KonNad C2000-RSDD-CK-CK31 User manual
Last updated: 2020-10-29
C2000-RSDD-CK-CK31
User Manual
3 * RS485 ⇋ 1 * RS485
Serial-to-Ethernet Device — Serial-to-Serial Converter
SinoCon Co., Ltd.
Copyright Notice
©2000 - 2020 SinoCon Co., Ltd. All Rights Reserved.
Trademarks
The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in
this manual belong to their respective manufacturers.
Disclaimer
This document only provides information about KonNaD products. No license to any intellectual property
rights is granted by this document, including any intellectual property licenses, expressed or implied, or by
any means. SinoCon assumes no responsibility other than the liability stated by SinoCon in the terms and
conditions of sale of its products and SinoCon makes no warranties regarding the sale or use of KonNaD
products, including the suitability for the specific use of the products, and marketability, and SinoCon doesn't
guarantee that it won't infringe any patent, copyright or other intellectual property rights, etc.
Information in this document is subject to change without notice and does not represent a commitment on
the part of SinoCon.
Contact US
SinoCon Co., Ltd.
Address: 16th Floor, Tower A, Zhongyin Building, Caitian Road, Futian District, Shenzhen, China
Web: www.sinoconsys.com
Tel: +86 0755-88865168
C2000-RSDD-CK-CK31 User Manual
3 / 12
SinoCon Co., Ltd. www.sinoconsys.com
C2000-RSDD-CK-CK31 User Manual
4 / 12
SinoCon Co., Ltd. www.sinoconsys.com
1. Hardware Description
1.1. Specifications
Classification Parameter Specification
Ethernet No. of Ports 1
Bandwidth 10/100M
Communication Distance 100m
Industrial Protocols TCP/IP
Downstream Serial
Port
Serial Standard RS485
No. of Ports 1
Connector Terminal block
Cascade Connection/Transparent
Transmission
Bidirectional transparent
transmission
Baud Rate 1200~115200bps
Upstream Serial Port Serial Standrad RS485
No. of Ports 3
Connector Terminal block
Baud Rate 1200~115200bps
Cascade Connection/Transparent
Transmission
Bidirectional transparent
transmission
Communication
Mode
Communication Mode Bidirectional transparent
transmission
Power Power Connector Terminal block
Input Voltage 9~27VDC
Current < 200mA @ 12VDC
Physical
Characteristics
Dimensions 184*124*32.5mm
C2000-RSDD-CK-CK31 User Manual
5 / 12
SinoCon Co., Ltd. www.sinoconsys.com
Installation Wall
Environmental
Limits
Operating Temperature -40℃ ~ 85℃
Storage Temperature -60℃ ~ 125℃
Ambient Relative Humidity 5% ~ 95% RH, non-condensing
Classification Parameter Specification
C2000-RSDD-CK-CK31 User Manual
6 / 12
SinoCon Co., Ltd. www.sinoconsys.com
1.3. Indicators
Classification Indicator Description Meaning
Ethernet LINK Network
status
indicator
Steady on：Network connection enabled
Flashing：Transmit or receive data
Off：The network port is not plugged into the
network cable
SPD 10/100Mbps
indicator
Steady on：100M network connected
Off：Not connected to the 100M network
RUN FAULT Equipment
failure
indicator
Steady on：Under voltage
Downstream
Serial Port
TXD RS485 data
transmit
indicator
Flashing：RS485 transmitting data
Off：RS485 no transmitting data
RXD RS485 data
receive
indicator
Steady on：RS485 line fault, please check if the
positive and negative poles of 485 line are reversed
Flashing：RS485 receiving data
Off：RS485 no receiving data
Power PWR Power
indicator
(9~27VDC)
Steady on：Normal power supply
Off：No power or abnormal power supply, please
check if the voltage range is 9~27VDC
C2000-RSDD-CK-CK31 User Manual
8 / 12
SinoCon Co., Ltd. www.sinoconsys.com
1.4. Port Description
Classification Port Description Recommended
wiring
Ethernet Ethernet RJ45 Ethernet port CAT-5e
DEBUG PORT +、-、
GND
RS485 debug port positive, RS485 debug port
negative, GND
RVSP 2*0.5
Reserved GND、
PP2、
GND、
PP1
Reserved port -
Power Input PE Used for reliable grounding of the device, surge
protection
RVV 2*0.5
VA+、
VA-、
VB+、
VB-
A channel power supply input positive, A channel
power supply input negative, B channel power
supply input positive, B channel power supply input
negative
RVV 2*1.0
Downstream
Serial Port
485+、
485-、
GND
RS485+, RS485-, GND (downward) RVSP 2*0.5
C2000-RSDD-CK-CK31 User Manual
9 / 12
SinoCon Co., Ltd. www.sinoconsys.com
3. Warranty Policy
In the normal use of the products you purchased, free warranty service will be provided from the date of
purchase whenever the quality problems caused by raw materials or production process are concerned.
However, due to the user's failure to install, disassemble or improperly use the product according to the
requirements of this product manual, the company provides maintenance services, but charges appropriate
maintenance fees. The warranty period is as follows:
Product category Warranty Period
Shelled product 6years
Unshelled product 3years
Note: Accessories are not covered by warranty.
Warranty Terms:
1. From the date of purchase, in the case of normal use (determined by the company's authorized
technicians), the failed product will be repaired free of charge during the warranty period.
2. Products that have been repaired or modified by a maintenance personnel other than our company
during the warranty period, or that have been improperly installed, incorrectly input voltage,
improperly used, accidental events or natural disasters, etc., are not covered by the warranty.
3. Before accepting the warranty service, the customer is required to prove the date of purchase of the
product by presenting the warranty card or purchasing the invoice. Otherwise, the warranty cannot
be guaranteed.
4. For all warranty or repair products, the customer bears the risk of shipping and shipping costs.
5. If the product exceeds the warranty period or does not meet the warranty requirements, the
company will provide charge maintenance.
6. The warranty terms for customized and ODM products should be defined in the contract.
7. Other verbal commitments that conflict with this warranty would be executed with reference to this
warranty.
8. Our company's responsibility for the manufacture, sale and use of the products shall not exceed the
original cost of the products. The company does not assume any joint responsibility.
9. The right to interpret this clause belongs to the company.
