Kogan KAM413TMSFA User manual

413L TOP MOUNT FRIDGE
KAM413TMSFA, KAM413TMSFB

Safety & Warnings 3
Overview 7
Before First Use 9
Operation 10
Functions 11
Cleaning & Care 13
Troubleshooting 15

ENSURE YOU HAVE READ THIS USER GUIDE CAREFULLY BEFORE USE. RETAIN THE
USER GUIDE FOR FUTURE REFERENCE.
Warning:
Warning: Risk of fire / flammable materials.
This appliance is intended to be used in household and similar applications such as staff
kitchen areas in shops, offices and other working environments; farmhouses and by clients
in hotels, motels and other residential type environments; bed and breakfast type
environments; catering and similar non- retail applications.
If the supply cord is damaged, it must be replaced by Kogan.com or an authorised
representative in order to avoid a hazard.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
The appliance must be unplugged after use and before carrying out user maintenance on
the appliance.
WARNING: Keep ventilation openings in the appliance enclosure or in the built-in structure,
clear of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
WARNING: If disposing, dispose according to local regulators as it contains flammable
blowing gas and refrigerant.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or
damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the
rear of the appliance.
Do not use extension cords or ungrounded (two prong) adapters.
DANGER Risk of child entrapment. Before you throw away your old refrigerator or freezer:
•Take off the doors.
•Leave the shelves in place so that children may not easily climb inside.
SAFETY & WARNINGS

•Refrigerant and cyclopentane foaming material used for the appliance are
flammable. Therefore, when the appliance is scrapped, it shall be kept away from
any fire source and be recovered by a special recovering company with corresponding
qualification other than be disposed by combustion, so as to prevent damage to the
environment or any other harm.
•This appliance can be used by children aged from 8 years and above and persons
with reduce physical sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by children without supervision.
•Children aged from 3 to 8 years can load and unload refrigerating appliances.
•WARNING: To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions.
Electricity related warnings
•Do not pull the power cord when pulling the power plug of the refrigerator. Firmly
grasp the plug and pull out it from the socket directly.
•To ensure safe use, do not damage the power cord or use the power cord when it is
damaged or worn.
•Use a dedicated power socket and the power socket shall not be shared with other
electrical appliances. The power plug should be firmly contacted with the socket or
else fires might be caused.
•Ensure that the grounding electrode of the power socket is equipped with a reliable
grounding line.
•Turn off the valve of the leaking gas and then open the doors and windows in case of
leakage of gas and other flammable gases. Do not unplug the refrigerator and other
electrical appliances considering that spark may cause a fire.
•Do not use electrical appliances on the top of the appliance.
Operation warnings
•Do not arbitrarily disassemble or reconstruct the refrigerator, nor damage the
refrigerant circuit; maintenance of the appliance must be conducted by Kogan.com
or an authorised representative.
•If the power cord is damaged, cease use immediately and contact Kogan.com for
assistance. Do not use the fridge again until it has been permitted.
•A damaged power cord must be replaced by Kogan.com or an authorised
representative in order to avoid danger.
•The gaps between the refrigerator door and cabinet is small. Do not to put your hand in
these areas to prevent from squeezing the finger. Be gentle when closing the
refrigerator door to avoid falling articles.
•Do not pick foods or containers in the freezing chamber when the refrigerator is running,
especially metal containers in order to avoid frostbite.

•Do not allow any child to get into or climb the refrigerator; otherwise suffocation or a
falling injury may be caused.
•Do not place heavy objects on the top of the refrigerator considering that objects may
fall when opening or closing the door and accidental injuries might be caused.
•If experiencing frequent power outages, we recommend un-plugging the fridge until the
power supply is consistent. Do not connect the refrigerator to the power supply within
five minutes to prevent damages to the compressor due to successive starts.
Warnings for placement
•Do not put flammable, explosive, volatile, and highly corrosive items in the refrigerator
to prevent damages to the product or fire accidents.
•Do not place flammable items near the refrigerator to avoid fires.
•The refrigerator is intended for household use, such as storage of foods; it shall not be
used for other purposes, such as the storage of blood, drugs or biological products, etc.
•Do not store bottled fluids (such as beer, soft drink, etc) or enclosed containers in the
freezing chamber of the refrigerator; the bottles or enclosed containers may
crack/shatter due to freezing and cause damages.
Warnings for energy
Refrigerating appliances might not operate consistently (possibility of defrosting of contents
or temperature becoming too warm in the frozen food compartment) when used for an
extended period below the cold end of the range of temperatures for which the refrigerating
appliance is designed.
Effervescent drinks should not be stored in food freezer compartments or cabinets or in low-
temperature compartments.
Do not exceed the storage time(s) recommended by the food manufacturers for any kind of
food and particularly for commercially quick-frozen food in food-freezer and frozen-food
storage compartments or cabinets.
Precautions are necessary to prevent an undue rise in the temperature of the frozen food
while defrosting the refrigerating appliance, such as wrapping the frozen food in several
layers of newspaper.
A rise in temperature of the frozen food during manual defrosting, maintenance or cleaning,
could shorten the storage life.
For doors or lids fitted with locks and keys, the keys be kept out of the reach of children and
not in the vicinity of the refrigerating appliance in order to prevent children from being
locked inside.

The picture above is only for reference and may differ to the actual product.
OVERVIEW
LED light
Shelf
Door tray
Fruit and
vegetables
compartment
Door tray
Shelf
Deodoriser
Temperature
control
Damper
adjustment
slider

Refrigerating chamber
•The refrigerating chamber is suitable for storage of a variety of fruits, vegetables,
beverages and other food consumed in the short term.
•Recently cooked foods shall not be put in the refrigerating chamber until cooled to
room temperature.
•Foods are recommended to be sealed before placing in the refrigerator.
•The adjustable shelves can be repositioned up or down for ideal configuration.
•For better use of the refrigerator, it is recommended to push the damper adjusting
slider to its top position; if it is not enough cool in the refrigerator chamber, check the
slider position.
Freezing chamber
•The low temperature freezing chamber may keep food fresh for a longer time and is
mainly used to store frozen foods and making ice.
•The freezing chamber is suitable for storage of meat, fish, rice balls and other foods
not to be consumed in short term.
•Chunks of meat are preferably to be divided into small pieces for quick freezing and
easy access. Food must be consumed within the shelf time.

Placement
•Before use, remove all packing materials, including bottom cushions, foam pads and
tapes inside of the refrigerator; tear off the protective film on the doors and the
refrigerator body.
•Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or
watery places to prevent rust or prevent reducing the insulating effect.
•Do not spray or wash the refrigerator; do not put the refrigerator in moist places easy
to be splashed with water so as not to affect the electrical insulation properties of the
refrigerator.
•The refrigerator should be placed in a well-ventilated indoor place; the ground shall
be flat and sturdy (rotate left or right to adjust the wheel for levelling if unstable).
•The top space of the refrigerator shall be greater than 30cm and the refrigerator
should be placed against a wall with a free distance more than 10cm to facilitate
heat dissipation.
Precautions before installation:
Before installation or adjusting of accessories, ensure that the refrigerator is disconnected
from power.
Precautions shall be taken to prevent fall of the handle from causing any personal injury.
Levelling Feet
Adjusting procedures:
•Turn the feet clockwise to raise the
refrigerator.
•Turn the feet counter-clockwise to
lower the refrigerator.
•Adjust the right and left feet based
on the procedures above to a
horizontal level.
The picture shown is only for reference.
The actual configuration will depend on
the physical product or statement by the distributor.
BEFORE FIRST USE

Starting
•Before initial start, keep the refrigerator still for two hours
before connecting it to a power supply.
•Before putting any fresh or frozen foods, the refrigerator
shall have run for 2-3 hours or for above 4 hours in
summer when the ambient temperature is high.
•Spare enough space for convenient opening of the doors
and shelves.
Energy saving tips
•The appliance should be in the coolest area of the room, away from heat producing
appliances or heating ducts and out of the direct sunlight.
•Let hot foods cool to room temperature before placing in the appliance. Overloading
the appliance forces the compressor to run longer. Foods that freeze too slowly may
lose quality or spoil.
•Be sure to wrap foods properly and wipe containers dry before placing them in the
appliance. This cuts down on frost build-up inside the appliance.
•The appliance storage bin should not be lined with aluminium foil, wax paper or
paper towelling. Liners interfere with cold air circulation, making the appliance less
efficient.
•Organise and label food to reduce door openings and extended searches. Remove as
many items as needed at one time and close the door as soon as possible.
OPERATION
WARNING: The appliance shall run continuously once it is started.
Generally, the operation of the appliance shall not be interrupted;
otherwise the service life may be impaired.

Temperature-control knob
A Setting button
1 Temp 1 (Cold) 3 Temp 3 (Coldest)
2 Temp 2 (Mid) 4 “Super cool” mode
FUNCTIONS
4
3
2
1
A
Note:
The image above is only for reference and the actual product may differ.

Display
When powering on the refrigerator for the first time, the display screen will light up fully for 3
seconds, then run according at setting 3.
Temperature setting
Each time the temperature setting button (A) is pressed once, the temperature setting
changes one time. After the temperature setting has been completed, the refrigerator will
run according to the set value after 15 seconds.
The shift regulation is:
Lock/Unlock
When the temperature control panel is in a locked state, press and hold the temperature
setting key for 3 seconds to unlock the panel. All LEDs will blink for 2 seconds when panel is
unlocked. When the temperature control panel is in the unlocked state, if there is no
operation on control panel within 15 seconds, it will enter the locked state automatically.
Damper adjusting slider
The temperature inside the freezer can be adjusted by changing the position of the damper
slider. The initial position of the damper slider is at position A. If a lower temperature inside
the freezer is required, you can adjust the damper slider from the position A to the left side.
For better use of the refrigerator, it is recommended to keep the damper slider at initial the
position.
Setting 1 Setting 2 Setting 3 Setting 4
Coldest
Max setting position
Damper slide
A
Cold

Overall cleaning
•Ensure dust behind the refrigerator and on the ground is cleaned regularly to improve
the cooling effect and save energy consumption.
•Check the door gasket regularly to make sure there is no debris. Clean the door gasket
with a soft cloth dampened with soapy water or diluted detergent.
•The interior of the refrigerator should be cleaned regularly to avoid odour.
•Turn off the power before cleaning interior, remove all foods, drinks, shelves, drawers,
etc.
•Use a soft cloth or sponge to clean the inside of the refrigerator, with two tablespoons
of baking soda and a quart of warm water, then rinse with water and wipe clean. After
cleaning, open the door and let it dry naturally before turning on the power.
•For areas that are difficult to clean in the refrigerator (such as narrow gaps or corners), it
is recommended to wipe them regularly with a soft rag, soft brush, etc. and when
necessary, use auxiliary tools (such as thin sticks) to ensure no contaminants or bacteria
accumulates in these areas.
•Do not use soap, detergent, scrub powder, spray cleaner, etc., as these may cause
odours in the interior of the refrigerator or contaminated food.
•Clean the bottle frame, shelves and drawers with a soft cloth dampened with soapy
water or diluted detergent. Dry with a soft cloth or dry naturally. Wipe the outer surface
of the refrigerator with a soft cloth dampened with soapy water, detergent, etc. then
wipe dry.
•Do not use hard brushes, clean steel balls, wire brushes, abrasives
(such as toothpastes), organic solvents (such as alcohol, acetone,
banana oil, etc.), boiling water, acid or alkaline items, which may
damage the fridge surface and interior. Boiling water and organic
solvents such as benzene may deform or damage plastic parts.
•Do not rinse directly with water or other liquids during cleaning to
avoid short circuits or affect electrical insulation after immersion.
CLEANING & CARE
WARNING: Please unplug the refrigerator before defrosting and
cleaning.

Cleaning the glass shelf
•Lift the front of glass shelf and then remove.
•Clean as necessary.
•Replace back into the refrigerator, positioning the
back first and then lowering the front (the reverse
motion of removing).
Defrosting
The refrigerator is made based on the air-cooling principle and thus has automatic
defrosting function. Frost formed due to change of season or temperature may also be
manually removed by disconnection of the appliance from power supply or by wiping with a
dry towel.
Changing the Light
Any replacement or maintenance of the LED lamps must be made by Kogan.com, an
authorised service agent or similar qualified person. Do not repair or replace LED lamps
yourself.
Out of operation
•Power failure: In case of power failure, even if it is in the summer, foods inside the
appliance can be kept for several hours; during the power failure, the times of door
opening shall be reduced and no more fresh food shall be put into the appliance.
•Long-time non-use:The appliance shall be unplugged and then cleaned. The doors
should be left open to prevent odour.
•Moving: Before the refrigerator is moved, take all objects inside out, fix the glass
partitions, vegetable holder, freezing chamber drawers etc. with tape and tighten the
levelling feet; close the doors and fix them with tape. During moving, the appliance
shall not be laid upside down or horizontally or be vibrated; the inclination during
movement shall be no more than 45°.

If you are experiencing difficulty with the appliance, refer to the below common
troubleshooting fixes first. If problems persist, contact help.Kogan.com for further
assistance.
Issue Solution
Failed operation
•Check whether the appliance is connected to power or whether the
plug is in well contact.
•Check whether the voltage is too low.
•Check whether there is a power failure or partial circuits have tripped.
Odour
•Odorous foods shall be tightly wrapped.
•Check whether there is any rotten food.
•Clean the inside of the refrigerator.
The compressor
is running for a
long time.
•Long operation of the refrigerator is normal in summer when the
ambient temperature is high.
•It is not recommended to overfill the refrigerator.
•Food shall get cool before being put into the appliance.
•The doors are opened too frequently.
Indicator
settings 3 and 4
are illuminated.
•Refrigerator temperature sensor failure. Contact help.Kogan.com for
assistance.
Indicator
settings 2 and 4
are illuminated.
•Freezer defrost sensor failure. Contact help.Kogan.com for assistance.
Indicator
settings 1 and 4
are illuminated.
•Ambient temperature sensor failure. Contact help.Kogan.com for
assistance.
Light fails to
turn on.
•Check whether the refrigerator is connected to a power supply and
whether the illuminating light is damaged.
Doors cannot
be properly
closed.
•The door is stuck due to food in the refrigerator. Move the food away
from the door openings.
•The refrigerator is tilted. Ensure the fridge is installed on a flat surface
and adjust the levelling foot.
TROUBLESHOOTING

Loud noise
•Check whether the floor is level and whether the refrigerator is placed
stably.
•Check whether accessories are placed at proper locations.
Door seal fails
to be tight.
•Remove foreign matter on the door seal.
•Heat the door seal and then cool it to restore (or blow it with an
electrical drier or use a hot towel for heating).
Water pan
overflows.
•There is too much food in the chamber or food stored contains too
much water resulting in heavy defrosting.
•The doors are not closed properly resulting in frosting due to entry of
air and increased water due to defrosting.
Hot housing
•Heat dissipation of the built-in condenser via the housing, which is
normal.
•When housing becomes hot due to high ambient temperature or the
overfilling of the refrigerator, it is recommended to provide sound
ventilation to facilitate heat dissipation.
Surface
condensation
•Condensation on the exterior surface and door seals of the refrigerator
is normal when the ambient humidity is too high. Wipe the
condensation off with a clean towel.
Abnormal noise
•Buzz: The compressor may produce buzzes during operation and the
buzzes are loud particularly upon start or stop. This is normal.
•Creaking: Refrigerant flowing inside of the appliance may produce
creaking. This is normal.
Disposal
This marking indicates that this appliance should not be disposed with other
household wastes. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources.

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
