Kodak Advantix 3600 ix User manual

1
3600ix Camera

2
4
3
2
1
Unexposed
Partially
Exposed
Fully
Exposed
Processed Negatives
Look for this logo to be certain that the film
you buy is made for this camera.
Look for this logo to select a certified
photofinisher for developing your film and to
assure that you get all the features of the
Advanced Photo System.
Film Status Indicator (FSI)
A highlighted indicator advances
from one symbol to another to
identify the status of the film inside
the cassette.

3
LCD
(8)
(1) (2)
(9)
(10)
(3)
(21)
(20) (19)
(a) (b)
(14)
(13)
(17)
(5)
(4)
(6)
(7)
(16)
LEFT
EXP
OPEN
(11) (12)
SELECT
MENU
ENTER
(18)
(30)
(c)
PM
LCD
(15)
OFFFILL
(28)
(29) (26)
(27)
(22)
(23)
ISO
PM
(24)
(25)
(d)

4
(e)
LCD
P
H
C
PM PM
o
(f)
PM
PM
1
4
23
56
7

5
ENGLISH
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE: Your model camera has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits provide reasonable protection against
interference in residential use. The camera generates, uses and can radiate radio frequency energy
and, if not used in accordance with the instructions, may cause interference to radio communications.
There is no guarantee that interference will not occur. If this camera does cause interference to radio
or television reception, which can be determined by turning the camera off and on, you may reduce
the interference by the following:
— Reorient or relocate the receiving antenna.
— Increase the separation between the camera and the receiver.
— Consult the dealer or an experienced radio/television technician for help.
Changes or modifications not approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Need help with your camera or more information about the new Advanced
Photo System? Call Kodak (United States only) toll free from 8:00 a.m. to
8:00 p.m. (Eastern time) Monday through Friday at 1 [phone]. The
toll free number (in Canada only) from 8:30 a.m. to 5:00 p.m. (Eastern time)
Monday through Friday is 1 [phone]; please ask for ext. 36100.
For warranty purposes, please keep your sales receipt as proof of the date
of purchase.

6
CAMERA IDENTIFICATION
See inside cover flaps of manual for camera diagrams.
(16) Viewfinder Eyepiece
(17) Focus/Flash Lamp
(18) Tripod Socket
(19) Film-Door Latch
(20) Film Door
(21) Strap Post
(22) Date & Time/ISO Film-Speed
Display
(23) Red-Eye-Reduction Indicator
(24) Battery Symbol
(25) Self-Timer Indicator
(26) Auto-Flash Indicator
(27) Film-Presence Indicator
(28) Fill-Flash Indicator
(29) Frame Counter/No Film in
Camera Indicator
(30) Off-Flash Indicator
(1) Shutter Button
(2) On/Off Button
(3) Meter-Cell Window
(4) Print-Size Selector
(5) Self-Timer/Focus-Ranging
Assist/Red-Eye-Reduction
Lamp
(6) Flash
(7) Battery Door
(8) Viewfinder
(9) Lens
(10) Focus-Ranging Sensors
(11) LCD Panel
(12) Menu Button
(13) Select/Flash Button
(14) Enter/Self-Timer Button
(15) Rewind Button

7
BATTERY
This camera uses a 3-volt lithium KODAK KCR 2 (or equivalent) Battery that supplies
power for all camera operations. This camera automatically turns off after 4
minutes.
Battery Indicator
When the battery symbol (24) “blinks,” you will need to replace the battery soon. When
the battery symbol is solid (non-blinking) and the shutter button does not operate,
replace the battery immediately.
Battery Tips:
•Keep a spare battery with you at all times. Lithium batteries perform
consistently until they suddenly die.
• Read and follow all warnings and instructions supplied by the battery manufacturer.
• Keep battery away from children.
• Do not attempt to disassemble, recharge or short circuit the battery, or subject it to
high temperature or fire.
• Store battery in its original packaging prior to use.
LOADING THE FILM
1. Slide the film-door latch (19) and insert the film cassette completely into the film
chamber ➌. Do not force the film cassette into the film chamber.
2. Close the film door (20) to start the auto-film advance. The LCD panel (11) will
show the total number of exposures (b). After you close the safety-interlock film
door, you cannot open the film door until the film is completely rewound into
the film cassette.

8
SETTING THE DATE AND TIME
With this camera, you can record the date and time of each exposure directly onto the film.
The information appears on the back of your prints when processed. It features a clock and
automatic calendar that includes leap years.
1. Press the menu button (12) to choose date. You must press this button to activate the
date and time function.
2. Press the hold the select/flash button (13) to view and change the “blinking” month
(d).
3. Press the enter/self-timer button (14) to store the selected month and move to the next
blinking date option (follow steps 2 and 3 to complete your selection.)
4. Repeat steps 1-3 to choose and set time.
NOTE: If you don’t press the select/flash button within a minute, the camera turns off
and returns to the picture-taking mode.
Choosing Optional Date and Time Formats
(mm, dd, yy / dd, mm, yy, / yy, mm, dd and 12/24 hour)
1. Press the menu button (12) to choose date. You must press this button to activate
the date and time function.
2. Press and hold for 3 seconds the enter/self-timer button (14) until desired date format
appears. (See SETTING THE DATE AND TIME, steps 2–3 above to set date.)
3. Press the menu button (12) to choose time.
4. Press and hold the enter/self-timer button (14) until desired time format appears. (See
SETTING THE DATE AND TIME, steps 2–3 above to set time.)
NOTE: If you don’t press the select/flash button within a minute, the camera turns off
and returns to the picture-taking mode.

9
Typical Print Sizes
C
Classic
31/2x 5" or 4 x 6"
(88.9 x 127 mm or
102 x 152 mm)
H
Group & Wide (HDTV)
31/2x 6" or 4 x 7"
(88.9 x 152 mm or
102 x 178 mm)
P
Panoramic
31/2x 10" to 4 x 111/2"
(88.9 x 254 mm to
102 x 292.7 mm)
TAKING PICTURES
You can take Classic (C), HDTV (H), and Panoramic (P) pictures on the same film
cassette (see following table for Typical Print Sizes). Your photo-processing
cost will be based on the format size(s) that you use to expose the film.
1. Press the on/off button (2), ➍.
2. Move the print-size selector (4), ➎to desired format.
3. Look through the viewfinder eyepiece (16) and place the auto-focus circle (f) on the
subject. For a sharp picture, stand at least 2 ft (0.60 m) from your subject.
4. Press the shutter button (1), ➏to take a picture.

10
Using the Focus Lock
This camera automatically focuses on whatever is within the auto-focus circle of the
viewfinder eyepiece (16). To get a sharp photograph, make sure the auto-focus circle is on
your main subject. If you want to take a picture with the subject positioned outside of the
auto-focus circle, use the focus lock as follows:
1. Place the auto-focus circle (f) on the subject that you want focused in the picture.
2. Partially depress and hold the shutter button (1) until the focus/flash lamp (17) glows
green to lock in the focus position.
3. While still depressing the shutter button, move the camera until your subject is where
you want it within the viewfinder.
4. Press the shutter button completely down to take the picture.
Special Focusing Situations
Some subjects or scenes, such as those described below, are difficult for the auto-focus
system to detect correctly; even though the focus lamp may glow green, the focus/exposure
may not be correct. To insure proper focus in the following situations, first lock the focus on
another object at the same distance from you as your main subject, then recompose your
picture and press the shutter button.
• Subject is near a very bright area or object such as a table lamp(s).
• A very bright- or low-contrast area fills the center of the auto-focus circle of the
viewfinder.

11
Using the Self-Timer
1. Use a tripod (tripod socket [18]) or place the camera on another firm support.
2. Press the on/off button (2), ➍.
3. Press the enter/self-timer button (14) to the self-timer (25) position.
4. Press the shutter button (1). The self-timer lamp (5) will “blink” 10 seconds before
the picture is taken.
NOTE: If you want to stop the self-timer operation before the picture is taken, press
the on/off button or the self-timer button again.
Tips for Better Pictures
• Hold the camera steady when taking pictures
• Keep your pictures simple. Move close enough to your subject so it fills the
viewfinder but not closer than 2 ft (0.60 m).
• Take pictures at the subject’s level. Kneel down to take pictures of children and pets.
• Hold your camera vertically to capture tall, narrow subjects, such as a waterfall,
skyscraper, or single person.
• Add interest to your picture by framing it with a tree branch, window, or even the
rails of a fence.
• Keep the sun behind you for best subject illumination.

12
TAKING FLASH PICTURES
In dim light, such as indoors or outdoors in heavy shade or on dark overcast days, you
need flash. Your camera features automatic flash that fires when you need it. It also
provides automatic daylight fill flash under certain bright-light conditions where
shadows may exist. If the focus/flash lamp (17) “blinks” red, the flash is not fully
charged. Wait for the light to turn green before you take a picture.
Focus/Flash Lamp Operation
Lamp Indicator Situation
Glows green Auto-focus operation complete and flash fully
charged. (Okay to take a picture.)
“Blinks” red Warning signal for flash needed or not ready,
flash out of range, or unable to focus. (Okay to
take a picture but picture may be under-
exposed or out of focus.)
Glows red Shutter button locks when subject is closer
than 2 ft (0.60 m ) from camera. (You can-
not take a picture until subject is beyond
2 ft [0.60 m]).

13
Flash-to-Subject Distance
ISO Film Speed Flash-to-Subject Distance
25 2 to 5.6 ft (0.60 to 1.7 m)
50 2 to 8 ft (0.60 to 2.0 m)
100 2 to 11.3 ft (0.60 to 3.5 m)
200 2 to 16 ft (0.60 to 5 m)
400 2 to 22.6 ft (0.60 to 6.8 m)
800 2 to 32 ft (0.60 to 10 m)
1600 2 to 45 ft (0.60 to 14 m)
Flash Tips
• Turn on room lights and have the subject face the lights to minimize
red eyes in pictures.
• Stand at an angle to shiny surfaces like windows or mirrors to avoid
flash reflection and bright spots in your pictures.
• Keep your fingers and other objects away from the picture-taking lens,
flash, and meter-cell window to avoid dark or light pictures.

14
Using Fill Flash, Off Flash, and Red-Eye Reduction
Fill Flash — Bright light indoors or outdoors from backlit subjects can create dark
shadows (especially on faces) in high-contrast scenes. Use fill flash to lighten the
shadows.
Off Flash — When you do not want to use the flash, especially indoors where flash is
prohibited, such as in theaters and museums, or in dim lighting situations, use off
flash. Use a tripod (tripod socket [18]) or place the camera on another firm support.
Red-Eye Reduction — Some people’s eyes (and some pets’) can reflect flash with a
red glow. To minimize red eyes in flash or fill-flash pictures, use red-eye reduction.
1. Press the on/off button (2) to turn the camera on.
2. Press the select/flash button (13) to select fill flash (28), off flash (30), or
red-eye reduction (23).
3. Press the shutter button (1) to take a picture.
4. Press the select/flash button to return to the auto-flash/start position (26).
UNLOADING THE FILM
After you take the last picture on the film cassette, the film automatically starts to
rewind. When the film is fully rewound, the LCD panel (11) displays “0” and an empty
film cassette (c). When you remove the cassette from the camera, the LCD panel
displays “E,” (a).
Using the Rewind Button
If you don’t want to take pictures on the entire film cassette, you can automatically
rewind the film by pressing the rewind button (15).Once you’ve used this feature,
you cannot reload the same film cassette into the camera.

15
TROUBLESHOOTING
What happened Probable cause Solution
Camera will not operate There are no more Remove the film
pictures remaining
Battery weak, dead, missing, Replace or reload the battery
or improperly inserted
Subject closer than Stand beyond 2 ft (0.60 m)
2 ft (0.60 m) from your subject
Focus/flash lamp glows red Subject closer than 2 ft (0.60 m) Move beyond 2 ft (0.60 m)
and shutter button locks from camera until red light disappears
Film does not Battery weak, dead, missing, Replace or reload the battery
advance or rewind or improperly inserted
LCD panel is blank (Flash (see Probable cause above) (see Solution above)
may fire inadvertently)
Film rewinds at beginning of Camera transport or film problem Load another film cassette
film load or middle of cassette into camera
(empty cassette symbol [27]
“blinks” on LCD panel) Call Kodak for assistance
Film door does Loaded exposed, partially
Load only unexposed film
not close exposed, or processed film into the camera
in the camera
All LCD indicators "blink" Camera mechanism problem Press shutter button, turn the
camera off and on, or replace
or reload the battery

16
SPECIFICATIONS
Film Type: KODAKADVANTIX Film for color prints
Lens: 24 mm, f/ 3.6 KODAK EKTON Lens
Focus System: 200 plus zones, passive auto focus with focus lock
Viewfinder: Real image with C, H, and P format display; auto-focus indicator
Film-Speed Range: DXIX (ISO) 25, 50, 100, 200, 400, 800 & 1600 for color print films
Flash Unit: KODAK SENSALITETM Flash
Focus Range: Daylight: 2 ft (0.60 m) to infinity
Apertures: f/ 3.6, f/ 7.2, f/ 14.4
Shutter: Programmed electronic; speeds from 1/2to 1/250 sec.
Power Source: one 3-volt lithium KODAK KCR 2 (or equivalent) Battery; auto power
off after 4 minutes
Dimensions: Approx. 1.5 x 2.5 x 4.7 in (38 x 63 x 119 mm)
Weight: Approx. 7 oz (195 g) with battery and film
Kodak,Advantix, Sensalite, Ekton, and the
Advanced Photo System symbol and logotype are trademarks.

17
Consumer Imaging
EASTMAN KODAK COMPANY
Rochester, NY 14650
1-97
Printed in U.S.A.
© Eastman Kodak Company, 1997
Pt. No. 916 3833
