Komatsu PC130-7 Manual

PC130-7
SERIALNUMBER
PC130-7-72642andup
HYDRAULIC EXCAVATOR
Unsafe use of this machine may cause serious injury or
death. Operators and maintenance personnel must read
this manual before operating or maintaining this
machine. This manual should be kept inside the cab for
reference and periodically reviewed by all personel who
will come into contact with the machine.
Operation &
Maintenance Manual
UEAM003604
WARNING

FOREWORD
11

FOREWORD FOREWORD
1-2
FOREWORD 1
This manual provides rules and guidelines which will help you use this machine safely and effectively. The pre-
cautions in this manual must be followed at all times when performing operation and maintenance. Most accidents
are caused by the failure to follow fundamental safety rules for the operation and maintenance of machines. Acci-
dents can be prevented by knowing beforehand conditions that may cause a hazard when performing operation
and maintenance.
WARNING
Operators and maintenance personnel must always do as follows before beginning operation or mainte-
nance.
Always be sure to read and understand this manual thoroughly before performing operation and mainte-
nance.
Read the safety messages given in this manual and the safety labels affixed to the machine thoroughly
and be sure that you understand them fully.
Keep this manual at the storage location for the Operation and Maintenance Manual given below, and have
all personnel read it periodically.
If this manual has been lost or has become dirty and cannot be read, request a replacement manual imme-
diately from Komatsu or your Komatsu distributor.
If you sell the machine, be sure to give this manual to the new owners together with the machine.
Komatsu delivers machines that comply with all applicable regulations and standards of the country to
which it has been shipped. If this machine has been purchased in another country or purchased from
someone in another country, it may lack certain safety devices and specifications that are necessary for
use in your country. If there is any question about whether your product complies with the applicable
standards and regulations of your country, consult Komatsu or your Komatsu distributor before operating
the machine.
Storage location for the Operation and Maintenance
Manual:
magazine box on the left side of the operator's seat.

FOREWORD SAFETY INFORMATION
1-3
SAFETY INFORMATION 1
To enable you to use this machine safely, safety precautions and labels are given in this manual and affixed to the
machine to give explanations of situations involving potential hazards and of the methods of avoiding such situa-
tions.
Signal words
The following signal words are used to inform you that there is a potential hazardous situation that may lead to per-
sonal injury or damage.
In this manual and on machine labels, the following signal words are used to express the potential level of hazard.
Example of safety message using signal word
WARNING
When standing up from the operator's seat, always place
the safety lock lever in the LOCK position.
If you accidentally touch the control levers when they are
not locked, this may cause a serious injury or death.
Other signal words
In addition to the above, the following signal words are used to indicate precautions that should be followed to pro-
tect the machine or to give information that is useful to know.
Indicates an imminently hazardous situation which, if not avoided, will result in death
or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury. This word is used also to alert against unsafe practices that may
cause property damage.
DANGER
WARNING
CAUTION
NOTICE This word is used for precautions that must be taken to avoid actions which could shorten
the life of the machine.
REMARKS This word is used for information that is useful to know.

SAFETY INFORMATION FOREWORD
1-4
qSafety labels
Safety labels are affixed to the machine to inform the operator or maintenance worker on the spot when carrying
out operation or maintenance of the machine that may involve hazard.
This machine uses “Safety labels using words“ and “Safety labels using pictograms“ to indicate safety procedures.
Example of safety label using words
Safety labels using pictogram
Safety pictograms use a picture to express a level of hazard-
ous condition equivalent to the signal word. These safety pic-
tograms use pictures in order to let the operator or
maintenance worker understand the level and type of hazard-
ous condition at all times.
Safety pictograms show the type of hazardous condition at the
top or left side, and the method of avoiding the hazardous con-
dition at the bottom or right side. In addition, the type of haz-
ardous condition is displayed inside a triangle and the method
of avoiding the hazardous condition is shown inside a circle.
Komatsu cannot predict every circumstance that might involve a potential hazard in operation and maintenance.
Therefore, the safety messages in this manual and on the machine may not include all possible safety precau-
tions.
If any procedures or actions not specifically recommended or allowed in this manual are used, it is your responsi-
bility to take the necessary steps to ensure safety.
In no event should you engage in prohibited uses or actions described in this manual.
The explanations, values, and illustrations in this manual were prepared based on the latest information available
at that time. Continuing improvements in the design of this machine can lead to changes in detail which may not
be reflected in this manual. Consult Komatsu or your Komatsu distributor for the latest available information of
your machine or for questions regarding information in this manual.
The numbers in circles in the illustrations correspond to the numbers in ( ) in the text. (For example: 1-> (1))

FOREWORD SAFETY INFORMATION
1-5
Noise emission levels 1
Two labels indicating the machine noise level are affixed on the
machine
21
qSound pressure level at the operator’s station, measured
according to ISO6396 (Dynamic test method, simulated
working cycle).
qSound power level emitted by the machine, measured
according to ISO 6395 (Dynamic test method, simulated
working cycle). This is the guaranteed value as specified
in European directive 2000/14/EC.
Vibration levels 1
When used for its intended purpose, levels of vibration for the earth-moving machine transmitted from the opera-
tor’s seat are lower than or equal to the tested vibrations for the relative machinery class in compliance with ISO
7096.
The actual acceleration value for the hands and arms is less than or equal to 2.5 m/s². The actual acceleration
value for the body is less than or equal to 0.5 m/s².
These values were determined using a representative machine and measured during the typical operating condi-
tion indicated below according to the measurement procedures that are defined in the standards ISO 2631/1 and
ISO 5349.
Operating condition: 1
(HYDRAULIC EXCAVATORS:) Excavating (Digging-loading-rotating-unloading-rotating)

SAFETY INFORMATION FOREWORD
1-6
Guide to Reduce Vibration Levels on Machine 1
The following guides can help an operator of this machine to reduce the whole body vibration levels:
1. Use the correct equipment and attachments.
2. Maintain the machine according to this manual
qTire pressures (for wheeled machines), tension of crawler (for crawler machines)
qBrake and steering systems
qControls, hydraulic system and linkages
3. Keep the terrain where the machine is working and traveling in good condition
qRemove any large rocks or obstacles
qFill any ditches and holes
qSite manager should provide machine operators with machine and schedule time to maintain terrain con-
ditions
4. Use a seat that meets ISO 7096 and keep the seat maintained and adjusted
qAdjust the seat and suspension for the weight and size of the operator
qWear seat belt
qInspect and maintain the seat suspension and adjustment mechanisms
5. Steer, brake, accelerate, shift gears (for wheeled machines), and move the attachment levers and pedals
slowly so that the machine moves smoothly
6. Adjust the machine speed and travel path to minimize the vibration level
qWhen pushing with bucket or blade, avoid sudden loading; load gradually
qDrive around obstacles and rough terrain conditions
qSlow down when it is necessary to go over rough terrain
qMake the curve radius of traveling path as large as possible
qTravel at low speed when traveling around sharp curves
7. Minimize vibrations for long work cycle or long distance traveling
qReduce speed to prevent bounce
qTransport machines long distances between worksites
8. The following guidelines can be effective to minimize risks of low back pain
qOperate the machine only when you are in good health.
qProvide breaks to reduce long periods of sitting in the same posture
qDo not jump down from the cab or machine
qDo not repeatedly handle and lift loads

FOREWORD INTRODUCTION
1-7
INTRODUCTION 1
This Komatsu machine is designed to be used mainly for the following work:
qDigging work
qLeveling work
qDitching work
qLoading work
qDemolition work
See the section “RECOMMENDED APPLICATIONS (3-100)“ for further details.
DIRECTIONS OF MACHINE 1
In this manual, the terms front, rear, left, and right refer to the travel direction as seen from the operator's seat
when the operator's seat is facing the front and the sprocket is at the rear of the machine.
BREAKING-IN THE NEW MACHINE
NOTICE
Your Komatsu machine has been thoroughly adjusted and tested before shipment from the factory. How-
ever, operating the machine under full load before breaking the machine in can adversely affect the perfor-
mance and shorten the machine life.
Be sure to break in the machine for the initial 100 hours (as indicated on the service meter).
Make sure that you fully understand the content of this manual, and pay careful attention to the following points
when breaking in the machine.
qRun the engine at idling for 15 seconds after starting it. During this time, do not operate the control levers or
fuel control dial.
qIdle the engine for 5 minutes after starting it up.
qAvoid operation with heavy loads or at high speeds.
qImmediately after starting the engine, avoid sudden starts, sudden acceleration, unnecessary sudden stops,
and sudden changes in direction.
Front
Right
Sprocket
Rear
Left
Operator’s seat

PRODUCT INFORMATION FOREWORD
1-8
PRODUCT INFORMATION 1
When requesting service or ordering replacement parts, please
inform your Komatsu distributor of the following items.
PRODUCT IDENTIFICATION NUMBER (PIN)/MACHINE SERIAL NO. PLATE 1
On the bottom right of the operator's cab
The design of the nameplate differs according to the territory.
ENGINE SERIAL NUMBER PLATE AND ITS LOCATION 1
On the upper side of the engine cylinder head cover.
EPA: Environmental Protection Agency, U.S.A.

FOREWORD PRODUCT INFORMATION
1-9
SERVICE METER LOCATION 1
On top of the machine monitor
YOUR MACHINE SERIAL NUMBERS AND DISTRIBUTOR 1
Machine serial No.
Engine serial No.
Product Identification Number
Manufacturers name:
Address:
KOMATSU UK Ltd.
Durham Road
Birtley
Chester-Le street
County Durham DH32QX
United Kingdom
Distributor
Address
Phone
Service personnel for your
machine:

PRODUCT INFORMATION FOREWORD
1-10
MACHINE SERIAL NUMBER PLATE
Model
Seriel Number
Manufacturing year
Weight
Engine power
Product Identification Number
Manufacturer

FOREWORD PRODUCT INFORMATION
1-11

CONTENTS
1-12
CONTENTS
FOREWORD
FOREWORD......................................................................................................................................................... 1-2
SAFETY INFORMATION...................................................................................................................................... 1-3
NOISE EMISSION LEVELS........................................................................................................................ 1-5
VIBRATION LEVELS .................................................................................................................................. 1-5
GUIDE TO REDUCE VIBRATION LEVELS ON MACHINE .............................................................. 1-6
INTRODUCTION................................................................................................................................................... 1-7
DIRECTIONS OF MACHINE ...................................................................................................................... 1-7
BREAKING-IN THE NEW MACHINE ......................................................................................................... 1-7
PRODUCT INFORMATION.................................................................................................................................. 1-8
PRODUCT IDENTIFICATION NUMBER (PIN)/MACHINE SERIAL NO. PLATE........................................ 1-8
ENGINE SERIAL NUMBER PLATE AND ITS LOCATION ......................................................................... 1-8
SERVICE METER LOCATION ................................................................................................................... 1-9
YOUR MACHINE SERIAL NUMBERS AND DISTRIBUTOR ..................................................................... 1-9
MACHINE SERIAL NUMBER PLATE....................................................................................................... 1-10
SAFETY
SAFETY INFORMATION...................................................................................................................................... 2-2
SAFETY LABELS................................................................................................................................................. 2-4
LOCATION OF SAFETY LABELS .............................................................................................................. 2-4
SAFETY LABELS ....................................................................................................................................... 2-5
SAFETY INFORMATION.................................................................................................................................... 2-13
SAFETY MACHINE OPERATION...................................................................................................................... 2-23
STARTING ENGINE ................................................................................................................................. 2-23
OPERATION ............................................................................................................................................. 2-25
TRANSPORTATION ................................................................................................................................. 2-32
BATTERY ................................................................................................................................................. 2-33
TOWING ................................................................................................................................................... 2-35
LIFTING OBJECTS WITH BUCKET ......................................................................................................... 2-36
SAFETY MAINTENANCE INFORMATION........................................................................................................ 2-38
OPERATION
MACHINE VIEW ILLUSTRATIONS ..................................................................................................................... 3-2
OVERALL MACHINE VIEW........................................................................................................................ 3-2

CONTENTS
1-13
CONTROLS AND GAUGES ....................................................................................................................... 3-3
DETAILED CONTROLS AND GAUGES.............................................................................................................. 3-4
MONITORING SYSTEM............................................................................................................................. 3-4
BASIC CHECK MONITORS .............................................................................................................. 3-5
CAUTION MONITORS ...................................................................................................................... 3-7
EMERGENCY MONITORS ............................................................................................................... 3-9
METER DISPLAY PORTION...........................................................................................................3-11
MONITOR SWITCHES PORTION .................................................................................................. 3-14
SWITCHES ............................................................................................................................................... 3-17
CONTROL LEVERS AND PEDALS ......................................................................................................... 3-23
SUN ROOF ............................................................................................................................................... 3-26
WINDSHIELD ........................................................................................................................................... 3-26
EMERGENCY EXIT FROM OPERATOR'S CAB ..................................................................................... 3-31
DOOR LOCK ............................................................................................................................................ 3-31
CAP WITH LOCK...................................................................................................................................... 3-32
HOT AND COOL BOX .............................................................................................................................. 3-34
MAGAZINE BOX....................................................................................................................................... 3-34
ASHTRAY ................................................................................................................................................. 3-34
AIR CONDITIONER CONTROLS............................................................................................................. 3-35
AIR CONDITIONER CONTROL PANEL ......................................................................................... 3-35
METHOD OF OPERATION .............................................................................................................3-40
USE AIR CONDITIONER WITH CARE ........................................................................................... 3-46
INSPECTION AND MAINTENANCE OF AIR CONDITIONER EQUIPPED MACHINE................... 3-46
OTHER FUNCTIONS ...................................................................................................................... 3-47
CAB RADIO CASSETTE .......................................................................................................................... 3-48
CONTROLS OF RADIO CASSETTE .............................................................................................. 3-48
PRECAUTIONS WHEN USING ...................................................................................................... 3-48
AUXILIARY ELECTRIC POWER.............................................................................................................. 3-49
24V POWER SOURCE ................................................................................................................... 3-49
12V POWER SOURCE ................................................................................................................... 3-49
FUSE ........................................................................................................................................................ 3-50
FUSIBLE LINK .......................................................................................................................................... 3-51
CONTROLLERS ....................................................................................................................................... 3-51
TOOL BOX................................................................................................................................................ 3-51
GREASE GUN HOLDER .......................................................................................................................... 3-51
HANDLING GREASE GUN ...................................................................................................................... 3-52
REFUELLING PUMP ................................................................................................................................ 3-53
ACCUMULATOR ...................................................................................................................................... 3-55
RELEASING HYDRAULIC PRESSURE WITH ACCUMULATOR................................................... 3-55
MACHINE OPERATIONS AND CONTROLS..................................................................................................... 3-56
BEFORE STARTING ENGINE ................................................................................................................. 3-56
WALK-AROUND CHECKS..............................................................................................................3-56
CHECKS BEFORE STARTING....................................................................................................... 3-58
ADJUSTMENT................................................................................................................................. 3-64
SEAT BELT ..................................................................................................................................... 3-69
OPERATIONS BEFORE STARTING ENGINE ............................................................................... 3-70

CONTENTS
1-14
STARTING ENGINE ................................................................................................................................. 3-72
NORMAL STARTING ...................................................................................................................... 3-72
STARTING ENGINE IN COLD WEATHER ..................................................................................... 3-74
AMBIENT TEMPERATURE RANGE FOR OPERATION ........................................................................ 6.-76
AFTER STARTING ENGINE .................................................................................................................... 3-76
WARMING-UP OPERATION........................................................................................................... 3-76
IN COLD WEATHER AREAS .......................................................................................................... 3-79
STOPPING THE ENGINE ........................................................................................................................ 3-83
MACHINE OPERATION ........................................................................................................................... 3-84
PREPARATIONS FOR MOVING THE MACHINE OFF................................................................... 3-84
MOVING MACHINE FORWARD ..................................................................................................... 3-85
MOVING MACHINE BACKWARD ................................................................................................... 3-86
STOPPING MACHINE..................................................................................................................... 3-87
STEERING THE MACHINE ...................................................................................................................... 3-88
STEERING ...................................................................................................................................... 3-88
SWINGING ............................................................................................................................................... 3-90
WORK EQUIPMENT CONTROLS AND OPERATIONS .......................................................................... 3-91
WORKING MODE..................................................................................................................................... 3-93
PROHIBITED OPERATIONS ................................................................................................................... 3-94
GENERAL OPERATION INFORMATION ................................................................................................ 3-96
TRAVELING ON SLOPES........................................................................................................................ 3-97
ESCAPE FROM MUD............................................................................................................................... 3-99
STUCK ONE SIDE OF TRACK ....................................................................................................... 3-99
STUCK BOTH SIDES OF TRACKS ................................................................................................ 3-99
RECOMMENDED APPLICATIONS........................................................................................................3-100
BACKHOE WORK ......................................................................................................................... 3-100
SHOVEL WORK ............................................................................................................................ 3-100
DITCHING WORK ......................................................................................................................... 3-100
LOADING WORK .......................................................................................................................... 3-101
BUCKET REPLACEMENT AND INVERSION ........................................................................................ 3-102
REPLACEMENT............................................................................................................................ 3-102
INVERSION ................................................................................................................................... 3-103
PARKING MACHINE .............................................................................................................................. 3-104
CHECK AFTER SHUT OFF ENGINE .....................................................................................................3-105
MACHINE INSPECTION AFTER DAILY WORK .................................................................................... 3-106
LOCKING................................................................................................................................................ 3-106
OVERLOAD WARNING DEVICE ........................................................................................................... 3-106
TRANSPORTATION......................................................................................................................................... 3-107
TRANSPORTATION PROCEDURE ....................................................................................................... 3-107
LOADING AND UNLOADING WITH TRAILER ...................................................................................... 3-108
LOADING....................................................................................................................................... 3-109
SECURING MACHINE .................................................................................................................. 3-111
UNLOADING ................................................................................................................................. 3-114
LIFTING MACHINE................................................................................................................................. 3-116
COLD WEATHER OPERATION ...................................................................................................................... 3-117
COLD WEATHER OPERATION INFORMATION................................................................................... 3-117

CONTENTS
1-15
FUEL AND LUBRICANTS ............................................................................................................. 3-117
COOLING SYSTEM COOLANT .................................................................................................... 3-117
BATTERY ...................................................................................................................................... 3-118
AFTER DAILY WORK COMPLETION.................................................................................................... 3-119
AFTER COLD WEATHER SEASON ...................................................................................................... 3-119
LONG TERM STORAGE.................................................................................................................................. 3-120
BEFORE STORAGE............................................................................................................................... 3-120
DURING STORAGE ............................................................................................................................... 3-120
AFTER STORAGE.................................................................................................................................. 3-121
STARTING MACHINE AFTER LONG-TERM STORAGE ...................................................................... 3-121
TROUBLES AND ACTIONS ............................................................................................................................ 3-122
RUNNING OUT OF FUEL ...................................................................................................................... 3-122
PHENOMENA THAT ARE NOT FAILURES........................................................................................... 3-122
TOWING THE MACHINE ....................................................................................................................... 3-123
LIGHTWEIGHT TOWING HOLE ............................................................................................................ 3-123
SEVERE JOB CONDITION .................................................................................................................... 3-124
DISCHARGED BATTERY ...................................................................................................................... 3-125
BATTERY REMOVAL AND INSTALLATION ................................................................................ 3-125
BATTERY CHARGES ................................................................................................................... 3-126
STARTING ENGINE WITH BOOSTER CABLES.......................................................................... 3-127
OTHER TROUBLE ................................................................................................................................. 3-129
ELECTRICAL SYSTEM................................................................................................................. 3-129
CHASSIS ....................................................................................................................................... 3-130
ENGINE ......................................................................................................................................... 3-131
ELECTRONIC CONTROL SYSTEM ............................................................................................. 3-132
MAINTENANCE
MAINTENANCE INFORMATION......................................................................................................................... 4-2
LUBRICANTS, COOLANT AND FILTERS.......................................................................................................... 4-5
HANDLING OIL, FUEL, COOLANT, AND PERFORMING OIL CLINIC ..................................................... 4-5
OIL ..................................................................................................................................................... 4-5
FUEL.................................................................................................................................................. 4-5
COOLING SYSTEM COOLANT ........................................................................................................ 4-6
GREASE............................................................................................................................................ 4-6
CARRYING OUT KOWA (KOMATSU OIL WEAR ANALYSIS)......................................................... 4-7
OIL AND FUEL STORAGE................................................................................................................ 4-8
FILTERS ............................................................................................................................................ 4-8
ELECTRIC SYSTEM MAINTENANCE ....................................................................................................... 4-8
WEAR PARTS...................................................................................................................................................... 4-9
WEAR PARTS LIST.................................................................................................................................... 4-9
LUBRICANTS, FUEL AND COOLANT SPECIFICATIONS............................................................................... 4-10
PROPER SELECTION ............................................................................................................................. 4-10

CONTENTS
1-16
TIGHTENING TORQUE SPECIFICATIONS ...................................................................................................... 4-14
TIGHTENING TORQUE LIST................................................................................................................... 4-14
SAFETY CRITICAL PARTS............................................................................................................................... 4-15
SAFETY CRITICAL PARTS LIST ............................................................................................................. 4-15
MAINTENANCE SCHEDULE............................................................................................................................. 4-16
MAINTENANCE SCHEDULE CHART......................................................................................................4-16
MAINTENANCE INTERVAL FOR HYDRAULIC BREAKER..................................................................... 4-18
MAINTENANCE PROCEDURE.......................................................................................................................... 4-19
INITIAL 250 HOURS MAINTENANCE (ONLY AFTER THE FIRST 250 HOURS) ................................... 4-19
INITIAL 1000 HOURS MAINTENANCE (ONLY AFTER THE FIRST 1000 HOURS) ............................... 4-19
WHEN REQUIRED ................................................................................................................................... 4-20
CHECK, CLEAN AND REPLACE AIR CLEANER ELEMENT ......................................................... 4-20
CLEAN INSIDE OF COOLING SYSTEM ........................................................................................ 4-25
CHECK AND TIGHTEN TRACK SHOE BOLTS.............................................................................. 4-28
CHECK AND ADJUST TRACK TENSION....................................................................................... 4-29
CHECK ELECTRICAL INTAKE AIR HEATER ................................................................................ 4-31
REPLACE BUCKET TEETH (VERTICAL PIN TYPE) ..................................................................... 4-32
REPLACE BUCKET TEETH (HORIZONTAL PIN TYPE)................................................................ 4-35
ADJUST BUCKET CLEARANCE .................................................................................................... 4-36
CHECK WINDOW WASHER FLUID LEVEL, ADD FLUID .............................................................. 4-37
CHECK AND ADJUST AIR CONDITIONER.................................................................................... 4-38
WASH WASHABLE FLOOR............................................................................................................ 4-39
BLEEDING AIR FROM HYDRAULIC SYSTEM............................................................................... 4-43
METHOD FOR RELEASING INTERNAL PRESSURE IN HYDRAULIC CIRCUIT.......................... 4-46
CHECK NITROGEN GAS CHARGE PRESSURE IN ACCUMULATOR (CONTROL CIRCUIT)..... 4-46
CHECK BEFORE STARTING .................................................................................................................. 4-47
EVERY 100 HOURS MAINTENANCE...................................................................................................... 4-48
LUBRICATING................................................................................................................................. 4-48
CHECK SWING MACHINERY CASE OIL, ADD OIL....................................................................... 4-50
EVERY 250 HOURS MAINTENANCE...................................................................................................... 4-51
CHECK OIL LEVEL IN FINAL DRIVE CASE, ADD OIL .................................................................. 4-51
CHECK LEVEL OF BATTERY ELECTROLYTE ............................................................................. 4-52
EVERY 500 HOURS MAINTENANCE...................................................................................................... 4-55
REPLACE FUEL FILTER CARTRIDGE .......................................................................................... 4-55
CHANGE OIL IN ENGINE OIL PAN, REPLACE ENGINE OIL FILTER CARTRIDGE .................... 4-56
CHECK SWING PINION GREASE LEVEL, ADD GREASE ............................................................ 4-57
LUBRICATE SWING CIRCLE ......................................................................................................... 4-57
RADIATOR CORE AND FINS - CHECK/CLEAN ............................................................................ 4-58
CLEAN AIR CONDITIONER FRESH/RECIRC FILTERS ................................................................ 4-59
REPLACE HYDRAULIC OIL FILTER ELEMENT ............................................................................ 4-61
REPLACE BREATHER ELEMENT IN HYDRAULIC TANK............................................................. 4-62
CHECK AND ADJUST COOLING FAN BELT TENSION ................................................................ 4-63
CHECK, ADJUST AIR CONDITIONER COMPRESSOR BELT TENSION ..................................... 4-64
EVERY 1000 HOURS MAINTENANCE....................................................................................................4-65
CHANGE OIL IN SWING MACHINERY CASE................................................................................ 4-65

CONTENTS
1-17
CHANGE OIL IN FINAL DRIVE CASE ............................................................................................ 4-66
CHECK ALL TIGHTENING PARTS OF TURBOCHARGER ........................................................... 4-66
CHECK PLAY TURBOCHARGER ROTOR .................................................................................... 4-66
CHECK NITROGEN GAS CHARGE PRESSURE IN ACCUMULATOR (FOR BREAKER)............ 4-66
EVERY 2000 HOURS MAINTENANCE....................................................................................................4-67
CHECK PTO GEAR CASE, ADD OIL ............................................................................................. 4-67
CLEAN HYDRAULIC TANK STRAINER ......................................................................................... 4-68
CLEAN, CHECK TURBOCHARGER............................................................................................... 4-68
CHECK ALTERNATOR, STARTING MOTOR ................................................................................ 4-68
CHECK ENGINE VALVE CLEARANCE, ADJUST.......................................................................... 4-68
EVERY 4000 HOURS MAINTENENCE....................................................................................................4-69
CHECK WATER PUMP................................................................................................................... 4-69
EVERY 5000 HOURS MAINTENANCE....................................................................................................4-70
CHANGE OIL IN HYDRAULIC TANK............................................................................................. 4-70
SPECIFICATIONS
SPECIFICATIONS................................................................................................................................................ 5-2
EXPLANATION OF LIFTING CAPACITY CHART (PC130-7 1- PC BOOM).............................................. 5-5
EXPLANATION OF LIFTING CAPACITY CHART (PC130-7 2-PC BOOM)............................................... 5-7
ATTACHMENTS AND OPTIONS
GENERAL PRECAUTIONS FOR SAFETY.......................................................................................................... 6-2
HYDRAULIC QUICK COUPLER PIPING ................................................................................................... 6-2
LOCATIONS ...................................................................................................................................... 6-2
OPERATION...................................................................................................................................... 6-3
PRECAUTIONS WHEN SELECTING......................................................................................................... 6-5
READ THE INSTRUCTION MANUAL THOROUGHLY.............................................................................. 6-5
PRECAUTIONS WHEN REMOVING OR INSTALLING ............................................................................. 6-5
PRECAUTIONS WHEN USING.................................................................................................................. 6-6
BUCKET WITH HOOK ......................................................................................................................................... 6-7
HOOK CONDITION .................................................................................................................................... 6-7
PROHIBITED OPERATIONS ..................................................................................................................... 6-7
MACHINE READY FOR ATTACHMENT ............................................................................................................. 6-8
LOCATIONS ............................................................................................................................................... 6-8
HYDRAULIC CIRCUIT.............................................................................................................................. 6-11
HYDRAULIC CIRCUIT CONNECTION ........................................................................................... 6-11
ATTACHMENT REMOVAL AND INSTALLATION.................................................................................... 6-12
ATTACHMENT REMOVAL..............................................................................................................6-12
ATTACHMENT INSTALLATION...................................................................................................... 6-12
ATTACHMENT OPERATIONS................................................................................................................. 6-14
WHEN USING BREAKER ............................................................................................................... 6-14
WHEN USING GENERAL ATTACHMENT SUCH AS CRUSHER.................................................. 6-15

CONTENTS
1-18
CRUSHER CONTROL FOR ROTATION ................................................................................................. 6-16
ACCUMULATOR ...................................................................................................................................... 6-17
HYDRAULIC SYSTEM - PRESSURE RELEASE............................................................................ 6-17
LONG TERM STORAGE .......................................................................................................................... 6-18
SPECIFICATIONS .................................................................................................................................... 6-18
ATTACHMENT GUIDE....................................................................................................................................... 6-19
OTHER ATTACHMENTS ......................................................................................................................... 6-19
ATTACHMENT COMBINATIONS............................................................................................................. 6-20
TRACK SHOES SELECTION................................................................................................................... 6-21
BUCKET TEETH SELECTION ................................................................................................................. 6-22
TEETH SELECTION........................................................................................................................ 6-22
SELECTION GUIDE FOR HORIZONTAL OR VERTICAL PIN TYPE TOOTH ............................... 6-22
HANDLING OF RUBBER PAD SHOE AND ROAD LINER ...................................................................... 6-23
WORKING ENVIRONMENT............................................................................................................ 6-23
WORKING CONDITIONS................................................................................................................ 6-23
STORAGE, PROTECTION.............................................................................................................. 6-24
EXTENT OF DAMAGE TO RUBBER .............................................................................................. 6-24
CHECK ROAD LINER ..................................................................................................................... 6-24
REPLACE ROAD LINER ................................................................................................................. 6-24
RECOMMENDED ATTACHMENT OPERATIONS............................................................................................. 6-25
HYDRAULIC BREAKER ........................................................................................................................... 6-25
2-PC BOOM........................................................................................................................................................ 6-29
FEATURES OF 2-PIECE BOOM & ARM ................................................................................................. 6-29
OPERATION ............................................................................................................................................. 6-30
BEFORE STORAGE POSTURE WHEN LEAVING MACHINE ....................................................... 6-31
TESTING AND ADJUSTING ...........................................................................................................6-32
PERODIC MAINTENANCE .............................................................................................................6-32
TRANSPORTATION ................................................................................................................................. 6-33
HANDLING MACHINES EQUIPPED WITH KOMTRAX.................................................................................... 6-34
BASIC PRECAUTIONS ................................................................................................................... 6-34
SUPER LONG FRONT BOOM AND ARM......................................................................................................... 6-35
OPERATION INSTRUCTION ................................................................................................................... 6-35
WORKING MODES .................................................................................................................................. 6-36
CHECKS BEFORE STARTING ................................................................................................................ 6-37
USING SUPER LONG FRONT................................................................................................................. 6-38
METHOD OF WORK ................................................................................................................................ 6-39
WHEN TRAVELLING ...................................................................................................................... 6-39
CONTROL LEVERS, PEDALS ................................................................................................................. 6-40
SAFETY LOCK LEVER (1) .............................................................................................................. 6-40
TRAVEL LEVERS (WITH PEDAL, AUTO-DECELERATION MECHANISM) (2)............................. 6-41
LEFT WORK EQUIPMENT CONTROL LEVER (3)......................................................................... 6-41
RIGHT WORK EQUIPMENT CONTROL LEVER (4) ...................................................................... 6-42
MACHINE OPERATION ........................................................................................................................... 6-43
PRECAUTIONS FOR OPERATION OF SUPER LONG FRONT .................................................... 6-43
