VM - 4UX
1:4 4K 12G SDI DA
The VM −4UX is a compact and high
performance 1:4 4K distributor for standard
broadcast−grade SDI signals of up to 12G
transmitted data rate. It auto−adapts to the
data rate of one SDI input signal, equalizes
and re−clocks the signal to improve
transmitted signal reach, and distributes the
signal to four identical SDI outputs.
Reliable Wire Connectivity - Coaxial broadcast−grade cables are reliably connected via lockable BNC connectors,
preventing unintentional wire disconnections, to gain fast and highly professional uncompressed SDI signals
distribution deployments.
Extended-reach Input Extension - Input signal equalization and output signals reclocking to gain extended−reach
signal extension. Using Kramer high−quality coaxial SDI cables, supports extension of up to 300m (984ft) for SD
signals; 200m (656ft) for 1.5G HD signals; 100m (328ft) for 3G and 6G HD signals; 80m (262ft) for 12G 4K signals.
Note: Reach depends on signal resolution, and quality of copper cable used. Reach extension performance may vary
while using non−Kramer coaxial cables.
Transmitted Data Rate - Auto −adapting from 270Mbps to 12Gbps data rates.
Compliance - Complies with SMPTE 259M (SD−SDI), 292M (HD−SDI), 344M (ED−SDI), 424M (3G HD−SDI),
ST −2081 (6G−SDI) and ST−2082 (12G−SDI) standards.
Max. Resolution - 4K@60Hz (4:2:2) 30bpp.
SDI Signal Transmission - SDI, HD–SDI, 3G HD–SDI, 6G and 12G SDI compliant signals, supporting pass−through
of standard embedded audio channels with ancillary ID and metadata information.
LED Indicators - Status indicators for transmitted SDI data rate of input and output connected signals, and power
indicator, for ease of maintenance and troubleshooting.
Easy Installation - Compact DigiTOOLS™ fan−less enclosure for small footprint spaces and over−ceiling mounting,
or side− by −side rack mounting.
FEATURES

VM - 4UX
TECHNICAL SPECIFICATIONS
INPUTS:
1 SMPTE 259M (SD−SDI), 292M (HD−SDI), 344M (ED−SDI), 424M (3G
HD−SDI), ST−2081 (6G−SDI) and ST−2082 (12G−SDI) compliant serial video,
75ΩonaBNCconnector.
OUTPUTS:
4 equalized and reclocked SMPTE 259M (SD−SDI), 292M (HD−SDI), 344M
(ED−SDI), 424M (3G HD−SDI), ST−2081 (6G−SDI) and ST 2082 (12G−SDI),
outputs75ΩonBNCconnectors.
CABLE EQUALIZATION REACH:
12Gbps: Up to 80m (260ft), 3Gbps and 6Gbps: Up to 100m (330ft), 1.5Gbps:
Up to 200m (660ft), SD: Up to 300m (980ft), Note: The above specs apply when
using Kramer cables.
VIDEO:
Up to 4K@60Hz (4:2:2) 30bpp resolution, 270Mbps to 12Gbps data rate.
MAXIMUM OUTPUT LEVEL:
800mVpp/75Ω.
COUPLING:
AC.
STANDARDS COMPLIANCE:
SMPTE 259M (SD−SDI), 292M (HD−SDI), 344M (ED−SDI), 424M (3G HD−SDI),
ST −2081 (6G−SDI), ST−2082 (12G−SDI).
POWER CONSUMPTION:
5V DC, 250mA.
POWER SOURCE:
5.2V/4A.
ENCLOSURE:
Tools size, Aluminum type.
COOLING:
Convection ventilation.
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F).
STORAGE TEMPERATURE:
−40° to +70°C (−40° to 158°F).
HUMIDITY:
10% to 90%, RHL non−condensing
PRODUCT DIMENSIONS:
12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H
PRODUCT WEIGHT:
0.2kg (0.4lbs) approx.
SHIPPING DIMENSIONS:
23.20cm x 12.00cm x 8.90cm (9.13" x 4.72" x 3.50" ) W, D, H
SHIPPING WEIGHT:
0.7kg (1.5lbs) approx.
INCLUDED ACCESSORIES:
Powersupply,mountingbracket,2maleBNC75Ωterminators.
OPTIONS:
RK−3T 19” rack adapter.
