Kraus KEA-144 Series User manual

www.kraususa.com I Toll Free: 1.800.775.0703 I © 2022 Kraus USA Plumbing LLC I REV. January 13, 2023
Kraus Bathroom Accessories
KEA-144**
R
INSTALLATION GUIDE

Congratulations on the purchase of your new
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your
receipt with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP
R

Prior to Installation:
·Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at
800-775-0703 for a replacement.
Tools you will need:
Safety Goggles Phillips Screwdriver
For technical assistance or replacement parts, please contact Kraus Customer Service
and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]
The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus
Accessory. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all
Kraus products by hiring a licensed professional.
Drill Hammer
R

Dimensions
Model #: KEA-14401
Double Hook Dimensions:
3” x 1 3/4" x 1 5/8”
Model #: KEA-14425
Towel Bar Dimensions:
9 1/4" x 3” x 1 5/8”
Model #: KEA-14429
Toilet Paper Holder Dimensions:
6 3/8" x 3” x 1 3/4”
3" (76mm) 1 3/4" (43mm)
1 5/8" (40mm)
9 1/4" (235mm)
3" (75mm)
1 5/8" (40mm)
6 3/8" (162mm)
1 3/4" (45mm)
3" (75mm)

Dimensions
Model #: KEA-14445
Bathroom Shelf Dimensions:
20” x 5 3/8" x 2 5/8”
Model #: KEA-14437
Towel Bar Dimensions:
25 1/4” x 3" x 1 5/8”
Model #: KEA-14442
Shelf with Towel Bar Dimensions:
25 1/4” x 8 1/8" x 4 7/8”
20" (507mm)
2 5/8" (66mm)
5 3/8" (137mm)
25 1/4" (640mm)
3" (75mm)
1 5/8" (40mm)
25 1/4" (640mm)
8 1/8" (205mm)
4 7/8" (123mm)

Installation
Please Note: The mounting hardware comes attached to your accessory. Remove from the accessory
before installing.
Ø 6mm
2
3
1

Installation
X
Ø 6mm
1
2
3

Replacement Parts
1. Mounting Base
2. Anchor Screw Set of Two
3. Anchor Screw Set of Four
4. Allen Screw
Replacement Parts List Part #
KP34001
5. Allen Key
KP34012
KP34018
1
4
5
2
KP34009
3
KP34010
KP34019
6. Glass Mounting Screw
6

Accessories
Kraus USA Plumbing, LLC (“Kraus”) extends this warranty to the original purchaser for personal household use of the Accessories when
purchased from an authorized Kraus dealer and in the location of original installation. This warranty is non-transferable.
Kraus warrants the structure and finish of the Accessories to be free from defects in material and workmanship under normal usage for a
period of one (1) year from the date of purchase.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a
product of equal value at the option of Kraus.
Commercial Warranty
Kraus USA Plumbing, LLC (“Kraus”) warrants its Products for a period of one (1) year to commercial purchasers of Products used in
industrial, commercial and business applications.
Care and Cleaning Instructions
Certain cleaning products may cause damage to a Product's finish and use of the following on the Product will void this warranty:
·Abrasive cleaners such as powders, bleach, ammonia, alcohol or chorine
·Abrasive pads, steel wool or wire brushes
What is Not Covered
This warranty does not cover Products that were discontinued when purchased or display Products, whether such Products were purchased
at discount outlets, unauthorized dealers, and/or sold on clearance. This warranty does not cover any free gifts included with purchase.
This warranty does not cover damage resulting from neglect, misuse (including use for an unintended application), abuse, carelessness,
accident, hard water or mineral deposits, exposure to corrosive materials, improper maintenance, alteration of the Product, or failure to follow
care, cleaning or installation instructions enclosed with your Product. Kraus recommends that all Kraus Products be installed by a fully
licensed and insured trade professional with experience in the installation of bathroom and/or kitchen manufactured goods.
R

How to Make a Warranty Claim
If you are a consumer purchaser, please contact a Kraus Customer Service Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an authorized partner, please contact a Partner Support Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide your proof of purchase and a description of the problem. Shipping charges will be covered
for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto Rico shipping charges may apply). International shipping fees are
not included.
Limitation on Duration of Implied Warranties
Please note that some states/provinces (including Quebec) do not allow limitations on how long an implied warranty lasts, so the below
limitations may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ANY IMPLIED WARRANTY, INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO THE STATUTORY PERIOD OR THE
DURATION OF THIS WARRANTY, WHICHEVER IS SHORTER.
Limitation of Special, Incidental or Consequential Damages
Please note that some states/provinces (including Quebec) do not allow the exclusion or limitation of special, incidental or consequential damages,
so the below limitations and exclusions may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY
DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
This warranty gives you specific legal rights, and you may also have other rights which vary from state/province to state/province.
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance
R

Register Your Kraus Product
Activate Your Warranty
Access Premium Customer Support
Get Product Information
REGISTER TODAY
http://www.kraususa.com/registration
R
