Kuppersberg GLA 689 Installation and maintenance instructions

TECHNICAL PASSPORT
ПАСПОРТ ТЕХНИЧЕСКОГО ИЗДЕЛИЯ
GLA 689,GLF 689
DISHWASHERS
ПОСУДОМОЕЧНЫЕ МАШИНЫ

2
TECHNICAL PASSPORT ENGLISH
Dishwasher
1. DISHWASHER......................................................................................................................... 3
2 IMPORTANT SAFETY INSTRUCTIONS ...................................................................... 4
3. INSTALLATION...................................................................................................................... 5
4. PREWASHING......................................................................................................................... 9
5. PROGRAM SELECTION AND OPERATING YOUR MACHINE.......................... 25
6. MAINTENANCE AND CLEANING.................................................................................. 31
7. TROUBLESHOOTING .......................................................................................................... 33
CONTENTS

3
ENGLISH TECHNICAL PASSPORT
Dishwasher
PLEASE READ THIS USER
MANUAL FIRST!
Dear Customer,
We hope that you get the best
results from the product which has
been manufactured in state-of-the-
art plants and passed through a strict
quality control procedure.
Therefore, please read the entire
user manual carefully before using
the product and keep it as a reference
for future use. In case of transferring
the product to someone else, give the
manual as well.
The user manual will help you
use your product in a fast and
safe way.
ÂRead the user manual before
installing and starting your product.
ÂAlways follow the safety
instructions.
ÂKeep this user manual within
easy reach for future reference.
ÂRead also the other documents
supplied with the product.
Explanation of symbols
Throughout this User Manual the
following symbols are used:
Important information or
useful hints about usage
Warning for hazardous
situations with regard to life and
property
Warning for electric shock
1. Upper basket with rack
2. Upper impeller
3. Lower impeller
4. Filters
5. Lower basket
6. Control panel
7. Door
8. Detergent dispenser
9. Silverware basket
10. Lower impeller slot
11. Salt reservoir lid
12. Upper basket rail
13. Ceiling silverware basket
14. Tabletop (depends on the model)
15. Ceiling impeller
16. Fan drying system (depends on the
model)
1. DISHWASHER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

4
TECHNICAL PASSPORT ENGLISH
Dishwasher

This product complies with the
following EU directives:
Development, production and sales
stages of this product comply with the
safety rules included in all pertaining
European Community regulations.
2006/95/EC, 2004/108/EC, 93/68/
EEC, IEC 60436, EN 50242
Power input 220-240 V, 50 Hz
Total power
consumption 1900-2200 W
Heater power
consumption 1800 W
Total current
(depends on the
model)
10 A (see type plate)
Drain pump power
consumption 30 W
Water pressure 0.3 –10 bar (= 3 – 100 N/
cm² = 0.01-1.0 Mpa)
Technical speci cations may be
changed without prior notice to improve
the quality of the product.
Figures in this manual are schematic
and may not match the product exactly.
Values stated on the product labels
or in the documentation accompanying
it are obtained in laboratory conditions
in accordance with the relevant
standards. Depending on operational
and environmental conditions of the
product, these values may vary.
Note for test institutions:
Data required for performance
tests shall be provided upon request.
Requests can be e-mailed to the
following address:
[email protected]
Do not forget to provide the code,
stock and serial numbers of the product
to be tested in your request e-mail along
with your contact information. Code,
stock and serial numbers of the product
is located on the type label attached to
the side of the door.
2 IMPORTANT SAFETY
INSTRUCTIONS
This section contains safety
instructions that will help to get
protected from risk of personal injury or
property damage Failure to follow these
instructions shall void all warranties.
General safety
ÂNever place the product on a
carpet-covered  oor; otherwise, lack of
air ow beneath the product will cause
electrical parts to overheat. This will
cause problems with your product.
ÂDo not operate the product if
the power cable / plug is damaged!
Call the Authorised Service Agent.
ÂConnecttheproducttoa grounded
outlet protected by a fuse complying
with the values in the “Technical
speci cations” table. Do not neglect
to have the grounding installation
made by a quali ed electrician.
Manufacturer shall not be liable for
any damages that will arise when the
product is used without grounding in
accordance with the local regulations.
ÂThe water supply and draining
hoses must be securely fastened and
remain undamaged.
ÂUnplug the product when not in
use.
ÂNever wash the product by
spreading or pouring water onto it!
There is the risk of electric shock!

5
ENGLISH TECHNICAL PASSPORT
Dishwasher
ÂNever touch the plug with wet
hands! Never unplug by pulling on the
cable, always pull out by grabbing the
plug.
ÂThe product must be unplugged
during installation, maintenance,
cleaning and repairing procedures.
ÂAlways have the installation and
repairing procedures carried out by the
Authorised Service Agent. Manufacturer
shall not be held liable for damages that
may arise from procedures carried out by
unauthorised persons.
ÂNever use chemical solvents
in the product. They bring forth risk of
explosion.
ÂWhen you pull the upper and
lower baskets out completely, the door
of the product will bear all the weight
of the baskets. Do not put other loads on
the door; otherwise, the product may tilt.
ÂNever leave the door of the
product open apart from loading and
unloading procedures.
ÂDo not to open the door of
the product when it is running unless
necessary. Be careful for the rush of hot
steam when you need to open the door.
Intended use
ÂThis product has been designed
for domestic use.
ÂIt must be used to do the
domestic type dishes only.
ÂOnly dishwasher safe detergents,
rinse aids and additives must be used.
ÂThe manufacturer waives any
responsibility arisen from incorrect
usage or transportation.
ÂThe service life of your product
is 10 years. During this period, original
spare parts will be available to operate
the appliance properly.
ÂThis productshould not be usedby
persons with physical, sensory or mental
disorders or unlearned or inexperienced
people (including children) unless they
are attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of the
product.
CHILDREN’S SAFETY
Electrical products are dangerous for
the children. Keep children away from
the product when it is in use. Do not let
them to tamper with the product.
ÂDo not forget to close the door
of the product when leaving the room
where it is located.
ÂStore all detergents and additives
in a safe place away from the reach of
the children.
3. INSTALLATION
Refer to the nearest Authorised
Service Agent for installation of your
product. To make the product ready
for use, make sure that the electricity,
tap water supply and water drainage
systems are appropriate before calling
the Authorised Service Agent. If they
are not, call a quali ed technician
and plumber to have any necessary
arrangements carried out.
Preparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer’s responsibility.
Installation and electrical
connections must be carried out by the

6
TECHNICAL PASSPORT ENGLISH
Dishwasher
Authorised Service Agent. Manufacturer
shall not be held liable for damages
that may arise from procedures carried
out by unauthorised persons.
Prior to installation, visually check if
the product has any defects on it. If so,
do not have it installed.
Damaged products cause risks for
your safety.
Make sure that the water inlet and
discharge hoses are not folded, pinched
or crushed while pushing the product
into its place after installation or
cleaning procedures.
When placing the product, pay
attention not to damage the oor, walls,
piping, etc. Do not hold the product
from its door or panel to move it.
Appropriate installation
location
ÂPlace the product on a solid
and at oor that has sufcient load
carrying capacity! The product must be
installed on a at surface in order for
the door to be closed comfortably and
securely.
ÂDo not install the product at
places where temperature may fall
below 0ºC.
ÂPlace the product at least 1 cm
Âaway from the edges of other
furniture.
ÂPlace the product on a rigid
oor. Do not place it on a long pile rug
or similar surfaces.
Do not place the product on the
power cable.
ÂMake sure that you select a
location that will allow you to load
and unload the dishes in a fast and
comfortable manner.
ÂInstall the product in a place
close to the tap and the drain hole.
Select the installation location by
considering that it will not be changed
after the connections are made.
Connecting water supply
We recommend attaching a lter on
the house/apartment supply water inlet
to protect the machine from damages
that may arise from impurities (sand,
dirt, rust, etc.) coming from the urban
water supply system or from your own
water system as well as to prevent
complaints such as yellowing or sludge
accumulation at the end of washing.
Permitted water temperature:
up to 25°C
The dishwasher may not be
connected to open warm water devices
or ow- through water heaters.
ÂDo not use old or used water
inlet hose on the new product. Use the
new water inlet hose supplied with the
product.
ÂConnect the water inlet hose
directly to the water tap. Pressure
coming from the tap should be
minimum 0.3 and maximum 10 bars. If
the water pressure exceeds 10 bars, a
pressure relief valve should be installed
in between.
Use a screw-on hose connector to
connect the water inlet hose to a water
tap with a ¾ inch external thread. If
required, use a lter insert to lter
deposits from the pipes.

7
ENGLISH TECHNICAL PASSPORT
Dishwasher
ÂOpen the taps completely after
making the connections to check for
water leaks.
For your safety, close the water
inlet tap completely after the washing
programme is over.
Connection to the drain
Water discharge hose can directly
be connected to the drain hole or sink’s
drainage. The length of this connection
must be min. 50 cm and max. 100 cm
from the  oor.
A discharge hose longer than 4
meters causes dirty washing.
Attach the water discharge hose
to the drainpipe without bending it.
Tightly  x the water discharge hose to
the drainpipe in order to prevent any
dislocation of the water discharge hose
during operation of the product.
Drainpipe must be connected to the
sewage system and it should not be
connected to any surface water.
Adjusting the feet
If the door of the product cannot be
closed properly or if the product swings
when you push it slightly, then you need
to adjust the feet of the product. Adjust
the feet of the product as illustrated in
the installation manual supplied with
the product.
Aquasafe+
(depends on the model)
Protect the Aquasafe+ system against
water leaks that may occur at hose inlet.
Water contact with the valve box of the
system must be prevented. Otherwise,
electrical assembly will get damaged. If
the Aquasafe system is damaged, unplug
the product and call the Authorised
Service Agent.
As the hose set contains electrical
connections and assemblies, never
shorten or lengthen the hose with
extension hoses.

8
TECHNICAL PASSPORT ENGLISH
Dishwasher
initial use,  ll the salt reservoir with 1
litre of water prior to  lling it with salt.
Some water might have remained in
the product due to the quality control
processes in the production. It is not
harmful for the product.
Disposing of packaging
material
Packaging materials are dangerous
to children. Keep packaging materials
in a safe place away from reach of the
children.
Packaging materials of the product
are manufactured from recyclable
materials. Dispose of them properly and
sort in accordance with recycled waste
instructions. Do not dispose of them
with normal domestic waste.
Transportation of the product
If you need to move the product,
do it in upright position and hold from
the rear side. Slanting the product onto
its front side may cause the electronic
parts in it get wet and damaged.
1. Unplug the product before
transporting it.
2. Remove water drainage and water
supply connections.
3. Drain the remaining water in the
product completely.
Disposing of the old product
Electrical connection
Connect the product to a grounded
outlet protected by a fuse complying
with the values in the “Technical
speci cations” table. Manufacturer shall
not be liable for any damages that will
arise when the product is used without
grounding in accordance with the local
regulations.
ÂConnection must comply with
national regulations.
ÂPower cable plug must be within
easy reach after installation.
Unplug the product after the washing
programme is over.
ÂThe voltage and allowed fuse or
breaker protection are speci ed in the
“Technical speci cations” section. If the
current value of the fuse or breaker in
the house is less than 16 Amps, have
a quali ed electrician install a 16 Amp
fuse.
 The speci ed voltage must be
equal to your mains voltage.
ÂDo not make connections via
extension cables or multi-plugs.
Damaged power cables must be
replaced by the Authorised Service Agent.
If the product has a failure, it should
not be operated unless it is repaired by
the Authorised Service Agent! There is
the risk of electric shock!
Initial use
Before starting to use the product,
make sure that all preparations are made
in accordance with the instructions in
sections “Important safety instructions”
and “Installation”.
ÂTo prepare the product to do the
dishes, perform  rst operation in the
shortest programme with detergent
while the machine is empty. During the

9
ENGLISH TECHNICAL PASSPORT
Dishwasher
4. PREWASHING
Tips for energy saving Following information will help you use the product in an
ecological and energy-ef cient manner.
ÂWipe away any coarse food remnants on the dishes before putting them in
the product.
 Operate the product after  lling it completely.
ÂWhen selecting a programme, refer to the «Programme Table».
ÂDo not put more detergent than suggested on the detergent package.
Technical drawings
Dispose of the old product in an environmentally friendly manner. Some parts
of the product are manufactured from recyclable materials. Along with a recycling
symbol, information about its nature (PE, PS, POM, etc) is also provided on the
material. These materials should not be disposed as normal domestic wastes.
Refer to your local dealer or solid waste collection centre in your area to learn
how to dispose of your product.
For children’s safety, cut the power cable and break the locking mechanism of
the door so that it will be non-functional before disposing of the product.

10
TECHNICAL PASSPORT ENGLISH
Dishwasher
Water softening system
The dishwasher requires soft water. If the hardness of the water is above 6°dH,
the water must be softened and descaled. Otherwise, ions that create the hardness
will accumulate on the surfaces of the dishes and may adversely affect the washing,
shining and drying performances of the product.
The product is equipped with a water softening system which reduces the
hardness of incoming water. This system softens the supply water that enters into
the product to a level that will allow washing the dishes with the required quality.
Adjusting the water softening system
Washing performance will increase when water softening system is adjusted
properly.
Use the test stripe supplied with the product to determine the supply water
hardness in order to adjust the system.
ÂPress and hold the Program Selection Key when the machine is off and press
On/Off button simulta-neouslyto turn on your machine.Release the Program Selection
Key when the water hardness level stored on your machine is displayed in “r…..” format.
 Start / Stop icon will start  ashing as soon as the water hardness level stored
on your machine is displayed in “r…..” format.
ÂSelect the water hardness level suitable to your machine from the Water
Hardness Level Adjustment Table by pressing the Delayed Start Key.
ÂPress «Start/Pause/Cancel» key for once to store the level you have selected.
ÂStart / Stop icon will light continuously when the new water hardness level is
stored.
ÂPress the On/Off button to turn off your machine.
Water Hardness & Regeneration Settings
Softening the water
Dishwashers require fairly soft water. If the hardness exceeds 6°dH lime scale
will form on crockery. To avoid this an automatic system adds a special salt to soften
the water so that you obtain the best possible cleaning and drying performance.
To  nd out the hardness level of your water contact your local water company,
or use the enclosed test strip to measure the water hardness:

11
ENGLISH TECHNICAL PASSPORT
Dishwasher
Water Hardness Level Adjustment Table
Hardness
Level
English
Water
Hardness
°dE
German
Water
Hardness
°dH
French
Water
Hardness
°dF*
Water Hardness Level Indicator
1st Level 0-5 0-4 0-8
Press the Delayed Start key to switch the
water hardness level to position 1.
2nd Level 6-9 5-7 9-13
3rd Level 10-15 8-12 14-22 Press the Delayed Start key to switch the
water hardness level to position 2.
4th Level 16-19 13-15 23-27 Press the Delayed Start key to switch the
water hardness level to position 3.
5th Level 20-24 16-19 28-34 Press the Delayed Start key to switch the
water hardness level to position 4.
6th Level 25-62 20-50 35-90 Press the Delayed Start key to switch the
water hardness level to position 5.
If the hardness level of the water
that you use is above 90 °dF (French
standard for water hardness) or if
you are using well water, than it is
recommended to use  lter and water
puri cation devices.
If the hardness level of the water that
you use is below 8°dF (French standard
for water hardness), there is no need to
use salt in your dishwasher. If this is the
case, “No Salt Warning Indicator” (if any)
illuminates continuously on the panel
of your machine.
If the water hardness adjustment
is set to level 1, the “No salt warning
indicator” will illuminate continu- ously
although it is not necessary to use salt.
If you use salt under this condition, salt
will not be consumed and the lamp will
not illuminate.
Warning:
If you move your house, it is very
important to make the water hardness
level adjustment of your machine
according to the new location you
move in order to preserve the washing
ef ciency.
If the water hardness level of your
machine is adjusted previously, your
machine will display the last water
hardness level adjustment. Adjust
the new water hardness level of your
machine on basis of the water hardness
level of your tap water.

12
TECHNICAL PASSPORT ENGLISH
Dishwasher
Adding salt
Water softening system needs to be
regenerated in order for the product
operates with the same performance
continuously. Dishwasher salt is used
for this purpose.
Use in your product only the special
softening salts produced particularly for
use in dishwashers.
We recommend using granular or
powder softening salts. Do not use salts
containing insoluble substances such as
table salt or common salt in the machine.
Performance of water softening system
may deteriorate in time.
Salt reservoir will  ll with water
when you start the product. Therefore,
add the softening salt before starting
the machine.
1. First take the lower basket out to
add softening salt.
2. Turn the salt reservoir lid in
counter clockwise to open it.
Before initial use,  ll the water
softening system with 1 litre of water.
3. Fill the salt reservoir with salt
by using salt funnel. To speed up
dissolution rate of salt in water,
stir it with a spoon.
You can put about 2 kg of softening
salt into the salt reservoir.
4. Replace the lid and tighten it
securely when the reservoir is full.

13
ENGLISH TECHNICAL PASSPORT
Dishwasher
5. If you will not start a washing
programme immediately after
adding the salt, run the machine
empty in the shortest programme
to dissolve and wash away the
scattered salt in the machine.
Since different salt brands in the
market have different particle sizes
and since the water hardness may vary,
dissolution of the salt in water may
take a couple of hours. Therefore, Salt
Indicator remains on for a while after
adding salt into the machine.
Detergent
You can use powder or tablet
detergent in the machine.
Only use in the machine the
detergents produced particularly for
use with dishwashers. We recommend
you not to use detergents that contain
chlorine and phosphate as they are
harmful for the environment.
Contact the detergent producer if
the dishes are wet and/or if you notice
limescale spots particularly on glasses
after the washing programme is over.
Adding detergent
Refer to the “Programme Table”
to determine the correct amount of
detergent for the selected programme.
Do not put solvents into the
detergent dispenser. There is the risk of
explosion!
Put the detergent into the detergent
dispenser just before operating the
machine as illustrated below.
1. Push the latch to right to open the
detergent dispenser lidе.
2. Put suggested amount of powder
or tablet detergent in the
dispenser.
Inside the detergent dispenser,
there are level markings that help you
use appropriate amount of detergent.
When brimful, detergent dispenser
will contain 40 cm³ of detergent. Fill
detergent up to 15 cm³ or 25 cm³
level marks in the detergent dispenser
according to fullness of the machine
and/or soiling degree of the dishes.
If dishes have been waiting for a
long time and have dried residues,  ll
the 5 cm³ compartment too.

14
TECHNICAL PASSPORT ENGLISH
Dishwasher
3. Close the detergent dispenser lid
by pressing on it lightly. A «click»
will be heard when the lid is
closed.
In programmes with prewash and
at high temperature, in which you use
tablet detergents, make sure that the
detergent dispenser lid is closed  rmly.
Use powder detergent in short
programmes without prewash since
the solubility of the tablet detergent
changes depending on the temperature
and time.
Excessive usage of powder
detergents will cause the detergent not
dissolve completely and will also cause
scratches on the glassware.
Tablet detergents
Table detergents exhibit water
softening and / or rinse aid effect in
addition to detergent effect. Some types
of these detergents also contain special-
purpose washing chemicals such as
glass and stainless steel protectors.
Tablet detergents give satisfying
results only under certain usage
conditions. The best washing
performance in dishwashers is obtained
by using detergent, rinse aid and water
softening salt individually.
Information about suitable places
(detergent dispenser, basket etc.) in the
dishwasher to place the tablet can be
found amongst the usage instructions
on the packages of the tablet detergents.
Tablet detergent types commonly
found in the market:
2 in 1: Contains detergent,
rinse aid or water softening salt
3 in 1: Contains detergent,
rinse aid and water softening salt
4 in 1: Contains glass
protectors in addition to detergent,
rinse aid and water softening salt
5 in 1: Contains glass and
stainless steel protectors in addition to
detergent, rinse aid and water softening
salt
Observe the instructions of the
detergent manufacturer on the package
when using tablet detergents.
When you switch to powder
detergent from tablet
detergent:
1. Make sure that salt and rinse aid
reservoirs are full.
2. Set the water hardness to the
highest level and perform an
empty run.
3. After the empty washing cycle,
review the user manual and
readjust the water hardness level
so as to suit the water supply.
4. Make the appropriate rinse aid
settings.

15
ENGLISH TECHNICAL PASSPORT
Dishwasher
Depending on the model, salt
indicator and/or rinse aid indicator must
be enabled again if they were disabled
before.
Rinse aid
The rinse aid used in dishwashers is
a special combination used to increase
drying ef ciency and prevent water or
limescale stains on the washed items.
For this reason, care must be paid to
have rinse aid in the rinse aid reservoir
and to use rinse aids produced specially
for dishwashers only.
Check Rinse Aid Indicator to
determine whether it is necessary to
add rinse aid or not (depends on the
model). Having a dark light on the
indicator shows that there is suf cient
amount of rinse aid in the dispenser. If
the colour of the indicator is light, add
rinse aid.
1. Open the lid of the rinse aid
reservoir by pressing its latch.
2. Fill the reservoir until “MAX” level.
3. Close the lid of the reservoir by
pressing on it lightly.
Wipe clean any spilled rinse aid
outside the reservoir. Rinse aid that
spilled accidentally will cause foaming
and it will eventually decrease washing
performance.
4. Turn the rinse aid amount
adjuster manually to a position
between 1 and 6. If there are
stains on tableware items after
washing, level must be increased
and if there is a blue trace after
wiping them by hand, it must be
decreased. This is set to position 4
as factory default.
Items not suitable for washing
in the dishwasher
ÂNever wash dishes soiled
by cigarette ash, candle remnants,
polish, dyestuff, chemicals, etc. in your
dishwasher.
ÂDo not wash iron alloy items in
the dishwasher. It can get corroded or
leave stains on other items.
ÂDo not wash silverware and
cutlery with wooden or bone stems,
glued pieces, or pieces that are not
resistant to heat, as well as copper and
tin-plated containers in the dishwasher.
Decorative prints of chinaware as
well as aluminum and silver items

16
TECHNICAL PASSPORT ENGLISH
Dishwasher
Suggestions for loading the
dishwasher
Lower basket
Upper basket
Improper Loading Of Dishware
Placing the dishes into the
dishwasher
You can use your dishwasher in the
optimum way with respect to energy
consumption and washing and drying
performance only if you place the dishes
in an orderly way.
ÂWipe away any coarse food
remnants (bones, seeds, etc.) on the
dishes before placing them in the
dishwasher.
ÂPlace thin, narrow pieces in the
middle sections of baskets if possible.
ÂThere are two separate baskets
in which you can place your dishes in
the dishwasher. Place the heavily soiled
and bigger items in the lower basket
and smaller, delicate and light items in
the upper basket.
ÂPlace the hollowed dishes such
as bowls, glasses and pans upside down
in the dishwasher. Thus, accumulation
of water in deep hollows is prevented.
To prevent possible injuries, always
place the sharp and pointed dishes such
as service fork, bread knife, etc. upside
down so as their pointed ends will face
down or they will lie horizontally on the
dish baskets.
ÂUnload dishes in the lower
basket  rst and then the dishes in the
upper basket.
may get discoloured or tarnished
after washing in the dishwasher just
as it happens in handwashing as
well. Some delicate glass types and
crystals may become dull in time. We
strongly recommend you to check if the
tableware you are going to purchase is
suitable for washing especially in the
dishwasher.

17
ENGLISH TECHNICAL PASSPORT
Dishwasher
Improper Loading Of Dishware Silverware basket
(depends on the model)
Silverware basket is designed to
wash your dishes such as fork, spoon
and etc. in a cleaner manner.
Silverware basket piece
(depends on the model)
You can place your forks, spoons and
etc. to upper basket with the additional
piece in the  gure.

18
TECHNICAL PASSPORT ENGLISH
Dishwasher
Movable silverware basket
(depends on the model)
Since the cutlery basket can be
moved, you can create a wider space
while placing your dishes to the lower
basket and free up space for your dishes
in different sizes.
Collapsable lower basket wires
(2 pieces)
(depends on the model)
The two piece foldable wires located
at the lower basket of the machine are
designed for an easier placement of
large pieces such as pans, bowls, etc. .
You can create larger spaces by
folding each wire individually or all of
them at once. Lay the foldable wires
down by pressing on the latch.

19
ENGLISH TECHNICAL PASSPORT
Dishwasher
Collapsable lower basket wires
(4 pieces)
(depends on the model)
The four piece foldable wires located
at the lower basket of the machine are
designed for an easier placement of
large pieces such as pans, bowls, etc.
You can create larger spaces by folding
each wire individually or all of them at
once. Lay the foldable wires down by
pressing on the latch.
Lower basket bottle wire
(depends on the model)
The bottle wire is designed for
easier washing of long pieces with wide
mouths. You may take out the bottle
wire from the basket when not in use by
pulling it out from both sides.
Lower basket multipurpose /
height adjustable service rack
(depends on the model)
This accessory located at the lower
basket of the machine allows you to
easily wash pieces such as extra glasses,
long ladles and bread knives.

20
TECHNICAL PASSPORT ENGLISH
Dishwasher
To close the racks:
1. Fold the rack.
2. Slide the rack up.
3. Put the rack in vertical position.
4. Slide the rack down and lock it
with the tabs.
Perform the same process in
reverse order to open the racks.
To adjust the height of the racks:
1. Fold the rack.
2. Slide the rack up.
3. Open the rack at the desired level.
Make sure that the impeller
does not touch the dishes you placed
on the racks.
Upper basket height adjustable
rack (depends on the model)
Use the lower and upper parts of
the height adjustable racks in the upper
basket of the machine by sliding them
down or up according to the heights of
the glasses, cups or etc.
Upper basket drawer
(depends on the model)
You can easily place additional
desert spoons, small forks and knives
into the basket drawer installed to the
upper basket of your machine
