Kogan SMARTERHOME KASMSWTH1GA User manual

KOGAN SMARTERHOME™
SMART TOUCH LIGHT SWITCH
(1, 2 & 3 GANG)
KASMSWTH1GA, KASMSWTH2GA & KASMSWTH3GA

Read and follow the installation instructions provided in the user guide before installation
and operation. Retain this user guide for future reference.
Electrical Safety:
• This product must be installed by a licensed electrician or qualified trade professional.
• Before installing or handling the smart light switch, ensure that the power supply to the
switch is turned off.
• Do not touch the electrical terminals of the switch with bare hands or conductive
objects.
• Ensure that the electrical wiring is properly grounded and meets local electrical codes
and regulations.
• Avoid exposing the smart light switch to water or other liquids to prevent electrical
shock or damage.
Installation and Use:
• Ensure that the smart light switch is securely mounted to the wall or junction box to
prevent it from falling or becoming loose.
• Avoid using the smart light switch in environments with extreme temperatures, high
humidity, or excessive dust.
• Keep the smart light switch away from direct sunlight or heat sources that may
damage the device.
• Use a soft, dry cloth to clean the surface of the smart light switch. Avoid using abrasive
or corrosive cleaning agents that may damage the device.
• Do not disassemble the smart light switch or attempt to repair it yourself. Contact
help.Kogan.com for support.
SAFETY & WARNINGS

1 gang light switch
Light switch
Operation
Methods
Indicator status
ON/OFF
Short press any
button
The indicator light turns on
and off according to the load
status.
Network pairing
mode
Long press (5 sec.)
the first button
The first button indicator will
flash quickly.
The indicator will turn off to
indicate successfully
connected to network.
OVERVIEW
First button
Light 1
Button indicator

2 gang light switch
3 gang light switch
Light 1
Light 2
First button
Light 1
Light 2
Light 3
First button

• This product must be installed by a licensed electrician or qualified trade professional.
• Before installation, ensure that the power supply to the switch is turned off.
• The installation location of the light switch must have a neutral wire. Where multiple
neutral wires are present, ensure that it is the same neutral wire as the light intended to
be controlled.
• When installing, the junction box should not be greater than: 71x45x26mm.
• Confirm all the wiring is correct before turning on the main power to avoid hazards.
Wiring Diagram
Follow the wiring diagram below to connect the wiring to the light switch. Note: The
diagram is for a 3 gang switch, 1 & 2 gang models will have the respective number of lights
to wire.
INSTALLATION
Light 3
Light 2
Light 1
Live wire
Neutral wire
Ground wire
Notes:
• This product must be protected by a 10A circuit breaker.
• The switched circuits cannot be used in SELV/PELV circuits.

Installing the Switch
1. Separate the switch face from the switch body using a flat screwdriver.
2. Attach the switch body to the wall junction box using the supplied screws.
3. Attach the wall switch face to the switch body.
4. Ensure the wiring has been connected correctly before turning the power back on.
Switch
face
Switch
body
Junction
box

Install App
Download the “Kogan SmarterHome” app from the Play Store (Android) or App Store (iOS).
Play Store (Android)
App Store (iOS)
To register:
1. If you already have a SmarterHome account, select ‘Log In’. To register a new
account, select ‘Sign Up’.
2. The system will automatically recognise your country. If needed, you can manually
select your country from the drop-down box. Enter your email address and tap
‘Get Verification Code’ to continue.
3. A 6-digit code will be sent to the submitted email address. Enter this code before
the one-minute timer expires.
4. Continue to the next page and complete your SmarterHome profile.
CONNECT TO SMARTERHOME™ APP

Set device in pairing mode
When the device is first turned on, it may automatically enter pairing mode (the indicator on
the first button is flashing rapidly).
If not automatically in pairing mode when powered on, you can manually set the device in
pairing mode by pressing and holding the first button for 5 seconds until the button
indicator begins flashing rapidly.
Add device through network
1. Once registered, tap “Add Device” on the app’s home page, or the “+” in the upper
right corner, to add a new device through the network.
2. Select the product type from the list of options in the app (Electrical > Smart
Touch Light Switch Gang).
3. Enter your Wi-Fi details. It is important that your SmarterHome™ device and the
app are connected to the same Wi-Fi network during setup.
Notes:
• The device and the app have to use the same Wi-Fi network.
• The device is only compatible with 2.4Ghz networks.
• Depending on the product, Steps 3 and 4 may be in opposite order.

4. Ensure that the device is in pairing mode, with the indicator on the first button
flashing rapidly, select “Confirm indicator rapidly blink” and tap “Next”.
5. The device will commence the pairing process and connect to the app. Ensure
your Wi-Fi router, mobile phone, and the SmarterHome™ device are kept close
until connection is complete.
6. After successfully being added, you will have the option to rename the device and
assign it to a location. It will now be listed on the app’s home page. Tap the device
listing to enter its control page.
Note:
Once connected, you can select Create Scene from the “+” in the upper right
corner (or from the Scene tab) to group connected SmarterHome™ products
and automate their functions.

Dimension
116 x 70 x 35mm
In-wall Size
71x45x26mm (LxWxH)
Output
Incandescent lamp 300W/gang.max
Fluorescent lamp 150W/gang.max
Input
AC 100V-240V 50/60Hz
Wireless Protocol
Wi-Fi & Bluetooth
Transmit Power
19dBm
Receiving Sensitivity
-100dBm
Communication Distance
>300m (Open area)
Control Method
Manual control, App control
SPECIFICATIONS

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
