Krups Coffee Machine User manual

1
2
3
1
4 Oz
120 ml 3-8 Oz
80-240 ml
2
3
200 ml 50-250 ml
1
4
2
2
4
2
1
3
1
5
3
4
5
1x
2x
2x
1,75 Oz 50 ml
3,5 Oz 100 ml
5,3 Oz 100 ml
1-3,5 Oz 20-100 ml
1,4-7 Oz 40-200 ml
1,75-7 Oz 50-150 ml
7 Oz 1,75-9 Oz
Recommendation: For a perfect espresso,prewarm cups -> Pre-heat cups with hot water
Espresso
Do not use instant coffee or
instant drink powder
Espresso E.S.E single portions Ground coffee
Fill with grounds + press down
Insert single portion &
select correct size in filter holder
Eject single portion Eject grounds & rinse filter holder
Start coffee preparation:
Programming coffee
quantity
To program settings press and
hold button until desired quantity
is reached. Your selection will be
stored for future use.
Settings Programmable range
Attach the filter holder by turning it from left to right until it
clicks into the center position + place cups under outlets
Attach the filter holder by turning it from left to right until
it clicks into the center position + place cup under outlet
Set to coffee preparation
Press «small cup» -> start coffee preparation
Set to coffee preparation
Small cup
2 small cups
Big cup
Coffee flow stops automaticaly,
to pause -> press button again
Coffee flow stops automaticaly,
to pause -> press button again
2 cups or 1 large cup
Espresso: 1 measuring spoonful of well roasted espresso coffee grounds
Cappuccino: 1/3 coffee,1/3 hot milk, 1/3 froth
Café latte: 1/3 coffee,2/3 slightly frothy milk
Hot chocolate: slightly frothy hot milk and then stir in cocoa powder
Recipes
1 cup ground coffee or Espresso pod
On/off
Steam
Hot water
Cup warming plate
(It will be keep cups warm to a temperature of
about 40 °C with no risk of burning)
Brewing head
Coffee selectors
Water tank
First use
Pull out cord Insert plug
- do not fill with hot water,
mineral water,milk or other
liquids
Fill up Replace tank Insertfilter Remove tank
Water/FilterOn/off
Clean the heating system
Filter holder
Attach
Press button -> Heating-up
Place container (not
included) under nozzle
Insert empty fiter holder
Installation
Packaging
click
Drip tray grid
Coffee outlets
Cup warming plate
Filter holder
Steam button
Steam nozzle
Drip tray
Tray full indicator
Hot water button
Function selector
ON / OFF
Coffee
Milk container
Auto shut off 2 hours after pushing any button
Press 3x «big cup»
(300 ml)
3x
To stop/pause water flow -> press button again
Appliancereadyforcoffee ... for steam / hotwater
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric
shock and/or injury to persons, including the following:
- Read all instructions.
- Do not touch hot surfaces. Use handles or knobs.
- To protect against fire, electric shock and injury to persons,do not immerse cord, plugs, or appliance in water or other
liquid.
- Close supervision is necessary when any appliance is used by or near children.
- Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts,
and before cleaning the appliance.
- Do not operate any appliance with a damaged cord in order to avoid a hazard or plug or after the appliance
malfunctions, or has been damaged in any manner. Return appliance to your nearest authorized KRUPS Service
Center fo examination, repair or adjustment (see Limited Warranty)
- The use of accessory attachments not recommended by KRUPS may result in fire, electric shock or injury to
persons.
- Do not use outdoors.
- Do not let cord hang over edge of table or counter,or touch hot surfaces.
- Do not place on or near a hot gas or electric burner,or in a heated oven.
- To disconnect, turn switch to “OFF”, then remove plug from wall outlet.
- Do not use appliance for other than intended use.
- Use extreme caution when dispensing hot steam.
SAVE THESE INSTRUCTIONS
CAUTION
- This appliance is for household use only. Any servicing other than routine cleaning and user maintenance should be
performed by authorized KRUPS service personnel only (see Limited Warranty).
- Do not immerse base in water.
- To reduce the risk of fire or electric shock, do not remove the base of the machine.There are no user serviceable parts
inside. Repairs should be performed by authorized KRUPS service personnel only.
SPECIAL CORD SET INSTRUCTIONS
Regarding your Cord Set:
A. A short power-supply cord is provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.
B. Longer extension cords are available and may be used if care is exercised in their use.
C. If a long extension cord is used, (1) the marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance, (2) the longer cord should be arranged so that it will not drape
over the counter top or table top where it can be pulled on by children or tripped over.
D. This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock,
this plug is intended to fit into a polarized outlet only one way. If the plus does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.
Recommend folding down the paper edges
... System heats up
Cappuccino
Programming steam for
frothing milk
Select steam Appliance ready
Remove and clean frothing
accessory
Hot nozzle! (danger of burning)
Place container under
nozzle Flush out residual milk
Stops automaticaly
to pause -> press button
Cleaning the Auto cappuccino nozzle
Clean the nozzle well
with a damp cloth
Setting Programmable range
To program settings,press and hold button until
desired quantity is reached. Your selection will be
stored for future use.
Set to steam
Fill receptacle with cold milk Put milk container at the
nozzle and hold cup under
the nozzle
Press steam button
after preheating
Prepare espresso accordingly
to section entitled “Espresso”
Stops automaticaly,
to pause -> press button
Hold cup under the
nozzle
Hot water
Programming hot water
Press hot water button
Set to steam
Stops automaticaly,
to pause -> press button
Setting Programmable range
Toprogramsettings, press and hold button
until desired quantity is reached. Your
selection will be stored for future use.
Turn the knob to the
cappuccino position
Comments

XP 5080
Autocappuccino
3x
2
3
4
1max. 0,5 ltr.
2 sec.
5
1-800-418-3325
Can
Maintenance
Before carrying out maintenance remove
the plug from the outlet and allow the
appliance to cool down
Do not rinse / clean accessory parts in
the dishwasher Wipe off with a soft damp cloth
Clean the appliance regularly using mild,
non-abrasive cleaning agents only
Fillwithfreshwaterbeforeuse Rinse regularly with hot water and mild dish soap,rinse
with clear water and dry off
Rinse regularly with hot water and mild dish soap, rinse
with clear water and dry off
Takeautocappuccino accessory apart,
rinse it in hot water and dry it off Suction opening blocked? – use a fine needle to unblock it
Accessories
*Measuring spoon / Nozzle key KRUPS descaling agent
available in Krups retail stores
*Filter cartridge
(Art.-Nr./
No.art.F088) (Art.-Nr./ No.art.F054)
Empty after approx. 7 - 8 cups
Rinse with hot water after each use
Cleanbrewingheadwithadamp
cloth
When not in use -> remove from brewing head
If the brewing head is heavily clogged up, unscrew the brewing
grid using a coin, clean under running water, see «Descaling»
Troubleshooting
- Pre-heat cups with hot
water
Coffee is not hot enough
- Positionfilter holder correctlyEspresso leaks around the filter holder
- Fill the water tankPump is very noisy - Press firmly on the
water tank
- Fill water in the watertank
and press firmly in place
Water doesn’t run trough - Clean the filter and
the grid on the head
-Nozzle blocked?
-> use a fine needle to unblock it
The milk is not very frothy - Use very cold and
very fresh milk - Try a different brandof milk
- Try a finer coffeeWater runs through too quickly - Fill with more grounds - Press down the coffee in the
filter holder more firmly
The espresso has no crema
(froth on coffee) - Use very fresh coffee- Try a finer coffee
Lots of water on the coffee grounds - Fill with more grounds
Please read the TSM Success Manual® before operating the appliance. In order to obtain beverages of good
quality and to avoid damage or injury, follow the instructions precisely.Ensure that these instructions are given
to any other users of the appliance and that they are kept in a safe place so that they can be referred to at any
time. The appliance has been strictly checked for safety and correct operation. It left the factory in fault-free
working order.
Operating manual
Consumer Service
- Descale appliance
If the descaling procedure stops prematurely, a rinse has to be done before resetting.
Descaling
The descaling frequency depends on the water hardness and frequency of use
Only use KRUPS descaling agent (art. no.F054)!
*Delivered with the appliance
- Clean the filter holder
- Press down the coffee in
the filter holder more firmly
For domestic use only
The warranty does not include espresso machines which do not function, or do not function properly,
because descaling has not been carried out.
Changing filter cartridge
The filter cartridge provides clean,clear and fresh water for perfect tasting espresso by
reducingwaterimpurities like chlorine.It also protects theespressomaker by reducing limescale
build-up.When using the Krups filter cartridge, one descaling per year will be sufficient.
Web site: www.KrupsUSA.com
Fill with water and descaling agent
*Milk container
-Plunge the total filter holderinhot
water during 15 min.
Filter holder very difficult to adjust
(1 or 2 cups)
Changefilter
cartridge Packaging Fill up
After descaling: Clean the system according
to section entitled “First use”
Place container under nozzle Press and hold both buttons for 2 sec.
-> 10 Oz / 300 ml of water will be
pumped through steam nozzle
If buttons are flashing before
starting: Change filter cartridge!
Rinse water tank thoroughly -> set up Place container under nozzle
-> press «hot water»
Place container below outlet -> press «small
cup»
Fill up
Press for 2 sec. hot water button Appliance switches on and preheats
If appliance is ready press hot water button -> Descaling start (approx. 10 min.)
Disassemble the brewing grid with a coin /remove
frothing accessory and putin container after rinsing Place container under nozzle
Turnappliance OFF
Place container under outlet Press «small cup» -> Descaling will continue until there is no water in tank Appliance ready for rinsing
- Do not fill with
hot water,
mineralwater,
milk or other
liquids
Switches off and let the
machine cool down Fillup
Replace tank: clean the system
according to section entitled “First Use”
Rinse brewing grid thoroughly -> set
up & re-attach
LIMITED WARRANTY
This Krups product is warranted for 1 year from the date of purchase against defects in material and workmanship.During
this period, the Krups product that, upon inspection by Krups,is proved defective, will be repaired or replaced, at Krups’
option, without charge to the customer.If a replacement product is sent, it will carry the remaining warranty of the original
product.This warranty does not apply to any defect arising from a buyer’s or user’s misuse of the product, negligence,failure
to follow Krups’ instructions, use on current or voltage other than that stamped on the product,wear and tear, alteration
or repair not authorized by Krups, or use for commercial purposes.
THE WARRANTIES SET FORTH HEREINARE EXCLUSIVE AND NO OTHER WARRANTIES,EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITEDTO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FORA PARTICULAR PURPOSE OR USE, ARE
MADE BY KRUPS OR AREAUTHORIZED TO BE MADE WITH RESPECTTO THE PRODUCT.
Some states do not allow limitation on how long an implied warranty lasts or do not allow the exclusion of incidental or
consequential damages, so the above limitations may not apply to you. This warranty gives you specific legal rights, and
you may also have other rights, which vary from state to state.
If you believe your product is defective, bring the product (or send it,postage prepaid) along with proof of purchase to the
nearest authorized Krups Service Center.(Please contact your respective countrys customer service department, indicated
below,for the address of the nearest authorized Krups Service Center.)
If you send the product, please include a letter explaining the nature of the claimed defect.
If you have additional questions, please call our Consumer Service Department:
USA:1-800-526-5377;
Mon – Fri 8:30 a.m. – 7:00 p.m.(EST).
www.KrupsUSA.com
Canada:1-800-418-3325;
Mon – Fri 8:30 a.m. – 4:30 p.m.(EST)
www.Krups.ca
Please note hours are subject to change.
Before calling the Consumer Service Department, please have the type number of your Krups appliance available.This
will assist in answering your questions.The type number is generally found on the bottom of the machine. It would be
helpful if you had the appliance available at the time of your call.
General correspondence can be addressed to:
USA:
Krups
196 Boston Avenue
Medford, MA 02155
Only letters can be accepted at this address. Shipments and packages that do not have a return authorization number
will be refused.
Canada:
Groupe SEB Canada Inc.
455 Finchdene Square
Scarborough, Ontario M1X1B7
USA 1-800-526-5377
Web site: www.Krups.ca
Coffee quantity in cup is too small
or too large - Re-programm coffee quantity as
described in Espresso section
- Recommend folding down
the paper as well
