KOHLA HAPPY EMOTION LIGHT User manual

INFORMATION CARRYING SYSTEM
CHILD SEAT
ROOF
EN
FEATURES
• Removable sun or rain roof
• Soft chin pad, removable
• Spacious 18ltr large bottom compartment
• Height adjustable seat
• Very stable aluminium frame
• High quality backpack carrying system
• Stable handlebar
• Padded hip belt with pocket
• Integrated rear view mirror
• Adjustable leg straps
• Reective stripes
• Optional rain cover
• Usable up to approx. 18 kg
• Weight: approx. 2100 g
Before you start tting,
loosen all the straps.
Open the straps of the child
seat.
You can hang the sun canopy
in the place provided for it.
You can open the side wing
so that the child can sit in
comfortably.
Fix the side wings. Adjust the footrests to the
appropriate height using the
carabiner.
There are three heights for
the footrests.
To adjust the child seat, pull
up on the adjustment loop or
loosen it down.
Push the roof all the way
down so that it cannot slip ...
Put the child inside and
fasten the child harness.
... and x it with the straps.
Next, tighten the straps so
that your child sits well.
Close the waist belt so that it
sits well on your mid-pelvic
bone and the main weight is
on your hip.
Now tighten the shoulder
straps.
Also tighten the load straps
at the top so that everything
ts well.
SECURITY INFORMATION
• Attention: The children carrier is for infants,
who are not yet able to hold themselves
upright and sit sit independently.
The maximum payload is 18 kg including
luggage.
• The children carrier is self-standing. But
please make sure that you place it on a even
surface. Do not leave your child unattended
in the carrier.
• Before putting your child in the carrier, check
that all the straps are correctly xed and
that your child is in a comfortable sitting. In
general, ONLY transport the child with the
seatbelt fastened!
• Take breaks! Sitting for long periods of time
can affect blood circulation, especially in
the legs, and can lead to frostbite or damage
in cold temperatures.
• Make sure you have suitable weather
protection and clothing. Because of the
restricted movement, your child will freeze
faster than you. Make sure your child is
protected from the sun.
WARNING
• Only children may be carried in the KOHLA
child carrier by adults.
• Before each use, check the carrier for
damage and never use it if it is damaged.
• Pay careful attention to the child‘s legs and
head of the child. It is easy for objects to
come into contact with them and cause
injury.
• Take extra care when leaning forward and
when picking up and putting down the
carrier.
• The Kohla child carrier is only suitable for
leisure activities, but not for sports such as
cycling, skiing or similar.
• Failure to observe these warnings may result
in serious injury or even death to the child.
IBEX Sportartikel GmbH | Hans-Maier-Straße 21, A-6020 Innsbruck | www.kohla.at
follow us Hotline [phone]
HAPPY EMOTION LIGHT
small child
bigger child
CHILDREN CARRIER

PICKING UP THE CHILD CARRIER
PUTTING DOWN THE CHILD CARRIER
EN
Fold the stand bar back-
wards, as in the next picture.
Note: If you are hiking alone,
leave the carrier in the
„standing“ position to ensure
easy picking up and putting
down.
Hold the stretcher rmly by
the main handle.
Slip one arm into the
shoulder strap and take the
weight on that side.
Fix all the straps again and
then you‘re ready to go.
For putting down, take the
main handle in your hand.
Thread one arm out of the
strap.
Put down the carrier carfully
and please make sure
that you place it on a even
surface.
Note: If you are hiking alone,
leave the carrier in the
„standing“ position to ensure
easy picking up and putting
down.
Note: If the stand bar is
folded in, ask someone to
unfold the stand bar before
parking.
