Kuppersbusch EKE8342.1ED Operation manual

BEDIENUNGSANWEISUNG
mit Montageanweisungen
Instructions for use and installation
Instructions d’utilisation et d’installation
EKE8342.1ED

17
Dear customer,
Thank you for having chosen a KÜPPERSBUSCH ceramic hob
In order to install properly your appliance and to make the best use of it, please read this entire
instruction manual carefully.
SUMMARY
SAFETY .......................................................................................................................................18
P RECAUTIONS BEFORE USING ...........................................................................................................18
U SING THE APPLIANCE ....................................................................................................................18
P RECAUTIONS NOT TO DAMAGE THE APPLIANCE ......................................................................................19
P RECAUTIONS IN CASE OF APPLIANCE FAILURE .......................................................................................19
O THER PROTECTIONS .....................................................................................................................19
DESCRIPTION OF THE APPLIANCE .................................................................................................20
T ECHNICAL DATA ..........................................................................................................................20
C ONTROL PANEL ...........................................................................................................................20
USE .............................................................................................................................................20
S ENSITIVE TOUCHES ......................................................................................................................20
D ISPLAY .....................................................................................................................................20
R ESIDUAL HEAT INDICATION .............................................................................................................21
“SLIDER” ZONE : TO SET POWER AND TIMER VALUES ................................................................................21
STARTING-UP AND APPLIANCE MANAGEMENT ...............................................................................21
B EFORE USING YOUR NEW HOB .........................................................................................................21
S TARTING - UP ...............................................................................................................................21
E XTENSION ZONE ..........................................................................................................................22
T IMER .......................................................................................................................................23
« K EEP WARM » F UNCTION ..............................................................................................................23
A UTOMATIC COOKING .....................................................................................................................24
P AUSE FUNCTION ..........................................................................................................................24
R ECALL F UNCTION ........................................................................................................................25
C ONTROL PANEL LOCKING ...............................................................................................................25
O PERATING TIME ..........................................................................................................................25
COOKING ADVICES .......................................................................................................................26
E XAMPLES OF POWER SETTING .........................................................................................................26
MAINTENANCE AND CLEANING .....................................................................................................26
WHAT TO DO IN CASE OF A PROBLEM ...........................................................................................26
ENVIRONMENT PROTECTION .........................................................................................................27
INSTALLATION INSTRUCTIONS ......................................................................................................28
ELECTRICAL CONNECTION ...........................................................................................................29

18
SAFETY
Precautions before using
•Unpack all the materials.
•The installation and connecting of the appliance have to be done by approved specialists.
The manufacturer cannot be responsible for damage caused by building-in or connecting
errors.
•To be used, the appliance must be well-equipped and installed in a kitchen unit and an
adapted and approved work surface.
•This domestic appliance is exclusively for the cooking of food, to the exclusion of any
other domestic, commercial or industrial use.
•Remove all labels and self-adhesives from the ceramic glass.
•Do not change or alter the appliance.
•The cooking plate cannot be used as freestanding or as working surface.
•The appliance must be grounded and connected conforming to local standards.
•Do not use any extension cable to connect it.
•The appliance cannot be used above a dishwasher or a tumble-dryer: steam may
damage the electronic appliances.
Using the appliance
•Switch the heating zones off after using.
•Keep an eye on the cooking using grease or oils: that may quickly ignite.
•Be careful not to burn yourself while or after using the appliance.
•Make sure no cable of any fixed or moving appliance contacts with the glass or the hot
saucepan.
•Magnetically objects (credit cards, floppy disks, calculators) should not be placed near to
the engaged appliance.
•Metallic objects such as knives, forks, spoons and lids should not be placed on the hob
surface since they can get hot.
•In general do not place any metallic object except heating containers on the glass
surface. In case of untimely engaging or residual heat, this one may heat, melt or even
burn.
•Never cover the appliance with a cloth or a protection sheet. This is supposed to become
very hot and catch fire.
•This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.

19
Precautions not to damage the appliance
•Raw pan bottoms or damaged saucepans (not enamelled cast iron pots,) may damage
the ceramic glass.
•Sand or other abrasive materials may damage ceramic glass.
•Avoid dropping objects, even little ones, on the vitroceramic.
•Do not hit the edges of the glass with saucepans.
•Make sure that the ventilation of the appliance works according to the manufacturer’s
instructions.
•Do not put or leave empty saucepans on the vitroceramic hobs.
•Sugar, synthetic materials or aluminium sheets must not contact with the heating zones.
These may cause breaks or other alterations of the vitroceramic glass by cooling: switch
on the appliance and take them immediately out of the hot heating zone (be careful: do
not burn yourself).
•Never place any hot container over the control panel.
•If a drawer is situated under the embedded appliance, make sure the space between the
content of the drawer and the inferior part of the appliance is large enough (2 cm). This is
essential to guaranty a correct ventilation.
•Never put any inflammable object (ex. sprays) into the drawer situated under the
vitroceramic hob. The eventual cutlery drawers must be resistant to heat.
Precautions in case of appliance failure
•If a defect is noticed, switch off the appliance and turn off the electrical supplying.
•If the ceramic glass is cracked or fissured, you must unplug the appliance and contact
the after sales service.
•Repairing has to be done by specialists. Do not open the appliance by yourself.
•WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of
electric shock.
Other protections
•Note sure that the container pan is always centred on the cooking zone. The bottom of
the pan must have to cover as much as possible the cooking zone.
•For the users of pacemaker, the magnetic field could influence its operating. We
recommend getting information to the retailer or of the doctor.
•Do not to use aluminium or synthetic material containers: they could melt on still hot
cooking zones.

20
DESCRIPTION OF THE APPLIANCE
Technical data
Type Total power Heating zone location Power Diameter
EKE8342.1ED 7600 W
Front left
Rear left
Rear right
Front right
2200 / 1000 W
1200 W
2400 / 1500 W
1800 W
220 / 145 mm
155 mm
265x180 mm
190 mm
Control panel
USE
Sensitive touches
Your ceramic hob is equipped with electronic controls with sensitive touch keys. When your
finger touches the key, the corresponding command is activated. This activation is validated by
a control light, a letter or a number in the display and/or a “beep” sound.
Touch only one key on the same time.
Display
Display Designation Function
0 Zero the heating zone is activated
1…9 Power level Selection of the cooking level
A Heat accelerator automatic cooking
E Error message Electronic failure
H Residual heat the heating zone is hot
U Keep warm Maintain automatically of 70°C.
II Pause the hob is in pause
Control light timer
Timer Display
On / Off
Power Display
Timer
key
Extension
zone
Selection zone
key
Power selection zone
“Slider” and timer
setting zone

21
Residual heat indication
After the switch-off of the hob, the heating zone is still hot and indicates [ H ] on the display.
The symbol [ H ] disappears when the heating zone may be touched safely.
When the residual heat indicator light is on, don’t touch the heating zone and don’t put any heat
sensitive object on them. There are risks of burn and fire!
“SLIDER” zone: to set power and timer values
Select the cooking zone. The display corresponding to the selected zone will be highlighted.
While the zone is activated (for a few seconds), you can adjust the power, either by sliding your
finger on the slider, or by direct access.
To adjust the power of another cooking zone, wait until the previous zone is no longer activated
(the highlighted display becomes normal).
STARTING-UP AND APPLIANCE MANAGEMENT
Before using your new hob
Clean your hob with a damp cloth, and then dry the surface thoroughly. Do not use detergent
which risks causing blue-tinted colour on the glass surface.
Starting-up
•Start-up/ switch off the hob
Action Control panel Display
To start press the key [ ] [ 0 ]
To stop press the key [ ] nothing or [ H ]
“slide“ “press“

22
•Start-up/ switch off a heating zone
Action Control panel Display
Zone selection Press on the “SLIDER“
across from the desired zone [ 0 ]
Select the power level Slide on the “SLIDER“ [ 1 ] to [ 9 ]
To stop Slide to [ 0 ] on “SLIDER“ [ 0 ] or [ H ]
or press on [ 0 ] [ 0 ] or [ H ]
If no action is made within 20 second the electronics returns in waiting position.
Extension zone
Action Control panel Display
Zone selection Press on the “SLIDER“
across from the desired zone [ 0 ]
Select the power level Slide on the “SLIDER“ [ 1 ] to [ 9 ]
Switch on the extension zone press key [ ] Extension zone
light is on
Select the power level Slide on the “SLIDER“ [ 1 ] to [ 9 ]
Switch off the extension zone press key [ ] Extension zone
light is off

23
Timer
The timer is able to be used simultaneous with all heating zones and this with different time
settings (from 1 to 99 minutes) for each heating zone.
•Setting and modification of the cooking time :
Action Control panel Display
Zone selection Press on the “SLIDER“
across from the desired zone [ 0 ]
Select the power level Slide on the “SLIDER“ [ 1 ] to [ 9 ]
Select « Timer » Press on the [ ] [ 00 ]
Set the « Timer » Press on the [ ] [ 10, 20, 30...]
Slide on the “SLIDER“ [ 31, 32, 33...]
The time is confirmed and the cooking starts.
•To stop the cooking time:
Action Control panel Display
Zone selection Press on the “SLIDER“
across from the desired zone time remaining
Select the timer Press on the [ ] time remaining
Stop the timer Press on the [ ] [ 00 ]
•Automatic stop at the end of the cooking time:
As soon as the selected cooking time is finished, the timer displays blinking [ 00 ] , a sound rings
and the heating zone stops.
To stop the sound and the blinking it is enough to press the timer key [ ].
•Egg timer function:
Action Control panel Display
To start press the key [ ] [ 0 ]
Select « Timer » Press on the [ ] [ 00 ]
Set the « Timer » Press on the [ ] [ 10, 20, 30...]
Slide on the “SLIDER“ [ 31, 32, 33...]
After a few seconds, the timer display stops blinking.
« Keep warm » Function
This function allows reaching and maintaining automatically a temperature of 70°C.
•To engage, to start the function « Keep warm » :
Action Control panel Display
To engage press on the “SLIDER“
between the [ 0 ] and the [ 1 ] [ U ]
To stop Slide on the “SLIDER“ [ 0 ] to [ 9 ]

24
Automatic cooking
All the cooking zones are equipped with an automatic cooking device. The cooking zone starts
at full power during a certain time, and then reduces automatically its power on the preselected
level.
•Start-up
Action Control panel Display
Power level selection Slide to the position [ 7 ] and stay 3s [ 7 ] Is blinking
(For example « 7 ») with [ A ]
•Switching off the automatic cooking
Action Control panel Display
Power level selection Slide on the “SLIDER“ [ 0 ] to [ 9 ]
Pause function
This function brakes the entire hob’s cooking activity and allows restarting with the same
settings.
•Start up / Stop the pause function
Action Control panel Display
Engage Pause Press [ ] key 3s. displays [ II ] in
the heating zone
displays
Stop the Pause Press [ ] key 3s.
and on the slider Last settings
Selected power Automatic cooking
time (Min:S)
100:48
202:24
303:36
405:24
506:48
602:00
702:48
803:36
9- : -

25
Recall Function
After switching off the hob ( ), it is possible to recall the last settings.
•cooking stages of all cooking zones (power)
•minutes and seconds of programmed cooking zone-related timers
•Heat up function
The recall procedure is following:
•Press the key [ ]
•Then press the key [ ] within 6 seconds
The precedent settings are activated.
Control panel locking
To avoid modifying a setting of cooking zones, in particular with within the framework of
cleaning the control panel can be locked (with exception to the On/Off key [ ]).
•Locking
Action Control panel Display
To start press the key [ ] [ 0 ] or [ H ]
Hob locking Hold a finger on the [ ]
and press 3 times on the [ ] [ L ]
•Unlocking
Action Control panel Display
To start press the key [ ] [ L ]
Unlocking the hob Hold a finger on the [ ]
and press 3 times on the [ ] [ 0 ] or [ H ]
Operating time
Each cooking zone is equipped with an operating time limitation: the cooking zone is automatically
switched off after a certain time without any change of settings. This time is varying according to
the selected power level as described in the table below.
Power level Max operating time
(hours)
16
26
35
45
54
61,5
71,5
81,5
91,5

26
COOKING ADVICES
Examples of power setting
(The values below are indicative)
1 to 2 Melting, Reheating Sauces, butter, chocolate, gelatine
Dishes prepared beforehand
2 to 3 Simmering, Defrosting Rice, pudding, sugar syrup
Dried vegetables, fish, frozen products
3 to 4 Steam Vegetables, fish, meat
4 to 5 Water Steamed potatoes, soups, pasta, fresh vegetables
6 to 7 Medium cooking, Simmering Meat, liver, eggs, sausages,
7 to 8 Cooking Potatoes, fritters, waffles
9 Frying, roasting, Boiling water Steaks, omelettes, fried dishes, water
MAINTENANCE AND CLEANING
Switch-off the appliance before cleaning.
Do not clean the hob if the glass is too hot because they are risk of burn.
•Remove light marks with a damp cloth with washing up liquid diluted in a little water.
Then rinse with cold water and dry the surface thoroughly.
•Highly corrosive or abrasive detergents and cleaning equipment likely to cause scratches
must be absolutely avoided.
•Do not ever use any steam-driven or pressure appliance.
•Do not use any object that may scratch the ceramic glass.
•Ensure that the pan is dry and clean. Ensure that there are no grains of dust on your
ceramic hob or on the pan. Sliding rough saucepans will scratch the surface.
•Spillages of sugar, jam, jelly, etc. must be removed immediately. You will thus prevent
the surface being damaged.
WHAT TO DO IN CASE OF A PROBLEM
The hob or the cooking zone doesn’t start-up:
•The hob is badly connected to the electrical system.
•The protection fuse has blown.
•The locking function is activated
•The sensitive keys are covered by grease or water.
•An object is covering the control panel.

27
The symbol [ E ] displays :
•Call the After-sales Service.
One or all cooking zones cut-off:
•The safety system has engaged
•You forgot to cut-off the cooking zone for a long time.
•One or more sensitive keys are covered.
•The pan is empty and has overheated.
The automatic cooking system « go and stop » doesn’t start-up:
•The cooking zone is still hot [ H ]
•The highest power level is set [ 9 ]
The symbol [ U ] displays :
•Refer to the chapter “keep warm“.
The symbol [ II ] displays :
•Refer to the chapter “Pause“.
The symbol [ L ] displays :
•Refer to the chapter control panel locking page.
ENVIRONMENT PROTECTION
•The packaging material is ecological and can be recycled.
•The worn appliances contain certain noble metals. Apply to the local government about
the possibilities of recycling.
•
Don't dispose of your appliance with
general household
waste
•Get in touch with the waste collection centre
of your local
council that control the recycling of household appliances.

28
INSTALLATION INSTRUCTIONS
The installation must be performed by a qualified electrical contractor. This contractor will take
the entire responsibility of the installation. The installation has to comply with the legislation and
the standards in force in your country.
How to stick the gasket:
The gasket supplied with the hob prevents the intrusion of liquids into the cabinet below.
Its installation has to be done carefully, as described below.
Fitting - installing:
•Cut out sizes of the worktop:
A B E F H
EKE8342.1ED 800 mm 520 mm 750 mm 490 mm 44 mm
•Ensure that there is a distance of 40 mm between the hob and the wall or sides.
•The hobs are classified as “Y” class for heat protection. Ideally the hob should be
installed with plenty of space on either side. There may be a wall at the rear and tall units
or a wall at one side. On the other side, however, no unit or divider must stand
higher than the hob.
Stick the gasket (2) two millimeters
from the external edge of the glass,
after removing the protection tape (3).

29
•The piece of furniture or the support in which the hob is to be fitted, as well as the edges
of furniture, the laminate coatings and the glue used to fix them, must be able to resist
temperatures of up to 75 °C.
•The mural rods of edge must be heat-resisting.
•Not to install the hob to the top of a not ventilated oven or a dishwasher.
•To guarantee under the bottom of the hob casing a space of 20 mm to ensure a good air
circulation of the electronic device.
•If a drawer is placed under the work, avoid to put into this drawer flammable objects (for
example: sprays) or not heat-resistant objects.
•Materials which are often used to make worktops expand on contact with water. To
protect the cut out edge, apply a coat of varnish or special sealant. Particular care must
be given to applying the adhesive joint supplied with the hob to prevent any leakage into
the supporting furniture. This gasket guaranties a correct seal when used in conjunction
with smooth work top surfaces.
•The safety gap between the hob and the cooker hood placed above must respect the
indications of the hood manufacturer. In case of absence of instructions respect a
distance minimum of 650 mm.
•The connection cord should not be subjected, after building-in, to any mechanical
constraint (for instance constraint given by a drawer installed below).
ELECTRICAL CONNECTION
•The installation of this appliance and the connection to the electrical network should be
entrusted only to an electrician perfectly to the fact of the normative regulations and
which respects them scrupulously.
•Protection against the parts under tension must be ensured after the building-in.
•The data of connection necessary are on the stickers place on the hob casing near the
connection box.
•The connection to the main must be made using an earthed plug or via an omnipolar
circuit breaking device with a contact opening of at least 3 mm.
•The electrical circuit must be separated from the network by adapted devices, for
example: circuit breakers, fuses or contactors.
•If the appliance is not fitted with an accessible plug, disconnecting means must be
incorporated in the fixed installation, in accordance with the installation regulations.
•The inlet hose must be positioned so that it does not touch any of the hot parts of the hob
or oven.

30
Caution!
This appliance has only to be connected to a network 230 V~ 50/60 Hz.
Connect always the earth wire.
Respect the connection diagram.
The connection box is located underneath at the back of the hob casing. To open the cover use
a medium screwdriver. Place it in the slits and open the cover.
* calculated with the simultaneous factor following the standard EN 60 335-2-6/1990
Connection of the hob
Setting up the configurations:
For the various kinds of connection, use the brass bridges which are in the box next the terminal
Monophase 230V~1P+N
Put a bridge between terminal 1 and 2.
Attach the earth to the terminate “earth”, the neutral N to terminal 4, the Phase L to one of the
terminals 1 or 2.
Biphase 400V~2P+N
Attach the earth to the terminate “earth”, the neutral N to terminal 4, the Phase L1 to the terminals 1
and the Phase L2 to the terminal 2.
Caution! Be careful that the cables are correctly engaged and tightened.
Mains Connection Cable diameter Cable Protection calibre
230V~ 50/60Hz 1 Phase + N 3 x 2.5 mm² H 05 VV - F
H 05 RR - F 25 A *
400V~ 50/60Hz 2 Phases + N 4 x 1.5 mm² H 05 VV - F
H 05 RR - F 16 A *
We cannot be held responsible for any incident resulting from incorrect connection
or
which could arise from the use of an appliance which has not been earthed or has been
equipped with a faulty earth connection.
