MINI SKID LOADER
MODELS 950, 1150
________________________________________________
OPERATOR’S MANUAL
________________________________________________
RAMROD Equipment
(A Division of Leon’s Mfg. Company Inc.)
Canada
P.O. Box 5002
135 York Road East
Yorkton, Saskatchewan
S3N 3Z4
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.ramrodequip.com
Rev. September 2018

INTRODUCTION
TO OUR CUSTOMER:
RAMROD EQUIPMENT is pleased that you have chosen a RAMROD MINI-SKID.
This loader is a simple, compact power source designed and manufactured to give you years of
dependable service.
Read this Manual carefully before operating the Mini-Skid. It contains the necessary
information for safe and proper operating, routine servicing and preventive maintenance.
We also recommend that you carefully read the Engine Manufacturer’s Manual before operating
the Mini-Skid. Do not neglect the maintenance that is recommended.
The reference to right-hand and left-hand used throughout this Manual refers to the position
when operating the machine, facing forward.
For any additional information required, please refer to your RAMROD Dealer.
© Copyright 2008, Ramrod Equipment Corporation
All rights reserved.
No part of this book may be reproduced or transmitted by any means, electronic or mechanical,
including photocopying, recording or by any information storage and retrieval system, without
written permission of Ramrod Equipment Corporation.
January 2008
Printed in Canada
RAMROD EQUIPMENT
(A Division Of Leon’s Mfg. Company Inc.)
CANADA
Box 5002 –135 York Road East
Yorkton, Saskatchewan
S3N 3Z4
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.ramrodequip.com

RAMROD WARRANTY
The RAMROD EQUIPMENT warrants each new RAMROD Mini-Skid to be free from proven
defects in material and workmanship under normal use and maintenance for a period of twelve
(12) months, commencing with delivery to the original buyer. Under conditions of this warranty,
the Mini-Skid must be operated according to manufacturer’s instructions, and by a competent
and careful operator.
This warranty shall not apply to the Mini-Skid on any part thereof, which has been subject to
misuse, negligence, alteration, accident, or used in any way, which, in the manufacturer’s option,
adversely affects its performance.
It is the responsibility of the Buyer, at his expense, to transport the Mini-Skid or any part thereof
in fulfilling this warranty to a designated service shop.
In no event shall the Buyer be entitled to recover for incidental or consequential damages such
as, but not limited to, rental of replacement equipment, loss of profits, and loss of Mini-Skid
fluids and lubricants.
This warranty does not extend to Mini-Skid components such as, but not limited to, engine, tires,
batteries, hydraulic/hydrostatic components which are manufactured by others, and which carry
separate warranties of their respective manufacturer’s.
This warranty is in lieu of all other warranty expressed or implied, and there are no warranties of
merchantability or fitness for a particular purpose.
No representative of the manufacturer, nor the selling dealer has authority to change this
warranty in any manner whatsoever.
Printed in Canada
NOTE: In order for warranty to be in effect, the following warranty
registration forms must be completed and one copy sent to Ramrod
Equipment at time of sale.

Leon's Mfg. Company Inc.
“Home of Quality Leon & Ramrod Products”
Leon's Mfg. Company Inc.
PO Box 5002, 135 York Road East, Yorkton, SK S3N 3Z4 Canada
Ph: 306.786.2600 Fx: 306.782.1884
www.leonsmfg.com www.ramrodequip.com www.lrattachments.com
RAMROD MINI-SKID LOADER
DEALER PRE-DELIVERY INSPECTION & SERVICE REPORT
Owner: Dealer:
Address: Address:
Model: Serial No: Date:
Engine Serial No: Hour Meter Reading:
Item Remarks
( ) Check engine oil
( ) Check hydraulic oil level
( ) Check radiator coolant level
( ) Check battery fluid level
( ) Check tension of engine belts
( ) Check air cleaner hoses & connections
( ) Grease/lubricate all pivot points
( ) Grease/lubricate control lever cross
shafts and linkages
( ) Check all wheel bolts for tightness
(90 ft-lbs)
( ) Check tire pressure
( ) Check drive chain adjustment
( ) Check for loose or missing bolts, nuts,
cotter pins etc.

RAMROD EQUIPMENT
NEW MINI-SKID WARRANTY REGISTRATION FORM
_____________________ __________________ _____________________
Mini-Skid Serial Number Model Number Engine Serial
Number
________________________________ _______________________________
Name of Owner Name of Dealer
________________________________
Owner’s Type of Business
________________________________ _______________________________
Owners Address Dealers Address
________________________________ _______________________________
Date Mini-Skid Sold Date Mini-Skid Delivered
OPTIONS & ACCESSORIES
TIRES:
4.00 X 8
16 X 6.50
18 X 8.50
20 X 8.50
TRACKS
BUCKETS:
31 inch ( 787 mm)
36 inch ( 914 mm)
42 inch (1067 mm)
44 inch (1118 mm)
RAMROD COPY
Please forward to:
RAMROD EQUIPMENT
P.O. Box 5002, 135 York Road East
Yorkton, Saskatchewan, Canada
S3N 3Z4
Phone: [phone]
Fax: [phone]

P.O. Box 5002, 135 York Road East
Yorkton, Saskatchewan, Canada
S3N 3Z4
Phone: [phone]
Fax: [phone]
RAMROD EQUIPMENT
NEW MINI-SKID WARRANTY REGISTRATION FORM
_____________________ __________________ _____________________
Mini-Skid Serial Number Model Number Engine Serial
Number
________________________________ _______________________________
Name of Owner Name of Dealer
________________________________
Owner’s Type of Business
________________________________ _______________________________
Owners Address Dealers Address
________________________________ _______________________________
Date Mini-Skid Sold Date Mini-Skid Delivered
OPTIONS & ACCESSORIES
TIRES:
4.00 X 8
16 X 6.50
18 X 8.50
20 X 8.50
TRACKS
BUCKETS:
31 inch ( 787 mm)
36 inch ( 914 mm)
42 inch (1067 mm)
44 inch (1118 mm)
DEALER COPY

7
P.O. Box 5002, 135 York Road East
Yorkton, Saskatchewan, Canada
S3N 3Z4
Phone: [phone]
Fax: [phone]
RAMROD EQUIPMENT
NEW MINI-SKID WARRANTY REGISTRATION FORM
_____________________ __________________ _____________________
Mini-Skid Serial Number Model Number Engine Serial
Number
________________________________ _______________________________
Name of Owner Name of Dealer
________________________________
Owner’s Type of Business
________________________________ _______________________________
Owners Address Dealers Address
________________________________ _______________________________
Date Mini-Skid Sold Date Mini-Skid Delivered
OPTIONS & ACCESSORIES
TIRES:
4.00 X 8
16 X 6.50
18 X 8.50
20 X 8.50
TRACKS
BUCKETS:
31 inch ( 787 mm)
36 inch ( 914 mm)
42 inch (1067 mm)
44 inch (1118 mm)
CUSTOMER COPY

TABLE OF CONTENTS
I. SAFETY ........................................................................................................................ 1
Safety Precautions........................................................................................................... 1
II CONTROL..................................................................................................................... 3
Engine Controls –Kawasaki 27hp Gas .......................................................................... 3
Engine Controls –Kubota 22hp Diesel .......................................................................... 4
Control Panel .................................................................................................................. 5
Attachment Lock Pins..................................................................................................... 7
III OPERATION ............................................................................................................... 8
Pre-Starting Inspection and Preparation ......................................................................... 8
Starting Procedures......................................................................................................... 8
Shut-off Procedures ........................................................................................................ 9
Mounting Attachments.................................................................................................. 10
Operational Procedures................................................................................................. 11
Lift Arm Support Device............................................................................................ 114
Lifting The Mini-Skid................................................................................................. 114
IV. MAINTENANCE.................................................................................................... 145
Engine Maintenance –Kawasaki Engine ..................................................................... 15
Engine Maintenance –Kubota Engine ......................................................................... 16
Battery Maintenance..................................................................................................... 17
Fuels, Lubricants and Capacities .................................................................................. 18
Hydraulic System Maintenance.................................................................................... 19
Final Drive Maintenance............................................................................................... 20
Chain Lubrication ......................................................................................................... 22
Periodic Greasing Details ............................................................................................. 23
Periodic Maintenance and Service Schedule................................................................ 24
Troubleshooting............................................................................................................ 25

1
I. SAFETY
OPERATE MINI-SKID SAFELY
IMPROPER OPERATION OF THIS MINI-SKID MAY RESULT IN SERIOUS INJURY.
BEFORE OPERATING THIS MINI-SKID, OPERATORS MUST HAVE PROPER
INSTRUCTIONS, BE FAMILIAR WITH THE SAFETY PRECAUTIONS, AND HAVE READ
THIS AND THE ENGINE MANUFACTURER’S MANUAL THOROUGHLY.
THIS SAFETY ALERT SYMBOL
POINTS OUT IMPORTANT
SAFETY PRECAUTIONS.
OPERATORS MUST UNDERSTAND CAPABILITIES AND LIMITATIONS OF THE EQUIPMENT,
WITH RESPECT TO SPEED, BRAKING, STEERING, STABILITY AND LOAD CHARACTERISTICS
BEFORE STARTING TO OPERATE.
NEW OPERATORS MUST CHECK ALL CONTROLS IN A SAFE, OPEN AREA BEFORE STARTING
WORK.
WARNING
This Decal Advised Of Actions or
Danger Which Can Cause
Personal Injury.
Wear Ear Protection
When Engine Is Running.
The Sound Pressure
Level Is: 102 DB for A
Weighted level & 88 DB
For C Weighted Level…
IMPORTANT
This Decal Identifies Procedures
Which Must Be Followed to
Prevent Damage Top The
Mini-Skid
Do Not Use The Mini-Skid
During A Thunderstorm
Or When There Is A
Chance Of A Lightning
Strike.
SAFETY PRECAUTIONS
READ YOUR OWNERS’S MANUAL AND ALL SUPPLEMENTS BEFORE OPERATING YOUR
MINI-SKID.
WHEN LEARNING TO OPERATE, PROCEED SLOWLY AND CAREFULLY.
DO NOT PLACE FEET UNDER THE PLATFORM.
DO NOT OPERATE ANY OF THE CONTROL LEVERS INCLUDING AUXILIARY POWER TAKE-
0FF UNLESS YOU ARE STANDING WITH BOTH FEET ON THE PLATFORM AND FIRMLY
HOLDING THE GRIP HANDLES.
DO NOT JERK THE CONTROL LEVERS, USE A STEADY EVEN MOTION.

2
SAFETY
SAFETY PRECAUTIONS –CONTINUED
KEEP HANDS, FEET AND CLOTHING AWAY FROM ALL MOVING PARTS AND CYLINDERS.
DO NOT RIDE IN BUCKET.
DO NOT ALLOW MORE THAN ONE PERSON ON THE MINI-SKID AT ANY TIME.
DO NOT ALLOW ANY OTHER PERSON OR ANIMAL CLOSE TO THE MINI-SKID WHILE IN OPERATION.
WATCH FOR OTHER PEOPLE AND EQUIPMENT.
KEEP THE BUCKET LOW WHEN TRAVELLING, TURNING OR CHANGING SPEED.
TRAVEL SLOWLY OVER ROUGH TERRAIN.
BEWARE OF TRENCHES, HOLES AND SIDE SLOPES
DO NOT DRIVE THE MINI-SKID ACROSS STEEP SLOPES.
LOAD, UNLOAD AND TURN AROUND ON FLAT, LEVEL GROUND ONLY.
ENSURE ADEQUATE VENTILATION WHEN USING THE MACHINE IN CONFINED SPACES.
DO NOT CARRY LOAD WITH ARMS IN A RAISED POSITION. ALWAYS CARRY LOADS CLOSE TO THE
GROUND. DO NOT STEP OFF PLATFORM WITH THE LOAD RAISED.
TO AVOID FREE-FALL OF LOAD WHEN LOWERING LIFT ARMS, DO NOT PUSH LIFT ARM LEVER
FULLY FORWARD.
DO NOT EXCEED RATED LOAD CAPACITY.
ALWAYS LOWER THE BUCKET AND SHUT OFF THE ENGINE BEFORE LEAVING THE MACHINE.
AVOID PARKING ON A SLOPE. IF IT IS NECESSARY, PARK ACROSS THE GRADE, GROUND THE
BUCKET AND BLOCK THE WHEELS.
WHEN HOOKING UP ATTACHMENTS TO THE MACHINE, CHECK TO BE SURE LOCK PINS ARE FULLY
ENGAGED.
DO NOT PLACE ANY PART OF THE OPERATOR’S BODY OR ALLOW ANYONE UNDER MINI-SKID ARMS
OR ATTACHMENTS.
DO NOT LUBRICATE, ADJUST OR REPAIR THE MACHINE WITH THE ENGINE RUNNING.
NEVER FUEL A HOT MACHINE.
DO NOT SMOKE WHEN FUELING OR OPERATING THE MACHINE.
ALWAYS READ THE OWNER’S MANUAL FOR PROCEDURES FOR SERVICING AND MAINTENANCE OF
THE MINI-SKID.
REMEMBER, SAFETY FIRST.

3
II CONTROL
It is necessary to become familiar with the location and purpose of each control before
operating the Mini-Skid.
ENGINE CONTROLS –KAWASAKI 27 HP GASOLINE
Low Fuel Indicator Low Hyd.
Oil Indicator
Low Oil Warning
Light Tachometer/
Hour Meter
Throttle Control
Ignition
Engine Temperature Switch
Indicator
Light Switch
Choke Control Figure 1: Kawasaki Instrument Panel
Choke Control –Pull choke control out
to start a cold engine. As the engine
warms up push choke control in
gradually
Throttle Control –When the Throttle
control lever is set down the engine is at
idle speed. Pushing the control up
increased the engine speed
Low Oil Warning Light –This light
illuminates if the engine oil is low. Stop
the engine and add oil immediately if the
light comes on
Ignition Switch –The ignition switch is
a three-position switch. Clockwise from
the OFF position are the ON and start
position.
Engine Temperature Light –This light
illuminates if the engine temperature
becomes too hot. Shut off the engine
immediately
IMPORTANT
Be Sure Ignition Key Is In Off Position,
Or Even Removed, When The Engine Is
Not Running
IMPORTANT
For Maximum Power While Working,
The Engine Should Be Running At Full
Throttle

4
II CONTROL
It is necessary to become familiar with the location and purpose of each control before
operating the Mini-Skid.
ENGINE CONTROLS –KUBOTA 22 HP DIESEL
Low Fuel Hourmeter
Indicator
Low Hyd. Ignition
Oil Indicator Switch
Low Oil
Warning Light
Throttle Light Switch Radiator Cover Shut-off Button
Figure 2: Kubota Instrument Panel
Low Hydraulic Oil Indicator –This
light illuminates if the hydraulic oil is
low. Stop the machine immediately and
add oil.
Throttle –When the control lever is set
down the engine is at idle speed.
Pushing the control up increases engine
speed.
Low Oil Warning Light –This light
illuminates if the engine oil is low. Stop
the engine and add oil immediately.
Radiator Cover –This plate allows
access to the radiator fill cap. Remove
the wing nut and cover to check fluid
level and fill. Always replace cover
before running machine to avoid
burns.
Shut-off Button –To shut-off the
machine turn the ignition switch to the
off position and hold shut-off button
until engine stops (3 to 4 seconds). The
ignition switch must be turned off to
prevent battery drain.
Hourmeter –The hour meter records
total machine hours. Note: the
hourmeter accumulates whenever the
machine key is not in the off position.
Ignition Switch –The ignition switch is
a four position switch. Turn the key
counter-clockwise and hold it to warm
the glow plugs. The glow plugs must be
warmed for three to four seconds prior to
starting the machine.
IMPORTANT
Be Sure Ignition Key Is In Off Position,
Or Even Removed, When The Engine Is
Not Running
IMPORTANT
For Maximum Power While Working,
The Engine Should Be Running At Full
Throttle

5
7
1
2
3
4
5
6
7
II CONTROL Figure 3: Control Panel
PRIMARY CONTROLS
1. Lift Arm Lever
2. Tilt Lever
3. Auxiliary Lever
4. Left Hand Drive Lever
5. Right Hand Drive Lever
6. Grip Handle
7. Auxiliary Controls –(6 GPM each)
DRIVE LEVERS, Item 4 & 5 Figure 1
The left hand drive lever controls the
wheels on the left hand side and the right
hand drive lever controls the wheels on the
right hand side.
Engage the drive levers slowly because
even a small movement of the levers will
cause motion. All lever movements
should be smooth and gradual. To drive
the Mini-Skid straightforward, move both
control levers forward the same amount.
To drive the Mini-Skid Straight backward,
move control levers back the same
amount.
The Mini-Skid is steered by moving one
lever further forward than the other. To
turn left, move the right lever further
ahead than the left lever; to turn right,
move the left lever further ahead than the
right lever. For the Mini-skid to perform a
spin-turn, or “Skid Steer”, move one lever
forward and the other backward the same
amount.
The “TASKMASTER” features single-
handed steering. For normal operation,
the most comfortable hand position is to
operate the two steering levers with the
Figure 4: Single Hand Steering
palm of the right hand, with the fingers
gripping the grip handle. Flexing the
fingers will allow forward travel, and
simply rotating the palm will allow
normal steering. To reverse, slip the
palm back to the rear of the grip handle,
and use the tips of the fingers to pull the
steering levers backwards.
This position will allow for more precise
control of the unit. At the same time, the
left hand should grip the grip handle for
operator stability, but can also be used to
operate the tilt and dump functions as
required.
NOTE: Be sure to slowly move the
levers to the center (neutral) position
when stopping. The Mini-Skid will stop
INSTANTLY if the operator releases the
drive levers.
Warning
Do Not Move Any Of The Control Levers
Unless Standing With Both Feet On The
Platform And Holding The Grip Handles

6
II CONTROL
Warning
Keep BOTH HANDS On The Grip
Handle At All Times When Operating
The Machine.
Warning
Use Extreme Caution When Stopping. If
The Bucket Or Attachments Is Raised,
The Machine Can Tip.
Keep All Movements Smooth. All New
Operators Must Work The Machine In A
Safe Open Area To Become Familiar
With Its Operating Characteristics.
LIFT CONTROL LEVER –Item 1,
Figure 3
The outside control lever located on the
left hand side controls the lift. Pushing
the lever forward lowers the lift arm and
pulling the lever back raises the lift arm.
In these two positions, the lever is spring
centered to neutral upon release of the
lever.
TILT CONTROL LEVER –Item 2,
Figure 3
The inside control lever located on the
left hand side controls the tilting action
of attachments such as buckets, forks,
etc. Pulling the lever back tilts the
attachments back. Pushing forward on
the lever tilts forward or “dumps” the
attachment. The lever is spring centered
to neutral upon release.
IMPORTANT
Ensure That The Auxiliary Lever Is Kept
In Neutral When Not Being Used To
Avoid Wasting Power. Engine Is
Difficult To Start If Lever Is Engaged.
Hydraulic Oil May Also Overheat.
AUXILIARY CONTROLS –Item 7,
Figure 3
The Taskmaster features two “T-Bar”
control knobs which each provide 6
gallons per minute oil flow to the
auxiliary circuit. This allows the
operator to select the speed of the
attachment. These are “push-pull”
knobs. Pulling the knob “up” turns the
oil flow on to the attachment circuit.
Pushing the knob “down” turns the oil
flow off.
Thus, for attachments where 6 GMP is
desired (grapples, dozer blades,
backhoes, etc.) pull either one of the
control knobs up.
For attachments where 12 GPM is
desired (trenchers, post-hole augers,
tillers, etc.) pull both of the control
knobs up.
When the auxiliary circuit is not in use
(no hydraulic attachment mounted on the
machine), both control knobs should be
pushed down to turn off this circuit.
AUXILIARY LEVER –Item 3,
Figure 3
Direction of auxiliary flow and “on-off”
control of attachments is provided by
this lever. When the auxiliary controls
above are turned on, this lever becomes
active. Pushing this lever forward will
operate the attachment in one direction,
while pulling it back will operate the
attachment in the opposite direction.
This lever locks in each position and
must be returned to the center (off)
position manually.

7
II CONTROL
ATTACHMENT LOCK PINS
ATTACHMENT LOCK PINS
The “Taskmaster: tool bar design allows
changing from one attachment to another
quickly and easily, without having to
remove pins.
Attachments are secured on the unit with
two spring-loaded pins. Rotating the
handles on the pins one half of a turn
moves the pins from the locked to the
unlocked position.
To unlock attachments, rotate both pins
so that their handles are both pointing to
the outside of the tool bar, as show in
Figure 5.
To lock attachments, rotate both pins
inwards so that both handles are pointing
towards the center of the machine as
shown in Figure 6. This will allow the
springs to push the pins downwards
through the mounting holes in the
attachment and secure it to the unit.
WARNING
The design of the quick attach system is such that
attachments can be lifted and carried without the
lock pins being engaged. Before using any
attachment, check to be sure that the lock pins
are fully engaged and properly in place. The
attachment will fall off when dumped if the lock
pins are not engaged, resulting in possible
damage or injury.
Figure 5 (Lock Pins Disengaged)
Figure 6 (Lock Pins Engaged)
WARNING
After Hook-Up To Attachment, Check To
Be Sure Lock Pins Are Fully Engaged,
And Locked Into Position.

8
III OPERATION
You can take full advantage of all the features of your RAMROD Mini-Skid by
following the operating information presented here. The Mini-Skid has been designed to
do a lot of work with a minimum of operating fatigue.
Note: For more information regarding engine starting and operation, refer to your engine
“Owner’s Manual”.
PRE-STARTING INSPECTION AND PREPARATION
Before you start the Mini-Skid for the first time each day,
perform the following checks and service:
1. Check engine crankcase oil level.
2. Check engine fuel and open fuel
shut-off valve if closed.
3. Check Hydraulic fluid level in
tank.
4. Check for fuel, engine oil or
hydraulic leaks. –WARNING-
Never check for hydraulic leaks
with your bare hand. High-
pressure fluid could penetrate
your skid and cause injury.
5. Visually inspect all hoses, lines,
fittings, tires, pivot points,
mounting pins, nuts and bolts,
safety shields and decals for
possible failure or looseness.
6. Check that all controls are in the
neutral position.
WARNING
Do Not Move Any Of The Control Levers
Unless Standing With Both Feet On The
Platform And Holding The Grip Handles
STARTING PROCEDURE –GASOLINE ENGINE
1. Push the throttle lever down
slightly
2. Engage choke
3. Turn the ignition switch to “ON”
and then through to the “START
position. (If the engine fails to
start by cranking for 10 seconds,
wait 5 seconds before trying
again.
4. As the engine warms up, push
back the choke control gradually.
5. Set the throttle lever for idling
speed. Avoid excessive engine
speed during warm-up.
6. To restart a warm engine –move
throttle control slightly and turn
ignition key to “START”.
IMPORTANT
Do Not Crank Engine With Starter For More
Than 10 Seconds At A Time, As This Will
Overheat The Starter.
IMPORTANT
Ensure The Auxiliary Lever is In Neutral When
Not Being Used To Avoid Wasting Power.
Engine is Difficult To Start If Lever Is Engaged.
Hydraulic Oil May Also Overheat
IMPORTANT
Do Not Put Mini-Skid Under Full Load
Condition Until It Has Had An Adequate Warm-
Up Period.

9
III OPERATION
SHUT-OFF PROCEDURE –GASOLINE ENGINE
1. Park the Mini-Skid on level ground.
If it is necessary to park on a slope,
park across the grade and block the
wheels.
2. Lower the lift arms and ground the
bucket.
3. Return throttle control to “idle”
position, and allow engine to idle for
a short while.
4. Ensure Auxiliary & Control levers
are in neutral position.
5. Turn ignition key off, and remove
key.
IMPORTANT
Be Sure Ignition Key Is In OFF Position
Or Even Removed When The Engine Is
Not Running.
STARTING PROCEDURE –DIESEL ENGINE
1. Move fuel shut-off forward to the
“On” position.
2. Open Throttle lever slightly.
3. Turn key clockwise to the first,
“Preheat Position and hold for a few
seconds.
4. Turn key further clockwise to the
“Start” position to crank engine.
5. Once engine starts, release key.
6. Set throttle lever to idling speed to
allow engine to warm up.
7. If engine fails to start after cranking
10 seconds, repeat steps 3 and 4,
allowing a longer “Preheat” period
8. To restart a warm engine, move fuel
shut-off to the “On” position and
turn key to start.
SHUT-OFF PROCEDURE –DIESEL ENGINE
1. Park the Mini-Skid on level ground.
If it is necessary to park on a slope,
park across the grade and block the
wheels.
2. Lower the lift arms and ground the
bucket.
3. Move throttle to a slow idling
position and allow the engine to run
for a few minutes to cool down.
4. Pull fuel shut-off knob back to the
“Off” position to stop engine.
5. Turn key counter –clockwise to the
“Off” position.

10
III OPERATION
MOUNTING ATTACHMENTS
INSTALLATION OF ATTACHMENT
1. Rotate Lock Pins to the unlock
position (handle pointing outwards).
2. Tilt the attachment frame forward as
show in Figure 7, so that the top
round edge of the attachment frame
will fit under the lip of the
attachment.
3. Drive into the attachment, raising the
arms so that the top of the
attachment frame slips under the lip
on the attachment, and attachment
lifts slightly.
4. Using the tilt cylinder, roll back the
attachment so it drops into place, as
shown in Figure 8
5. Rotate the lock pins to the locked
position (handles facing inwards),
and check that the lock pins are fully
inserted through the lock holes in the
attachment.
6. Connect attachment hydraulic hoses
(if required) to the quick couplers as
shown in Figure 9.
WARNING
After Hook-Up To Attachment, Check To
be Sure Lock Pins Are Fully Engaged
and Locked Into Position
REMOVAL OF ATTACHMENT
1. Lower lift arms and tilt forward on
the attachment so that the attachment
is resting on the ground.
2. If attachment is hydraulically
equipped, stop the engine, relieve
hydraulic pressure in the attachment
lines by shifting the auxiliary lever
back and forth, and disconnect the
attachment.
Figure 7
Figure 8
Figure 9
3. Rotate the lock pins to the unlocked
(handles pointing outwards) position.
4. Start engine, tilt the attachment
mount frame clears that lip on the
attachment, and back the Mini-Skid
away from the attachment.

11
III OPERATION
OPERATIONAL PROCEDURE
Mini-Skid operational procedure and suggestions in this manual are based on the use of a bucket.
Operating procedure and suggestions for such other attachments as dozer blade, posthole auger,
trencher, rock hammer, etc., are included in the respective attachments bundle.
OPERATING SUGGESTIONS
1. Install an attachment (bucket). Drive
carefully to a clean and level area and
practice operating the Mini-Skid at a
slow rate until familiar with the
operation of all controls.
2. Hydraulic power transmission is
instantaneous. When using the drive
levers, sudden movement will result in
acceleration to full speed and a very
jerky ride. Use smooth and gradual
movements when using the drive levers.
3. For efficient operation of the Mini-Skid,
Keep the work area small, and as level
as possible.
4. Decrease cycle time by “SKID” turning
rather than backing up, using a slow
turn, then going forward.
5. When driving on slopes keep the
heaviest end of the Mini-Skid upward.
When driving on a slope with an empty
bucket, back up the slope in reverse, and
drive down a slope forward as in Figure
10. When driving on a slope with a
load, drive up the slope forward and
back down the slope in reverse as in
Figure 11.
6. Fill the bucket to rated capacity.
Turning is easier with a full load than
with a partial load.
7. To increase machine life, let the engine
warm completely before starting
operations each day. Avoid “over-
loading” or “lugging” the Mini-Skid.
WARNING
Always Carry The Bucket Low While Moving. Drive
Directly Up And Down Instead of Across A Slope
Figure 10 –Empty Bucket
Figure 11 –Full Bucket
Figure 12
WARNING
If Operating Mini-Skid Indoors, Make Sure
Building Is Well Ventilated.

12
III OPERATION
FILLING AND DUMPING A BUCKET
1. Approach the pile with the lift arms fully
down and bucket cutting edge just
skimming the top of the ground as in
Figure 12.
2. As soon as the bucket is full, tilt bucket
back and back away from the pile, as
shown in Figure 13 and 14.
3. When dumping, raise bucket high
enough to clear stockpile or sides of
container being loaded.
4. Drive slowly forward until bucket is
over dumping area and tilt bucket
forward until it completely empties.
5. Tilt bucket, back up if necessary to clear
container side and back away.
WARNING
Use Extreme Caution When Stopping. If
The Bucket Or Attachment Is Raised The
Machine Can Tip. Keep All Movements
Smooth and Gradual When Maneuvering
With Lift Arms Raised. Do Not Cross
Obstructions With Arms Raised. All New
Operators Must Work The Machine In A
Safe Open Area To Become Familiar With
Its Operating Characteristics.
WARNING
Never Step Off The Operator Platform With
The Load Raised
DIGGING WITH A BUCKET
1. Lower lift arms fully and tilt bucket
forward until cutting edge is on the
ground.
2. Drive Machine forward slowly and
continue to tilt bucket forward until it
enters the ground to desired depth and
then tilt it back a small amount to keep
an even depth, as show in Figure 15.
3. Continue driving forward until bucket is
full and then tilt bucket fully back while
driving slowly forward or
stopping the machine.
Figure 13
Figure 14
Figure 15
Figure 16
LEVELING
1. To spread material on uneven
ground, raise lift arms and tilt
bucket forward while driving
slowly forward, as shown in
Figure 16.
