Konig DVB-T FTA21 User manual

2012-10-18
DVB-T FTA21
MANUAL (p. 8)
FULL HD FTA RECEIVER
ANLEITUNG (S. 24)
FULL HD FTA RECEIVER
MODE D’EMPLOI (p. 42)
RÉCEPTEUR DE CANAL GRATUIT
ENTIÈREMENT HD
GEBRUIKSAANWIJZING (p. 59)
VOLLEDIGE HD FTA-ONTVANGER
MANUALE (p. 76)
RICEVITORE FTA FULL HD
MANUAL DE USO (p. 93)
RECEPTOR FTA FULL HD
HASZNÁLATI ÚTMUTATÓ (o. 110.)
TELJES HD FTA VEVŐKÉSZÜLÉK
KÄYTTÖOHJE (s. 127)
FULL HD FTA -VASTAANOTIN
BRUKSANVISNING (s. 143)
FULL HD FTA-mottagare
NÁVOD K POUŽITÍ (s. 159)
PŘIJÍMAČFTA (NEKÓDOVANÝH
PROGRAMŮ) V PLNÉM HD ROZLIŠENÍ
MANUAL DE UTILIZARE (p. 175)
RECEPTOR FTA HD INTEGRAL
ΕΓΧΕΙΡΙ∆ΙΟ XPHΣHΣ(σελ. 191)
∆ΕΚΤΗΣ FTA FULL HD
BRUGERVEJLEDNING (s. 209)
FULDSTÆNDIG HD FTA-MODTAGER
VEILEDNING (s. 225)
FULL HD FTA-MOTTAKER
ИНСТРУКЦИЯ (стр. 241)
РЕСИВЕР FULL HD FTA

2
Contents
ENGLISH...............................................................................................................................8
GENERAL INFORMATION .................................................................................................................... 8
Main Features.................................................................................................................................. 8
For your safety:................................................................................................................................ 8
General information: ........................................................................................................................ 9
General Operation: .......................................................................................................................... 9
Remote control: ............................................................................................................................. 10
INSTALLATION .....................................................................................................................................11
INSTALLATION GUIDE........................................................................................................................ 12
MAIN MENU ......................................................................................................................................... 13
1. Program:.................................................................................................................................... 13
2. Picture ....................................................................................................................................... 15
3. Channel search ......................................................................................................................... 15
4. Time........................................................................................................................................... 16
5. Option ........................................................................................................................................ 17
6. System....................................................................................................................................... 17
7. USB ........................................................................................................................................... 19
8. Hotkey ....................................................................................................................................... 20
TROUBLESHOOTING ......................................................................................................................... 22
DEUTSCH ...........................................................................................................................24
ALLGEMEINE INFORMATIONEN ....................................................................................................... 24
Hauptfunktionen............................................................................................................................. 24
Für Ihre Sicherheit: ........................................................................................................................ 25
Allgemeine Informationen:............................................................................................................. 26
Allgemeine Informationen zum Betrieb:......................................................................................... 26
Fernbedienung: ............................................................................................................................. 27
INSTALLATION .................................................................................................................................... 28
INSTALLATIONSANLEITUNG............................................................................................................. 29
HAUPTMENÜ....................................................................................................................................... 30
1. Programme:............................................................................................................................... 30
2. Bild............................................................................................................................................. 32
3. Sendersuche ............................................................................................................................. 33
4. Zeit............................................................................................................................................. 33
5. Option ........................................................................................................................................ 34
6. System....................................................................................................................................... 35
7. USB ........................................................................................................................................... 36
8. Hotkey ....................................................................................................................................... 38
FEHLERBEHEBUNG........................................................................................................................... 40
FRANÇAIS..........................................................................................................................42
INFORMATION GÉNÉRALE................................................................................................................ 42
Fonctions principales..................................................................................................................... 42
Pour votre sécurité : ...................................................................................................................... 43
Information générale :.................................................................................................................... 44
Fonctionnement général :.............................................................................................................. 44
Télécommande :............................................................................................................................ 45
INSTALLATION .................................................................................................................................... 46
GUIDE D'INSTALLATION .................................................................................................................... 47
MENU PRINCIPAL ............................................................................................................................... 48

3
1. Program :................................................................................................................................... 48
2. Image (Picture) .......................................................................................................................... 50
3. Recherche de canal................................................................................................................... 51
4. Heure (Time).............................................................................................................................. 51
5. Option ........................................................................................................................................ 52
6. Système..................................................................................................................................... 53
7. USB ........................................................................................................................................... 54
8. Touche de fonction..................................................................................................................... 56
DÉPANNAGE ....................................................................................................................................... 58
NEDERLANDS ...................................................................................................................59
ALGEMENE INFORMATIE .................................................................................................................. 59
Belangrijkste kenmerken ............................................................................................................... 59
Voor uw veiligheid:......................................................................................................................... 60
Algemene informatie:..................................................................................................................... 61
Algemene bediening:..................................................................................................................... 61
Afstandsbediening: ........................................................................................................................ 62
INSTALLATIE ....................................................................................................................................... 63
INSTALLATIEGIDS .............................................................................................................................. 64
HOOFDMENU ...................................................................................................................................... 65
1. Programma:............................................................................................................................... 65
2. Beeld ......................................................................................................................................... 67
3. Kanalen zoeken......................................................................................................................... 67
4. Tijd ............................................................................................................................................. 68
5. Optie .......................................................................................................................................... 69
6. Systeem..................................................................................................................................... 69
7. USB ........................................................................................................................................... 71
8. Sneltoets.................................................................................................................................... 73
PROBLEMEN OPLOSSEN.................................................................................................................. 74
ITALIANO............................................................................................................................76
INFORMAZIONI GENERALI................................................................................................................ 76
Caratteristiche principali ................................................................................................................ 76
Per la vostra sicurezza: ................................................................................................................. 77
Informazioni generali: .................................................................................................................... 78
Funzionamento Generale: ............................................................................................................. 78
Telecomando: ................................................................................................................................ 79
INSTALLAZIONE ................................................................................................................................. 80
GUIDA ALL'INSTALLAZIONE ............................................................................................................. 81
MENU PRINCIPALE............................................................................................................................. 82
1. Programma:............................................................................................................................... 82
2. Immagine................................................................................................................................... 84
3. Ricerca Canale .......................................................................................................................... 84
4. Ora............................................................................................................................................. 85
5. Opzione ..................................................................................................................................... 86
6. Sistema...................................................................................................................................... 86
7. USB ........................................................................................................................................... 88
8. Tasti veloci ................................................................................................................................. 90
RISOLUZIONE DEI PROBLEMI .......................................................................................................... 92
ESPAÑOL ...........................................................................................................................93
INFORMACIÓN GENERAL ................................................................................................................. 93

4
Características principales............................................................................................................. 93
Por su seguridad: .......................................................................................................................... 94
Información general:...................................................................................................................... 95
Funcionamiento general: ............................................................................................................... 95
Mando a distancia:......................................................................................................................... 96
INSTALACIÓN...................................................................................................................................... 97
GUÍA DE INSTALACIÓN...................................................................................................................... 98
MENÚ PRINCIPAL ............................................................................................................................... 99
1. Programa:.................................................................................................................................. 99
2. Imagen..................................................................................................................................... 101
3. Búsqueda de canales .............................................................................................................. 101
4. Hora......................................................................................................................................... 102
5. Opción ..................................................................................................................................... 103
6. Sistema.................................................................................................................................... 103
7. USB ......................................................................................................................................... 105
8. Tecla caliente........................................................................................................................... 107
PROBLEMAS Y SOLUCIONES......................................................................................................... 108
MAGYAR........................................................................................................................... 110
ÁLTALÁNOS ISMERTETŐ.................................................................................................................110
A készülék legfontosabb jellemzői................................................................................................110
Saját biztonsága érdekében: ........................................................................................................111
Általános ismertető: ......................................................................................................................112
Általános használat:......................................................................................................................112
A távirányító:.................................................................................................................................113
ÜZEMBEHELYEZÉS...........................................................................................................................114
ÜZEMBEHELYEZÉSI ÚTMUTATÓ .....................................................................................................115
FŐMENÜ .............................................................................................................................................116
1. Programme:..............................................................................................................................116
2. Kép ...........................................................................................................................................118
3. Csatornakeresés ......................................................................................................................118
4. Idő.............................................................................................................................................119
5. Opció ....................................................................................................................................... 120
6. Rendszer ................................................................................................................................. 120
7. USB ......................................................................................................................................... 122
8. Gyorsbillentyű.......................................................................................................................... 124
HIBAELHÁRÍTÁS .............................................................................................................................. 125
SUOMI...............................................................................................................................127
YLEISET TIEDOT............................................................................................................................... 127
Päätoiminnot................................................................................................................................ 127
Turvallisuusohjeet:....................................................................................................................... 127
Yleiset tiedot: ............................................................................................................................... 128
Yleiset käyttöohjeet: .................................................................................................................... 128
Kaukosäädin:............................................................................................................................... 129
ASENNUS .......................................................................................................................................... 130
ASENNUSOPAS ................................................................................................................................ 131
PÄÄVALIKKO .................................................................................................................................... 132
1. Program (Ohjelma): ................................................................................................................. 132
2. Picture (picture) ....................................................................................................................... 134
3. Channel search (kanavahaku)................................................................................................. 134
4. Time (kellonaika) ..................................................................................................................... 135
5. Option (valinnat) ...................................................................................................................... 136

5
6. System (järjestelmä)................................................................................................................ 136
7. USB ......................................................................................................................................... 138
8. Hotkey (monitoimintopainike) .................................................................................................. 140
VIANMÄÄRITYS ................................................................................................................................ 141
SVENSKA .........................................................................................................................143
ALLMÄNNA UPPGIFTER .................................................................................................................. 143
Huvudegenskaper ....................................................................................................................... 143
För din säkerhet:.......................................................................................................................... 143
Allmänna upplysningar: ............................................................................................................... 144
Allmän användning: ..................................................................................................................... 144
Fjärrkontroll:................................................................................................................................. 145
INSTALLATION .................................................................................................................................. 146
INSTALLATIONSANVISNINGAR ...................................................................................................... 147
MAIN MENU ....................................................................................................................................... 148
1. Program:.................................................................................................................................. 148
2. Bild........................................................................................................................................... 150
3. Kanalsökning ........................................................................................................................... 150
4. Tid............................................................................................................................................ 151
5. Alternativ.................................................................................................................................. 152
6. System..................................................................................................................................... 152
7. USB ......................................................................................................................................... 154
8. Kortkommando ........................................................................................................................ 156
FELSÖKNING .................................................................................................................................... 157
ČESKY ..............................................................................................................................159
VŠEOBECNÉ INFORMACE .............................................................................................................. 159
Hlavní vlastnosti .......................................................................................................................... 159
Pro vaši bezpečnost: ................................................................................................................... 159
Všeobecné informace:................................................................................................................. 160
Základní instrukce: ...................................................................................................................... 160
Dálkové ovládání: ........................................................................................................................ 161
INSTALACE........................................................................................................................................ 162
INSTALAČNÍ PRŮVODCE ................................................................................................................. 163
HLAVNÍ NABÍDKA ............................................................................................................................. 164
1. Program:.................................................................................................................................. 164
2. Obraz....................................................................................................................................... 166
3. Vyhledávání kanálů................................................................................................................. 166
4. Čas .......................................................................................................................................... 167
5. Volby........................................................................................................................................ 168
6. Systém..................................................................................................................................... 168
7. USB ......................................................................................................................................... 170
8. Rychlá klávesa ........................................................................................................................ 172
ŘEŠENÍ PROBLÉMŮ......................................................................................................................... 173
ROMÂNĂ..........................................................................................................................175
INFORMAŢII GENERALE.................................................................................................................. 175
Funcţii principale.......................................................................................................................... 175
Pentru siguranţa dumneavoastră: ............................................................................................... 176
Informaţii generale:...................................................................................................................... 177
Funcţionare generală:.................................................................................................................. 177
Telecomandă: .............................................................................................................................. 177

6
INSTALARE........................................................................................................................................ 178
MANUAL DE INSTALARE ................................................................................................................. 180
MAIN MENU (MENIUL PRINCIPAL).................................................................................................. 180
1. Program:.................................................................................................................................. 180
2. Imagine.................................................................................................................................... 182
3. Căutare canale ........................................................................................................................ 183
4. Oră........................................................................................................................................... 184
5. Opţiune .................................................................................................................................... 184
6. Sistem...................................................................................................................................... 185
7. USB ......................................................................................................................................... 186
8. Tastărapidă............................................................................................................................. 188
REZOLVAREA PROBLEMELOR....................................................................................................... 190
ΕΛΛΗΝΙΚA........................................................................................................................191
ΓΕΝΙΚΕΣ ΠΛΗΡΟΦΟΡΙΕΣ................................................................................................................. 191
Βασικά χαρακτηριστικά ................................................................................................................ 191
Για την ασφάλειά σας:.................................................................................................................. 192
Γενικές πληροφορίες: .................................................................................................................. 193
Γενική λειτουργία: ........................................................................................................................ 193
Τηλεχειριστήριο:........................................................................................................................... 194
ΕΓΚΑΤΑΣΤΑΣΗ .................................................................................................................................. 195
Ο∆ΗΓΟΣ ΕΓΚΑΤΑΣΤΑΣΗΣ ................................................................................................................ 196
ΒΑΣΙΚΟ ΜΕΝΟΥ ................................................................................................................................ 197
1. Program (Πρόγραμμα):............................................................................................................ 197
2. Picture (Εικόνα) ....................................................................................................................... 199
3. Channel search (Αναζήτηση καναλιών)................................................................................... 200
4. Time (Ώρα)............................................................................................................................... 201
5. Option (Επιλογή) ..................................................................................................................... 201
6. System (Σύστημα) ................................................................................................................... 202
7. USB ......................................................................................................................................... 203
8. Πλήκτρο συντόμευσης............................................................................................................. 205
ΑΝΤΙΜΕΤΩΠΙΣΗ ΠΡΟΒΛΗΜΑΤΩΝ ................................................................................................... 207
DANSK..............................................................................................................................209
GENERELLE OPLYSNINGER........................................................................................................... 209
Vigtigste egenskaber ................................................................................................................... 209
Af hensyn til din sikkerhed:.......................................................................................................... 209
Generelle oplysninger:................................................................................................................. 210
Generel brug:............................................................................................................................... 210
Fjernbetjening:..............................................................................................................................211
INSTALLATION .................................................................................................................................. 212
INSTALLATIONSVEJLEDNING: ....................................................................................................... 213
HOVEDMENU .................................................................................................................................... 214
1. Program:.................................................................................................................................. 214
2. Billede...................................................................................................................................... 216
3. Kanalsøgning........................................................................................................................... 216
4. Tid............................................................................................................................................ 217
5. Valgmulighed ........................................................................................................................... 218
6. System..................................................................................................................................... 218
7. USB ......................................................................................................................................... 220
8. Hotkey ..................................................................................................................................... 222
FEJLFINDING .................................................................................................................................... 223

7
NORSK..............................................................................................................................225
GENERELL INFORMASJON............................................................................................................. 225
Hovedfunksjoner.......................................................................................................................... 225
For din sikkerhets skyld: .............................................................................................................. 225
Generell informasjon: .................................................................................................................. 226
Generelt om drift:......................................................................................................................... 226
Fjernkontroll:................................................................................................................................ 227
INSTALLASJON................................................................................................................................. 228
INSTALLASJONSVEILEDNING ........................................................................................................ 229
HOVEDMENY..................................................................................................................................... 230
1. Program:.................................................................................................................................. 230
2. Bilde......................................................................................................................................... 232
3. Kanalsøk.................................................................................................................................. 232
4. Tid............................................................................................................................................ 233
5. Alternativer............................................................................................................................... 234
6. System..................................................................................................................................... 234
7. USB ......................................................................................................................................... 236
8. Snarveier ................................................................................................................................. 238
FEILSØKING...................................................................................................................................... 239
РУССКИЙ .........................................................................................................................241
ОБЩАЯ ИНФОРМАЦИЯ.................................................................................................................. 241
Основные функции .................................................................................................................... 241
Для вашей безопасности:.......................................................................................................... 242
Общая информация: ................................................................................................................. 243
Общие указания по эксплуатации: ........................................................................................... 243
Пульт дистанционного управления:.......................................................................................... 244
Установка .......................................................................................................................................... 245
ИНСТРУКЦИЯ ПО УСТАНОВКЕ ...................................................................................................... 246
ГЛАВНОЕ МЕНЮ.............................................................................................................................. 247
1. Program:.................................................................................................................................. 247
2. Picture (Изображение) ........................................................................................................... 249
3. Поиск канала.......................................................................................................................... 249
4. Time (Время)........................................................................................................................... 250
5. Option (Опция)........................................................................................................................ 251
6. System..................................................................................................................................... 251
7. USB ......................................................................................................................................... 253
8. «Горячие» главиши ................................................................................................................ 255
УСТРАНЕНИЕ НЕИСПРАВНОСТЕЙ ............................................................................................... 257

8
ENGLISH
FULL HD FTA RECEIVER
GENERAL INFORMATION
This Digital Terrestrial Receiver (DTR) will bring you into the new and exciting world of digital television
world of crystal clear widescreen pictures, digital sound, more information and new services. All this
and more is on “Free to Air” digital television.
To make full use of your new DTR, please take the time to familiarise yourself with the extensive
features of the unit detailed in this User's Guide.
If you need help in setting up please call your retailer or a customer service adviser.
Main Features
• SD MPEG-2/HD H.264 & fully DVB-T compliant
• Automatic PAL/NTSC conversion
• 1000 channels TV and Radio programmable
• 8 different favourite group selections
• Multi-lingual On Screen Display
• Fully supports 7 days Electronic Program Guide (EPG)
• Picture in Graphics (PIG) support
• 256 colours On Screen Display
• Channel search in automatic and manual search
• Various channel editing functions (favourite, move, lock, rename and sort)
• Parental control for channels
• Easy to use Menu System
• Software upgrades through USB port
• Time set by GMT offset automatically and manually, summer time support
• Automatic turn on/off by Timer setting (multiple options)
• Subtitle support DVB EN300743 and EBU
• Teletext support DVB ETS300472 by VBI and OSD
• Automatic save for the last channel
• Support Logic Channel Number (LCN)
• Support FAT16/FAT32/FAT12,NTFS (Option)
• MP3/ JPEG/ BMP/ OGG files
• Default 2 hours, user can setting the end time (Support subtitle), record scramble program and
descramble program
• Lock/Delete/Rename, Preview playback, Browse record files information
• Play/Pause/Stop
• Fast Forward/Fast Backward 2/4/8/16/32
For your safety:
To avoid the risk of electric shock, do not open the
cabinet, refer to qualified personnel only.
Keep the receiver away from flower vases, tubs,
sinks etc. in order to avoid damaging the
equipment.

9
Do not expose the receiver to sunlight and keep it
away from any heat source.
Do not block the ventilation holes of the receiver
so that air can circulate freely.
When this occurs you must cut off the power
immediately.
Do not touch the receiver during thunderstorms,
since that may create electric shock hazards.
Switch the receiver off whenever it will be out of
service for an extended period.
Be sure to turn the receiver off and disconnect the
power before cleaning. Only use mild soapy water
and wring out the cloth thoroughly.
General information:
1 Remote control 2x AAA batteries 1 user manual
General Operation:
Throughout this manual you will notice that the everyday operation of the receiver is based on a series
of user friendly on screen displays and menus. These menus will help you get the most from your
receiver, guiding you through installation, channel organising, viewing and many other functions.
All functions can be carried out using the buttons on the RCU, and some of the functions can also be
carried out using the buttons on the front panel.
The receiver is easy to use, always at your command and adaptable for future upgrades.

10
Please be aware that new software may change the functionality of the receiver.
Should you experience any difficulties with the operation of your receiver, please consult the relevant
section of this manual, including the Trouble Shooting secton. If this does not have the desired effect,
please call your dealer or a customer service adviser.
Remote control:
Key: Function:
Turns power ON/OFF
Mute sound
To select the number of the menu or the channel to
watch
Switch between TV and radio
SHIFT Time shift function key
FAV Displays the favourite group list
FIND Displays the “FIND” window
INFO Show information
MENU Press once to run MENU on screen
Moves up/down a page in the list
Switch back to the previous channel
OK/LIST Executes the selected item in the menu screen or
enters the desired value in any input mode.
PR+, PR- Channel up/down or move up/down in a menu.
To adjust the volume or move left/right in the menu.
Return to the previous menu or escape from the
menu.
Call the Electronic Program Guide (EPG)
Displays the audio window
Switch the video between current video mode and
YUV 576i
Change the HD format
Switch to teletext mode
Switch to subtitle mode
Enter sleep mode
Record the program
Play
Stop
Pause and resume play
Fast forward or rewind
Previous and next

11
INSTALLATION
Rear panel:
Connecting to TV using SCART support:
CONNECT TO DIGITAL AMPLIFIER
POWER CABLE
CONNECT TO TV USING A SCART CABLE
CONNECT TO TV’S HDMI INPUT
CONNECT TO USB DEVICE
ANT IN: CONNECT TO ANTENNA
LOOP: CONNECT TO ANOTHER RECEIVER
Antenna
DTR
TV

12
Connecting to digital amplifier
INSTALLATION GUIDE
When powering on for the first time, the Installation Guide will display as below.
Press PR+ and PR−to move the highlighted bar to select
OSD language, Country and Channel Search.
Press to move the cursor to choose your choice.
Move the highlighter to the Channel Search option and
press OK to search channels
Press [EXIT] to exit this menu.
DIGITAL AUDIO
CONVERTOR OR
AMPLIFIER
Antenna
DTR
SPEAKER

13
MAIN MENU
When you press [MENU], you enter the Main Menu.
This menu consists of 7 major sub-menus as follows.
- Program
- Picture
- Channel Search
- Time
- Option
- System
- USB
1. Program:
This menu consists of 4 major sub-menus as follow:
- Program edit
- EPG
- Sort
- LCN
1.1 Program edit
Press OK to pop up the “Input Password” dialogue box. You
cannot open into the menu unless the correct password is
input. The default password is “000000”.
1. Press PR+, PR−keys to select the programme that you
want to play, and then press OK to view the programme
in the small window. If you move the yellow cursor to
select up or down, you will see a gray line which
indicates the playing program in the small window.
2. Select the program and press FAV to pop up the
favourite type list. In the list, select the favourite type that
you want and press OK, and then you will find the
favourite icon is displayed to the right of the selected
program.
Select Disable in favourite type list to remove all the
favourite types you selected, and the favourite icon will
disappear behind the programme.
3. Select the program and press the yellow key to mark this
program with the Lock icon. You can cancel this icon by
pressing the yellow key once more.

14
4. Select the programme and press the green key to mark
this program with the skip icon. You can cancel this mark
by pressing the green key once more.
5. Select the program and press the blue key to pop up a
warning dialogue box: “Do you want to delete this?”
Press OK to delete it and press EXIT to cancel.
6. Press to pop up the rename window. Press
to move the cursor left or right to select the
characters.
1.2 EPG
You can find information for a programme in the EPG
window. Programmes are in the left side list and details of
the program are shown on the right side. At the bottom of
the window you can see the function keys.
Press the blue key to page up in the program list. Press the
yellow key to page down in the program list. Press the
green key to page up in the detail list and press the red key
to page down in the detail list.
Press OK to select the program. You can see the
programme you selected in the book list.
In EPG mode you can press INFO to enter the booking list.
All the programmes you booked will be in the schedule.
Press the red key to add a programme to the booking list,
and press the green key to edit the programme. Press the
blue key to delete the programme.
Press EXIT to exit the booking list window.

15
1.3 SORT
Select by service ID, LCN, ONID or service name.
1.4 LCN
Select between On and Off.
2. Picture
This menu consists of 4 major sub-menus as follows:
- Aspect Ratio
- Resolution
- TV Format
- Video Output
2.1 Aspect Ratio
Select between 16:9 Pillar Box, 16:9 Pan&Scan, 4:3 Letter Box, 4:3 Pan&Scan, 4:3 Full, 16:9 Wide
Screen and Auto.
2.2 Resolution
Select between 1080i, 1080p, 576i, 576p, 480i and 720p.
2.3 TV Format
Select between PAL and NTSC.
2.4 Video Output
Select between CVBS and RGB.
3. Channel search
This menu consists of 4 major sub-menus as follows:
- Auto Search
- Manual Search
- Country
- Antenna Power
3.1 Auto search
Press OK on Auto Search to search channels. For the first
searching, all searched TV channels and radio channels
will be displayed on the list in order. Through one colour bar
at the bottom of the search window, users can know the
searching progress of the current channel. The TV and
Radio Channels you searched will be shown in the list, you
can know the number of programmes at the top of the
window. During the search, you can press EXIT to cancel.
After searching, press EXIT to return to the normal mode.

16
3.2 Manual search
Frequency channel: Press to select the
channel.
Frequency: Press the number key to input.
Bandwidth: Press to select between 6, 7 and
8M.
Through two colour bars at the bottom of the search
window, users can see the signal quality and strength of the
current channel.
After setting, press OK to enter the searching window.
3.3 Country
Press to select the country.
3.4 Antenna power
Select On or Off.
4. Time
There are 5 sub-menus in this menu
- Time Offset
- Country region
- Time zone
- Sleep
- Power On/Off
Select between Auto and Manual. If you select Auto, the
time zone item will turn grey. If you select Manual, you can
edit the time zone item, but the country region item will turn
grey.
4.2 Country Region
Press to select.
4.3 Time zone
Press to select from GMT-12 to GMT+12
4.4 Sleep
Press to select among Off, 1 hour or 12 hours.
4.5 Power On/Off
Power On/Off: Select Disable or Enable. When selecting
Enable you can edit Power On/Off Time by pressing the
number keys.
Power On/Off Time: Press the number key to input.

17
5. Option
There are 5 sub-menus in this menu
- OSD Language
- Subtitle Language
- Audio Language
- Digital Audio
- Audio Description
5.1 OSD language
Press to select the language in the circle.
5.2 Subtitle language
Press to select the language in the circle.
5.3 Audio language
Press to select the language in the circle.
5.4 Digital audio
Press to select between PCM/, RAW/HDMI RAW, RAW/HDMI PCM and Off.
5.5 Audio description
Select from 1-31 and Off.
6. System
There are 5 sub-menus in this menu.
- Parental Guidance
- Set Password
- Restore Factory Default
- Information
- Software update
6.1 Parental guidance
The consumer can select an age from 4-18 or Off.

18
6.2 Set password
Input the old password: Input the password by pressing
the number keys 0-9.
Input the new password: Input the password by pressing
the number keys 0-9.
Confirm the new password: Press the number keys 0-9 to
input the new password again.
Note: The default password is: 000000. Please record your
new password. If your new password is lost, please contact
your service provider.
6.3 Restore factory default
Choose the option of Restore Factory Default and press [OK] to restore.
Press [OK] to start and press [EXIT] to quit.
Note: Please use this function carefully.
6.4 Information
When you enter the Information menu, the screen displays
the receiver information, such as model, SW version and so
on.
Press [EXIT] to leave this menu.
6.5 Software upgrade
There are 2 Update modes: OTA update and USB update.
6.5.1 OTA upgrade
1. Status: Select between On and Off. If you select Off, the
Start Time turns grey.
2. Start Time: Select between 00:00 to 23:00.
6.5.2 USB upgrade
Press OK to upgrade through a USB Device.

19
7. USB
This menu has 5 sub-menus such as: Multimedia, Photo
Configuration, Movie Configuration, PVR configuration
and Record.
7.1 Multimedia
There are 4 sub-menus in this menu.
- Music
- Photo
- Movie
- PVR
These menus will be disabled when no USB device is
plugged in.
7.1.1 Music
Press OK to enter the Music window. Press PR+, PR- to
move the cursor up and down. Press to go back to
the folder. Select the music and press OK to play it. Press
and to play or pause and press to stop playing.
7.1.2 Photo
Select the picture and press to enter the slide show
mode.
Press the blue key to enter grid show mode. In this mode,
select the picture and press the OK to see it in full screen.
7.1.3 Movie
Select the movie you want to watch and press the red key
to enter full screen mode.

20
7.1.4 PVR
In normal mode, press the RECORD on RCU, then
will appear on the screen. It means you are
recording the program now.
Press “■” and a dialogue box will pop up: “Do you want to
stop recording?” Press OK to stop recording and save it or
press EXIT to continue recording.
If you choose to stop recording, the program you recorded
will be added to the PVR RECORD folder in PVR submenu.
In PVR menu you can see the programme you recorded.
Press the red key to switch to full screen mode and press
the exit key to go back to preview mode. Press the yellow
key to delete the program. Press the green key to rename
the program. Press OK or ►to play the programme. Press
■to stop playing.
Press to fast forward or rewind.
7.2 Photo configuration
1. Slide time: select between 1 s – 8 s.
2. Slide mode: Select between 0 – 59 or random.
3. Aspect ratio: Select between keep and discard.
7.3 Movie configuration:
1. Subtitle specific: Select normal, big or small.
2. Subtitle background: Select transparent, grey, white,
and yellow green.
3. Subtitle font color: Select red, white, black, blue or
green.
7.4 PVR configuration
1. Record device: Here you see the information of the USB
device
2. Format: Press OK to format the disk.
8. Hotkey
8.1 Number
Use the numeric keys (0-9) to input the number of the desired channel. If the input number is beyond
the valid channel number, the system will read “Invalid number”, press OK to close this message.
