Kodak 5300 - EASYSHARE All-in-One Color Inkjet Instruction Manual

Start Here
All-in-One Printer
EasyShare 5300
All-in-One Printer
EasyShare 5300
TransferRotate Zoom
Attention
Cancel On/Off
HelpMenu
Scan Copy
Start
Proofsheet
10
BlackInk Cartridge
10
BlackInk Cartridge
10
Color Ink Cartridge
10
Color Ink Cartridge
Note: A USB 2.0 cable is required to connect your Kodak All-in-One Printer to your Windows or Macintosh OS computer.
Print
Copy
Scan

Identify Main Components
www.kodak.com/go/aiosupport
2
Easyshare5300
All-in-OnePrinter
All-in-OnePrinter
EasyShare5300
Ea
11.
10.
9.
8.
7.
5.
4.
3.
2.
1.
16.
15.
14.
13.
12.
6.
1. Scanner glass
2. Printer access door
3. Output tray
4. Paper-width guide
5. Main tray
6. Photo tray
7. Paper-length guide
8. Photo tray light
9. USB drive/PictBridge port
10. Memory card light
11. Memory card slots
12. Control panel
13. USB port
14. Power connector
15. Rear access door
16. Scanner lid

Unpack Printer and Install Control Panel
1
3
a) See box flaps for unpacking instructions.
Remove all orange shipping tape from the printer.
c) Press down on all edges of the overlay until
it snaps into position.
Transfer
RotateZoom
Attention
Cancel On/Off
Help
Menu
Scan Copy
Proofsheet
EasyShare5300
All-in-OnePrinter
OK
b) If not preinstalled, insert the control panel overlay,
bottom end first.
EasyShare5300
E
All-in-OnePrinter
OK
OK
www.kodak.com/go/aiosupport
IMPORTANT: Do not connect the USB cable to the printer until instructed during
software installation.

4
Load Paper
www.kodak.com/go/aiosupport
2
b) Push the photo tray in until it clicks into place.
NOTE: You can only print to the photo tray when the
photo tray is pushed in.
Lower the photo tray lid.
a) Load photo paper into the photo tray.
Lift the photo tray lid until it remains standing without
support. Insert the photo paper glossy side down.
IMPORTANT: Do not overload the photo tray.
Max 20 sheets.
c) Load plain white paper into the main tray.

Install Printhead
3
c) Pull on the orange tab to remove the protective retainer.
b) Remove the printhead from its bag.
IMPORTANT: Insert the printhead immediately
upon opening sealed bag.
IMPORTANT: The printhead is fragile. Handle
carefully.
a) Lift the printer access door. Make sure the orange
tape is removed from the carriage.
www.kodak.com/go/aiosupport 5

f) Push firmly against the back wall of the printhead
until it clicks into place.
Tip: The printhead requires a firm push and makes
an audible click when locked into place.
e) Place the printhead into the carriage. Insert at the
angle shown.
d) Carefully remove and discard the black plastic shield
and the orange protective cap.
IMPORTANT: Do not touch the copper-colored
contacts.
www.kodak.com/go/aiosupport
6
Install Printhead

Install Ink Cartridges
4
c) Insert the black ink cartridge into the printhead.
10
Black Ink Cartridge
10
Black Ink Cartridge
a) Remove the black ink cartridge from its bag.
IMPORTANT: Insert ink cartridges immediately
upon opening sealed bag.
10
Black Ink Cartridge
b) Carefully remove and discard the orange cap.
Handle ink cartridges carefully to avoid ink transfer.
www.kodak.com/go/aiosupport 7
10
Black Ink Cartridge

d) Press down on the ink cartridge until you hear it
click into position.
10
Black Ink Cartridge
10
10
Black Ink Cartridge
Color Ink Cartridge
10
f) Press down firmly on the ink cartridge until you hear
it click into position. It is normal for the printhead to
flex when inserting the cartridge. You will not damage
the printer.
Close the printer access door.
e) Open and uncap the color ink cartridge. Insert it into
the printhead.
10
Black Ink Cartridge
10
ColorInk Cartridge
www.kodak.com/go/aiosupport
8
Install Ink Cartridges

Connect Power
5
All-in-One Printer
EasyShare 5300
Easyshare5300
All-in-OnePrinter
a) Connect the power supply and adapter.
b) Remove the plastic film from the LCD display.
Position the LCD display and press ON.
www.kodak.com/go/aiosupport
c) Press ON. If prompted, select your language.
Use the key to select a region.
All-in-One Printer
EasyShare 5300
-ON
9

6Calibrate Printer
b) Remove the calibration sheet from the output tray.
Place it face down and align to the front, right corner
of the scanner glass, as shown.
IMPORTANT: The blue arrow in the corner of the
calibration sheet must point to the registration
marks as shown.
IMPORTANT: Make sure that the photo tray is
pushed in. The photo tray light should be lit.
a) Press Start. Wait two minutes for the calibration sheet
to print.
Tip: If the calibration sheet does not print properly,
see the Troubleshooting section in this setup guide.
4x6
www.kodak.com/go/aiosupport
c) Lower the scanner lid and press Start. Remove the
sheet from the scanner glass when the calibration
is complete.
d) Lift the photo tray lid, then slide the photo tray toward
you to return to main tray operation. The photo tray
light will turn o.
10
4x6
4x6
