Scissor Lift „Zurich“ X46
Short manual for the Installation
Stand: 05e/2021
We would like to ask you to read the manual of the usage and maintenance of the scissor lift carefully before
stating to work with it. Furthermore, we would like to point out that this information is not legally binding and
that we can change it at any given time without a prior notice.
KHG Krömer‘s Handelsgesellschaft mbH | Rosa-Luxemburg-Strasse 34 | 03044 Cottbus DE
[e-mail] | www.hebebuehnen-kroemer.de | [phone]
Before starting the installation, read the safety instructions in the main manual carefully.

2
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289
Lift & Control Panel
Overview of Lift & Control Panel
a) Control panel handle b) Control panel wheels c) Mobile kit wheels 1 d) Mobile kit wheels 2 e) Coupling
f) Mobilkit Gripper arm g) Rubber pads h) Handle mobile kit i) Support rod gripper arm
j) Ramps k) Foot protection bars
a) b)
f)
c) d)
e)
h)
g)
j)
i)
Overview Mobile kit
Checklist
Overview of individual parts
k)
Pcs.
1
1
1
2
4
4
2
Packs.
2 - 1
2 - 2
2 - 2
2 - 1
2 - 2
2 - 2
2 - 2
Packs.
2 - 2
2 - 1
2 - 2
2 - 2
2 - 2
2 - 2
(a)
(b)
(g)
(j)
(k)
Description
Scherenhebebühne X26
Bedienpult
Control panel handle
Control panel wheels
Rubber pads
Ramps
Foot protection bars
Pcs.
2
2
1
1
1
1
(c)
(d)
(e)
(f)
(h)
(i)
Description
Mobile kit wheels 1
Mobile kit wheels 2
Coupling
Gripper arm
Handle mobile kit
Support rod gripper arm

23
The foot protection bars (j) are simply hooked into the brackets.
1Attach the foot protection bars
First, attach the wheels on the bottom of the control panel and connect the handle to the top of it. In order
to ll the control panel with hydraulic oil, the front side should be removed.
2Ready the control panel and ll it with hydraulic oil
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289

4
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289
HLP 46
5 L
Hydraulic oil can be purchased voluntarily on the website.
Unscrew the oil tank and with assist of a funnel (is not the part of delivery) ll in the hydraulic oil.
5
Liter

45
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289
3Connect the control pannel with lift.
Direct the cables from the lift through the hole on the side of the control panel and connect the
hydraulic connection to the control panel as shown above.
After the conrol panel is successfully lled with oil, the lift is connected, in order to do thhat, the cables
should be removed.

6
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289
B
B
B
B
A
A
A
A
After the cables have been connected, the front of the control panel can be reconnected and the
control panel can be connected to the power supply.
Then the (remaining) cables are connected to the control panel (connector A to A; B to B).

7
Fasten four access ramps (e) to the upper platforms with the holding axles and secure them on the right
and left with circlips.
Please use circlip pliers for this installation step
4Install the access ramps
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289

8
Build the mobile kit. Attach the rollers (d) to the drawbar and secure with circlips and hook the mobile
kit handle into the platform.
Fold down the mobile kit handle to let the lift stand on wheels at the front.
5Attach the mobile kit
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289

9
Attach the coupling and secure the mobile kit handle by folding down the fuse.
Assemble part 2 of the Mobilktis and hook it into the coupling.
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289

10
Fold down part 2 and the stage can be pushed through the room.
66 Remove the mobile kit
In order to remove the mobile kit, the one should do the opposite of the previous steps.
Item no.:
manufacturer:
EAN-Code:
X46
Kroemer
0703441952289

11
Issue status
5th edition of the instruction manual, 2021
A1-2021
©KHG mbH
All rights reserved. No part of this document may be reproduced without the express permission of KHG
mbh. All rights are reserved in case of patent grant or utility model registration. The content of this edition
has been carefully checked for accuracy, however, errors cannot be completely excluded. Please notify us if
you discover any errors. We reserve the right to make technical changes at any time without prior notice. The
target group is users with previous technical knowledge in the eld of automotive engineering.
Manufacturer
KHG Krömer‘s Handelsgesellschaft mbH
Rosa-Luxemburg-Straße 34
03044 Cottbus
Deutschland
Web: www.hebebuehnen-kroemer.de
E-Mail: [e-mail]
Service
Telefon: [phone]
Fax: [phone]
Important Informations
7Successfull Installation
After removing the mobile kit, the Krömer scissor lift is ready for you to use.
