Koy 05-k1 User manual

PRODUCT MANUAL
Model
05-k1

1
0
01
02
02
03
04
05
05
06
07~13
14~16
17~18
19
20
20
20
21
21
22
22
23
23
Content
Preparation
Part list
KYO718AA
KYO715CA
KYO713AA
Parameter
parts drawing
Installation drawing
KYO718AA
KYO715CA
KYO713AA
Warning
Usage Notice
Reminder
Maintainance
Trouble Shooting
Safety Instruction
KYO713AA
KY0715CA
KYO718AA
Install Electricity box
Installation
Operation instruction
Aftersales service
Circuit drawing

0
2
Part list
5×60
10pcs
4×30
6pcs
4×25
4pcs
4×18
4pcs
4×12
18pcs
Heater underlay
4pcs
Ø10
3pcs
Wire fixer Ø
7pcs
8 Wire fixer Pulley
2PCS
Pulley
2PCS
5×7 0
4pcs
4×25
4pcs
Decorated
washer
6pcs
Decorated
screw cap
6pcs

3
0
KYO718AA

0
4
KYO715CA

5
0
Technology parameters
Load parameter
Rated Voltage：AC220-240V
Rated Power：1820W
Rated Current：8A
Rated frequency ：50/60HZ
Insulated Resistance：>20MΩ
Class: I
Back/ Side board heater：AC220-240V/350W
Leg heater：AC220-240V/300W
Front heater：AC220-240V/150W
Fan：DC12V/5W
Color Light：DC12V/5W
Speaker：8Ω/10W
KYO713AA

04
02
16
08
01
1
2
1
3
1
4
1
5
1
6
1
29
1
10
11
Plastic seal BF003-06-12.42
13
Plastic seal BF002-06-12 2
12
10
06
1
03
15
11
07
7 1
8
Seat heater
1
2
前侧固定玻璃 2
14
1
15
0
6
09
05
13
Back fixed glass 2
2
14
Glass door
15
16
1
AFan 1
1
B
1
C
D
Parts drawing
Parts drawing
Model Size：
1000*958*2000mm
No. Parts name Qty No. Parts name Qty
Right seat rack
Left seat rack
back board
Backrest
Front heater corer
Handle 3
ST 4 *2 5
B
AC
D
E
ST3*10
ST3*10
ST3*10
ST4 * 25
ST4*18
F
14
12
Left seat board
Left seat rack 1
colour light
Power Box
Speaker
heater
control panel frame
4
1
E
F
Front side fixed glass

7
0
Installation drawing
Step Material QtySize
Step 1
Step 2
Attention: The side board bottom slot
must be aimed at the floor batten.
left side board
floor batten
lead rail batten
side board
90
floor batten
1Screw ST4*40mm 2

0
8
Installation drawing
Step 3
Step Material QtySize
Step 4
44
Screw ST5*70mm
4Screw ST4*18mm 4
Screw ST4*25mm 4
3

9
0
Installation drawing
Step 5
Step 6
6 6
Screw ST5*60mm
Plastic seal
LR007-6
Step Material Qty
Screw
Size
ST4*30mm
Decorated screw cap
5
5
5
Decorated washer 6
6
6

8 4
1
0
Installation drawing
Step 7
Step Material QtySize
Screw ST5*60mm
Step 8

1
1
8 8
St4×18mm
Installation drawing
Step 8
Step 9
Material QtySize
Screw
Plastic seal LR001-3.4
Plastic seal LR001-3.4
Plastic seal BF002-6-15.5
92
540mm
Plastic seal
92
500mm
Plastic seal
Plastic seal BF001-06
Hole
fastening
St4×18mm

1
2
Installation drawing
Step 10
Step Material QtySize
10 up Pulley 4
10 down Pulley 4
Adjust the screw to
adjust the height of
the glass door.

3
1
11 Handle 3 1
Installation drawing
Step Material QtySize
Step 11

1
4
Operation instruction
Key
01.[Temperature+]；
02.[Temperature-]；
03.[Time+]；
04.[Time-]；
05.[CD/MP3 input]；
06.[Infrared sauna group A]；
07.[Infrared sauna group B]；
08.[Colour light]；
09.[Fan]；
10.[FM]；
11.[CD/MP3]；
12.[FM frequency+]；
13.[FM frequency-]；
14.[Volume+]；
15.[Volume-]；
16.[Power on/off]。
A.[Temperature/FM ]；
B.[Temperature indicator light]；
C.[MP3]；
D.[FM tune indicator light]；
E.[Volume/time]
F.[Volume adjust indicator light]；
G.[Time setting indicator light]；
H.[Infrared sauna group A light]；
I.[Infrared sauna group B light]；
J.[Automatic fan indicator light]；
K.[Fan by hand indicator light]；
L.[Power on/off indicator light]
Display Area
70％ 80％
Audio input
16
15
14
13
12
11
10
02
09
08
07
06
05
04
03
02
01
02
D
E
F
G
H
I
J
K
L
C
A
MP3
B
KYO718AA

5
1
Operation instruction
Under power on condition,the indicator light of power will be twinkling,and
then press it will be turned on.The multi-color,the carbon fiber heater,and the
far infrared heater will be turn on at the same time.The display show 45℃
temperature for 5 seconds, if there's no any operation, 5 seconds later it will
renew to the temperature of nature.The setted time when it turn on is 30
minutes, at the same time,the indicator light will turn on.Press again, it will
turn off and turn off all of the function and display
Press infrared sauna group A/B to start infrared sauna fuction.
Press infrared sauna key the first time with 100% power,
Second time power90%,
Third time power80%,
Fourth time power70%,
While fifth time to close it.
Under turn on condition,press time+ / time- ,the time will be downwards or
upwards 1 minute,press the key about 1 second,it will be automatically quickly
adjusting.The scale of time adjusting is 01-99 minutes.
Under turn on condition,press temperature+/temperature-,the time will be
downwards or upwards 1℃,press the key about 1 second,it will be quickly
adjusting automatically.The scale of temperature adjusting is 35～60℃.When
the temperature inside reach to the setted temperature,the system will adjust
the power into 70%.When temperature inside is 2℃ lower than the setted
temperature,the system will adjust the power into 100% power.
Press color light key to adjust the color lamp by hand.It works circularly from
white/green/yellow/blue/red/turn off.Top lamp is controled by the key
within15minutes after shut down the control panel. The control system will
turn off multh-color lamp function automatically aftor shuting the system for is
minutes,Once turn on power,white is acquiescence.
1.Turn on/Turn off
2. Infrared sauna
3.Time/Temperature setting
4.Multi-color top lamp

1
6
Operation instruction
Under power on condition,press fan key to turn on it and then the indicator
light of "HAND" will be light.Press fan key again,the indicator l ight of "HAND"
will be turn off and the same time turn on the "AUTO"function.The indicator l
ight of "AUTO" will be l ight.After the temperature inside the cabinreach to the
setted temperature,the fan will be turn on automatically.When the
temperature inside is 2℃ lower thanthe setted temperature,the fan will be turn
off automatically.
Under power on condition,press FM key to turn on radio.The setted frequency
is the frequency you turn off last time,at the same time the frequency will be
shown on the display for 5seconds,then the temperature will be shown on the
display and the indicator light of frequency will be turn off.Press FM again,the
radio will be turn off.The display show "OFF" world for 10 seconds ; The scale
of frequency is 87.5-108MHZ。
Adjust the frequency under radio on ,press FM+ /FM- to adjust the
frequency.Press one time the frequency will be downwards or upwards
0.1MHZ.Press FM+ / FM- about 2 seconds ,the system will search the
frequency automatically until find a clearly frequency, and then play the
frequency searched.
Under power on condition,input CD/MP3.Press CD/MP3 key to turn on
CD/MP3 function. On the display, it will shown cd on it.Press again to display
MP3,press it the third time to turn off then show OFF on the display.
Under condition of turn on radio or CD/MP3,the setted volume is 8.Press key+
or key- ,the volume will be downwards or upwards "1" each time.Press key+ or
key- about 1second,it will be automatically quickly adjusting.The scale of
volume is 0～12.
5.Fan function
6.FM function
7.CD/MP3 input
8.Volume adjust

7
1
Operation instruction
Key
01.[Infrared sauna group A]；
02.[Infrared sauna group B]；
03.[Colour light]；
04.[Fan]；
05.[Key+]；
06.[Key-]；
07.[CD/MP3/FM]；
08.[Menu]；
09.[Play/Pause]；
10.[Power on/off].
Screen
A.[Temp/FM]；
B.[Colour light]；
C.[Fan]；
D.[CD]；
E.[MP3]；
F.[Lock]；
G.[Volume/time]；
H.[Volume setting；
I.[FM/MP3 setting]；
J.[Temp setting]；
K.[Time setting]；
L.[Infrared sauna].
01
G
H
I
J
K
L
A
C
D
E
F
01 0102 0103 0104 0105 0106 0107 0108 0109 0110
B
KYO715CA

1
8
Operation instruction
On: Press the key is about 1 second to start it.
Off: Press power on/off key about 2 seconds to turn off
Touch infrared sauna key group A/B key to start it and it will show its icon. Touch
again to turn off them. When reaches setting temperature, the system will shut
down automatically. when temperature less than 3℃, the system will restart
infrared sauna function automatically .
Touch the menu the first time and the key flashing, touch up/down key to adjust
time setting between 01 ~ 99 minutes; touch the menu again to display
temperature then touch up/down key to adjust the temperature setting with
range 35~60℃.
Press color light key to adjust the color lamp by hand.It works circularly from
white/green/yellow/blue/red/turn off.Top lamp is controled by the key
within15minutes after shut down the control panel.The control system will turn
off multh-color lamp function automatically aftor shuting the system for is
minutes,Once turn on power,white is acquiescence.
Touch the fan key to start fan with fan light icon.Touch it again to turn off.
Under power on condition,press FM key to turn on radio.The setted frequency is
the frequency you turn off last time,at the same time the frequency will be
shown on the display,then the MP3 will be shown on the display .Press FM key
again,the radio will be turn off.The scale of frequency is 87.5-108MHZ.Adjust
the frequency Under radio turn on condition,press FM+/FM- to adjust the
frequency.Press one time the frequency will be downwards or upwards
0.1MHZ.Press FM+/FM- about 2 seconds,the system will search the frequency
automatical ly until find a clearly frequency,and then play the frequency
searched.
Touch CD/MP3/FM key to turn on CD /MP3.When CD/MP3 works,touch the
menu to set FM display,then touch up/down key to play the next song. Touch
the play/Pause to switch CD/MP3.
Under condition of turn on radio or CD/MP3,the setted volume is 8 Press up or
down key to adjust volume which betweent0 and 12,it displays current volume
under setted time 5seconds,then recover time showing.
After the control panel in the dormancy for 60 minutes ,all the function will lock
automatically,the display become black,the key is on,press"Power on/off "for 2
seconds to release it.
Function: Avoid the mistaken operation of unconscous touch or kids fan while
showering.
1.Power on/off
2.Infrared sauna function
3.Time/tempreture setting
4.Multi-color top lamp
5.Fan function
6.FM function
7.CD/MP3 function
8.Volume adjust
9.Key-press lock
