Kogan LAPVR50XXXA User manual

<WsZϱϬyyy
USER MANUAL

TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
IMPORTANT SAFEGUARDS
Read and Follow Instructions- All the safety and operation instructions
should be read before the video product is operated. Follow all
operating instructions.
Retain Instructions- The safety and operating instructions should be
retained for future reference.
Heed all Warnings-Comply with all warnings on the video product and in
the operating instructions.
Polarization- Some video products are equipped with a polarized
alternating -current line plug. This plug will fit into the power outlet, try
reversing the plug. If the plug still fails to fit, contact your electrician to
replace your obsolete outlet. To prevent electric shock, do not use this
polarized plug with an extension cord, receptacle, or other outlet unless
the blades can be fully inserted without blade exposure. If you need an
extension cord, use a polarized cord.
Power Sources- This video product should be operated only from the
type of power source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your video dealer or
local power company. For video products intended to operate from
battery power, or other sources, refer to the operating instructions.
Overloading- Do not overload wall outlets or extension cords as this can
result in a risk of fire or electric shock. Overloaded AC outlets, extension
cords, frayed power cords, damaged or cracked wire insulation, and
broken plugs are dangerous, They may result in a shock or fire hazard.
Periodically examine the cord, and if its appearance indicated damage
or deteriorated insulation, have it replaced by your service technician.
Power-Cord Protection- Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the video product.
Ventilation- Slots and openings in the case are provided for ventilation
to ensure reliable operation of the video product and to protect it from
overheating. These openings must not the blocked or covered. The
openings should never be blocked by placing the video product on a
bed, sofa, rug, or heat register. This video product should not be placed
in a built-in installation such as a book case or rack, unless proper
ventilation is provided or the video product manufacturer's instructions
have been followed.
Attachments- Do not use attachments unless recommended by the
video product manufacturer as they may cause hazards.
Where the MAIN plug or an appliance coupler is used as the disconnect
device,the disconnect device shall remain readily operable.
: To reduce the
risk of fire and electric shock, do
not remove the cover (or back) of
the unit. Refer servicing only to qualified service personnel.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operation and servicing
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT AND FULLY INSERT.
In addition to the careful attention devoted to quality standards
in the manufacture of your video product, safety is a major factor
in the design of every instrument. However, safety is your
responsibility, too. This sheet lists important information that will
help to assure your enjoyment and proper use of the video
product and accessory equipment. Please read them carefully
before operation and using your video product.
Installation
The apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids ,such as vases shall be placed on the apparatus.
Caution: Maintain electrical safety. Powerline operated equipment or accessories
connected to this unit should bear safety certification mark on the accessory itself
and should not be modified so as to defeat the safety features. This will help avoid
any and should not be modified so as to defeat the safety features. This will help
avoid any potential hazard from electrical shock or fire. If in doubt, contact qualified
service personnel.
Accessories- Do not place this video product on an unstable cart, stand, tripod,
bracket, or table. The video product may fall, causing serious injury to a child or
adult as well as serious damage to the video product. Use this video product only
with a cart, stand, tripod, bracket, or table recommended by the manufacturer's or
sold with the video product. Any mounting of the product should follow the
manufacturer's instructions and use of a mounting accessory recommended by the
manufacturer.
A video product and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the video product and cart
combination to overturn.
Note to CATV system installer
This reminder is provided to call the CATV system installer's attention to
Section 820-40 of the NEC which provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.
Outdoor Antenna Grounding- If an outside antenna or cable system is connected to
the video product, be sure the antenna or cable system is grounded so as to
provide some protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code, ANSI/NFPA No.70-1984 (Section 54 of
Canadian Electrical Code, Part1) provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna-discharge unit, connection to grounding electrodes, and requirements for
the grounding electrode.
Power Lines-An outside antenna system should not be located in the vicinity of
overhead power lines, other electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching or approaching such power lines or
circuits, as contact with them might be fatal. Installing an outdoor antenna can be
hazardous and should be left to a professional antenna installer.
Use
Cleaning- Unplug this video product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Objects that may touch dangerous voltage points or "short-out" parts could result
in a fire or electric shock. Never spill liquid of any kind on the video product.
Lightning-For added protection for this video product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage
to the video product due to lightning and power line surges.
Service
Servicing-Do not attempt to service this video product yourself, as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
Conditions Requiring Service-Unplug this video product from the wall outlet and
refer servicing to qualified service personnel under the following conditions:
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into the video product.
C. If the video product has been exposed to rain or water.
D. If the video does not operate normally by following the operating
instructions.
Adjust only those controls that are covered by operating instructions.
Improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the video product
to its normal operation.
E. If the video product has been dropped or cabinet has been damaged.
F. When the video product exhibits a distinct change in performance-this
indicates a need for service.
Replacement Parts-When replacement parts are required, have the service
technician verify that the replacements he uses have the same safety
characteristics as the original parts. Use of replacements specified by the video
product manufacturer can prevent fire, electric shock, or other hazards.
Safety Check-Upon completion of any service or repairs to this video product, ask
the service technician to perform safety checks recommended by the
manufacturer to determine that the video product is in safe operating condition.
Wall or Ceiling Mounting- The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
Heat-The product should be situated away from heat sources such as radiators,
heat registers, stoves, or other products (including amplifiers) that products heat.
10.
11.
11a.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
CAUTION
The apparatus shall not be exposed to dripping or splashing, and that no
objects filled with liquids, such as vases, shall be place on the apparatus.
SAFETY INFORMATION
1.
2.
3.
4.
5.
6.
7.
8.
9.

CONTENTS
SAFETY INFORMATION
INTRODUCTION
Front panel
Rear panel
Remote control
SYSTEM CONNECTION
General
Connecting the TV
Connecting a HiFi System
GETTING STARTED
Welcome
Installation
OPERATION
Changing channels
Access the Electronic Programme Guide(EPG)
EDIT CHANNEL
Edit Channel menu
TV Channel list
Radio Channel list
Delete All
SYSTEM SETUP
System setup menu
Language
TV System
Local Time Setting
Timer Setting
Parental Lock
OSD Setting
Favorite
Auto Standby
TOOLS
Tools main menu
Information
Load Factory Setting
Software Upgrade
Remove USB device safely
GAMES
Game
REC
REC main menu
Media Player
HDD Information
PVR Setting
TIMESHIFT/RECORD
Timeshift
Record
Two Programs Recording in the same TP( Transponder)
Two Programs Recording in Difference TP
TROUBLESHOOTING
SPECIFICATIONS
3
3
3
4
4
5
5
6
6
6
6
7
7
7
7
7
8
8
8
8
9
9
9
9
10
11
12
12
13
13
14
14
14
15
16
17
1
1
2

Front panel
Rear panel
INTRODUCTION
Remote sensor
AC Mains
Composite Video
Coaxial Digital Audio
TV aerial
for an external TV aerial
RF Loop through
for an external device HDMI Output
1
English
1
USB port
Standby button
Down Mix Audio
2 Channel L/R
Display
Progressive Scan Video
(Y Pb Pr)
MENU
Channel Up/
Down
Volume Up/
Down
OK button
OK
Cursor /Enter
REC
PLAY/PAUSE MENU EXIT
STANDBY/ON
OK
USB REC
PLAY/PAUSE
Coaxial
Digital Audio
KAPVR50XXXA
AC 220-240V
~50/60Hz
DVB-T RECEIVER
POWER SUPPLY:
AC 220-240V~50/60Hz
MAX POWER CONSUMPTION:15W
RF IN
Pr
CVBS R L
Y
Pb
HDMI
RF OUT

STANDBY INFO SUBTITLE
OK
EPG
AUDIOUSB TV/RADIO
BACK
VOL+ VOL-
CH+
CH-
TTX TIMER FAV
MUTE
MEDIA
RES
EXIT
MENU
RECORD
INTRODUCTION
Remote control
1
English
2
1
2
3
4
5
6
15
18
19
12
20
21
22
7
8
9
10
11
13
14
16
17
23
24
26
25
1
2
3
STANDBY
(switch the STB on and standby)
INFO
(Press for current channel information )
PLAY
26
OK button
(Confirm a selection within a menu)
Numeric entry
(Enter numeric values and select the channel
directly by entering it's number)
AUDIO
(Select audio mode and audio track)
SUBTITLE (On/Off Subtitle)
TTX (Open interactive service)
8
9
11
10
12
13
15
14
4
5
6
7
16
17
18
19
20
21
22
23
24
25
BACK
(Switch to previous channel)
EPG
(Open up Electronic Program Guide Menu)
Cursor/CH+, -/VOL+,-
(Cursor: Navigation buttons used to navigate
menu's items)
(CH+/-: Channel Up and Down)
(VOL+/-: Volume Up and Down)
RECORD
(Record the TV program)
Search backward /forward
FAV
(Open the Favorite list)
RED/GREEN/YELLOW/BLUE Buttons
(For interactive function/Submenu
function buttons)
PAUSE(Pause/Active timeshift function)
Previous/Next
STOP
(Stop program playback or recording)
TV/RADIO
(Switch between TV and Radio)
MUTE (Turn off/on the volume)
MEDIA
(Enter Record menu)
USB
(Enter Music menu)
TIMER
(Timer wake-up)
Menu
(Open and close the menu screen)
EXIT (Exit from menu)
RES (Switch HDMI resolution)

AC 220-240V
~5 0/60 Hz
MA X. 9W
YPb P r
VIDEO R- AUDI O-L
AN T IN AN T OUT HD MI COAXIAL
SYSTEM CONNECTION
There are many different types of TV and other equipment that you can connect to the STB.
In this manual you will see some of the most common ways to connect your equipment.
General
Connecting a HiFi system
Coaxial cable
Connecting the TV
1
English
3
Hi-Fi
AC 2 20-2 40V
~5 0/60 Hz
MA X. 9W
YPb P r
VIDEO R- AUDI O-L
AN T IN AN T OUT HD MI COAXIAL
HDMI TV
RF cable
Audio
(Down mix stereo)
HDMI cable
Component Video
Video (Composite)

Welcome
If you use the STB for the first time, the "Welcome" menu appears.
Press cursor button to setup the Region, Language, Display Mode
and Aspect Mode.
Highlight "OK" and press the "OK" button to start channel search.
GETTING STARTED
Installation
Select "Channel Scan", press the "OK" button to enter the Channel
Scan menu.
Press cursor button to set Scan mode, Scan Band ,
Channel No., Frequency and Bandwidth, then highlight "Search",
press "OK" button to start channel scan .
1
1
2
2
4
Press the cursor button to set "FTA Only", then highlight "Search",
press the "OK" button to start auto scan .
1
2
3
Channel Scan mode:
By channel
By frequency
Select the "Aerial Adjustment", press"OK" to enter the Aerial
Adjustment.
Press the cursor button to set the desired setting.
When "Tuner Power" is selected "On", the STB will provide 5V power
to antenna.
It will not provide when selected "Off".
1
2
1
English
4
Auto Scan
Channel Scan
Aerial Adjustment
LCN
Press the "MENU" button to enter main menu.
Press "UP"or " DOWN " button to highlight "Installation", press
"RIGHT" button to enter the Installation menu.
Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK"button to enter the sub-menu .
Press "EXIT" button to exit.
Select the "Auto Scan", press "OK" button to enter the Auto Scan menu.
If LCN( Logical Channel Number) Select function is activated, you can't change the original
number of TV channels by scanning .
You can activate/disactivate the LCN function by setting the "LCN Mode" to on/off.
Auto Scan
Channel Scan
Aerial Adjustment
LCN
Installation
Auto Scan
FTA Only
Search
No
Channel Scan
Scan Mode
Scan Band
Ch No.
Search
Frequency
Bandwidth
By channel
UHF
CH37(666000KHz)
666000KHz
8MHz
Signal Intensity
Signal Quality
81%
97%
Aerial Adjustment
Ch No.
Tuner Power
CH37(666000KHz)
Off
Signal Intensity
Signal Quality
81%
97%
Welcome
Region
Language
Display Mode
Aspect Mode
Australia
English
Auto
1080i
OK

Accessing the Electronic Program Guide (EPG)
OPERATION
Changing Channels
There are three ways of channel selection - stepping through the channel list, selection by number
and from the on-screen channel list.
Stepping through the channel list:
To move through the channel list, press the upward arrow or downward arrow key on the
remote control.
Selected by number:
Enter the channel number directly by pressing numeric buttons ,and press the "OK" button
to select desired channel.
Selected by on-screen channels list:
You can also select the required channel directly from on-screen channel list. This is
displayed using the STB's main menu. See "Edit Channel" in this manual for operation detail.
1
2
3
Accessing the EPG of all channels:
1
2
3
Press "EPG" button to enter EPG menu .
Press cursor button to switch between channel list, events
schedule of the selected channel and now/next events.
Press "Green" button to Timer the events.
Press "Red" button to display " Time Bar" menu.
4
1
English
5
0008
0009
0010
0011
0012
Interecon
BBC Parl
BBC FO
CBeebie
301
0010 BBC FOUR
The Recor
This is CBeebies!
Auntie's War on Smut
The Recor
Commons Questions
Proms on FOUR
Auntie's War on Smut
01:30-02-30
Timer
Time
EPG
3/19 01:30 02:00 02:30 03:00
01:39 xx/xx/xxxx

Edit Channel menu
EDIT CHANNEL
TV Channel list
In the Edit Channel menu, select "TV Channel List", press "OK"
button to enter TV channel list menu.
1
2
Use this menu to favor, lock, skip, move, sort, delete and rename
channel.
Press "FAV" button, then press "OK" button to edit the FAV
function.
Press "UP" or "DOWN" button to highlight channel, press the "OK"
button to preview the desired TV channel.
1
English
6
4
1
2
3
Press the "MENU" button to enter main menu.
Press "UP" or "DOWN " button to highlight "Edit Channel", press
"RIGHT" button to enter the Edit Channel menu.
Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK" button to enter the sub-menu .
Press "EXIT" button to exit.
Sort
YooPlay Ga
xxxxxxxx
xxxxxx
xxxx
xxx
TV Channel List
FAV Lock Skip
Move Edit
All Channel
0001 No Name
0002 YooPlay Ga
0003 E4+1
0004 UKTV Histor
0005 SKY THREE
0006 Sky Spts Ne
0007 Sky News
0001 No Name
0002 YooPlay Ga
0003 E4+1
0004 UKTV Histor
0005 SKY THREE
0006 Sky Spts Ne
0007 Sky News
i
Radio Channel list
In the Edit Channel menu, select "Radio Channel List", press "OK" button to enter the Radio
Channel list menu.
Press "UP" or "DOWN" button to highlight channel press the "OK" button to listen the desired TV
channel.
1
2
NOTE:
Basically, the operation of "Radio Channel List" is the same as "TV Channel List",
but there is one point different: In "Radio Channel List" mode, there is no video
information, so it will always display Radio's logo in the right side preview window.
Delete All
1
2A warning window appears.
Select "Yes", press "OK" button to delete all channels.
Select "No", Press "OK" button to cancel deleting.
Warning! Do you really want to delete
all channels?
Yes No
In the Edit Channel menu, select "Delete All", press "OK" button.
Press "color" button, then press "OK" button to edit the
corresponding function.
TV Channel List
Radio Channel List
Delete All
Edit Channel
Rename Delete
YooPlay Ga
xxxxxxxx
xxxxxx
xxxx
xxx
Edit Channel
All Channel
i

System setup menu
System setup menu allows us to set Language, TV System, Local Time
Setting, Timer Setting, Parental Lock, OSD Setting, Favorite and Auto
Standby.
Language
This menu allows you to set Language.
SYSTEM SETUP
Local Time Setting
This menu allows you to set the region and time.
GMT Usage:
This menu is used for open the usage of GMT.
The options are : Off / On
GMT Offset: This menu is valid only when selected "User Define"
in GMT Usage menu .
The GMT offset range is "-11:30 ~ +12:00", increasing
half hour progressively.
Date:
Time:
"Date" and "Time" menus are valid only when selected "Off" in GMT Usage menu.
Press numeric button to input the time.
Region: This menu is used for changing the region setting.
1
English
7
Region
GMT Usage
GMT Offset
Summer Time
Date
Time
Australia
On
GMT+10:00
Off
xxxx/xx/xx
01:51
Local Time Setting
xxxx,xxx,xxxx
4
1
2
3
Press the "MENU" button to enter main menu.
Press "UP" or "DOWN" button to highlight "System Setup",
press "RIGHT" button to enter the System Setup menu.
Press "UP" or "DOWN" cursor button to highlight the desired
item and press "OK" button to enter the sub-menu.
Press "EXIT" button to exit.
Language
First Audio
Second Audio
Subtitle Language
Subtitle Display
Teletext
English
English
German
English
Off
English
Language
Timer Setting
This menu allows us to set the program timer. You can set 8 timers.
Timer Mode:
Timer Service:
Wakeup Channel:
Wakeup Date:
Wakeup Time:
Duration:
Off/Once/Daily/Working day/Weekly
Channel/Record
You can select a desired channel as the wakeup channel.
Press numeric button to input date.
Press numeric button to input the time.
Press numeric button to input the duration time.
Save Cancel
Current Time/date: 01:36PM xx/xx/xxxx
Timer Mode
Timer Service
Wakeup Channel
Wakeup Date
Wakeup Time
Duration
Daily
Channel
BBC FOUR
xx/xx/xxxx
xx:xx
xx:xx
System Setup
Language
TV System
Local Time Setting
Timer Setting
Parental Lock
OSD Setting
Favorite
Auto Standby
TV System
This menu allows us to set Video Resolution, Aspect Mode and
Digital Audio Output.
Aspect Mode:
Auto/4:3PS/4:3LB/16:9
Digital Audio Output:
Video Resolution:
LPCM Out/ BS Out
576p/720p/1080i/1080p
Video Resolution
Aspect Mode
Digital Audio Output
576p
Auto
LPCM Out
TV System

OSD Setting
This menu allows you to set OSD Timeout and OSD Transparency .
This menu allows you to rename the favorite group.
OSD Timeout: 1-10
OSD Transparency:
To set the OSD transparency to Off/10%/20%/30%/
40%.
SYSTEM SETUP
Parental Lock
In "System Setup" menu, select "Parental Lock" and press "OK" button,
you are asked to input a password(the default password is"0000").
After inputting the correct password by pressing numeric buttons,
the parental lock menu appears.
1
2
Menu Lock:
New Password: To change the password.
Confirm Password: To confirm the new password.
Channel Lock:
Off/ P,C,G,PG,M,MA,AV,R
1
English
8
To lock the Edit channel/ installation/System setup/ Tools/
REC menu. When you want to enter these menus, you must
input the password. You can set menu lock to on/off.
This menu allows you to protect menu and channel, and change the
Password.
Favorite
In Channel menu, select "Favorite", press "OK" button to enter
Favorite menu.
Select desired group, press "OK" button to open the mock keypad.
Input letter and numeric one by one by pressing the cursor button
and press "OK" button to confirm. After finishing input, highlight
"OK" on mock keypad to confirm, you change Favorite group name
successfully.
Press "EXIT" button to quit the group rename menu.
1
2
3
Auto Standby
No command to STB on front panel or Remoter in 3 hours and
no timer event, the STB will enter standby mode automatically.
The STB can't enter standby mode automatically.
On
Off
Menu Lock
Channel Lock
New Password
Confirm Password
Off
Off
----
----
Parental Lock
OSD Timeout
OSD Transparency
5
Off
OSD Setting
1
2
3
4
5
6
7
8
Favorite
Fav group 1
Fav group 2
Fav group 3
Fav group 4
Fav group 5
Fav group 6
Fav group 7
Fav group 8
Auto Standby On
Auto Standby
CAPS
A
Fav group 1
G
M
S
Y
4
SP
Rename
Del OK
B C D E F
K LH J I
N
T
Z
5
O
U
0
6
?
P
V
1
7
<-
Q
W
2
8
OK
R
X
3
9

Tools main menu
Information
In "Tools" menu, select "Information", press "OK" button to open
information window.
Press "EXIT" button to exit.
1
2
TOOLS
This menu can display some parameters information in this STB.
Load Factory Setting
This menu allows you to re-set the STB back to factory settings,
clear all existed channels.
In the "Tools" menu, select "Load Factory Default", press "OK" button.
You are asked to input a password(the default password is"0000").
1
2
Software Upgrade
Press "EXIT" button to exit.
Enter "Tools" menu, select "S/W Upgrade by OTA" or "Upgrade
by USB", press "OK" button, Software Upgrade menu is shown.
1
2Press cursor button to select the desired item, then highlight
"Start" and press "OK" button to start upgrade.
3
A confirmation window is displayed.
Select "Yes" to return back to factory settings and clear all channels.
Select "No" to cancel back to factory settings.
Press "EXIT" button to exit .
We offer the functions for user to upgrade software version by OTA
or by USB .
1
English
9
4
1
2
3
Press the "MENU" button to enter main menu.
Press "UP" or " DOWN " button to highlight "Tools", press "RIGHT"
button to enter the Tools menu.
Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK" button to enter the sub-menu.
Press "EXIT" button to exit.
3
Tools
Information
Load Factory Setting
S/W Upgrade by OTA
Upgrade By USB
Remove USB device safely
Information
x.x.x
xxxxx
xxxxx
x.x.x
x.x.x
xxx
xxxxx
xxxxx
xxx
xxx
Load Factory Setting
This operation will load the default settings and
erase all the channels , the system will reboot,
do you want to continue?
Yes No
Upgrade by USB
Upgrade mode
Upgrade File
Start
Allcode
No File
0%
Remove USB device safely
In "Tools" menu, select "Remove USB device safely",
Press "OK" button to confirm. Then a window is displayed.
Press "OK" button again.
Information
Load Factory Setting
S/W Upgrade by OTA
Upgrade By USB
Remove USB device safely
Tools
Disk Remove
Remove
OK
USB Disk A-3 GB
Cancel

Game
This menu allows you to play games.
GAME
4
1
2
3
Press the "MENU" button to enter main menu.
Press "UP" or "DOWN" button to highlight "Game", press "RIGHT"
button to enter the Game menu.
Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK" button to enter the game.
Press "EXIT" button to exit.
1
English
10
Game
Othello
Sudoku

REC main menu
REC
1
English
11
4
1
2
3
Press the "MENU" button to enter main menu.
Press "UP"or "DOWN" button to highlight "REC", press
"RIGHT" button to enter the REC menu.
Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK"button to enter the sub-menu.
Press "EXIT" button to exit.
Media Player
3
In "REC" menu, select "Media Player", press "OK" button to enter
Media Player menu.
First you enter media player window, the highlight is on the
USB/HDD device. Press "Down" button to move the highlight to
directory and file field.
Press "INFO" button ,you can switch TAB between
Music/Image/Video/Record.
Press "UP" or "DOWN" cursor button to select a desired item,
and press "OK" button to play the desired files.
Press "EXIT" button to exit.
1
2
This function allows you to play files from USB device.
I swear.mp3
3319KB
00:03:32
00:03:15 00:03:32
1
3
4
5
6
7
2
Music
840.mpg
Why.mp3
Lonely.mp3
Because.mp3
I swear.mp3
USB 1
/..
Play List
Switch Repeat Sort
MPG
MP3
MP3
MP3
MP3
JPG
JPG
INFO 2
1
REC
Media Player
HDD Information
PVR Setting
FAV FAV All Edit
Exit
EXIT
Image Video Record
Music:
Image:
Press "RED" button to show Play List.
Move the highlight to the file which you want to add to play list, then press
"Green" button to add. It will mark a favorite icon on the file.
Press "Yellow" button to add all file of current directory to play list. Press again to
delete all file of current directory from the play list.
Press "Blue" button to enter to edit sub-menu.
Press "1" button to open the sort window. You can sort by Name/Time/Size/Favorite.
Press "2" button to set repeat mode. The option is Repeat Folder/
Random Folder/Repeat One.
Return to parent directory.
4
5
Press "Red" button to show play list.
Move the highlight to the file which you want to add to play list, then press
"Green" button to add. It will mark a favorite icon on the file.
Press "Yellow" button to add all file of current directory to play list. Press again to
delete all file of current directory from the play list.
Press "Blue" button to enter to edit sub-menu.
Press "1" button to open the sort window. You can sort by Name/Time/Size/Favorite.
Press "2" button to open image setup
Press "3" button to view image in multi view mode
Return to parent directory.
"RED" button:
"GREEN" button:
"YELLOW" button:
"BLUE" button:
"1" button:
"2" button:
"EXIT" button:
"RED" button:
"GREEN" button:
"YELLOW" button:
"BLUE" button:
"1" button:
"2" button:
"3" button:
"EXIT" button:

This menu allows us to set the PVR Setting.
Press "UP" or "DOWN" cursor button to select desired item,
press "LEFT" or "RIGHT" cursor button to change the setting.
TimeShift On/Off
Timeshift to Record On/Off
Standby after record On/Off
PVR Setting
1
English
12
REC & MEDIA
HDD Information
In "REC" menu, select "HDD Information", press "OK"
button to open HDD information window.
Press "EXIT" button to exit.
This menu can display some parameters of Removable Disk.
1
2
HDD Information
USB Disk A: xxxG bytes
Volume
Total Size
Free Size
Rec Size
TMS Size
File System
xxxx
xxxx
xxxx
xxxx
xxxx
xxx
Format DVR Set
Timeshift
Timeshift to Record
Standby after record
ON
ON
OFF
PVR Setting
DVR Set Select storage for REC&TMS/Record/Timeshift
Press BLUE button to open DVR Set menu.
Press "LEFT" or "RIGHT" cursor button to change DVR Type.
Select "OK" to confirm. Select "Cancel" to cancel.
Press YELLOW button to open Format menu.
Press "LEFT" or "RIGHT" cursor button to change Disk Mode.
Select "OK" to format. Select "Cancel" to cancel.
Format FAT/NTFS
DVR Set
DVR Type
OK
REC& TMS
Cancel
Format
Disk Mode
OK
FAT
Cancel
Record:
Press "Red" button to open rename window.
Move the highlight to the program which you want to lock. Pressing "Green"
button, it will ask you to input password. Default password is "0000". After
input correct password, the program is locked. If you want to unlock the
program, press the "Green" button again.
Press "Yellow" button to make a delete mark on the program which
you want to delete.
Return to parent directory.
Video:
Press "Blue" button to enter to edit sub-menu.
Press "1" button to open the sort. You can sort by Name/Time/Size.
Return to parent directory.
"BLUE" button:
"1" button:
"EXIT" button:
"RED" button:
"GREEN" button:
"YELLOW" button:
"EXIT" button:

TIMESHIFT/RECORD
Timeshift
The HDD gives you access to Time Shift/Record a broadcast programme.
Pause a broadcast programme and continue watching it later (Time Shift )
Record a broadcast programme.
When the space available on the Mass Storage Device runs out, recording operation of
broadcast will stop.
Initiate
Trickmodes
Stop the Time Shift
Time Shift can be done in viewing mode by pressing the
"PAUSE" button.
Press "RIGHT" or "LEFT" button to move the cursor to
the time you desired to view. Press "OK" button to confirm.
During the playback, it is possible to perform the following actions :
Press "PAUSE" button to pause the playback
Press "FORWARD" button to fast forward the playback
Press "BACKWARD" button to rewind the playback
Record
Instant record
In viewing mode, press "RECORD" button to instantaneously start a record on the current channel.
Press "RECORD" button again can input duration.
Press "STOP" button to stop recording, then a confirmation window appears.
Select "Yes" to stop recording. Select "No" to continue recording.
Press "STOP" button to stop TimeShift.
BBC FOUR
Play 00:02:37 00:07:12
TS
2%
03/19 01:36
1
English
13
NOTE:
Please use internal storage or USB 2.0 disk when recording or timeshift.
For timeshift and recording feature, you need take bigger size USB pen
driver or HDD (>2GB) for recording.
Two Programs Recording in the same TP( Transponder)
When recording 2 FTA programs in the same transponder user can change to
any programs via CH+/- button.
In order to indicate the information of the recording programs, there is a REC
icon on the screen if the program is recording.
Press "STOP " button to stop recording, then a confirmation window appears.
Select Rec1/Rec2 to stop recording Rec1/Rec2. Select "Cancel" to continue recording.
Rec 2 Cancel
Stop recording?
Rec 1: [SZTVM01]
Rec 2: [SZTVM04]
Rec 1

1
English
14
TIMESHIFT/ RECORD
Please select USB 2.0 USB HDD or USB stick for Recording and Timeshift, such as
SAMSUNG, HITACHI and SONY. Some USB devices maybe can't be supported due to its quality.
famous brand
NOTE:
Two Programs Recording in Difference TP
When recording 2 FTA programs in difference TP, user can tune to FTA programs in the two TP.
In the channel list, the programs outside of the TP are grayed and can not be selected.

In some region, the digital terrestrial signal may be weak. So you'd better use the antenna in
which the booster was built, for watching the weak signal channels.
TROUBLESHOOTING
Problem
Standby light not lit
No signal found
No picture or sound
Scrambled channel
message
No response to remote
control
Forgotten channel lock
code
Forgotten menu lock
code
The remote control will
not operate your STB
After moving the STB to
another room you find you
are no longer able to
receive digital reception
Timeshift has no function/
Record has no function
Possible cause What to do
Mains lead unplugged
Mains fuse blown
Aerial is disconnected
Aerial is damaged/misaligned
Out of digital signal area
Scart/AV is not selected on your TV
Channel is scrambled
Receiver off
Handset not aimed correctly
Front panel obstructed
Hand set batteries exhausted
(1) The batteries in your remote
control need replacing
(2) There is an obstruction
blocking the signal path
between the remote control
and the box.
The aerial feed former new point
may come through a distribution
system which may reduce the
digital signal now received by the
box.
(1) Poor contact between PVR and
HDD.
(2)HDD runs out.
Check mains lead
Check fuse
Check aerial lead
Check aerial
Check with dealer
Reduce to another channel
Select alternative channel
Plug in and turn on plug
Aim handset at front panel
Check for obstructions
Replace handset batteries
Re-install channels to cancel
channel lock
Contact help line
(1) Replace the batteries
(2) Check that there is nothing in
the way of the path between
the remote control and the
receiver
Try a direct feed from the antenna
(1) Check the HDD to make sure
good connection.
(2) Delete some files to make sure
the HDD has enough available
space.
1
English
15

Design and Specifications are subject to change without notice.
TUNER & CHANNEL RF INPUT CONNECTOR x1
(IEC-TYPE, IEC169-2, FEMALE)
RF OUTPUT CONNECTOR x1
(IEC-TYPE, IEC169-2, MALE (LOOPTHROUGH))
FREQUENCY RANGE:
174MHz~230MHz(VHF)
470MHz ~862MHz (UHF)
SIGNAL LEVEL:
-15 ~ -70 dbm
DECODER
Video decoder
Audio decoder
VIDEO FORMATS
MODULATION
INPUT RATE MAX. 48Mbit/s
4:3/,16:9 SWITCHABLE
QPSK,16QAM,64QAM
CONNECTION
MAIN POWER CABLE
TUNER
SPDIF
FIXED TYPE
ANTENNA INPUTx1, RF OUTPUT x1
COAXIAL x1
USB slot
POWER SUPPLY
INPUT VOLTAGE
POWER CONSUMPTION
AC220~240V, 50/60Hz
MAX. 15W
DATA PORT
1
English
16
MPEG-2 MP@HL,
MPEG-4 ASP SUPPORTED
AVC/H.264 HP @L4.1
MPEG-1 Layer 1,2/PCM/HE-AAC V1.0
ICE958 SPDIF
RCA OUTPUT V/L/R x1
SPECIFICATIONS
NOTE:
HDMI HDMI OUTPUT x1
COMPONENT VIDEO OUTPUT Y Pb Pr Component Video output x1
INTERNAL HDD SATA HDD( 2TB maximum, optional)
