Protos COMFF 3400(X)-085
Communication Module
Communication Unit for FOUNDATION Fieldbus
User Manual
Protos II 4400(X) / Protos 3400(X)
Process Analysis System
Latest Product Information: www.knick.de

Trademarks
The following trademarks are used in this document without further marking:
Calimatic®, Protos®, Sensocheck®, Sensoface®, Unical®, VariPower®, Ceramat®, SensoGate®
are registered trademarks of Knick Elektronische Messgeräte GmbH & Co. KG, Germany
Memosens®
is a registered trademark of
Endress+Hauser Conducta GmbH & Co. KG, Germany
Knick Elektronische Messgeräte GmbH & Co. KG, Germany
Returns
Please contact our Service Team before returning a defective device. Ship the cleaned device to the
address you have been given.
If the device has been in contact with process medium, it must be decontaminated/disinfected before
shipment. In this case, place a Declaration of Contamination in the consignment to prevent any risk to the
health and safety of our service personnel. The declaration is available at:
https://www.knick-international.com/en/service/repairs/
Disposal
Please observe the applicable local or national regulations concerning the disposal of “waste electrical and
electronic equipment”.

3
Table of Contents
Protos COMFF 3400(X)-085 Module
Returns........................................................................................................................................... 2
Disposal ......................................................................................................................................... 2
Trademarks ................................................................................................................................... 2
Intended Use.................................................................................................... 5
Safety Instructions .......................................................................................... 6
Operation in Explosive Atmospheres: COMFF 3400X-085 Module ......................... 6
Firmware Version ............................................................................................ 7
Foundation Fieldbus (FF) Technology ........................................................... 8
Bus Communication.................................................................................................................. 9
Terminal Plate ............................................................................................... 10
Installing the Module.................................................................................... 11
Foundation Fieldbus Installation................................................................. 12
Communication Model..........................................................................................................14
Resource Block (RB) ................................................................................................................14
Analog Input Block (AI) ..........................................................................................................14
Analog Input Transducer Block (AI TB) ............................................................................14
Connections (Channels).........................................................................................................14
AI-TB Configuration on the Device....................................................................................15
Bus Activation............................................................................................................................16
For Copy: Individual Settings......................................................................................17
Offline Configuration..............................................................................................................18
Initial Commissioning.............................................................................................................20
Analog Input Blocks ................................................................................................................21
Configuration of AI TB ............................................................................................................22
Configuration with Foundation Fieldbus........................................................................23
Commissioning on the Foundation Fieldbus ................................................................23
Commissioning and Configuration ...................................................................................24
Calibration Protocols...............................................................................................................28
Parameters of AI Transducer Blocks...................................................................................29
Function Block AO ...................................................................................................................30

4
Table of Contents
Protos COMFF 3400(X)-085 Module
DI Function Blocks ...................................................................................................................31
DI 1: Unical Status............................................................................................................31
DI 2: CONTACTS / LOCK Status / ENABLE Request ..............................................31
DI 3: Unical Messages.....................................................................................................32
Explanation of Unical Messages: Maintenance Request...................................32
Explanation of Unical Messages: Failure.................................................................33
DI 4: Unical Step...............................................................................................................33
DO Function Blocks .................................................................................................................34
DO 1: HOLD Control .......................................................................................................34
DO 2: PARSET.....................................................................................................................34
DO 3: Unical Control.......................................................................................................35
DO 4: LOCK Control.........................................................................................................35
Enable / Lock via DCS .............................................................................................................36
Function Control Matrix ........................................................................................................37
Specifications................................................................................................. 38
Process
Variables Available for Fieldbus...................................................... 40
pH Modules ................................................................................................................................40
Calculation Block pH / pH .....................................................................................................40
Process
Variables Available for Fieldbus...................................................... 41
O2Modules.................................................................................................................................41
Calculation Block O2/ O2.....................................................................................................41
pH Modules ................................................................................................................................42
Calculation Block COND/COND ..........................................................................................42
O2Modules.................................................................................................................................43
Calculation Block CONDI / CONDI......................................................................................43
Index............................................................................................................... 44

5
Intended Use
The module is a communication unit for Foundation Fieldbus.
The COMFF 3400X-085 module is intended for operation in locations subject to
explosion hazards which require equipment of Group II, device category 2(1),
gas/dust.

6
Safety Instructions
Operation in Explosive Atmospheres: COMFF 3400X-085 Module
The module is approved for operation in explosive atmospheres.
When installing the product in a hazardous location, observe the information
in the supplements to the certificates and, if applicable, the relevant control
drawings.
Observe all applicable local and national codes and standards for the instal-
lation of electrical equipment in explosive atmospheres. For orientation,
please refer to IEC 60079-14, EU directives 2014/34/EU and 1999/92/EC (ATEX),
NFPA70 (NEC), ANSI/ISA-RP12.06.01.
WARNING! Possible impairment of explosion protection.
• Modules which have already been used shall be subjected to a professional
routine test before they may be operated in another type of protection.
• Prior to commissioning, the operating company must verify the intrinsic
safety in accordance with the installation regulations of IEC60079-14 for
the complete interconnection of all equipment involved, including the
connecting cables.
• The interconnection of Ex and non-Ex modules (mixed assembly) is not
permitted.
• In hazardous locations the device shall only be cleaned with a damp cloth to
prevent electrostatic charging.
Maintenance
The Protos modules cannot be repaired by the user. For inquiries regarding
module repair, please contact Knick Elektronische Messgeräte GmbH & Co. KG
at www.knick.de.

7
Menu Display Device description
Device hardware and firmware
version
Provides information on all modules
installed: Module type and function,
serial number, hardware and firmware
version, and device options.
Select the different modules (FRONT,
BASE, slots 1 - 3) using the arrow keys.
Device description
Return
22.7 °C
7.00 pH
Operating panel Protos
Module FRONT 3400-011
Hardware: 1.1, Software: A.2
Serial number: 08150815
BASE
Module FRONT
Options
Device description
Return
22.7 °C
7.00 pH
Foundation Fieldbus
Module COMFF 3400-085
Hardware: 1, Software: 1.0
Serial number: 471101147
BASE
Module FRONT
Options
Query module software
Module COMFF 3400-085,
hardware and firmware version,
serial number –
here installed in slot3.
Note: The display may vary depending on the device version.
Query Current Device Firmware/Module Firmware
When the device is in measuring mode:
Press menu key, open Diagnostics menu: Device Description
Firmware Version
Module compatibility COMFF 3400-085 COMFF 3400X-085
Protos 3400 from FRONT firmware version 7.0 x
Protos 3400X from FRONT firmware version 7.0 x
Protos II 4400 from FRONT firmware version 1.0.0 x
Protos II 4400X from FRONT firmware version 1.0.0 x
COMFF 3400(X)-085 module firmware: Firmware version 2.x

8
Foundation Fieldbus (FF) Technology
Foundation Fieldbus (FF) is a digital communication system that connects
different field devices over a common cable and integrates them into a control
system. Its application range covers manufacturing, process, and building
automation. As fieldbus standard according to EN 61158-2 (IEC 1158-2) the
Foundation Fieldbus ensures the communication of different devices over one
bus line.
Basic Properties
The “Data Link Layer“ of the Fieldbus Foundation protocol defines 3 device
types:
• The Active Link Master plans all activities as “Link Active Scheduler“ (LAS).
It controls the complete data traffic on the bus. Several Link Masters on one
bus increase safety, but only one is active at a time.
• Basic devices are peripheral devices such as valves, drives, transmitters
or analyzers. They can react acyclically to servicing, configuration and
diagnostic tasks of the master. The Link Master cyclically reads the
measurement data with status.
• Bridges can connect a network from different bus systems.

9
Foundation Fieldbus (FF) Technology
Bus Communication
Foundation Fieldbus (FF) permits cyclic and acyclic services:
• Cyclic Services - Scheduled Communication:
are used for transmission of measurement data with status information.
The Link Active Scheduler maintains a list of transmission times for all data
in all devices that need to be cyclically transmitted. When it is time to trans-
mit data, the LAS issues a “Compel Data (CD)” start signal to the respective
device. Upon receipt of the “Compel Data” signal, the device broadcasts the
data to all devices on the fieldbus.
• Acyclic Services - Unscheduled Communication:
are used for device configuration, remote maintenance and diagnostics
during operation.
All devices are given the chance to send acyclic (unscheduled) messages
between transmissions of cyclic (scheduled) data. The LAS grants permis-
sion to a device to broadcast acyclic messages by issuing a “Pass Token
(PT)” message. Upon receipt of the “Pass Token”, the device starts data
transmission.

10
Terminal Plate
Terminal Plate COMFF 3400-085 Module:
Attaching the Terminal Plates
The terminal plates of the lower modules can be
sticked to the inner side of the door.
This facilitates maintenance and service.

11
1) Switch off the power supply to the device.
2) Open the device (loosen the 4 screws on the front).
3) Plug the module into the slot (D-SUB connector),
see figure.
4) Tighten the module's fastening screws.
5) Connect the signal lines (see next page).
6) Check whether all connections are correctly wired.
7) Close the device by tightening the screws on the front.
8) Switch on the power supply.
CAUTION! Incorrect measurement results.
Incorrect parameter setting, calibration or adjustment may result in incorrect
measurements being recorded. Protos must therefore be commissioned by a
system specialist, all its parameters must be set, and it must be fully adjusted.
Installing the Module
CAUTION! Electrostatic discharge (ESD).
The modules' signal inputs are sensitive to electrostatic discharge.
Take measures to protect against ESD before inserting the module and wiring
the inputs.
Note: Strip the insulation from the wires using a suitable tool to prevent dam-
age.

12
Foundation Fieldbus Installation
Basic build-up of a PROFIBUS system:
e.g. Protos 3400(X)
with
COMFF 3400(X)-085
Shield
12
13
COMFF 3400(X)-085 module
Fieldbus cable
14
Electrical connection between module and Foundation Fieldbus is in accor-
dance with FISCO (Fieldbus Intrinsically Safe Concept, www.fieldbus.org).
H1 Fieldbus
Linking
Device
Control room
A
B
Ethernet or HSE
Fieldbus

Module Selection
AI TB 1
Transducer
Block
AI 1
Analog Input
RB
Resource Block
AI 2
Analog Input
AI 3
Analog Input
AI 4
Analog Input
Select process variable
Records
Calibration
Module I
Module II
Calc. Block I
Module Selection
AI TB 2
Transducer
Block
AI 5
Analog Input
AI 6
Analog Input
AI 7
Analog Input
AI 8
Analog Input
Select process variable
Records
Calibration
AO
Analog Output
AO TB
DI 1
DI 2
DI 3
DI 4
DO 1
DO 2
DO 3
DO 4
DI TB
DO TB
Meas. Value Correction
Unical Status
CONTACT Status
UNICAL Message
Unical Step
HOLD Control
PARSET
Unical Control
LOCK Control
Foundation Fieldbus
Channel
Calc. Block II
Module I
Module II
Calc. Block I
Calc. Block II
1
2
3
4
5
6
7
8
21
11
12
13
14
31
32
33
34

14
Communication Model
See diagram on previous side
All variables and parameters of the transmitter are assigned to blocks.
Resource Block (RB)
Describes the transmitter characteristics (manufacturer, device name,
operating status, general status).
Analog Input Block (AI)
2 x 4 Analog Input Function Blocks provide for cyclic transmission of measured
values (currently measured value with status, alarm limits, freely selectable
process variable from up to 2 measuring modules).
Analog Input Transducer Block (AI TB)
Provides for acyclic data transmission. Calibration, configuration, and main-
tenance commands coming from the control station are processed in the
Transducer Block. The sensor signal is first preprocessed in the Transducer
Block. From here, the measured value is sent to the Analog Input Blocks where
it can be further processed (limit values, scaling).
Connections (Channels)
The communication model shows the channel numbers for connecting the
function blocks to the Transducer Blocks.

15
AI-TB Configuration on the Device
Assigning process variables to Analog Input Blocks on the device
Menu Display Assigning process variables to
Analog Input Blocks
Open parameter setting
From the measuring mode:
Press menu key to select menu.
Select parameter setting using arrow
keys, confirm by pressing enter.
Administrator level:
Access to all functions, also passcode
setting.
Releasing or blocking a function for
access from the Operator level.
Select module.
Protos permits variable equipment
with 2 measuring modules (and
FFmodule). The available process
variables are assigned via
“AI-TB configuration”.
Menu selection
Return to meas
7.00 pH
25.6° C
Select: [enter]
Lingua
Parameter setting
Return
7.00 pH
25.6 °C
Viewing level
Administrator level (All Data) adm
(Operation Data) opl
(All Data) view
Operator level
Parameter setting (Administrator)
Return
7.00 pH
25.6 °C
System control
Module COMFF 3400-085
Module PH 3400-032
Module BASE
Release
Module FRONT
OXY 3400-062 module
Select AI-TB block:
Assign a module to an AI-TB block.
The AI-TB block includes 4 Analog
Input blocks to each of which you can
assign a process variable from the
module.
Module COMFF 3400-085 (Administrator)
Return
7.00 pH
25.6 °C
Bus activation
AI-TB2
AI-TB1
Note: The display may vary depending on the device version.

16
Select AI-TB configuration:
Assign each process variable to one
of the 4 Analog Input Blocks per TB.
(See Page 19)
NOTICE! The assignments made
here also apply to the FF configura-
tion for the connection of Analog
Input Blocks to the channels of the
AITransducer Blocks! Be sure to make
identical settings!
AI TB1 configuration (Administrator)
Return
7.00 pH
25.6 °C
Analog Input AI 2
pH
°C
mV
°F
Analog Input AI 1
Measuring module
Analog Input AI 4
Analog Input AI 3
Module PH 3400-032
AI-TB Configuration on the Device
Assigning process variables to Analog Input Blocks on the device
Menu Display Assigning process variables to
Analog Input Blocks
Bus Activation
On:
Access control by DCS
(Control system programming
required by customer!)
Off:
Device access via passcode or
signature (Audit Trail) as usual
Bus activation (Administrator)
Return
7.00 pH
25.6 °C
Bus activation
Off
On
Note:
If access control has inadvertently
been activated, the device must be
separated from the FF bus to make
the menu accessible again.
Menu Display Bus activation
Note: The display may vary depending on the device version.

17
For Copy: Individual Settings
Assigning process variables to Analog Input Blocks on the device
AI Block Process variable assigned
AI-TB1 Selected measuring module
Analog Input Block AI 1
Analog Input Block AI 2
Analog Input Block AI 3
Analog Input Block AI 4
AI-TB2 Selected measuring module
Analog Input Block AI 5
Analog Input Block AI 6
Analog Input Block AI 7
Analog Input Block AI 8

18
Offline Configuration
The AI blocks are divided into two groups (AI Transducer Blocks) which are
each assigned to one measuring module. This allows control of functions in the
measuring modules. If there is only one measuring module, both AI TBs can be
assigned to the same module so that they can output more measured values
cyclically. In this exemplary configuration there is a PH 3400-032 module in
slot[I], an OXY 3400-062 module in slot [II], and the COMFF 3400-085 module in
slot [III].
AI TB1 configuration (Administrator)
Return
7.03 pH
25.6 °C
Analog Input AI 2
pH
°C
mV
°F
Analog Input AI 1
Measuring module
Analog Input AI 4
Analog Input AI 3
Module PH 3400-032
You can assign individual process variables from the selected measuring
module to the different AI channels.
Example 1:
AI-TB1 is assigned to the pH 3400-032 module,
therefore all process variables of the pH
module are available for AI1 to AI4.
AI TB2 configuration (Administrator)
Return
0.03 %Air
25.6 °C
Analog Input AI 6
%Air
°C
pL
mg/l
Analog Input AI 5
Measuring module
Analog Input AI 8
Analog Input AI 7
OXY 3400-062 module
Example 2:
AI-TB2 is assigned to the OXY 3400-062
module,
therefore all process variables of the Oxy
module are available for AI5 to AI8.
Bus communication on the Foundation Fieldbus can only function properly
when during online configuration the blocks in the control system are set in
accordance with the AI-TB configurations selected in the device configuration.
The modular Protos does not allow permanent assignment of process variables
to AIs - any available module can be located in one of the three slots, which
cannot be recognized from the control system.
Therefore you cannot preconfigure the device offline per DD from the control
system.

AI TB 1 (AI Transducer Block)
As an example, this block was assigned to the Module I
(measuring module, pH). All process variables available from
this module can be assigned to the AI channels.
(See chapter “Process Variables Available for Fieldbus“ for
assignment of process variables):
Select process variable
pH
ORP
Temperature (°C)
Channel
Glass impedance
Foundation Fieldbus
Reference impedance
Slope
Other values...
AI 1
Analog Input
pH
ORP
Temperature (°C)
Glass impedance
Reference impedance
Slope
Other values...
AI 2
Analog Input
pH
ORP
Temperature (°C)
Glass impedance
Reference impedance
Slope
Other values...
AI 3
Analog Input
pH
ORP
Temperature (°C)
Glass impedance
Reference impedance
Slope
Other values...
AI 4
Analog Input
1
2
3
4

20
Commissioning and Configuration
Initial Commissioning
1. Supply the device with power.
2. Open the configuration program of the control system.
3. Load CFF file and DD.
After the first connection establishment, the device answers as follows:
Device ID
4. Assign the desired name (PD_TAG) to the field device.
Setting the Resource Block (RB) parameters
5. Set the MODE_BLK. TARGET to Auto.
Setting the Analog Input Block (AI) parameters
6. Set MODE_BLK. TARGET to OOS (Out Of Service).
7. Select the desired process variable from the CHANNEL parameter
(Observe parameter setting of FRONT module!).
8. Select the unit belonging to the process variable from the
XD_SCALE parameter.
9. Select the unit belonging to the process variable from the
OUT_SCALE parameter.
10. Set the LIN_TYPE linearization type to Direct and transmit the changes.
11. If these steps are not properly executed, the “Block Configuration Error“ is
generated when the block is set to “Auto“.
Using the NI-FBUS Configurator from National Instruments, for example,
you can graphically connect the function blocks and then load the system
configuration in the device.
12. Download all data and parameters to the field device.
13. Set the target modes of all Analog Input Blocks to “Auto“.
