Koryo KIC 21C Guide

User’s Manual & Warranty Card
KIC 21C
Induction Cook Top

Thank you for purchasing our KORYO induction cook top, please read this instruction manual
carefully before using and preserve it for your future reference.
Induction cook top is one of the new environment-friendly kitchenware; this induction cook top is
of international standard, suitable for all kinds of cooking and which has the advantage of being
small in size, multiple function, energy saving, safe and reliable. Cooking with no re, no smoke
and exhaust.
2

Operation and usage
1. Please check if the local voltage is suitable for the product’s working voltage range before
starting, please check if the plug and socket is well connected.
2. Please clean the water stains on the surface of cook top and glass plate, then put the
distributed pots on the center of the heating area, do no heat an empty pan or pot.
3. After the cook top is connected with electricity, working indicator and power tube light, buzzer
sounds short “Beep”, for a while, the power tube reveals [—] At this time, you can choose “on/
off” button to start the cook top, the cook top default is set at “hot-pot” function.
4. The maximum weight shall not exceed 4.5 kgs.
5. Always use induction cook top at base utensil.
Function usage
1. During the working you can change the setting, press the “function” button to choose different
functions, and the correspondingly working indicator will light up.
2. With “Fried” and “Hot-pot” buttons you can adjust the setting while the other buttons are xed
controlled by MCU, and you cannot adjust manually.
Menu Function
1. Hot-pot: During the heating process, you can adjust the power level at random (Between
300W to 2000W). When you use to boil with nothing in the pot or the electric control parameter
occurs abnormal, the induction cook top will carry out auto-protection or shut down, and the
digitron will reveal fault code accordingly.
2. Fried: During the warming process, you can adjust the temperature, when the pot temperature
reaches the correspondingly temperature control setting (different shift as different temperature
control point), the induction cook top will start intermittently heating or stop heating, when the
pot temperature lower, it’ll heat again.
3. Boil: Auto function, you cannot adjust power level during heating. Display unit reveals (2000W)
and the cook top heating with its maximum power, water will start boiling.
4. Soup: Auto function, you cannot adjust power level during heating. Put the soup into the pot,
press the “soup” button and it comes to the auto-cooking mode. The cook top will heat to
specied temperature rst, and then heat intermittently until the soup boils.
5. Stewing: Auto function, you cannot adjust power level during heating. Put the steaming basket
will food into the pot and cover the pot. Start the cook top and select “stewing” function, the
cook top will enter stewing working status.
6. Conjee: Auto function, you cannot adjust power level during heating, Start the cook top and
select “conjee” function, the cook top will enter conjee status; the software combines fuzzy
control technology with intermittent heating way to complete the work of cooking porridge.
7. Warming: Auto function, you cannot adjust repower during heating. Start the cook top and
2
3

select “warming” function, the warming indicator light. The cook top will control power level
automatically, when the food reaches certain temperature, the cook top will turn into intermittent
heating way, keeping the food temperature from 60º-80ºC.
8. Cooling fan - Auto off feature.
Compatible & non compatible utensile
Usable Pans
Steel or cast iron, enamelled iron, stainless steel, at-bottom pans/pots with diameter from
12 to 20cm.
Non-usable Pans
Heat-resistant glass, ceramic container, copper, aluminium pans/pots, rounded-bottom
pans/pots.
Enameled iron pot
Rounded Bottom
Pot
Pot with Stands
Aluminium
Copper Pot
Ceramic Pot
Bottom Measuring
Less than 12cm
Heat-Resistant
Glass Pot
Cast Iron Pan Iron PotIron or Enameled
Iron Pot
Deep-Fry Pan Stainless Steel Pot Iron Plate
4

Caution
• Please insert the plug into socket.
• Do not ush the cook top with water directly, use damp soft cloth to clean.
• Do not heat empty pot, in case the pot temperature becomes too high it can be dangerous.
• The cook top edge should has at least 10cm distance from other object.
• Do not use the cook top in high temperature environment and be far away from the re.
• Do not use the cook top on metal or stainless table which has magnetic conduction.
Cleanliness & Maintenance
1. Please shut off the power and pull out the plug before your cleaning.
2. After remove dirt, please use neat wet cloth to clean the unit.
3. Do not clean by water directly, if water gets inside it may cause malfunction.
4. Make the glass plate and pan clean before cook, otherwise, dirt after charring is very difcult
to clean and the plate may get discoloration.
5. You may clean air vent / air entry’s dirt by vacuum cleaner to suck up or by cotton. If there is
dirt with oil, add a little litmus less detergent with tooth brush to clean.
6. Don’t use caustic impregnate to clean. It may damage the cook top by chemical reaction.
7. Do not use thinner, scrubbing brush or polishing power to clean the induction cook top.
Trouble Shooting
When the cook top show fault code during working, it means there is something wrong with the
cook top. Below are the fault code and their solutions. Please note “EO” is not a fault code, it
reminds that there is no pot on the cook top
Possible reasons Trouble code
Low voltage protection E1
High voltage protection E2
Cook top surface’s sensor
Short circuit or exceed temperature E3
Cook top surface’s sensor circuit opened E4
IGBT sensor short circuit or exceed temperature E5
IGBT sensor circuit to opened E6
Resonant loop fault E9
4
5

Terms and Conditions
This product comes with a warranty of 12 months from the date of purchase as specied on the
warranty card. This is against all defective material or workmanship. In the event of a defect,
Future Value Retail Limited undertakes to repair the set, free of charge, during the warranty period.
In the event of a defect developing in the product, contact Future Value Retail Limited and provide
information about the defect, the model number and serial number of the product.
THIS WARRANTY IS VOID IF
1. The completed warranty card is not presented to the authorised personnel at the time of
servicing of the product.
2. The product is not operated according to the instructions given in the user manual.
3. Defects are caused by improper or reckless use.
4. Modications or alterations have been made to the product or if the product has been
tampered with, in any manner whatsoever.
5. Repairs to the product are carried out by anyone other than an authorised company
representative.
6. For defects other than faulty parts or workmanship such as damage due to lightning,
abnormal voltage, spillages, dust, accidental damage, etc.
7. The serial number is deleted or altered.
8. Used for any non–domestic purpose.
OTHER TERMS AND CONDITIONS
1. Repairs or replacement will be carried out either by a Future Value Retail Limited authorised
customer care centre or by a representative.
2. All expenses incurred in collecting the unit(s) or part(s) thereof from the Customer Service
Centre, as well as any other expenses and incidentals will be borne by the customer.
3. Whilst the company will make every effort to carry out repairs at the earliest, it is made
expressly clear that the company is under no obligation to do so in a specied period of time.
4. The company or its authorised customer centre reserves the right to retain any part(s) or
component(s) replaced at its discretion, in the event of a defect being noticed in the equipment
during the warranty
