Kupo DIGI-FAN DF-500 Quick start guide

Contacting Information
If you have any product-related questions, you are
welcome to contact us via the following
methods:
Please make a call to our Line during our business
hour Monday-Friday (9:00am-6:00pm)
TEL: [phone]
Or, you can visit Kupo's official website at the
following URL: www.stage.com.tw
Or, you can send email to our official address:
[email protected]
To obtain more product-related information
please do not hesitate to contact : KUPO CO.,LTD
HEAD OFFICE- TAIPEI
6F NO.4, LANE 609, SEC.5,
CHUNG SHIN RD.,
SAN CHUNG, TAIPEI, TAIWAN
TEL: [phone]
FAX: [phone]
E-MAIL: [email protected]
Introduction
Specification
Installation
Operation
Safety Information
Maintenance
Troubleshooting
1.
Contents
***************************************************
***************************************************
BRANCH OFFICE- SHANGHAI
Room 302, Tower 3, No. 86,
Jiang Chang 3 Rd,Zha Bei
District, Shanghai, China
Zip code : 200436
TEL : [phone]
FAX : [phone]
E-MALL : [email protected]

Introduction
2.
DigiFan DF-500 features DMX as standard with XLR5
pin connector and with wide range power input for
100-120V & 220-240V. The remote controlled box
including: DMX setting, 9 programs memory setting,
volume control and turbo.
The fan housing is contructed from a molded light-
weight plastic venting device with rugged tubular
steel surrounded for transport and protection. The
11" one piece blade and spiral front grill for
creating focus wind effect. It can be sitting on
floor by its own floor stand or rigging through the
TVMP(stud)in the center of the bracket.
Feature:
1. sending smoke and haze over long distance
2. creating a fantastic wind effect
3. blowing bubbles, confetti and snow
4. cooling performer
5. excellent ventilation
Technical Information:
1. Motor: 500W Max. 3500RPM
2. Power: 100-120V & 200-240V, AC 50-60Hz
3. DMX Mode: DMX on-off & volume control
4. Memory: 9 mode memeory setting available
5. One Touch Turbo Function: 0-3500RPM within 5sec.
6. Air Volume: 1700CBM/HR
7. Wind Speed: 60KM/HR
8. Remote Controller: supplied w/3M standard cable
***************************************************
***************************************************

Specification
3.
***************************************************
***************************************************
Front Figure.
blade
DMX controller box
power supply box
bracket
body
cover
motor
Back Figure.
Rear Panel Close-Up
fuse
10A/250V
knob
knob
switch
F
ront F
ig
ure
.
b
lad
e
D
MX
co
n
t
r
olle
r
bo
x
su
pp
ly
box
co
v
e
r
motor
b
r
ac
k
et
b
od
y
B
ack F
ig
ure.
R
e
a
k
no
b
k
n
ob
s
w
i
t
c
controller bracket

4.
***************************************************
***************************************************
Dimension & Speed Chart
motor speed wind speed
Dimension: 480(W) x 560(H) x 460(T) mm
Weight: 12.5kg

Installation
5.
***************************************************
***************************************************
DF-500 DigiFan may be suspended from a suitable
spport such as a truss, sitting on strong support
such as stand, or standing alone by its steel bracket.
Suspending from a Support
Block access below the work area and work from a
stable platform when installing, servicing or
removing the machines.
Always use a secure secondary attachment that can
hold at least 10 times the weight of the machine.
Rigging clamps are available as accessories from
KUPO Co.,Ltd.
Rigging clamps:
(a) KCP-836 stud coupler, which is incorporate a
16mm(5/8") stud
(b) KCP-844 TV coupler, which is with a 28mm TV
spigot or 16mm baby stud to horizontal or
vertical pipes
(c) KCP-100 TV clamp, which is with 29mm ( 1-1/8")
socket
(d) KCP-703 stage clamp, which is with 16mm stud
1. Verify that any structure used to supported the
machine can supported at least 10 times the total
weight of all installed fixtures, clamps, auxilary
equipment, etc.

6.
***************************************************
***************************************************
2. Check that all rigging clamps are undamaged and
can support at least 10 times the machine's weight
3. Clamp the fan to a truss or similar support
4. Loosen the swivel locks and tilt the fan to the
desired angle. Turn the swivel locks clockwise to
tighten. Check that fan, hardware and safety
attachment are secure before applying power
Sitting on a Supporting
Using a stand as a supporting for the Fan is more in
Grip Industry.
Stands supporting Fan to stand alone must be composed
by strong legs, and can afford the weight of the Fan.
(weight of the fan is 12.5kg, so the supporting
weight of the stand must be higher than 12.5kg) The
stand would be available to have from KUPO Co.,Ltd.
Stands:
(a) 310M Low Mighty Stand (supporting weight:35kg)
(b) 350 Runway Base Stand (supporting wieght:70kg)
Both of the above would need an adaptor to meet the
16mm hole of the fan to put on the stand.
Recommend adaptor: KUPO KS-200 adaptor 28mm/16mm stud

Master & Slave Installation
7.
***************************************************
***************************************************
Connect the DMX-output of the master fixture in the
data-chain with the DMX-input of the first salve.
Always connect output with the input of the next slave
until all slaves are connected (up to 9 devices).
Caution:
It is necessary to insert the XLR termination plug
(with 120 Ohm) into the input of the master device and
into the output of the last slave device in the link in
order to ensure proper transmission on the data link.

Operation-DMX Controller Box
8.
***************************************************
***************************************************
XLR 3 pin male coonector
for DIGIFAN Power Driver
DMX 512
input &
output
XLR 5 pin
connector
LED Display:
1. Fan Level Display
2. DMX 512 Address
binary digit display
3. Program Select Display
4. Setting Function Select Display
Slider Control:
1. Fan Speed Level
2. Edit Program
3. Run Program Timing
Select
the
Mode
by these
4 option
A. Function Mode: DMX512,
Program, Manual Slider
B. Setting Mode: DMX Address,
Program Edit, Erase All
input output
Local or
DMX Switch

9.
***************************************************
***************************************************
(b) Program mode
-9 control programs: program 1-5 is build-in
program that is fix, program 6-9 could be edited
that is variable under the program mode, the fan
speed can be set and it is under automatically
repeat mode
-press or and then "Enter" key to carry out,
or you can use manual "Slider" control to carry
out the speed you select(the green LED will be
on showing change the next step)
-fan speed = 0 when non-selection
(program mode
"program 1-5")
menu
full speed
(program mode
"program 6-9")
full speed menu
(DMX512 mode)
A. Function Mode
- press "Menu" key to select "DMX512", "Program",or
"Slider" mode as a control system
- press "Enter" key to move forward to the mode you
select
(a) DMX512 mode
-control the signal by DMX512 console
-set the DMX512 channel address at "setting" mode
-press "Full Speed" key for full speed
-has 512 DMX control channel levels (0:fan speed
zero, 1-512: 1-100% fan speed)

10.
***************************************************
***************************************************
B. Setting Mode
- press "Menu" key to select "Setting" mode and then
press "Enter" key to carry out
- press or key to select "DMX Address", "Pro.Edit"
or "Erase All" mode and then press "Enter" key to
get into the mode you select
(a) DMX Address Setting mode
-when you enter this mode, it will show out the
previous DMX512 Address setting
-display 2 digit, if LEDs are all on means the
#512 channel
-LED ON +1 = DMX512 Address Channel
(For Example: Address9=2 +1)see above figure
press "Enter" key to input the latest DMX
Address Channel, and press "Menu" key to give up
the editing
(b) Program Edit Setting mode
-press or to input the program you would like
n
3
menu
full speed full speed menu
(setting mode
"DMX Address") ("DMX Address9")
menu
full speed
(slider mode)
(c) Slider mode
-use manual "slider" to control fan speed
- press "full speed" key for 100% Fan speed

11.
***************************************************
***************************************************
to select (only at program 6-9, because program
1-5 is built-in as pre-set is fixed)
-press "Enter" key, you would be enter into
setting mode (at this moment, the pre-set memory
would be erased)
-use manual "Slider" key to record the first step
slider level, but you would have to
-press "Enter" key everytime you input a speed
signal (if you did not press "Enter" key, the
segment could not be memorized)
-up to 124 steps could be record
-after all the steps are recorded, you would have
to press the "Menu" key to leave the mode
(c) Erase All Setting mode
-select "Erase All" then press "Enter" key to
erase out program 6-9
menu
full speed
menu
full speed
(setting mode
"program edit") (setting mode
"erase all")

Fan Operation
12.
***************************************************
***************************************************
Using Fan with Smoke Machine:
When using a fan in combination with a smoke machine,
fog machine or hazer place the fan behind or beside
the machine as illustrated below ( photo A & B).
Do not place the fan in front of the fog machine
(Photo C) and direct the output from the fog machine
into the fan, as this will cause undesirable residue
build-up and the fan blades will degrade the quality
of the smoke.
Photo A:
Correct
Photo B:
Correct
Photo C:
Incorrect

Safety Information
13.
***************************************************
***************************************************
DF-500 is not for household use. It presents risks of
lethal or servere injuiry due to electric shock,
falls and fast moving blades.
To reduce the risk of fire or electric shock, do not
use this fan with any solid-state speed control
device.
Read this manual before powering or installing the
fan, follow the safety precautions listed below and
observe all warnings in this manual and printed on
the machine. If you have any question about how to
operate the machine safely, please contact a Kupo for
assistance.
Preventing a Electric Shocks
1. Always ground (earth) the machine electrically
2. Disconnect the machine from power before removing
any components or servicing, and when not in use
3. Moisture can cause dangerous electrical faults. Do
not aim fog output at electrical connections or
devices
4. Do not expose this machine to wet conditions- the
machine is not waterproof
5. Do not spill fluid over the machine. If fluid is
spilled, disconnect the machine from power and
clean with a damp cloth. If fluid is spilled onto
electric parts, contact KUPO Co.,Ltd
6. Do not dismantle or attempt to repair a faulty
machine. Refer all service to KUPO Co.,Ltd

14.
***************************************************
***************************************************
7. Do not operate the machine if the power cable or
connector is damaged. A damaged cable or connector
must be replaced with a new item, available from
KUPO Co.,Ltd
8. Do not operate the machine with damaged, deformed
or missing parts
Preventing Injuries
1. Never allow any object or part of your body to
enter the path of the fan blades, and ensure that
clothing, cables or other items cannot be sucked
into the fan
2. Disconnect the fan from power before removing any
cover or grill. Do not operate the fan unless all
covers and grills are installed and securely
fastened
3. Ensure that the supporting structure or surface
can hold at least 10 times the weight of all
installed device
4. Use an approval means of secondary attachment such
as a safety cable
Unpacking
DF-500 DigiFan is supplied with:
1. power supply box
2. power cable 3M
3. user manual
4. DMX controller box
5. steel bracket
6. a bag of knob
7. Fan

Maintenance
15.
***************************************************
***************************************************
Any service procedure not described here should be
referred to a qualified technician.
Disconnect the fan from power before removing anything.
Cleaning
Clean the outside of the fan with a damp cloth only.
Do not use solvents.
Periodic cleaning of the fan blades and grills is
necessary to maintain peak performance. Cleaning
intervals will depend on the operating environment.
Inspect the fan regularly for dust and smoke residue
buildup, and clean as soon as there is significant
dirt buildup on fan blades or at the first signs that
airflow through grills maybe restricted.Use a soft
brush and vacuum to clean grills and fan blades.
Cleaning Steps
1. Disconnect the fan from power.
2. Remove the four cross-head screws and lift the grill.
3. Clean the housing and blade.
4. After cleaning, replace the grill and screws,
ensuring that screws are securely tightened.
Replacing the Fuse
The main fuse can be replaced by the user if necessary.
An indication that the main fuse may have blown is that
the power LED does not light when the power is applied.
Never bypass the fuse or replace it with one of another
size of rating. To replace the main fuse:
1. Disconnect the power cable from the fan.
2. Screw off the main fuse holder.
3. Replace the fuse with one of the same rating and
type. 250V,10A vfuse.
4. Replace the fuse holder and reconnect to power.
If the fuse blows repeatedly, disconnect the machine
from power and contact your dealer for service.

16.
***************************************************
***************************************************
Problem Probable causes Suggested remedy
No light from status LEDs on
DMX control box or fan
No power Check power supply and
connection
DMX control box not connect
well
Check connection both
outside 3pin XLR and inside
connection (showed photo 1-1
& 1-2 )
Fuse blown Disconnect the power and
replace fuse with one of same
type and rating(showed photo
2 )
Power is applied, but no fan
action using DMX
Incorrect DMX address Go setting mode erase all
then re-set DMX address
No DMX termination Fit termination plug to last
device on DMX link
Excessively noisy operation Front grill loose Disconnect the power and
tighten grill retaining
screws(showed photo 3)
Motor holder loose Disconnect the power and take
off front grill then tighten
4 screws which hold the
motor(showed photo 4)
Reduced airflow Grills and/or fan blade are
dirty
Check and clean
Low supply voltage Check AC supply
Fan automatically shut off
and get back working after a
while
The power supply working
temperature is too high
Disconnect the power and
check your local dealer for
further advice
Troubleshotting

Photos illustrate
17.
***************************************************
***************************************************
Photo 1-1 Photo 1-2
Photo 2 Photo 3
Photo 4 Photo 5
Note:
If that is necessary to take out the power supply
box. It is simple just unscrew the 4 screws on rear
tubing then pull out the power supply box. (Photo 5)

Accessory Photos
18.
***************************************************
***************************************************
350 Runway
Base STand
310M Low
Mighty Stand
KCP-703 clamp KCP-836 clamp
KCP-100B black
KCP-100S silver KCP-844 clamp
KS-200 adaptor
28mm/16mm stud

w
w
w
.
s
t
a
g
e
.
c
o
m
.
t
w
w
w
w
.
s
t
a
g
e
.
c
o
m
.
t
w
TAIPEI OFFICE
6F. NO.4, LANE 609, SEC.5,
CHUNG-SHIN RD., SAN CHUNG,
TAIPEI, TAIWAN
TEL: [phone]
FAX: [phone]
WWW.STAGE.COM.TW
[email protected]
