KT Tech KT-3128 User manual

K T TECH
KT-3128/3098BT/
KT-3128/3098BTU
DIGITAL DUAL ALARM FM CLOCK RADIO
INSTRUCTION
MANUAL
Thank you for buying Brandname’s product.
Read this manual carefully to get the best
performance form this unit.
SNOOZE/DIMMER/SLEEP/SCAN
FUNCTION

IMPORTANT
· Read these instructions.
· Heed all warnings.
· Follow all instructions.
· Do not block any ventilation openings, Install in
accordance with the manufacturer’s instructions.
· Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
· Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the
point where they exit from the clock radio.
· Only use attachments/accessories specified by the
manufacturer.
· Unplug this clock radio during lightning storms or when
unused for long periods of time.
· Refer all servicing to qualified service personnel.
Servicing is required when the clock radio has been
damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into
the clock radio, the clock radio has been expose to rain or
moisture, does not operate normally, or has been dropped.
· This clock radio shall not be exposed to dripping or
splashing.
· Do not place any sources of danger on the clock radio
(e.g. liquid filled objects, lighted candles).
· Attention should be drawn to the environmental aspects of
battery disposal. Don’t throw used batteries in dustbin.
Please contact your retailer in order to protect the
environment.
Attention should be drawn to the environmental aspects of
battery disposal.
Electrical products should not be disposal of with household
1

LOCATION OF CONTROL
MEMORY
TUNINGVOLUME
AL2AL1 TIME SET
SNOOZE/DIMMER/SLEEP/SCAN
FUNCTION
61
7
2
3
5
4
8
10
9AL1
PM
AL 2
Bluetooth Digital Clock Radio
11
12
waste. Please recycle where facilities exist. Check with your
Local Authority of retailer for recycling device.
(Batteries pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
8. PM INDICATOR
9. AL1 INDICATOR
10. AL2 INDICATOR
11. Bluetooth
12. DIGIT DISPLAY
15
14
13 13. FM ANTENNA WIRE
14. DC INPUT
15. USB For charging
the phone or other
2
1. /FUNCTION
2. MEMORY / /TIME SET
3. TUNING DOWN
4. TUNING UP
5. VOLUME - / AL2
6. VOLUME + / AL1
7. SNOOZE / DIMMER /
SLEEP/SCAN

CONNECT POWER
BOTTOM OF SET
LISTEN TO FM RADIO
CAUTION
· Risk of product damage! Ensure that the power voltage
corresponds to the voltage printed on the back or
underside of the clock radio.
· Risk of electric shock! When you unplug the AC adaptor,
always pull the plug from the socket. Never pull the cord.
Battery compartment for 1.5 volt (LR6, UM-3, AA) battery
2pcs. (not included) for temporary time storage.
SET TIME
13. FM ANTENNA WIRE
14. DC INPUT
15. USB For charging
the phone or other
1. Press and hold TIME SET for two seconds.
[0:00] Hour digit is blink.
2. Press Tuning + or - to set hour.
3. Press TIME SET again to set miniute.
4. Press Tuning + or – again to set minute.
5. Press TIME SET again to confirm setting.
For better reception, fully extend and adjust the position of
the FM antenna wire.
1. Press / FUNCTION to turn on FM radio.
[FM frequency] is displayed.
Press and hold TUNING ︿ ﹀ for the FM Tuner tunes to a
station with strong reception automatically.
To seach for a radio station manually :
Press TUNING ﹀︿ repeatedly to tune to a radio station .
3

1. Press / FUNCTION to Bluetooth mode.
2. [bt] displays on the screen.
3. Bluetooth indicator flash to wait for Bluetooth enabled
device / smartphone to pair it.
4. On Bluetooth function at Bluetooth enable device /
smartphone.
5. Scan KT-3128BT/3098BT/KT-3128BTU/KT-3098BTU as device
name.
6. Select KT-3128BT/3098BT/KT-3128BTU/KT-3098BTU on
device name list.
7. Bluetooth indicator flash slowly after pairing and
4
STORE FM RADIO STATIONS
You can store up to 20 FM radio stations in preset channel
automatically or manually.
STORE FM RADIO STATIONS AUTOMATICALLY (AUTO SCAN)
1. Press / FUNCTION to turn on FM radio.
2. Press SNOOZE/DIMMER/SLEEP/SCAN multi-function button
and hold for 2 seconds.
The received stations are automatically stored to preset
numbers.
STORE FM RADIO STATIONS MANUALLY.
1. Tune to an FM radio station.
2. Press MEMORY to activate the storing mode.
3. Press TUNING ︿﹀ to select the preset number.
[P 01 ~ P 20] is preset station numbers.
If this position is occupied, the previous stored frequency
will be displayed ;
To remove a pre-stored FM radio station, store another
station in its place.
LISTEN TO A PRESET FM RADIO STATION
In FM mode, press MEMORY to select a preset number.
LISTEN TO BLUETOOTH WIRELESS MUSIC STEAMING

connecting.
8. Playback music or multi-media audio source at the devices /
smartphone.
9. Press Volume + / - or adjust volume level at the devices /
smartphone to desire level.
10. Press Backward skip to select previous song.
11. Press Forward skip to select next song.
12.
Press Play/Pause to play or pause the song is being played back.
Note
The digit display returns to clock display if no buttons is
pressed for 10 seconds.
SET ALARM TIMER
Make sure that you have set the clock correctly.
You can set two separate alarm timers. For the alarm sound,
you can select the FM radio or the buzzer.
1. Press / FUNCTION to Clock mode.
2. Press and hold AL1/AL2 for two seconds.
[0:00] Hour digit is blink.
Press Tuning + or - to set alarm hour.
Press AL1 or AL2 again to set alarm miniute.
Press Tuning + or – again to set alarm minute.
Press TIME SET again to confirm setting.
3. Press AL1 / AL2 again to select a sound source : FM or
Buzzer or Bluetooth
The [rAd] is blink if FM radio source is selected and AL1 /
AL2 indicator is light up.
[bu2] is blink if the buzzer sound is selected and AL1 /
AL2 indicator is light up.
[bt] is blink if the Bluetooth wireless steaming is selected
and AL1 / AL2 indicators is light up.
Press AL1/AL2 again to set alarm volume level.
Press Tuning + or – to adjust desire alarm volume level
Press AL1/AL2 to off alarm function and AL1/AL2
indicator is off.
5

SET SLEEP TIMER
1. Press / Functon to radio mode.
2. Press SNOOZE/DIMMER/SLEEP multi-function button
repeatedly to select the sleep timer period (in minutes).
To deactivate the nap timer, press SNOOZE/DIMMER/SLEEP
multi-function button repeatedly until back to radio
frequency.
Sleep / Nap Timer period circle as follow :
ADJUST VOLUME
SNOOZE ALARM
When alarm sounds, press SNOOZE to activate the snooze
time 9 minutes.
The AL1 / AL2 indicator keeps blinking.
While listening, press + VOLUME – to adjust volume.
ADJUST DISPLAY BRIGHTNESS
During standby mode, press and hold DIMMER for 2 seconds
repeatedly to select high or low brightness levels.
BATTERY BACK-UP
(For Temporary Time Storage Only)
Install 2 x LR06, AA or EU-3 battery (not included) according to
polarity shown inside the battery compartment. In the event of
a power interruption, your set will not work normally from the
90 >80 >70 > 60 > 50 > 40 >30 >20 >10
OFF
6

The statements should be displayed in the
user manual:
mains supply but there is now the advantage that your clock will
continue to work. The clock display will not light up, as the
clock time will be held in the memory. This also enables you to
move the set from place to place without re-setting the clock
every time. The battery back-up system is only meant to be
used from short temporary power interruption. For longer
durations, the battery may become exhausted or there may be
some deviation in accuracy. When the battery is exhausted, it
should be removed from the set to prevent leakage. If you do
not wish to take advantage of the battery back-up system, your
set will work normally without a battery. However, if
disconnected from the mains, the clock figures will flash when
the mains are re-connected and you must re-set the clock as
described in the Electronic Clock Operation paragraph.
Attention should be drawn to the environmental aspects of
battery disposal. Don’t throw used batteries in dustbin. Please
contact your retailer in order to protect the environment.
Attention should be drawn to the environmental aspects of
battery disposal.
Electrical products should not be disposal of with household
waste. Please recycle where facilities exist. Check with your
Local Authority of retailer for recycling device.
(Batteries pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
7

SPECIFICATION
Power Source : 100-240V ~50/60Hz,
Tuner Range :FM 87.5-108.0MHz
Power Consumption : 5W
Product information is subject to change without
prior notice.
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
8
