Kubota B2301/2601 Cab
* Shown with optional equipment *
Kubota B2301/2601 Cab
This ROPS cab is designed and built to fit the Kubota B2301, B2601.
Designed and Built by:
Tektite Manufacturing Inc:
427 Buffalo Street
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: [phone]
[email protected]
www.tektite.ca
One year standard product warranty provided by Tektite.
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

Tektite Manufacturing Incorporated thanks you for purchasing a Kubota B2301/2601 ROPS cab!
Tektite has worked very hard to design and build this ROPS product and we hope that it
provides you with many years of ROPS protection.
Tektite’s ROPS products are designed to provide safe and dependable service during operation
when they are properly maintained according to the instructions. Please read this operator
manual carefully before using this ROPS product.
The photos/illustrations provided in this manual may not provide all the detail needed, and are
for reference only.
All directions provided are from the reference point of the tractor seat facing the steering
wheel. All left and right references are from this view point.
For reference, please fill in the information below. This will assist your dealer in providing
service for this ROPS. It is advisable that this information be provided to your insurance
company as well in the event that the tractor is lost or damaged.
Vehicle Model: _________________________________________________________
ROPS Serial Number: ___________________________________________________
Date of Purchase: _______________________________________________________
Dealer Name: ___________________________________________________________
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

Tektite Limited Warranty
Tektite Manufacturing Inc. (“Tektite”) warrants to the original purchaser (the “Claimant”), that Tektite products will
be free from defective materials or workmanship, under normal use and service, for a period of (1) full year from
the original invoice date. Tektite’s liability under this Limited Warranty is limited to the repair or (at the discretion
of Tektite) the replacement of those components of its products, which were manufactured by Tektite that are
defective in materials or workmanship. Tektite shall have no liability under this Limited Warranty unless Tektite is
notified of the defect during the stated Warranty Period.
Limitations and Exclusions: Tektite has no responsibility to a Claimant under this Limited Warranty or on any other
basis for any of the following:
a) defects caused, in whole or in part, by accident or misuse, negligence or failure to maintain the product or
component;
b) products or components sold to a customer on an “as is” basis;
c) wiper blades, light bulbs, fuses, clear vinyl or other consumables;
d) glass where the point of failure has not been preserved intact and delivered to Tektite for analysis of the
cause of the failure;
e) products or components which have been modified after shipping from Tektite to its customer;
f) transportation charges for returned, repaired or replacement items;
g) defects that are subject of a Tektite initiated recall where the Claimant fails to comply with the terms of
the recall notice that comes to the attention of the Claimant;
h) components of Tektite products that are manufactured by third parties (Tektite’s only obligation in relation
to such components shall be to accord to the Claimant the benefit of any transferable warranty accorded
to Tektite by third party manufacturer);
i) defects in workmanship or materials in products or components that are repaired or replaced by Tektite
unless Tektite is notified of the new defect within the Warranty Period that applied to the original product
or component that has been repaired or replaced;
j) defects that result, in whole or in part, from inadequate engineering or specifications provided to Tektite
by its customer;
k) any actual or alleged deficiency in technical or engineering services or advice provided by Tektite to its
customer whether provided for valuable consideration or otherwise;
l) consequential damages, or any other damages whether foreseeable or not, resulting from the defect or any
delay in remedying the defect;
m) any breach or alleged breach of any implied warranty of merchantability or fitness for particular purpose
of use;
n) defects or part failure due to misuse or failure to follow recommended cab installation procedures; and
o) travel expenses, including mileage.
This Limited Warranty expresses the entire obligation of Tektite, its officers, directors, agents and employees, to its
customer or any Claimant in respect of any defect in workmanship, or materials of any product or component sold
or manufactured by Tektite whether on grounds of breach of contract, negligence or other tortuous liability, breach
of express or implied warranty or other basis in law of any jurisdiction.
Acceptance by a customer of delivery of products of Tektite constitutes acceptance of this Limited Warranty in lieu
of all other warranties express or implied including without limitation all implied warranties of merchantability or
fitness for particular purpose or use and constitutes acceptance by customer of the exclusions and limitations of the
liability of Tektite set out above. Once received, the cab should have ALL exterior cardboard, Styrofoam wrapping
removed for immediate inspection of product to ensure that no damages have occurred during transportation.
Outer coverings should stay off the cab and the cab be stored indoors in a controlled environment.The warranty
card must be completed and returned to Tektite.
Warranty claims should be reported to pa[email protected]. A warranty claim form and instructions will be provided at this time.
Warranty work not pre-authorized by Tektite may not be covered by this warranty agreement. Labor rate and time allowances
are fixed by Tektite. Approved warranty claims will be issued in the form of credits applied to customer account.
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

Safety Precautions
Safety First
Read these instructions carefully. It is essential that you read the instructions and safety
regulations before you attempt to assemble or use the features that are on this cab/ROPS.
Danger: Indicates an immediate hazardous situation which, if not avoided, will result in death
or serious injury.
Warning: Indicates a potentially hazardous situation which, if not avoided, may result in death
or serious injury.
Caution: Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
Important: Indicates that cab or property damage may result if instructions are not carefully
followed.
NOTE: All products are designed to give safe, dependable service if they are operated and
maintained according to instructions. It is the owner’s responsibility to be certain anyone
operating this product reads this manual, and all other applicable manuals, to become familiar
with this cab and all safety precautions. Failure to do so could result in serious personal injury
or cab damage. If you have any questions, consult your dealer. Read and understand this
manual before operation.
NOTE: A safe operator is the best assurance against accidents. All operators, no matter how
experienced they may be, should read this operator manual and all other related manuals
before attempting to operate features in this cab/ROPS and operate the base tractor. Please
read the following section and pay particular attention to all safety recommendations
contained in this manual and those labelled on the cab and on the tractor.
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

General Safety
1. Never let an unqualified or untrained driver operate the tractor.
2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be
familiar with its use.
3. Do not carry passengers.
4. Never operate the tractor in a closed building for a prolonged period. Ensure adequate
ventilation is present, as engine exhaust fumes are poisonous and can kill.
5. Always keep sleeves, jackets or other loose clothing relatively tight and belted. Loose clothing
may catch on moving parts and result in severe personal injury or death.
6. Provide a first-aid kit, securely attached inside of the ROPS for use in case of accident.
7. Never jump from the tractor. There is a danger of tripping or falling on protruding parts.
8. Use steps and hand holds when mounting and dismounting the tractor, or for servicing
components too high to reach from the ground.
9. When seated in the ROPS, fasten seat belt before starting the engine. A proper seat belt must
be worn at all times when using a ROPS.
10. Safety devices and shields are intended to protect operators from injury or death. Under no
circumstances should they be modified, disabled or removed.
Operating Safety
1. Always operate the tractor controls while sitting in the operator’s seat.
2. Lock seat in position and buckle seat belt before operating the tractor.
3. Avoid abrupt sharp turns at high speeds.
4. On sloped terrain, do not make sharp turns as machine stability could be compromised.
5. Operate the tractor smoothly, avoid abrupt starts and stops.
6. Keep all shields in place when operating the tractor.
7. Do not operate the tractor when you are tired, sick, or impaired.
8. Never operate the tractor in confined areas; visibility next to the tractor is reduced. Injury to
bystanders or damage to the ROPS or equipment may result.
Safety
Carefully review the procedures given in this manual and the tractor operator’s manual with all
operators annually. It is important that all operators become familiar with and follow safety
precautions. Operating instructions must be given to everyone using the tractor before
operation and at least once yearly thereafter in compliance with OSHA Regulations 1928.57
(United States).
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

Safe Operation on Rough Terrain
1. Drive the tractor slowly on hillsides and curves to eliminate the danger of tipping. Avoid
slopes which are too steep for safe operation. Avoid sharp uphill turns.
2. Always drive slowly enough over rough ground or obstructions. Drive at speeds slows enough
to ensure your safety.
3. When driving out of a ditch, gully, or up a steep hillside, engage the clutch slowly. Avoid
sharp uphill turns.
4. When descending steep grades, select a sufficiently low gear to maintain control with
minimum use of braking.
5. Use caution when driving near the edge of a ditch or gully. It may cave in, causing the tractor
to roll over.
6. Be alert when operating near trees, slopes and around obstructions. Tree branches can cause
damage to ROPS components.
Maintenance Safety
1. Remove mud, crop residue, chains, and tools from steps and operator’s platform. They may
interfere with pedal operation or entry/exit from tractor.
2. When servicing components are too high to reach from the ground use steps and handholds.
Do not use fenders or shields that are not designed as steps.
Safe Highway Operation
1. Before operating the tractor on, or near, public roadways check with your local authorities
for any local regulations that will affect you.
2. Equip towed implements with slow moving vehicle (SMV) signs when traveling on public
roads.
3. Install additional lights on implement rear to safeguard against rear end collisions.
4. Use hazard warning flashers as required by law when transporting or driving on public roads.
If the tractor had warning flashers removed when mounting the ROPS, they must be replaced
prior to operation on public roads.
5. Keep to the right, yielding right-of-way traffic, especially if pulling implements. Pull off the
road and stop to allow motorists to pass. Drive on the road shoulder, if permitted by law.
6. Use extreme caution when pulling heavy loads at road speeds. Avoid hard application of the
tractor brakes at high speed.
7. Always drive slowly near curbs, approaches or ditches.
8. If equipped, ensure headlights are aligned so they will not blind the operators of oncoming
vehicles. If the tractor is not equipped with turn signals and law requires them, install them
prior to operating on or near public roads.
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

9. Use your turn signals, checking for traffic well in advance of turning. If the tractor is not
equipped with turn signals and law requires them, install them prior to operating on or near
public roads.
Safety Decals
1. Keep decals clean. Remove dirt with a wet clean cloth when necessary.
2. Replace safety decals if destroyed, missing, painted over or unreadable. If any safety decals
are covered or obscured when the ROPS is mounted, it is recommended that you purchase
replacement decals from the tractor manufacturer. Mount them in a readable location at, or
near, their original location before operating the tractor.
3. New ROPS decals and tractor decals are available from your tractor dealer.
ROPS Safety
1. Install the ROPS in accordance with Tektite mounting instructions. Failure to do so may affect
the ROPS ability to withstand a roll over.
2. If the ROPS is subjected to alteration, structural damage or involved in an over turn accident,
the entire structure must be replaced. Failure to do so may result in injury or death in the event
of a roll over.
3. If the tractor in not equipped with seat belts, purchase approved seat belts from the tractor
manufacturer or Tektite prior to operating the tractor.
4. Always fasten seat belts prior to operating the tractor.
5. Always operate the tractor from the operator’s seat.
6. Remove mud, crop residue, chains and tools from steps and operator’s platform. They may
interfere with pedal operation or entry/exit from the tractor.
7. Remove all loose chains, tools, and equipment from the operator’s platform. Failure to do so
may cause injury or death in the event of a roll over.
8. Do not install the ROPS on a tractor model that the ROPS is not designated for (compatible
tractor designations are printed on the ROPS serial number plate). The ROPS is designed
specifically for individual models to ensure ROPS requirements will be met. Installing the ROPS
on a non designated tractor may result in injury or death.
Emergency Exits
This ROPS cab has 2 exits, which may be used in an emergency: left and right doors.
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

Operating Instructions
Important
The following section locates, identifies and briefly describes the functions of all cab controls.
All operators should familiarize themselves with control location and function prior to operating
the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or
death to operators and bystanders.
There is one switch plate located in the cab. The following switches are available and their
functionality is described.
Cab Switch Plate
1. Front Wiper Rocker Switch (standard)
Low position: Off
High position: On
Note: indicator light activates when wiper is on.
2. Rear Wiper Rocker Switch (not available on all models)
Low position: Off
High position: On
Note: indicator light activates when wiper is on.
3. Front Work Light Rocker Switch (optional)
Low position: Off
High position: On
Note: indicator light activates when work lights are on.
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

4. Rear Work Light Rocker Switch (optional)
Low position: Off
High position: On
Note: indicator light activates when work light is on.
5.Beacon Rocker Switch (optional)
Low position: Off
High position: On
Note: indicator light activates when work lights are on.
6. Water Heater Fan Rocker Switch (optional)
Low position: Off
High position: On
Note: indicator light activates when work lights are on.
7. Wiper Washer Momentary Rocker Switch (Front and rear may be optional)
Low position: On
Mid position: Off
High position: On
Standard and optional features are individually fused, and the fuses can be accessed behind the
plug in the middle of the switchplate.
Cab Circuit Protection
The Tektite ROPS cab is wired to provide maximum protection against individual circuit
overload. All optional components are fused internally behind the cab switch plate. Cab wiring
is direct to the tractor battery. DO NOT leave options activated when tractor is not running as
battery run down can occur.
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

After your ROPS Cab has been installed:
Before starting a tractor equipped with a Tektite ROPS cab:
1. Clear the operator platform of all tools. Tools left in or around the ROPS and tractor can
cause operator interference which could lead to bodily injury and/or damage the machine.
2. Inspect the ROPS and tractor to ensure all bolts are tight and re-tighten if required.
3. Ensure that all pedals, levers, and controls have adequate clearance for normal operation.
4. Ensure that all electrical components of both the ROPS and tractor operate normally.
5. Ensure your door latches properly onto the striker pin. Immediately after installation, the
ROPS frame may flex slightly from installation, and the door latch will need to be re-aligned for
proper operation. Loosen the striker pin, striker mounting plate and door latch as necessary to
get a proper alignment of the door striker.
Using Tractor Back-Hoe:
The cab rear window must be un-bolted from the bottom and removed prior to operating back-
hoe on tractor.
Service Parts Breakdowns:
Following are parts breakdowns for components that may require service parts replacement
during the life of the ROPS. If you require replacement parts, please contact the dealer that
you purchased the ROPS from and indicate which parts you require.
June 2021© Kubota B2301/2601 ROPS Cab Operation Manual

Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X = 1/16"
Angular = 1.0
Drawn By:
Checked By: Size:
File Name:
Units:
Date:
Date:
Req'd: Description:
Tektite Manufacturing Inc.
427 Buffalo Street, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name Description Qty
1 A00-0013 TEKT-0009 5MM Bushing 4
2 A00-0014 TEKT-0092 Thick Bushing 4
3 A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB 4
4 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 4
5 K07-0004 KUB2601-029 Lower Front Window 1
6 K07-0017 KUB2601-060- Lower Front WIndow Seal 1
L&R Lower Front Window Assembly
Daryl Furkalo 2020-01-27 Imp. KUB2601-ASM-30_OP
B
Discontinued on new cabs Jan 1, 2020
SCALE 0.500
1
2
3
4
5
6

Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X = 1/16"
Angular = 1.0
Drawn By:
Checked By: Size:
File Name:
Units:
Date:
Date:
Req'd: Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name Description Qty
1 A00-0013 TEKT-0009 5MM Bushing 5
2 A00-0014 TEKT-0092 Thick Bushing 3
3 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 1
4 A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB 3
5 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 4
6 A00-0033 315-080 Rear Wiper Shaft Grommet 1
7 A00-0043 WWF-MOTOR WWF Wiper Motor, 1" Shaft 1
8A00-0429(A00-0108-old) TEKT-ASM-037 WWF, Adjustable Radial Arm, 15" to 19" 1
9A00-0430(A00-0339-old) 302-1160_BLADE Wiper Blade, 16", Narrow Saddle 1
10 K07-0010 KUB2601-040 Windshield Glass, Standard Cab 1
11 K07-0016 KUB2601-059- Windshield Seal, Std Cab 1
1 req Windshield Assembly
Daryl Furkalo 2015-09-23 Imp. KUB2601-ASM-29_OP
B
SCALE 0.250
1
2
3
4
5
6
7
8
9
10
11
*Inquire with us to ensure you are ordering the correct wiper blade/arm*

Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X = 1/16"
Angular = 1.0
Drawn By:
Checked By: Size:
File Name:
Units:
Date:
Date:
Req'd: Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name Description Qty
1 A00-0013 TEKT-0009 5MM Bushing 5
2 A00-0014 TEKT-0092 Thick Bushing 3
3 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 1
4 A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB 3
5 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 4
6 A00-0033 315-080 Rear Wiper Shaft Grommet 1
7 A00-0043 WWF-MOTOR WWF Wiper Motor, 1" Shaft 1
8A00-0430(A00-0109-old) 302-1160_BLADE Wiper Blade, 16", Narrow Saddle 1
9A00-0429(A00-0316-old) TEKT-ASM-052 WWF, Adjustable Radial Arm, 14" Length 1
10 K07-0009 KUB2601-039 Rear Window, Standard Cab 1
11 K07-0015 KUB2601-058_ Rear Window Seal, STD cab 1
1 req Rear Window Assembly
Daryl Furkalo 2015-09-23 Imp. KUB2601-ASM-28_OP
B
SCALE 0.250
2
3
9
4
5
67
8
10
11
1
*Inquire with us to ensure you are ordering the correct wiper blade/arm*

Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X = 1/16"
Angular = 1.0
Drawn By:
Checked By: Size:
File Name:
Units:
Date:
Date:
Req'd: Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name Description Qty
1 A00-0013 TEKT-0009 5MM Bushing 8
2 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 4
3 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 4
4 A00-0044 TEKT-ASM-002 Side Window Hinge Weldment 2
5 A00-0057 TEKT-0020MIR Side Window Latch, L60776 1
6 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD 1
7 A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD 1
8 A00-0087 TEKT-0028 Side Window Slider Bracket 2" tube 1
9 A00-0119 WASHER_1-4 Washer, Flat, 1/4" 2
10 K07-0008 KUB2601-038 Side Window Glass, Standard Cab 1
11 K07-0013 KUB2601-056R Side Window Seal, Std Cab 1
1 req Right Side Window Assembly
Daryl Furkalo 2015-09-23 Imp. KUB2601-ASM-26R_OP
B
SCALE 0.250
1
11 10
9
8
7
6
5
4
3
2

Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X = 1/16"
Angular = 1.0
Drawn By:
Checked By: Size:
File Name:
Units:
Date:
Date:
Req'd: Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name Description Qty
1 A00-0013 TEKT-0009 5MM Bushing 8
2 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 4
3 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 4
4 A00-0046 TEKT-ASM-002R Side Window Hinge Right 2
5 A00-0056 TEKT-0020 Side Window Latch, L60775 1
6 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD 1
7 A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD 1
8 A00-0087 TEKT-0028 Side Window Slider Bracket 2" tube 1
9 A00-0119 WASHER_1-4 Washer, Flat, 1/4" 2
10 K07-0008 KUB2601-038 Side Window Glass, Standard Cab 1
11 K07-0013 KUB2601-056- Side Window Seal, Std Cab 1
1 req Left Side Window Assembly
Daryl Furkalo 2015-09-23 Imp. KUB2601-ASM-26_OP
B
SCALE 0.250
1
2
3
4
5
6
7
8
9
10
11

Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X = 1/16"
Angular = 1.0
Drawn By:
Checked By: Size:
File Name:
Units:
Date:
Date:
Req'd: Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name Description Qty
1 A00-0001 DLP-HANDLE Outside Push Button Handle 1
2 A00-0003 RIGHT-LATCH Suicide Door Right Latch 1
3 A00-0013 TEKT-0009 5MM Bushing 17
4 A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB 3
5 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 1
6 A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB 4
7 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 10
8 A00-0040 REID-RST-160-RST-163 Grab Handle 1
9 A00-0041 TEKTITE-DECAL Tektite Cab Decal - Solid White 1
10 A00-0042 TEKT-ASM-001R Right Cab Door Hinge Weldment, Upper 1
11 A00-0118 FLANGE_BOLT_1-4X1 Flange Bolt, 1/4" x 1", YD 2
12 A00-0177 TEKT-0068 Handle Washer Spacer 1
13 A00-0229 TEKT-ASM-029R Right Door Hinge Weldment, Lower 1
14 A00-0295 FLANGE_BOLT_M6X30 Flange Bolt, M6x30, YD 1
15 K07-0007 KUB2601-037 Door Glass, Standard Cab 1
16 K07-0012 KUB2601-ASM-27R Right Door Frame Weldment, Standard Cab 1
17 K07-0014 KUB2601-057-R Door Seal, Std Cab 1
1 req Right Door Assembly
Daryl Furkalo 2015-09-23 Imp. KUB2601-ASM-25R_OP
B
SCALE 0.170
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X = 1/16"
Angular = 1.0
Drawn By:
Checked By: Size:
File Name:
Units:
Date:
Date:
Req'd: Description:
Tektite Manufacturing Inc.
24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name Description Qty
1 A00-0001 DLP-HANDLE Outside Push Button Handle 1
2 A00-0002 LEFT-LATCH Suicide Door Left Latch 1
3 A00-0013 TEKT-0009 5MM Bushing 17
4 A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB 3
5 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 1
6 A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB 4
7 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 10
8 A00-0039 TEKT-ASM-001 Left Door Hinge Weldment, Upper 1
9 A00-0040 REID-RST-160-RST-163 Grab Handle 1
10 A00-0041 TEKTITE-DECAL Tektite Cab Decal - Solid White 1
11 A00-0118 FLANGE_BOLT_1-4X1 Flange Bolt, 1/4" x 1", YD 2
12 A00-0177 TEKT-0068 Handle Washer Spacer 1
13 A00-0228 TEKT-ASM-029 Left Door Hinge Weldment, Lower 1
14 A00-0295 FLANGE_BOLT_M6X30 Flange Bolt, M6x30, YD 1
15 K07-0007 KUB2601-037 Door Glass, Standard Cab 1
16 K07-0011 KUB2601-ASM-27 Left Door Frame Weldment, Standard Cab 1
17 K07-0014 KUB2601-057- Door Seal, Std Cab 1
1 req Left Door Assembly
Daryl Furkalo 2015-09-23 Imp. KUB2601-ASM-25_OP
B
SCALE 0.170 1
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2

Notice of Confidentiality
This material is property of Tektite Manufacturing
Inc and is not to be used by the recipient for any
purpose other than the purpose for which it was
transmitted. The material remains the property of
Tektite and shall be returned upon request. The
material may not be reproduced or disclosed to third
parties without the written consent of Tektite.
Tolerances:
Unless otherwise
specified
X.X = 1/16"
Angular = 1.0
Drawn By:
Checked By: Size:
File Name:
Units:
Date:
Date:
Req'd: Description:
Tektite Manufacturing Inc.
427 Buffalo Street, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name Description Qty
1 KUB2601-ASM-32 1
2 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 2
3 A00-0023 FLANGE_BOLT_1-4X3-4 Flange Bolt, 1/4" x 3/4", YD 4
4 A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD 2
5 A00-0061 TEKT-0021 Striker Mounting Plate 2
6 A00-0084 TEKT-0070 Gas Shock 2
7 A00-0085 TEKT-0069 Gas Shock Stud 2
8 A00-0101 STRIKER-PIN Striker Pin 2
9 A00-0141 ROUND_MIRROR_6_INCH External 6" Mirror 2
10 A00-0202 TEKT-ASM-009R Right Mirror Bracket Weldment 1
11 A00-0203 TEKT-ASM-009 Left Mirror Bracket Weldment 1
12 A00-0371 TEKT-0175 New LED Work Light (Blazer Intl) 4
13 A00-0389 KUBX2380-NOSTRIL Plastic Light Nostril 2
14 K07-0038 KUB2601-076 Lower Front Window, 2020 2
1 req Accessories
Daryl Furkalo 2020-01-27 Imp. KUB2601-ASM-13
B
SCALE 0.140
2
12
9
8
7
6
5
4
3
10
11
13
14
