KSB Amarex Installation instructions

Submersible Motor Pump
Amarex
Sizes DN 50 to DN 150
60 Hz
NEMA
Installation/Operating Manual

Legal information/Copyright
Installation/Operating Manual Amarex
Original operating manual
All rights reserved. The contents provided herein must neither be distributed, copied, reproduced,
edited or processed for any other purpose, nor otherwise transmitted, published or made available to a
third party without the manufacturer's express written consent.
Subject to technical modification without prior notice.
© KSB SE & Co. KGaA, Frankenthal 10/2/2020

Contents
3 of 72
Amarex
Contents
Glossary .................................................................................................................................................. 5
1 General.................................................................................................................................................... 6
1.1 Principles ...........................................................................................................................................................6
1.2 Installation of partly completed machinery....................................................................................................6
1.3 Target group.....................................................................................................................................................6
1.4 Other applicable documents............................................................................................................................6
1.5 Symbols .............................................................................................................................................................7
1.6 Key to safety symbols/markings.......................................................................................................................7
2 Safety...................................................................................................................................................... 8
2.1 General..............................................................................................................................................................8
2.2 Intended use .....................................................................................................................................................8
2.3 Personnel qualification and personnel training.............................................................................................9
2.4 Consequences and risks caused by non-compliance with these operating instructions ..............................9
2.5 Safety awareness ..............................................................................................................................................9
2.6 Safety information for the operator/user.......................................................................................................9
2.7 Safety information for maintenance, inspection and installation ..............................................................10
2.8 Unauthorized modes of operation................................................................................................................10
2.9 Explosion protection ......................................................................................................................................10
2.9.1 Repair..................................................................................................................................................10
3 Transport/Storage/Disposal ................................................................................................................ 11
3.1 Checking the condition upon delivery..........................................................................................................11
3.2 Transport.........................................................................................................................................................11
3.3 Storage/Preservation ......................................................................................................................................11
3.4 Return to supplier...........................................................................................................................................12
3.5 Disposal ...........................................................................................................................................................12
4 Description of the Pump (Set)............................................................................................................. 14
4.1 General description ........................................................................................................................................14
4.2 Product information as per Regulation No 1907/2006 (REACH)..................................................................14
4.3 Designation.....................................................................................................................................................14
4.4 Name plate......................................................................................................................................................15
4.5 Design details..................................................................................................................................................15
4.6 Installation types ............................................................................................................................................16
4.7 Configuration and function...........................................................................................................................18
4.8 Scope of supply...............................................................................................................................................18
4.9 Dimensions and weights ................................................................................................................................19
5 Installation at Site................................................................................................................................ 20
5.1 Safety regulations...........................................................................................................................................20
5.2 Checks to be carried out prior to installation...............................................................................................21
5.2.1 Preparing the place of installation ...................................................................................................21
5.2.2 Checking the lubricant level..............................................................................................................21
5.2.3 Checking the direction of rotation ...................................................................................................22
5.3 Installing the pump set ..................................................................................................................................22
5.3.1 Stationary wet installation................................................................................................................23
5.3.2 Transportable model for wet installation ........................................................................................29
5.4 Electrical system..............................................................................................................................................30
5.4.1 Information for planning the control system ..................................................................................30
5.4.2 Electrical connection..........................................................................................................................33
6 Commissioning/Start-up/Shutdown................................................................................................... 36
6.1 Commissioning/start-up .................................................................................................................................36
6.1.1 Prerequisites for commissioning/start-up .........................................................................................36
6.1.2 Start-up...............................................................................................................................................36

Contents
4 of 72 Amarex
6.2 Operating limits..............................................................................................................................................37
6.2.1 Frequency of starts.............................................................................................................................37
6.2.2 Operation on the power supply mains.............................................................................................37
6.2.3 Operation on a frequency inverter...................................................................................................38
6.2.4 Fluid handled .....................................................................................................................................38
6.3 Shutdown/storage/preservation ....................................................................................................................39
6.3.1 Measures to be taken for shutdown ................................................................................................39
6.4 Returning to service .......................................................................................................................................40
7 Servicing/Maintenance........................................................................................................................ 41
7.1 Safety regulations...........................................................................................................................................41
7.2 Maintenance/inspection.................................................................................................................................42
7.2.1 Inspection work..................................................................................................................................43
7.2.2 Lubrication and lubricant change.....................................................................................................44
7.3 Drainage/cleaning ..........................................................................................................................................48
7.4 Dismantling the pump set..............................................................................................................................48
7.4.1 General information/Safety regulations...........................................................................................48
7.4.2 Preparing the pump set.....................................................................................................................49
7.4.3 Dismantling the pump section ..........................................................................................................49
7.4.4 Removing the mechanical seal and motor section ..........................................................................50
7.5 Reassembling the pump set...........................................................................................................................51
7.5.1 General information/Safety regulations...........................................................................................51
7.5.2 Reassembling the pump section .......................................................................................................51
7.5.3 Reassembling the motor section.......................................................................................................53
7.5.4 Leak testing........................................................................................................................................53
7.5.5 Checking the connection of motor/power supply ...........................................................................54
7.6 Tightening torques.........................................................................................................................................54
7.7 Spare parts stock.............................................................................................................................................54
7.7.1 Ordering spare parts..........................................................................................................................54
7.7.2 Recommended spare parts stock for 2 years' operation to DIN24296 ..........................................55
7.7.3 Spare parts sets ..................................................................................................................................55
8 Trouble-shooting.................................................................................................................................. 56
9 Related Documents.............................................................................................................................. 58
9.1 General assembly drawings with list of components...................................................................................58
9.1.1 General assembly drawing ................................................................................................................58
9.2 Exploded views with lists of components .....................................................................................................60
9.2.1 Exploded view....................................................................................................................................60
9.3 Wiring diagrams .............................................................................................................................................63
9.3.1 Wiring diagram, motor versions US and YS, star configuration for resin-sealed cable entry.......63
9.3.2 Wiring diagram, motor versions US and YS, star/delta configuration for resin-sealed cable entry ..
64
9.4 Flamepaths on explosion-proof motors........................................................................................................65
9.5 Sectional drawings of the mechanical seal...................................................................................................68
10 Certificate of Decontamination........................................................................................................... 69
Index ..................................................................................................................................................... 70

Glossary
5 of 72
Amarex
2573.830/01-EN-US
Glossary
Certificate of decontamination
If a product is to be returned to the manufacturer,
the customer declares in a certificate of
decontamination that the product has been
properly drained to eliminate any environmental
and health hazards arising from components in
contact with the fluid handled.
Close-coupled design
Motor directly fitted to the pump via a flange or a
drive lantern
Hydraulic system
The part of the pump in which the kinetic energy
is converted into pressure energy
IE3
Efficiency class to IEC60034-30:
3=PremiumEfficiency (IE = International
Efficiency)

1 General
6 of 72 Amarex
2573.830/01-EN-US
1 General
1.1 Principles
This operating manual is supplied as an integral part of the type series and variant
indicated on the front cover (for details, please refer to the table below).
Table1: Variants covered by this manual
Size Impeller type Material variant
G G1 G2 GH
50-140 F F F F F
50-220 F F F F F
65-150 F F F F F
65-170 F F F F F
65-230 F F F F F
80-140 D D - D D
80-150 F F F F F
80-170 D D - D D
80-180 F, D F, D F F, D F, D
80-220 F F F F F
80-230 F, D F, D F F, D F, D
100-140 D D - D D
100-170 D D - D D
100-180 F, D F, D F F, D F, D
100-230 F, D F, D F F, D F, D
150-180 F F F F F
150-230 F, D F, D F F, D F, D
The manual describes the proper and safe use of this equipment in all phases of
operation.
The name plate indicates the type series and size, the main operating data, the order
number and the order item number. The order number and order item number
clearly identify the pump set and serve as identification for all further business
processes.
In the event of damage, immediately contact your nearest KSB service facility to
maintain the right to claim under warranty.
1.2 Installation of partly completed machinery
To install partly completed machinery supplied by KSB refer to the sub-sections under
Servicing/Maintenance.
1.3 Target group
This operating manual is aimed at the target group of trained and qualified specialist
technical personnel. (ðSection2.3,Page9)
1.4 Other applicable documents
Table2: Overview of other applicable documents
Document Contents
Data sheet Description of the technical data of the pump (set)
General arrangement drawing/
outline drawing
Description of mating and installation dimensions
for the pump (set), weights
Hydraulic characteristic curve Characteristic curves showing head, flow rate,
efficiency and power input

1 General
7 of 72
Amarex
2573.830/01-EN-US
Document Contents
General assembly drawing1) Sectional drawing of the pump
Spare parts lists1) Description of spare parts
Supplementary operating
manual1)
E.g. for installation parts of stationary wet-
installed models
For accessories and/or integrated machinery components observe the relevant
manufacturer's product literature.
1.5 Symbols
Table3: Symbols used in this manual
Symbol Description
✓Conditions which need to be fulfilled before proceeding with the
step-by-step instructions
⊳Safety instructions
⇨Result of an action
⇨Cross-references
1.
2.
Step-by-step instructions
Note
Recommendations and important information on how to handle
the product
1.6 Key to safety symbols/markings
Table4: Definition of safety symbols/markings
Symbol Description
!DANGER
DANGER
This signal word indicates a high-risk hazard which, if not avoided,
will result in death or serious injury.
!WARNING
WARNING
This signal word indicates a medium-risk hazard which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION
This signal word indicates a hazard which, if not avoided, could
result in damage to the machine and its functions.
General hazard
In conjunction with one of the signal words this symbol indicates a
hazard which will or could result in death or serious injury.
Electrical hazard
In conjunction with one of the signal words this symbol indicates a
hazard involving electrical voltage and identifies information about
protection against electrical voltage.
Machine damage
In conjunction with the signal word CAUTION this symbol indicates
a hazard for the machine and its functions.
1If agreed upon in the scope of supply.

2 Safety
8 of 72 Amarex
2573.830/01-EN-US
2 Safety
!DANGER
All the information contained in this section refers to hazardous situations.
In addition to the present general safety information the action-related safety
information given in the other sections must be observed.
2.1 General
▪This operating manual contains general installation, operating and maintenance
instructions that must be observed to ensure safe operation of the system and
prevent personal injury and damage to property.
▪Comply with all the safety instructions given in the individual sections of this
operating manual.
▪The operating manual must be read and understood by the responsible specialist
personnel/operators prior to installation and commissioning.
▪The contents of this operating manual must be available to the specialist
personnel at the site at all times.
▪Information and markings attached directly to the product must always be
complied with and kept in a perfectly legible condition at all times. This applies
to, for example:
– Arrow indicating the direction of rotation
– Markings for connections
– Name plate
▪The operator is responsible for ensuring compliance with all local regulations
which are not taken into account.
2.2 Intended use
▪The pump set must only be operated within the operating limits described in the
other applicable documents.
▪Only operate pump sets which are in perfect technical condition.
▪Do not operate partially assembled pump sets.
▪Only use the pump set to handle the fluids described in the data sheet or product
literature of the pump variant.
▪Never operate the pump set without the fluid to be handled.
▪Observe the limits for continuous duty specified in the data sheet or product
literature (Qmin and Qmax) (to prevent damage such as shaft fracture, bearing
failure, mechanical seal damage, etc).
▪When untreated waste water is handled, the duty points in continuous operation
lie within 0.7 to 1.2×Qoptto minimize the risk of clogging/hardening.
▪Avoid duty points for continuous operation at very low speeds and small flow
rates (<0.7xQopt).
▪Observe the minimum flow rates and maximum flow rates indicated in the data
sheet or product literature (to prevent overheating, mechanical seal damage,
cavitation damage, bearing damage, etc).
▪Do not throttle the flow rate on the suction side of the pump set (to prevent
cavitation damage).
▪Consult the manufacturer about any use or mode of operation not described in
the data sheet or product literature.
▪Only use the respective impeller types in combination with the fluids described
below.

2 Safety
9 of 72
Amarex
2573.830/01-EN-US
Free-flow impeller
(impeller type F-max)
Suitable for the following fluids:
Fluids containing solids and stringy material as well as fluids with
entrapped air or entrapped gas
Open two-vane impeller
(impeller type D-max)
Suitable for the following fluids:
Waste water containing wet wipes and long fibers
2.3 Personnel qualification and personnel training
All personnel involved must be fully qualified to transport, install, operate, maintain
and inspect the machinery this manual refers to.
The responsibilities, competence and supervision of all personnel involved in
transport, installation, operation, maintenance and inspection must be clearly
defined by the operator.
Deficits in knowledge must be rectified by sufficiently trained specialist personnel
training and instructing the personnel who will carry out the respective tasks. If
required, the operator can commission the manufacturer/supplier to train the
personnel.
Training on the pump (set) must always be supervised by technical specialist
personnel.
2.4 Consequences and risks caused by non-compliance with these operating
instructions
▪Non-compliance with these operating instructions will lead to forfeiture of
warranty cover and of any and all rights to claims for damages.
▪Non-compliance can, for example, have the following consequences:
– Hazards to persons due to electrical, thermal, mechanical and chemical
effects and explosions
– Failure of important product functions
– Failure of prescribed maintenance and servicing practices
– Hazard to the environment due to leakage of hazardous substances
2.5 Safety awareness
In addition to the safety information contained in this operating manual and the
intended use, the following safety regulations shall be complied with:
▪Accident prevention, health regulations and safety regulations
▪Explosion protection regulations
▪Safety regulations for handling hazardous substances
▪Applicable standards, directives and laws
2.6 Safety information for the operator/user
▪Fit protective equipment (e.g. contact guards) supplied by the operator for hot,
cold or moving parts, and check that the equipment functions properly.
▪Do not remove any protective equipment (e.g. contact guards) during operation.
▪Provide the personnel with protective equipment and make sure it is used.
▪Contain leakages (e.g at the shaft seal) of hazardous fluids handled (e.g.
explosive, toxic, hot) so as to avoid any danger to persons and the environment.
Adhere to all relevant laws.
▪Eliminate all electrical hazards. (In this respect refer to the applicable national
safety regulations and/or regulations issued by the local energy supply
companies.)
▪If shutting down the pump does not increase potential risk, fit an emergency
stop control device in the immediate vicinity of the pump (set) during pump set
installation.

2 Safety
10 of 72 Amarex
2573.830/01-EN-US
2.7 Safety information for maintenance, inspection and installation
▪Modifications or alterations of the pump (set) are only permitted with the
manufacturer's prior consent.
▪Use only original spare parts or parts/components authorized by the
manufacturer. The use of other parts/components can invalidate any liability of
the manufacturer for resulting damage.
▪The operator ensures that maintenance, inspection and installation is performed
by authorized, qualified specialist personnel who are thoroughly familiar with
the manual.
▪Only carry out work on the pump (set) during standstill of the pump.
▪Only perform work on the pump set when it has been disconnected from the
power supply (de-energized).
▪The pump (set) must have cooled down to ambient temperature.
▪Pump pressure must have been released and the pump must have been drained.
▪When taking the pump set out of service always adhere to the procedure
described in the manual. (ðSection6.3,Page39)
▪Decontaminate pumps which handle fluids posing a health hazard.
▪As soon as the work has been completed, re-install and re-activate any safety-
relevant devices and protective devices. Before returning the product to service,
observe all instructions on commissioning. (ðSection6.1,Page36)
2.8 Unauthorized modes of operation
Never operate the pump (set) outside the limits stated in the data sheet and in this
manual.
The warranty relating to the operating reliability and safety of the pump (set)
supplied is only valid if the equipment is used in accordance with its intended use.
2.9 Explosion protection
Special conditions apply to the operation of explosion‑proof pumps.
▪The explosion-proof status of the pump set is only assured if the pump set is used
in accordance with its intended use.
▪The limits stated in the data sheet and on the name plate must not be exceeded
under any circumstances.
▪Correct monitoring of the motor temperature is imperative to ensure explosion
protection.
▪Observe the wiring diagrams.
▪Never operate an explosion-proof pump set without temperature monitoring.
▪Modifications or alteration of the pump set could affect explosion protection and
are only permitted after consultation with the manufacturer.
▪Only original spare parts and accessories authorized by the manufacturer must be
used for explosion-proof pumps.
2.9.1 Repair
Special regulations apply to repair work on explosion-proof pumps. Modifications or
alterations of the pump set can affect explosion protection and are only permitted
after consultation with the manufacturer.

3 Transport/Storage/Disposal
11 of 72
Amarex
2573.830/01-EN-US
3 Transport/Storage/Disposal
3.1 Checking the condition upon delivery
1. On transfer of goods, check each packaging unit for damage.
2. In the event of in-transit damage, assess the exact damage, document it and
notify KSB or the distributor and the insurance company about the damage in
writing immediately.
3.2 Transport
DANGER
Improper transport
Danger to life from falling parts!
Damage to the pump set!
▷Attach lifting accessories to the pump set handle only.
▷Never suspend the pump set by its power cable.
▷Use the lifting chain/rope included in the scope of supply exclusively for
lowering or lifting the pump set into/out of the pump sump.
▷Securely attach the lifting chain/rope to the pump and crane.
▷Use tested, marked and approved lifting accessories only.
▷Observe the regional transport regulations.
▷Observe the documentation of the lifting accessory manufacturer.
▷The load-carrying capacity of the lifting accessories must exceed the weight
indicated on the name plate of the pump set to be lifted. Take into account any
additional system components to be lifted.
3.3 Storage/Preservation
If commissioning is to take place some time after delivery, we recommend that the
following measures be taken for pump set storage:
CAUTION
Damage during storage due to humidity, dirt or vermin
Corrosion/contamination of the pump (set)!
▷For outdoor storage cover the pump (set) or the packaged pump (set) and
accessories with waterproof material.
CAUTION
Wet, contaminated or damaged openings and connections
Leakage or damage to the pump!
▷Clean and cover pump openings and connections as required prior to putting
the pump into storage.

3 Transport/Storage/Disposal
12 of 72 Amarex
2573.830/01-EN-US
Table5: Ambient conditions for storage
Ambient condition Value
Relative humidity 5% to 85%
(non-condensing)
Ambient temperature -4°F to 158°F [- 20°C to +70°C]
▪Store the pump set under dry and vibration-free conditions, if possible in its
original packaging.
1. Spray-coat the inside wall of the pump casing and, in particular, the impeller
clearance areas with a preservative.
2. Spray preservative through the suction nozzle and discharge nozzle.
It is advisable to then close the pump nozzles (e.g. with plastic caps or similar).
NOTE
Observe the manufacturer's instructions for application/removal of the preservative.
3.4 Return to supplier
1. Drain the pump as per operating instructions. (ðSection7.3,Page48)
2. Flush and clean the pump, particularly if it has been used for handling noxious,
explosive, hot or other hazardous fluids.
3. If the pump has handled fluids whose residues could lead to corrosion damage
in the presence of atmospheric humidity or could ignite upon contact with
oxygen, the pump must also be neutralized, and anhydrous inert gas must be
blown through the pump to ensure drying.
4. Always complete and enclose a certificate of decontamination when returning
the pump.
Always indicate any safety measures and decontamination measures taken.
(ðSection10,Page69)
NOTE
If required, a blank certificate of decontamination can be downloaded from the
KSB web site at: www.ksb.com/certificate_of_decontamination
3.5 Disposal
WARNING
Fluids, consumables and supplies posing a health hazard
Hazard to persons and the environment!
▷Collect and dispose of any preservatives, flushing liquids and fluid residues.
▷Wear safety clothing and a protective mask, if required.
▷Observe all legal regulations on the disposal of fluids posing a health hazard.
1. Dismantle the product.
Collect greases and other lubricants during dismantling.
2. Separate and sort the materials, e.g. by:
- Metals
- Plastics
- Electronic waste
- Greases and other lubricants
3. Dispose of materials in accordance with local regulations or in another
controlled manner.

3 Transport/Storage/Disposal
13 of 72
Amarex
2573.830/01-EN-US
Electrical or electronic equipment marked with the adjacent symbol must not be
disposed of in household waste at the end of its service life.
Contact your local waste disposal partner for returns.
If the used electrical or electronic equipment contains personal data, the operator is
responsible for deleting it before the equipment is returned.

4 Description of the Pump (Set)
14 of 72 Amarex
2573.830/01-EN-US
4 Description of the Pump (Set)
4.1 General description
Waste water transport, waste water management, drainage systems, waste water
treatment plants, stormwater transport, recirculation, sludge treatment
4.2 Product information as per Regulation No 1907/2006 (REACH)
For information as per chemicals Regulation (EC) No 1907/2006 (REACH), see http://
www.ksb.com/reach.
4.3 Designation
Table6: Designation example
Position
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
A R X D 1 0 0 - 2 3 0 / 0 3 6 C 4 U S G - 2 2 0 / 0 0 0 0 0 X 1 0 0
See name plate and data sheet See data sheet
Table7: Designation key
Position Code Description
1-3 Pump type
ARX Amarex
5 Impeller type
D-max Open two-vane impeller
F-max Free-flow impeller
6-12 Size
100 Nominal discharge nozzle diameter [mm]
230 Size of hydraulic system
14-16 Motor rating PN [kW]
012 1,24
... ...
084 8,40
17 Efficiency class2)
C IE3
F None
18 Number of motor poles
2 2 poles
4 4 poles
19 Motor version
U Non-explosion-proof, for fluid temperatures and ambient
temperatures up to 104 °F [40 °C]
Y Explosion-proof, for fluid temperatures and ambient temperatures
up to 104 °F [40 °C]
20 Motor construction type
S Wet installation
21-22 Material variant
G Standard variant, gray cast iron3)
2IEC60034-30 standard not binding for submersible motor pumps. Efficiencies calculated/determined according
to the measurement method specified in IEC60034-2. The marking is used for submersible motors that achieve
efficiency levels similar to those of standardized motors acc. to the IEC60034-30 standard.
3Depending on the configuration the impeller and suction cover of versions with D-max impeller are made of
nodular cast iron.

4 Description of the Pump (Set)
15 of 72
Amarex
2573.830/01-EN-US
Position Code Description
21-22 G1 Standard variant gray cast iron, impeller made of duplex stainless
steel
G2 Standard variant gray cast iron, impeller made of white cast iron
GH Standard variant gray cast iron, impeller and discharge cover
made of white cast iron
24-26 Nominal impeller diameter [mm]
090 90
... ...
220 220
28-36 00000X100 Additional design code
4.4 Name plate
ZN 3826 - M 74
TYPE
No.
Q
TEMP. MAX. °F lbs
MADE IN FRANCE
H
WARNING - DO NOT OPEN WHILE ENERGIZED
THERMALLY PROTECTED
MOTOR IP 68 SUBM. MAX. 82FT CLASS H
3~ M.-No.
V Hz PF
RPM FLA LRA SF 1.15
HP
P2
KSB S.A.S.
128, rue Carnot
59320 Sequedin
France
440 US gpm
ARX D100-170/046C2USG -135/12000L101
99729xxxxx /11700 /1
50 ft
104 257
460 60 0.72
3502 8.91 85.5
70262940
NG10LN02-170
2020
6.15
ZN 3826 - M 66
TYPE
No.
Q
TEMP. MAX. °F lbs
MADE IN FRANCE
H
WARNING - DO NOT OPEN WHILE ENERGIZED
THERMALLY PROTECTED
MOTOR IP 68 SUBM. MAX. 82FT CLASS H
3~ M.-No.
V Hz PF
RPM FLA LRA SF
HP
P2
XP CLASS I, DIV. 1 GROUPS C&D T 4
KSB S.A.S.
128, rue Carnot
59320 Sequedin
France
IP 68
1.15
ARX D100-170/046C2YSG -135/12020L101
99729xxxxx / 11700 /1
440 US gpm
70262940
50 ft
460 0.72
3502 8.91 85.5
104 251 2020
6.15
NG10LN02-170
60
a) b)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Fig.1: Name plate (example) a)Standard pump set, b)Explosion-proof pump set
1 Description 2 KSB order number
3 Flow rate 4 Maximum fluid and ambient temperature
5 Enclosure 6 Rated power
7 Rated speed 8 Rated voltage
9 Rated current 10 Head
11 Total weight 12 Year of construction
13 Maximum submergence 14 Thermal class of winding insulation
15 Motor number 16 Power factor at rated operating point
17 Service factor 18 Rated frequency
19 Starting current 20 Explosion protection marking
4.5 Design details
Design
▪Fully floodable submersible motor pump
▪Not self-priming
▪Close-coupled design
Drive
▪Three-phase asynchronous squirrel-cage motor
▪Type of protection Ex db IIB (applies to explosion-proof pump sets only)
▪Enclosure IP68 to EN60529/ IEC529
Shaft seal
▪Two bi-directional mechanical seals in tandem arrangement, with liquid reservoir

4 Description of the Pump (Set)
16 of 72 Amarex
2573.830/01-EN-US
Impeller type
▪Various application-oriented impeller types
Bearings
Motor-end bearings:
▪Grease-packed bearings sealed for life
▪Maintenance-free
Pump-end bearings:
▪Grease-packed bearings sealed for life
▪Maintenance-free
▪Reinforced bearings4)
4.6 Installation types
Table8: Installation type S, stationary wet installation
Installation type Description Comment
Guide hoop arrangement
P1: pump
P2: installation parts for guide hoop arrangement,
installation depth = 4.9ft/ 5.9ft/ 6.9ft
P5: claw
P7: chain and shackle
Only available for specific sizes,
see selection configurator.
Guide cable arrangement
P1: pump
P4: installation parts for guide cable arrangement,
installation depth = 14.8ft
P5: claw
P7: chain and shackle
4Standard for impeller type D-max, optional for impeller type F-max

4 Description of the Pump (Set)
17 of 72
Amarex
2573.830/01-EN-US
Installation type Description Comment
Single guide rail arrangement
P1: pump
P4: installation parts for single guide rail
arrangement
P5: claw
P7: chain and shackle
Only available for specific sizes,
see selection configurator.
Twin guide rail arrangement
P1: pump
P4: installation parts for twin guide rail arrangement
P5: claw and adapter
P7: chain and shackle
Only available for specific sizes,
see selection configurator.
Table9: Installation type P, transportable wet-installed model
Installation type Description
P1: pump
P6: pump foot
P7: chain and shackle

4 Description of the Pump (Set)
18 of 72 Amarex
2573.830/01-EN-US
4.7 Configuration and function
1
2
3
4
8
9
10
7
6
5
1 Shaft 2 Bearing bracket
3 Discharge cover 4 Discharge nozzle
5 Suction cover 6 Suction nozzle
7 Impeller 8 Shaft seal
9 Bearing, pump end 10 Bearing, motor end
Design The pump is designed with an axial fluid inlet and a radial outlet. The hydraulic
system sits on the extended motor shaft. The shaft runs in common bearings.
Function The fluid enters the pump axially via a suction nozzle (6) and is accelerated outward
in a cylindrical flow by the rotating impeller (7). In the flow passage of the pump
casing the kinetic energy of the fluid is converted into pressure energy. The fluid is
pumped to the discharge nozzle (4), where it leaves the pump. At the rear side of the
impeller, the shaft (1) enters the hydraulic system via the discharge cover (3). The
shaft passage through the cover is sealed to atmosphere with a shaft seal (8). The
shaft runs in rolling element bearings (9 and 10), which are supported by a bearing
bracket (2) joined to the pump casing and/or discharge cover.
Sealing The pump is sealed by two bi-directional mechanical seals in tandem arrangement.
A lubricant chamber in-between the seals ensures cooling and lubrication of the
mechanical seals.
4.8 Scope of supply
Depending on the model, the following items are included in the scope of supply:
Stationary wet installation (installation type S)
▪Pump set complete with connection cables
▪Claw with sealing elements and mounting elements
▪Mounting bracket with mounting elements
▪Base elbow with mounting elements
▪Guiding equipment5)
5The guide rails are not included in the scope of supply.

4 Description of the Pump (Set)
19 of 72
Amarex
2573.830/01-EN-US
Transportable model for wet installation (installation type P)
▪Foot plate or pump stool with mounting elements
▪Lifting rope/ lifting chain6)
NOTE
A separate name plate is included in KSB's scope of supply.
Attach this name plate in a clearly visible position outside the place of installation,
e.g. at the control panel, pipeline or mounting bracket.
4.9 Dimensions and weights
For dimensions and weights refer to the general arrangement drawing/outline
drawing or data sheet of the pump set.
6Optional

5 Installation at Site
20 of 72 Amarex
2573.830/01-EN-US
5 Installation at Site
5.1 Safety regulations
DANGER
Improper installation in potentially explosive atmospheres
Damage to the pump set!
▷Comply with the applicable local explosion protection regulations.
▷Observe the information given in the data sheet and on the pump/motor name
plates.
DANGER
Risk of falling when working at great heights
Danger to life by falling from great heights!
▷Do not step onto the pump (set) during installation work or dismantling work.
▷Pay attention to safety equipment, such as railings, covers, barriers, etc.
▷Observe the applicable local occupational safety regulations and accident
prevention regulations.
DANGER
Persons in the tank during pump operation
Electric shock!
Risk of personal injury!
Danger of death from drowning!
▷Never start up the pump set when there are persons in the tank.
WARNING
Hands, other body parts or foreign objects in the impeller or intake area
Risk of personal injury! Damage to the submersible motor pump!
▷Never insert your hands, other body parts or foreign objects into the impeller
and/or impeller intake area.
▷Check that the impeller can rotate freely.
WARNING
Impermissible solid objects (tools, screws/bolts or similar) in the pump sump/inlet
tank during pump start-up
Personal injury and damage to property!
▷Check the pump sump/inlet tank for impermissible solid objects before
flooding, and remove, if necessary.
