Krone WK 7.3 STG User manual

19/07/2023
EN
OPERATING INSTRUCTIONS
SWAP BODIES
505410825-02

Dear customer,
These are the instructions for the KRONE product you have purchased.
These instructions contain important information for the proper use and safe
operation of the KRONE product.
If these instructions should become completely or partially unusable for any
reason, you can order replacement instructions for your KRONE product by
stating the item number.
KRONE Telematics Support
Telephone: [phone]
email: [email protected]
Spare Parts
Telephone: [phone]
email: [email protected]
Internet: www.brueggen-service.de
Mobile repairs
Telephone: [phone]
email: [email protected]
Internet: www.brueggen-service.de
www.brueggen-gmbh.de
www.krone-trailer.com
www.krone-trailerparts.com

TABLE OF CONTENTS
Operating instructions • Swap bodies • 505410825-02 • 07/2023 3
Table of contents
1 Information about this document ................................................................. 7
1.1 Introduction....................................................................................................... 7
1.2 Other applicable documents............................................................................. 7
1.3 Product identification and type plate ................................................................ 7
1.4 Retention of documents ................................................................................... 8
1.5 Part positions.................................................................................................... 8
1.6 Optional components ....................................................................................... 8
1.7 Symbols used in these instructions .................................................................. 8
1.8 Copyright .......................................................................................................... 9
2 Safety............................................................................................................. 10
2.1 Warnings ........................................................................................................ 10
2.2 Intended use................................................................................................... 10
2.3 Personnel qualification and requirements ...................................................... 11
2.3.1 Operator ......................................................................................................... 11
2.3.2 Driving staff .................................................................................................... 11
2.3.3 Skilled craftsmen ............................................................................................ 12
2.4 Personal protective equipment....................................................................... 12
2.5 Information, warning, and mandatory signs ................................................... 12
2.6 Danger areas.................................................................................................. 13
2.7 General safety instructions............................................................................. 13
2.8 Warranty and liability ...................................................................................... 15
2.9 Environmental hazards................................................................................... 15
3 Product overview ......................................................................................... 16
4 Commissioning ............................................................................................ 20
4.1 Initial commissioning ...................................................................................... 20
4.2 Delivery and handover ................................................................................... 20
4.3 Commissioning before each trip..................................................................... 20
5 Operating the swap body ............................................................................ 21
5.1 Landing legs ................................................................................................... 21
5.2 Rear gantry..................................................................................................... 24
5.2.1 Doors.............................................................................................................. 25
5.2.2 Door stop........................................................................................................ 30
5.2.3 Rear wall ........................................................................................................ 33
5.2.4 Rear wall doors .............................................................................................. 35
5.2.5 Loading ramp ................................................................................................. 36

TABLE OF CONTENTS
4Operating instructions • Swap bodies • 505410825-02 • 07/2023
5.2.6 Top flap .......................................................................................................... 36
5.2.7 Rolling door .................................................................................................... 37
5.3 Step-on devices.............................................................................................. 39
5.3.1 Hand strap...................................................................................................... 39
5.3.2 Folding telescopic ladder................................................................................ 39
5.3.3 Fold-down steps ............................................................................................. 40
5.4 Sliding curtain superstructure......................................................................... 40
5.4.1 Side curtain .................................................................................................... 40
5.4.2 Curtain buckle ................................................................................................ 41
5.4.3 Curtain cramps ............................................................................................... 43
5.4.4 Front curtain tensioning device ...................................................................... 43
5.4.5 Rear curtain tensioning device ....................................................................... 45
5.4.6 Lateral load compartment limiter .................................................................... 46
5.4.7 Centre posts ................................................................................................... 48
5.5 Full-tarp superstructure .................................................................................. 51
5.5.1 Opening and closing the side curtain/rear curtain .......................................... 51
5.5.2 Lateral load compartment limiter .................................................................... 52
5.5.3 Centre posts ................................................................................................... 54
5.6 Roofs .............................................................................................................. 55
5.6.1 Roof tarp......................................................................................................... 55
5.6.2 Sliding roof ..................................................................................................... 55
5.6.3 Fixed roof (full-tarp superstructure) ................................................................ 56
5.6.4 Lifting roof....................................................................................................... 57
5.7 Power supply.................................................................................................. 59
5.8 Internal lighting ............................................................................................... 59
5.9 Stacking and unstacking swap bodies ........................................................... 60
5.9.1 Stacking the swap body ................................................................................. 60
5.9.2 Unstacking the swap body ............................................................................. 61
5.9.3 Supporting plates ........................................................................................... 62
5.10 Crane transport .............................................................................................. 63
5.10.1 Marked gripper surfaces................................................................................. 64
5.10.2 Stacking swap bodies..................................................................................... 64
5.11 Forklift transport ............................................................................................. 64
5.11.1 Forklift pockets ............................................................................................... 65
6 Loading and securing .................................................................................. 66
6.1 Lashing material ............................................................................................. 67
6.2 Ensuring form-fitting ....................................................................................... 69
6.3 Securing pallets with hoop casings and shrink-wrap...................................... 69
6.4 Additional aids ................................................................................................ 69
6.5 Lashing possibilities ....................................................................................... 69
6.6 Load securing rail ........................................................................................... 71
6.7 Pallet stop....................................................................................................... 71

TABLE OF CONTENTS
Operating instructions • Swap bodies • 505410825-02 • 07/2023 5
6.8 Keyhole plates................................................................................................ 71
6.9 Locking rods ................................................................................................... 71
6.10 Locking bars ................................................................................................... 73
6.11 Clamping rails................................................................................................. 73
6.12 Clothes rails.................................................................................................... 74
6.13 Strap net......................................................................................................... 75
6.14 Using the Multi Safe system........................................................................... 75
6.14.1 Using the Multi-Lock external frame............................................................... 75
6.14.2 Using the Multi Block system ......................................................................... 76
6.14.3 Using the Multi Wall system ........................................................................... 77
6.15 Vario Lock system .......................................................................................... 78
6.16 Folding second loading level .......................................................................... 79
6.17 Double-deck loading....................................................................................... 81
7 Telematics unit ............................................................................................. 87
7.1 Function description ....................................................................................... 87
7.2 Type plate....................................................................................................... 88
7.3 View................................................................................................................ 88
7.4 LED display .................................................................................................... 88
7.5 Battery ............................................................................................................ 88
7.6 Solar panel ..................................................................................................... 88
7.7 Data................................................................................................................ 89
8 Troubleshooting in the event of faults ....................................................... 90
9 Maintenance and repair ............................................................................... 91
9.1 Care and cleaning .......................................................................................... 91
9.2 Maintenance................................................................................................... 92
9.2.1 Regular checks and functional testing............................................................ 92
9.2.2 Maintenance intervals for the operator........................................................... 93
9.2.3 Maintenance intervals for the authorised specialist workshop ....................... 93
9.2.4 Lubricating the swap body.............................................................................. 94
9.2.5 Electrical equipment ....................................................................................... 94
9.2.6 Bolted connections ......................................................................................... 94
9.2.7 Load securing................................................................................................. 94
9.2.8 Locking mechanism........................................................................................ 95
9.3 Repair............................................................................................................. 95
10 Decommissioning ........................................................................................ 96
10.1 Temporary decommissioning ......................................................................... 96
10.2 Recommissioning ........................................................................................... 96
10.3 Final decommissioning and disposal.............................................................. 96

TABLE OF CONTENTS
6Operating instructions • Swap bodies • 505410825-02 • 07/2023
11 Spare parts and customer service.............................................................. 97
11.1 Spare parts..................................................................................................... 97
11.2 Customer service and support ....................................................................... 97
12 Technical data .............................................................................................. 98
12.1 products.......................................................................................................... 98
13 Legal requirements .................................................................................... 100
Index ............................................................................................................ 101

INFORMATION ABOUT THIS DOCUMENT
Operating instructions • Swap bodies • 505410825-02 • 07/2023 7
1 Information about this
document
1.1 Introduction
These operating instructions are intended
for the operator of the swap body and their
staff. The operating instructions are de-
signed to help you to get to know the swap
body and to use it within its intended pos-
sible uses.
It is mandatory that the operating instruc-
tions be read, understood, and applied by
every person who is tasked with the follow-
ing work on the swap body:
○ stacking and unstacking,
○ loading and unloading,
○ remedying operation interferences,
○ maintenance, and
○ disposal of operating and auxiliary ma-
terials.
The operating instructions contain import-
ant advice on how to operate the swap
body in a safe, competent, and economical
manner. They serve to
○ prevent risks and damages,
○ reduce repair costs and downtimes,
and
○ increase the reliability and durability of
the swap body.
KRONE cannot be held liable for damage
and operational interference caused by fail-
ure to observe these operating instructions.
The warranty conditions can be found in
our general terms and conditions of busi-
ness.
INFO
If you have any questions, please contact
KRONE customer service (see "11.2 Cus-
tomer service and support", pg.97).
1.2 Other applicable documents
For safe and failure-free operation of the
swap body, detailed knowledge of the indi-
vidual components is required.
Other documents also apply in conjunction
with these operating instructions.
► Please observe the following additional
documents, especially the safety in-
structions:
○ Operating instructions for the carrier
vehicle,
○ All instructions for additional parts and
components,
○ All instructions for additional equip-
ment and special equipment.
► Re-order any instructions that have
gone missing or become illegible (see
"11 Spare parts and customer service",
pg.97).
► When handling the vehicle and for all
maintenance work, please also ob-
serve:
○ The maintenance regulations for the
used installed components,
○ Load securing regulations.
1.3 Product identification and
type plate
Every swap body can be clearly identified
by the attached type plate. For product
identification, the type plate is attached in
the lower area of the front wall at the front
right in the direction of travel:
1
Fig.1-1: Type plate attachment points
1 Type plate

INFORMATION ABOUT THIS DOCUMENT
8Operating instructions • Swap bodies • 505410825-02 • 07/2023
The following information is listed on the
type plate:
3
1
2
4
5
67
Fig.1-2: Type plate
1 Manufacturer
2 Type designation
3 Customs number (optional)
4 Vehicle ID number
5 Year of construction
6 Curb weight
7 Permitted total weight
For vehicles without customs certificate,
the top line can be empty or be completely
omitted.
On stackable units, the vehicle ID number
is also embossed on the front right of the
corner fitting.
Moreover, identification plates with the
stacking load and the CSC mark can be
found beside the type plate.
The CSC regulation is a safety standard.
The CSC plates provides information about
the stackability, the permitted weights and
the registration number.
Fig.1-3: CSC plate
The product type plates are located in the
corresponding area of the components.
1.4 Retention of documents
► Store these instructions and all other
applicable documents in a safe place.
► Pass the complete documentation on
to the next driver or owner.
1.5 Part positions
The description of part positions is always
viewed in forward driving direction.
1.6 Optional components
KRONE swap bodies are equipped with a
number of optional components. The oper-
ating instructions describe all of the com-
ponents in the following sections.
All components are not necessarily
equipped on your swap body.
1.7 Symbols used in these in-
structions
Various markings and symbols are used in
the text in these instructions. These are ex-
plained below.
○ Bullet list
– Sub-list
1. Numbered list
þPrerequisite for action
► Action step
ðIntermediate action result
üResult of the action

INFORMATION ABOUT THIS DOCUMENT
Operating instructions • Swap bodies • 505410825-02 • 07/2023 9
Name of the software buttons
INFO
Additional information and tips.
: Also observe the enclosed supplier
documentation.
1.8 Copyright
These instructions represent an official
document within the meaning of laws
against unfair competition. They incorpor-
ate texts and drawings which, in their en-
tirety or partly, without written consent of
the manufacturer, are not to be
○ copied (except attached copy origin-
als),
○ published, or
○ made public by other means.
The copyright to these instructions remains
with
Fahrzeugwerk Bernard KRONE
GmbH & Co. KG, D‑49757 Werlte
Violations oblige compensation for dam-
ages.

SAFETY
10 Operating instructions • Swap bodies • 505410825-02 • 07/2023
2 Safety
This manual contains instructions for your
safety and for safe operation.
The basic safety instructions include in-
structions that apply fundamentally to the
safe use or the maintenance of the safe
condition of the swap body.
The action-related warnings warn you
about residual hazards and are found be-
fore a dangerous action.
► Follow all the instructions to prevent
personal injury, environmental or prop-
erty damage.
2.1 Warnings
Design and structure
The action-related warnings are structured
as follows:
!
WARNING
Type and source of the danger!
Explanation of the type and source of the
danger.
► Measures to avert the danger.
Hazard level
The warnings are classified according to
the severity of the danger. The following
explains the danger levels with their asso-
ciated signal words and warning symbols.
!
DANGER
Direct danger to life or serious injuries
!
WARNING
Possible danger to life or serious injuries
CAUTION
Possible slight injuries, environmental
damage or property damage
WARNING
Possible serious injury caused by crushing
CAUTION
Possible slight injury caused by crushing
NOTE
Possible environmental damage or prop-
erty damage
2.2 Intended use
Intended use includes the observance of
all operating and maintenance instructions
supplied with the swap body as well as the
observance of the maintenance intervals
and conditions prescribed therein.
KRONE swap bodies are intended exclus-
ively for transportation purposes in compli-
ance with applicable laws, rules and regu-
lations.
Operational reliability is only guaranteed if
all instructions, settings, and limitations ap-
plicable to the swap body are fully com-
plied with.
The swap body is produced with state-of-
the-art manufacturing systems in compli-
ance with all applicable safety-related laws,
rules, and regulations. Nevertheless, oper-
ation of the swap body involves dangers
for life and limb of the operator and other
personnel or risks of damage to the swap
body and other material damage.
► Swap bodies are only to be operated if
in perfect condition and only as inten-
ded, with awareness of safety and
hazards, and in compliance with the
operation instructions.
► Have any faults that could impair
safety immediately repaired by an au-
thorised specialist workshop.
For swap bodies with telematics unit, the
following also applies:
The KRONE Smart Collect Solar telematics
unit sends the collected data to the
KRONE server (KRONE Telematics Portal
and device management). The status and
position data for the swap body can be
called up through the portal.

SAFETY
Operating instructions • Swap bodies • 505410825-02 • 07/2023 11
Foreseeable misuse
Any use going beyond proper transport us-
age is considered non-intended. Avoid the
following:
○ Transport of persons or animals
○ Dangerous goods transports without
official and manufacturer approval
○ Transport of unsecured loads
○ Transport of materials, which due to
their properties, do not allow safe
handling and transport or only with ad-
ditional equipment
○ Driving with the rear gantry open
○ Exceeding the technically permitted
weights, dimensions, axle loads and
drawbar loads of the carrier vehicle
○ Exceeding the max. permissible total
weight
○ Use of components that are not ap-
proved by KRONE
Fahrzeugwerk Bernard KRONE GmbH &
Co. KG is not liable for damage resulting
from non-intended use. Risks deriving from
such infractions are exclusively borne by
the operator.
2.3 Personnel qualification and
requirements
KRONE swap bodies may only be used
and maintained by persons who are appro-
priately qualified and who have read and
understood the operating instructions.
In the operating instructions, a distinction is
made between:
○ Operator
○ Driving staff
○ Skilled craftsmen.
2.3.1 Operator
The operator is responsible for proper op-
eration of the vehicle. The operator must:
○ Instruct the driving and operating staff
in the use of the swap body.
○ Ensure that the swap body is regularly
inspected and serviced at an author-
ised specialist workshop.
2.3.2 Driving staff
The driving staff consists fundamentally of
the vehicle driver and a co-driver if applic-
able. The driving staff are responsible for
proper operation of the vehicle and must
○ have read and understood the operat-
ing instructions,
○ Have reached the legal minimum age.
When transporting, only driving staff may
be used who have received instruction
prior to the first deployment and who have
subsequently received verbal instruction at
least once a year relating to this work.
This instruction should particularly cover
the following points:
○ The operating instructions,
○ The measures to be taken in the event
of malfunctions.
Driving is limited to persons who have the
required driving license. In addition, the
drivers must receive training with respect
to:
○ The respective transport trailer and as-
sociated tractor unit,
○ The additional suppliers' information
listed (see "1.2 Other applicable docu-
ments", pg.7),
○ Motor Vehicle Traffic Regulations and
Motor Vehicle Construction and Use
Regulation, C.U.R., and
○ All relevant regulations that apply to
health and safety, accident prevention
and environmental protection in the
country of use, as well as
○ Other safety-related, occupational
health and road traffic regulations.

SAFETY
12 Operating instructions • Swap bodies • 505410825-02 • 07/2023
2.3.3 Skilled craftsmen
The skilled craftsmen of a specialist work-
shop are authorised to perform the main-
tenance work (maintenance and repair).
Authorised skilled craftsmen must have a
recognised qualification or have the relev-
ant knowledge of their specialised area re-
quired to meet the relevant regulations,
rules and guidelines.
2.4 Personal protective equip-
ment
Personal protective equipment serves to
avoid injuries and is prescribed by national
regulations depending on the cargo.
► Wear suitable personal protective
equipment when loading and unload-
ing.
○ Depending on the transported goods,
eyes, ears and respiratory tract must
be protected with suitable protective
equipment.
○ Gloves and safety shoes are generally
worn.
► Observe the national regulations re-
garding personal protective equipment.
► Always keep an eyewash bottle filled
with clean water at hand in the working
environment.
2.5 Information, warning, and
mandatory signs
There are information, warning, and man-
datory signs attached to the swap body.
► Observe and follow the signs.
► Keep the signs clean and legible.
► Do not remove, paint over or paste
over the signs.
► Immediately replace signs that have
become illegible or are missing.
Depending on the equipment and use, ap-
propriate pictograms are used in the in-
formation, warning and mandatory signs.
Sign Attachment point/meaning
Warning sign for tilt stability
Attachment point: Inside on the right rear door
Roof collision warning sign
Attachment point: Front wall, interior

SAFETY
Operating instructions • Swap bodies • 505410825-02 • 07/2023 13
Sign Attachment point/meaning
Warning sign for dead angle
Attachment point: Outside on the right rear door
Warning sign for loading flap
Attachment point: Outside on the loading flap
2.6 Danger areas
On and around the swap body, there are
areas with an increased risk to your safety
or to the safety of other persons.
► Observe the following danger areas
and instruct unauthorised persons to
leave these areas:
Danger area Danger
Loading and unload-
ing area
There is a risk of in-
jury on loose or un-
even ground or on
slopes.
Between the swap
body and the load
There is a risk of
crushing.
Connection between
carrier vehicle and
swap body
There is a risk of in-
jury when stacking
and unstacking the
swap body from the
carrier vehicle
through incorrect op-
eration when opening
and closing the lock-
ing and securing
devices.
Danger area Danger
Area approx.3m
(10ft) around the
swap body
There is a risk of ac-
cidents.
Under the raised
swap body
The raised swap
body could start mov-
ing if defective or
when being stacked
by a carrier vehicle
and could cause seri-
ous injury.
Roller shutter, doors,
board wall, loading
ramp
There is a risk of
crushing
2.7 General safety instructions
The basic safety instructions include all
safety measures sorted according to the
theme, and must always be observed.
Superstructure stability
The stability of the superstructure is ob-
tained by a variety of constructive meas-
ures and components.
► Do not make any changes to the deliv-
ery condition of the superstructure.
► Use the intended tensioning devices.

SAFETY
14 Operating instructions • Swap bodies • 505410825-02 • 07/2023
► Observe the instructions from the load
security certificates concerning the
components used.
Dangers while driving
There is a risk of impact on bridges, in tun-
nels or with other structures. Persons can
be injured or the vehicle, the transported
goods, and the structure can be severely
damaged.
► Observe the vehicle dimensions incl.
the transported goods.
► Observe the permissible passage di-
mensions (height, width).
► When driving in curves, be mindful of
the vehicle swivelling out.
Dangers when setting down
When setting down the swap body in a
public place, mark the swap body in com-
pliance with the legal requirements.
► Place supporting plates under the
landing legs if necessary.
Load securing
Unsecured or incorrectly secured loads
can result in poor road handling or even
accidents. Lost loads can cause injury to
other road users.
► Secure the load according to the re-
quirements of the relevant regulations
for load securing.
► Observe the instructions on the load
securing certificates.
Load distribution
Incorrect load distribution as well as im-
properly secured loads can lead to danger-
ous road handling and serious accidents or
damage to the vehicle.
► Observe the specified axle loads and
drawbar loads.
► Secure the load in accordance with the
applicable regulations.
► Ensure that the load securing aids are
not damaged and are functional.
Dangers caused by improper mainten-
ance
Improperly performed maintenance work
(care and cleaning, maintenance, repairs)
impairs the safety.
► Perform regular inspections for de-
fects.
► Perform care and cleaning work prop-
erly.
► Perform maintenance tasks according
to the instructions.
► Park the vehicle before performing any
work.
► Only have repair work carried out by
authorised specialist workshops or by
KRONE.
Operating materials
Operating materials (e.g. lubricants,
coolants, fuels) are hazardous to health.
Immediately seek medical attention upon
ingesting operating materials. If possible,
avoid breathing vapours. Do not allow op-
erating materials to come into contact with
the skin, eyes, or clothing. Clean affected
skin areas with water and soap. If it enters
the eyes, immediately and thoroughly
clean them with abundant clear water.
Change soiled clothing as soon as pos-
sible. Keep operating materials away from
children.
Noxious fumes
Fumes can cause serious health damage
or even death.
► Switch off generators, if possible.
► Ensure sufficient ventilation when the
engine is running.
► In closed rooms, extract exhaust
gases with a suitable extraction sys-
tem.
Technical safety
Technical safety refers to all electronic
devices, such as the telematics unit.

SAFETY
Operating instructions • Swap bodies • 505410825-02 • 07/2023 15
► In case of errors and malfunctions or if
the device falls down, interrupt work
immediately to prevent further dam-
age. The device should be examined
immediately by qualified specialist per-
sonnel for technical safety and proper
functioning
► Do not open the housing. Otherwise,
there is a risk of electric shock.
► Do not expose the device to naked
flame or burn them with rubbish.
► Damaged cables, plugs and other
components must only be replaced
with original spare parts and spare
parts authorised by Krone.
► During operation, check all of the
bolted and plug connections at regular
intervals.
2.8 Warranty and liability
The "General terms and conditions of sale
and delivery" from Fahrzeugwerk Bernard
KRONE GmbH & Co. KG fundamentally
apply.
Warranty and liability claims for personal
injury and material damage are excluded if
they are due to one of more of the follow-
ing causes:
○ Improper use (see "2.2 Intended use",
pg.10),
○ Failure to observe the instructions, re-
quirements and prohibitions of these
operating instructions and the operat-
ing instructions for the accessories,
○ Failure to follow the instructions, re-
quirements and prohibitions of the
maintenance instructions,
○ Unauthorised structural changes to the
KRONE product,
○ Inadequate monitoring of wear parts,
○ Improper maintenance or repairs not
being carried out in good time,
○ Use of non-approved and unsuitable
spare parts (see "11.1 Spare parts",
pg.97).
You can find the warranty conditions at
www.krone-trailer.com.
2.9 Environmental hazards
► Always observe environmental protec-
tion when operating.
► Avoid the release of operating materi-
als into nature and the environment.
► Dispose of operating materials and
other chemicals in accordance with the
applicable national regulations.

PRODUCT OVERVIEW
16 Operating instructions • Swap bodies • 505410825-02 • 07/2023
3 Product overview The following figures show examples of the
swap body superstructures.
1 2
34 4
5
Fig.3-1: Swap flatbed with sliding curtain superstructure
1 Sliding curtain superstructure
2 Rear gantry
3 Folding telescopic ladder
4 Landing legs with leg braces
5 Marked gripper surfaces

PRODUCT OVERVIEW
Operating instructions • Swap bodies • 505410825-02 • 07/2023 17
1
2
34 46
5
Fig.3-2: Swap flatbed with full-tarp superstructure
1 Full-tarp superstructure
2 Rear wall doors
3 Folding telescopic ladder
4 Landing legs with leg braces
5 Marked gripper surfaces
6 Board wall

PRODUCT OVERVIEW
18 Operating instructions • Swap bodies • 505410825-02 • 07/2023
1 2
34 4
5
Fig.3-3: Swap box
1 Box body superstructure
2 Rear gantry
3 Folding telescopic ladder
4 Landing legs with leg braces
5 Marked gripper surfaces
Usage designs
KRONE swap bodies are available as a
flatbed or box version. Essential character-
istics of the individual trailer types and their
special features are described briefly be-
low.
All swap bodies are also available as a
Mega version with a bigger load capacity.
Swap flatbeds
Swap flatbeds are used for typical trans-
port situations. They are designed as a
swap body with a sliding curtain, full-tarp or
as a plateau. To facilitate loading and un-
loading, swap flatbeds can be equipped
with a lifting roof.
Swap box
KRONE swap boxes (Dry Box) are swap
bodies for dry freight transport with variable
interior equipment.
Ribbed-steel Dry Box
The ribbed-steel Dry Box, the skeleton of
the superstructure is made of steel. The
side wall is made of ribbed sheet steel.
This type enables a great variety of interior
equipment (keyhole rails, wood panelling,
various lashing rails, double-deck, etc.)
Dry Box Plywood
With the Dry Box Plywood, the skeleton of
the superstructure is made of steel. The
side walls are made of plywood and can be
optionally equipped with strapping strips.

PRODUCT OVERVIEW
Operating instructions • Swap bodies • 505410825-02 • 07/2023 19
Dry Box with clinched sheet steel cas-
settes (smooth steel wall)
With the Dry Box with clinched sheet steel
cassettes, the superstructure is made of
steel. The smooth side walls are made of
galvanised sheet steel cassettes. This type
enables a great variety of interior equip-
ment (keyhole rails, wood panelling, vari-
ous lashing rails, double-deck, etc.).
Dry Box with sliding curtain on one side
The superstructure of this Dry Box has a
sliding curtain on one side, and the other
side of the box is made of clinched sheet
steel cassettes.
Dry Box Duoplex Steel, lightly insulated
With the Dry Box Duoplex Steel, based on
the insulated box body technology, the
light, insulated superstructure is made of
galvanised steel sheet. It is fitted with 30
mm thick Duoplex steel side panels and
optional integrated doubledeck guide rails
and strapping strips.
The following figure shows an example of
the swap body superstructure.

COMMISSIONING
20 Operating instructions • Swap bodies • 505410825-02 • 07/2023
4 Commissioning
4.1 Initial commissioning
Initial commissioning is performed by
Fahrzeugwerk Bernard KRONE GmbH &
Co. KG. The delivery from the factory or
production site is ready for operation.
► Check that the documentation
provided is complete.
► Obtain instruction on operation and
ask questions if necessary.
INFO
The transfer is not done by staff from
Fahrzeugwerk Bernard KRONE GmbH &
Co. KG.
4.2 Delivery and handover
Delivery and handover of the trailer takes
place at a production site of Fahrzeugwerk
BernardKRONEGmbH & Co. KG.
► Check that the documentation
provided is complete.
► Familiarise yourself with the product
and the documents.
► Obtain instruction on operation and
ask questions if necessary.
► Collect with a suitable carrier vehicle.
4.3 Commissioning before each
trip
Commissioning before each trip ensures
road safety and includes a check before
driving off and after loading and unloading.
► Prior to starting each trip, perform a
departure check:
1. Are the documents for the carrier
vehicle and swap body available?
2. Is the carrier vehicle suitable for the
transport task?
3. Are the applicable regulations for driv-
ing on public roads observed with the
transport tasks?
4. Have all accident prevention regula-
tions been complied with?
5. Are all existing superstructure com-
ponents of the swap body properly
fastened and/or closed and secured?
6. Have all locking mechanisms of the
carrier vehicle intended to secure the
swap body been properly closed and
secured?
7. Is the load properly distributed and
correctly secured?
8. Has the permitted maximum total
weight been adhered to?
9. Are all landing legs locked and doubly
secured?
► Fix any observed defects.
► Only drive the vehicle when road
safety is ensured.
