Kogan KAWTCHMWRTA User manual

Strapless Sports Heart Rate Monitor Watch
KAWTCHMWRTA
Quick Start Guide
The Strapless Sports Heart Rate Monitor is the ideal device for anyone leading an
active lifestyle. With this unique multi-mode device, fitted with custom settings,
you can record data without discomfort and eep an eye on your health and
fitness.
Product Checklist
The following items are included:
•Strapless Sports Heart Rate Monitor
•USB adapter w/ charging cable
Specifications
Screen : 96*96 pixel
Wor temperature: -20℃～75℃
Size: 50 47 14.5mm × ×
Battery: 230mAh
G.W.: 70g
Bluetooth: V2.0
Note: The image above is a guide only.
There may be small changes between guide image and
the final product.

Getting Started / Charging nstructions
1. Position the monitor within the charging clip so its underside connects with
the charging clip's corresponding prongs. The monitor should be nestled
firmly within the charging clip to facilitate charging.
2. Ta e the USB end of the charging clip and connect it to the corresponding
port of the AC adapter. Plug the adapter into a power soc et and switch on
the power. The monitor will begin to charge, as indicated by the animated
battery icon on the LCD display. Note: alternatively, you may plug the USB
end of the charging clip into a powered device – eg. PC/Mac – to charge
the monitor.
3. Upon first use, you will be as ed to set a profile for the monitor. Note: if this
step has not occurred, you will need to reboot the device. To reboot, press
and hold both the Up (C) button and Down (E) button at the same time.
4. When the 'Please Set Profile' text appears, press the Confirm (D) button to
continue. You will be required to set values for height, weight, etc. To do so,
use the Up (C) button and the Down (E) button to adjust the values and
the (D) button to confirm and continue. Once this initial setup process has
been completed, the monitor will display a 'Welcome' text. Press Confirm
(D) to begin using the monitor. The first display screen will be the MODE 1
display screen.
Understanding the LCD Display
MODE 1 – STOPWATCH with TIME/DATE
This screen displays the monitor's time and date, in addition to
providing stopwatch data. To activate the stopwatch, press the
Confirm (D) button. To pause/reactivate the stopwatch, press
the Confirm (D) button. To reset the stopwatch, hold down the
Confirm (D) button.
MODE 2 – DATA SCREEN
This screen displays/records data as the monitor is being used.
To activate press the Confirm (D) button. Two icons will appear
in the top half of the LCD display and two green LEDs will
illuminate on the underside of the monitor. To select which data
the monitor displays whilst in this mode, press the Up (C)
button and the Down (E) button. (you can cycle between time-
based statistics and m/calorie statistics with each button
respectively)

MODE 3 – TARGET
To activate the target / reverse stopwatch, press the Confirm
(D) button. To pause/reactivate the stopwatch, press the
Confirm (D) button. To reset the stopwatch, hold down the
Confirm (D) button. Press and hold the Down (E) button view
data/records.
SETTINGS MENU
To access the settings menu, press the Menu (B) button. To
cycle through and highlight the setup sub-menus, use the Up
(C) and Down (E) button. To confirm your selection and enter
the sub-menu, press Confirm (D) when the desired sub-menu is
highlighted. Note: if you press Confirm (D) when 'Return' is
highlighted, you will be returned from the settings menu to the
previous screen. Pressing the Menu (B) button also exits from
the current menu interface.
* Target
This sub-menu will enable an exercise/activity target to be set for the user
(to be utilised via MODE 3). Press Confirm (D) to enter the 'Tar. Setup', then
use the Up (C) and Down (E) buttons to adjust the time/distance values.
Press Confirm (D) to set each value and to return to the Target sub-menu.
Highlighting 'Start' and pressing (D) returns the user to MODE 3. Data
recording will automatically commence. 'High Score' displays the user's best
records. Selecting 'Return' will exit the menu. Pressing the Menu (B) button
exits from the current menu interface.
* MS View
This sub-menu pertains to the storage of sport and phone data. It is
possible to lin the monitor with a phone via Bluetooth functionality. Note:
to activate the monitor's Bluetooth functionality, press and hold the Mode
(A) button whilst on one of the MODE screens, until the monitor vibrates
and a Bluetooth icon appears on the display. 'Sport' and 'Phone' allows
access to recorded sport and phone data (when Bluetooth is activated)
respectively, whereas 'DEL MS' can be used to delete data. Pressing the
Menu (B) button exits from the current menu interface.
* Sys Setup
This sub-menu pertains to the system setup of the monitor.
'Profile' enables the user to edit the height, weight and gender data entered
upon initially booting the monitor, using the Up (C) and Down (E) button
buttons to adjust each specific value. 'Time and Date' enables the user to
edit the monitor's time and date. Pressing the Menu (B) button exits from
the current menu interface. The 'Heartbeat' menu allows the user to toggle
heartbeat on/off. 'Bluetooth' is the menu in which the user can activate
Bluetooth functionality. (this can also be achieved by pressing and holding
the Mode (A) button whilst on one of the MODE screens).
'Alarm' allows the user to set an alarm for the monitor in accordance with the time/date set,
using the Up (C) and Down (E) buttons to adjust each specific value. 'Version' displays the
monitor's ID.

Miscellaneous Functions
Quick-access to data – Press and hold the Down (E) button whilst in one of the
MODE screens.
Monitor backlight – Press and hold the Up (C) button until the bac light
activates. Note: the bac light is only temporary.
Reboot – Press and hold the Up (C) and Down (E) buttons simultaneously to
reboot.
Warnings / Disclaimers
- Do not submerge in water or use in the shower.
- Do not disassemble the product.
- Any misuse of the product will void warranty. In the event of product misuse,
Kogan will not be responsible for damage or injury if applicable.
- If you believe this device has malfunctioned or requires repair, please refrain
from attempting to repair it yourself. Refer all servicing matters to qualified
personnel, or contact the Kogan Customer Support Team.
