Installation and Care Guide
Amplifier
K-1263840
Français, page ″Français-1″
Español, página ″Español-1″
1298482-2-C

Specifications
Ambient Temperature Max 104°F (40°C)
Maximum Relative Humidity 90% non-condensing
Electrical Service 120 VAC, 50/60 Hz, 1.3 A Max
Power Cable Length 36″(914 mm)
Data Cable Length 6’ (1.83 m)
Output Power 90 Watts total
Frequency Response 20 Hz - 18 kHz +/- 3dB
Signal/Noise Ratio >75 dB
Total Harmonic Distortion <0.1% at 1 Watt, <1% at full output
power
Tools and Materials
Before you Begin
WARNING: Risk of electric shock. Disconnect power before
servicing.
CAUTION: Risk of product damage. The amplifier is rated to
operate in temperatures up to 104°F (40°C). Do not install near heat
sources (such as radiators or heat registers) or in any location where
the temperature may exceed 104°F (40°C).
CAUTION: Risk of product damage. A network cable is provided
with this product. For all bath installations with combined user
experiences, you must use the supplied cable in place of the cable
shipped with the bath. Failure to do so may cause irreparable
damage to the amplifier.
• Wire Cutter/Stripper
Plus:
1298482-2-C 2 Kohler Co.

Before you Begin (cont.)
NOTICE: This product is not water-resistant. Do not install in a
location where excessive moisture, high humidity levels, or
condensation are present.
NOTICE: Follow all electrical and building codes.
NOTICE: Provide unrestricted service access to the amplifier.
NOTICE: Provide a minimum of 6″(152 mm) of space around the
amplifier for proper air flow.
Determine amplifier and speaker locations before beginning
installation. Test the BLUETOOTH
®
range between the amplifier
and your wireless device when determining amplifier location.
Under normal conditions, the maximum range is 30’ (9.14 m).
The amplifier can be mounted in any orientation. Use the
supplied brackets or rubber feet to accommodate your mounting
configuration.
Locate the amplifier within close proximity to a 15 A 120 V
electrical outlet. Install a GFCI or RCD electrical outlet within the
stud framing and within 24″(610 mm) of the amplifier.
A qualified electrician should install an electrical outlet.
Install the electrical outlet prior to installing the amplifier.
This amplifier complies with CE, FCC, IC, and RoHS.
Kohler Co. 3 1298482-2-C

1. Preparation
NOTE: To play your personal music files, a wireless BLUETOOTH
device or a device with a 3.5 mm stereo cable connection is required.
Plan the location of the amplifier to allow access to the front and
back ports.
Allow adequate reach for wires between the bath and the
amplifier.
Make sure the status LED will be visible after installation.
NOTICE: The circular auxiliary-in port is not an Ethernet
communication port. Do not connect an Ethernet network to the
auxiliary-in port. Use the auxiliary-in port only for a standard
accessory.
Status LED
AC Power Supply
User Interface
Amplifier
Auxiliary-In Cable
Chromatherapy Cable In
Transducers
1298482-2-C 4 Kohler Co.

2. Installation
CAUTION: Risk of product damage. The amplifier is rated to
operate in temperatures up to 104°F (40°C). Do not install near heat
sources (such as radiators or heat registers) or in any location where
the temperature may exceed 104°F (40°C).
NOTICE: Mount the amplifier in a dry location, and provide a
minimum of 6″(152 mm) of space for proper air flow.
NOTE: Choose the mounting location to best suit the location of the
incoming transducer wires and other cables.
NOTE: Make sure the status LED will be visible after installation.
Mounting Options
Wall-mount: Secure the amplifier in an upright position using the
mounting brackets, anchors, and short screws provided.
Cabinet-mount: Secure the amplifier in an upright position using
the mounting brackets and short screws provided.
Cabinet-Mount
Under-MountSurface-Mount
Wall-Mount
Kohler Co. 5 1298482-2-C

Installation (cont.)
Surface-mount: Attach the four rubber feet to the underside of
the amplifier to protect against scratching your shelf or
countertop surface.
Under-mount: Secure the amplifier in position using the
mounting brackets and short screws provided.
Bracket Installation
Position the amplifier with attached brackets in the desired
location.
Mark the bracket hole locations with a pencil.
Drill pilot holes or insert anchors as needed at the marked
locations.
Secure the brackets using the four screws provided.
1298482-2-C 6 Kohler Co.

3. Amplifier Connection
CAUTION: Risk of product damage. Use the network cable
provided with the amplifier for installation with baths having more
than one user experience (whirlpool, vibracoustic, air bath, etc.). For
these installations, remove and discard the network cable assembled
to the bath, and replace it with the new network cable. Failure to
replace the network cable may cause irreparable damage to the
amplifier.
IMPORTANT! A network cable is provided with this product.
Depending upon the type of bath product being installed, use this
cable to connect the amplifier and user interface, or to connect the
bath and user interface. Refer to the bath Homeowners Guide or the
bath product page on kohler.com to determine the bath type being
installed.
NOTE: The transducer terminals and wires are numbered to
identify the correct connections. When required, the amplifier can be
removed to aid in the wire connection process.
NOTICE: The circular auxiliary-in port is not an Ethernet
communication port. Do not connect an Ethernet network to the
auxiliary-in port. Use the auxiliary-in port only for a standard
accessory.
Disconnect the power from the amplifier.
If equipped, connect the chromatherapy connector from the bath
to the chromatherapy connection on the amplifier.
Power
Cable
Transducer
Terminals
User Interface
Connection
BACKFRONT
Auxiliary-In
Port
Chromatherapy
Connection
Status LED
Kohler Co. 7 1298482-2-C

Amplifier Connection (cont.)
Connect the transducer wires to the transducer terminals on the
amplifier. The white wires with black stripes are connected to the
positive (+) terminals, and the solid white wires are connected to
the negative (-) terminals.
Connect the clear connector of the user interface cable to the
amplifier user interface connection.
If used, connect the auxiliary-in cable to the auxiliary-in port on
the amplifier.
Reconnect the power to the amplifier.
Verify that the status LED turns on.
1298482-2-C 8 Kohler Co.

4. Operation
When using the auxiliary-in, set your music device to midrange
volume after connecting to the amplifier, but before sending an
audio signal from the device.
To listen to a BLUETOOTH source, go to the AUX screen of the
user interface. Activate by pressing the AUX icon.
A wireless BLUETOOTH source will override an auxiliary-in
source.
When listening to an auxiliary-in source, a tone will be heard
when a BLUETOOTH device is paired with the amplifier. The
tone indicates that the auxiliary-in source is no longer active.
To listen to an auxiliary-in source, the BLUETOOTH source must
be un-paired from the amplifier.
When listening to a BLUETOOTH device which is paired with the
amplifier, a tone will be heard when the BLUETOOTH device has
unpaired from the amplifier and is no longer active.
Status LED Light
Yellow blink = Amplifier error: Contact the Customer Care
Center.
Blue blink = Stand-by mode: Normal operation - No
BLUETOOTH connection.
Blue solid = Normal operation: BLUETOOTH receiver is paired
with a device.
Green blink = User interface error - For example, loose or
disconnected cable.
Power
Cable
Transducer
Terminals
User Interface
Connection
BACKFRONT
Auxiliary-In
Port
Chromatherapy
Connection
Status LED
Kohler Co. 9 1298482-2-C

Operation (cont.)
3.5 mm Stereo Input
A wired audio device can be connected to the auxiliary-in port on
the amplifier.
Audio input may be slightly delayed when a device is initially
connected.
Wireless Input
Once a BLUETOOTH device is paired, the LED will be solid blue
and the audio input will fade-in.
On the BLUETOOTH user device, the amplifier will display as
″VibrAcoustic.″
If a BLUETOOTH pin number is required, use ″0000.″
NOTE: For more information on system operation, refer to the
Homeowners Guide.
Troubleshooting
IMPORTANT! Turn off the power supply before performing any
maintenance.
NOTE: For service parts information, visit your product page at
kohler.com/serviceparts.
This troubleshooting guide is for general aid only. For service and
installation issues or concerns, call 1-800-4KOHLER.
Troubleshooting Table
Symptoms Probable Cause Recommended Action
1. One or more
transducers do
not produce
sound.
A. Transducer wire is
not connected
properly.
A. Make sure the wires
are properly
connected to the
amplifier. Each
transducer has a
white with black
wire which is the
positive (+) lead, and
a solid white wire
which is the negative
(-) lead.
1298482-2-C 10 Kohler Co.

Troubleshooting (cont.)
Troubleshooting Table
Symptoms Probable Cause Recommended Action
B. Damaged
transducer wires. B. The bath has six transducers with
cables that are
permanently
attached. Inspect the
six transducers for
frayed, cut, or loose
wires. Contact the
Customer Care
Center for assistance.
C. Transducer is
missing, loose, or
not attached.
C. If any one of the six
transducers is
missing, loose, or not
attached to the bath,
contact the Customer
Care Center for
assistance.
2. The music
stops even
though a song
is properly
selected, and
the status
indicator light
is blinking
yellow.
A. Thermal shut
down. A. Shut down the system for 1 hour to
allow the unit to
cool. Make sure the
area where the unit
is installed does not
exceed 104°F (40°C).
Restart the system.
The LED status
indicator should be
solid blue.
B. Amplifier error. B. Contact the
Customer Care
Center if the
amplifier LED status
indicator is blinking
yellow after the
system has been
restarted.
3. The status LED
is not
illuminated.
A. Power supply is
not plugged into
the outlet.
A. Plug the power
supply into the
outlet.
B. Power supply
connection to the
amplifier is loose
or disconnected.
B. Check power supply
connection to the
amplifier and
reconnect if needed.
Kohler Co. 11 1298482-2-C

Troubleshooting (cont.)
Troubleshooting Table
Symptoms Probable Cause Recommended Action
C. The outlet is not
powered. C. Make sure there is power to the
electrical outlet.
D. Circuit breaker has
been tripped. D. Reset the circuit breaker.
4. No sound
plays through
the
transducers.
A. The song is
paused. A. Make sure a song is playing. If the song
is paused, press the
resume feature to
continue playback.
B. Auxiliary-in or
BLUETOOTH
source is not
connected.
B. Make sure a song is
playing from the
auxiliary-in or
BLUETOOTH source.
C. Vibracoustic
experience has not
been selected on
the user interface.
C. Make sure the
Vibracoustic
experience has been
selected.
D. The amplifier has
been muted. D. Go to the intensity screen on the user
interface and unmute
the amplifier.
E. The volume is too
low. E. Make sure the volume is high
enough.
5. The amplifier
is not
connecting to a
BLUETOOTH
device.
A. The BLUETOOTH
device is not
within range.
A. Make sure the
BLUETOOTH device
is within range of the
amplifier. Under
normal conditions,
the maximum range
is 30’ (9.14 m).
B. The BLUETOOTH
device is not
paired with the
amplifier.
B. Pair the
BLUETOOTH device
with the amplifier
according to the
pairing instructions
for the BLUETOOTH
device.
1298482-2-C 12 Kohler Co.

Troubleshooting (cont.)
Troubleshooting Table
Symptoms Probable Cause Recommended Action
6. The status LED
is blue, but the
audio signal is
intermittent.
A. The BLUETOOTH
device signal is
weak.
A. Move the
BLUETOOTH device
closer to the
amplifier location.
Under normal
conditions, the
maximum range is
30’ (9.14 m).
Compliance
Contains: Kohler Company, Model: 1263840, FCC ID: N82KOHLER017,
IC: 4554A-KOHLER017, CE: CE2200
FCC Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
The circular auxiliary-in port is not an Ethernet communication port.
Do not connect it to an Ethernet network.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Kohler Co. 13 1298482-2-C

Compliance (cont.)
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
Industry Canada Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that
may cause undesired operation of the device.
CAN ICES-3(B)/NMB-3(B)
CE2200
FCC and IC Radiation Exposure Statement for Mobile Devices
This equipment complies with FCC and IC radiation exposure limits
set forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 7-7/8″(200 mm)
between the radiator (amplifier) and your body. The transmitter must
not be co-located or operating in conjunction with any other antenna
or transmitter.
Range and Function Disclaimer
BLUETOOTH
®
is the name for a short-range radio frequency (RF)
technology that operates at 2.4 GHz. The effective range of most
BLUETOOTH mobile devices is 10 meters. BLUETOOTH is designed
for very low power use. The compatibility of the BLUETOOTH
amplifier interface to mobile/portable devices differs according to the
various individual devices and, in particular, may vary with different
software versions for a device. The normal mobile device
BLUETOOTH range can be up to 10 meters, however, placement of
your mobile device and the BLUETOOTH amplifier’s installation
environment will impact your reception range.
Water and walls can act as blocking agents to the BLUETOOTH signal
that your mobile device is using to broadcast to your BLUETOOTH
amplifier. Therefore, selecting an installation location that removes
1298482-2-C 14 Kohler Co.

Range and Function Disclaimer (cont.)
these range blocking obstacles will increase the effective range and
performance of your BLUETOOTH amplifier.
You can test your BLUETOOTH reception by performing simple range
tests using your mobile device prior to performing a permanent
installation. The best way to make use of the short BLUETOOTH range
is to make sure your BLUETOOTH amplifier is as close to the
BLUETOOTH transmitter (mobile phone, tablet, etc.) as possible. The
less distance between the two devices, the greater will be the reliability
of your BLUETOOTH audio signal, and the less distance means less
obstacles in the medium through which the transmission is passing, so
there is a reduced chance of audio signal loss.
The compatibility of the BLUETOOTH amplifier to mobile/portable
devices differs according to the various individual devices and, in
particular, may vary with different software versions for a device. All
functions are based on industry-wide communications standards.
Compatibility between the BLUETOOTH amplifier and mobile device
is therefore largely dependent upon the software version of the mobile
device. Other factors (e.g. installation location, walls, distance) mean
that in individual cases, sporadic impairment of functions may occur in
devices that otherwise function reliably. Not all functions are
supported in all countries.
Because of these reasons, Kohler Co. can assume no guarantee for the
unlimited compatibility and functionality of your mobile device in
conjunction with the BLUETOOTH amplifier.
_________________________________________________________________
The BLUETOOTH
®
word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by Kohler
Co. approved suppliers is under license. Other trademarks and trade
names are those of their respective owners.
Warranty
ONE-YEAR LIMITED WARRANTY
KOHLER plumbing products are warranted to be free of defects in
material and workmanship for one year from date of installation.
Kohler Co. will, at its election, repair, replace or make appropriate
adjustment where Kohler Co. inspection discloses any such defects
occurring in normal usage within one (1) year after installation. Kohler
Co. is not responsible for removal or installation costs. Use of in-tank
toilet cleaners will void the warranty.
To obtain warranty service contact Kohler Co. either through your
Kohler Co. 15 1298482-2-C

Warranty (cont.)
Dealer, Plumbing Contractor, Home Center or E-tailer, or by writing
Kohler Co., Attn.: Customer Care Center, 444 Highland Drive, Kohler,
WI 53044, USA, or by calling 1-800-4-KOHLER (1-800-456-4537) from
within the USA and Canada, and 001-800-456-4537 from within Mexico,
or visit www.kohler.com within the USA, www.ca.kohler.com from
within Canada, or www.mx.kohler.com in Mexico.
IMPLIED WARRANTIES INCLUDING THAT OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE EXPRESSLY LIMITED IN DURATION TO THE
DURATION OF THIS WARRANTY. KOHLER CO. AND/OR
SELLER DISCLAIM ANY LIABILITY FOR SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES. Some states/provinces do not
allow limitations on how long an implied warranty lasts, or the
exclusion or limitation of special, incidental or consequential damages,
so these limitations and exclusions may not apply to you. This
warranty gives you specific legal rights. You may also have other
rights which vary from state/province to state/province.
This is Kohler Co.’s exclusive written warranty.
1298482-2-C 16 Kohler Co.

Guide d’installation et d’entretien
Amplificateur
Spécifications
Température ambiante Max 104°F (40°C)
Humidité relative maximale 90% sans condensation
Service électrique 120 VCA, 50/60 Hz, 1,3 A Max
Longueur de câble
d’alimentation 36″(914 mm)
Longueur du câble de
données 6’ (1,83 m)
Puissance de sortie 90 Watts au total
Réponse en fréquence 20 Hz - 18 kHz +/- 3 dB
Rapport signal/bruit >75 dB
Distorsion harmonique totale <0,1% à 1 watt, < 1% à la puissance de
sortie intégrale
Outils et matériel
Avant de commencer
AVERTISSEMENT: Risque de choc électrique. Déconnecter
l’alimentation électrique avant d’effectuer un entretien.
ATTENTION: Risque d’endommagement du produit.
L’amplificateur est destiné à fonctionner à des températures de
• Coupe-fils/
Pince à dénuder
Plus:
Kohler Co. Français-1 1298482-2-C

Avant de commencer (cont.)
104°F (40°C) maximum. Ne pas installer à proximité de sources de
chaleur (comme des radiateurs ou des registres de chaleur), ni dans
des endroits où la température pourrait dépasser 104°F (40°C).
ATTENTION: Risque d’endommagement du produit. Un câble de
réseau est fourni avec ce produit. Pour toutes les installations de
baignoire avec effets combinés pour l’utilisateur, le câble fourni doit
être utilisé au lieu du câble expédié avec la baignoire. Un non
respect de cette directive pourrait créer des dommages irréparables
pour l’amplificateur.
AVIS: Ce produit n’est pas hydrorésistant. Ne pas installer dans
un endroit avec une humidité excessive, avec des niveaux de haute
humidité ou avec condensation.
AVIS: Respecter tous les codes électriques et codes du bâtiment
locaux.
AVIS: Fournir un accès libre à l’amplificateur aux fins d’entretien.
AVIS: Fournir un minimum de 6″(152 mm) d’espace autour de
l’amplificateur pour assurer une circulation d’air appropriée.
Déterminer les emplacements de l’amplificateur et des
haut-parleurs avant de commencer l’installation. Tester la portée
de l’appareil BLUETOOTH
®
entre l’amplificateur et le dispositif
sans fil lors de l’établissement de l’emplacement de
l’amplificateur. Dans des conditions normales, la portée maximale
est de 30’ (9,14 m).
L’amplificateur peut être monté dans n’importe quelle orientation.
Utiliser les supports ou les pieds en caoutchouc fournis pour
adapter la configuration de montage.
Positionner l’amplificateur à proximité d’une sortie électrique de
15 A 120 V. Installer une prise électrique pour disjoncteur de fuite
de terre (GFCI) ou dispositif de protection à courant résiduel
(RCD) dans les limites de l’ossature et dans une distance de 24″
(610 mm) de l’amplificateur.
Une prise électrique doit être installée par un électricien qualifié.
Installer la prise électrique avant d’installer l’amplificateur.
Cet amplificateur est conforme aux normes CE, FCC, IC et RoHS.
1298482-2-C Français-2 Kohler Co.

1. Préparation
REMARQUE: Un dispositif BLUETOOTH sans fil ou un appareil
avec une connexion de câble stéréo de 3,5 mm sont requis pour lire
des fichiers de musique personnels.
Planifier l’emplacement de l’amplificateur de manière à permettre
un accès aux ports avant et arrière.
Laisser un espace d’accès adéquat pour les fils entre la baignoire
et l’amplificateur.
S’assurer que le voyant DEL d’état est visible après l’installation.
AVIS: Le port d’entrée auxiliaire circulaire n’est pas un port de
communication Ethernet. Ne pas connecter de réseau Ethernet au
port d’entrée auxiliaire. Seulement utiliser le port d’entrée auxiliaire
pour un accessoire standard.
DEL d'état
Alimentation
électrique c.a.
Interface utilisateur
Amplificateur
Câble d'entrée auxiliaire
Câble d'entrée de chromathérapie
Transducteurs
Kohler Co. Français-3 1298482-2-C

2. Installation
ATTENTION: Risque d’endommagement du produit.
L’amplificateur est destiné à fonctionner à des températures de
104°F (40°C) maximum. Ne pas installer à proximité de sources de
chaleur (comme des radiateurs ou des registres de chaleur), ni dans
des endroits où la température pourrait dépasser 104°F (40°C).
AVIS: Monter l’amplificateur dans un emplacement sec et fournir
un minimum de 6″(152 mm) d’espace pour assurer un débit d’air
approprié.
REMARQUE: Choisir l’emplacement de fixation pour mieux
l’adapter à l’emplacement des fils d’entrée des transducteurs et
d’autres câbles.
REMARQUE: S’assurer que le voyant DEL d’état est visible après
l’installation.
Options de montage
Montage mural: Sécuriser l’amplificateur dans une position
verticale en utilisant les supports de fixation, les dispositifs
d’ancrage et les vis courtes fournies.
Montage sur
meuble
Montage sous
plan
Montage en
surface
Montage mural
1298482-2-C Français-4 Kohler Co.
