Kstove KS 8020HY User manual

FREESTANDING PELLET STOVE
WITH HOT WATER
(PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE)
Please register your K-Stove pellet stove
@
www.kstove.com

1
FREESTANDING PELLET STOVE
WITH HOT WATER
(PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE)
A LIFETIME OF WARMTH
*Please read this entire manual before installation and use of this pellet fuel burning room heater.
Failure to follow these instructions could result in property damage, bodily injury, or even death.
*Save these instructions!
INSTALLER: THIS MANUAL MUST STAY WITH APPLIANCE!
INTRODUCTION ....................................................................................3
1. WARNING AND WARRANTY ......................................................................4
1.1. SAFETY INSTRUCTIONS ..................................................................................................................... .4
1.2. OPERATING INSTRUCTION ...................................................................................................................5
1.3. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE
2002/96/EC ............................................................................................................................................. .5
1.4. GUARANTEE CONDITIONS .................................................................................................................. 6
1.4.1. Limitations .......................................................................................................................................6
1.4.2. Exclusions ....................................................................................................................................... 6
2. THEORETICAL NOTIONS FOR INSTALLATION ..........................................................7
2.1. Pellets ................................................................................................................................................ 7
2.2. PRECAUTIONS FOR INSTALLATION ................................................................................................... 8
2.3. OPERATING ENVIRONMENT ................................................................................................................ 9
2.4. CONNECTION TO THE EXTERNAL AIR INTAKE ................................................................................... . 9
2.5. CONNECTION OF SMOKE DISCHARGE PIPE ....................................................................................... .10
2.6. CONNECTION TO THE CHIMNEY ....................................................................................................... .10
2.7. CONNECTION TO AN EXTERNAL FLUE WITH INSULATED OR DOUBLE-WALL PIPE ............................... 10
2.8. CONNECTION TO THE FLUE PIPE ...................................................................................................... 11
2.9. OPERATING PROBLEMS CAUSED BY DRAUGHT DEFECTS IN THE FLUE .................................................. 11
2.10. HYDROLIC CONNECTION ..................................................................................................................12
3. INSTALLATION AND ASSEMBLY ................................................................... 12
3.1. DRAWINGS AND TECHNICAL CHARACTERISTICS................................................................................... 12
3.1.1. Dimensions of HYDRO stoves ............................................................................................................ 12
3.1.2. Technical DATA SHEET.................................................................................................................... 13
3.2. PREPARATION AND UNPACKING ................................................................................. ........................ 14
3.3. Hydro CONNECTION DIAGRAM ............................................................................... ............................ 14
3.3.1. Connections to the system ................................................................................................................ 15
3.3.2. Filling the water network ....................................................................................................................16
3.3.3. Water characteristics ........................................................................................................................ 16
3.4. KIT WATER PRODUCTION ................................................................................................................... 17

PELLET BURNING STOVES INSTALLATION & MAINTENANCE MANUAL
2
3.5. EXAMPLE INSTALLATION DIAGRAMS .....................................................................................................17
3.5.1. Installation diagram for heating system with domestic hot water kit (SUITE/CLUB/MUSA) ...................... 17
3.5.2. Heating installation in combination with a storage tank .........................................................................18
3.5.3. Heating installation diagram in combination with a boiler...................................................................... 19
4. OPERATION .................................................................................... 20
5. MAINTENANCE AND CLEANING .......................................................................32
5.1. DAILY OR WEEKLY CLEANING PERFORMED BY THE USER ..................................................................... .32
5.1.1. BEFORE EACH IGNITION ....................................................................................................................32
5.1.2. Check every 2/3 days .........................................................................................................................32
5.1.3. Cleaning the glass ..............................................................................................................................32
5.1.4. Cleaning of stainless steel and satin-finish surfaces ..............................................................................33
5.1.5. Cleaning of painted parts .......................................................................................................... ........33
5.2. CLEANING TO BE PERFORMED BY SPECIALIZED TECHNICIAN ................................................................33
5.2.1. Cleaning the heat exchanger and the pipe unit ........................................................................... ........33
5.2.1.1. CLEANING THE EXCHANGER AND PIPE UNIT (EGO/STAR) ............................................................33
5.2.1.2. CLEANING THE EXCHANGER AND PIPE UNIT (SUITE/MUSA and CLUB): ................................ ......34
5.2.2. Shutting the stove down (end of season) ............................................................................................34
5.3. CHECK OF INTERNAL COMPONENTS ....................................................................................................35
6. PROBLEMS / CAUSES / SOLUTIONS .................................................................37
7. ELECTRICAL DIAGRAMS ...........................................................................41
INSTALLATION AND MAINTENANCE MANUAL
INTRODUCTION
Dear Customer,
First, we wish to thank you for the preference granted to K-Stove ESIGN products and in particular to a stove from our
Hydro line.
In order to obtain the optimum performance of the stove and to enjoy the warmth and sense of wellness being that the
warmth of the flame can spread in your home, we recommend that you read this manual carefully before making the
first start- up of the stove.
Congratulations again , for your choice , please note that the pellet stove MUST NOT be used by children, which
should always be kept at a safe distance!
Revisions to the publication
In order to improve the product, to update this publication K-Stove DESIGN reserves the right to make changes without
notice.
Consultation
• Take care of this manual and keep it in a place of easy and quick access

PELLET BURNING STOVES INSTALLATION & MAINTENANCE MANUAL
3
• If this manual should be lost or destroyed, or if still in poor condition, ask for a copy from your dealer
• A key topic or that requires special attention is high lightened in a "bold text".
• "Italic text" is used to draw your attention to other sections of this manual or for any additional clarification.
SYMBOLS ON THIS MANUAL
WARNING:
This warning symbol indicates that you read and understand the message that is reported as
the non- observance of what is written, could cause serious damage to the stove and put at
risk the safety of the user.
INFORMATION:
This symbol is intended to emphasize the important information for the proper functioning of
the stove. A failure to comply with the requirements affect the use and operation of the
stove will prove unsatisfying.
SEQUENCE OF OPERATIONS:
Indicates a sequence of buttons to press to access the menu or make adjustments.
MANUALE (instruction manual)
Indicates you should read this manual or instructions.
1. WARNINGS AND WARRANTY
1.1. SAFETY INSTRUCTIONS
• Installation, electrical connection, check that the installation and maintenance are performed only by qualified and
authorized by K-Stove DESIGN.
• Install the heater according to the regulations of the place, region or state.
• This appliance is not intended to be used by people (including children) with reduced physical, sensory, mental, or
with limited experience and knowledge, unless they are trained to use the device or supervised by the person who is
fully responsible for his security.
• For the correct use of the stove and electronic equipment connected to it and to prevent accidents it is important to
follow and observe all indications and information and instructions reported in this manual.
• The use, regulation and settings must be carried out by an adult. Errors or bad settings can cause hazardous
conditions and / or erratic operation.
• Before starting any operation, the user or anyone who is about to operate on the stove must have read and correctly
and completely understood the entire contents of this instruction booklet.
• The stove must be intended solely for the purpose for which it is intended. Any other use is considered improper and
therefore dangerous under the full responsibility of those who make improper use, and therefore void with immediate
effect a guarantee thereof.
• Do not use the stove as a ladder or support structure.
• Do not put towels on the stove to dry.
• Any clothes or similar must be kept at a specific distance from the heater, due to possible fire hazard.

PELLET BURNING STOVES INSTALLATION & MAINTENANCE MANUAL
4
• Any liability for misuse of the product is solely responsible and design raises K-Stove from all civil and criminal
responsibility ;
• Any type of unauthorized tampering or substitution of non-original parts of the stove can be dangerous to the operator
safety and lifts K-Stove DESIGN from all civil and criminal.
• Most of the surfaces are very hot (door, door handle , front door glass, flue pipes, etc..). It is therefore necessary to
avoid contact with these parts without adequate protective clothing or special thermal protection , such as gloves and
thermal protection systems devices such as “ cold hands", not supplied with this oven and complete responsibility and
discretion of the end user .
• Explain carefully the danger to the elderly, disabled and particularly children, keeping them away from the stove
during operation.
• It is 'forbidden’ to operate the stove with the door open or with broken glass.
• Do not touch the stove with wet hands, being an electrical appliance. Always remove the power cord before opening.
• Before performing any cleaning or maintenance work make sure , in advance , to disconnect the heater from the
mains by unplugging the power cable.
• In case of fire in the chimney, turn off the stove, please disconnect from the network and never open
the door. Then call the appropriate authorities.
• The stove must be electrically connected to a network with grounded discharge facility.
• The stove must be connected to an electrical network appropriately sized to the electric power of the
stove.
• Incorrect installation or poor maintenance (non-conforming to the information in this booklet) can
cause damage to persons, animals or things. In this case K-Stove DESIGN is relieved of any civil or
criminal liability.
1.2. OPERATING INSTRUCTIONS
• Turn off the heater in case of failure or malfunction.
• NEVER manually load the pellet into the burner.
• The accumulation of unburned pellets in the burner after repeated "misfire" must be removed before
proceeding with a new ignition.
• Do not wash the inside of the stove with water.
• Do not wash the stove with water. Water may enter the unit and damage the electrical iinstallation,
causing electric shock.
• Do not expose your body to hot air for a long time. Do not overheat the room where you are
staying and where the stove is installed. This can damage the physical condition and cause health
problems.
• Do not expose to direct the flow of hot air plants or animals. It could have harmful effects on
plants or animals.
• Do not use other fuel other than EN-A1-Plus Certified – wood pellets .
• Install the stove in a suitable location which has available all necessary facilities required such as
fire prevention facilities and all necessary utilities are available such as – but not limited - power
supplies (air and electric) and exhaust fume, in conformity with the provisions in force.
• The storage of the stove and the ceramic coating must be stored in a dry and humidity free premises.
•
It is recommended to place the stove directly on the floor , and whereas this floor is made of flammable materials ,
in this case it is required to isolate properly.

PELLET BURNING STOVES INSTALLATION & MAINTENANCE MANUAL
5
• Never turn on any heater with flammable materials in the event of failure of the ignition system.
INFORMATION
In case of any problems, get in touch with your dealer, or a qualified engineer authorized by K-Stove, and if a repair
is necessary, insist on the use of original spare parts.
Use only the fuel recommended by K-Stove
Periodically check and clean the smoke outlet ducts (connection to the flue pipe).
Accumulated unburnt pellets in the burner after repeated failed ignitions must be removed before re-start
1.3. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC
.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service.
Disposing of a appliance separately avoids possible negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in
energy and resources.
As a reminder of the need to dispose of appliances separately, the product is marked with a crossed-out wheeled
dustbin.

GUARANTEE CONDITIONS
K-Stove guarantees the stove, excluding the components which are subject to normal wear, for a
period of one year from the date of purchase, as proved by a supporting document which gives the name of the vendor
and the date on which the sale took place. The guarantee is conditional on the guarantee certificate being filled in and
returned within 8 days or if you have your stove registered via www.kstove.com , and requires that the product be
installed and tested by a specialized installer, according to the detailed instructions given in the instruction booklet
supplied with the product.
The term 'guarantee' is to be understood to denote the free-of-charge replacement or repair of parts recognized to
have been defective at the start by reason of manufacturing defects.
1.4.1. Limitations
The above guarantee does not cover components relating to electrical and electronic parts, or fans, on which the
guarantee period is 1 year from the purchase of the product, documented as specified above. The guarantee does not
cover parts subject to normal wear such as gaskets, glass, and any parts with can be removed from the firebox.
The replacement parts will be guaranteed for the remainder of the guarantee period starting from the date of purchase
of the product.

PELLET BURNING STOVES INSTALLATION & MAINTENANCE MANUAL
6
1.4.2. Exclusions
Variations in color in the painted or ceramic parts, and crackling of the glaze on the ceramics, do not constitute grounds
for a claim under the guarantee, as they are natural characteristics of the material and of the use of the product.
The guarantee does not cover any parts which may be found to be faulty as a result of negligence or carelessness in use,
or of incorrect maintenance, or of installation not complying with the K-Stove specification (see the relevant chapters in
this user manual).
K-Stove refuses to accept any responsibility for any damage which may be caused, directly or indirectly, by persons,
animals or things in consequence of the failure to observe all the prescriptions laid down in the instruction booklet,
especially those concerning warnings on the subject of installation, use and maintenance of the appliance.
If the product does not perform correctly, contact your local retailer and or distributor.
Damage caused by transport and/or handling is excluded from the guarantee.
For installation and use of the product, reference must be made exclusively to the booklet supplied.
The guarantee will be invalidated in the event of damage caused by tampering with the appliance, atmospheric agents,
natural disasters, electrical discharges, fire, defects in the electrical system, and caused by lack of, or incorrect,
maintenance in terms of the manufacturer's instructions.
CLAIMS UNDER THE GUARANTEE
the request for action under the guarantee must be addressed to the retailer, who will
forward the claim to the local distributor for technical assistance service.
K-Stove refuses to accept any responsibility in the event that the stove or any other accessory
have been improperly used or modified without authorization. For all replacement of parts, only original
K-Stove spare parts must be used.
2. THEORETICAL NOTIONS FOR THE INSTALLATION
2.1. PELLETS
The pellet is obtained by processing the sawdust produced during working wood and timber (dried wood and paint free).
The compactness of the material is guaranteed by the lignin which is contained in the wood itself and allows the
production of pellets without the 'use of glues or binders.
The market offers different types of pellets with characteristics that vary based on mixtures of wood used. The diameter
varies between 6 and 8 mm, with a standard length between 5 and 30 mm. The pellets of good quality has a density
ranging from 600 to more than 750 kg / m3 with a water content that is maintained between 5% and 8% of its weight.
In addition to being an environmentally friendly fuel, as you push the limits of wood residues resulting in a
cleaner- burning than that produced with fossil fuels, the pellets also have technical advantages. While a good wood
has a calorific value of 4.4 kW / kg (15% RH, after 18 months of seasoning), the pellet is 4.9 kW / kg.
To ensure good combustion, and no power problems, it is imperative that the pellets are stored in a dry place,
protected from dirt, and the thermos-stove is placed in a place where the conditions are the same, not to generate the
same type of problems on the power pellets in the tank. The pellet is usually supplied in 10, 14 or 15 kg bags, so
storage is very handy.
A good quality pellet ensures good combustion lowering harmful emissions into the atmosphere.

PELLET BURNING STOVES INSTALLATION & MAINTENANCE MANUAL
7
If the fuel is poor , the more often cleaning inside the grate and the combustion chamber will be
required .
K-Stove strongly recommends using certified fuel in its stoves (EN-A1 Plus).
The use of fuel of inferior quality or not conforming to the specification given above compromises the
running of your stove and can therefore lead to the termination of the guarantee and of the manufacturer's
responsibility for the product.
K-Stove pellet stoves run exclusively on pellets with a diameter of 6 mm (European countries) with lengths.
IMPORTANT!
Installation and assembly of the stove must be carried out by qualified personnel.
The stove must be installed in a suitable position to allow the normal operations of opening and ordinary maintenance.
The site must be:
capable of providing the environmental conditions for operation
equipped with power supply 230V 50 Hz
capable of taking an adequate system for smoke discharge
provided with external ventilation
provided with an earth connection complying with CEI
The stove must be connected to a flue pipe or an internal or external vertical duct conforming to current
standards UNI 7129 - 7131 9615. The stove must be positioned in such a way that the electrical plug is
accessible.
IMPORTANT!
The stove must be connected to a flue pipe or a vertical duct which can discharge the fumes at the
highest point of the building. The fumes are however derived from the combustion of wood products, and if
they come into contact with or close to walls, they can make dirty marks. Also take care because the fumes
are very hot but almost invisible, and can cause burns on contact. The holes for the passage of the smoke
pipe and for the intake of air from outside should be made before positioning the stove unit.
2.3. OPERATING ENVIRONMENT
For proper operation, and a uniform distribution of temperature, the stove
should be placed in a location with an air flow that guarantees the air
needed for combustion of the pellets (should be available approximately 40
m³ / h) according to the installation and the second regulations in the
country.
The volume of the environment must not be less than 30 m³.
The air must enter through permanent openings on the walls (near the stove) with
a minimum of 100 square centimeters.
These openings must be made so that they cannot be obstructed in any way, and
allow proper airflow. Air can also be taken to ventilate rooms adjacent provided
they are equipped with air hose and are not used as a bedroom and bathroom, or

PELLET BURNING STOVES INSTALLATION & MAINTENANCE MANUAL
8
where there is no fire hazard such as: garages, sheds, storage of combustible materials, etc., strictly complying with
the requirements under current rules. It is absolutely prohibited to installation the stove in bedrooms, bathrooms, and
where it is already installed another d heating device without adequate airflow (fireplace, stove, etc..).
It is expressly prohibited the placement of the stove in environments with
explosive atmospheres. The floor of the room where the stove will be installed must be
sized appropriately to support the weight of the stove itself (which should be
considered in addition to the weight of the machine said the same load must be added
a maximum of 60 kg for the pellets, and 80 kg for water). When installing , keep a
minimum distance from obstacles and not flammable (B) of 25 cm the rear to, lateral
(LR) of 25 cm and anterior (C) of 80 cm. In the presence of objects believed to be
particularly sensitive such as furniture, curtains, sofas, carpets, etc., greatly increase the distance of the stove from
them. In the presence of wooden floor floor- prepare the plan and in accordance with
rules in force in the country, on fire prevention .
2.4. CONNECTION TO THE EXTERNAL AIR INTAKE
It is essential that the room where the stove is installed , the stove can avail of an
air flow in sufficient quantity as it is required by the regular combustion equipment
and ventilation. This can be done by means of permanent openings on the walls
that give the room to be ventilated to the outside, ventilation ducts or through
individual or collective. Within this scope , the outer wall near the stove must have
an opening minimum 100 cm ², protected by a grid inside and outside. The air
intake must also:
• be communicating directly with the installation environment
•be protected by a grate, wire mesh or other suitable protection, provided it does
not reduce the minimum section.
• position in a suitable manner as to prevent it from being obstructed in any way
It is prohibited to connect the air directly to the stove (communicating
directly from the outside), to avoid compromising thermodynamic performance,
however it is required that the conditions still guarantee about 50 m³ / h of air
replacement, as provided in the current UNI 10683 .
2.5. CONNECTION OF SMOKE DISCHARGE PIPE
When making the hole for the flue pipe it must be taken into account the possible
presence of inflammable materials. If the hole has to go through a wood wall or
other thermo labile material , the installer MUST use the Industrial insulated pipe
(with min thermal conductivity of 0.07 W / m ° K). The same applies if the stove pipe
must go vertical or horizontal sections remain near (min.20cm) to a heat- labile wall.
The combustion chamber works in depression, so the exhaust duct for the exhaust
fumes will be linked to depression when effective chimney as prescribed.

PELLET BURNING STOVES INSTALLATION & MAINTENANCE MANUAL
9
It should always use pipes and fittings with appropriate seals to ensure air‐tightness in order to avoid
possible harmful CO fumes into the environment.
All sections of the exhaust duct must be inspect able and removable to allow for periodic cleaning of
the interior, which is necessary for the proper functioning of the system (T-piece with inspection). Position the
stove strict accordance with all regulatory requirements and attention to highlighted date.
Important:
All changes direction 90 degrees of the flue gas channel must be prepared if possible with the appropriate
fittings to "T" with inspection. It is absolutely forbidden to use a net at the end of the hose as it can cause
serious problems for the proper and safe operation of the stove.
In connection do not use the chimney sections of pipe horizontally, but always the same place at an angle of
5° minimum to rise, possibly avoiding the use of a 90° (you can use up to 3), and use preferably 45 ° curves. It
is recommended to not use a total length of the pipe diameter 80 mm, greater than 6 m in total.
2.6. CONNECTION TO THE CHIMNEY
The chimney must have inside dimensions of no more than cm. 20X20 or 20 cm
diameter. In the case of larger or poor condition of the chimney (ie: cracks, poor
insulation, etc.) it is recommended to insert stainless steel tube in the chimney
of a of suitable diameter for its entire length, to the very top. Check with
suitable instruments that there is a minimum draft. Guaranteed 15 Pa. At
the bottom of a chimney inspection for periodic inspection and cleaning, which
must be done annually. You must ensure that a chimney top is installed
according to regulations for wind force.
This type of connection must guarantee of 15 Pa, allows the correct discharge
of smoke with a natural draft even if there is no electricity.
2.7. CONNECTION TO AN EXTERNAL FLUE PIPE WITH
ISOLATED OR DOUBLE WALL
The external pipe must have minimum internal
dimensions of cm. 10X10 or 10 cm diameter. cm, and maximum. 20X20 or 20 cm
diameter. Check with appropriate tools that there is a draw of 10 Pa. It
must use only, and only pipes insulated (double wall) within the smooth stainless
steel (stainless steel flexible tubes are not allowed) fixed to the wall, to prevent,
and / or minimize condensation problems. At the bottom of the outer vertical duct
an inspection tap for periodic inspections and cleaning to be done annually. You
must ensure that the chimney is installed according to wind force.
This type of connection, even in case of momentary power
failure, ensuring the evacuation of the fumes.
2.8. CONNECTION TO THE FLUE PIPE
