KT&C KPC-HDB450 User manual

HD CCTV
Digital Video Camera
OPERATION MANUAL
Thank you for choosing our high quality camera.
Before attempting to connect or operate, please read and
follow these instructions.
M130-HDB450-001
Aegis Electronic Group
www.aegiselect.com

These servicing instructions are for use by qualified service
personnel only.
To reduce the risk of electric shock do not perform any servicing
other than that contained in the operating instructions unless
you are qualied to do so.
Use Class 2 Power Supply Only
CAUTION
2
Aegis Electronic Group
www.aegiselect.com

CONTENTS
1. CAUTIONS
2. IMPORTANT SAFETY INSTRUCTION
3. FEATURES
4. EQUIPMENT AND ACCESSORIES
5. INSTALLATION
6. DIMENSIONS
7. SPECIFICATION
8. OSD MENU STRUCTURE
9. OSD FUNCTION DESCRIPTION
3
Aegis Electronic Group
www.aegiselect.com

1. CAUTIONS
4
1. A regulated DC12V 500mA power supply is recommended for use with this
camera for the best picture and the most stable operation.
An unregulated power supply can cause damage to the camera.
When unregulated power supply is applied, product warranty will be
out of subject.
2. It is recommended that the camera is used with a monitor that has a
CCTV quality 75 video impedance level. If your monitor is switched to high
impedance then please adjust accordingly.
3. Do not attempt to disassemble the camera to gain access to the internal
componets. Refer servicing to your dealer.
4. Never face the camera towards the sun or any bright or reective light,
which may cause smear on the picture and possible damage to the CCD.
5. Do not remove the serial sticker for the warranty service.
6. Do not expose the camera to rain or other types of liquid.
7.The apparatus must be connected to a mains socket-outlet with a
protective earthing connection.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions;
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.
Note
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.”
WARNING
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
Caution
Any changes or modications in construction of this device which are not
expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
Aegis Electronic Group
www.aegiselect.com

1. CAUTIONS
5
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European
countries with separate collection systems)
This marking shown on the product or its literature, indicate that
it should not be disposed with other household wastes at the end
of its working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate this
from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
This product should not be mixed with other commercial wastes
purchased this product, or their local government ofce, for details of
where and how they can take item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.
Household users should contact either the retailer where they for
disposal.
Aegis Electronic Group
www.aegiselect.com

2. IMPORTANT SAFETY INSTRUCTION
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety.
If the provided plug does not t into your outlet, consult an electrician
for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11) Only use attachments/accessories specied by the anufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused
for long periods of time.
14) Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
6
Aegis Electronic Group
www.aegiselect.com

3. FEATURES
•High Resolution
1/3” 2.1 Mega pixel PANASONIC Color CMOS.
• Support various digital video output
720p 50fps / 720p 60fps
1080p 25fps / 1080p 30fps
• Video Outputs
HD-SDI / CVBS
• S/N Ratio : More than 50dB
• OSD menu for setup and configuration
• Power Source : DC 6 ~ 15V
7
Aegis Electronic Group
www.aegiselect.com

4. EQUIPMENT AND ACCESSORIES
Camera
Mounting
Bracket
Screw 3ea
Operation
Manual
Service
Video Output
Test Cable
CAUTIONS
When you connect Service Video Output Cable
WDR function does not work.
8
Aegis Electronic Group
www.aegiselect.com

5. INSTALLATION
• CAMERA MOUNTING POSITION
9
Aegis Electronic Group
www.aegiselect.com

5. INSTALLATION
• Service Video Out & OSD Control
• MONITOR CONNECTION
10
OSD Control Joystick
Service Video Connector
SDI Out BNC
Power LED
Terminal
DC12V REGULATED
POWER SUPPLY
HD SDI IN
SDI
RECEIVER
DISPLAY
DEVICE
HANDHELD
MONITOR
TEST CABLE
Aegis Electronic Group
www.aegiselect.com

6. DIMENSIONS
Unit(mm)
11
MOUNTING HOLE
(1/4"-20 UNC, Depth 4.5)
MOUNTING HOLE
(1/4"-20 UNC, Depth 4.5)
75
Ø45
97
Ø60
3-Ø3.5
41.5
36
Aegis Electronic Group
www.aegiselect.com

7. SPECIFICATION
CMOS 1/3" 2.1 Mega pixel PANASONIC Color CMOS
Pixel size 2.75um (H) x 2.75um (V)
Effective Pixels 1944(H) x 1092(V)
Manual Shutter 1/30(25), 1/60(50), 1/120(100), 1/250, 1/700, 1/1K,
1/1.6K, 1/2.5K, 1/5K, 1/7K, 1/10K, 1/30K
Sense-up x 2, x 3, x4
AGC Off / 0dB ~ 23dB
White Balance AUTO / Manual / PUSH LOCK
Sensitivity 1.0 Lux
S/N ratio More than 50dB
Video Output HD-SDI / CVBS
Day & Night OFF / ON(digital D&N)
LENS Board Lens
Dimension 45(ø) x 75(mm)
Weight 145g
ETC. Motion Detection, 3DNR, Mirror(H,V,H/V),
Digital Zoom, BLC, WDR, OSD(JOYSTICK)
POWER
Consumption DC 6 ~ 15V / MAX 160mA(DC 12V(±10%) )
Operating
Temperature 14˚F~122˚F (-10˚C~+50˚C)
Storage
Temperature -4˚F~140˚F (-20˚C~+60˚C)
Specifications and designs are subject to change for improving
the functionality of this product without notice.
12
Aegis Electronic Group
www.aegiselect.com

8. OSD MENU STRUCTURE
Main Sub Menu Sub Menu
SETUP
EXPOSURE
BRIGHTNESS 0 ~ 20
SHUTTER MODE AUTO, MANUAL
SHUTTER
SPEED
1/30(25), 1/60(50), 1/120(100), 1/250, 1/700, 1/1K,
1/1.6K, 1/2.5K, 1/5K, 1/7K, 1/10K, 1/30K.
DSS
(Digital Slow Shutter) OFF, X2, X3, X4.
AGC MAX 0 ~ 23dB
INITIAL
RETURN
WHITE
BALANCE
WB MODE AUTO / PUSH LOCK / MANUAL
CHROMA 0 ~ 20
KELVIN LOW, MIDDLE, HIGH
RED GAIN 0 ~ 20
BLUE GAIN 0 ~ 20
PUSH AUTO -
INITIAL
RETURN
WDR / BLC
MODE OFF, WDR, BLC
WDR LEVEL 0 ~ 4
BLC OSD OFF, ON
BLC X - POSITION 0 ~ 20
BLC Y - POSITION 0 ~ 20
BLC X - SIZE 0 ~ 20
BLC Y - SIZE 0 ~ 20
INITIAL
RETURN
DAY & NIGHT
D&N MODE AUTO, COLOR, BW
DWELL TIME 1sec ~ 10sec
AGC THRS 0 ~ 20
MARGIN 0 ~ 20
INITIAL
RETURN
SHARPNESS 0 ~ 10
MIRROR OFF, ON
FLIP OFF, ON
DZOOM(Digital Zoom) 1X ~ 20X
SHADING OFF, ON
HLMASK OFF,ON
HLMASK LEVEL 0 ~ 20
HLMASK COLOR
WHITE, YELLOW,
CYAN, GREEN
MAGENTA, RED,
BLUE, BLACK
INITIAL
RETURN
13
Aegis Electronic Group
www.aegiselect.com

8. OSD MENU STRUCTURE
Main Sub Menu Sub Menu
D-WDR OFF, ON
DNR OFF, LOW, MIDDLE, HIGH
INITIAL
RETURN
SPECIAL
CAM TITLE
CAM TITLE
0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K
L M N O P Q R S T U V W X Y Z ! - () < >
SPA > > < < BAK
LOCATION
RETURN
LANGUAGE ENGLISH, RUSSIAN, SPANISH,
GERMAN, FRENCH, PORTUGUESE
PRIVACY
OFF, ON ZONE NO 0 ~ 29
MASK MODE OFF, ON
X - POSITION 0 ~ 60
Y - POSITION 0 ~ 40
X - SIZE 0 ~ 40
Y - SIZE 0 ~ 40
COLOR
BLACK, WHITE,
YELLOW, CYAN,
GREEN, MAGENTA,
RED, BLUE
TRANSPARENCY 100%,75%,50%,25%,0%
INITIAL
RETURN
MOTION DETECT
OFF, ON RESOLUTION 0 ~ 4
SENSITIVITY 0 ~ 20
INITIAL
RETURN
DISPLAY
CAM TITLE OFF, ON
MOTION DETECT OFF, ON
ZOOM OFF, ON
INITIAL
RETURN
SYSTEM
SHADING DET OFF, ON
DEFECT DET OFF, ON
DOUT FORMAT 720P, 1080P
DOUT FPS 50, 60 / 25, 30
COLOR BAR OFF, ON
INITIAL
RETURN
FACTORY
DEFAULT
EXIT
14
Aegis Electronic Group
www.aegiselect.com

9. OSD FUNCTION DESCRIPTION
• EXPOSURE
- BRIGHTNESS:
Enable user to control the image
brightness (0~20steps).
- SHUTTER MODE:
Enable user to set up the Shutter Mode.
-> AUTO, MANUAL
- SHUTTER SPEED:
Enable user to set up the Shutter Speed.
-> 1/30(25), 1/60(50), 1/120(100), 1/250,
1/700, 1/1K,1/1.6K, 1/2.5K, 1/5K, 1/7K,
1/10K, 1/30K.
*() is for PAL TYPE.
- DSS(Digital Slow Shutter):
Enable user to set up the DSS Level. -> OFF, X2, X3, X4.
- AGC MAX:
Enable user to make imager bright to amplify the Gain(0~23dB).
- INITIAL:
Enable user to initialize the Exposure menu set up.
•WHITE BALANCE
:Enable user to represent the accurate white color by controlling the R,G,B level.
- WB MODE
1. AUTO : Enable user to trace the White
Balance automatically in the range of
2,300K~10,000K.
2. PUSH LOCK : Enable user to fix the
White Balance according to the color
temperature in the certain environment.
3. MANUAL : Enable user to sets
the White Balance according to the
circumstance.
- CHROMA: Enable user to set the Color Gain(0~20steps).
- KELVIN: In the MANUAL setting of WB MODE, enable user to set the
color temperature range.
- RED GAIN: In the MANUAL setting of WB MODE, enable user to set
the RED GAIN.
- BLUE GAIN: In the MANUAL setting of WB MODE, enable user to set
the BLUE GAIN.
- PUSH AUTO: In the PUSH LOCK setting of WB MODE, enable user
to fix the White Balance in camera setting.
- INITIAL: Enable user to reset the WHITE BALANCE menu setting.
15
EXPOSURE
> BRIGHRNESS
SHUTTER MODE
SHUTTER SPEED
DSS
AGC MAX
INITIAL
RETURN
|
||||||
|
|||
|
14
AUTO
– – –
OFF
23dB
WHITE BALANCE
> WB MODE
CHROMA
KELVIN
RED GAIN
BLUE GAIN
PUSH AUTO
INITIAL
RETURN
AUTO
|
||
|
|||||||
|
7
– – –
– – –
– – –
– – –
Aegis Electronic Group
www.aegiselect.com

16
9. OSD FUNCTION DESCRIPTION
• WDR/BLC
- MODE:
Enable user to set WDR/BLC mode.
-> OFF, WDR, BLC
1. WDR(Wide Dynamic Range):
Use the condition which Image doesn’t
figure out with BLC such as place
surrounded windows and lobby.
(*The screen display may be unnatural)
2.BLC(Backlight compensation mode):
This function works for subjects in the
kind of backlight conditions.
- WDR LEVEL: Enable user to set up WDR Level (0~4 level).
- BLC OSD: Enable user to set up screen output of chosen BLC zone.
- BLC X-POSITION: Enable user to set up Horizontal start position(0~20steps).
- BLC Y-POSITION: Enable user to set up Vertical start position(0~20steps).
- BLC X-SIZE: Enable user to set up Horizontal size (0~20steps).
- BLC Y-SIZE: Enable user to set up Vertical size (0~20steps).
- INITIAL: Enable user to initialize the WDR/BLC setting.
• DAY&NIGHT
: Conversion of output image COLOR / BW depending on exterior environment.
- D&N MODE
1. COLOR : Enable user to fit the output
image in color.
2. B/W : Enable user to fit the output
image in B/W.
3 AUTO : Enable user to convert to
COLOR/BW automatically by luminance
element on Screen
- DWELL TIME: In D&N MODE AUTO, enable user to set to delay time for
changing COLOR/BW(0~10sec).
- AGC THRS: The value of switching from Day to Night.
In D&N MODE AUTO, enable user to set to AGC THRS
level (0~20steps).
- MARGIN: To switch from Day to Night margins. In D&N MODE AUTO,
enable user to set to MARGIN level (0~20steps).
- INITIAL: Enable user to initialize the setting in DAY&NIGHT menu.
WDR / BLC
> MODE
WDR LEVEL
BLC OSD
BLC X - POSITION
BLC Y - POSITION
BLC X - SIZE
BLC Y - SIZE
INITIAL
RETURN
WDR
4
ON
|
||
|
|||||||
| 6
|
|
|
||||||||
| 4
|
|||||
|
||||
| 7
|
|||||||
|
||
| 10
DAY&NIGHT
> MODE
DWELL TIME
AGC THRS
MARGIN
INITIAL
RETURN
AUTO
3s
|
|||||
|
||||
|
10
|
|||||
|
||||
|
10
Aegis Electronic Group
www.aegiselect.com

17
9. OSD FUNCTION DESCRIPTION
• IMAGE
- SHARPNESS:
Enable user to control the image
sharpness (0~10steps).
- MIRROR:
Sets the horizontal flip for the display
output.
- FLIP: Sets the Vertical flip for the displayoutput.
- DZOOM(Digital Zoom): Max. 20x Digital Zoom
- SHADING: Enable user to set up the lens shading compensation mode.
- HLMASK: This function that improves the visual recognition of license
plates and other such objects by suppressing or masking
strong light sources
1. HLMASK LEVEL: Enable user to set HLMASK Level(0~20steps).
2. HLMASK COLOR: Set the HLMASK color
(Black, White, Yellow, Cyan, Green, Magenta, Red, Blue).
- D-WDR: In this mode, the brightness of a single image is compensated
using the gamma curve.
- DNR: This function reduces noise.
- INITIAL: Enable user to initialize the setting on IMAGE menu.
> SHARPNESS
MIRROR
FLIP
DZOOM
SHADING
HLMASK
D-WDR
DNR
INITIAL
RETURN
4
OFF
OFF
1X
OFF
OFF
OFF
MIDDLE
(OFF) (ON)
(Outline of DNR function)
(OFF) (ON)
Aegis Electronic Group
www.aegiselect.com

18
9. OSD FUNCTION DESCRIPTION
• SPECIAL
: Setting up the CAM TITLE, LANGUAGE, PRIVACY, MOTION,
DISPLAY, SYSTEM.
- CAM TITLE :
Enable user to choose any word in screen(Maximum 10 letter is available)
1. A letter Choice from the screen using
Menu key
2. Enable user to move to next menu
using LEFT, RIGHT KEY in LOCATION.
3. By using UP, DOWN, LEFT, RIGHT
KEY, enable user to choose any letters in
LOCATION and then get back to previous
step.
4. Enable user to finish words choice and
position by using LEFT, RIGHT KEY in
RETURN
- LANGUAGE
: Enable user to set up an OSD language
-> ENGLISH, RUSSIAN, SPANISH, GERMAN, FRENCH, PORTUGUESE.
SPECIAL
> CAM TITLE
LANGUAGE
PRIVACY
MOTION
DISPLAY
SYSTEM
INITIAL
RETURN
[ ]
ENGLISH
OFF
OFF
[ ]
[ ]
CAM TITLE
0123456789ABCDEFGHIJKLMN
OPQRSTUVWXYZ!?*#$%()<>{}
SPACE>> <<BACK
TITLE SET
LOCATION [ ]
RETURN
[ TITLE LOCATION]
TITLE SET
[U][D][L][R] [M] +
Aegis Electronic Group
www.aegiselect.com

9. OSD FUNCTION DESCRIPTION
- PRIVACY
: Privacy is the function that covers the some part on screen to prevent
private life.(Maximum 30 point covered)
1. ZONE NO : Enable user to set up a
position from 0 to 29 area.
2. MASK MODE : Enable user to set up
screen output of chosen position.
3. X-POSITION : Mask Horizontal start
position.
4. Y-POSITION : Mask Vertical start
position.
5. X-SIZE : Mask Horizontal width.
6. Y-SIZE : Mask Vertical height.
7. COLOR : Set the mask color.
8. TRANSPARENCY : Set the transparency of the mask.
9. INITIAL : Enable user to initialize setting of PRIVACY MENU.
- MOTION:
Motion detection function.
1. RESOLUTION :
Enable user to set up resolution
2. SENSITIVITY :
Enable user to set up sensitivity.
3. INITIAL :
Enable user to initialize setting of
MOTION DETECT
- DISPLAY :
Enable user to set up a screen marking of CAM TITLE, MOTION, DZOOM.
1. CAM TITLE : Enable user to set up
output in fixed CAM TITLE.
2. MOTION : Enable user to set up
out put of MOTION on the screen as
MOTION ON setting.
3. DZOOM : Enable user to set up output
DZOOM ratio..
4. INITIAL : Enable user to initialize of
DISPLAY menu.
19
PRIVACY
> ZONE NO
MASK MODE
X-POSITION
Y-POSITION
X-SIZE
Y-SIZE
COLOR
TRANSPARENCY
INITIAL
RETURN
0
ON
12
2
3
3
CYN
0%
DISPLAY
> CAM TITLE
MOTION
DZOOM
INITIAL
RETURN
OFF
OFF
OFF
MOTION
> RESOLUTION
SENSITIVITY
INITIAL
RETURN
0
10
Aegis Electronic Group
www.aegiselect.com

20
9. OSD FUNCTION DESCRIPTION
- SYSTEM
1. SHADING DET: Lens shading detection function.
2. DEFECT DET: White pixel detection and compensation function.
3. DOUT FORMAT: Enable user to set up digital output format(720p, 1080p).
4. DOUT FPS: Enable user to set up digital output frame rate.
5. COLOR BAR: Enable user to set up output colorbar.
6. CVBS: Enable user to set up CVBS type NTSC or PAL.
•FACTORY DEFAULT
: Enable user to reset all of the status as the factory default.
•EXIT
: After saving the current settings in the OSD menu and exit.
SYSTEM
> SHADING DET
DEFECT DET
DOUT FORMAT
DOUT FPS
COLOR BAR
CVBS
COLOR
INITIAL
RETURN
OFF
OFF
1080P
30
OFF
NTSC
Aegis Electronic Group
www.aegiselect.com
