Kucht KRH301A Assembly instructions

UNDER CABINET RANGE HOOD
www.kucht.com
APPLICABLE MODEL: KRH301A, KRH361A, KRH481A,
KRH3020A, KRH3620A, KRH4820A
INSTALLATION GUIDE AND USER MANUAL
BE A PRO IN YOUR KITCHEN 30” 36” 48”

IMPORTANT:
Read and save these instructions.
NOTICE:
Installer: Leave this guide with the homeowner.
Homeowner: Keep this guide for future reference.
KUCHT Warranty covers defects in Parts and Labor for functional parts that are
the result of normal usage for a period of time of 4 Years for Parts and Labor
from date of purchase. Functional parts are those components parts that are
critical to the performance of the product\’s essential function. Nonfunctional
parts are those that are not critical like knobs, handles, or cosmetic parts.
KUCHT will repair or replace the unit or any parts, therefore, as required, subject
to these terms and conditions.
General Conditions:
a. Warranty does not cover failure as a result of misuse, abuse, rust or corrosion,
spilled liquids or foreign objects found inside the unit; repair of damage caused
by accident, theft, re, ood, external causes such as, but not limited to, blow
fuses, inadequate electrical power, water and gas lines beyond the equipment,
or any use of the product not authorized by the manufacturer.
b. The maximum liability of the warranty for product replacement or repair shall
not exceed the original purchase price of the product.
c. KUCHT reserves the right to repair or replace the covered product with a
comparable feature model of like kind.
d. Warranty does not cover deterioration of the appearance of the product, any
cosmetic part such as paint, porcelain, glass, dents, scratches, chips, rust or
peeling.
e. Any damage resulting from unauthorized replacement parts, improper
service, or modications made to the covered product are not covered.
f. KUCHT is released from all liability due to indirect, consequential, or incidental
damages.
Limit of Liability:
Our Liability is limited to the original price of the covered equipment
WARRANTY

INSTALLATION GUIDE AND USER MANUAL
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
IMPORTANT SAFETY INSTRUCTIONS
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS,
READ THE FOLLOWING:
Use this unit only un the manner intended by the
manufacturer. If you have questions, please contact the
manufacturer.
Before servicing or cleaning the unit, switch the power o
and lock the service panel. This will prevent the power for
accidentally turning on. If the service panel does not lock,
secure a warning label, such as tag, to the service panel.
Installation work and electrical wiring must be done by a
qualied proesional(s) in accordance with all applicable
codes, standars, and re-rated constructions.
Do not operate any fans with a damaged cord or plug.
Discard the fn or return it to an autorized service facility for
further examination and/or repair.
To prevent back draft, sucient air is needed for proper
combustion. Gas from fuel burning equipment needs to
exhaust through the ue (chimney). Follow the heating
equipment manufacturer´s guideline and safety standards
such a those published by the National Fire Protection
Association (NFPA), the American Society for Heating,
Refrigeration and Air Conditioning Engineers (ASHRAE),
and the local code authorities.
When cutting or drilling into walls or ceilings; be aware of
electrical wires, piping, and other utilities.
Ducted fans must always be vented outdoors.
CAUTION: For general ventilation use only. Do
not use to exhaust hazardous or explosive
materials and vapors.
CAUTION: To reduce the risk of fire and to
porperly exhaust air, be sure to duct air
outside. - DO NOT vent exhaust air into attics,
crawl spaces, garages, or within walls and
ceilings.
WARNING: TO REDUCE THE RISK OF A RANGE
TOP GREASE FIRE, READ THE FOLLOWING:
Never leave surface units unatended at high settings,
Boil-over can cause smoke and grease to spill over that
may ignite. Heat oils slowly on low or medium settings.
Always turn the hood ON when cooking at high heat or
when ambeing food (i.e. Crepes Suzette, Cherries Jubilee,
Peppercorn Beef Flambé).
Use proper pan size. Always use cookware appropiate for
the size of the surface element.
WARNING: TO REDUCE THE RISK OF INJURY. IN
THE EVENT OF A RANGE TOP GREASE FIRE,
READ THE FOLLOWING:
SMOTHER FLAMES with a close tting lid, cookie sheet, or
metal tray, then turn o the burner. BE CAREFUL TO
PREVENT BURNS. If the ames do not go out imemediately,
EVACUATE AND CALL THE FIRE DEPARTMENT.
NEVER PICK UP A FLAMING PAN - you may get burned
DO NOT USE WATER, including wet dishcloths or towels - a
violent steam explosion will result.
Use a re extinguisher ONLY if:
- You know you have a class ABC extinguisher, and you
already know how to operate it.
- The re is small and contained in the area where ir
started.
- The re department is being called.
- You can ght the re with your back to an exit.
Based on “Kitchen Fire Safety Tips” published by NFPA
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRICAL SHOCK, DO NO USE THIS FAN
WITH ANY SOLID-STATE SPEED CONTROL
DEVICE.

1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the
address or telephone number listed in the warranty.
2. Before servicing or cleaning unit, switch power o at service panel and lock the service disconnecting means to
prevent power from being switched on accidentally. When the service disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag, to the service panel.
3. Installation work and electrical wiring must be done by a qualied person(s) in accordance with all applicable codes
and standards, including re-rated construction codes and standards.
4. Sucient air is needed for proper combustion and exhausting of gases through the ue (chimney) of fuel burning
equipment to prevent backdrafting. Follow the heating equipment manufacturer’s guideline and safety standards such
as those published by the National Fire Protection Association (NFPA), and the American Society for Heating,
Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
6. Ducted fans must always be vented to the outdoors.
7. Acceptable for use over a tub or shower when connected to a GFCI (Ground Fault Circuit Interrupter) - protected
branch circuit (ceiling installation only).
8. This unit must be grounded.
1. For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors.
2. This product can be installed in a wall if mounted 8-ft. or more above the oor.
3. To avoid motor bearing damage and noisy and/or unbalanced impellers, keep drywall spray, construction dust, etc. o
power unit.
4. Please read specication label on product for further information and requirements.
CAUTION
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
INJURY TO PERSONS, OBSERVE THE FOLLOWING:

INSTALLATION GUIDE AND USER MANUAL
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
TOOLS & PARTS
REQUIRED FOR
INSTALLATION
LOCATION REQUIREMENTS
CONTENT OF
THE BOX
Electrical drill or ratchet driver
1/2” drill bit for drilling pilot holes
1 1/4” drill bit for drilling electrical wiring access hole
Screwdriver: Phillips & Straight blade
Pliers
Tape Measure or ruler + pencil
Electrical supplies for wiring
Aluminium foil tape and/or HVAC tape
Hammer
Jigsaw or saber saw
Stud nder
Observe all governing codes and local ordinances. Have a qualied technician install the range hood. It is the installer´s
responsibility to comply with installation clearences specied on the model serial rating plate.
Canopy hood´s location should be away from strong draft areas, such as windows, doors, and strong heating vents.
Recommended heights are shown. Given dimensions provide minimum cleareance.
Body (Main Unit): 1 pc
Installation Manual: 1 pc
Metal Grease Filter: 1-4 pcs
Hardware: 1 set

Range hoods must be ventilated to the outdoors, except for non-vented (recirculating) installations.
Do not ventilate the range hood into an arric or other encloed areas.
Do not use 4” (10.2 cm) laundry-type wall caps.
The length of the range hood exhaust and the number of elbows should be kept to a minimum to provde maximum
performance.
Use no more than three 90° elbows.
Make sure there is a minimum of 24”(61 cm) of straight duct between the elbows if more than one elbow is used.
Do not install two elbows together.
Use clamps to seal all joints in the vent system.
The vent system must have a damper. If the roof or wall cap has a damper, do not use the damper supplied with the
range hood.
Use caulking to seal exterior walls or roof openings around the cap.
The size of the vents should be uniform
VENTILATION REQUIREMENTS
Local building codes may require the use of makeup air systems, when using ventilation systems greater than specied
CFM of air movements in your area.
MAKEUP AIR
An additional back draft damper should be installed to minimize backward cold air ow. A thermal break should be
installed to minimize conduction of outside temperatures as part of the vent system. The damper should be on the cold
air side of the thermal break. The break should be as close as possible to where the vent system enters the heated portion
of the house.
COLD WEATHER INSTALLATIONS
This canopy hood is factory set for through the roof wall. A 6” (15.2 cm) round vent system is needed for installation.
The hood exhaust opening is 6” (15.2 cm ) round. To vent through a wall, a 90° elbow is needed. If exhaust ducting with
a diameter of less than 5.91” (150 mm) or if at ducting is used, the noise level of the range hood will increase and
extraction will be less ecient.
VENTING METHOD
A 90° elbow may be installed immediately above the hood.
REAR DISCHARGE

INSTALLATION GUIDE AND USER MANUAL
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
ELECTRICAL REQUIREMENTS & SPECIFICATIONS
IMPORTANT: Observe all governing codes and ordinances.
It is the customer’s responsibility to contact a qualied electrical installer.
A 120 Volt, 60 Hz, AC only, fused electrical supply is required on a 15-amp circuit.
DO NOT have a fuse in the neutral or ground circuit.
The 3-prong outlet should be grounded. If the power cord plug is not used, the power cord’s green wire should be
connected to ground.
Check with a qualied electrician if you are not sure that the range hood is properly grounded.
DO NOT ground to a gas pipe.
The range hood must be connected with copper wire/plug only.
The range hood should be connected directly to the fused disconnect (or circuit breaker) box through exible armored
or non-metallic sheathed copper cable. ETL listed strain relief must be provided at each end of the power supply cable.
ITEM Unit Parameter
Rated Voltage V 110
Rated Frequency Hz 50
Motor Power W 50
Lamp Power W ≤2x1.5
Air Pressure Pa >160
Noise Level dB(A) <67
Air Output Diameter mm 150

ATTENTION HOMEOWNER
These installation steps are meant to be a general guideline for mounting and installing your under cabinet range hood.
If you require assistance, please contact your local contractor.
Please exercise extreme caution when handling a range hood to prevent risk of injury and electric shock.
Building codes will vary. It is the buyer or contractor’s responsibility to know local county or state regulations before
installation of this range hood.
PREPARATIONS:
NOTE: To avoid damage to your hood, prevent debris from entering the vent opening
Decide the location of the venting pipe from the hood to the outside. Please see“Venting Method” section.
A straight, short vent will allow the hood to perform more eciently.
Try to avoid as many transitions, elbows, and long run as possible. This may reduce the performance of the hood.
IMPORTANT: Peel white or blue plastic protective lm o the hood.
Use HVAC foil tape / duct tape to seal joints between the pipe sections.
For installing under cabinets with a recessed bottom, attach 4-inch wide wood ller strips (not provided) on each side.
Refer to Figure 1.
Using references in measurements and diagrams provided, create an opening for electrical wires and hood exhaust
under the cabinet
CAUTION: If moving the cooking range is necessary to install the hood, rst turn o the power.
Always turn o the gas before moving a gas range.
Puncture the knockout holes (for mounting under the cabinet) on the hood as shown in Figure 2.
If necessary, attach two rubber panels with adhesive tape to the rear corners of the range hood.
This will help reduce vibrations and shaking when in operation.

Proceed if you would like to mount this range hood using the provided hood mounting bracket (If included).
1. Using references in the Location Requirements section, mark the leveling point of the hood. Position two mounting
screws on the wall, leaving 1/8” space away from the wall. Mounting the hood on wall studs is highly recommended.
2. Attach the hood mounting bracket to the back of the hood with four screws as shown in Figure 3.
3. Puncture the knockout wire access hole at the back of the hood and draw the electrical wires.
4. Align hood-mounting brackets to the screws on the wall and hook the hood into place as shown on the next page.
5. Tighten screws to secure hood to the wall.
CAUTION: Make certain the range hood is fully secured before releasing!
INSTALLATION GUIDE AND USER MANUAL
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
ATTENTION HOMEOWNER
STEP 1 | METHOD A
Two people will be required to lift and install the main unit. We highly recommend professional help and an extra set of
hands.
Measure the distance between the stove top and the bottom of the range hood. A distance of 24” to 32” is
recommended.
There are two methods (A or B) to mount the range hood, choose the one that better ts your setup and model.
Proceed if you would like to mount this range hood without using the hood mounting bracket.
1. Using references in the Location Requirements section, center the hood beneath the cabinet and ush with the front
of the cabinet.
2. Draw the electrical wires through the cabinet access opening if not done so already.
3. From inside of the hood, place screws into the exact center of each knockout hole and secure to cabinet bottom. Finish
tightening all screws until secure. Be careful when using electrical screwdrivers, they may cause damage to the range
hood.
Skip Method B below and proceed to step 2.
CAUTION: Make certain the range hood is fully secured before releasing!
STEP 1 | METHOD B
