Komunica DX-HF-Pro-1 User manual

Wide Band Portable Antenna
';HF-PRO-1
ENG
Notes for Using the Antenna
Specication
• Range7Mhz-430Mhz.
• 1/4wave(50/144MHz),5/8wave(144/430MHz)
• Youcanalsousetheantennaas1/4wave(144Mhz)
• Tousethisantennaproperly,readthisinstructionthoroughlybeforeusingit.Thisantenna(7-430Mhz)isdesigned
exclusivelyforamateurradio,communicationonly.
• Keepthismanualcarefullyathandforlateruse.
Toavoidaccidents,followthebelownotices
1. Thisantennaisdesignedtousethecarbodyorthemetalhandrailasthegroundearthwhentheportableuse.Donot
installtheantennaxedandontothetransceiverallthetimeduetotheissuesoftheproductstrengthandwaterproof.This
antennaisprohibitedfromusingformobile,duetothisantennaisnotpreparedforstrongwinds.
2. Donottouchtheantennaduringtransmission.Touchingtheantennaduringtransmíssionmaycausetoelectrifydepending
onthepowerused.
Description
1. TheHF-PRO-1canbeoperatedonwideband7-430MHz.ltisOKtousetheHF-PRO-1onlywhenportableoperation.
2. Ifthefrecuencyadjustedisahighervalue,lowertherodelement.
3. 144MHzbandcanbeoperatedatboth1/4waveand5/8wavedependingonthelenghtoftheadditionalelementused.
Frequency 7-430MHzBand
Max.PowerRating 130W(SSB)
Impedance 50ohms
Lenght 0.5-1.77m
Weight 300gr
Connector PL
Type
1/4wavereducedtype(HFBand).1/4wave
(50/144MHz),5/8wave(144/430MHz)
*144MHzbandcanbeoperatedatboth1/4waveand
5/8wavebythelengthoftherodelement.
Accessory AditionalElements(Short/Large)

AntennaBody
SetScrew
Scale
1. Selecttherightfrecuency,checkthepositionof
theantennabodyscalewiththegraphicorthe
bandchartFig.1&Fig.2
2. Loosenthesetscrewasahalfturnbyhand.
(Keeptherodelementretracted).
3. Slidetheantennabodytotherequest
frequencyafterstep1andfasten it with the
set screw by hand.Maketherodelement
fulllength.
(Donotuseanytoolssuchasplierswhen
fastensetscrew.Theantennamaybe
damaged).
4. TransmitandmeasuretheSWR.lfthe
tuningfrequencyislowerthantherequest
frequency,maketherodelementshortor
maketheantennabodydown.
TheSWRshouldbelowerthan1.5
dependingontheconditions.Ifnot,please
changetheinstallationconditions.Wealso
recommendusingtheantennatuner.
5. lfthetuningfrequencyishigherthanthe
requestfrequency,movetheantennabody
up.
6. Whenadjusting50MHzband,putthe
antennabodydownandmaketherod
elementfulllength.(Largeradialelement).
7. Whenadjusting144/430MHzbands,putthe
largeradial(Largeradialelement)inthexed
antennaandfastentheradialelement.When
adjust144MHzband,shortentheantenna
body1/4wave,changetheradialelementof
thebodyantennatotheshorterone(Shortradial
element).Whenadjustíng430MHz,makethe
antennabodyretractedwiththelargeradial
element(Largeradialelement).
Adjustment
Atenttion!!!
1. Pleaseinstalltheantennavertically
tohaveabetterperformance.
2. TheSWRshouldbelowerthan1.5
dependingontheconditions.Inthat
case,pleaseusetheantennatuner.
Installation Place (example)
1. Setthebracketwherethe
groundingearthcanbetaken.
(guttermount,trunklidetc)
2. lnstalltheantennaatthecarroof
bythemagnetbase.
3. Setthemagnetbaseonthewood
tableandinstalltheantennawith
approx.10mgroundwireand
connecttothegroundingearth.
4. Installtheantennaatthemetal
handrailwherethegroundingearth
canbetaken.
SettingsofHFPRO1
Frequency Scale(mm)
30.000 3
29.000 3
28.000 3
24.900 4
21.300 4
18.000 5
14.100 8
10.500 16
7.400 22
(Fig.1)
(Fig.2)
Scale
Frequency
(Mhz)
27
25
20
15
10
5
2
710 14 18 21 24 28 30
RodElement
RadialElement
(AdditionalLarge/Short)
O
OO
O
