KTI Networks KB-100L User manual

High Speed
Internet BroadBand Router
User Guide

FCC Warning
This equipment has been tested and found to comply with the regulations
for a Class Bdigital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with this user’s guide, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his own
expense.
CE Mark Warning
This is a Class Bproduct. In a domestic environment, this product may
cause radio interference, in which case the user may be required to take
adequate measures.
VCCI Warning
Rev.A1-01

17
TABLE OF CONTENT
About This Guide.....................................................................................18
Purpose................................................................................................18
Overview of this User’s Guide............................................................18
Introduction..............................................................................................19
Applications:........................................................................................20
Features: ..............................................................................................20
Unpacking and Setup...............................................................................21
Unpacking............................................................................................21
Setup....................................................................................................21
Hardware Installation...............................................................................22
Front Panel...........................................................................................22
Rear Panel............................................................................................22
Hardware connections .........................................................................23
Connect the Internet Broadband Router ..........................................23
Check the installation ......................................................................24
PC Network TCP/IP Setting ....................................................................25
Windows 95/98/ME.............................................................................25
Windows 2000.....................................................................................26
Windows NT4.0...................................................................................28
Windows XP........................................................................................29
Internet Broadband Router Configuration................................................30
Login to the Internet Broadband Router..............................................30
Quick Setup.........................................................................................31
Advance Setup.....................................................................................35
Technical Specifications..........................................................................51

ABOUT THIS GUIDE
Congratulations on your purchase of this 4-port Broadband Router. This
device integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network
capabilities in a highly flexible desktop package. It provides a complete
solution for Internet surfing and office resources sharing, and it is easy to
configure and operate for even non-technical users.
Purpose
This manual discusses how to install the 4-port Broadband Router.
Overview of this User’s Guide
Introduction. Describes the Broadband Router and its features.
Unpacking and Setup. Helps you get started with the basic installation of
the Router.
Identifying External Components. Describes the front panel, rear panel
and LED indicators of the Router.
Connecting the Router.Tells how you can connect the Router to your
xDSL/Cable Modem.
Technical Specifications. Lists the technical (general, physical and
environmental, performance and Routers settings) specifications of the
Broadband Router.

Introduction
With the explosive growth of the Internet, accessing information and
services at any time, day or night has become a standard requirement for
most people. The era of the standalone PC is waning. Networking
technology is moving out of the exclusive domain of corporations and
into homes with at least two computers.
Broadband network access is also gaining ground. However, allowing
more than two computers to access the Internet at the same time means
less affordable, higher costs. Thus, there is a need to share one legal IP
address over a single Internet connection to link the home with the
Internet.
The scarcity of IP addresses and using a shared Internet connection
through an Internet sharing device can solve high network access costs.
All linked computers can make full use of broadband capabilities over
such a device.
This device not only comes equipped with a wide range of features, but
also can be installed and configured right out of the box. This device
supports a simple local area network and Internet access share, offering
great cost savings.
The local area network connects up home computers while also allowing
any of the computers to access the Internet, share resources, or play online
games—the basis of the family computing lifestyle.

Applications:
Broadband Internet access:
Several computers can share one high-speed broadband connection (LAN
and WAN-Internet).
Resource sharing:
Share resources such as printers, scanners and other peripherals.
File sharing:
Exchange data, messages, and distribute files thus making good use of
hard disk space.
Online gaming:
Through the local area network, online gaming and e-commerce services
can be easily setup.
Firewall:
Abuilt-in firewall function — for security and anti-hack system.
Features:
ØHigh speed data transfer rate, FTP up to 40Mbps
ØSupports NAT for share 1 IP address to all LAN user.
ØSupports PPPoE and PPTP protocol for Dial-Up ADSL.
ØSupports DHCP Server / Client.
ØSupports UPnP (Universal Plug and Play).
ØSupports virtual server mapping.
ØSupports packet filtering.
ØSimple Firewall protection.
ØUpgradeable firmware for future function.
ØSimple setting using Quick Setup.
ØEasy configuration via WEB Browser.

Unpacking and Setup
This chapter provides unpacking and setup information for the Broadband
Router.
Unpacking
Open the box of the Broadband Router and carefully unpack it. The box
should contain the following items:
uOne 4-port High Speed Broadband Router
uOne external power adapter
uThis User’s Guide
If any item is found missing or damaged, please contact your local reseller
for replacement.
Setup
The setup of the Broadband Router can be performed using the following
steps:
uThe power outlet should be within 1.82 meters (6 feet) of the
Broadband Router.
uVisually inspect the DC power jack and make sure that it is fully
secured to the power adapter.
uMake sure that there is proper heat dissipation from and adequate
ventilation around the Broadband Router. Do not place heavy
objects on the Broadband Router.

Hardware Installation
Front Panel
The figure below shows the front panel of the Broadband Router.
4-Port 10/100Mbps Ethernet Broadband Router Front Panel
POWER
This indicator lights green when the hub is receives power, otherwise, it is
off.
SYSTEM
This indicator blinksgreen meansthe Internet Broadband Router is
working successful. Otherwise, this indicator always on or off meansthe
function of the Internet Broadband Router is fail.
WAN (Link/ACT)
This indicator lights green when the WAN port is connected to an
xDSL/Cable modem successfully.
This indicator blinksgreen while the WAN port is transmitting or
receiving data on the xDSL/Cable modem.
LAN (Link/ACT)
From port 1 to port 4indicator lights green when the LAN port is
connected to a 100Mbps Fast Ethernet station, if the indicator blinksgreen
while transmitting or receiving data on the 100Mbps Fast Ethernet or
10Mbps Ethernet network.
Rear Panel
The figure below shows the rearpanel of the Broadband Router.

4 Port 10/100Mbps Ethernet Broadband Router Rear Panel
WAN
In the four port broadband router, there is an RJ-45 10/100Mbps Auto-
MDIX port for the WAN that will fit the xDSL/Cable modem’s
specification need.
LAN (1-4)
Four RJ-45 10/100Mbps Auto-MDIX ports for connecting to either
10Mbps or 100Mbps Ethernet connections.
RESET
Use a pin-shape item to push to reset this device to factory default settings.
It will be useful too when the manager forgot the password to login, but
the setting will be back to default setting.
Hardware connections
POWER
SYSTEM LAN
1234
Link/ACT
100M
Internet Broadband Router
PC
xDSL Modem
PC
PC
PC
Connect the Internet Broadband Router
1. Plug in one end of the network cable to the WAN port of the 4-port
Internet Broadband Router.
2. Plug in the other end of the network cable to the Ethernet port of the
xDSL or Cable modem.

3. Use another network cable to connect to the Ethernet card on the
computer system, the other end of the cable connects to the LAN port
of the Internet Broadband Router. Since the Internet Broadband
Router has four ports, you can connect up to four computers directly
to the unit. There you do not have to buy a switch to connect these
computers since one Internet Broadband Router functions both as a
connection-sharing unit and as a switch.
Check the installation
The control LEDs of the Internet Broadband Router are clearly visible and
the status of the network link can be seen instantly:
1. With the power source on, once the device is connected to the
broadband modem, the Power, CPU, LAN and WAN port link LEDs
of the Internet Broadband Router will light up indicating a normal
status.
2. While the WAN is link up to the ADSL/Cable modem, the WAN
port’s Link/ACT LED will light up.
3. While the LAN is link up to the computer system, the LAN port’s
Link/ACT LED will light up.

PC Network TCP/IP Setting
The network TCP/IP settings differ based on the computer’s operating
system (Win95/98/ME/NT/2000/XP) and are as follows.
Windows 95/98/ME
1. Click on the “Network neighborhood” icon found on the desktop.
2. Click the right mouse button and a context menu will be show.
3. Select “Properties” to enter the TCP/IP setting screen.
4. Select “Obtain an IP address automatically” on the “IP address”
field.
5. Select “Disable DNS” in the “DNS” field.

6.
7. Select “None” for the “Gateway address” field.
Windows 2000
Double click on the “My computer” icon on the desktop. When “My
computer” window opens, open the “Control panel” and then open the
“Network dialup connection” applet. Double click on the “Local area

network connection” icon. Select “Properties” to enter the TCP/IP setting
window.
1. In the “Local area network status” window, click on “Properties.”
2. In the “Local area network connection” window, first select
TCP/IP setting and then select “Properties.”
3. Set both “IP address” and “DNS” to Automatic configuration.

Windows NT4.0
Click on the “Start” button located on the lower left corner of the menu
bar.
Select “Settings” and then “Control panel.”
In the “Control panel” window, select “Network” to enter the TCP/IP
setting window.
1. Set “IP address” to “Obtain an IP address automatically.”
2. Set “DNS” to “Disable DNS.”

Windows XP
Point the cursor and click the right button on the “My Network Place”
icon.
Select “properties” to enter the TCP/IP setting window.
1. Set “IP address” to “Obtain an IP address automatically.”
2. Set “DNS” to “Obtain DNS server address automatically.”

INTERNET BROADBAND ROUTER CONFIGURATION
First make sure that the network connections are functioning normally.
This Internet Broadband Router can be configured using Internet Explorer
4.0 or newer web browser versions.
Login to the Internet Broadband Router
Before you configure this device, note that when the Broadband Router is
configured through an Ethernet connection, make sure the host PC must
be set on the IP subnetwork that can be accessed by the xDSL/Cable
modem. For example, when the default network address of the
xDSL/Cable modem Ethernet interface is 192.168.1.x, then the host PC
should be set at 192.168.1.xxx (where xxx is a number between 2 and
254), and the default subnet mask is 255.255.255.0.
1. Open Internet Explorer 4.0 or above Internet browser.
2. Enter IP address http://192.168.1.1 (the factory-default IP address
setting) to the URL web address location.
3. When the following dialog box appears, remain blank (first login) or
enter the password and press Login to enter the main configuration
window.
Note: If needed to set a password, then refer to the Administrator
Setting.

4. After entering the password, the main web page comes up, there are
two choices for setting, Quick Setup or Advanced Setup, it is
recommended that the beginner to use the Quick Setup, it will lead
you step by step to configure the Broadband Router.
Quick Setup
In the main web page, select “Quick Setup”to specify the Time Zone and
the WAN connection type: Cable modem (DHCP), Fixed IP, or Dial-up
xDSL (PPPoE).
1-1 Time Zone
To set the time zone in order to synchronize the system clock in the global
through the SNTP Server.
1-2 WAN Connection Type
To select which the WAN connection type will be connected to, point the
cursor to the Cable modem (DHCP), Fixed IP, or Dial-up xDSL (PPPoE)
to process.

1-2-1 Cable modem (DHCP)
To connect a cable modem with the Broadband Router, check the cable
modem with the related user’s guide, then the Cable modem will
automatically configure itself, the Broadband Router is configured to
automatically assign addresses to each PC.
Fill up the MAC Address of the network adapter when the DNS server
need a certain address with the network adapter, or press the “Clone MAC
Address”button to get the manager’s PC MAC Address.
1-2-2 Fixed IP
If the Internet Service Providers assign a fixed IP address,choose this
option and enter the assigned IP address, subnet mask, gateway IP and
DNS IP addresses for your Broadband Router.

1-2-3 PPPoE (Dial-up xDSL)
If connected to the Internet using a PPPoE (Dial-up xDSL)Modem, the
ISP will provide a Password and User Name, then the ISP uses PPPoE.
Choose this option and enter the required information, if the ISP provided
a Service Name, enter it in the column of the Service Name field,
otherwise, leave it blank.
The dialog box in Service Name, IP Address and DNS Address must be
filled up when the ISP Provider provide these information to you, if the
ISP Provider provides Dynamic IP Address, then you can skip on these
dialog box.
The MTU feature specifies the
largest packet size permitted for
network transmission. Enter the
value desired, for most DSL
users, it is recommended to use
1492. By default, MTU is set at
1492.
The Maximum Idle Time feature
can control the connection time
while user’s need to save the
cost of connection fee from ISP
provider (default time=0, always connect). Click on the Connect-on-
demand button to dial up to the ISP when only on demand, while there is
a need of connecting to the ISP automatically.
1-2-4 PPTP
If connected to the Internet using
a (PPTP) xDSL Modem, enter
the PPTP Account Name, PPTP
Password, Host Name, Service

IP Address, Your IP Address, Your Subnet Mask required by your ISP in
the appropriate fields. If your ISP has provided you with a Connection ID,
enter it in the Connection ID field, otherwise, leave it zero.
The MTU feature specifies the largest packet size permitted for network
transmission. Enter the value desired, for most DSL users, it is
recommended to use 1460. By default, MTU is set at 1460
The Maximum Idle Time feature can control the connection time while
user’s need to save the cost of connection fee from ISP provider (default
time=0, always connect). Click on the Connect-on-demand button to dial
up to the ISP when only on demand, while there is a need of connecting to
the ISP automatically.
1-3 DNS
The Domain Name System (DNS) is the way that Internet domain names
are located and translated
into Internet Protocol (IP)
addresses.
If your ISP providedat least one DNS Server IP Address, type that IP
Address in the Primary DNS address fields. You can type up to another
DNS Server IP Addresses. The Router will utilize these for quicker access
to functioning DNS Servers.
1-4 Status
When finish configuring the Quick Setup, the Status screen will list up the
connection status for the Broadband Routers' WAN/LAN interfaces,
firmware and hardware version numbers, and the number of connected
clients to the network.
