May 2005 •TI-2037
TECHNICAL DATA / PRINTED CIRCUIT BOARD FILM
KODAK PRECISION LINE
Contact Film UCA7
—High Complexity PCB Starts With the Right Phototools—
• Designed for making contact phototools from
photoplotter output or other line work.
• Negative working, slow speed, ultraviolet sensitivity
• Expose with high intensity metal halide or pulsed-xenon
source
• Use in white fluorescent illumination covered with
ultraviolet-absorbing material or in yellow fluorescent
illumination
• Very dimensionally stable ESTAR Thick Base with
antistatic properties under a wide range of humidity
conditions, both before and after processing.
• Excellent scratch and abrasion resistant overcoat.
• Produces high image density at line-for-line exposures
with minimum pinholes.
• Sufficient matte level on both sides to minimize
Newton's rings and to provide rapid drawdown in
vacuum printing frames.
• Can also be processed in a wide selection of machine
developers including lith and rapid-access, along with
KODAK ULTRALINE Developer and Replenisher.
SUPPORT
Dimensionally stable support.
7-mil (0.18 mm) ESTAR Thick Base
DARKROOM RECOMMENDATIONS
This film can be safely handled for up to a total of
60 minutes, before or after exposure, in up to 40 footcandles
(430 lux) of roomlight illumination substantially free of
ultraviolet (UV) energy. Such illumination is supplied by
yellow fluorescent lamps (warm white preferred) and white
fluorescent lamps covered by UV-absorbing or modified by
UV-absorbing plastic diffusers. Other roomlight sources
contain varying amounts of UV energy, and their roomlight
tolerances for this film should be tested under the specific
conditions of use.
STORAGE AND HANDLING
Keep unexposed film and processed film in a cool, dry place.
Process film as soon as possible after exposure.
EXPOSURE
Expose with a multi-level high-intensity metal-halide
exposure source. Optimum exposure should be determined
by means of a trial exposure series, following the equipment
manufacturer's recommended procedures. Use a trial
exposure time of 5 to 20 seconds at an exposure distance of
127 to 152 cm (36 to 60 inches). Contact your Kodak
representative for more information.
Note: Exposures for optimum line width reproduction are
critical when using a broad light source, and when making
base-to-emulsion exposures. Any light falloff from the
center to the edge of the exposing source may affect overall
reproductionqualityandintroduceproblemswithaccurate
line-width reproductions.
Precautionary: Contact the manufacturer of high intensity
ultraviolet lamps for safety information pertaining to
ultraviolet radiation and ventilation requirements due to
ozone generation.

2KODAK PRECISION LINE Contact Film UCA7 •TI-2037
RECIPROCITY
With recommended processing, the reciprocity speed change
is negligible (1/3-photographic stop or less) within exposure
range of 1/1000 second to 100 seconds; there is no change in
contrast.
PROCESSING
Notice: Observe precautionary information on product labels and on
the Material Safety Data Sheets.
Use KODAK ACCUMAX Rapid Access Developer and
Replenisher (diluted 1:2) and KODAK PROFESSIONAL
Rapid Fixer and Replenisher (diluted 1:3). Do not use any
type of hardener in the fixer.
Size CAT No.
KODAK ACCUMAX Rapid
Access Developer and
Replenisher
5 L concentrate 887 5569
KODAK PROFESSIONAL
Rapid Fixer and
Replenisher
5 L concentrate 174 9839
Recommended Starting Points:
Fixer: Use a fixer temperature of 32 - 35°C (90 - 95°F).
Replenishment Rates:
Developer
Temperature
Time
(Seconds)
ACCUMAX Developer
38°C (100°F) 30 seconds
35°C (95°F) 45 seconds
32°C (90°F) 60 seconds
RA 2000 Developer Repro Developer (Liquid)
35°C (95°F) 30 seconds
32°C (90°F) 45 seconds
Developer Fixer
350 mL / sq m 540 mL / sq m)

3KODAK PRECISION LINE Contact Film UCA7 •TI-2037
DIMENSIONAL STABILITY
Dimensional stability is an all-inclusive term. In
photography, it applies to size changes caused by changes in
humidity and in temperature, and by processing and aging.
The dimensional properties of ESTAR Base may vary
slightly in different directions within a sheet; the differences
that may exist, however, are not always equal between the
length and width directions.
Differences in size change between length and width
directions should be within 10 percent of each other.
CURVES
Characteristic Curve
95F, 22 sec
LOG EXPOSURE (lux-seconds)
0.0
0.0
2.0
DENSITY
1.0
2.0
3.0
7.0
3.0 4.0
Densitometry:
Exposure:
Process: RA 2000 Developer and Replenisher,
26 sec
Diffuse visual
6.0
5.0
4.0
1.0
F009_0415AC

KODAK PRECISION LINE Contact Film UCA7
Revised 5-05
Printed in U.S.A.
KODAK PRECISION LINE Contact
Film UCA7
KODAK Publication No. TI-2037
NOTICE: The sensitometric curves and data in this publication represent product tested under the conditions
of exposure and processing specified. They are representative of production coatings, and therefore do not apply
directly to a particular box or roll of photographic material. They do not represent standards or
specifications that must be met by Eastman Kodak Company. The company reserves the right to change
and improve product characteristics at any time.
Aerial and Industrial Markets Business
EASTMAN KODAK COMPANY •ROCHESTER, NY 14650
MORE INFORMATION
For the latest version of technical support publications for
Kodak products, visit Kodak on-line at:
http://www.kodak.com/go/PCBproducts
If you have questions about Kodak products, call Kodak.
In the U.S.A.:
1-800-242-2424, Ext. 19, Monday–Friday
9 a.m.–7 p.m. (Eastern time)
In Canada:
1-800-465-6325, Monday–Friday
8 a.m.–5 p.m. (Eastern time)
From outside the US/Canada: 1-716-724-4000
Note: The Kodak materials described in this publication for
use with UCA7 Film are available from dealers who supply
KODAK PROFESSIONAL Products. You can use other
materials, but you may not obtain similar results.
