frayed or
damaged.
Cushion strength adjustment
The seat cushion can be adjusted according to the weight of the driver.
Turning the cushion adjustment lever counterclockwise to the 50 kg position makes the cushion lighter, and
turning the lever clockwise to the 130 kg position makes the cushion heavier.
ROPS (ROLL OVER PROTECTION STRUCTURES)
17


NOTES
18

Introduction to safety informatio
n
This symbol means ATTENTION! YOUR SAFETY IS INVOLVED. The message that follows the
symbol contains important information about safety. Carefully read the message.
Signal words
Danger
Warning
Caution
A signal word - DANGER, WARNING OR CAUTION - is used with safety alert symbol. DANGER identifies
the most serious hazards. Safety signs with signal Word - DANGER OR WARNING - are typically near
specific hazards. General precautions are listed on CAUTION safety signs.
Introduction to safety instructions Introduction to safety instructions
Protection children
Carefully read all safety instructions given in this manual
for your safety. Tempering with any of the safety devices
can cause serious injuries or death. Keep all safety signs
in good condition.
Replace missing or damaged safety sings.
Keep your tractor in proper condition and do not allow any
unauthorized modifications to be carried out on the tractor,
which may impair the function/safety and affect tractor life
.
U18N134
When using the tractor, prevent other persons from
accessing the tractor.
Reverse travel
- Look around if someone is not behind the tractor.
- Do not allow anyone to ride on the tractor or implement.
U18N135
SAFETY INSTRUCTIONS
19
