Komatsu D85EX_15R - D85PX-15R User guide

Photo may include optional equipment.
www.Komatsu.com Printed in Japan 200706 IP.AD (10)
CEN00192-00 Materials and specifications are subject to change without notice.
is a trademark of Komatsu Ltd. Japan.
HORSEPOWER
Gross: 199 kW 266 HP @ 1900 rpm
Net: 197 kW 264 HP @ 1900 rpm
OPERATING WEIGHT
D85EX-15R: 28000 kg 61,730 lb
D85PX-15R: 27550 kg 60,740 lb
CRAWLER DOZER
STANDARD EQUIPMENT
●Alternator 50 ampere/24V
●Back up alarm
●Batteries 140 Ah/2 x 12V
●Decelerator pedal
●Dry-type air cleaner with dust evacuator
and dust indicator
●Electric priming pump
●Engine hood
●Final drive case wear guard
●Front pull hook
●Hinged front mask, perforated
●Hydraulic drive radiator cooling fan
●Hydraulic track adjusters
●Hydrostatic steering system (HSS)
●Lighting system (including two front
and rear lights)
●Muffler with rain cap
●Palm lever steering control
●Perforated side covers
●Radiator reserve tank
●Rear cover
●Segmented sprockets
●Shoes:
560 mm 22" single-grouser (EX)
910mm 36” single-grouser (PX)
●Starting motor 7.5 kW/24 V
●Suspension seat and reclining
●TORQFLOW transmission
●Track frames
●Track roller guards, full length (EX),
center and end section (PX)
●Warning horn
●Water separator
ROPS canopy (without cab):*
Weight. . . . . . . . . . . . . . . . . . 437 kg 970 lb
Roof dimensions
Length . . . . . . . . . . . . . . . 1368 mm 4’6”
Width . . . . . . . . . . . . . . . . 1850 mm 6’1”
Height from
compartment floor . . . . . . 1768 mm 5’10”
*Meets ISO 3471 and SAE J/ISO 3471 ROPS
standards, as well as ISO 3449 FOPS standard.
ROPS for cab:*
Weight. . . . . . . . . . . . . . . . . . 371 kg 820 lb
Roof dimensions
Length . . . . . . . . . . . . . . . . 650 mm 2’2”
Width . . . . . . . . . . . . . . . 1774 mm 5’10”
Height from
compartment floor . . . . . . . 1754 mm 5’9”
*Meets ISO 3471 and SAE J/ISO 3471 ROPS
standards.
Multi-shank ripper (EX):
Hydraulically controlled parallelogram ripper
with three shanks.
Weight (including hydraulic
control unit) . . . . . . . . . 2500 kg 5,520 lb
Beam length . . . . . . . . . . . . . 2246 mm 7’4”
Maximum lift above ground . . 564 mm 1’10”
Maximum digging depth . . . . . 653 mm 2’2”
Steel cab:*
Weight. . . . . . . . . . . . . . . . . . 410 kg 910 lb
Dimensions:
Length . . . . . . . . . . . . . . . 1758 mm 5’9”
Width . . . . . . . . . . . . . . . . 1323 mm 4’4”
Height from compartment
floor to ceiling . . . . . . . . . . 1592 mm 5’3”
*Meets ISO 3449 FOPS standard.
OPTIONAL EQUIPMENT
●Air conditioner
●Alternator 75 ampere/24 V
●AM-FM radio with cassette
●Batteries 200 Ah/2 x 12V
●Fire extinguisher
●First-aid kit
●Heater and defroster
●Light for ripper point
●Lunch box
●Mirror, rearview
●Panel cover
●Seat belt
●Shoes:
610 mm 24” Single grouser shoe (EX)
660 mm 26” Single grouser shoes (EX)
910 mm 36” Swamp shoes (PX)
●Starting motor 11 kW/24V
●Sun visor
●Suspension seat, turn, fabric material
●Thermos
●Tool kit
●Vandalism protection kit
D85EX-15R
D85PX-15R

2 3
WALK-AROUND
Simple hull frame
and monocoque track frame
with pivot shaft for greater
reliability. See page 8.
D85-15
Extra-low machine profile provides excellent
machine balance and low center of gravity.
SAA6D125E-5 turbocharged after-cooled
diesel engine provides an output of 197 kW 264 HP
with excellent productivity. See page 6.
Large blade capacities:
D85EX:
5.2 m36.8 yd3(Straight tilt dozer)
7.0 m39.2 yd3(Semi-U tilt dozer)
D85PX:
5.9 m37.7 yd3(Straight tilt dozer)
See page 6.
Preventative maintenance
●Centralized service station
●Enclosed hydraulic piping
●Modular power train design
●Electric priming pump
See page 8.
Photo may include optional equipment.
Low-drive, long-track, undercarriage
ensures outstanding grading ability and stability.
See page 6.
Filtration
Further enhanced reliability of the machine against fuel
contamination thanks to the improvement in fuel filtration.
See page 9.
CRAWLER DOZER
D85EX/PX-15R CRAWLER DOZER
Genuine Answers for Land and Environment Optimization
New hexagonal designed cab includes:
●Spacious interior
●Comfortable ride with new cab damper
●Excellent visibility
●High capacity air conditioning system (optional)
●Palm Command Control System (PCCS) lever
●Pressurized cab (optional)
●Adjustable armrests
Hydrostatic Steering System (HSS)
provides smooth, quick and powerful control in
various ground conditions.
See page 5.
The track link life is greatly improved through
increased bushing diameter and link height in addition to
lubricated track. See page 8.
HORSEPOWER
Gross: 199 kW 266 HP @ 1900 rpm
Net: 197 kW 264 HP @ 1900 rpm
OPERATING WEIGHT
D85EX-15R 28000 kg 61,730 lb
D85PX-15R 27550 kg 60,740 lb
BLADE CAPACITY
Semi-U Tilt Dozer:
D85EX-15R: 7.0 m39.2 yd3
Straight Tilt Dozer:
D85EX-15R: 5.2 m36.8 yd3
D85PX-15R: 5.9 m37.7 yd3
Komatsu-integrated design for the best value,
reliability, and versatility. Hydraulics, power train, frame,
and all other major components are engineered by
Komatsu. You get a machine whose components are
designed to work together for higher production, greater
reliability, and more versatility.
Hydraulic drive radiator cooling fan
controlled automatically, reduces fuel
consumption and operating noise levels.
See page 6.
Building on the technology and expertise Komatsu has
accumulated since establishment in 1921, GALEO presents
customers worldwide with strong, distinctive image of
technological innovation and exceptional value.
The GALEO brand will be employed for Komatsu’s full lineup
of advanced construction and mining equipment. Designed
with high productivity, safety and environmental
considerations in mind, the machines in this line reflect
Komatsu’s commitment to contributing to the creation of a
better world.

54
PALM COMMAND CONTROL SYSTEM (PCCS)
D85-15
CRAWLER DOZER
D85EX/PX-15R CRAWLER DOZER
Palm command
electronic controlled
travel control joystick
Palm command travel joystick
provides the operator with a
relaxed posture and superb
fine control without operator
fatigue. Transmission gear
shifting is simplified with
thumb push buttons.
Full-adjustable suspension seat and travel control
console
The travel control console has adjustment fore and aft, and
height.
For improved rear visibility during reverse operations, the
operator can adjust seat 15° to the right. (opt)
Palm command
PPC controlled
blade control joystick
Blade control joystick uses the
Proportional Pressure Control
(PPC) valve and joystick is
similar to the travel control
joystick. PPC control combined
with the highly reliable Komatsu hydraulic system enables
superb fine control.
Fuel control dial
Engine revolution is controlled by electric signal, providing
ease of operation, eliminating maintenance of linkage and
joints.
Height adjustable armrest
Armrest is height adjustable without any tools, providing the
operator with firm arm support in an ideal armrest.
Trav el
control
lever
Fuel
control
dial
Monitor panel
Deceleration
pedal
Steering and
transmission
controller
Engine
controller
Electronic controlled
transmission
Engine
Fuel control
valve unit
ECMV ECMV ECMV ECMV
Brake pedal
potentiometer
Acceleration
sensor
Transmission
output shaft
speed sensor
Auto shift
down switch Service
switch
Transmission
control valve
Water
temp.
Fuel
temp.
Engine
oil
pressure
Engine
speed
Facing front
When turned 15° (opt)
Komatsu’s new ergonomically designed control system “PCCS” creates an operating
environment with “complete operator control”.
Blade and ripper
control joystick
Outline of electronic control system
Human-machine interface
Power train electronic control system
Smooth and soft operation
D85EX/PX utilizes a newly designed power train electronic control system. The controller registers the amount of operator
control (movements of lever and operation of switches) along with machine condition signals from each sensor, to calculate
accurately the control of the transmission for optimal machine operation. The ease of operation and productivity of the new
D85EX/PX is greatly improved through these new features.
Electronic Controlled Modulation Valve (ECMV) controlled transmission
Controller automatically adjusts each clutch engagement depending on travel conditions
such as gear speed, revolution and shifting pattern. This provides smooth shockless clutch
engagement, improved component reliability, improved component life and operator ride
comfort.
Hydrostatic Steering System—smooth, powerful turning
The Hydrostatic Steering System (HSS) is powered by an independent hydraulic pump with
engine power transmitted to both tracks without power interruption on the inside track. When
the machine turns, the outside track moves faster and the inside slower, for smooth,
powerful turns. Counter-rotation is available for minimum turning radius providing
excellent maneuverability. Shock-free steering reduces machine vibration and minimizes
operator fatigue.
Preset travel speed function
Preset travel speed selection function is provided as standard equipment. The preset switch enables the operator to select a
combination of forward/reverse gear shifts, from 4 patterns; F1-R1, F1-R2, F2-R1 and F2-R2, by using UP/DOWN shift switch,
and once the shift pattern is selected, operator can control the machine concentrating his attention on directional control only.
Once F2-R2 pattern is selected, for example, 2nd gear is automatically selected when travel control joystick is moved into
forward/reverse. This function reduces gear shifting frequency during machine operation and is especially helpful when used
in combination with Auto-Downshift Function.
Auto downshift function
Controller monitors engine speed, travel gear and travel speed.
When load is applied and machine travel speed is reduced, the
controller automatically downshifts to optimize gear speed to
provide high fuel efficiency. This function provides comfortable
operation and high productivity without manual downshifting. (This
function can be deactivated with cancel switch.)
F1-R2 MODE
F2-R1 MODE
Press DOWN switch
Press DOWN switch
Press UP switch
Press UP switch
F1-R1 MODE
F2-R2 MODE
Press DOWN switch Press UP switch
UP
DOWN
Electronic Controlled
Modulation Valve (ECMV)
Conventional modulation valve
Time
Clutch pressure
Heavy load Light load
Actuated on heavy
load or steep slope
●Tu r ning while dozing— the machine turns by driving the
left and right tracks under power at different speeds
allowing the machine to travel at the same speed as in
straight dozing.
●Side cutting— when side-loading the blade, straight travel
can be maintained utilizing HSS.
●On downhill slopes— the machine doesn’t require counter-
steering. The joystick provides the same steering response
on downhill slopes as on flat ground.
●Grading— can be done efficiently without damaging the
ground, because the inside track is not locked during
turning.
Steering planetary
gear units Hydraulic motor
Brakes

76
PRODUCTIVITY FEATURES
D85-15
CRAWLER DOZER
D85EX/PX-15R CRAWLER DOZER
Photo may include optional equipment.
Engine
The Komatsu SAA6D125E-5 engine delivers 197 kW 264 HP
at 1900 rpm. The fuel-efficient Komatsu engine, together
with the heavy machine weight, make the D85EX/PX supe-
rior crawler dozers in both ripping and dozing operations.
The engine features direct fuel injection, turbocharger, and
air-to-air aftercooler to maximize fuel efficiency.
To minimize noise and vibration, the engine is mounted to
the main frame with rubber cushions.
Hydraulic drive radiator cooling fan
Fan rotation is automatically controlled depending on coolant
and hydraulic oil temperature, saving fuel consumption and
providing great productivity with a quiet operating environment.
Undercarriage
Low drive and long track undercarriage
Komatsu’s design is extraordinarily tough and offers
excellent grading ability and stability. Large-diameter
bushings, increased track link heights, and improved oil-
seals help to increase undercarriage durability.
Improvements
Numerous improvements to increase undercarriage
reliability and durability have been incorporated.
Serviceability has also been improved with the addition of
remote greasing of the equalizer bar center pin.
Operator comfort is essential for productive work.
The D85EX/PX provides a quiet, comfortable environment
where the operator can concentrate on the work at hand.
Hexagonal pressurized cab
●The cab’s new hexagonal design and large tinted glass
windows provide excellent front, side and rear visibility.
●Air filters and a higher internal air pressure combine
to prevent dust from entering the cab.
Comfortable ride with new cab damper mounting
D85EX/PX’s cab mount uses a new cab damper which
provides excellent shock and vibration absorbtion capacity
with its long stroke. Cab damper mounts soften shocks and
vibration while traveling over adverse conditions, which
conventional mounting system are unable to absorb. The cab
damper spring isolates the cab from machine chassis,
suppressing vibration and providing a quiet, comfortable
operating environment.
New suspension seat
D85EX/PX uses a new suspension seat. Fore and aft
sliding rails and suspension spring increase strength and
rigidity. The new seat provides excellent support, improving
riding comfort. Fore
and aft seat travel can
be adjusted to
accommodate different
operator sizes.
Operator comfort
Photo may include optional equipment.
Spring
Silicon oil
Rubber Boot
Cab damper mounting
WORKING ENVIRONMENT
Work equipment
Large blade
Capacities of 5.2 m36.8 yd3(Straight tilt dozer for D85EX),
5.9 m37.7 yd3(D85PX), 7.0m39.2 yd3(Semi-U tilt dozer for
D85EX) yield outstanding production. High-tensile-strength
steel has been incorporated into the front and sides of the
blade for increased durability.
Rippers (EX)
●The multi-shank ripper features a long sprocket center-to-
ripper point distance, making ripping operation easy and
effective while maintaining high penetration force.
●The multi-shank ripper is a parallelogram type ideal for
ripping in tough material. The ripping depth is adjustable in
two stages.

98
EASY MAINTENANCE
D85-15
CRAWLER DOZER
D85EX/PX-15R CRAWLER DOZER
RELIABILITY FEATURES
Centralized service station
To assure convenient maintenance, the transmission and
HSS oil filters, power train oil level gauges and hydraulic
tank are arranged in the right side of the machine.
Monitor with self-diagnostic function
With the starting switch turned ON, the monitor displays
check-before-starting and caution items appear on the
lower right part of the panel. If the monitor finds
abnormalities, corresponding warning lamp blinks and
warning buzzer sounds. The monitor displays engine
rpm and forward/reverse gear speed on the upper part
of the monitor during operation. If abnormalities occur
during operation, user code appears on display. When a
critical user code is displayed, the caution lamp blinks and
a warning buzzer sounds to prevent the development of
serious problems.
Easy cleaning with hydraulic drive radiator fan
The radiator core and the core on the front side of the oil
cooler can be easily cleaned by running the hydraulic engine
fan in reverse. Accordingly, the cleaning intervals of those
cores can be increased.
Electric priming pump
Simply pressing the button enables bleeding air from the
fuel circuit at the time of filter replacement, etc.
Enclosed hydraulic piping
Hydraulic piping for the blade tilt cylinder is completely
housed in the push arm, ensuring damage protection from
materials.
Modular power train design
Power train components are sealed in a modular design that
allows the components to be dismounted and mounted
without oil spillage.
Reliable simple structure
Simple hull structure main frame design increases durability
and reduces stress concentration at critical areas. The track
frame has a large cross section and utilizes pivot shaft
mounting for greater reliability.
Maintenance free disc brakes
Wet disc brakes require less maintenance.
Gull-wing engine side covers
The opening area is further
enlarged when gull-wing
engine side covers are
opened, facilitating engine
maintenance and filter
replacement. Side covers
have been changed to a
thick one-piece structure with
a bolt-on catch to improve durability.
Heavy-duty track link
The track link life is greatly improved through increased
bushing diameter and link height in addition to lubricated
track.
Preventative maintenance
Preventative maintenance is the only way to ensure long service life from your equipment. That’s why Komatsu designed the
D85EX/PX with conveniently located maintenance points to make necessary inspections and maintenance quick and easy.
Filtration
Engine
Newly added main fuel filter of 2µm and water separator
protect the engine against dirt and water in the fuel.
The fuel tank is
equipped with a high-
filtration breather with
pressure valve to
prevent dust from
entering.
Hydraulic
A filter is added to the
hydraulic tank cap in
order to prevent dust
from entering the tank
cap and protect
hydraulic components
against dust.
Engine
Power train unit
Hull frame
Pivot shaft
Final drive
Tra c k frame
Shoe

1110
SPECIFICATIONS
D85-15
CRAWLER DOZER
D85EX/PX-15R CRAWLER DOZER
STEERING SYSTEM
PCCS lever controls for all directional movements. Pushing the
PCCS lever forward results in forward machine travel, while pulling it
rearward reverses the machine. Simply tilt the PCCS lever to left to
make a left turn. Tilt it to the right for a right turn.
Hydrostatic Steering System (HSS) is powered by steering planetary
units and an independent hydraulic pump and motor. Counter-
rotation turns are also available. Wet, multiple-disc, pedal-controlled
service brakes are spring-actuated and hydraulically released. Gear
shift lock lever also applies parking brake.
Minimum turning radius D85EX-15R . . . . . . . . . . . . 1.99 m 6’6”
D85PX-15R . . . . . . . . . . . . 2.24 m 7’4”
UNDERCARRIAGE
Suspension . . . . . . . . . . . . . Oscillating equalizer bar and pivot shaft
Track roller frame . . . . . . . . . . . . . . . . . . . Monocoque, large section,
durable construction
Rollers and idlers. . . . . . . . . . . . . . . . . . . . . . Lubricated track rollers
Track shoes
Lubricated tracks. Unique seals prevent entry of foreign
abrasive material into pin to bushing clearances to provide
extended service life. Track tension is easily adjusted with grease
gun.
ENGINE
Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Komatsu SAA6D125E-5
Type. . . . . . . . . . . . . . . . . . . . . 4-cycle, water-cooled, direct injection
Aspiration . . . . . . . . . . . . . . . . . . Turbocharged, air-to-air aftercooled
Number of cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Bore x stroke . . . . . . . . . . . . . . . . . 125 mm x 150 mm 4.92” x 5.91”
Piston displacement. . . . . . . . . . . . . . . . . . . . . . . . . 11.04 ltr 674 in3
Governor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . All-speed, electronic
Horsepower
SAE J1995 . . . . . . . . . . . . . . . . . . . . . . . . . Gross 199kW 266HP
ISO 9249 / SAE J1349* . . . . . . . . . . . . . . . . . . Net 197kW 264HP
Rated rpm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1900rpm
Fan drive type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hydraulic
Lubrication system
Method . . . . . . . . . . . . . . . . . . . . . . . Gear pump, force lubrication
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Full-flow
*Net horsepower at the maximum speed of
radiator cooling fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179 kW 240HP
TORQFLOW TRANSMISSION
Komatsu TORQFLOW transmission consists of a water-cooled,
3-element, 1-stage, 1-phase, torque converter and a planetary gear,
multiple-disc clutch transmission which is hydraulically actuated and
force-lubricated for optimum heat dissipation. Gearshift lock lever
and neutral safety switch prevent accidental starts. D85EX-15R D85PX-15R
Number of track rollers (each side) 7 8
Type of shoes (standard) Single grouser Single grouser
Number of shoes (each side) 41 45
Grouser height 72 mm 2.8” 72 mm 2.8”
Shoe width (standard) 560 mm 22” 910 mm 36”
Ground contact area 34160 cm263340 cm2
5295 in29,820 in2
Ground pressure 73.6 kPa 43.1 kPa
(with dozer, cab and ROPS) 0.75 kg/cm2 0.44 kg/cm2
10.7 psi 6.3 psi
Track gauge 2000 mm 6’7” 2250 mm 7’5”
Length of track on ground 3050 mm 10’ 3480 mm 11’5”
COOLANT AND LUBRICANT
CAPACITY (REFILL)
Fuel tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 490 ltr 129 U.S. gal
Coolant. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 ltr 15.3 U.S. gal
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 ltr 10.0 U.S. gal
Torque converter, transmission,
bevel gear, and steering system . . . . . . . . . . 60 ltr 15.9 U.S. gal
Final drive (each side). . . . . . . . . . . . . . . . . . . . 26 ltr 6.9 U.S. gal
FINAL DRIVES
Double-reduction final drive of spur and planetary gear sets to
increase tractive effort and reduce gear tooth stresses for long final
drive life. Segmented sprocket rims are bolt-on for easy replacement.
Travel speed Forward Reverse
D85EX-15R D85PX-15R D85EX-15R D85PX-15R
1st 3.3 km/h 3.3 km/h 4.4 km/h 4.4 km/h
2.1 mph 2.1 mph 2.7 mph 2.7 mph
2nd 6.1 km/h 6.0 km/h 8.0 km/h 7.9 km/h
3.8 mph 3.7 mph 5.0 mph 4.9 mph
3rd 10.1 km/h 10.0 km/h 13.0 km/h 12.7 km/h
6.3 mph 6.2 mph 8.1 mph 7.9 mph
60
60
50
40
30
20
10
0
50
40
30
20
10
00
01234567 mph
Travel Speed
Drawbar Pull
246810 12 km/h
US ton tonkN
500
400
300
200
100
0
F3
F2
F1
D85EX-15R
Power Shift
DRAWBAR PULL vs. SPEED
MAXIMUM USABLE PULL
DEPENDS ON TRACTION AND
WEIGHT OF TRACTOR
INCLUDING MOUNTED
EQUIPMENT
D
EF
A
B
CH
G
Overall Maximum Maximum Maximum Weight
length with Blade Blade lift above drop below tilt Dozer Hydraulic Ground
dozer capacity length x height ground ground adjustment equipment oil pressure*
D85EX-15R 5640 mm 5.2 m33715 mm x 1436 mm 1210 mm 540 mm 750 mm 3305 kg 24 kg 72.6 kPa 0.74 kg/cm2
Straight tilt dozer 18'6" 6.8 yd312'2" x 4'9" 4' 1'9" 2'6" 7,290 lb 53 lb 10.5 psi
D85EX-15R 5795 mm 7.0 m33635 mm x 1580 mm 1210 mm 540 mm 735 mm 3575 kg 24 kg 73.6 kPa 0.75 kg/cm2
Semi-U tilt dozer 19' 9.2 yd311'11" x 5'2" 4’ 1'9" 2'5" 7,890 lb 53 lb 10.7 psi
D85PX-15R 6065 mm 5.9 m34365 mm x 1370 mm 1230 mm 570 mm 500 mm 3343 kg 23 kg 43.1 kPa 0.44 kg/cm2
Straight tilt dozer 19'11" 7.7 yd314'4" x 4'6" 4' 1'10" 1'8" 7,370 lb 51 lb 6.3 psi
D85EX-15R 6035 mm 4.0 m34515 mm x 1130 mm 1173 mm 760 mm 520 mm 3730 kg 24 kg 73.6 kPa 0.75 kg/cm2
Mechanical angle
19'10" 5.2 yd314'10" x 3'8" 3'10" 2'6" 1'8" 8,220 lb 53 lb 10.7 psi
power tilt dozer
DOZER EQUIPMENT
Blade capacities are based on the SAE recommended practice J1265.
* Ground pressure shows tractor, cab, ROPS canopy operator, standard equipment and applicable blade.
DIMENSIONS
OPERATING WEIGHT
Tractor weight:
Including rated capacity of lubricant, coolant, full fuel tank,
operator, and standard equipment.
D85EX-15R . . . . . . . . . . . . . . . . . . . 21120 kg 46,560 lb
D85PX-15R . . . . . . . . . . . . . . . . . . . 23400 kg 51,590 lb
Operating weight
Including Semi-U tilt dozer (EX) or straight tilt dozer (PX), multi-
shank ripper (EX), steel cab, ROPS, operator, standard
equipment, rated capacity of lubricant, coolant, and full fuel tank.
D85EX-15R . . . . . . . . . . . . . . . . . . . 28000 kg 61,730 lb
D85PX-15R . . . . . . . . . . . . . . . . . . . 27550 kg 60,740 lb
HYDRAULIC SYSTEM
Closed-center load sensing system (CLSS) designed for precise and
responsive control, and for efficient simultaneous operation.
Hydraulic control units:
All spool valves externally mounted beside the hydraulic tank.
Plunger type hydraulic pump with capacity (discharge flow) of 195
ltr/min 51.5 U.S. gal/min at rated engine rpm.
Relief valve setting . . . . . . . . . . . . . 22.6 MPa 230 kg/cm23,270 psi
Control valves:
Spool control valves for tilt dozer
Positions: Blade lift . . . . . . . . . . . . . . Raise, hold, lower, and float
Blade tilt. . . . . . . . . . . . . . . . . . . . . Right, hold, and left
Additional control valve required for multi-shank ripper (EX)
Positions: Ripper lift . . . . . . . . . . . . . . . . . . Raise, hold, and lower
Hydraulic cylinders . . . . . . . . . . . . . . . . . . . . . . Double-acting, piston
Hydraulic oil capacity (refill):
Straight tilt dozer. . . . . . . . . . . . . . . . . . . . . . 67 ltr 17.7 U.S. gal
Semi-U tilt dozer . . . . . . . . . . . . . . . . . . . . . . 67 ltr 17.7 U.S. gal
Ripper equipment (additional volume):
Multi-shank ripper . . . . . . . . . . . . . . . . . . . . 11 ltr 2.9 U.S. gal
Number of cylinders Bore
Blade lift 2 100 mm 3.9”
Blade tilt 1 150 mm 5.9”
Ripper lift 2 130 mm 5.1”
D85EX-15R D85PX-15R
A2000 mm 6'7" 2250 mm 7'5"
B3635 mm 11'11" 4365 mm 14'4"
C3330 mm 10'11" 3330 mm 10'11"
D3050 mm 10' 3480 mm 11'5"
E5795 mm 19' 6065 mm 19'11"
F1460 mm 4'9" —
G72 mm 2.8" 72 mm 2.8"
H3324 mm 10'11" 3324 mm 10'11"
Ground clearance: 450 mm 1'6"
Dimensions with semi-U tilt dozer and multi-shank ripper (D85EX)
