When a fault occurs, the drive fault relay is opened, the output stage is switched off (motor loses all torque),
or the load is dynamically braked. The specific drive behavior depends on the type of fault. The LED display on
the front panel of the drive shows the number of the fault that occurred. If a warning is issued prior to the fault,
the warning is shown on the LED and has the same number as the associated fault. Warnings do not trip the
power stage of the drive or fault relay output.
The left side of the LED displays Ffor a fault or nfor a warning. The right side displays the fault or warning
number as follows: 1-0-1-[break]. The highest priority fault is displayed on the LED, but multiple faults may be
present when a fault condition is occurring. Check the AKD Faults screen or read the status of DRV.FAULTS
through the controller or HMI for the entire list of faults.
1. AKD Fault and Warning Messages
Fault Message/Warning Cause Remedy
F0 N/A Reserved. N/A
..
1. 24V Control Power input voltage dip.
or
2. Auxillary encoder 5V (X9-9) shorted.
1. Insure adequate 24V
supply current capacity for
the system.
or
2. Check and fix X9 wiring.
F101 Firmware
incompatible. Installed firmware is not compatible with the drive hardware. Load compatible firmware into the drive.
F102 Resident firmware
failed. Software failure detected. Restart drive. If issue
persists, contact
technical support.
F103 Resident
FPGA failed.
Software failure detected. Load resident FPGA
failure occurred (several cases according to
flowchart, including incompatible image to
FPGA type and fieldbus type).
Restart drive. If issue
persists, contact
technical support.
F104 Operational FPGA
failed.
Software failure detected. Load operational
FPGA failure occurred (several cases
according to flowchart).
Restart drive. If issue
persists, contact
technical support.
F105 NV memory stamp
invalid. NV memory stamp is corrupted or invalid. Reset the drive to default
memory values using
Parameter Load.
F106 NV memory data
invalid.
NV memory data is corrupted or invalid.
This fault often occurs when downloading
firmware.
Reset the drive to default
memory values using
Parameter Load.
F107 Positive switch imit exceeded. Warning
issued prior to fault. Positive software position limit is exceeded. Move the load away from
the limits.
F108 Negative switch limit exceeded. Warning
issued prior to fault. Negative software position limit is exceeded. Move the load away from
the limits.
F121 Homing error. Drive did not finish homing sequence. Check homing sensor, homing mode, and homing
configuration.

Fault Message/Warning Cause Remedy
F123 Invalid motion task. Warning issued prior
to fault. Invalid motion task.
Check motion task settings and
parameters to make sure that
the values entered will produce
a valid motion task. Refer to the
motion task documentation for
additional guidance on specific
causes of invalid motion tasks.
F125 Synchronization lost. Warning issued prior
to fault. The fieldbus lost synchronization.
Check fieldbus connection (X5
and X6 if you are using EtherCAT;
X12 and X13 if you are using
CANopen) or the settings of your
EtherCAT or CANopen master.
F126 Too much movement. Warning issued prior
to fault.
Too much movement was created
during a Bode plot. Motor is unstable
and is not following drive instructions.
Check that the system
is closed loop stable. Refer to the
system tuning guide.
F127 Incomplete emergency
stop procedure.
Incomplete emergency stop procedure
(problem with the emergency stop
motion task).
Disconnect power from
drive and check emergency
stop procedure.
F128 MPOLES/FPOLES not
an integer. Ratio of motor poles to feedback poles must be a whole number. Change to a compatible feedback device.
F129 Heartbeat lost. Heartbeat lost. Check CANopen cabling. Reduce bus load or increase the
heartbeat update time.
F130 Secondary feedback
supply over current. 5V power supply was shorted out on X9. Check secondary feedback (X9 connection).
F131 Secondary feedback
A/B line break. Problem in secondary feedback detected. Check secondary feedback (X9 connection).
F132 Secondary feedback
A/B line break. Problem in secondary feedback detected. Check secondary feedback (X9 connection).
F134 Secondary feedback
illegal state. Feedback signals were detected in an illegal combination. Check secondary feedback (X9 connection).
F135 Homing is needed. Warning issued prior
to fault.
Attempt to issue motion task before
the axis is homed. Axis must be homed
before motion task can start. Change opmode or home axis.
F136 Firmware and FPGA versions are not
compatible.
The FPGA version does not match the
firmware FPGA version constants. Load the FPGA version that is compatible with the firmware.
5
AKD PDMM Fault Card | F123 – F136

6
Fault Message/Warning Cause Remedy
F137 Homing and feedback
mismatch
The configured homing mode is not
supported by the motor feedback
type used. Change homing mode.
F138 Instability during
autotune.
Drive current (IL.CMD) or velocity
feedback (VL.FB) exceeds allowable
limit. This fault only occurs in BODE.
MODE 5.
Change BODE.MODE if appropriate.
Otherwise the motor is not stable
and may require manual tuning.
F139
Target Position
over short due to
invalid motion task
activation.
The drive cannot decelerate from
its current speed to reach the end
point of the second motion task
without moving past it. Increase
the deceleration rate in the move or
trigger the move earlier
Change Motion task profile and
clear fault with DRV.CLRFAULTS,
or change the value of FAULT139.
ACTION = 1 to ignore this condition.
F140 VBUS.HALFVOLT has
changed.
The user changed the numerical
value of VBUS.HALFVOLT. The change
only takes effect after a DRV.NVSAVE
command and after rebooting the
AKD.
Save the parameters in the non-
volatile memory with DRV.NVSAVE
and turn off/on the 24[V] power
supply in order to reboot the drive
or restore the original setting of
VBUS.HALFVOLT.
F151
–
F170
Motion task warning. Motion task settings and parameters are not set to produce a valid motion
task.
DRV.CLRFAULTS will clear the
warning. Check motion task
settings and parameters to make
sure the values will produce a valid
motion task.
F201 Internal
RAM failed. Hardware failure detected. Restart drive. If issue persists, contact technical support.
F202 External
RAM failed. Hardware failure detected. Restart drive. If issue persists, contact technical support.
F203 Code integrity failed. Software failure detected. FPGA
register access failure occurred. Restart drive. If issue persists, contact technical support.
F204
–
F232
EEPROM
failure detected. EEPROM failure detected. Restart drive. If issue persists, exchange drive.
F234
–
F237
Control temperature
sensor high. Warning
issued prior to fault.
High temperature
limit reached. Check cabinet ventilation system.
F240
–
F243
Power temperature
sensor low. Warning
issued prior to fault.
Low temperature
limit reached. Check cabinet ventilation system.
F245 External fault. This fault is user generated and is
caused by user settings.
Users can configure a digital input
to trigger this fault (DINx.MODE =
10). the fault occurs according to
this input setting. Clear the input to
clear the fault.
AKD PDMM Fault Card | F137 – F245

Fault Message/Warning Cause Remedy
F247 Bus voltage exceed
allowed thresholds. Hardware problem in bus measurement. Troubleshoot and repair hardware problem.
F248 Option board EEPROM
corrupted. EEPROM failure detected. Restart drive. If issue persists, exchange drive.
F249 Option board
downstream checksum. Communications with the I/O on the option board failed.
DRV.CLRFAULTS. If issue
persists, contact technical
support.
F250 Option board upstream
checksum. Communications with the I/O on the option board failed.
DRV.CLRFAULTS. If issue
persists, contact technical
support.
F251 Option board
watchdog. Communications with the I/O on the option board failed.
DRV.CLRFAULTS. If issue
persists, contact technical
support.
F252 Firmware and option board FPGA types are
not compatible.
The option board FPGA is not compatible
with this hardware. Download the correct firmware file for this drive.
F253 Firmware and option board FPGA versions
are not compatible
The version of the option board FPGA is
not compatible with this firmware. Download the correct firmware file for this drive.
F301 Motor overheated. Motor overheated. Check ambient temperature. Check motor mounting heat
sink capability.
F302 Over speed. Motor exceeded VL.THRESH value. Increase VL.THRESH or lower
velocity command.
F303 Motor foldback. Maximum motor power has been exceeded; the power has been limited to
protect the motor.
Current command to the
motor is too high for too
long. Reduce servo gains, or
reduce command trajectory
aggressiveness.
F304 Motor foldback. Warning issued prior
to fault.
Maximum motor power has been
exceeded; the power has been limited to
protect the motor.
Change move profile to reduce
load on motor. Check for load
jamming or sticking. Check
that current limits are set
correctly.
F305 Brake
open circuit. Motor brake open circuit. Check cabling and general functionality.
7
AKD PDMM Fault Card | F247 – F305

8
Fault Message/Warning Cause Remedy
F306 Brake
short circuit. Motor brake short circuit. Check cabling and general functionality.
F307 Brake closed during
enable state. Motor brake closed unexpectedly. Check cabling and general functionality.
F308 Voltage exceeds motor
rating. Drive bus voltage exceeds the motor’s defined voltage rating. Make sure that the motor fits the driving rating.
F309 Motor I2t load. Reduce
load.
Motor I2t load (IL.MI2T) has
exceeded the warning threshhold
IL.MI2TWTHRESH. This warningcan
only be generated in case that the
motor protection mode IL.MIMODE has
been set to 1.
Reduce the load of the Drive
by e.g. adjusting lower
acceleration/deceleration
ramps.
F401 Failed to set feedback
type. Feedback is not connected or wrong feedback type selected. Check primary feedback (X10 connection).
F402 Analog signal
amplitude fault.
Analog signal amplitude is too low.
Analog fault (resolver signal amplitude
or sin/cos amplitude).
Check primary feedback (X10
connection), resolver and sine/
cos encoder only.
F403 EnDat communication
fault. General communication problem with feedback. Check primary feedback (X10 connection), EnDat only.
F404 Hall error.
Hall sensor returns invalid Hall state
(111, 000); either all Hall sensors are on
or off. Legal Hall states are 001, 011,
010, 110, 100, and 101. This fault can
be caused by a broken connection in any
one of the Hall signals.
Check the feedback wiring;
check all feedback connectors
to ensure all pins are positioned
correctly.
F405 BiSS
watchdog fault. Bad communication with the feedback device. Check primary feedback (X10 connection), Biss only.
F406 BiSS
multicycle fault. Bad communication with the feedback device. Check primary feedback (X10 connection), Biss only.
F407 BiSS
sensor fault. Bad communication with the feedback device. Check primary feedback (X10 connection), Biss only.
F408
–
F416
SFD Feedback Fault Bad communication with the SFD
device.
Check primary feedback (X10
connection). If fault persists,
internal feedback failure.
Return to manufacturer for
repair.
F417 Broken wire in primary
feedback.
In primary feedback, a broken wire was
detected (incremental encoder signal
amplitude).
Check feedback
cable continuity.
AKD PDMM Fault Card | F306 – F417

Fault Message/Warning Cause Remedy
F418 Primary feedback
power supply. Power supply fault for primary feedback. Check primary feedback (X10 connection).
F419 Encoder init procedure
failed Phase find procedure did not complete successfully.
Check encoder wiring, reduce/
balance motor load prior to
phase finding.
F420 FB3 EnDat
Communications Fault
A communication error was detected
with the EnDat 2.2 device connected
to the X9 connector.
Check tertiary feedback (X9
connection).
F436 EnDat overheated. Endat Feedback Device is over
termperature.
Check ambient temperature.
Check motor mounting heat
sink capability.
F437 Close to limit. Drive or motor over current or over
speed warning.
Check for increased load,
jamming or sticking. Is position
error set too low?
F438 Following error (numeric) Warning issued prior to
fault.
Motor did not follow command values.
Motor exceeded maximum allowed
position following error (numeric).
Check for increased load,
jamming or sticking. Is position
error set too low?
F439 Following
error (user).
Motor did not follow command values.
Motor exceeded maximum allowed
position following error (user).
Check feedback commutation
setup and tuning parameters.
F450 Following error
(presentation).
Motor did not follow command values.
Motor exceeded maximum allowed
position following error (presentation).
Check feedback commutation
setup and tuning parameters.
F473 Wake and Shake.
Insufficient movement. There was less movement than defined by WS.DISTMIN.
Increase WS.IMAX
and/or WS.T. Or try using
WS.MODE 1 or 2.
F475 Wake and Shake.
Excess movement.
WS.DISTMAX has been exceeded in
WS.MODE 0 or more than 360 degrees
was traveled in WS.MODE 2.
Increase WS.DISTMAX value
or reduce WS.IMAX or WS.T.
Note that wake and shake
is not supported for vertical/
overhung loads.
F476 Wake and Shake. Fine-coarse delta too
large.
The angle difference between the
coarse and fine calculation was larger
than 72 deg.
Modify WS.IMAX or WS.T and
try again.
F478 Wake and Shake.
Overspeed. WS.VTHRESH was exceeded. Increase WS.VTHRESH value or reduce WS.IMAX or WS.T.
9
AKD PDMM Fault Card | F418 – F478

10
Fault Message/Warning Cause Remedy
F479 Wake and Shake. Loop
angle delta too large.
The angle between
complete loops was larger
than 72 deg. Modify WS.IMAX or WS.T and try again.
F480 Fieldbus command
velocity too high. Fieldbus command velocity exceeds VL.LIMITP Lower fieldbus command trajectory or increase the value of VL.LIMITP
F481 Fieldbus command
velocity too low. Fieldbus command velocity exceeds VL.LIMITN Increase fieldbus command trajectory or decrease the value of VL.LIMITN
F482 Commutation not
initialized.
The motor requires the
commutation initialization
(there are no encoder
commutation tracks,
Hall sensors, etc.) and
no successful Wake and
Shake sequence has been
performed.
Clear any faults, activate the Wake and
Shake procedure (WS.ARM) and enable
the drive.
F483
–
F485
Wake and Shake error.
Motor U, Motor V, or Motor
W phase missing. No
current was detected in the
phase during initialization
(Mode 0 only).
Check the motor connections and
WS.IMAX (very low current may produce
this error).
F486 Motor velocity exceeds
EMU-speed.
Motor velocity exceeds
the maximum speed the
emulated encoder output
can generate.
Reduce value of
DRV.EMUEPULSEIDTH.
F487 Wake and Shake - Validating positive
movement failed
After applying a positive
current, motor moved in the
wrong direction.
Check motor phase wiring and motor
encoder wiring is correct.
F489 Wake and Shake - Validating negative
movement failed.
After applying a negative
current, motor moved in the
wrong direction.
Check motor phase wiring and motor
encoder wiring is correct.
F490 Wake and Shake - Validating Comm.
angle timed out.
During one of the W&S
validation stages the drive
stopped responding to
commands.
Contact customer support.
F491
Wake and Shake -
Validating Comm.
angle moved too far -
Bad Comm Angle.
After applying a current,
the motor moved too far
(>15 electrical degrees).
This indicates a poor motor phase angle
was found by Wake and Shake. Revise
Wake and Shake parameters, and re-run
Wake and Shake.
F492
Wake and Shake -
Validating Comm.
angle required more
than MOTOR.ICONT.
A current larger than
MOTOR.ICONT was used to
excite the motor.
This indicates one of the following:
1. Phase angle is incorrect due to a bad
wake and shake.
2. Motor has very high friction, requiring
high current to break free.
3. Motor power cable is disconnected or
improperly wired.
F501 Bus over voltage. Bus voltage too high. Usually, this problem is load
related.
Reduce load or change motion profile.
Check system regen capacity; add capacity
if needed. Check mains voltage.
AKD PDMM Fault Card | F479 – F501

Fault Message/Warning Cause Remedy
F502 Bus under voltage. Warning issued prior
to fault.
Bus voltage below
threshold value. Check mains voltage.
F503 Bus capacitor overload. Warning
issued prior to fault.
Single phase AC input
on a drive only rated
for three-phase input
or excessive single-
phase power load.
Check mains voltage.
F504
–
F518
Internal supply
voltage fault.
Internal supply
voltage fault
detected.
Check wiring for electromagnetic compatibility
(EMC). If issue persists
exchange drive.
F519 Regen short circuit. Regen resistor short
circuit. Regen IGBT short circuit. Contact technical support.
F520 Regen overload. Regen resistor
overload. Motor is being overhauled or motor is being stopped too quickly.
F521 Regen over power. Too much power stored in regen
resistor.
Either get larger regen resistor or use DC bus
sharing to dissipate power.
F523 Bus over voltage
FPGA. Bus over voltage hard fault. Check mains voltage and check system brake capacity.
F524 Drive foldback.
Maximum drive
power has been
exceeded. The power
has been limited to
protect the drive.
Motion requires too much power. Change profile
to reduce load.
F525 Output over current. Current exceeds drive
peak. Check for short or feedback faults.
F526 Current sensor short
circuit. Current sensor short circuit. Restart drive. If issue persists, contact technical support.
F527 Iu current AD
converter stuck. Hardware failure detected. Restart drive. If issue persists, contact technical support.
F528 Iv current AD
converter stuck. Hardware failure detected. Restart drive. If issue persists, contact technical support.
F529 Iu current offset limit
exceeded. Hardware failure detected. Restart drive. If issue persists, contact technical support.
F530 Iv current offset limit
exceeded. Hardware failure detected. Restart drive. If issue persists, contact technical support.
11
AKD PDMM Fault Card | F502 – F530

12
Fault Message/Warning Cause Remedy
F531 Power
stage fault. Hardware failure detected. Restart drive. If issue persists, replace drive.
F532 Drive motor parameters setup
incomplete.
Before a motor can
be enabled, you must
configure a minimum
set of parameters.
These parameters
have not been
configured.
Issue the command DRV.SETUPREQLIST to display
the list of the parameters that you must configure.
Configure these parameters either manually or
automatically. You can manually configure these
parameters in three ways: (1) set each parameter
individually; (2) use the setup wizard to select the
motor; or (3) select the motor type from the motor
data base in the Motor window (MOTOR.AUTOSET
must be set to 0 (FALSE)). If you use the Motor
window, you must first select the feedback type. If
the motor has Biss Analog, Endat, or SFD feedback
(feedback with memory), then these parameters are
set automatically when MOTOR.AUTOSET is set to
1 (TRUE).
F534 Failed to read motor parameters from
feedback device.
Motor either does not
have motor feedback
memory, or the motor
feedback memory
is not programmed
properly so the
parameters cannot
be read.
Try to read parameters again by clicking the
Disable and Clear Faults button, or by issuing the
DRV.CLRFAULTS command. If this attempt is not
successful, then set MOTOR.AUTOSET to 0 (false)
and program the parameters using the setup
wizard or manually set up the parameters. If the
motor has motor memory (Biss Analog, Endat, and
SFD motors have motor memory), return the motor
to have the memory programmed.
F535 Power-board over-
temperature fault.
The power-board
temperature sensor
indicates more than
85 °C.
Reduce the load of the drive or ensure better
cooling.
F601 Modbus data rate is
too high. Modbus controller data rate is too high. Reduce data rate.
F602 Safe torque off. Safe torque off function has been
triggered.
Reapply supply voltage
to STO if safe to do so.
F603 OPMODE incompatible with
CMDSOURCE.
This warning is
generated when the
drive is enabled and
the gearing command
source is selected
at the same time as
torque or velocity
opmode.
Select a different DRV.OPMODE and DRV.
CMDSOURCE combination.
F701 Fieldbus runtime. Runtime
communication fault. Check fieldbus connections (X11), settings, and control unit.
F702 Fieldbus
communication lost.
All fieldbus
communication was
lost.
Check fieldbus connections (X11), settings, and
control unit.
F703 Emergency timeout occurred while axis
should disable.
Motor did not stop in
the timeout defined. Change timeout value, change stop parameters, improve tuning.
AKD PDMM Fault Card | F531 – F703

13
2. AKD PDMM Errors and Alarms
When an Error(s) occur, the highesty priority error is displayed on the 7-seg LED of the AKD PDMM. Error
messages have priority over Alarm messages. When an Error or Alarm occur, always check the controller log
messages. The log messages will provide more details about the failure and the history of events leading
up to the failure. From the log messages, you can determine the specifics about the cause of the failure to
correct the underlying problem.
Errors and alarms are either hardware or software clearable. For instructions on clearing an Error or Alarm
locate its number in the table below, and follow the remedy instructions.
Error Message/Warning Cause Remedy
Errors
E01
Critical temperature
exceeded. PDMM
operation is stopped,
CPU will be put to
sleep.
CPU temperature exceeded safe
operating temperature limit.
Power-off. Check airflow and operating
environment are within hardware
specifications. Allow unit to cool
before power-on.
E02 Out of memory. KAS
runtime is stopping. Memory leak, memory corrupted, or hardware memory failure.
Power-off/on. If problem is recurrent,
check release notes for firmware
updates or return hardware for repair.
E03 Fan failure. CPU cooling fan was not able to
operate properly.
Check temperature and monitor for
High temp alarm (see A01). Return
hardware for fan replacement.
E10 Firmware is
corrupted.
Flash memory corrupted during
firmware download or flash
hardware failure.
Re-download firmware or boot into
recovery mode, download firmware,
and power-off/on. If problem persists,
return hardware for repair.
E11 Flash is corrupted, no filesystem is
available.
At startup the filesystem could not
be mounted on the flash. Reset to factory defaults. If problem persists, return hardware for repair.
E12 Not enough flash
memory available. Flash memory is full, unable to write to flash.
Clean-up the flash memory by
removing log files, application
programs, recipes, or other data files.
E13 Out of NVRAM space for retained
variables. NVRAM is full. Change application to reduce the
amount of retained variables.
E14 Reset to Factory
Defaults failed.
Flash memory could not be
formatted during a Reset to Factory
Defaults procedure.
Try reset to factory defaults again
from power-on. If problem persists,
return hardware for repair.
E15 Cannot read/write files from/to a SD
card.
SD card is not plugged-in or the
filesystem is corrupt and cannot
be mounted. PLC function failures
will not cause this error.
Insert a valid SD card or re-format
the SD card using Settings/SD card/
Format button.
E16 Not enough space available on the SD
card.
SD card is full, unable to write to
the SD card. PLC function failures
will not cause this error.
Clean-up SD card space by deleting
files or re-format the card using
Settings/SD
E20
Runtime plug-in,
process, thread or
application failed to
start.
KAS runtime or application code
failed to auto-start at boot.
Power-off/on. Reset to factory
defaults. If problem is recurrent,
check release notes for firmware
updates or download firmware.

Error Message/Warning Cause Remedy
E21
Runtime process,
thread, or driver failed
to respond during
operation.
KAS runtime code failed
during normal operation.
Power-off/on. If problem is recurrent,
check release notes for firmware
updates.
E22 Fatal error in PLC program, application
stopped.
Virtual machine failed to
execute an instruction.
Re-compile application, download,
and re-start. Check the IDE and
controller firmware versions are
compatible.
E23 CPU is overloaded.
Either the motion engine cycle
did not complete or the PLC
program did not complete
within the timeout period due
to excessive CPU loading.
Stop the application or power-off/on.
Reduce the sample rate, simplify the
application, or reduce the application
cycles and re-start the application.
E24 PLC application cannot
be started.
PLC application cannot be
started, due to an existing
condition.
Possible reasons:
1. Maintenance operation
is in progress.
2. Controller is in online
config mode.
3. AKD Restore failed.
4. The IDE version of the
compiled PLC code
and controller runtime
version do not match.
Check the following:
1. Controller web-server home
page for any maintenance
operation in-progress. Wait for
the operation to finish.
2. Connect to the controller with
the IDE and disable online
config mode.
3. EtherCAT network topology by
using the Scan network button
in the web-server’s Restore tab.
Correct the physical topology
and re-execute an AKD restore.
4. IDE version (only major.minor.
micro) should match with
runtime version. To correct,
install the correct version of IDE
or Runtime.
E30
EtherCAT
communication failure
during operational
mode.
EtherCAT network operation
failed due to a network
communciation error.
Check the EtherCAT network wiring
and devices state. Re-start the
application.
E31 EtherCAT communication failure
during preop mode.
EtherCAT network operation
failed due to a network
communciation error.
Check the EtherCAT network wiring
and devices state. Re-start the
application.
E32 EtherCAT communication failure
during bootstrap mode.
EtherCAT network operation
failed due to a network
communciation error.
Check the EtherCAT network wiring
and devices state. Re-start the
application.
E33 EtherCAT failed to initialize into
operational mode.
EtherCAT network initialization
failed due to a network
communciation error.
Check the EtherCAT network wiring
and devices state. Re-start the
application.
E34 EtherCAT failed to initialize into preop
mode.
EtherCAT network initialization
failed due to a network
communciation error.
Check the EtherCAT network wiring
and devices state. Re-start the
application.
E35 EtherCAT failed to initialize into bootstrap
mode.
EtherCAT network initialization
failed due to a network
communciation error.
Check the EtherCAT network wiring
and devices state. Re-start the
application.
14
AKD PDMM Fault Card | E21 – E36

15
Error Message/Warning Cause Remedy
E36
EtherCAT failed to
discover the expected
devices.
EtherCAT network discovery failed due
to a mismatch between the discovered
and expected devices.
Check the EtherCAT devices and wiring
order. Correct the device order wiring
or re-scan the network, re-compile,
and download the updated application.
Re-start the application.
E37 EtherCAT failed to return
to init state.
EtherCAT network initialization failed
due to a network communciation error.
Check the EtherCAT network wiring
and devices state. Re-start the
application.
E50 Backup to SD card failed. An unrecoverable error occurred
during the backup operation.
Repeat the backup to SD card
operation. If it fails again, replace the
SD card.
E51 Restore from SD card
failed.
An unrecoverable error occurred
during the restore operation.
Do NOT reboot the PDMM! Repeat
the restore operation. If it fails again,
reset the PDMM to factory defaults.
If problem persists, return hardware
for repair.
E52 SD Backup files are
missing or corrupt.
The restore operation failed due to
missing, incomplete, or corrupt files
on the SD card.
Perform a backup operation before the
restore or use an SD card with valid
backup files.
Alarm Message/Warning Cause Remedy
Alarms
A01 High temperature
exceeded.
CPU temperature near the safe
operating temperature limit.
Check airflow and operating
environment are within hardware
specifications.
A02 Low on memory. Memory leak or corruption.
Power-off/on. If problem is recurrent,
check release notes for firmware
updates or return hardware for repair.
A04 Low input voltage. +24 volt input power is +19 volts or
less.
Check power supply voltage and
connection to the PDMM.
A12 Flash memory is low on
free space. Flash memory is almost full.
Clean-up the flash memory by
removing log files, application
programs, recipes, or other data files.
Reset to factory defaults.
A21
Recoverable process or
thread failed to respond
during operation.
KAS non-runtime code failed
during normal operation and was
automatically restarted.
If problem is recurrent, power-off/
on. Check release notes for firmware
updates.
A23 CPU is overloaded. CPU usage is too high for 5 (or more)
seconds.
Reduce the sample rate, simplify the
application, or reduce the application
cycles.
A30
EtherCAT missed a send
frame during operation
mode.
EtherCAT master was unable to send a
frame for one or more cycles.
Reduce the controller CPU load, so it
has enough Real-Time margin to send
EtherCAT frames every cycle.
A38
EtherCAT missed a
receive frame during
operation mode.
EtherCAT master did not receive a
frame for one or more cycles.
Check the EtherCAT network wiring
and devices.
A40 Local digital IO missed a
cyclic update.
Local digital IO was not updated
during a cycle or the updates are no
longer synchronous.
Reduce the sample rate, simplify the
application, or reduce the application
cycles.
AKD PDMM Fault Card | A01 – A40

14
About Kollmorgen
Kollmorgen is a leading provider of motion systems and components
for machine builders. Through world-class knowledge in motion,
industry-leading quality, and deep expertise in linking and integerating
standards and custom products, Kollmorgen delivers breakthrough so-
lutions that are unmatched in performace, reliability, and ease-of-use,
giving machine builders an irrefutable marketplace advantage.
For assistance with your application needs visit www.kollmorgen.com
or contact us at:
North America
Kollmorgen
203A West Rock Road
Radford, VA 24141 USA
Phone: [phone]
Fax: [phone]
Email: [email protected]
Europe
Kollmorgen Europe GmbH
Pempelfurtstraße 1
40880 Ratingen Germany
Phone: [phone]
Fax: [phone]
Email: [email protected]
Asia
Kollmorgen
Rm 2205, Scitech Tower, China
22 Jianguomen Wai Street
Phone: +86 - 400 666 1802
Fax: +86 - 10 6515 0263
Email: [email protected]
