Sagem ITD 5510 User manual

1
Technology in action
ITD 5510
DIGITAL
TERRESTRIAL
TV RECEIVER
USER
MANUAL
ENGLISH
S
1Couv.p65 10/12/02, 09:521

3
BLEU PANTONE 293C
CONTENTS
CONGRATULATIONS!
This new generation of Set Top Box gives you access to new digital services and
makes it easy for you and your family to choose the very best experiences of
Digital TV.
Once you have connected your Set Top Box and ad usted it according to your
preference, you can en oy all the services
You can update your Set Top Box through the satellite stream as new functions and
services become available.
SAGEM Set Top Box operates a policy of continuous development. Therefore we
reserve the right to ma e changes and improvements to any of the products
described in this manual without any prior notice.
The EMC Directive 89/336/EEC is applied to this product.
SAGEM is a registred trademark of SAGEM SA
Copyright © SAGEM SA
All rights reserved
Ch00.p65 10/12/02, 09:523

4
BLEU PANTONE 293C
CONTENTS
1. GENERAL INFORMATION........................................................................................................... 6
1-1 Safety .................................................................................................................................... 6
1-2 Packing list ............................................................................................................................ 6
1-3 Connection to the mains supply ............................................................................................ 6
2. GENERAL DESCRIPTION ........................................................................................................... 7
2-1 Front panel description .........................................................................................................
2-2 Rear panel description .......................................................................................................... 8
2-3 Remote Control Unit ............................................................................................................. 8
2-3-1 Batteries installation ..................................................................................................... 8
2-3-2 RCU operation .............................................................................................................9
2-3-3 Smart card ................................................................................................................. 10
2-3-3-1 Subscription smart card and banking card .................................................... 10
3. CONNECTIONS .......................................................................................................................... 11
3-1 Introduction ......................................................................................................................... 11
3-2 Connection to TV set, VCR and antenna ............................................................................ 11
3-3 Hi-Fi amplifier ...................................................................................................................... 12
4. SET TOP BOX INSTALLATION ................................................................................................. 13
4-1 Preliminary .......................................................................................................................... 13
4-2 Channels installation with scanning .................................................................................... 14
4-3 Network status .................................................................................................................... 15
4-4 Favourite lists installation .................................................................................................... 16
4-5 Audio/video installation ....................................................................................................... 1
4-5-1 TV .............................................................................................................................. 1
4-5-2 VCR ........................................................................................................................... 1
4-6 Language setting ................................................................................................................ 18
4-5-3 Modulator ................................................................................................................... 18
4- Time setting ........................................................................................................................ 18
4-8 Change protection code ......................................................................................................19
Ch00.p65 10/12/02, 09:524

5
BLEU PANTONE 293C
CONTENTS
5. USING YOUR SET TOP BOX ..................................................................................................... 20
5-1 Changing channels and lists ............................................................................................... 20
5-1-1 Switching channels .................................................................................................... 20
5-1-2 Info zapping ............................................................................................................... 20
5-1-3 Quick return key ( ) ................................................................................................. 20
5-2 Info programme screen .......................................................................................................21
5-2-1 Summary of the current programme .......................................................................... 21
5-2-2 Bargraph indicator ..................................................................................................... 21
5-2-3 Total length of the current programme ....................................................................... 21
5-2-4 Short summary of the next programme ..................................................................... 21
5-2-5 Number of broadcasted audio languages .................................................................. 22
5-2-6 Change current audio language played ..................................................................... 22
5-2- Name of the current channel ..................................................................................... 22
5-2-8 Name of the current programme ................................................................................ 22
5-2-9 Reference of current favourite list .............................................................................. 22
5-2-10 Number of current channel ...................................................................................... 22
5-2-11 Navigator function .................................................................................................... 22
5-2-12 Summary of the next programme ............................................................................ 23
5-2-13 Transparency ........................................................................................................... 23
5-3 List of channels ................................................................................................................... 23
5-4 User preferences (appearance preferences) ...................................................................... 24
5-5 Locking ............................................................................................................................... 25
5-6 Changing audiotrack and subtitles on a current channel ..................................................... 25
5- Volume adjustment ............................................................................................................. 26
5-8 TV/SAT/VCR mode .............................................................................................................26
5-9 Timer programming............................................................................................................. 26
5-10 Conditional access ............................................................................................................ 2
5-10-1 Smart card code protection ...................................................................................... 2
5-10-2 Subscription information .......................................................................................... 28
5-10-3 PIN code modification .............................................................................................. 29
5-10-4 Conditional access messages ................................................................................. 30
5-11 Guide mode ....................................................................................................................... 30
5-12 Set Top Box enhancement ................................................................................................ 31
5-13 Troubleshooting ................................................................................................................ 32
5-14 Outline specifications ........................................................................................................ 33
Ch00.p65 10/12/02, 09:525

6
BLEU PANTONE 293C
1. GENERAL INFORMATION
1. Gene al info mation
1-1 SAFETY
In order to keep your Set Top Box high performance, it should:
xbe located in an indoor place to protect it from lightning, rain and direct sunlight,
xbe located in a dry and well-ventilated place,
xbe protected from damp,
xbe installed in a way to avoid violent shocks,
xbe plugged directly into the mains with the cords provided with the Set Top Box. The use of an
extension cord is not recommended,
xdo not place anything on top of your Set Top Box to permit ventilation.
Be ca eful
xA contact with a liquid would lead to deterioration of your Set Top Box, which could cause failure.
Never open your Set Top Box, in case of technical problem contact qualified service personnel.
xLike any electronic device, the Set Top Box contains fragile components. It should thus be
installed in a place where it is unlikely to fall and out of reach of children.
xThe case of the Set Top Box can be cleaned with a soft and dry cloth. Do not use any type of
abrasive pad, scouring powder nor solvents, such as alcohol or turpentine, as they could damage
the surface of the case.
xThe Set Top Box must be disconnected from mains supply (from wall socket or rear panel) before
any modification of connection between TV, VCR or antenna. Take care to provide free access
to mains plug and socket.
xDo not forget to put the batteries inside the remote control unit.
1-2 PACKING LIST
Your Set Top Box is delivered with the following components :
xa remote control unit,
x2 batteries (R6) for the remote control unit,
xa scart cord for connection to the TV set,
xa power cord,
xthis user’s manual,
xan RF cord.
1-3 CONNECTION TO THE MAINS SUPPLY
The Set Top Box must be connected by the power cord to a 220-240V wall socket. Turn on the mains
power on the wall.
Ch01.p65 10/12/02, 09:526

7
BLEU PANTONE 293C
GENERAL DESCRIPTION .2
2. Gene al desc iption
2-1 FRONT PANEL DESCRIPTION
GreenDoor Red
Stand-by and switch on key.
Programme changing key.
Red LED(*) Stand-by mode.
Green LED Reception of commands from remote control.
4 digit front panel display
B
C
A
A: for the subscription smart card
B: not used
C: not used
Ch02.p65 10/12/02, 09:527

8
BLEU PANTONE 293C
2. GENERAL DESCRIPTION
2-2 REAR PANEL DESCRIPTION
A - 220-240V 50Hz power supply socket (**)
B - Socket for Serial Data Port
C - IEC 958 connector for optical connection to HI-FI audio
D - Socket for connection to video devices (*)
E - Socket for connection to HI-FI audio, left channel (*)
F - Socket for connection to HI-FI audio, right channel (*)
G - Scart socket for connection to the TV set (*)
H - Scart socket for connection to the VCR (*)
I - Terrestrial network input (*)
J - RF output for TV (*)
(*) : Security electric low voltage
(**) : Excessive voltage
2-3 REMOTE CONTROL UNIT
2-3-1 Batte ies installation
The remote control unit requires two R6 batteries for operation.
The diagram inside the battery compartment will show you how to insert the batteries.
Wa ning: Only use the appropriate batteries, according to the manufacturer specifications
(see "Specifications" section on page 33). The provided batteries are not
rechargeable. Bring back the defective or empty batteries to your local waste
disposal in accordance with the current regulations. Do not dispose of used
batteries in your dustbin.
FH IJDCBA EG
Ch02.p65 10/12/02, 09:528

9
BLEU PANTONE 293C
GENERAL DESCRIPTION .2
2-3-2 RCU operation
KEY FUNCTION
Stand-by
Red Color function key
Green Color function key
Yellow Color function key
Blue Color function key
Left
Right
Down
Up
OK
Confirm
Return
X
xit
iInformation
Guide
Menu
Change page in events
Change page in events
Not used
Not used
Not used
-
Audio Volume -
+
Audio Volume +
P+
Next programme
P-
Previous programme
Teletext
Not used
TV/VCR
Audio Mute
0-9 Numerical keys
OK
X
P-
P+
i
-+
0
456
789
123
@
/
&
a
b
c
d
e
f
g
h
i
j
k
l
m
n
o
p
q
r
s
t
u
v
w
x
y
z
Be sure to point the remote control unit directly towards the Set Top Box.
Ch02.p65 10/12/02, 10:119

10
BLEU PANTONE 293C
2. GENERAL DESCRIPTION
2-3-3 Sma t ca d
2-3-3-1 Subscription smart card and banking card
If your programmes are transmitted with an access control, your card must be inserted in the smart card
reader. In order to avoid loss or damage, this card should never be removed from the unit.
To insert the card, open the door located on the left side of the front panel and insert your card, microchip
facing up in the slot.
B
C
A
Card reader A for subscription
Note:
xNever extract or insert your card unnecessarily.
xDo not bend your card.
xDo not clean your card with a liquid of any kind.
Ch02.p65 10/12/02, 09:5210

11
BLEU PANTONE 293C
CONNECTIONS .3
3. Connections
3-1 INTRODUCTION
There are several ways of connecting the Set Top Box to your audio/TV system. Some of the methods
enable you to listen to music in stereo sound of CD like quality.
Consult your local supplier for assistance in setting up an audio/video configuration best suited to your
unique requirements.
Wa ning:
Disconnect the Set Top Box from the mains before connecting or disconnecting any device to it.
3-2 CONNECTION TO TV SET, VCR AND ANTENNA
Only connect your satellite antenna when the Set Top Box is unplugged.
The Set Top Box connects directly to your TV by a scart connector which includes RGB signals to
garantee optimum image quality. Connect the supplied scart cable between the TV scart connector of
the Set Top Box and the main scart connector of the TV (the one with 3 points indicating that RGB
provision is available).
Then connect the Set Top Box (VCR scart connector) to your VCR (main cart connector on the VCR).
The scart cord is not supplied.
Terrestrial
antenna
VIDEO
(not supplied)
RF inRF in RF out
(not supplied)
Ch03.p65 10/12/02, 09:5211

12
BLEU PANTONE 293C
3. CONNECTIONS
3-3 HI-FI AMPLIFIER
Hi-Fi amplifier (Digital-Optical input) Hi-Fi amplifier (analog input)
You can connect your Set Top Box to your Hi-Fi amplifier (standard, with equalizer or even better,
Prologic) to obtain excellent listening comfort comparable to those of audio programmes.
Volume adjustment is possible directly from your Set Top Box.
Ch03.p65 10/12/02, 09:5212

13
BLEU PANTONE 293C
SET TOP BOX INSTALLATION .4
4. Set Top Box installation
HUVUDMENY
KANALLISTA
INSPELNINGSTIMER
INFORMATION
INSTALLATION
FLYTTA
TILLBAKA X
AVSLUTA
Use the arrow key to move down to the INSTALLATION
line and press
OK
to confirm.
Access to the installation menus is protected by a secret
installation code to avoid any inadvertent misadjustment. Your
Set Top Box is supplied with default code 1234.
Note: you will not be prompted to enter any code as long as the
installation code is 0000.
INSTALLATION
ANGE ER INSTALLATIONSKOD
OCH BEKRÄFTA MED OK KNAPPEN
- - - -
TILLBAKA X
AVSLUTA
OK
BEKRÄFTA
Enter your code.
As soon as each value is entered, the segment is replaced by
a star.
Using the arrow key of the remote control unit, you can come
back to a value that has already been entered and modify it
provided the code has not been confirmed by
OK
.
After entering the four digits press
OK
to confirm.
INSTALLATION
ANGE ER INSTALLTIONSKOD
OCH BEKRÄFTA MED OK KNAPPEN
FEL KOD
BÖRJA OM
- - - -
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
An error message will be displayed if the code you have entered
is not correct.
4-1 PRELIMINARY
Your Set Top Box is supplied ready to use for a standard configuration.
TV : 4/3 format, RGB, stereo sound
VCR : PAL, stereo sound
Access to the installation screens shown below will enable you to adapt your Set Top Box to your
favourite equipment.
Generally, access to the screens is obtained by pressing the key (Menu).
You can memorise your selections by pressing the
OK
key.
Return to the previous screen by pressing the key (Return).
Exit from all the screens by pressing the
X
key (Quit).
Ch04.p65 10/12/02, 09:5213

14
BLEU PANTONE 293C
4. SET TOP BOX INSTALLATION
4-2 CHANNELS INSTALLATION WITH SCANNING
This installation will complete list A with all the channels fournd during the scanning of all the frequencies.
This list is a summary of all the channels and will not be modified. It will be possible to create personal
lists based on this reference list (see chapter 4.5).
BOX INSTÄLLNINGAR
KANALSÖKNING
TV OCH VIDEOBANDSPELARE
MOTTAGARENS STATUS
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
KANALSÖKNING
STARTA KANALSÖKNING
ÖNSKAR NI STARTA KANALSÖKNING?
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
KANALSÖKNING
X
AVS L UTA
Söker... TV-kanaler funna
0000
482 MHz
0% 100%
KANALSÖKNING
Klar TV-kanaler funna
0020
482 MHz
0% 100%
FLYTTA
OK
BEKRÄFTA
Sökningen är klar
LAGRA LISTAN?
JA NEJ
Press
OK
to search.
Press
OK
to confirm.
An indicator at the bottom of the screen will indicate the
percentage of the scanned frequencies band.
The current frequency found is displayed in real time.
A message at the end of the scanning process will ask you to
memorise. Press
OK
.
You can cancel the scanning process at any time by pressing
the
X
key.
You can memorise or not.
Ch04.p65 10/12/02, 09:5214

15
BLEU PANTONE 293C
SET TOP BOX INSTALLATION .4
4-3 NETWORK STATUS
At any time you can check the newtork status
Press
OK
to confirm.
BOX INSTÄLLNINGAR
KANALSÖKNING
TV OCH VIDEOBANDSPELARE
MOTTAGARENS STATUS
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
MOTTAGARENS STATUS
OFDM Synk JA
FFT Synk JA
Frekvens Synk JA
TPS Synk JA
VITERBI Synk JA
BER < 1.0 E-8
Center frekvens offset 0 KHz
Signal till brus 27 dB
TILLBAKA X
AVS L UTA
Technical parameters are displayed for information.
Ch04.p65 10/12/02, 09:5215

16
BLEU PANTONE 293C
4. SET TOP BOX INSTALLATION
4-4 FAVOURITE LISTS INSTALLATION
This function will enable you to make up a FAVOURITE list of the TV or radio type from the reference
list A (built from provider (transponder) installation or a scanning) and erase it entirely to reconstruct a
new one.
SKAPA FAVORITLISTOR
LISTA B
Tom lista
Ändra i lista
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
CREATION
Two lists are displayed simultaneously.
xThe list on the right side is the reference list (issued
from transponder or scanning installation).
xThe list on the left side is the list under construction.
Use the and keys of the remote control unit to move
from one list to another.
Use the and keys of the remote control unit to
move through a list. To improve navigation inside a list, you
can enter directly the number of a channel, and the index will
go directly on it.
1 TEST 2
2 Dïravelo ylHC
3 SVC10
4 SVC11
5 SVC12
6 SVC13
7 SVC14
8 SVC15
9 SVC16
10 SVC17
Favoritlista B Nätlista
Radera Lagra
Infoga Lägg till
FLYTTA
TILLBAKA X
AVSLUTA
To copy a channel from list A to favourite list (B to H), place the index on the programme to be transferred
and press the blue key. Restart as many times as necessary.
At the end of creation, memorise using the yellow key.
MODIFICATIONS
At any moment, yo can modify your favourite list (B to H).
xTo erase, place the index on the channel to be erased and press the red key.
Memorise at the end of creation using the yellow key.
xTo insert a new channel from main list A (for example if you have forgotten to put it in number 5).
Move the index in the list A (all channels), select it by pressing the green key (the index moves to the
favourite list).
Move the index in your favourite list up to the channel just after the number where you want to insert
(example 6), press the green key.
xTo move a channel from one place to another in a favourite list, delete it and then insert it from
the main list to the place you want.
Ch04.p65 10/12/02, 09:5216

17
BLEU PANTONE 293C
SET TOP BOX INSTALLATION .4
Press
OK
for access to this menu.
4-5 AUDIO/VIDEO INSTALLATION
BOX INSTÄLLNINGAR
KANALSÖKNING
TV OCH VIDEOBANDSPELARE
MOTTAGARENS STATUS
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
TV OCH VIDEOBANDSPELARE
TV-FORMAT 4/3 Letter box
RGB LJUSSTYRKA SVAG
VIDEOBANDSPELARSTD PAL
SLÅAV RGB TILL TV-N NEJ
MODULATOR JA
UTGÅNGSSTANDARD PAL B/G
UTGÅANGSKANAL 43
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
4-5-1 TV
TV OCH VIDEOBANDSPELARE
TV-FORMAT 4/3 Letter box
RGB LJUSSTYRKA SVAG
VIDEOBANDSPELARSTD PAL
SLÅAV RGB TILL TV-N NEJ
MODULATOR JA
UTGÅNGSSTANDARD PAL B/G
UTGÅANGSKANAL 43
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
4-5-2 VCR
After a final check, press
OK
to memorise the settings.
Press (Return) to continue installation or
X
(Quit) to terminate.
A number of choices are available.
Scroll through the choices using the or arrow keys.
xTV format 4/3, 16/9 or letter box.
xRGB brightness level high or low.
xRGB standard yes or no.
A number of choices are available.
Scroll through the choices using the or arrow keys.
xPAL or SVHS standard
If you have chosen PAL or SVHS, the TV composite
video standard will be PAL. Mono or stereo sound.
Ch04.p65 10/12/02, 09:5217

18
BLEU PANTONE 293C
4. SET TOP BOX INSTALLATION
4-5-3 Modulato
TV OCH VIDEOBANDSPELARE
TV-FORMAT 16/9
RGB LJUSSTYRKA STARK
VIDEOBANDSPELARSTD PAL
SLÅAV RGB TILL TV-N NEJ
MODULATOR JA
UTGÅNGSSTANDARD PAL B/G
UTGÅANGSKANAL 43
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
If you want to adjust the channel for an another TV set:
xdirectly access the menu,
xchoose the channel (21 to 69) by entering the number,
xverify that the VCR standard is PAL,
xchoose the standard of your country (B/G, I or K).
The channel is factory-set to 43.
4-6 LANGUAGE SETTING
ANVÄNDAR INSTÄLLNINGAR
SPRÅKINSTÄLLNING
ANVÄNDARINSTÄLLNING
FAVORITLISTA
LÅSA KANALER
BYTE AV INSTALLATIONSKOD
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
Press
OK
for access to various configurations.
Select LANGUAGE SETTING and press
OK
to confirm.
SPRÅKINSTÄLLNING
MENYSPRÅK SVENSKA
FAVORITSPRÅK LJUD SVENSKA
ALTERNATIVT SPRÅK LJUD FRANSKA
FAVORITSPRÅK TEXTNING SVENSKA
ALTERNATIVT SPRÅK TEXTNING INGET
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
xMENU LANGUAGE
You may select the menu display language.
xMAIN AND ALTERNATIVE AUDIO LANGUAGE
If more than one audio language is transmitted, you may
select the main and the alternative languages.
xSUBTITLES
If more than one subtitle is transmitted, you may select the
main and the alternative subtitles. To have no subtitle, select
NONE for main or alternative subtitle.
4-7 TIME SETTING
ANVÄNDARINSTÄLLNING
MAX TID SKÄRMMEDDELANDE 4
GENOMSKINLIGHET 25%
MAX TID VOLYMREGLAGE 4
ANVÅDARLAND SWEDEN
FLYTTA
TILLBAKA X
AVS L UTA
OK
BEKRÄFTA
The time is set from the GMT time by using the or key
and selecting the country where you live.
Press
OK
to confirm.
Ch04.p65 10/12/02, 09:5218

19
BLEU PANTONE 293C
SET TOP BOX INSTALLATION .4
4-8 CHANGE PROTECTION CODE
BYTE AV INSTALLATIONSKOD
NY KOD
BEKRÄFTA
- - - -
ÄNDRA
TILLBAKA X
AVSLUTA
OK
BEKRÄFTA
Enter your new code.
The first segment blinks until its value is entered, then the
second segment blinks, etc.
As soon as the value has been entered, the segment is
replaced with a star.
Use the arrow key on the remote control unit to come back
to a value that has been entered and modify it until the whole
is confirmed by
OK
.
In this case, the value becomes a blinking segment again,
indicating that entry is possible.
BYTE AV INSTALLATIONSKOD
NY KOD
BEKRÄFTA - - - -
- - - -
ÄNDRA
TILLBAKA X
AVSLUTA
OK
BEKRÄFTA
Enter the same new code to confirm it.
BYTE AV INSTALLATIONSKOD
NY KOD
BEKRÄFTA - - - -
- - - -
FELAKTIG
BEKRÄFTELSE
BÖRJA OM
ÄNDRA
TILLBAKA X
AVSLUTA
OK
BEKRÄFTA
If you have not entered the right code, you will see an error
message.
BYTE AV INSTALLATIONSKOD
NY KOD
BEKRÄFTA - - - -
- - - -
GODKÄND
BEKRÄFTELSE
ÄNDRA
TILLBAKA X
AVSLUTA
OK
BEKRÄFTA
Indication of correct acknowledgement.
Ch04.p65 10/12/02, 09:5219

20
BLEU PANTONE 293C
5. USING YOUR SET TOP BOX
5. Using you Set Top Box
5-1 CHANGING CHANNELS AND LISTS
5-1-1 Switching channels
The Set Top Box provides several ways for channel switching:
xUsing the and keys on the f ont panel o
P+
and
P-
on the emote cont ol unit :
The Set Top Box switches to the next service up (
P+
) or the next service down (
P-
) from the current
channel.
xEnte ing the nume ical code fo the channel on the emote cont ol keypad
Type in a single digit (1), which is displayed in the 3rd digit position on the front panel display and on
the screen banner, e.g. "1—".
If you do not type in another digit within 2 seconds, the digit is displayed in the first digit position on the
front panel display and on the screen banner, the second and third digits are blanked out and the video
and audio playing process is activated on the new Video service. e.g. "1".
If you type in another digit (2), this is displayed in the 2nd digit position. e.g. "12-".
If you do not type in another digit within 2 seconds, the 2 digits are displayed in the first and second digit
positions on the front panel display and on the screen banner, the third digit is blanked out and the video
and audio playing process is activated on the new Video service. e.g. "12".
If you type in another digit (3), this last digit is displayed in the first digit position on the front panel display
and on the screen banner and the video and audio playing process is activated on the new Video service.
e.g. "123".
If the numerical code entered does not correspond to a video service in the list, the Set Top Box selects
the first lower Video service in the list.
5-1-2 Info zapping
A
Undefined TELEFILM
ENGLISH
ITALIAN
262 RAI2 14:39
1
1
?
This way of zapping enables you to view data concerning the
current programmes on the different Video services of the list.
Press the
P+
or
P-
keys (or i key and then and
keys) and hold them down.
The screen banner is displayed showing data concerning the
programme on the next video service up (
P+
) or down (
P-
).
The current audio and video streams are still played.
As you release the key, the video and audio playing process is
activated onto the service whose number is currently displayed
on the screen banner.
5-1-3 Quick etu n key ( )
The key enables you to zap between the current channel and the last channel viewed
You can use this key e.g. when waiting for a feature film to begin.
Ch05.p65 10/12/02, 09:5220

21
BLEU PANTONE 293C
USING YOUR SET TOP BOX .5
5-2 INFO PROGRAMME SCREEN
Il nostro amico Charly: Charly lo scozzese
AT 14:58 : In diretta dalla Camera dei
TOTAL : 49 Min
A
Undefined TELEFILM
ENGLISH
ITALIAN
262 RAI2 14:39
1
1
?
§5-2-
§5-2-9
§5-2-10
§5-2-11
Programme
type
§5-2-5
§5-2-6
Current time
§5-2-4
§5-2-3
§5-2-2
§5-2-1
§5-2-8
5-2-1 Summa y of the cu ent p og amme
By pressing the
i
key on the remote control unit, you can read the summary of the current programme
(available if the channel provider broadcasts it).
5-2-2 Ba g aph indicato
By pressing the i key on the remote control unit, you can read the Bargraph indicator showing the time
elapsed since the beginning of the current programme (available if the channel provider broadcasts it).
5-2-3 Total length of the cu ent p og amme
By pressing the i key on the remote control unit, you can read the total length of the current programme
(available if the channel provider broadcasts it).
5-2-4 Sho t summa y of the next p og amme
By pressing the i key on the remote control unit, you can read the Short summary of the next
programme (available if the channel provider broadcasts it).
Ch05.p65 10/12/02, 09:5221
