Krups ESPRESSO AUTOMATIC SERIE EA9000 User manual

DEFRNLIT
EN
ENGLISH
WWW.KRUPS.COM
ESPRESSO AUTOMATIC
SERIE EA9000
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page1

2
3
14
4
11
16
6
5
7
15
23
18
19
20
1
21
12
22
13
17
7
9
8
10
20
ENGLISH
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page3

KRUPS SERIE EA9000
WELC ME
Dear Customer,
Congratulations! You are now the proud owner of an Espresso Automatic Series EA9000. With
your machine, you can prepare a wide range of drinks; espressos, coffees or milk-based drinks,
entirely automatically. It is designed so that you can enjoy the same quality at home as in a
restaurant, whatever the time of the day and throughout the week. You will appreciate both the
quality of the result in your cup and its superior ease-of-use.
Thanks to its Compact Thermoblock System with built-in brewing chamber, its 15 bar pump, and
because it can use either coffee beans freshly ground just before the coffee is made or ground
coffee fed via a funnel, your machine will give you ristrettos, espressos and coffees hot from the
first cup with maximum aroma and a fine creamy golden-brown top.
With its exclusive and patented system for preparing milk-based drinks automatically, you can easily
make delicious cappuccinos and caffe lattes, without compromise: hot, with the “three layer effect”
and thick, creamy froth. Its automatic steam nozzle rinsing and cleaning programmes guarantee
hassle-free hygiene for long-lasting performance, cup after cup.
With the hot water function, you can prepare teas and other drinks instantaneously.
You can also personalise all of these drinks using the “Favourites” menu. You can set the volume,
proportions, intensity and temperature of your drinks.
The colour touch-screen makes navigation ergonomic and comfortable. It will guide you through
each step, from preparing your drink to servicing your machine.
We wish you many years of enjoyment with your Krups machine.
The Krups team
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page4

ENGLISH
A FEW EXPERT TIPS
Here are a few tips for achieving the best results from your machine:
nThe quality of your water significantly influences the quality of the flavours. Limescale and
chlorine can alter the taste of your coffee. We recommend that you use the Claris Aqua
Filter System cartridge or low mineral-content water to preserve all of the flavours of your
coffee.
nWhen preparing ristretto, espresso and coffee recipes, we recommend that you use
tulip-shaped porcelain cups, preheated beforehand (by running them under hot water, for
instance), and whose size is appropriate for the quantity you want to make. For your
cappuccino, caffe latte and hot milk recipes, we recommend that you use thick glass cups,
for an appealing, precise and gourmet presentation.
nRoasted coffee beans can lose their flavour if they are not protected. We recommended
that you use the amount of beans required for your consumption for the next 4-5 days. As
the machine automatically detects when there are no beans, you can be certain that you
will always have sufficient beans for preparing your coffee drinks. Though the quality of coffee
beans is subjective and varied, we can nevertheless recommend that you use arabica rather
than robusta. After a few trials, you will learn how to mix and roast the coffee beans
according to your tastes. Lastly, please remember that oily and caramelised coffee beans
must be avoided, as they can damage your machine.
nThe quality and fineness of the grinding determine the strength of the flavours and the quality
of the crema. The finer the ground, the richer the crema. Moreover, it must be adapted to
the drink you want: fine for ristretto and espresso, coarser for coffee. For your comfort, the
machine carries out this operation automatically.
nThanks to the ground coffee funnel and spoon, you can choose to serve your drink
differently. You can vary the flavours and strengths of your coffee as you wish. Ground coffee
should ideally be stored in the refrigerator in a hermetically sealed bag.
nYou can use pasteurised or UHT, skimmed, semi-skimmed or whole milk, straight from the
refrigerator (7°C). Using special milks (microfiltered, raw, fermented, enriched, etc.) can
produce less satisfactory results especially regarding the quality of the froth. However, we
recommend that you use fresh, cold milk for pre-programmed recipes.
DEFRNLIT
EN
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page5

KRUPS SERIE EA9000
The duration of this guarantee is 2 years.
Please check your guarantee card for more details on the guarantee conditions in your country.
This appliance is intended for domestic use only and is not suitable for commercial or professional use.
Any use other than domestic will void the guarantee.
The guarantee does not cover damage or faults resulting from improper use, repair by unauthorised
persons or non-observance of the instructions for use. The guarantee will become invalid if all of the
maintenance operations and instructions have not been followed, or if cleaning or descaling products
which do not comply with the original KRUPS specifications are used; if the Claris Aqua Filter System
water filter is not used in accordance with KRUPS instructions. Normal wear and tear of parts (grinding
disks, valves, seals) is exempted from the guarantee, as well as damages caused by foreign objects in
the coffee grinder (e.g. wood, stones, plastic parts etc.).
Caution: For the guarantee to be valid, this machine must be used only with Krups accessories.
!
Manufacturer
SAS GSM
Rue Saint-Léonard
F-53104 Mayenne
France
F 088 Claris -
Aqua Filter
System
cartridge
(1 cartridge
supplied)
XS 3000 Packet
of 10 cleaning
tablets (2 tablets
supplied)
F 054
Descaling
powder
(1 sachet
supplied)
ACCESS RIES (sold separately) Actual appearance may vary
Important: Read these instructions carefully and keep them for reference.
Please follow the safety guidelines.
!
XS 9000
(2 bottles of steam
nozzle cleaning liquid)
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page6

DEFRNLIT
EN
ENGLISH
CONTENTS
1
2
3
4
5
7
8
9
10
11
12
6
IMP RTANT INF RMATI N N THE APPLIANCE AND INSTRUCTI NS 6
1.1 Guide to the symbols used in the instructions................................................................................................. 6
1.2 Safety guidelines........................................................................................................................................................... 6
1.3 Correct use...................................................................................................................................................................... 8
1.4 Products supplied with your machine ................................................................................................................. 9
1.5 Factory check................................................................................................................................................................. 9
VERALL VIEW 10
2.1 Description of the appliance.................................................................................................................................. 10
2.2 Presentation of the different symbols................................................................................................................ 12
2.3 Main operations of the appliance........................................................................................................................ 12
FIRST USE 15
INSTALLING THE APPLIANCE 15
3.1 Before first use ............................................................................................................................................................ 15
3.2 Initial settings ............................................................................................................................................................... 16
3.3 Defining the settings ................................................................................................................................................. 16
PREPARING DRINKS 20
4.1 Information on recipes ............................................................................................................................................ 20
4.2 Preparing coffee-based drinks from coffee beans ...................................................................................... 22
4.3 Preparing coffee-based drinks from ground coffee .................................................................................... 26
4.4 Preparing other drinks: hot milk with or without froth, and hot water ............................................... 28
“FAV URITES” MENU 32
SETTINGS 35
INF RMATI N 37
MAINTENANCE AND CLEANING 39
8.1 Regular maintenance ............................................................................................................................................... 39
8.2 Maintenance menu.................................................................................................................................................... 41
8.3 Automatic cleaning programmes........................................................................................................................ 47
TR UBLESH TING 51
TECHNICAL DATA 54
TRANSP RT 54
DISP SAL F WASTE 54
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page7

KRUPS SERIE EA9000
6
IMP RTANT INF RMATI N N THE APPLIANCE
AND INSTRUCTI NS
nIn this manual you will find all of the important information concerning the preparation, use and
maintenance of your automatic coffee/espresso machine. Important safety guidelines are also included.
Read these instructions carefully before using your appliance for the first time and keep them for
reference: Krups may not be held responsible for any incorrect use.
1.1 Guide to the symbols used in the instructions
nSymbols and associated words used in these instructions.
1.2 Safety Instructions
Conditions of Use
nDo not immerse the appliance in water. Do not immerse the power cord or the mains plug in water or
any other liquid. Any contact of the conductive parts of the appliance with moisture or water may lead
to fatal injuries due to the presence of electricity! This appliance must only be used indoors in dry
areas.
nIn the case of a change in the ambient temperature, from cold to hot, wait for a few hours before
using your machine so that it is not damaged by condensation.
nAvoid leaving the appliance in direct sunlight, exposed to heat, cold, frost or humidity.
nDo not place the appliance on a hot surface such as a hob or close to a naked flame, in order to
avoid any risks of fire or other damage!
nKeep the appliance out of the reach of children.
1
SYMB L ASS CIATED W RD MEANING
Danger Warning against risks of serious or fatal injuries.
The lightning bolt symbol warns against electrical dangers.
Caution Warning against risks of incorrect operation, damage
or destruction of the appliance.
Important
Note General or important note on the operation of the appliance.
!
!
Important: These safety guidelines are intended to protect you and other persons, and the appliance.
They must therefore be respected.
!
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page6

DEFRNLIT
EN
7
ENGLISH
nThis appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
nChildren should be supervised to ensure that they do not play with the appliance.
nIn case of ingestion of any of the products supplied with the machine, inform your physician and/or
the poison control centre immediately.
Electrical power supply
nCheck that the supply voltage marked on the rating plate of the appliance is the same as that of
your electrical supply. Only connect the appliance to an earthed mains socket.
nEnsure that the mains socket is easily accessible so that the appliance can be unplugged easily,
for example in the event of any failure or a thunderstorm. For the safety of the appliance, unplug
it from the socket during thunderstorms. Do not pull on the power cord to unplug it from the
socket.
nUnplug it from the mains socket immediately if any operational failure occurs or if there is a problem
with brewing. Unplug the appliance when it is not to be used for a long period and when you are
cleaning it.
nDo not use the appliance if the power cord or the appliance itself is damaged.
nIf the power cord or the mains plug is damaged, they must only be replaced by an approved
KRUPS service centre.
nDo not let the power cord dangle over the edge of a table or a worktop. Do not leave the power
cord close to or in contact with the hot parts of the appliance.
nWe do not recommend the use of extensions or multi-adapter plugs.
nAny incorrect connection invalidates the guarantee.
Appliance
nDo not pour water into the coffee bean container and/or under the ground coffee funnel.
nExcept for cleaning and descaling as described in the instructions for the appliance, all work on
the appliance must be carried out by a KRUPS approved service centre.
nFor your safety, only use KRUPS approved accessories and consumables as they are perfectly
adapted to your appliance.
nUnplug the appliance when leaving the room or your home for prolonged periods.
nNever open the appliance, as there is a risk of fatal injury due to electricity! Any unauthorised
opening of the appliance invalidates the guarantee. Do not use your appliance if it is not working
correctly or if it has been damaged. In such cases, we recommend having the appliance checked
by a KRUPS approved service centre (see the list in the KRUPS Service handbook).
nFor safety and approval (CE) reasons, any transformation or modification of the appliance carried
out by an individual is prohibited, as only tested appliances have been approved and the
manufacturer is absolved of all responsibility in the event of damage.
Danger: Failure to respect these guidelines may lead to fatal injuries due to electricity!
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page7

KRUPS SERIE EA9000
8
nWhen producing steam for making cappuccino, hot milk or hot water, do not block the mechanism
that brings the steam nozzle forward, downward, upward or backward. In such cases, the
manufacturer is absolved of all responsibility in the event of damage to the appliance and the guarantee
will not apply.
nFor your safety, while producing steam for making cappuccino, hot milk or hot water, do not place
your hand under the steam nozzle.
nThe steam nozzle can be hot. Do not handle it during or immediately after a preparation.
nDo not place your hand or any other obstacle in front of the nozzle that can hinder the movement of
the nozzle.
nIf you do not set a cup in place or if you do so incorrectly, there may be risks of pinching or scalding.
nDo not put anything but ground coffee or the cleaning tablet in the funnel provided for this purpose;
do not add more than the maximum dose of ground coffee (1 spoon). In such a case, any damage
to the appliance will not be covered by the guarantee.
Use and Maintenance
nIn the event of a problem or incorrect operation, check the appliance and try to resolve the problem
(see Section 9: “Troubleshooting”) or have the appliance repaired if the problem persists.
nAlways refer to the instructions for descaling/cleaning the appliance. Unplug from the socket before
any maintenance operation.
nShould cleaning or regular maintenance not be carried out or if there is a foreign body in the grinder
or in the ground coffee funnel, the guarantee will not be valid.
1.3 Correct use
nThis Espresso Automatic Series EA9000 coffee/espresso machine must only be used to prepare
espresso, coffee, hot water or to froth milk.
nThis appliance is designed for domestic use only. It is not intended to be used in the following
environments and the guarantee will not apply for:
- staff kitchen areas in shops, offices and other working environments,
- farmhouses,
- by clients in hotels, motels and other residential-type environments,
- bed and breakfast-type environments.
nThis Espresso Automatic Series EA9000 coffee/espresso machine is not designed for commercial or
professional use. Any use other than that described in this manual does not comply with these
recommendations and may lead to injuries and damage to equipment as well as damage or destruction
of the appliance (see Section 1.2, “Safety guidelines”).
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page8

DEFRNLIT
EN
9
ENGLISH
1.4 Products supplied with your machine
nCheck the products supplied with your machine. If any parts are missing, contact our helpline (see
3.2: “Initial settings”).
Parts supplied:
nEspresso Automatic Series EA9000
n2 bottles of steam nozzle cleaning liquid
n2 cleaning tablets
n1 descaling sachet
nClaris – Aqua Filter System cartridge with fitting accessory
n2 cappuccino cups
nGround coffee spoon with built-in brush
n1 stick for testing water hardness
nInstructions
nList of approved Krups service centres
nGuarantee documents
n1 power cord
n1 cleaning needle
1.5 Factory check
nYour appliance has been checked and tested before leaving the manufacturing plant. Despite all
the care given to its cleaning, you may find traces of coffee in the coffee grinder and/or coffee
drops on the drip tray grid. Thank you for your understanding. We also recommend that you rinse
the appliance one or more times before you use it for the first time or if you have not used it for
several days.
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page9

KRUPS SERIE EA9000
10
VERALL VIEW
2.1 Description of the appliance
nThe fold-out page shows a photo of the appliance. Fold out this page. The various controls of the
appliance are listed below with a brief description of them:
2
No. IDENTIFICATI N FUNCTI N
1ON/OFF button To switch the appliance on and off.
2Ground coffee button To access the machine’s ground coffee function and to unlock
the ground coffee funnel.
3Colour touch screen To access the recipes and other functions of the machine.
4Removable water tank + lid Contains water for preparing recipes, cleaning and rinsing.
5Used coffee collector Collects the used ground coffee.
6Small drip tray and grid: can be
removed to position tall cups
To collect water or coffee that might flow out of the appliance
during/after preparation.
It can be removed to use taller cups (large recipes, caffe latte in
particular).
7arge drip tray with metal contacts
Collects water flowing out of the appliance (when draining the
Thermoblock and hydraulic system) or water coming from the
small drip tray.
8Steam/hot water nozzle
To produce steam to heat or froth milk.
r
To produce hot water.
9Steam/hot water tube
10 Steam nozzle tip
11 Steam nozzle cleaning container For automatic programmes that rinse and clean the milk nozzle.
12 Ground coffee funnel
Holds the ground coffee.
Holds the cleaning tablet during the automatic cleaning
programme.
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page10

DEFRNLIT
EN
11
ENGLISH
No. IDENTIFICATI N FUNCTI N
13 Cup rest To hold and preheat cups.
14 Right door To access the water tank.
15 eft door To access the cleaning liquid bottle, the ground coffee
spoon/brush and the used coffee collector.
16 Coffee nozzles and
height-adjustable handle To dispense the prepared coffee recipe.
17 Power cord To supply power to the machine (removable).
18 Cleaning liquid bottle Contains the product necessary for automatic cleaning of
the steam nozzle.
19 Cleaning liquid bottle drawer Holds the cleaning bottle (fitting).
20 Ground coffee spoon with built-in
brush
To measure the quantity of ground coffee necessary to
prepare a ground coffee.
The brush is used to remove ground coffee residue from
the ground coffee funnel.
21 Removable bean container lid
Closes the bean container. (Just open the removable lid
slightly using the notches on the side of the bean container.
Then it opens by itself.)
22 Coffee bean container Holds the coffee beans and is equipped with automatic
detection.
23 ED cup lighting Illuminates your drink as it is being prepared.
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page11

KRUPS SERIE EA9000
12
2.2 Presentation of the different symbols
nThe table below summarises all the symbols used on the screen:
To confirm the step.
To return to the previous step.
To scroll through the different options.
To bring the steam nozzle up in some menus.
To bring the steam nozzle down in some menus.
To go to the next step or stop a preparation in progress.
For example, during a cycle of cappuccino, to move from phase the foaming phase to the coffee
phase during coffee recipe or interrupt the coffee phase at the end of recipe.
To stop the cycle during preparation.
2.3 Main operations of the appliance
nTurning the appliance on or off
nFilling the bean container
Open the bean container
lid.
Put in the coffee beans. Close the bean container
lid.
Press the “On/Off”
button.
h
h
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page12

DEFRNLIT
EN
13
ENGLISH
n Filling the water tank
nEmptying the used coffee collector
nEmptying the drip trays
Open the right door. ift and pull the tank out. Replace the tank.Fill the tank.
Open the right door. Remove the used coffee
collector.
Replace the used coffee
collector.
Empty the used grounds.
Remove the small drip tray. Empty the small drip tray. Empty the large drip tray.
Wipe the metal contacts.
Remove the large drip tray.
Replace the large and small drip trays.
h h
hh
h
h
h
h
h
h
h
1
2
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page13

KRUPS SERIE EA9000
14
n Adjusting the coffee nozzle height
n2 espresso cups under the nozzles
nCoffee cup under the nozzles
nCappuccino cup on the small drip tray
nCaffe latte glass without the small drip tray
Your machine is supplied with two cups (for cappuccino and caffe latte).
h
h
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:38 Page14

DEFRNLIT
EN
15
ENGLISH
FIRST USE
3
INSTALLING THE APPLIANCE
nPlace your machine on a stable, flat, heat-resistant surface away from water splashes and
sources of heat. Ensure that the location chosen is sufficiently well ventilated, as the appliance
gives off heat. Please do not place the appliance on surfaces such as marble. Remove the
protective films from the display and grids.
3.1 Before first use
nBefore using the appliance for the first time, check the hardness of your water so that you can set
the appliance accordingly. This operation should also be carried out when you use your machine
in a place where the hardness of the water is different or if you notice a difference in the hardness
of the water. To check the water hardness, use the stick supplied with your machine or contact
your local water authority.
Measuring the water hardness
nFill a glass of water and immerse the stick in it for 5 seconds. Wait for a minute before reading the
water hardness. You will be asked for the hardness class observed (from 0 to 4) during the initial
setup of the machine. The red zones on the stick indicate the degree of hardness: class 0 = no red
zone, i.e. your water has a very low mineral content. Your water is more or less hard depending on
the number of red zones. The details of the classes are given in the table below:
Degree of
hardness Class 0 Class 1 Class 2 Class 3 Class 4
° dH < 3° > 4° > 7° > 14° > 21°
° e < 3,75° > 5° > 8,75° > 17,5° > 26,25°
° f < 5,4° > 7,2° > 12,6° > 25,2° > 37,8°
Appliance
setting 0 1 2 3 4
01234
The water hardness classes for the initial setting of the appliance (section 3.2)
Danger: Connect the appliance to an earthed mains socket. Voltage 220 - 240V. Failure to do
so means that you run the risk of fatal injury due to electricity! Respect the safety
guidelines (see section “Safety guidelines”).
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page15

KRUPS SERIE EA9000
16
nWhen your machine displays this screen to you, or when you have performed the water hardness test,
you must indicate the number of red and green zones, using the touch screen. If the stick shows 2
red zones and 2 green zones, press the first two red squares and the last two green squares on the
touch screen. The screen will then show an identical representation of your stick.
If you move home or if the quality of your water changes significantly, you can also reset the water
hardness at any time.
3.2 Initial settings
nWhen using the machine for the first time, you will be prompted to configure various settings. Follow
the indications displayed on the screen. The aim of the following paragraphs is to give you a few visual
cues.
3.3 Configuring the settings
nSwitch on the appliance by pressing the ON/OFF button (1). A welcome message is displayed on the
screen, followed by the “Language” setting menu. After each selection, you can go back by using the
symbol. Configure the other settings by following the indications on the screen.
LANGUAGE
n Your machine has a touch screen.
n Select a display language by pressing the arrows until “Hello” appears in the
language of your choice.
n Press OK to confirm.
H TLINE
n The number is associated with the country you have selected. However, you
can modify this number, as it may change over time.
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page16

DEFRNLIT
EN
17
ENGLISH
DATE
n The correct date should normally be displayed automatically. If necessary,
you can adjust the day, month and year using the arrows.
n Press OK to confirm.
TIME
n Press the desired time format.
n For 12 hour format (AM/PM): set the hours, the minutes and lastly AM or
PM. Press the corresponding box to confirm. You can go back using the
symbol.
n For 24 hour format: set the hours and then the minutes.
V LUME UNIT
n Select oz or ml as the volume unit, and press the corresponding box to
confirm.
AUT - FF
n Auto-off: you can select the length of time after which your appliance
switches off automatically: from 15 minutes to 2 hours, in steps of 15
minutes.
n Set the auto-off time using the arrows.
n Press OK to confirm.
WATER HARDNESS
n You must set your machine depending on the hardness of your water, from
0 to 4 (see p. 15 and p. 16).
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page17

KRUPS SERIE EA9000
18
INSTALLING THE FILTER (LATER)
n Press “Later” and confirm.
n Remove the water tank from inside the right door.
n Fill the water tank and then put it back in the machine.
n Close the right door again.
INSTALLING THE FILTER (N W)
n Filter installation: press “Now“.
n Open the right door of the machine and remove the water tank.
n Remove the filter cartridge and the fitting accessory from the packaging and
assemble the cartridge fitting accessory as illustrated.
n Set the month when the cartridge is fitted (position 1 on the illustration, left
side figure in the opening) by turning the grey ring located on the upper end
of the filter. The month when the cartridge should be replaced is indicated in
position 2 on the illustration.
n Attach the cartridge fitting accessory to the filter cartridge as shown in the
illustration.
n Take off the removable lid.
n Screw the filter cartridge into the screw thread at the bottom of the water
tank: place the filter cartridge into the thread and screw in the cartridge.
Remove the cartridge fitting accessory from the filter cartridge.
n Fill the water tank and then put it back in the machine.
n Close the right door. Your machine will fill the filter cartridge.
Note: The filter cartridge must be replaced approximately every 50 litres of water
or at least every 2 months. Your machine tells you how many days or litres remain
before you need to change the cartridge. (see Section 7, “Info menu”)
!
h
h
h
h
1
1
2
2
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page18

DEFRNLIT
EN
19
ENGLISH
Note: If the first use cycle is interrupted before it has fully completed, you will be asked to save certain
parameters again or to confirm certain settings.
!
Important: Ensure that all of the lids, covers and doors are closed and that all parts of the machine are
fitted correctly before starting to prepare a drink.
!
INSTALLING THE CLEANING LIQUID
n Press “Now” to confirm or “Later” to do it later.
n Open the left door (15). Pull the container (19) and screw the bottle (18)
onto the container.
n Replace the container back with the bottle and close the door.
n Do not screw in the bottle fully.
n The bottle must be positioned in line with the drawer.
AUT MATIC STEAM N ZZLE CLEANING PR GRAMME
n Your machine will prompt you to start this programme.
n To do so, press “Now“. The cycle will last about 5 minutes and the screen
will display the progress of the cleaning.
PREHEATING, AUT MATIC MAINTENANCE, RINSING
n The machine will start by preheating the circuits, then will carry out an
automatic test and finally will ask you if the appliance needs to be rinsed
or not.
n Place a container under the coffee nozzles and press YES if this is required.
The rinsing procedure starts and stops automatically, after around 40 ml
have passed through.
n The main drink selection menu is then displayed on the screen.
h
IFU_EN_KR_COFFEEMAKER_BARISTA_0828479_M se en page 1 15/06/11 10:11 Page19
