Koldfront KIM210SV User manual

Portable Ice Maker
Owner’s Manual
For more information on other great Koldfront products on the web, go to http://www.edgestar.com
KIM210SV

i
Important Safety Information
Improper handling can cause serious damage to the Koldfront ice maker and/or injury to the user. This ice maker is
designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other use may
invalidate the warranty. Please review the ratings label located on the rear panel of the unit for electrical and other
technical data related to this unit. The unit must be used in a properly grounded wall outlet. Please read and follow the
safety information listed below to reduce the risk of fire, electric shock or injury.
Electrical Safety
xDo not exceed the power outlet ratings.
xIt is recommended that the ice maker be
connected on its own circuit.
xA standard electrical supply (115 V, 60Hz), that is
properly grounded in accordance with the
National Electrical Code and local codes and
ordinances is required.
xUse outlets that cannot be turned off by a switch
or pull chain.
xAlways turn the unit off and unplug it from the
outlet when cleaning.
xUnplug the unit if it is not going to be used for an
extended period of time.
xDo not operate the unit with a power plug that is
missing the ground plug, a damaged cord or a
loose socket.
xBe sure the ice maker is properly grounded.
xNever plug or unplug the unit with wet hands.
xDo not bypass, cut or remove the grounding plug.
xDo not use extension cords or power strips with
this unit. You may need to contact your electrician
if it is necessary to use a longer cord or if you do
not have a grounded outlet. Do not modify the
power cord’s length or share the outlet with other
appliances. If you must use an extension cord,
use No.14AWG minimum size and rated no less
than 1875 watts.
xDo not start or stop the unit by switching the
circuit’s power on and off.
xIf the power cord is damaged, it must be replaced
by the manufacturer or a qualified technician.
xNever repair the unit while it is plugged in.
xImmediately unplug the unit if it makes strange
sounds, emits an odor or smoke comes out of it,
and contact customer service.
xDo not remove any part of the casing unless
instructed by an authorized technician.
xYou should never attempt to repair the unit
yourself.
xContact EdgeStar Support if the unit needs repair
service.
xDo not tip the unit over while it has water in the
reservoir.
General Safety
xUse at least two people to move and install the ice
maker to prevent back and other types of injuries.
xInstall the ice maker in a well ventilated area where
the ambient temperature is above 50°F and below
90°F.
xThis unit is designed to be installed indoors, and
protected from rain, sleet, snow, etc. Do not use
your ice maker outdoors. Place the ice-maker away
from direct sunlight and make sure that there is at
least 4 inches of space between the back of your
unit and wall. Keep a minimum distance of 4 inches
on each side of your unit free.
xThis unit is not intended to be used by children and
should be supervised to ensure that they do not play
with this product.
xNever allow children to crawl inside the ice maker.
xDo not use this appliance near flammable gas or
combustibles, such as gasoline, benzene, thinner,
etc.
xDo not place the unit near heat sources such as
ovens and grills.
xOnly use in an upright position on a flat, level
surface and provide proper ventilation.
xDiscard the first batch of cubes produced by the ice
maker.
xIf the unit has not been used for an extended period,
thoroughly clean it before using it.
xDo not leave any cleaning solutions in or on the unit
xDo not use solvent-based cleaning agents or
abrasive solutions on the interior as they may
transmit taste to the ice cubes and damage the
interior.
xDo not clean the unit with flammable fluids. The
fumes can create a fire hazard or cause an
explosion.
xOther than water do not use other types of liquid to
make ice.
xThis appliance is not intended for use by persons,
including children, with reduced physical, sensory or
mental capabilities, unless they have been given
supervision or instruction concerning the use of the
appliance by the person(s) responsible for their
safety.

Koldfront Portable Ice Maker ii
Table of Contents
IMPORTANT SAFETY INFORMATION.................................................................I
INTRODUCTION ...................................................................................................1
PARTS IDENTIFICATION.....................................................................................2
OUTER VIEW .......................................................................................................2
INSIDE VIEW ........................................................................................................2
BEFORE YOU BEGIN: PREPARING THE ICE MAKER FOR USE ....................3
UNPACKING THE ICE MAKER.................................................................................3
CLEANING THE ICE MAKER ...................................................................................3
INSTALLATION REQUIREMENTS .............................................................................3
Clearance and Environment Requirements..................................................3
Water Requirements .....................................................................................3
Electrical Requirements ................................................................................3
OPERATION..........................................................................................................4
USING YOUR ICE MAKER......................................................................................4
USING THE CONTROL PANEL ................................................................................5
Power ............................................................................................................5
Ice Size Selector ...........................................................................................5
HOW THE PORTABLE ICE MAKER PRODUCES ICE...................................................6
DRAINING THE UNIT..............................................................................................6
NORMAL SOUNDS ................................................................................................6
CLEANING AND MAINTENANCE........................................................................7
TROUBLESHOOTING ..........................................................................................8
SPECIFICATIONS.................................................................................................9
LIMITED WARRANTY.........................................................................................10
This owner’s manual is provided for reference use only. Specifications may
change without prior notice. Refer to the product label on the back of your
ice maker for the latest technical information.

1
Introduction
Thank you for purchasing this Koldfront ice maker. We are glad you chose us.
We believe that your purchase of this product opens a relationship between you
and EdgeStar. We will provide the customer support needed to nurture that
relationship.
This manual contains important information regarding the proper installation, use
and maintenance of your ice maker. Following this manual will ensure that your
product will work at its peak performance and efficiency.
Please save the original product packaging in case you need to safely
transport your portable ice maker.
For Your Records:
Please write down the model number and serial number
below for future reference. Both numbers are located on the
ratings label on the back of your unit and are needed to
obtain warranty service. You may also want to staple your
receipt to this manual as it is the proof of your purchase, and
is also needed for service under your warranty.
Model Number:
Serial Number:
Date of Purchase:
To better serve you, please do the following before contacting customer service:
xIf you received a damaged product, immediately contact the dealer that
sold you the product.
xRead and follow this instruction manual carefully to help you install, use
and maintain your ice maker.
xRead the troubleshooting section of this manual as it will help you
diagnose and solve common issues.
xVisit us on the web at http://www.edgestar.com to register your
product, download product manuals, and access additional
troubleshooting resources and up-to-date information.
xIf you need warranty service, our friendly customer service
representatives are available via email at [e-mail] or by
telephone at 1 [phone].

Koldfront Portable Ice Maker 2
Air Outlet
Drain Plug
Control Panel
Cover Window
Evaporator Rods Ice Basket
Parts Identification
Inside View
Outer View
Ice Scoop

3
Before you Begin: Preparing the Ice Maker for Use
Before you plug the ice maker in to a power supply, be sure to let it stand upright
for at least 24 hours to allow the compressor’s oils to settle.
Unpacking the Ice Maker
Carefully remove the packaging materials. Remove any shipping tape and glue
from your ice maker before using. Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove tape or glue. These products
can damage the surface of your icemaker. Check to make sure the ice basket
and ice scoop are included. If any parts are missing, please contact our customer
service. Put the ice maker on a level and flat surface away from direct sunlight
and other sources of heat such as a stove, furnace, radiator, etc. The appliance
must be positioned so that the power plug is accessible.
Cleaning the Ice Maker
Follow the Cleaning and Maintenance section to clean the ice maker.
Installation Requirements
The ice maker has been designed for free-standing installation which will allow
you to install the unit in almost any place you desire provided you level the unit
and follow the instructions for clearance, water and electrical requirements.
Clearance and Environment Requirements
• Choose a well ventilated area with temperatures above 50°F and below 90°F.
Operation outside these temperatures may result in lowered production or may
cause other adverse effects.
• This unit MUST be installed in an area protected from the elements, e.g., wind,
rain, water spray or drips. The icemaker should not be located next to ovens,
grills or other high heat sources.
• The unit should be located on a firm and level surface that is able to support the
ice maker’s total weight with water.
• There must be at least 4 inches of space around the back and sides of the unit
for proper air circulation.
Water Requirements
• Only use potable water or water suitable for drinking.
• The temperature of the water should be between 51°F and 90°F.
• Change the water in the water reservoir every 24 hours to ensure a reasonable
hygiene level.
Note: The add water light uses an electronic sensor that may not detect purified,
filtered, reverse osmosis, or distilled water. You may need to add a pinch of salt
to the water to increase the mineral content.
Electrical Requirements
Read all safety precautions listed at the beginning of this manual. It is
recommended that a separate circuit serving only your ice maker be provided.
Use receptacles that cannot be turned off by a switch or pull chain.
The ice maker is equipped with a power supply cord having a 3-prong grounding
plug. To minimize possible shock hazard, the cord must be plugged into a mating
3-pronged and grounding-type wall receptacle providing 110-120V, 60Hz,
grounded in accordance with the National Electrical Code and local codes and
ordinances. If a mating wall receptacle is not available, it is the personal
responsibility of the customer to have a properly grounded, 3-prong wall
receptacle installed by a certified electrician.
IMPORTANT: Do not remove any
safety, warning, or product
information labels from your ice
maker.
WARNING! Do not, under any
circumstances, cut or remove the
third (ground) prong from the
power cord.
Note: If the room temperature is
lower than 60°F, it is best to select
the small size setting; otherwise, the
ice cubes may stick together.

Koldfront Portable Ice Maker 4
Operation
Using Your Ice Maker
Before using your ice maker it is strongly recommended to clean it thoroughly.
Read and follow the Cleaning and Maintenance section of the manual before
proceeding.
Follow the steps below to start using your ice maker.
1. Open the top cover and remove any packaging tape that may be holding down
the ice case, ice shovel, ice basket, and ice scoop. Remove the ice scoop.
2. Remove the ice basket and clean it.
3. Clean the water reservoir.
4. Pour water into the water reservoir. Keep the water level below the “MAX”
water mark.
5. Insert the ice basket into the water reservoir.
6. Close the lid.
7. Plug the ice maker’s power plug in to a grounded outlet.
8. Press the On/Off button on the Control Panel.
9. Press the Select button on the Control Panel to choose between small and
large sized cubes. If the room temperature is lower than 60°F, it is best to select
the small size setting; otherwise, the ice cubes may stick together. The ice
making cycle may take up to thirteen minutes for a single batch of ice.
Notes: If the water pump is unable to detect or pump water, the unit will stop
automatically, and the “Add Water” indicator will be lit. Add water to the unit and
restart the unit by pressing the On/Off button twice.
The ice maker will continue making ice until the ice basket is full. When the ice
basket is full “Ice Full” indicator will be lit.
CAUTION: Direct sunlight may
cause the ice full infrared sensor to
malfunction. If the unit continues to
produce ice even though the basket
is full, you may need to move the
unit away from the sunlight.
IMPORTANT: Discard the first
batch of ice produced by the
portable ice maker.

5
Using the Control Panel
Power
Use the On/Off button to turn the portable ice maker on and off.
The Power Indicator light will be solid green when the unit is in the
“On” position. If the power light is blinking on and off, the unit is in
standby mode, and indicates the unit is plugged in.
Ice Size Selector
Use the Select button to switch the ice size between small and
large. The S indicator light corresponds to small ice while the L
indicator light corresponds to large ice.
Select Button
Small Ice Indicator
Medium Ice Indicator
Power Indicator
IMPORTANT: Do not power on
the unit without any water.
Button Function
POWER Powers the unit on or off.
SELECT Changes the ice size between Small and Large. The indicator light will turn on next
to the size you set.
Indicator Function
ADD WATER The add water light will turn on if the unit
does not have water in the reservoir.
ICE FULL The ice full light will turn on if the ice
basket is full.
POWER The power light will be solid green when
the unit is powered on.
SThe S indicates the unit will produce
small ice.
MThe M indicates the unit will produce
medium ice.
LThe L indicates the unit will produce
large ice.
Add Water Indicator
Ice Full Indicator
Power Button
Large Ice Indicator

Koldfront Portable Ice Maker 6
How the Portable Ice Maker Produces Ice
After the unit is powered on, the ice maker begins with rotating the ice
case into a horizontal water fill position under the evaporator. The water
pump is engaged and fills the ice case with water. Water overflows for a
few seconds before the compressor turns on. The compressor then
pumps refrigerant and the fan will turn on automatically after the
condenser heats up. The unit will be producing bullet shaped ice around
the stainless steel evaporator. When the batch of ice has been fully
formed, the ice maker stops the freeze cycle and begins the harvest
cycle. A valve opens diverting hot refrigerant gas into the evaporator. The
gas heats the evaporator causing the ice cube bullets to slide off the
evaporator. The ice shovel will automatically push the newly formed ice
into the ice basket, and will move the ice case back into the water fill
position for the next batch of ice. The ice maker will produce ice until ice
reaches the ice full sensor, or until the unit is out of water. The ice bin
compartment is insulated, but not refrigerated and the ice in the bin will
slowly melt and the water will be reused. Once enough of the ice has
melted, the ice maker will automatically start making more ice.
Draining the unit
Follow the steps below to drain the unit.
1. Carefully move the unit towards a sink or other suitable location for
draining.
2. Remove the rubber drain plug from the bottom of the water reservoir to
drain all the water.
3. Firmly install the rubber drain plug into the drain port.
Normal Sounds
Your new ice maker may make sounds that are not familiar to you. Most
of the new sounds are normal. Hard surfaces like the floor, walls can
make the sounds seem louder than they actually are. The following
describes the kinds of sounds that might be new to you and what may be
making them.
xThe ice case motor will make a whirling noise when the ice case and
shovel are moving.
xRattling noises may be produced from the flow of the refrigerant.
xThe compressor may make a pulsating or high-pitched sound.
xThe compressor may also produce a low tone humming sound.
xWater that is being pumped into the ice case will make trickling,
dripping or splashing sounds.
xAs each cycle ends, you may hear a gurgling sound due to the
refrigerant flowing.
xYou may hear fan noise and air being forced over the condenser by
the condenser fan.
xDuring the harvest cycle, you may hear the sound of ice cubes falling
into the ice basket.
xIf the ice maker is run without water, the water pump will make a
screeching noise. Note: Do not run the unit without water!
WARNING! Do not tip the unit
over while there is water in the
reservoir.

7
CLEANING AND MAINTENANCE
Periodic cleaning and proper maintenance will ensure efficiency, top
performance, and long life.
Never use a solvent-based cleaning agent. These cleaners may transmit taste to
the ice cubes, or damage and discolor the interior.
Unplug the unit before cleaning the exterior and interior.
Before using your ice maker, you are strongly recommended to clean it
thoroughly. (This process should clean the unit of any impurities that may have
been left behind during the manufacturing process.)
1. Take out the ice basket.
2. Clean the interior with a diluted cleaning solution, warm water and a soft cloth.
(DO NOT use any caustic or abrasive solutions) (Do not clean your ice maker
with flammable fluids.)
3. The outside of the ice maker should be cleaned regularly with a mild detergent
and warm water.
4. Dry the interior and exterior with a soft cloth.
If the ice has a strange taste
If the ice has an unappealing taste, or the unit develops a musty odor, try running
a few cycles of the ice maker with a mild white vinegar solution or lemon juice.
Then empty out all the vinegar or lemon juice solution and run a few cycles with
plain water to eliminate all traces of the vinegar or lemon juice.
If you find the bad taste remains after this procedure, use a solution of 2
tablespoons of baking soda to a full water reservoir of water left in the unit
overnight to absorb any remaining odors/tastes. Drain the solution, rinse the
water reservoir, and dry the interior.
Routine maintenance
1. Take out the ice basket.
2. Add a mild cleaning solution mixture to the water reservoir. Use a 10:1 ratio of
water to either white vinegar or lemon juice.
3. Run the ice maker to make a couple of batches of ice (at least 2). Discard the
ice.
4. Drain the cleaning solution from the water reservoir.
5. Add fresh water to the water reservoir up to the water level mark.
6. Run the ice maker to make a few batches of ice. Discard the ice.
7. Drain the water.
8. Add fresh water to the water reservoir to make ice, or dry the interior and
exterior with a clean soft cloth to store the machine.
9. The ice scoop should be washed regularly. Wash it just like any other utensil.
If the ice maker will not be used for an extended period of time, you should
unplug the unit from power, drain the water from the reservoir and dry the
interior with a clean soft cloth.
•Do not touch the power plug when your hands are wet.
•Never unplug the unit by pulling on the plug.
The icemaker must be thoroughly
cleaned if it has been left unused
for a long time. Follow carefully
any instructions provided for
cleaning or use of sanitizing
solution. Do not leave any
solution inside the icemaker after
cleaning.
DO NOT turn the ice machine
upside down to dry! This will
cause the oils from the
compressor to shift, which can
result in the machine breaking or
becoming inoperable.
