Aztech FG7008GR(AC) Instructions for use

FG7008GR(AC)
DUAL BAND WIRELESS-AC
MU-MIMO GIGABIT ROUTER
Easy Start Guide
VERSION 1.0

FG7008GR(AC)(Easy Start Guide)

3
FG7008GR(AC)(Easy Start Guide)
Contents
Check Package Contents
STEP 1: Connecting your ONT to the Router
STEP 2: Connecting your Wireless Devices
• Default Network Name and Network Key
• Connecting to your Wireless Network
• Accessing the Web User Interface
• Configuring the 2.4GHz and 5.0GHz Wireless
Properties (Option)
Troubleshooting Tips
Frequently Asked Questions (FAQs)
Aztech Technical Support Details
This Easy Start Guide along with the User Manual which provides a
more advanced guide to this product is downloadable on our Aztech
Support Website (www.aztech.com/support).

FG7008GR(AC)(Easy Start Guide)
Check Package Contents
The following items are included in your FG7008GR(AC)
package.
FG7008GR(AC) Power Adapter
Easy Start Guide
NOTE: Please contact your Dealer if any of the following items
below are missing from your package.
Ethernet Cable
Warranty Policy
This Easy Start Guide will help you setup your FG7008GR(AC)
for internet connectivity and configure your wireless network’s
properties (e.g. changing of Wireless Network name and Password).

5
FG7008GR(AC)(Easy Start Guide)
a. Power ON your FG7008GR(AC) by connecting and
plugging its power adapter to a power outlet.
b. Connect your ONT device to the FG7008GR(AC)’s WAN
port using an Ethernet cable.
c. You may connect an Ethernet device (e.g. Desktop/PC)
on your FG7008GR(AC)’s Ethernet ports.
STEP 1: Connecting your ONT to the Router
WARNING: Please ensure that
all involved Ethernet devices are
switched OFF first before setting up.
Power
Adapter
FG7008GR(AC)
ONT
Desktop/PC
NOTE: Ensure that your ONT
device and desktop is already
plugged.
CHECK THE LEDS :
• The POWER, BROADBAND, and INTERNET LEDs
should now be GREEN. If an Ethernet device is
connected, its corresponding Ethernet LED would be in
GREEN. The Ethernet LED will also be blinking if there
is activity on the corresponding port.
NOTE: Singapore Fibre Residential customers do not need to configure
anything since the FG7008GR(AC) would AUTOMATICALLY DETECT THE
SETTINGS of your Fibre connection.
a
c
b

FG7008GR(AC)(Easy Start Guide)
STEP 2: Connecting your Wireless
Devices
Every FG7008GR(AC) device has been configured with a unique Wireless
Network Name (SSID) and Network Key (wireless password). These
details are displayed on the device label sticker located on the side of
your FG7008GR(AC) as seen below.
2.1 DEFAULT NETWORK NAME AND NETWORK KEY
• For any changes in your wireless router, you will have to
connect again to the wireless network of your FG7008GR(AC).
• Do take note that your Dual Band Wireless Router will
broadcast two Wireless SSIDs (one for both 2.4GHz and
5.0GHz bands as seen above).
• The 5.0GHz SSID (wireless network name) will only be visible
to your wireless device if it has a dual band support.
ADDITIONAL NOTES :
** The Default SSIDs (Wireless Network
Name) and Network Key (Password) of both
the 2.4GHz and 5.0GHz band can be seen on
the label sticker. You may proceed to Section
2.4 of STEP 2 if you wish to change the
Wireless Password of your FG7008GR(AC).

7
FG7008GR(AC)(Easy Start Guide)
2.2 CONNECTING TO YOUR WIRELESS NETWORK
Kindly refer and follow your respective operating system’s instructions:
If you are using Windows 7:
a. On the system tray, click the Wireless icon
and the Available Wireless Networks list
would appear.
b. On the Available Wireless Networks list,
double click on your wireless network (in
this case, AztechFG7008(5G)-IBZ1).
The default wireless network name and
network key can be seen on the label
sticker of your FG7008GR(AC) as shown
on Section 2.1.
NOTE: If the wireless network name is not on the
list, click the button to refresh the available
wireless networks.
c. You will be prompted to enter a network
Security Key (wireless password). Key
in the correct password of your wireless
network.
d. On the Set Network Location window,
double click Home Network, then click
the Close button to complete the setup.
e. Once your wireless device has succesfully
connected, the wireless icon on its system
tray would reflect the signal strength of
your router.
b
c
d
a
e

FG7008GR(AC)(Easy Start Guide)
If you are using Windows 8:
Move your mouse cursor to the lower right
corner of the screen. The Charms Bar will appear.
a. Click Settings.
b. Click the Wi-Fi Icon.
c. From the Network List, select your
own wireless network (in this case,
AztechFG7008(5G)-IBZ1).
NOTE: The Default SSID and Password can be
seen on the device label sticker as indicated
on Section 2.1.
d. Click the Connect button.
You may tick the Connect Automatically
checkbox if you want your device to connect
to the network without entering the password
again.
e. Input the correct Network Security Key
(wireless password) and then click Next.
f. If you are prompted to turn on network
device content discovery, click Yes.
a
b
c
d
e
f
g. The status Connected would be displayed
under the FG7008GR(AC)’s wireless network
name indicating a successful connection.
g

9
FG7008GR(AC)(Easy Start Guide)
NOTE : Singapore customers do not need to configure anything
in the Quick Setup area. All of these information are already pre-
configured in your ONT device and would automatically be detected
by your FG7008GR(AC) upon correctly following the setup provided
on Step 1.
The Web User Interface is used to configure both the basic and advanced
router settings. It can easily be accessed through any Web Browser (e.g.
Internet Explorer, Google Chrome).
2.3 ACCESSING THE WEB USER INTERFACE
a. Launch any Web browser (e.g. Internet Explorer, Google Chrome).
b. On the address bar type http://192.168.1.254 and press enter. You
will then be redirected to your FG7008GR(AC) Web User Interface’s
Quick Setup page.
To access the Web User Interface of your FG7008GR(AC) :

FG7008GR(AC)(Easy Start Guide)
a. Launch a Web Browser and access the Web User Interface (you
may refer to Section 2.3).
b. On the Web User Interface click Quick Setup. On the sub-menu
click the Wireless tab.
2.4 CONFIGURING THE 2.4GHz and 5.0GHz WIRELESS
PROPERTIES
The Web User Interface also allows you to configure the properties of
your wireless network. Please read and follow the instructions provided
below in configuring your wireless network.
c. On the wireless band that you wish to configure (e.g. 2.4GHz or
5.0GHz Wireless), you may enable or disable the 2.4GHz or 5.0GHz
wireless by ticking or unticking the Enable Wireless checkbox
present on each section.
a
b
c

11
FG7008GR(AC)(Easy Start Guide)
d. If you want to hide the Network from active scans, simply tick the
Non-Broadcast SSID checkbox.
NOTE: By ticking the Non-Broadcast SSID checkbox, you would
have to manually connect to your FG7008GR(AC)’s SSID.
e. Change the Network Authentication method to Mixed WPA2/
WPA-PSK.
f. Input your preferred password on the WPA Pre-shared key input
box, and verify the input password by clicking the Click here to
display button.
g. Click the Save/Apply button to save and apply changes. You may
also change the other wireless band’s password if desired.
h. Connect your wireless devices again to either of the
FG7008GR(AC)’s 2.4GHz or 5.0GHz wireless SSIDs.
NOTE: You may have to write down or save your new password for
future reference.
d
f
e

FG7008GR(AC)(Easy Start Guide)
LED INDICATORS BEHAVIOUR
Each LED indicator in your FG7008GR(AC) aims to indicate activity in
your device and even in your network.
LED NAME BEHAVIOR DESCRIPTION
Power
OFF No power is supplied to the device.
Green (Steady) Device is connected to a power supply.
Red (Steady) Error on the device.
Ethernet
1-4
OFF There is no device connected to the corresponding port.
Green (Steady) An Ethernet device is connected to the corresponding port.
Green (Blinking) Corresponding port is currently transmitting / receiving data.
2.4GHz/
5.0GHz
OFF There is no wirelessly connected device present.
Green (Steady) There is a wirelessly connected device.
Green (Blinking) Wireless interface is actively transmitting / receiving data.
USB OFF There is no USB device connected to the corresponding USB port.
ON A USB device is connected to a USB port.
IPTV
OFF IPTV interface is not up.
Red (Steady) IPTV is up and Set-top box is inactive or not connected.
Green (Steady) IPTV Interface is up and Set-top box is active.
Broadband
OFF There is no connectivity to the ONT.
Green (Steady) • Connectivity to the ONT is established.
• WAN Ethernet interface is connected.
Green (Blinking) Device is currently establishing ONT Signal.
Internet
OFF No internet.
Red (Steady) Authentication Failed.
Green (Steady) Internet interface is up.
WPS Green (Steady) WiFi Protected Setup (WPS) pairing has been established.
Green (Blinking) Ongoing / Active WiFi Protected Setup (WPS) process.
TROUBLESHOOTING TIPS

13
FG7008GR(AC)(Easy Start Guide)
FREQUENTLY ASKED QUESTIONS
Q1: How can I access the Web User Interface of my FG7008GR(AC)?
A1: Launch a Web Browser (e.g. Internet Explorer, Google Chrome)
and type in http://192.168.1.254 on the address bar.
Q2: Where can I find the Wireless Password of my FG7008GR(AC)?
A2: The Wireless SSID and the Wireless Password of both the 2.4GHz
and the 5.0GHz frequency band can be seen on the label sticker of
your FG7008GR(AC) device.
Q3: How can I connect to the 5.0GHz band of my FG7008GR(AC)?
A3: Please ensure first that your wireless device has a dual band
support. This can be done by either (1) checking the specifications
of your device, or (2) by performing a wireless scan on your wireless
device. If both the 2.4GHz and the 5.0GHz wireless SSIDs (wireless
network name) are seen, this means that your device is dual band
supported.
Q4: Does the 5.0GHz offer better wireless speeds and coverage?
A4: Since the 5.0GHz frequency band is less used by common
devices, wireless performance is expected to be higher than its
2.4GHz counterpart. However, since the 5.0GHz operates at a higher
frequency, it is also expected to have a smaller coverage.
Q5: How can I reset the FG7008GR(AC) to its factory default?
A5: Press and hold the Reset button at the back panel of the
FG7008GR(AC) for 10 seconds then release.
Q6: How do I upgrade the firmware of my FG7008GR(AC)? Is it
advisable to do so?
A6: On the web user interface, click Device Administration > Firmware
Upgrade > Choose File then locate the downloaded firmware file.It
is strongly recommended to only update your firmware if advised by
your ISP or if it has been released and advised by Aztech to be stable.

FG7008GR(AC)(Easy Start Guide)
AZTECH TECHNICAL SUPPORT DETAILS
Service Center Address:
31 Ubi Road 1 Aztech Building
Lobby B 5th Floor
Singapore 408694
Hotline: [phone]
Email: [email protected]om
Operating Hours
Monday to Friday: 9:00 AM to 6:15 PM
Saturday: 9:00 AM to 1:00 PM
(Except Public Holidays)
