KROHNE OPTISWITCH 5300 C User manual

OPTISWITCH 5300 C Handbook
Vibrating Level Switch
Two-wire 8/16 mA
With SIL qualication

2
Contents
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
Contents
1 About this document ............................................................................................................... 4
1.1 Function ........................................................................................................................... 4
1.2 Target group ..................................................................................................................... 4
1.3 Symbols used................................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 5
2.3 Warning about incorrect use............................................................................................. 5
2.4 General safety instructions............................................................................................... 5
2.5 Safety label on the instrument .......................................................................................... 6
2.6 EU conformity................................................................................................................... 6
2.7 Installation and operation in the USA and Canada ........................................................... 6
2.8 Safety instructions for Ex areas........................................................................................ 6
3 Product description ................................................................................................................. 7
3.1 Conguration.................................................................................................................... 7
3.2 Principle of operation........................................................................................................ 9
3.3 Adjustment ....................................................................................................................... 9
3.4 Storage and transport..................................................................................................... 10
3.5 Accessories.................................................................................................................... 10
4 Mounting................................................................................................................................. 12
4.1 General instructions ....................................................................................................... 12
4.2 Mounting instructions ..................................................................................................... 15
5 Connecting to power supply................................................................................................. 19
5.1 Preparing the connection ............................................................................................... 19
5.2 Connection procedure.................................................................................................... 20
5.3 Wiring plan, single chamber housing.............................................................................. 20
6 Setup ....................................................................................................................................... 23
6.1 General information........................................................................................................ 23
6.2 Adjustment elements...................................................................................................... 24
6.3 Function table................................................................................................................. 25
6.4 Proof test (WHG, SIL)..................................................................................................... 26
7 Maintenanceandfaultrectication...................................................................................... 32
7.1 Maintenance .................................................................................................................. 32
7.2 Rectify faults................................................................................................................... 32
7.3 Exchanging the electronics ............................................................................................ 33
7.4 How to proceed if a repair is necessary.......................................................................... 33
8 Dismount................................................................................................................................. 34
8.1 Dismounting steps.......................................................................................................... 34
8.2 Disposal ......................................................................................................................... 34
9 Supplement ............................................................................................................................ 35
9.1 Technical data ................................................................................................................ 35
9.2 Dimensions .................................................................................................................... 41
9.3 Trademark ...................................................................................................................... 44

3
Contents
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
Editing status: 2018-06-25

4
1 About this document
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
1 About this document
1.1 Function
This operating instructions manual provides all the information
you need for mounting, connection and setup as well as important
instructionsformaintenance,faultrectication,theexchangeofparts
and the safety of the user. Please read this information before putting
the instrument into operation and keep this manual accessible in the
immediate vicinity of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Information, tip, note
This symbol indicates helpful additional information.
Caution: If this warning is ignored, faults or malfunctions can result.
Warning: If this warning is ignored, injury to persons and/or serious
damage to the instrument can result.
Danger: If this warning is ignored, serious injury to persons and/or
destruction of the instrument can result.
Ex applications
This symbol indicates special instructions for Ex applications.
• List
The dot set in front indicates a list with no implied sequence.
→ Action
This arrow indicates a single action.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.

5
2 For your safety
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
only by trained specialist personnel authorised by the plant operator.
During work on and with the device the required personal protective
equipment must always be worn.
2.2 Appropriate use
The OPTISWITCH 5300 C is a sensor for point level detection.
Youcannddetailedinformationabouttheareaofapplicationin
chapter "Product description".
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.
2.3 Warning about incorrect use
Inappropriate or incorrect use of the instrument can give rise to
application-specichazards,e.g.vesseloverllordamagetosystem
components through incorrect mounting or adjustment.Thus dam-
age to property, to persons or environmental contamination can be
caused. Also the protective characteristics of the instrument can be
inuenced.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives. The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument. When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
During the entire duration of use, the user is obliged to determine the
compliance of the necessary occupational safety measures with the
current valid rules and regulations and also take note of new regula-
tions.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety

6
2 For your safety
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed and their meaning read in this oper-
ating instructions manual.
2.5 Safety label on the instrument
The safety approval markings and safety tips on the device must be
observed.
2.6 EU conformity
ThedevicefullsthelegalrequirementsoftheapplicableEUdirec-
tives.ByaxingtheCEmarking,weconrmtheconformityofthe
instrument with these directives.
2.7 Installation and operation in the USA and
Canada
This information is only valid for USA and Canada. Hence the follow-
ing text is only available in the English language.
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code.
2.8 Safety instructions for Ex areas
PleasenotetheEx-specicsafetyinformationforinstallationandop-
eration in Ex areas. These safety instructions are part of the operating
instructions manual and come with the Ex-approved instruments.

7
3 Product description
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• OPTISWITCH 5300 C point level switch
• Documentation
– This operating instructions manual
– Safety Manual "Functional safety (SIL)"
– Supplementary instructions manual "Plug connector for level
sensors" (optional)
– Ex-specic"Safety instructions" (with Ex versions)
– Ifnecessary,furthercerticates
The OPTISWITCH 5300 C consists of the components:
• Housing lid
• Housing with electronics
• Processttingwithtuningfork
1
2
3
4
Fig. 1: OPTISWITCH 5300 C - compact version with plastic housing
1 Housing lid
2 Housing with electronics
3 Temperature adapter
4 Processtting
Scope of delivery
Constituent parts

8
3 Product description
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
1
2
3
4
5
Fig. 2: OPTISWITCH 5300 C with plastic housing and tube extension
1 Housing lid
2 Housing with electronics
3 Temperature adapter
4 Processtting
5 Tube extension
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument:
• Article number
• Serial number
• Technical data
• Article numbers, documentation
Inadditiontothetypelabeloutsideontheinstrument,youndthe
serial number also inside the instrument.
Type label

9
3 Product description
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
3.2 Principle of operation
OPTISWITCH 5300 C is a point level sensor with tuning fork for point
level detection.
It is designed for industrial use in all areas of process technology and
can be used in liquids. It is particularly suitable for applications with
high temperatures up to 450 °C (842 °F) and high process pressure
up to 160 bar (2320 psig).
Typicalapplicationsareoverllanddryrunprotection.Thesmall
tuning fork allows use in all kinds of tanks and vessels. Thanks to its
simple and rugged measuring system, OPTISWITCH 5300 C is virtu-
allyunaectedbythechemicalandphysicalpropertiesoftheliquid.
Itfunctionsevenunderdicultconditionssuchasturbulence,foam
generation, buildup, external vibration or changing products.
The OPTISWITCH 5300 C is not suitable for use in pipelines.
Function monitoring
The electronics module of OPTISWITCH 5300 C continuously moni-
tors the following criteria via frequency evaluation:
• Strong corrosion or damage on the tuning fork
• Loss of vibration
• Break in the vibration drive circuit
If one of these faults is detected, the electronics signals it via a
denedcurrenttothesignalconditioninginstrument.Theconnection
cable to the sensor is also monitored for line break and short-circuit.
The tuning fork vibrates at its mechanical resonance frequency of
approx.1400Hz.Whenthetuningforkissubmergedintheproduct,
the frequency changes.This change is detected by the integrated
electronics module, passed on to the processing system as a current
value and converted there into a switching command.
Depending on your requirements, OPTISWITCH 5300 C with two-
wireelectronicscanbeconnectedtodierentsignalconditioning
instruments. Compatible signal conditioning instruments are listed in
chapter "Technical data".
Thedataforpowersupplyarespeciedinchapter"Technical data".
3.3 Adjustment
Withthefactorysetting,productswithadensity≥0.7g/cm³
(0.025lbs/in³)canbedetected.Theinstrumentcanbeadaptedto
products with lower density.
Ontheelectronicsmoduleyouwillndthefollowingdisplayand
adjustment elements:
• Signal lamp for indication of the operating status (green)
• Control lamp for indication of the switching status (yellow)
• Control lamp for fault indication (red)
• DIL switch for sensitivity adjustment
• Mode switch for selecting the switching behaviour (min./max.)
• Test key
Application area
Functional principle
Voltage supply

10
3 Product description
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
3.4 Storage and transport
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging of standard instruments consists of environment-
friendly, recyclable carton material.The sensing element is additional-
ly protected with a cardboard cover. For special versions, PE foam or
PE foil is also used. Please dispose of the packaging material through
specialised recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Storage and transport temperature see chapter "Supplement -
Technical data - Ambient conditions"
• Relative humidity 20 … 85 %
With instrument weights of more than 18 kg (39.68 lbs) suitable and
approved equipment must be used for lifting and carrying.
3.5 Accessories
Screwedangesareavailableindierentversionsaccordingtothe
following standards: DIN 2501, EN 1092-1, BS 10, ASME B 16.5,
JIS B 2210-1984, GOST 12821-80.
Youcanndadditionalinformationinthesupplementaryinstructions
manual "Flanges according to DIN-EN-ASME-JIS".
The electronics module SW E60 is a replacement part for level switch-
es OPTISWITCH 5300 C .
Youcanndinformationintheoperatinginstructionsmanualofthe
electronics module.
For connecting the sensors with a separator to voltage supply or sig-
nal processing, the sensors are also available with plug connectors.
Packaging
T
ransport
Transport inspection
Storage
Storage and transport
temperature
Lifting and carrying
Flanges
Electronics module
Plug connector

11
3 Product description
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
The following plug connectors are available:
• M12 x 1
• ISO 4400
• Harting HAN 7D
• Harting HAN 8D
• Amphenol-Tuchel

12
4 Mounting
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
4 Mounting
4.1 General instructions
Make sure that all parts of the instrument coming in direct contact
with the process, especially the sensor element, process seal and
processtting,aresuitablefortheexistingprocessconditions,such
as process pressure, process temperature as well as the chemical
properties of the medium.
Youcanndthespecicationsinchapter"Technical data" and on the
nameplate.
The instrument is suitable for standard and extended ambient condi-
tions acc. to DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1.
In general, OPTISWITCH 5300 C can be installed in any position.
The instrument only has to be mounted in such a way that the tuning
fork is at the height of the desired switching point.
The tuning fork has lateral markings (notches) that indicate the
switching point with vertical mounting. The switching point applies
to water in conjunction with the basic setting of the density switch
≥0.7g/cm³(0.025lbs/in³).WhenmountingOPTISWITCH5300C,
make sure that this marking is at the height of the requested switch-
ing point. Keep in mind that the switching point of the instrument will
shiftifthemediumhasadensityotherthanwater-wateris1g/cm³
(0.036lbs/in³).Forproducts≤0.7g/cm³(0.025lbs/in³)and≥0.47g/
cm³(0.017lbs/in³)thedensityswitchmustbesetto≥0.47g/cm³.
Keepinmindthatfoamswithadensity≥0.45g/cm³(0.016lbs/in³)
are detected by the sensor. This can lead to erroneous switchings,
particulary when the sensor is used for dry run protection.
2
3
14
Fig. 3: Vertical mounting
1 Switching point approx. 13 mm (0.51 in)
2 Switching point with lower density
3 Switching point with higher density
4 Switching point approx. 33 mm (1.3 in)
Suitability for the process
conditions
Suitability for the ambient
conditions
Switching point

13
4 Mounting
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
1
2
Fig. 4: Horizontal mounting
1 Switching point
2 Markingontopwiththreadedversions,markingalignedtoangeholeswith
angeversions
1
2
Fig. 5: Horizontal installation (recommended mounting position, particularly for
adhesive products)
1 Switching point
2 Marking with screwed version, facing up
Inthecaseofangeversions,theforkisalignedasfollows.
1
Fig.6:Forkpositionwithangeversions
1 Markingwithangeversion,facingup
Use the recommended cables (see chapter "Connecting to power
supply") and tighten the cable gland.
You can give your instrument additional protection against moisture
penetration by leading the connection cable downward in front of the
cableentry.Rainandcondensationwatercanthusdraino.Thisap-
plies mainly to outdoor mounting as well as installation in areas where
high humidity is expected (e.g. through cleaning processes) or on
cooled or heated vessels.
To maintain the housing protection, make sure that the housing lid is
closed during operation and locked, if necessary.
Makesurethatthedegreeofcontaminationspeciedinchapter
"Technical data" meets the existing ambient conditions.
Moisture

14
4 Mounting
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
Fig. 7: Measures against moisture ingress
1
2
Fig. 8: Housing position (self-emptying acc. to 3A)
1 Stainless steel housing (electropolished)
2 Aluminium die-cast housing
Caution:
Do not hold OPTISWITCH 5300 C on the tuning fork. Particularly with
angeortubeversions,thetuningforkcanbedamagedjustbythe
weight of the instrument.Transport coated instruments very carefully
and avoid touching the tuning fork.
Remove the packaging or the protective cover just before mounting.
The vibrating level switch is a measuring instrument and must be
treated accordingly. Bending the vibrating element will destroy the
instrument.
Warning:
The housing must not be used to screw the instrument in! Applying
tightening force can damage internal parts of the housing.
Use the hexagon above the thread for screwing in.
Metric threads
In the case of instrument housings with metric thread, the cable
glands are screwed in at the factory. They are sealed with plastic
plugs as transport protection.
You have to remove these plugs before electrical connection.
NPT thread
In the case of instrument housings with self-sealing NPT threads, it is
not possible to have the cable entries screwed in at the factory. The
Transport
Handling
Cable entries - NPT
thread
Cable glands

15
4 Mounting
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
free openings for the cable glands are therefore covered with red dust
protection caps as transport protection.
Prior to setup you have to replace these protective caps with ap-
proved cable glands or close the openings with suitable blind plugs.
4.2 Mounting instructions
The thread and the seal on the threaded version of OPTISWITCH
5300 C correspond to DIN 3852 part 2, screwed plug Form A.
Use screw-in openings or screw-in sleeves according to DIN 3852
part 2.
Make sure that with instruments with 1" NPT thread, the screw-in
opening on the vessel has an inside diameter of at least 29.5 mm
(1.16 in).
To mount the sensor, proceed as follows:
1. Screw the OPTISWITCH 5300 C into the mounting boss up to the
stop.You can determine the later position already before welding.
2. Mark the position of the OPTISWITCH 5300 C on the mounting
boss.
3. Mark the respective position of the mounting boss on the vessel.
In case of lateral mounting, make sure the mark on the spanner
atofOPTISWITCH5300Cpointsupwards.
4. Remove the OPTISWITCH 5300 C from the mounting boss
before welding.
5. Weld the mounting boss according to your marking.
Incaseofhorizontalmountinginadhesiveandviscousproducts,
the surfaces of the tuning fork should be vertical in order to reduce
builduponthetuningfork.Onthescrewedversionyouwillnda
marking on the hexagon. With this, you can check the position of the
tuning fork when screwing it in.
Inthecaseofangeversions,theforkisalignedwiththeangeholes.
When used in adhesive and viscous products, the tuning fork should
protrude into the vessel to avoid buildup. For that reason, sockets
forangesandmountingbossesshouldbeavoidedwhenmounting
horizontally.
Theprocessttingmustbesealedifthereisgaugeorlowpressurein
the vessel. Before use, check if the seal material is resistant against
the measured product and the process temperature.
Themax.permissiblepressureisspeciedinchapter"Technical
data" or on the type label of the sensor.
Note:
Sealforinstrumentswithprocessttingthread
The thread and the seal form on the mounting boss correspond to
DIN 3852, part 2, screwed plug Form A.
We recommend using a temperature and medium-resistant seal for
dismounting the instrument for maintenance and revision purposes.
Welded socket
Adhesive products
Pressure/Vacuum

16
4 Mounting
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
Instruments for high temperatures have a temperature adapter be-
tweenprocessttingandelectronicshousing.Thisisusedforthermal
decoupling of the electronics from high process temperatures.
Information:
The temperature adapter may be embedded in the vessel insulation
only up to max. 50 mm (1.97 in). Only then is a reliable temperature
decoupling guaranteed.
1
2
Fig. 9: Mounting the instrument on insulated vessels.
1 Temperature isolation - max. 50 mm (1.97 in)
2 Ambient temperature on the housing
IfOPTISWITCH5300Cismountedinthellingstream,unwanted
false measurement signals can be generated. For this reason, mount
OPTISWITCH 5300 C at a position in the vessel where no distur-
bances,e.g.fromllingopenings,agitators,etc.,canoccur.
This applies particularly to instrument types with long extension tube.
Mounting in the vessel
insulation
Inowingmedium

17
4 Mounting
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
Fig.10:Inowingmedium
To make sure the tuning fork of OPTISWITCH 5300 C generates as
littleresistanceaspossibletoproductow,mountthesensorsothat
the surfaces are parallel to the product movement.
Duetotheeectsofagitators,equipmentvibrationorsimilar,thelevel
switch can be subjected to strong lateral forces. For this reason, do
not use an overly long extension tube (optional) for OPTISWITCH
5300 C , instead check if it is possible to mount a short level switch
OPTISWITCH5300Conthesideofthevesselinhorizontalposition.
Extreme vibration caused by the process or the equipment, e.g.
agitators or turbulence in the vessel, can cause a long extension
tube of OPTISWITCH 5300 C to vibrate in resonance. This leads to
increased stress on the upper weld joint. Should a longer tube version
be necessary, you can provide a suitable support directly above the
tuning fork to secure the extension tube.
This measure applies mainly to applications in Ex areas of category
1GorWHGaswellastoshipclassications.Makesurethatthetube
is not subject to bending stress due to this measure.
Fig. 11: Lateral suppot of OPTISWITCH 5300 C
Productow
Agitators

18
4 Mounting
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
The second seal of the gas-tight leadthrough (option) prevents an
uncontrolled leakage of the medium.The service life of the gas-tight
leadthrough depends on the chemical resistance of the materials.
See "Technical data".
Caution:
If it is determined (e.g. via an error message from OPTISWITCH 5300
C ) that medium has already penetrated into the vibrating element,
the instrument must be exchanged immediately.
Gas-tight leadthrough

19
5 Connecting to power supply
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
5 Connecting to power supply
5.1 Preparing the connection
Always keep in mind the following safety instructions:
Warning:
Connect only in the complete absence of line voltage.
• The electrical connection must only be carried out by trained
personnel authorised by the plant operator.
• Alwaysswitchopowersupply,beforeconnectingordisconnect-
ing the instrument.
Inhazardousareasyoumusttakenoteoftherespectiveregulations,
conformityandtypeapprovalcerticatesofthesensorsandpower
supply units.
Connect the voltage supply according to the following diagrams.Take
note of the general installation regulations. As a rule, connect OPTIS-
WITCH 5300 C to vessel ground (PA), or in case of plastic vessels,
to the next ground potential. On the side of the instrument housing
there is a ground terminal between the cable entries.This connection
servestodrainoelectrostaticcharges.InExapplications,theinstal-
lationregulationsforhazardousareasmustbegivenpriority.
Thedataforpowersupplyarespeciedinchapter"Technical data".
The instrument is connected with standard two-wire cable without
screen. If electromagnetic interference is expected which is above the
test values of EN 61326 for industrial areas, screened cable should
be used.
Make sure that the cable used has the required temperature resist-
anceandresafetyformax.occurringambienttemperature
Use cable with round cross section for instruments with housing and
cablegland.Toensurethesealeectofthecablegland(IPprotection
rating),ndoutwhichcableouterdiameterthecableglandissuitable
for.
• 5 … 9 mm (0.20 … 0.35 in)
• 6 … 12 mm (0.24 … 0.47 in)
• 10 … 14 mm (0.40 … 0.55 in)
Useacableglandttingthecablediameter.
Inhazardousareas,useonlyapprovedcableconnectionsforOPTIS-
WITCH 5300 C .
Take note of the corresponding installation regulations for Ex applica-
tions.
Cover all housing openings conforming to standard according to
EN 60079-1.
Note safety instructions
Take note of safety
instructions for Ex
applications
Voltage supply
Connection cable
Connection cable
for Ex applications

20
5 Connecting to power supply
OPTISWITCH 5300 C • Two-wire 8/16 mA
48077-EN-180704
5.2 Connection procedure
With Ex instruments, the housing cover may only be opened if there is
no explosive atmosphere present.
Proceed as follows:
1. Unscrew the housing lid
2. Loosen compression nut of the cable gland and remove blind
plug
3. Remove approx. 10 cm (4 in) of the cable mantle, strip approx.
1 cm (0.4 in) of insulation from the ends of the individual wires
4. Insert the cable into the sensor through the cable entry
5. Open the terminals with a screwdriver
6. Insert the wire ends into the open terminals according to the wir-
ing plan
7. Tighten the terminals with a screwdriver
8. Check the hold of the wires in the terminals by lightly pulling on
them
9. Tighten the compression nut of the cable entry gland. The seal
ring must completely encircle the cable
10. Screw the housing lid back on
Theelectricalconnectionisnished.
5.3 Wiring plan, single chamber housing
The following illustrations apply to the non-Ex as well as to the Ex-d
version.
5
5
55
1 2
4
3
Fig. 12: Material versions, single chamber housing
1 Plastic (not with Ex d)
2 Aluminium
3 Stainless steel, precision casting
4 Stainless steel, electropolished (not with Ex d)
5 Filter element for air pressure compensation
Housing overview
