Krups xp7225 ESPRESSERIA AUTOMATIC User manual

Household use only
The warranty excludes espresso machines that do not work or work incorrectly due to lack of cleaning,
failure to descale or due to the presence of foreign bodies in the grinder.
ESPRESSERIA AUTOMATIC
CCOONNSSUUMMEERRSSEERRVVIICCEEUUSSAA::11--880000--552266--55337777
CCaannaaddaa::11--880000--441188--33332255

www.krupsusa.com
www.krups.ca
www.krups.com.mx
001188000011112288332255MMeexxiiccoo::
* Actual model may vary slightly from photo
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page a1

PAGE
2 IMPORTANT SAFEGUARDS
4 PRODUCT DESCRIPTION
5 WELCOME
Recipes
Limits to use
6 BEFORE FIRST USE
Measuring water hardness
Claris - Aqua Filter System cartridge
7-8 PREPARING THE MACHINE FOR FIRST USE
Programming your machine
Rinsing the machine
Adjusting the grinder
8-9 PREPARING ESPRESSO AND PRESSURE BREWED COFFEE
Preparing an espresso (from 0.7 to 2.4 oz / 20 to 70 ml)
Preparing ordinary coffee (from 2.7 to 7.4 oz / 80 to 220 ml)
2-cup function
9-10 U S I N G STEAM
Frothing milk
Auto-Cappuccino Set
10 PREPARING HOT WATER
11 MAINTAINING YOUR MACHINE
Emptying the coffee grounds collector, the cleaning tray and the drip tray
Automatic cleaning program
12 AUTOMATIC DESCALING PROGRAM
General maintenance
13 OTHER FUNCTIONS
Maintenance
Settings
14 PRODUCT INFORMATION
Demonstration mode
Moving the machine
Electrical or electronic product at end of service life
15 PROBLEMS AND CORRECTIVE ACTIONS
16 LIMITED WARRANTY
CONTENTS
Actual model may vary slightly from photo
1
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 1

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and/or injury to persons including the following :
1. Read all instructions prior to first use.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to persons, do not immerse cord,
plugs or machine in water or other liquid and keeps hands and utensils out of the
bean container while grinding and when the machine is plugged in.
4. Do not put water into the coffee bean container and/or under the servicing flap.
5. Not intented for use by children.
6. Close supervision is necessary when any machine is used near children. Keep
machine out of reach of children.
7. Burns can occur from touching hot surfaces, hot water or steam. Exercise caution.
8. Exercise caution when using the steam nozzle as steam can cause scalding.
9. Unplug machine from outlet as soon as you stop using it and when you clean it. Allow
to cool before putting on or taking off parts, before cleaning the machine, and before
storing.
10. All appliances are subjet to stringent quality control. Practical tests using appliances
taken at random are conducted and this may explain any slight marks or coffee
residue showing prior to use.
11. Do not operate any machine with a damaged cord or plug or after the machine
malfunctions, or has been damaged in any manner. Return machine to the nearest
Krups Service Center for examination, repair or adjustement.
12. To reduce the risk of injury do not drape cord over the counter top or table top where
it can be pulled on by children or tripped over unintentionally.
13. Do not let cord hang over edge of table or counter, or touch hot surfaces.
14. The use of accessory attachments not recommended by Krups may result in fire, elec-
tric shock or injury to persons.
15. Do not use outdoors.
16. Do not place on or near a hot gas or electric burner, or in a heated oven.
17. To disconnect the machine, turn the control to “off” then remove plug from wall
outlet. Do not yank cord, instead grasp plug and pull disconnect.
18. Do not use the machine for other than intended use.
19. Do not pour liquids other than water and descaling solutions specified in this manual
into the water tank.
20. Protect the machine against humidity and freezing.
21. This machine is intended for household use only.
SAVE THESE INSTRUCTIONS
CAUTION
This machine is intended for household use only. Any servicing other than cleaning and
user maintenance should be performed by the nearest authorized Krups Service Center.
Visit our website at www.krups.com or contact our Consumer Service department for the
service center nearest to you.
To reduce the risk of fire or electric shock, do not dismantle the machine. Repair should be
done by an authorized Krups Service Center only.
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 2

3
SHORT CORD INSTRUCTIONS
AA..We do not recommend using an extension cord with this device.
BB..If an extension cord is absolutely necessary,
1) the marked electrical rating of the extension cord should be at least as great
as the electrical rating of the machine,
2) the longer cord should be arranged so that it will not drape over the counter
top or table top where it can be pulled on by children or tripped over.
CC..This machine has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way.
If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to modify the plug in any way.
In the interest of improving products, Krups reserves the right to change specifications
without prior notice.
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 3

4
Hot water button
OK validation button
Steam button
Rotating selection knob
Program settings button
“On/Off” button
Coffee grounds collector
Top view
Grinding fineness selector knob
Cleaning tablet pipe
DESCRIPTION
Cleaning tray
Water tank
Select (Rotate) Confirm (Push)
Metal grinding wheel
Quick reference guide
Coffee outlets with height adjusting
handles Water level floats
Steam nozzle
Knob
Cup warming tray
Coffee bean container
Coffee bean container lid
Drip tray grid
Digital display
Display screen
Water tank handle/lid
* Actual model may vary slightly from photos
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 4

5
Congratulations and thank you for your purchase of this Krups Espresseria Automatic
espresso machine. We are confident you will enjoy the versatility of this machine as well as
the convenience. Should you have any questions, please contact one of our specially
trained consumer service managers. They are available Monday through Friday from 8:30
am to 6:30 pm (EST) at 1-800-526-5377 for the US, and Monday through Friday from
8:30 am to 4:30 pm (EST) at 1-800-418-3325 for Canada.
We strongly recommend that you register this product as quickly as possible to ensure that
the warranty program is validated. As an incentive to do so, we will extend the
customary 1 year warranty by 6 months when you complete the enclosed product
registration card.
Enclosed in this box is the Krups VIP Exclusive Service Kit. Within this kit, we have
included everything you need to get started. Each kit contains 1 packet of descaling
powder, 2 cleaning tablets, water hardness testing strip, a full color instruction manual, and
1 Claris water filter.
Here are some recipes you can make using your Espresseria Automatic:
• Cappuccino
For a cappuccino, the ideal proportions are as follows:
1/3 steamed milk, 1/3 espresso, 1/3 milk froth.
• Caffe Latte
To make coffee with milk, also often called Latte Macchiato,
the proportions are as follows: 3/5 steamed milk, 1/5 espresso,
1/5 milk froth.
For these milk-based preparations, it is best to use cold skimmed milk
straight from the refrigerator (ideally between 6 and 8° C).
WELCOME
RECIPES
LIMITS TO USE
This Espresseria Automatic machine must only be used to prepare espressos or coffee, to
froth up milk and heat liquids. This product has been designed for domestic use only. Any
commercial or professional use, inappropriate use or failure to comply with th instructions will
void the warranty.
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 5

To get the best tasting coffee and espresso and to extend your machine’s service life, we advise you to use the Claris - Aqua
Filter System cartridge enclosed with this machine.
This filter system reduces chlorine, impurities, lead, copper, pesticides, etc. that may be present in the water. Minerals and
trace elements will then be preserved.
6
Before using the machine for the first time, you will need to complete an initial set up procedure to ensure that the machine will
operate properly. You will be asked to set the water hardness level, language, clock, date, and a few other options. The digital
display will walk you through each step and the initial set up takes just a few minutes. Please note, if you disconnect the
machine from the power source, you will need to complete parts of this process again.
BEFORE FIRST USE
After 1 minute the hardness measurement will appear.
This is the number you will be asked to program into the machine.
Filter the water using the
Claris - Aqua Filter System
cartridge to reduce
carbonate hardness,
chlorine, lead, copper,
aluminium*.
Your machine will give you
a message telling you when
to replace your Claris -
Aqua Filter System
cartridge.
The Claris cartridge needs
to be replaced for about
every 50 litres of water or
every two months at least.
Fill a glass with the
water you normally use
and immerse the test
strip.
Degree of
hardness
0
very soft
1
soft
2
moderately hard
3
hard
4
extremely hard
°f < 5,4° > 7,2° > 12,6° > 25,2° > 37,8°
°dH < 3° > 4° > 7° > 14° > 21°
°TH < 3,75° > 5° > 8,75° > 17,5° > 26,25°
1 sec.
012
34
MEASURING WATER HARDNESS
CLARIS - AQUA FILTER SYSTEM F 088 CARTRIDGE
* indications provided by the manufacturer
F 088
To install the water filter,
simply screw it into the
water tank.
Be sure to set the
date of installation for
reference in the future.
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 6

7
Pull out and fill the
water tank with fresh
water.
Select (rotate) Confirm (push)
Replace the tank, press
firmly to insure its fitted
properly. Close the lid.
Open the coffee bean
container lid. Add fresh
coffee or espresso beans.
Close the coffee bean
container lid again.
Check that the coffee beans do not contain any foreign particles, as any damage caused by the presence of
foreign particles will void the warranty.
Do not put water into the coffee bean container.
Remember to fit the drip tray to avoid waste water flowing onto the work surface and staining it or scalding you.
Be sure that the drip tray is properly installed to avoid overflow.
Do not fill the water tank with hot water, mineral water, milk or any other liquid. If you turn on the machine when the
water tank is not in place or not correctly filled (under the “min.” level,), the “fill water tank” light will come on.
This machine will not operate when the tank is empty.
Never put ground coffee in the coffee container.
When you first use your machine, it will ask you to set several parameters. If you disconnect your machine, you will again be
asked for some of these parameters.
Use the selector knob
to choose a language
(highlighted). Press the
OK key to validate.
Press “On / Off” to turn
your machine on. Follow
the instructions that
appear on the “choice of
language” screen.
Use the selector knob to choose a function and increase
or reduce values. Confirm your choice using the OK key.
PREPARING THE MACHINE FOR FIRST USE
PROGRAMMING YOUR MACHINE
The machine will ask you to set:
Language
Measurement unit
Date
Clock
Auto-off
Auto-on
Water hardness
Filter
You can select your chosen language from those offered.
Choose either ml or oz as your measurement unit.
You can set the date (mandatory if you use the Claris - Aqua Filter
System cartridge).
You can choose between 12 hour or 24 hour time display.
You can choose the period after which your machine will stop
automatically, from 30 minutes to 4 hours (by 30 minute increments).
You can automatically start pre-heating of your machine at your
chosen time.
You must set your water hardness between 0 and 4. See “Water
hardness measurement” section.
You must indicate whether a filter has been installed or not
(Claris - Aqua Filter System cartridge).
Take care when using oily espresso / coffee beans as excessive oil may clog the machine or grinder.
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 7

8
You can rinse the system once
the machine has been turned
on and pre-heating has been
completed.
Place a medium cup under the coffee
outlets then select “YES” from the
menu proposed.
The rinsing cycle will stop automatically
after about 1.3 oz / 40 ml.
Press button at any time to display menus to perform rinsing and then select MAINTENANCE => OK => RINSING.
You should periodically rinse the machine. We recommend for instance rinsing the machine if it has not been used for several
days. Use a large cup, choose the “Yes” option in the rinsing function and follow the instructions on the screen.
There are three fineness settings on this grinder. You can adjust the fineness to select your own personal preferences.
The finer the grind, the stronger the flavor. To change the grind, turn the knob during the grinding process.
CHANGE THE SETTING DURING GRINDING.
NEVER FORCE THE GRINDING FINENESS SETTING BUTTON.
CARAMELIZED COFFEE (e.g. flavor of strawberry) CAN BLOCK THE GRINDER.
Turn counter-
clockwise for
a finer grind.
Turn clockwise
for a coarser
grind.
RINSING THE MACHINE
ADJUSTING THE GRINDER
PREPARING ESPRESSO AND PRESSURE BREWED COFFEE
YOUR MACHINE IS DESIGNED TO MAKE COFFEE AND ESPRESSO FROM COFFEE BEANS ONLY.
When you first make coffee with the machine or after a prolonged period of non-use or a cleaning or
descaling procedures, a little steam and hot water will come out of the steam nozzle (priming).
Splashing or scalding may occur if the coffee outlets are set too high in relation to the size of the cups.
With a simple touch of a button, you can prepare 4 types of beverages : espresso, strong espresso, coffee and
strong coffee.
AAmmoouunnttooffwwaatteerr
Espresso 0.7 - 2.4 oz / 20 - 70 ml
Strong Espresso 0.7 - 2.4 oz / 20 - 70 ml
Coffee 2.7 - 7.4 oz / 80 - 220 ml
Strong Coffee 2.7 - 7.4 oz / 80 - 220 ml
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 8

9
Press the on/off button , wait for the end of pre-heating and perform a rinsing operation if you wish.
You can change the
volume of water at any
time using the rotating
knob.
Use the rotating button
to select your choice
and confirm by pressing
the OK button.
The selection menu will
be displayed.
PPlleeaasseennoottee::The ground coffee is first moistened with a little hot water after the grinding stage. This is called
“pre-brewing” and it optimizes the brewing process by ensuring that the grounds are evenly wet.
A few moments later, the full brewing cycle begins.
You can use your machine to make 2 cups of coffee or espresso by cycling the machine twice. Remember not to remove
the cups after the first cycle.
Put two cups under the
coffee outlets.
You can lower or raise the
coffee outlets to suit the
size of your cups.
Put a cup under the coffee
outlets.
You can lower or raise the
coffee outlets to suit the
size of your cups.
Select your drink and confirm
by pressing the OK button
twice. A message will appear
to tell you that you have
chosen two cups.
If the drip tray is full or the water tank is empty after preparing the first coffee, the second cycle will not function.
You will then have to restart your second cycle after you have emptied the tray and refilled the water tank.
The machine will
automatically
sequence through
two complete cycles.
To stop coffee flowing into the cup, you can either again press “OK” or turn the rotating button to reduce
volume.
x 2
TWO-CUP FUNCTION
There is a temperature setting function to control how hot your coffee is (see Settings).
USING STEAM
Steam is used to froth milk (for cappuccino / latte) but can also be used to reheat other liquids. As you need a higher
temperature to produce steam than to make an espresso, the machine runs an additional pre-heating phase for steam.
When the screen displays the selection menu, press the “steam” key . The screen will
inform you that the machine is being pre-heated. Once the pre-heating phase has been
completed, a message will ask you to place a container under the steam nozzle. Press the
“steam” key again to start generating steam. A little water will be produced first and
then steam will start. Use the same key to stop steam generation.
FALC DISP USA dernière version 7220.qxp 7/06/06 9:56 Page 9
